Lenovo IdeaPad U330p/U330 Touch U430p/U430 Touch

User Guide

Read the safety notices and important tips in the included manuals before using your computer.

Notes

•

Before using the product, be sure to read Lenovo Safety and General Information Guide first.

•

Some instructions in this guide may assume that you are using Windows® 8. If you are using other Windows operating systems, some operations may be slightly different. If you are using other operating systems, some operations may not apply to you.

•

The features described in this guide are common to most models. Some features may not be available on your computer and/or your computer may include features that are not described in this user guide.

•

The illustrations used in this manual are for Lenovo IdeaPad U430p unless otherwise stated.

•

The illustrations in this manual may differ from the actual product. Please refer to the actual product.

Regulatory Notice

•

For details, refer to Guides & Manuals at http://support.lenovo.com.

First Edition (April 2013)

LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

Contents

Chapter 1. Getting to know your computer ..........................................1

Top view.......................................................................................................................1

Left-side view ..............................................................................................................5

Right-side view............................................................................................................8

Bottom view ...............................................................................................................11

Chapter 2. Starting to use Windows 8 ................................................13

Configuring the operating system for the first time ............................................13

Operating system interfaces ....................................................................................13

Charms and the charms bar.....................................................................................14

Putting the computer to sleep or shutting it down..............................................16

Touch screen operation (U330 Touch/U430 Touch)............................................18

Connecting to a wireless network ..........................................................................21

Help and support ......................................................................................................22

Chapter 3. Lenovo OneKey Recovery system ...................................23

Chapter 4. Troubleshooting.................................................................24

Frequently asked questions .....................................................................................24

Troubleshooting ........................................................................................................27

Trademarks............................................................................................31

Chapter 1. Getting to know your computer

Top v iew - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Note: The dashed areas indicate parts that are invisible from outside.

Attention:



• Do not open the display panel beyond 130 degrees. When closing the display panel, be

careful not to leave pens or any other objects in between the display panel and the keyboard. Otherwise, the display panel may be damaged.

Chapter 1. Getting to know your computer

Integrated

Use the camera for video communication.

camera

Built-in

microphone

Multi-touch

display (U330 Touch/

Captures sound which can be used for video conferencing, voice narration, or audio recording.

The LCD display with LED backlight provides brilliant visual output. Multi-touch function is available on this display.

U430 Touch)

Display (U330p/

Provides brilliant visual output.

U430p)

Power button

Touchpad

Note: You can enable/disable the touchpad by pressing .

Ventilation slots

Attention:



• Make sure that none of the ventilation slots are blocked or else overheating of the

computer may occur.

Wireless

antennas

Press this button to turn on the computer.

The touchpad functions as a conventional mouse. Touchpad To move the cursor on the screen, slide your fingertip over the pad in the direction in which you want the cursor to move. Touchpad buttons The functions of the left/right side correspond to that of the left/right mouse button on a conventional mouse.

Dissipate internal heat.

Connect to the wireless adapter to receive and send wireless radio.

Chapter 1. Getting to know your computer

 Hotkeys

You can access certain system settings quickly by pressing the appropriate hotkeys.

Mutes/unmutes the sound.

Decreases the volume level.

Increases the volume level.

Closes the currently active

window.

Refreshes the desktop or the

currently active window.

Enables/disables the

touchpad.

Note: If you changed the HotKey Mode from Enabled to Disabled in the BIOS setup utility,

you will need to press the Fn key in combination with the appropriate hotkey.

Enables/disables Airplane

mode.

Switches the active program.

Turns on/off the backlight of

the LCD screen.

Projects to a connected

display.

Decreases display

brightness.

Increases display brightness.

Chapter 1. Getting to know your computer

Function key combinations

Through the use of the function keys, you can change operational features

instantly. To use this function, press and hold Fn ; then press one of the

function keys .

The following describes the features of each function key.

Fn + Home: Activate the pause function.

Fn + End: Activate the break function.

Fn + PgUp: Enable/Disable the scroll lock.

Fn + PgDn: Activate the insert function.

Fn + Space (U430p/ U430 Touch)

Turn on/off the keyboard backlight.

(on select models):

Chapter 1. Getting to know your computer

Left-side view - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

 U330p/U330 Touch

a c d e

 U430p/U430 Touch

a b c d e

Novo button

Notes:

• For details, see “Chapter 3. Lenovo OneKey Recovery system” on page 23.

• If your computer is preinstalled with a Linpus operating system, Onekey Recovery

system is not available.

RJ-45 port

HDMI port

USB ports

Notes:

• The blue port supports USB 3.0.

• For details, see “Connecting USB devices” on page 6.

Combo audio

When the computer is off or in hibernation mode, press this button to start the Lenovo OneKey Recovery system or the BIOS setup utility, or to enter the boot menu.

Connects the computer to an Ethernet network.

Connects to devices with HDMI input such as a TV or a display.

Connect to USB devices.

Connects to headsets.

jack

Notes:

• At the default setting, the combo audio jack does not support conventional microphones.

• The recording function may not be supported if third-party headphones or headsets are

connected, due to different industry standards.

Chapter 1. Getting to know your computer

 Connecting USB devices

You can connect a USB device to your computer by inserting its USB plug (Type A) into the USB port on your computer.

The first time you plug a USB device into a particular USB port on your computer, Windows automatically installs a driver for that device. After the driver is installed, you can reconnect the device without performing any additional steps.

Note: Typically, Windows detects a new device after connecting it, and then installs the

driver automatically. However, some devices may require you to install the driver before connecting. Check the documentation provided by the device’s manufacturer before connecting the device.

Before disconnecting a USB storage device, make sure your computer has finished transferring data by that device. Click the Safely Remove Hardware and Eject Media icon in the notification area of the Windows desktop screen to remove the device before disconnecting.

Notes:

• If your USB device uses a power cord, connect the device to a power source before

connecting it. Otherwise, the device may not be recognized.

• To connect or disconnect USB device in sleep mode, you should wake up your computer

first.

Chapter 1. Getting to know your computer

 Connecting a Bluetooth device (on select models)

If your computer has an integrated Bluetooth adapter card, it can connect to and transfer data wirelessly to/from other Bluetooth enabled devices, such as notebook computers, PDAs and cell phones. You can transfer data between these devices up to 10 meters range in open space.

Note: The actual maximum range may vary due to interference and transmission barriers.

For best transfer speed, place the device as near your computer as possible.

Enabling Bluetooth and WLAN communications on your computer

Press to make configuration.

Notes:

• When you do not need to use the Bluetooth function, turn it off to save battery power.

• You need to pair the Bluetooth enabled device with your computer before you can transfer

data between them. Read the documentation supplied with the Bluetooth enabled device for details on how to pair the device with your computer.
