Product Specifications Reference
Lenovo and ThinkVision Monitors
2013 to present - withdrawn
lenovo.com
Page 2
Contents
Lenovo D186 Wide - withdrawn................................................................ 1
Lenovo ThinkVision L197 Wide - withdrawn............................................. 2
Lenovo ThinkVision L1711p - withdrawn ..................................................3
Lenovo ThinkVision L1900p - withdrawn ..................................................4
Lenovo ThinkVision L2250p Wide - withdrawn......................................... 5
Lenovo ThinkVision L2251x Wide - withdrawn ......................................... 6
Lenovo ThinkVision LS1922 Wide - withdrawn ........................................ 7
Lenovo ThinkVision LS2023 Wide - withdrawn ........................................ 8
Lenovo ThinkVision LS2223 Wide - withdrawn ........................................ 9
Lenovo ThinkVision LS2323 Wide - withdrawn ...................................... 10
Lenovo ThinkVision LT1712p - withdrawn .............................................. 11
Legal Information and Trademarks ......................................................... 12
Page 3
Lenovo D186 Wide - withdrawn
Product Specifications Reference (PSREF)
Name
Case color
Type-model
Panel
Viewable image size
Max view area (W x H)
Optimum resolution
Maximum resolution
Aspect ratio
Pixel pitch (mm)
Dot/Pixel per Inch
Brightness
Contrast ratio
Pixel response time
Color gamut
Anti-reflective
Viewing angle at 10:1 CR
Stand
Bezel width
Dimensions (HxWxD)
Power supply
Weight
Limited warranty
4
Available date
VESA-compliant
2
Power management
Ergonomics
Pixel defect
Emission standards
Environmental
Preset resolutions
Presets
Viewing adjustments
Rotating screen
On screen display
Control features
USB hub
Multiple input
Monitor connectors
Signal cables
Mounting features
Security
Ship group
D186 Wide Flat Panel Monitor
Business black
2580-AB1
TFT-LCD, twisted nematic (TN), CCFL backlight
18.5" (470mm) diagonal
16.1" x 9.1" / 409.8mm x 230.4mm
1366x768 at 60Hz
1366x768 at 60Hz (135MHz max pixel rate)
• Widescreen 18.5-inch monitor
• High Definition (HD) ready; 1366x768 resolution
• Detachable stand tilts for comfortable viewing
• Supports VESA mount (100mm)
• 50% less mercury
• Kensington
lock slot ready for enhanced security
Features
16:9
.300mm
85 dpi
200 nits or cd/m2 (typical)
600:1 (typical)
5ms (typical)
67%
Anti-reflective, anti-glare
90° (+/- 45°) horizontal, 50° (+/- 25°) vertical
Tilt adjustable stand
Sides:
0.61" (15.6mm)
; top: 0.67" (17.1mm);
bottom: 1.19" (30.1mm)
14.6" H x 17.4" W x 8.3" D;
370mm H x 442mm W x 210mm D
16 watts typical, 24 watts maximum,
<1 watts standby/suspend, universal,
integrated (no external brick-like power supply)
7.28 lb; 3.3kg
3 years (includes backlight)
January 2010
VESA DDC2B/CI, VESA DPMS-compliant
None
ISO 9241-307
ISO 9241-307 pixel defect standard
FCC Class B
WEEE, RoHS (EU Directive 2002/95/EC),
VGA: 640x350, 640x480, 720x400
SVGA: 800x600
XGA: 1024x768
WXGA: 1280x720, 1280x768
Lenovo D186 Wide Monitor
1360x768, 1366x768
Standard presets: 20; user settings: 16
Tilt: 20° back, -5° forward; no lift; no swivel; detachable stand
None
On screen display with digital user controls (8 languages)
Direct access (control buttons on front) for automatic image setup and adjustment for brightness
None
None
VGA
15-pin D-shell,
Detachable, VGA
analog,
blue
15-pin D-shell at each end, analog, 1.8 meter
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor
installation files, 1.8 meter analog signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty
➫ International Warranty Service
➫ Replacement normally arrives in two business days, excluding holidays
➫ Lenovo pays all shipping costs for valid warranty claims
➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(Lenovo Services part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information
US model announced January 12, 2010
US model withdrawn effective October 31, 2013
Accessories
Kensington MicroSaver Cable Lock 73P2582
Kensington Twin Head Cable Lock 45K1620
