COMPACT DISC PLAYER
WITH AM/FM STEREO CASSETTE RECORDER
MODEL CD-2036
OPERATING INSTRUCTIONS
PLAYS ALL MUSIC COMPACT DISCS, CD-R & CD-RW
•
FULLY PROGRAMMABLE CD PLAYER WITH REPEAT
•
RECEIVES AM/FM STEREO BROADCASTS
•
RECORDS FROM CD, RADIO, OR BUILT-IN MICROPHONE
•
2 WAY POWER - AC/DC
•
USES 6 SIZE “D” BATTERIES (not included)
•
PLEASE READ CAREFULLY BEFORE USE
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM1
IB-CD2036(SY)-WM-E-010805
WARNING
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THE PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO REDUCE THE
RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO
RAIN OR MOISTURE. TO PREVENT ELECTRICAL SHOCK, MATCH WIDE BLADE
PLUG TO WIDE SLOT, FULLY INSERT.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with
arrowhead symbol, within an
equilateral triangle, is intended
to alert the user to the
presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may
be of sufficient magnitude to
constitute a risk of electric
shock to persons.
WARNING: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USER
SERVICEABLE PARTS INSIDE.
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
The exclamation point within
an equilateral triangle is
intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the
appliance.
SEE BOTTOM OF THE SET
IMPORTANT SAFETY INSTRUCTIONS
1.Read these instructions.
2.Keep these instructions.
3.Heed all warnings.
4.Follow all instructions.
5.Do not use this apparatus near water.
6.Clean only with dry cloth.
7.Do not block any ventilation openings, install in accordance with the manufacturer’s
instructions.
8.Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9.Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10.Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11.Only use attachments/accessories specified by the manufacturer.
12.Unplug this apparatus during lightning storms or when unused for long periods of time.
13.Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally or
has been dropped.
14.This appliance shall not be exposed to dripping or splashing water and that no
object filled with liquid such as vases shall be placed on the apparatus.
1
IB-CD2036(SY)-WM-E-010805
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM2
IMPORTANT SAFETY INSTRUCTIONS
15.Power Sources - This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company. For products intended to
operate from battery power, or other sources, refer to the operating instructions.
16.Overloading - Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
17.Servicing - Do not attempt to service this product yourself as opening or removing
covers may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
18.Safety Check - Upon completion of any service or repairs to this product, ask the
service technician to perform safety checks to determine that the product is in proper
operating condition.
It is the intent of Lenoxx that this product be used in full compliance with the
copyright laws of the United States and that prior permission be obtained from
copyright owners whenever recording songs from the RADIO or CD’s.
Do not apply oil or petroleum products or solvents to any part of this set.
Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
This compact disc player is classified as CLASS 1 LASER PRODUCT as stated
on the bottom of the set.
Please read important information displayed on the rating plate located on the
bottom enclosure before connecting to AC Mains or any operation.
CAUTION
2
IB-CD2036(SY)-WM-E-010805
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM3
BATTERY SAFETY INSTRUCTIONS
CAUTION: TO REDUCE THE RISK OF FIRE OR PERSONAL INJURY OR DAMAGE
1.Use only the type and size of batteries mentioned in the operating instructions booklet
2.Do not dispose the batteries into a fire. The cells may explode. Check with local
3.Do not open or mutilate the batteries. Released electrolyte is corrosive and may
4.Be careful when handling batteries in order not to short the battery with conducting
5.Do not attempt to recharge non-rechargeable batteries. The batteries may leak
6.Do not attempt to rejuvenate the batteries identified for use with this product by
7.All batteries should be replaced at the same time. Mixing fresh and discharged
8.When inserting batteries into this product, the proper polarity ( and ) or direction
9.Remove the batteries from this product if the product will not be used for a long period
10.Discard weak or dead batteries as soon as possible since they are more likely to leak
11.Do not store this product in high temperature areas. Batteries that are stored in a
12.If this product does not operate normally, see TROUBLE SHOOTING in this
13.If liquid leaks from the batteries, carefully wipe this liquid. Do not allow it to touch
14.Do not mix batteries (OLD and NEW or CARBON and ALKALINE, etc.).
15.The use of rechargeable batteries is not recommended for this set because their
16.Installation of batteries should be done by an adult only.
TO YOUR SET, READ AND FOLLOW THESE INSTRUCTIONS.
