Lenoxx 885 User Manual

AM/FM HEADPHONE RADIO

MODEL 885M

Operating Instructions

3

2

1

1. VOLUME CONTROL & POWER ON/OFF

2. ADJUSTABLE TOP HEADBAND

3. FM ANTENNA

4. POWER LED INDICATOR

5. AM/FM BAND SWITCH

6. TUNING CONTROL

7. BATTERY DOOR

8. EAR PADS

9. ADJUSTABLE BACK HEADBAND

8

7

--- 1 ---

9

4

5

6

IB-885M(CF)-WM-E-051403

BATTERY INSTALLATION

1. Push the BATTERY DOOR to left and lift the BATTERY
DOOR.

2. Toward you (outwards) as shown on the diagram below. Insert
two size AA batteries (not included) as shown below, then
replace the BATTERY DOOR.

NOTE: Carefully
observe (+) and (-)
polarities.

BATTERY REPLACEMENT

When volume decreases or sound gets distorted, replace both
batteries with new ones.

Do not mix old and new batteries.



Do not mix alkaline, standard (carbon-zinc) or rechargeable



(nickel-cadmium) batteries.
Alkaline batteries are recommended and will normally



provide more playing time.

RADIO OPERATION

1. Rotate the VOLUME control past click. The power led will
turn on.

2. Adjust to the desired sound level.

3. Select AM/FM with the BAND switch.

4. Rotate the TUNING control to select your favorite radio station
(rotate the TUNING control slowly and adjust for the loudest
and clearest sound).

5. To close the radio, gently turn the VOLUME control past
minimum to OFF position counterclockwise.

--- 2 ---

IB-885M(CF)-WM-E-051403
