4. How to clean the electric clothes dryer
Failure
phenomenon
Cause Analysis
Troubleshooting
Electric clothes
drying rack does not
work
Power plug is not connected
Check the power plug
connections
Turned on the switch or not
Turn the switch to the ON
Power cord is damaged
replace the power cord by
professionals
Name:
Size:
Electric Clothes Dryer
1470*540*860MM
Rated Voltage:
IP Degree:
AC 220-240V
IP X1
1. Before cleaning, please be sure to cut off the power and let the clothes
rack cool down.
2. Do not let the drying rack,power cord,power plug immersed in water.
3. Ensure the electrical wiring dry.
4. Wipe the shell with a damp cloth,then use soft cloth to dry the rack. Note:
Never use metal balls or other coarse cloth to clean the racks, avoid to
damage the rack surface.
5. Implementation of standards
Electric Clothes Dryer
Instructions
Note:
1． In the event of any technical statistics difference, please refer to the
actual product.
2． The power supply system connected to it must be provided with
over-current protection device.
Before using this product, please read the following instructions carefully and
Item
Name
Function
1
Power Cord
For connecting the power
2
Switch button
ON(Start to work) / OFF(Finish working)
3
Support legs
Support the drying racks and objects
4
Heating region
For drying clothes/towels/socks,ect
keep for future reference.
1. Warning
1. This product should be installed and placed away from the shower, bath,or
the place easy to splashed by water.
2. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
3. This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved.
- Children shall not play with the appliance.
- Cleaning and user maintenance shall not be made by children without
supervision.
- This appliance is intended only for drying textiles washed in water.
4. Only use to dry Washable textiles, Silk fabric is prohibited to dry.
5. After powered on for 5 minutes, the heat pipe temperature constant at 45-50
degrees, covering clothing working temperature will up to 60 degrees.
6. Do not use to dry poor heat resistant textiles, if they really need to dry,please
put it on a clean towel to dry indirectly.
7. To save energy and be safety, when using this product, please dehydrate or
drying clothes wring their hands
8. This product must be equipped with a fixed wiring and power cut-off device,
must be connected to the room overcurrent protection apparatus.
9. This product must be used by connecting to the power that matched the
ranted voltage shown on the nameplate.
10. Prohibit to use when the heating elements or enclosure damaged.
11 This product provides the matching triangle plug and three-wire power
cord.The product must be grounded to avoid the security risks and dangers.
12. If the external wire device needs to repairing, the power must be completely
cut off.
2. Components and Functions
3. Product use instructions
1. Use drying clothes racks, should be follow the Safety Use Precautions, and
select the appropriate power position.
2. Stretch the legs following the figure indicated direction. After placed stably,
turn on the power to start working.
3. When finish using, fold the support legs and wings to facilitate the
admission.