(batteries are not included with this set, please buy the proper batteries).
codes for possible special disposal instructions.
cause damage to the eyes or skin. It may be toxic if swallowed.
materials such as rings, bracelets and keys. The battery or conductor may over heat
and cause burns.
corrosive electrolyte or explode.
heating them. Sudden release of the battery electrolyte may cause burns or irritation
to eyes or skin.
batteries could increase internal cell pressure and rupture the batteries.
must be observed. Reverse insertion of some or all of the batteries may result in
battery electrolyte leakage or explosion.
of time (several months or more) since during the period the batteries could leak,
damaging the product.
in the product. Batteries should be replaced (depending on the product) when the
display gets dim or if the Low Battery Indicator shows or if the sound gets distorted.
freezer or refrigerator for the purpose of extending shelf life should be protected from
condensation during storage and defrosting. Batteries should be stabilized at room
temperature prior to use after cold storage.
instruction manual. If you can’t resolve the problem, or if the product is damaged,
refer to the LENOXX WARRANTY INFORMATION. Opening or removing covers
may expose you to dangerous voltages or other risks. Incorrect reassembly can
cause electric shock when the appliance is subsequently used.
your skin, and discard the leaking batteries.
voltage and life is lower than standard batteries.
SAVE THESE INSTRUCTIONS
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM4
3
IB-CD2036(SY)-WM-E-010805
CHOOSING THE POWER SOURCES
D
You can use the AC power or batteries as a power source.
To a wall outlet
BATTERY DOOR
(on the bottom of the set)
TIP
If the plug of the AC power
•
cord does not match your
outlet, do not force it.
Reverse it and try again.
The plug is polarized and
only fits one way into the
wall outlet.
Replace the batteries
•
when the POWER lamp
dims or when the player
stops operating. Replace
all the batteries with new
ones. Before you replace
the batteries, be sure to
take out the CD from the
player and remember to
check the Battery Safety
Instructions on Page 3.
If the CD does not play on
•
batteries, this means the
batteries are almost used
up. But the radio may
continue to play on these
weak batteries because it
uses less power than the
CD player.
NOTE:One blade of plug
and outlet is wider.
1.Connecting the AC power
Insert one end of the supplied AC power cord into
the socket located at the rear of the set, and the
other end into the 120V, 60Hz standard household
outlet.
2.Using the player on batteries
Insert 6 size “D” batteries (not supplied) into the
battery compartment as shown, observe + and polarities.
To use the player on batteries, disconnect the AC
power cord from both the wall outlet and the back of
the player.
D
D
DD
D
D
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM5
Install Batteries as illustrated
4
IB-CD2036(SY)-WM-E-010805
PLAYING A CD
PLAY
PAUSE
REPEAT
PROG.
REPEAT
PROG.
REPEAT
PROG.
FUNCTION
switch
(at the left side of the set)
Connect the supplied AC power cord or batteries (refer to page 4).
1
FUNCTION POWER
TAPE/OFF
RADIO
2
Lift here to open the
CD door
PLAY/PAUSE
button
Slide the FUNCTION
switch to CD position
CD
(power on), the POWER
lamp will be on, the display
will show 2 dashes “ ”
FM ST.
PLAY/
PAUSE
flashing, then “ ”.
Lift the either side of the
CD DOOR to open it and
place a CD in the CD
compartment. The label
side of the CD should face
upward.
3
Close the CD DOOR by
pushing it down. The
display will show the total
POWER
FM ST.
tracks of that CD.
4
Press the CD PLAY/
PAUSE button, the PLAY/
PAUSE lamp will be
steadily on, the player will
POWER
FM ST.
play all the music tracks
once.
Track number
TIP: “ ” will show in the display if there is no CD disc in the CD compartment or the
CD disc was inserted upside down.
5
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM6
IB-CD2036(SY)-WM-E-010805
PLAY/
PAUSE
PLAY/
PAUSE
USE THESE BUTTONS FOR
REPEAT
PROG.
ADDITIONAL OPERATIONS
POWER
FM ST. PLAY/
TIP
When CD play is
•
paused, the PLAY/
PAUSE lamp will flash
and no music will play.
To resume play, press
•
the PLAY/PAUSE
button again, the
PLAY/PAUSE lamp will
stop flashing and
music will play.
If you bump the set
•
during CD play, the
music will stop or skip
for a few seconds.
This is normal for this
type of player.
PAUSE
VOLUME
scale
VOLUME
control
PHONES jack
STOP button
SKIP/SEARCH
buttons
To
Adjust the volume
Stop playback
Pause playback
Go to the next track
Go back to the previous
track
Locate a point in a song
To enjoy the music
without disturbing others.