Lenovo Easy Reach Monitor Stand 55Y9258
6
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
Lenovo
(D186) December 2013
Page 4
Lenovo ThinkVision L197 Wide - withdrawn
Product Specifications Reference (PSREF)
Flat Panel Monitors - US model
Name
Case color
Type-model
Stand
Screen
Viewable image size (diag)
Aspect ratio
Pixel pitch (mm)
Max view area (inches)
Max view area (mm)
Viewing angle at 5:1 CR
Viewing angle at 10:1 CR
Video input
Dual input
Rotating screen
USB Hub
Optimum resolution
Maximum resolution
Vertical frequency
Horizontal frequency
Preset display modes
Presets / user settings
Brightness
Contrast ratio
Pixel response time
Color gamut
On screen display
Control features
Monitor connectors
Signal cables
Anti-reflective
Dimensions
Weight
Viewing adjustments
Mounting features
Security
VESA-compliant
2
Power management
Ergonomics
Pixel defect
Emission standards
Environmental
Ship group
Power supply
Limited warranty
4
Available date
Features
L197 Wide Flat Panel Monitor
Business black
4434-HE1
Tilt stand
LCD Active Matrix TFT (Thin Film Transistor)
19.0" / 481mm (diagonal)
16:10
.285mm
16.1" x 10.0" (horizontal x vertical)
408mm x 255mm (horizontal x vertical)
176° vertical, 176° horizontal
• Widescreen 19-inch flat panel monitor
• EPEAT Gold rating
• View images in a 16:10 wide aspect ratio
• Resolution of 1440x900 provides crisp screen images
• Slim 14.3mm (0.56") side bezel
• High-bandwidth Digital Content Protection (HDCP)-compliant
• Includes dual input connection for attachment to two
systems concurrently (analog and digital)
• Complements the ThinkCentre
• Microsoft
Windows Vista Premium certified
and ThinkPad systems
160° vertical, 170° horizontal
Digital or analog (two separate connectors)
Dual input (two different PCs attach to two different
connectors; one PC shows image; select via button)
No pivot
None
1440x900 at 60Hz
1440x900 at 75Hz (137MHz maximum pixel rate)
50 to 76Hz
30 to 81kHz
VGA: 640x480 60, 66, 72, 75Hz
640x350 70Hz
720x400 70Hz
SVGA: 800x600 56, 60, 72, 75Hz
832x624 75Hz
XGA: 1024x768 60, 70, 75Hz
1152x864 75Hz
SXGA: 1280x1024 60, 70, 75Hz
WXGA+: 1440x900 60, 75Hz
Standard presets: 20; user settings: 20
250 nits or cd/m2 (typical)
1000:1 (typical)
5ms (typical)
Lenovo ThinkVision L197 Wide
72%
On screen display with digital user controls (7 languages)
Direct access (buttons on front) for automatic image setup
Two connectors: (1) analog VGA
15-pin D-shell [blue],
(2) Digital Visual Interface (DVI-D) for digital (not analog) attach [white], HDCP-compliant
Two cables: (1)
detachable, VGA 15-pin D-shell at each end (for analog connector), 1.8 meter, matches color of monitor
(2) detachable digital, DVI-D at each end (for digital connector), 1.8 meter, matches color of monitor
Anti-reflective, anti-glare
15.0"H x 17.3"W x 7.0"D / 381mm height x 440mm width x 179mm depth
9.15lb / 4.15kg
Tilt: 30° back, 4° forward / no lift, no swivel, detachable stand
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR
ISO 13406 Part 2
3
5.0
1
ISO 13406-2 Class II pixel defect standard
MPR-2, MPR-3A, FCC Class B
TCO 03, WEEE, RoHS (EU Directive 2002/95/EC), EPEAT Gold rating
Monitor, attached stand, Setup Guide, Safety and Warranty Information, CD with multilingual User's Guide and
monitor installation files, analog signal cable, digital signal cable, 1.8m black power cord
90-264Vac (universal), integrated (no external brick-like power supply), 22 watts typical, <2 watts standby/suspend
3 year (includes backlight)
April 2008
Limited Warranty
➫ 3 year limited warranty
➫ International Warranty Service
➫ Replacement normally arrives in two business days, excluding holidays
➫ Lenovo pays all shipping costs for valid warranty claims
➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(Lenovo Services part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information
US model announced April 15, 2008
US model withdrawn effective August 1, 2013
Accessories
Kensington
MicroSaver Cable Lock 73P2582
Kensington Twin Head Cable Lock 45K1620
6
Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(L197W) December 2013
