Lenoxx MP-555 Instruction

QUICK INSTRUCTIONS

VOL

POWER

MP-555 MP3 / WMA PLAYER

For detailed instructions, please see the full instruction
manual in the Driver Setup disc.

1. CHECK LIST

BASS

1

01:22/05:36001/288

MP3 player USB cable

Driver setup disc for
Installation (for older
Windows 98SE), also
includes Windows
Media Player 9/10,
Adobe PDF Reader, and
full instruction manual

1 size AAA

alkaline battery

Stereo

earphones

2. GETTING STARTED

1.Open the battery door in the rear.

2.Place an AAA size battery into the
battery compartment, observe and

polarities.

3.Connect the earphones into the player.

4.Press and hold the POWER button
several seconds to turn on the MP3
player.

VOL

1

BASS

I love you

01:22/05:36001/288

1

QI-MP555-WC-E-020507

3. COPYING AND STORING SONGS TO THE MP3 PLAYER

A. Connecting the MP3 player to your

computer

Open the rubber USB cover on your MP3
player and connect the USB cable to the
computer’s USB jack and the MP3 player.

If your computer’s operating system is
Windows 98SE, insert the driver setup
disc into the CD drive of your computer
to install the software driver. (If your
computer’s operating system is Windows
Me or XP or later, there is no need to
install the software driver, go to step B.)

The computer screen will display the

•

MP-555 menu.

Click “Windows 98SE Driver”, ONLY if

•

you are using Windows 98SE (Windows
Me/2000/XP doesn’t need driver

installation).

Click “Windows Media Player” to install

•

the Windows Media Player on your
computer.

Click “Adobe Acrobat Reader” to install

•

the Adobe Acrobat Reader software.

NOTE: If you have Windows 98SE
system, you will need to download
Adobe Acrobat Reader version 6.0.1
from www.adobe.com if you don’t have
that installed on your computer yet.
Windows 98SE system doesn’t support
Adobe 6.0.2 or later versions.

Click “Instructions” to read or print the

•

instruction booklet on using Adobe
Reader.

Click “Exit” to go back to Windows

•

Desktop screen.

B. Storing Music Files onto the MP3

player

Click the “My Computer” icon from the
Windows Desktop screen, an “MP-555”
icon will be added to the “Devices with
Removable Storage” section.
Simply drag and drop (or copy and paste)
music files to the MP-555. The MP3 player
will have the songs you loaded (copied)
ready to play.

NOTE 1:

This player does not support DRM­protected files (such as music
downloaded from some online music
stores).

NOTE 2:

If you cannot download music from the
web site to the MP3 player directly, please
download the music to the computer and
then copy the music to the MP3 player.

NOTE 3:

This player can also be used as a
removable drive (also known as a USB
flash drive). You can drag and drop files
into the player. (Up to the limit of about
1GB for internal memory.)

2

QI-MP555-WC-E-020507

4. DISCONNECTING THE MP3 PLAYER FROM YOUR COMPUTER

For Windows Me/2000/XP users, the MP3 player can be disconnected safely by
following these instructions:

1.Click the “Safely Remove Hardware” icon in the Windows Toolbar (on the bottom
right corner near the clock icon on your computer).

2.From the list of Hardware Devices, select the player.

3.Click “Stop” button.

4.Click “OK” to confirm.

5.Click “Close” after finished.

6.Now, it is safe to disconnect the player.

Click on this icon to disconnect the
USB cable safely.

CAUTION: Do not disconnect MP3 player from the computer
while data transfer is in progress, some data may be lost.

3

QI-MP555-WC-E-020507

5. DEVICE AND LCD OVERVIEW

01:22/05:36

VOL

1

MINI-USB PORT (UNDER RUBBER COVER)

neck strap, backpack bag or

anything else that has a loop.

01:32/04:01 001/012

Current track total time

EQ SETTING

more bars equal more life

More steps mean louder volume

DEVICE OVERVIEW

Links to your PC or laptop by USB cable

Connects to the earphones with 3.5mm plug

VOLUME BUTTONS

Turns player on or off

HANGING CLASP SWITCH

BATTERY COMPARTMENT

STEREO EARPHONES JACK

Equalizer and menu selection

Adjust the volume

POWER BUTTON

Locks the controls

MODE SWITCH

LOCK BUTTON

Slide to open the

hanging clasp

Requires 1 size

AAA-Alkaline battery

LCD OVERVIEW

LCD SCREEN

Displays current status

BASS

001/288

PLAY/PAUSE BUTTON

Controls player play,
pause and stop

HANGING CLASP

Hang the player to your

BACK COVER

Remove to install battery

Current EQ mode

REPEAT SETTING

Normal, repeat one track,

repeat all, random

PLAY STATUS ICON

Play/pause/stop

SONG TITLE

Song title display

MUSIC PLAYING TIME

Current track playing time

TRACK TIME

VOL

1

I LOVE YOU

4

VOLUME LEVEL

LOCK INDICATOR

Shows when lock is on

BATTERY LEVEL

Battery life indicator,

TOTAL TRACK
NUMBER

TRACK NUMBER

Current track number

QI-MP555-WC-E-020507

6. START TO PLAY MUSIC

+

MusicList

1.To turn the player on, press and hold the POWER button , the set will be turned
on and start to play.

2.To turn the player off, press and hold the POWER button until the player is off.

3.To adjust the volume, press the VOLUME – or VOLUME + button.

4.To play the current track, press the PLAY/PAUSE button.

5.To pause playback, press the PLAY/PAUSE button.

6.To stop playback, press and hold the PLAY/PAUSE button.

7.To skip to your favorite music during play, turn the MODE switch left or right.