Remove the CD
Turn off the power
Lift here to open the
CD door
PLAY/PAUSE
button
Press or Adjust
VOLUME control
STOP button
PLAY/PAUSE button
The PLAY/PAUSE lamp will
flash during pause. Press
again to resume play after
pause.
SKIP/SEARCH
FORWARD button
SKIP/SEARCH
BACKWARD button
or
Press and hold down while
playing until you find the point
of the song you want.
Insert your headphones (not
included) plug into the
PHONES jack.
Press the STOP button first,
then lift the CD DOOR.
Slide the FUNCTION switch
to TAPE/OFF position, the
AC power lamp goes off.
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM7
6
IB-CD2036(SY)-WM-E-010805
PLAYING CD TRACKS REPEATEDLY
REPEAT
PROG.
REPEAT
PROG.
REPEAT
PROG.
(REPEAT PLAY)
You can play CD tracks over and over in normal or programmed play mode (refer to
page 8).
FUNCTION
switch
SKIP/SEARCH buttons
REPEAT button
PLAY/PAUSE button
1. Slide the FUNCTION switch to CD position, the POWER lamp will be steadily on.
2. Select the track by pressing or , and then press .
3. Press the REPEAT button.
To repeat
A single track (song)
All the tracks (all songs)
on this disc
Press
Press the REPEAT button
once, the REPEAT lamp will
flash.
Press the REPEAT button
twice, the REPEAT lamp will
be steadily on.
Display shows
POWER
FM ST. PLAY/
POWER
FM ST.
PAUSE
PLAY/
PAUSE
During programmed play,
Programmed tracks
press the REPEAT button
twice, both the REPEAT
and PROG. lamps will be
steadily on.
POWER
FM ST.
PLAY/
PAUSE
To cancel Repeat Play
Press the REPEAT button until the REPEAT lamp goes off.
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM8
7
IB-CD2036(SY)-WM-E-010805
PLAYING CD TRACKS IN PROGRAMMED ORDER
SKIP/SEARCH
REPEAT
REPEAT
PROG.
REPEAT
PROG.
You can make a program of up to 20 tracks in the order you want them to be played.
REPEAT
PROG.
PLAY/
PAUSE
REPEAT
PLAY
PAUSE
PLAY/PAUSE
STOP button
STOP
POWER
FM ST.
PROGRAM
button
PROGRAM button
REPEAT button
SKIP/SEARCH buttons
1.Slide the FUNCTION switch to CD position.
Make sure the CD is stopped.
2.Press the PROGRAM button. The letters “ ”
and the PROG. lamp will flash.
3.Press or to select the track you want to
POWER
FM ST. PLAY/
PROG.
PAUSE
program in the order you want. The track
number you selected will be steadily on and the
PROG. lamp will flash.
4.Press the PROGRAM button to confirm. The letters
POWER
FM ST.
PLAY/
PAUSE
“ ” and the PROG. lamp will flash.
5.Repeat above steps 3 and 4. You can program up
to 20 tracks, then the display will show the tracks
number you programmed, and the PROG. lamp
will flash.
6.Press to start programmed play. The PROG.
lamp will be steadily on.
POWER
FM ST.
PLAY/
PAUSE
NOTE:
1.Programming can only be done while in STOP mode.
2.The programmed memory will be lost if the STOP button is pressed twice or the power
is shut off, or the CD door is opened.
To change the current program
Just create a new program following the programming procedure.
To cancel Programmed Play
Press the STOP button, then slide the FUNCTION switch to TAPE/OFF position.
8
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM9
IB-CD2036(SY)-WM-E-010805
LISTENING TO THE RADIO
TUNING
REPEAT
PROG.
AM/FM dial scale
FUNCTION
switch
FM ST. lamp
(FM STEREO)
Connect the supplied AC power cord or batteries (refer to page 4).
1
2
3
POWER
4
FM ST.
FUNCTION
TAPE/OFF
RADIOCD
BAND
FM
FM ST. AM
PLAY/
PAUSE
TUNING
control
BAND
switch
Slide the FUNCTION switch to
RADIO position, the POWER
lamp will turn on.
Slide the BAND switch to the
proper band position (AM, FM, or
FM ST.) that you want.
Tune into the station you prefer
using the TUNING control. Adjust
for the clearest sound.
The FM stereo indicator will light
up when receiving an FM Stereo
broadcast.