Lenovo
Page 5
Lenovo ThinkVision L1711p - withdrawn
Product Specifications Reference (PSREF)
Name
Case color
Type-model
Panel
Viewable image size
Max view area (W x H)
Optimum resolution
Maximum resolution
Aspect ratio
Pixel pitch (mm)
Dot/Pixel per Inch
Brightness
Contrast ratio
Pixel response time
Color gamut
Anti-reflective
Vertical frequency
Horizontal frequency
Viewing angle at 10:1 CR
Stand
Bezel width
Dimensions (HxWxD)
Power supply
L1711p Flat Panel Monitor
Business black
5047-HB2
TFT-LCD, twisted nematic (TN), CCFL backlight
17.0" (432mm) diagonal
13.3" x 10.6" (337.9mm x 270.3mm)
1280x1024 at 60Hz
1280x1024 at 75Hz (165MHz max pixel rate)
5:4
0.264mm
96 dpi
250 nits or cd/m2 (typical)
1000:1 (typical)
5ms (typical)
72%
Anti-reflective, anti-glare
50 to 75Hz
30 to 83kHz
160° (+/- 80°) horizontal, 160° (+/- 80°) vertical
Tilt height adjustable stand
Sides: 0.6" (15.3mm); top: 0.72" (18.4mm);
bottom: 1.11" (28.1mm)
16-20.33" H x 14.6" W x 6.1" D;
405.7-515.7mm H x 370mm W x 155.2mm D
18 watts typical, 21 watts maximum,
<1 watts standby/suspend, universal,
integrated (no external brick-like power supply)
Weight
Limited warranty
4
Available date
VESA-compliant
2
Power management
Ergonomics
Emission standards
Environmental
9.3 lb; 4.21kg
3 year (includes backlight)
November 2009
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR
5.0
ISO 9241-307
MPR-2. MPR-3A, FCC Class B
TCO (TCO Displays 5.0), WEEE, RoHS,
EPEAT Gold rating
Preset resolutions
VGA: 640x350, 640x480, 720x400
SVGA: 800x600
XGA: 1024x768
Presets / user settings
SXGA: 1280x1024
Standard presets: 17;
user settings: 22
Viewing adjustments
Rotating screen
On screen display
Control features
Multiple input
Monitor connectors
Signal cables
Mounting features
Security
Ship group
Tilt: 20° back, -3° forward; lift: 4.3" (110mm); detachable stand
None
On screen display with digital user controls (8 languages)
Direct access (buttons on front) for automatic image setup
Dual input (two different PCs attach to two different connectors; one PC shows image; select via button)
(1) VGA
(2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant
(1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DVI-D at each end, digital, 1.8 meter
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor
installation files, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty
➫ International Warranty Service
➫ Replacement normally arrives in two business days, excluding holidays
➫ Lenovo pays all shipping costs for valid warranty claims
➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(Lenovo Services part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9215)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
Features
• Regular screen 17-inch monitor
• Supports SXGA 1280x1024 resolution
• Ergonomic stand tilts and provides a 4.3" (110mm)
range height adjustment for comfortable viewing
• Includes dual input connection for attachment to two
systems concurrently (analog and digital)
• Reduces mercury content by 50% and arsenic free glass
• Up to 70% recycled packaging materials
• Privacy Filter Slot
• Microsoft
Windows 7 certified
ThinkVision L1711p Monitor
Accessories
Kensington MicroSaver Cable Lock 73P2582
Kensington Twin Head Cable Lock 45K1620
Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
See footnotes for important warranty information
US model announced October 20, 2009
US model withdrawn effective August 1, 2013
(L1711P) December 2013
Lenovo
Page 6
Lenovo ThinkVision L1900p - withdrawn
Product Specifications Reference (PSREF)
Name
Case color
Type-model
Panel
Viewable image size
Max view area (W x H)
Optimum resolution
Maximum resolution
Aspect ratio
Pixel pitch (mm)
Dot/Pixel per Inch
Brightness
Contrast ratio
Pixel response time
Color gamut
Anti-reflective
Vertical frequency
Horizontal frequency
Viewing angle at 10:1 CR
Stand
Bezel width
Dimensions (HxWxD)
Power supply
L1900p Flat Panel Monitor
Business black
4431-HE1
TFT-LCD, twisted nematic (TN), CCFL backlight
19.0" (483mm) diagonal
14.8" x 11.85" (376mm x 301mm)