8.To fast forward the music, turn the MODE switch to the right and hold.

9.To rewind the music, turn the MODE switch to the left and hold.

10.Equalizer selection: Press the MODE switch to select from the 6-band EQ mode:

Normal, Bass, Jazz, Rock, Pop, Classical.

11.To lock the buttons, slide the lock button to the locked position and the lock icon
will appear in the display. To unlock, slide the lock button to the unlocked position

.

7. MENU OPERATIONS

1.You can perform the operations in the menu by

following these instructions.
a.Press and hold the MODE switch to enter the

SETUP menu.

b.Turn the MODE switch left or right to select the

option you want.
c.Press the MODE switch to confirm.
d.Press and hold the MODE switch to exit.

+

Push Turn left Turn right

5

QI-MP555-WC-E-020507

2.The menu has many submenus and choices you may select. Here is a list of the options.

MUSIC LIST :

Includes a variety of ways to browse and play your music. During selection, you can
press the PLAY/PAUSE button to return to the previous menu.

a.Play All: Plays all songs on the player in order.
b.Artist: Lists all the artists on the player.
c.Album: Lists all albums on the player.
d. Genre: Lists all genres on the player.

e. Songs: Lists all the songs on the player.

EQUALIZER :

NORM (normal), Bass, Jazz, Rock, Pop, Classical.

+

PLAY MODE

+

:

Play mode setting.

a. Normal (no mark): Plays all the songs in sequence, and the player will be

automatically turned off when all the songs have been played.
b.Repeat 1: Plays one song over and over.
c.Repeat all: Plays all the songs then repeats them over again, until you press and

hold the PLAY/PAUSE button to turn the player off.
d.Random: Plays all the songs in random order, and the player will be automatically

turned off when all the songs have been played.

LANGUAGE :

Setting the LCD display language (English, Spanish, French).

MEMORY INFORMATION :

Viewing the memory size and the firmware version.

EXIT :

Exit the menu.

Please see the operating instructions on the driver setup disc for more details.

6

QI-MP555-WC-E-020507

EIA

EST.1924

8. USING THE HANGING CLASP

/
2
8
8

0
1
:
2
2
/
0
5
:
3
6

0
0
1
/
2
8
8

B
A
S
S

V
O
L

1

You can hang the MP3 player to your neck using any neck strap, or you can attach it to
your belt loop or backpack bag with the hanging clasp.

1.Slide the hanging clasp switch downward
and hold to open it.

2.Insert the neck strap or some available loop

01:22/05:36 001

1

BAS S

VOL

on your dress or bag through the open slot.

3. Release the hanging clasp switch.

CAUTION

For your comfort, health and safety, be sure to observe
the following guidelines when you listen to the music
using the earphones.

1.Do not play your MP3 player at a high volume. Hearing

experts advise against continuous extended play.

2.If you experience a ringing in your ears, reduce the volume or discontinue use.

3.Do not use while operating a motorized vehicle. It may create a traffic hazard and is

illegal in many areas.

4.You should use extreme caution or temporarily discontinue use in potentially hazardous

situations.

5.Even if your earphones are the open-air type designed to let you hear outside sounds,

do not adjust thevolume too high so that you can hear what is around you.

6.Sounds can be deceiving. Over time your hearing “comfortable level” adapts to higher

volumes of sound. So what sounds “normal” can actually be loud and harmful to
your hearing. Guard against this by setting your equipment at a safe level before
your hearing adapts.

TO ESTABLISH A SAFE LEVEL:

• Start your volume control at a low setting.

• Slowly increase the sound until you can hear it at a comfortable and clear level, and

without distortion.

Once you have established a comfortable sound level: Leave it there.

7

QI-MP555-WC-E-020507

LIMITED WARRANTY

We warrant this product to be free from defects in material and workmanship
under normal use for a period of 1 year after purchase and we will repair it free of
charge or replace it at no charge, should it become defective under this warranty,
providing you submit proof of purchase (sales slip) with the set.

During the initial 1 year period after original purchase, we will service the set
that is returned to LENOXX ELECTRONICS CORP, prepaid, at no charge. After
the initial 1 year period expires, we will exchange, at no charge, any part that is
defective, but will charge for the cost of labor, return postage paid by Lenoxx.

This warranty does not apply to any products which have been subject to
misuse, neglect or accident. This warranty does not cover broken earphones or
cabinet. UNDER NO CIRCUMSTANCES WILL LENOXX ELECTRONICS CORP.
BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES. Some
states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitations or exclusions may not apply to you.

This warranty gives you specific legal rights, and you may also have other
rights which vary from state to state. The following charges apply to repairs beyond
the warranty period: $30.00. Be sure to pack carefully and return postage paid
insured together with your money order (personal checks will not be accepted)
and sales receipt to: LENOXX ELECTRONICS CORP., 35 BRUNSWICK AVENUE,
EDISON, N.J. 08817, USA

We reserve the right to make design and specification changes for product improvement.
The descriptions and characteristics given in this document are given as a general

indication and not as a guarantee. In order to provide the highest quality product possible,
we reserve the right to make any improvement or modification without prior notice.
The English version serves as the final reference on all product and operation details
should any discrepancies arise in other languages.

For customer service

Dial: 1-800-315-5885

(MONDAY - THURSDAY 8:00 AM - 5:00 PM, FRIDAY 8:00 AM - 1:30 PM EST)

or Visit Our Website: http://www.lenoxx.com
or Email: [e-mail]

© 2007 LENOXX ELECTRONICS CORP.

35 BRUNSWICK AVENUE

EDISON, N.J. 08817, USA

MADE & PRINTED IN CHINA

8

QI-MP555-WC-E-020507