FUNCTION
TAPE/OFF
5
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM10
RADIOCD
To turn the set off, slide the
FUNCTION switch to TAPE/OFF.
9
IB-CD2036(SY)-WM-E-010805
USE THESE BUTTONS FOR
ADDITIONAL OPERATIONS
TIP
If the FM broadcast is
•
noisy, slide the BAND
switch from FM Stereo
to FM.
Next time you want to
•
listen to the radio, just
slide the FUNCTION
switch to RADIO
position. The set
will automatically play the
previously tuned station.
FUNCTION switch
(at the left side of the set)
VOLUME
control
To
Adjust the volume
Turn off the Radio
Slide or Adjust
VOLUME control
Slide the FUNCTION
switch to TAPE/OFF
position
FM antenna
To improve broadcast reception
Change position of the antenna for FM or FM Stereo.
Move the set itself to improve AM reception.
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM11
10
IB-CD2036(SY)-WM-E-010805
PLAYING A TAPE
OK
NO
OK
NO
INSERT TAPE THIS WAY
FULL
REEL
REEL
TAPE PLAY DIRECTION
A
STOP/EJECT button
FUNCTION switch
(at the left side of the set)
Connect the supplied AC power cord or batteries (refer to page 4).
PLAY button
1
2
3
4
FUNCTION
TAPE/OFF
RADIO
STOP/EJECT
PLAY
AUTO STOP
Slide the FUNCTION
switch to TAPE/OFF
CD
position.
Press the STOP/
EJECT button to open
the tape compartment
and insert a recorded
tape, then close the
door.
Press the PLAY button,
the player turns on and
starts playing.
When the set finishes
playing one side of the
tape, the set will
automatically stop. To
hear the other side of the
tape, flip the tape over,
then insert and press
PLAY.
EMPTY
FULL REEL ON RIGHT
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM12
11
IB-CD2036(SY)-WM-E-010805
RECORDING ON A TAPE
OKNOOK
NO
INSERT TAPE THIS WAY
FULL
REEL
REEL
TAPE PLAY DIRECTION
A
STOP/EJECT
button
FUNCTION switch
(at the left side of the set)
Connect the supplied AC power cord or batteries (refer to page 4).
F.FWD
button
REWIND
button
PLAY button
RECORD
button
Built-in
microphone
1
2
3
4
STOP/EJECT
FUNCTION
TAPE/OFF
RADIO
OR
FUNCTION
TAPE/OFF
RADIOCD
OR
FUNCTION
TAPE/OFF
RADIOCD
PLAY
REWIND
CD
RECORD
PLAY
Press the STOP/EJECT button to
open the tape compartment and
insert a blank tape. Select the
program source (AM, FM, CD, or
built-in microphone) you want to
record.
To record from the CD player. Slide
the FUNCTION switch to CD
position, and insert a CD, then follow
the CD playing steps to play.
To record from a radio. Slide the
FUNCTION switch to RADIO
position, and tune into the station
that you want.
To record from the built-in
microphone, slide the FUNCTION
switch to the TAPE/OFF position,
and speak in front of the set.
Press the RECORD button to start
recording. (The PLAY button is
depressed automatically.)
To hear what you recorded, slide
the FUNCTION switch to TAPE/
OFF position, then press REWIND
and PLAY buttons.
EMPTY
FULL REEL ON RIGHT
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM13
12
IB-CD2036(SY)-WM-E-010805
USE THESE BUTTONS FOR ADDITIONAL
OPERATIONS
STOP/EJECT
PAUSE button
FUNCTION switch
(at the left side of the set)
button
VOLUME
control
PHONES
JACK
Connect the supplied AC power cord or batteries (refer to page 4).
To Press or Adjust
Adjust the volume
F.FWD
button
REWIND
VOLUME control
button
PLAY button
RECORD
button
Stop playback or recording
Fast forward or rewind the tape
Pause playback or recording
Eject the cassette
To enjoy the music without
disturbing others
To shut power off
STOP/EJECT button
FAST FORWARD or REWIND button
PAUSE button
Press again to resume play or recording after
pause
STOP/EJECT button
Insert your headphones plug into the PHONES
jack (HEADPHONES not included)
Make sure cassette buttons are all up (stop)
and the power lamp is turned off
13
IB-CD2036(SY)-WM-E-010805
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM14
PRECAUTIONS
On Safety
As the laser beam used in the CD player
•
section may be harmful to the eyes, do
not attempt to disassemble the cabinet.
Refer servicing to qualified personnel
only.