1280x1024 at 60Hz
1280x1024 at 75Hz (135MHz max pixel rate)
5:4
.294mm
86 dpi
250 nits or cd/m2 (typical)
800:1 (typical)
5ms (typical)
72%
Anti-reflective, anti-glare
56 to 76Hz
30 to 81kHz
160° (+/- 80°) horizontal, 160° (+/- 80°) vertical
Tilt, swivel, pivot, and height adjustable stand
Sides: 0.6" (15.3mm); top: 0.66" (16.8mm);
bottom: 1.05" (26.8mm)
14.9-19.2" H x 16.1" W x 7.4-9.5" D;
378.7-488.7mm H x 408mm W x 188-241.1mm D
17 watts typical, 24 watts maximum,
<1 watts standby/suspend, universal,
integrated (no external brick-like power supply)
Weight
Limited warranty
4
Available date
VESA-compliant
2
Power management
Ergonomics
Pixel defect
Emission standards
Environmental
12.5 lb; 5.7kg
3 year (includes backlight)
November 2008
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR
ISO 13406 Part 2
3
5.0
1
ISO 13406-2 Class II pixel defect standard
MPR-2. MPR-3A, FCC Class B
TCO 03, WEEE, RoHS (EU Directive 2002/95/EC),
EPEAT Gold rating, GREENGUARD certified
Preset resolutions
VGA: 640x350, 640x480,
720x400
SVGA: 800x600
XGA: 1024x768
Presets / user settings
SXGA: 1280x1024
Standard presets: 21;
user settings: 17
Viewing adjustments
Rotating screen
On screen display
Control features
Multiple input
Monitor connectors
Signal cables
Mounting features
Security
Ship group
Tilt: 30° back, 0° forward; lift: 4.3" (110mm); swivel: +/-45°; detachable stand
Screen pivots 90 degrees from landscape to portrait (requires image rotation support from graphics controller)
On screen display with digital user controls (8 languages)
Direct access (buttons on front) for automatic image setup
Multiple input (two different PCs attach to two different connectors; one PC shows image; select via button)
(1) VGA
(2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant
(1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DVI-D at each end, digital, 1.8 meter
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
Monitor, attached stand, cable cover, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide
and monitor installation files, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty
➫ International Warranty Service
➫ Replacement normally arrives in two business days, excluding holidays
➫ Lenovo pays all shipping costs for valid warranty claims
➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(Lenovo Services part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
Features
• Regular screen 19-inch monitor
• Supports SXGA 1280x1024 resolution
• Ergonomic stand tilts, swivels, pivots and provides a 4.3"
(110mm) range height adjustment for comfortable viewing
• Detachable rear stand cable cover and clip to hide cables
• Microsoft
Windows Vista certified
ThinkVision L1900p Monitor
with optional ThinkVision Soundbar
Accessories
Kensington MicroSaver Cable Lock 73P2582
Kensington Twin Head Cable Lock 45K1620
Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
See footnotes for important warranty information
US model announced November 11, 2008
US model withdrawn effective October 31, 2013
(L1900P) December 2013
Lenovo
Page 7
Lenovo ThinkVision L2250p Wide - withdrawn
Product Specifications Reference (PSREF)
Name
Case color
Type-model
Panel
Viewable image size
Max view area (W x H)
Optimum resolution
Maximum resolution
Aspect ratio
Pixel pitch (mm)
Dot/Pixel per Inch
Brightness
Contrast ratio
Pixel response time
Color gamut
Anti-reflective
Vertical frequency
Horizontal frequency
Viewing angle at 10:1 CR
Stand
Bezel width
Dimensions (HxWxD)
Power supply
L2250p Wide Flat Panel Monitor
Business black
2572-HB6
TFT-LCD, twisted nematic (TN), CCFL backlight
22.0" (559mm) diagonal
18.7" x 11.7" (473.8mm x 296.1mm)
1680x1050 at 60Hz
1680x1050 at 75Hz (205MHz max pixel rate)
16:10
.282mm
90 dpi
250 nits or cd/m2 (typical)
1000:1 (typical)
5ms (typical)
72%
Anti-reflective, anti-glare
50 to 75Hz
30 to 83kHz
170° (+/- 85°) horizontal, 160° (+/- 80°) vertical
Tilt and height adjustable stand
Sides: 0.60" (15.3mm); top: 0.79" (20.0mm);
bottom: 1.10" (28.0mm)
15.68-18.83" H x 19.92" W x 6.11" D;
398.3-478.3mm H x 506mm W x 155.2mm D