Should any solid object or liquid fall into
•
the player, unplug the player, and have it
checked by qualified personnel before
operating it any further.
On Placement
Do not leave the player in a location
•
near a heat source, or in a place subject
to direct sunlight, excessive dust or
mechanical shock.
Do not place the player on an inclined
•
or unstable place.
Do not place anything within 1 inch of the
•
back of the cabinet. The ventilation holes
must not be covered for the player to
operate properly and prolong the life of
its components.
If the player is left in a car parked in the
•
sun, be sure to choose a location in the
car where the player will not be subjected
to the direct rays of the sun.
Since a strong magnet is used for the
•
speakers, keep personal credit cards
using magnetic coding or springwound
watches away from the player to prevent
possible damage from the magnets.
On Power Sources
For battery operation, use 6 size “ D”
•
batteries. We recommend alkaline
batteries for longer life.
When the batteries will not be used for a
•
few weeks or more, remove them to avoid
damage that can be caused by battery
leakage or corrosion.
On Operation
If the player is brought directly from a
•
cold to a warm location, or is placed in a
very damp room, moisture may condense
on the lens inside the CD player section.
Should this occur, the player will not
operate properly. In this case, remove
the CD and wait about an hour for the
moisture to evaporate. If the player has
not been used for a long time, set it in
playback mode to warm it up for a few
minutes before inserting a cassette.
This CD player is designed to be played
•
on a stable no vibration position. If you
bump the set during CD play, the music
will stop or skip for a few seconds. This
is normal for this type of player.
Notes on CDs
Before playing, clean the CD with a
•
cleaning cloth. Wipe the CD from the
center out.
Do not use solvents such as benzine,
•
thinner, commercially available cleaners
or anti-static spray intended for vinyl LPs.
Do not expose the CD to direct sunlight
•
or heat sources such as hot air ducts,
nor leave it in a car parked in direct
sunlight as there can be a considerable
rise in temperature inside the car.
Do not stick paper or stickers on the CD,
•
nor scratch the CD.
After playing, store the CD in its case. If
•
there is a scratch, dirt or fingerprints on
the CD, it may cause a tracking error or
skipping.
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM15
14
IB-CD2036(SY)-WM-E-010805
Notes on Cassettes
RECORD/PLAYBACK HEAD
CAPSTAN
COTTON SWAB
Break off the cassette tab from side A or
•
B to prevent accidental recording.
Side A
Cleaning the Tape Head
Wipe the tape head, the pinch roller and
the capstan with a cleaning swab slightly
moistened with cleaning fluid or alcohol
after every 10 hours of operation for
optimum playback and recording quality.
After cleaning, insert a tape when the
areas cleaned are completely dry.
Tab for side B
To record on a tape with its tab broken off,
•
cover the respective tab hole for side A
or B with adhesive tape.
Use of a cassette with more than 90
•
minutes, such as C-120 (120
minutes), is not recommended. The
extreme thinness of this tape may
damage this set.
To reduce the chances of tape jamming
•
or tangling, you should check that there
are no loose layers of tape visible
through the cassette center window. If
any, tighten these loose layers of tape
using a pencil before inserting the
cassette into the set.
Tab for side A
MAINTENANCE
Cleaning the Lens
If the lens becomes dirty, it may cause a
skipping of sound during CD operation.
Clean with a commercially available lens
cleaner and blower.
PINCH ROLLER
NOTE: In order to see and clean the tape
head, you may have to press
PLAY first.
ERASE HEAD
Notes for Storing
Cassette Tape
1. Do not put a tape near a magnetic field,
such as a TV, or speaker. Magnetic
fields may reduce the tape sensitivity or
even erase the recording.
2. Do not store tape for any length of time
in a hot, moist or dusty place.
Cleaning the Cabinet
Clean the cabinet, panel and controls with
a soft cloth slightly moistened with a mild
detergent solution. Do not use any type
of abrasive pad, scouring powder, or
solvent, such as alcohol or benzine.
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM16
15
IB-CD2036(SY)-WM-E-010805
TROUBLE SHOOTING
Problem
The power is not on.
There is no sound.
General
“ ” appears in the display
even when a CD is in place.
CD does not play.
CD player
The sound drops out.
CD does not play while radio may
continue to play.
The sound is weak or has poor
quality.
Radio
The RECORD button does not
function/The tape does not play.
The tape does not erase
completely.
The tape does not record.
Tape jamming or tangling.
Tape player
The sound is weak/The sound
quality is poor.
Cassette PLAY button pops up.
Remedy
Insert the AC plug into a wall outlet securely.
•
Make sure the batteries are installed correctly and they
•
are fresh.
Make sure the FUNCTION switch is at the right position
•
as you want.
Adjust the volume.
•
Unplug the headphones when listening through
•
speakers.
Insert the CD with the label side up.
•
Make sure that the CD compartment is closed.
•
Clean the CD.
•
Replace the disc (this set will not play damaged or
•
scratched CDs), or buy a disc repair polisher to repair it
yourself.
Take out the CD and leave the CD DOOR open for about
•
an hour to dry moisture condensation.
Make sure the FUNCTION switch is at CD position.
•
Clean the CD, or replace it if the CD is badly
•
damaged.
Place the player in a location free from vibration.
•
Check if your batteries are fresh.
•
It is normal since the radio uses less power than the CD
•
player.
Replace all the batteries with new ones if they are weak,
•
or bring the set near a window, or rotate the set.
Make sure the safety tab on the cassette is
•
in place.
Make sure the FUNCTION switch is at TAPE/OFF
•
position.
Clean the erasing head.
•
Replace all the batteries with new ones if they are weak.
•
Make sure the tape is inserted properly.
•
Make sure the safety tab of the cassette is in place.
•
Use only better quality tapes.
•
Do not use a cassette with more than 90 minutes.
•
Make sure there are no loose layers of tape visible before
•
inserting the cassette.
Clean the heads, pinch roller and capstan.
•
The tape has reached its end. Remove it, flip to the other
•
side and re-insert.
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM17
16
IB-CD2036(SY)-WM-E-010805
SPECIFICATION
General Description
Power source:
Output power:
Dimensions:
CD Section
Plays disc type: Any normal music CD used in portable players, including CD-R & CD-RW.
Laser wavelength:
Tracking method:
Frequency response:
Tape Recorder Section
Frequency response: Standard normal bias cassette tape
Radio Section
Frequency range:
Lenoxx reserves the right to make design and specification changes for product improvement.
PROTECT YOUR FINE FURNITURE!
WE RECOMMEND A CLOTH OR OTHER PROTECTIVE MATERIAL BE PLACED UNDER THE SET
WHEN PLACING IT ON SURFACE WITH A NATURAL OR LACQUER FINISH.
We warrant this product to be free from defects in material and workmanship under normal use for a
period of 90 days after purchase and we will repair it free of charge or replace it at no charge, should it
become defective under this warranty, providing you submit proof of purchase (sales slip) with the set.
During the initial 90 day period after original purchase, we will service or exchange, at no charge, the
set that is returned to LENOXX ELECTRONICS CORP. After the initial 90 day period expires, and for a
period of 12 months from original purchase, we will repair the unit covering any part(s) that need to be
replaced at no charge, but will charge for the cost of labor, return postage paid by Lenoxx.
This warranty does not apply to any products which have been subject to misuse, neglect or accident.
This warranty does not cover broken cord or cabinet. UNDER NO CIRCUMSTANCES WILL LENOXX
ELECTRONICS CORP. BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some
states do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitations or exclusions may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state. The following charges apply to repairs beyond the warranty period: $12.00. Be sure to pack
carefully and return postage paid insured together with your money order (personal checks will not be
accepted) and sales receipt to:
LENOXX ELECTRONICS CORP., 2 GERMAK DRIVE, CARTERET N.J. 07008
Dial 1-800-315-5885
AC 120V, 60Hz,
DC 9V (6 size “D” batteries, not included)
(Alkaline batteries are recommended)
1.5W/channel
Width: 15 1/2”
Depth: 9 1/8”
Height: 6 3/8”
Weight: 4.4 lbs (without batteries)
760 - 800 NM
3 - spot error detection 3.86 mm lens
50Hz - 15kHz +1/-2dB
70Hz - 10kHz
FM: 88 - 108 MHz
AM: 530 - 1700 kHz
LIMITED WARRANTY
For customer service
(MONDAY - THURSDAY 9:00 AM - 5:00 PM, FRIDAY 9:00 AM - 1:00 PM EST)
or Visit Our Website: http://www.lenoxx.com
© 2005 LENOXX ELECTRONICS CORP.
2 GERMAK DRIVE
CARTERET, N.J. 07008
MADE & PRINTED IN CHINA
17
IB-CD2036(SY)-WM-E-010805
IB-CD2036(SY)-WM-E-010805.PMD 2/23/2005, 2:38 PM18
Loading...