21 watts typical, 28 watts maximum,
<1 watts standby/suspend, universal,
integrated (no external brick-like power supply)
Weight
Limited warranty
4
Available date
VESA-compliant
2
Power management
Ergonomics
Emission standards
Environmental
11.49 lb; 5.21kg
3 year (includes backlight)
October 2009
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR
5.0
ISO 9241-307
MPR-2. MPR-3A, FCC Class B
TCO (TCO Displays 5.0), WEEE, RoHS,
EPEAT Gold rating
Preset resolutions
VGA: 640x350, 640x480, 720x400
SVGA: 800x600
XGA: 1024x768,1152x864
SXGA: 1280x1024
WXGA+: 1440x900
UXGA: 1600x1000
Presets / user settings
Viewing adjustments
Rotating screen
On screen display
Control features
USB hub
Camera
Multiple input
Monitor connectors
Signal cables
Mounting features
Security
Ship group
WSXGA+: 1680x1050
Standard presets: 24; user settings: 20
Tilt: 20° back, -3° forward; lift: 3.1" (80mm); detachable stand
None
On screen display with digital user controls (8 languages)
Direct access (buttons on front) for automatic image setup
None
None
Dual input (two different PCs attach to two different connectors; one PC shows image; select via button)
(1) VGA
(2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant
(1) detachable, VGA
(2) detachable, DVI-D at each end, digital,
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
1.8
meter
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor
installation files, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty
➫ International Warranty Service
➫ Replacement normally arrives in two business days, excluding holidays
➫ Lenovo pays all shipping costs for valid warranty claims
➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(Lenovo Services part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
Features
• Widescreen 22-inch monitor
• Supports WSXGA+ 1680x1050 resolution
• Ergonomic stand tilts and provides a 3.1" (80mm)
range height adjustment for comfortable viewing
• Includes dual input connection for attachment to two
systems concurrently (analog and digital)
• Reduces mercury content by 50% and arsenic free glass
• Up to 65% recycled packaging materials
• Privacy Filter Slot
• Microsoft
Windows 7 certified
ThinkVision L2250p Wide Monitor
Accessories
Kensington MicroSaver Cable Lock 73P2582
Kensington Twin Head Cable Lock 45K1620
Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
See footnotes for important warranty information
US model announced October 20, 2009
US model withdrawn effective August 1, 2013
(L2250P) December 2013
Lenovo
Page 8
Lenovo ThinkVision L2251x Wide - withdrawn
Product Specifications Reference (PSREF)
Name
Case color
Type-model
Panel
Viewable image size
Max view area (W x H)
Optimum resolution
Maximum resolution
Aspect ratio
Pixel pitch (mm)
Dot/Pixel per Inch
Brightness
Contrast ratio
Pixel response time
Color gamut
Anti-reflective
Vertical frequency
Horizontal frequency
Viewing angle at 10:1 CR
Stand
Bezel width
Dimensions (HxWxD)
Power supply
L2251x Wide Flat Panel Monitor
Business black
2578-HB6
TFT-LCD, twisted nematic (TN), white LED backlight
22.0" (559mm) diagonal
18.7" x 11.7" / 473.8mm x 296.1mm
1680x1050 at 60Hz
1680x1050 at 75Hz (205MHz max pixel rate)
16:10
.282mm
90 dpi
250 nits or cd/m2 (typical)
1000:1 (typical)
5ms (typical)
68%
Anti-reflective, anti-glare
50 to 75Hz
30 to 83kHz
170° (+/- 85°) horizontal, 160° (+/- 80°) vertical
Tilt, swivel, pivot, and height adjustable stand
Sides: 0.60" (15.3mm); top: 0.79" (20.0mm);
bottom: 1.10" (28.0mm)
14.97-19.3" H x 19.92" W x 9.50" D;
380.3-490.3mm H x 506mm W x 241.2mm D
21 watts typical, 28 watts maximum,
<1 watts standby/suspend, universal,
integrated (no external brick-like power supply)
Weight
Limited warranty
4
Available date
VESA-compliant
2
Power management
Ergonomics
Emission standards
Environmental
12.39 lb; 5.63kg
3 year (includes backlight)
November 2009
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR
3
5.0
ISO 9241-307
MPR-2. MPR-3A, FCC Class B
TCO (TCO Certified Edge), WEEE, RoHS,
EPEAT Gold rating
Preset resolutions
VGA: 640x350, 640x480, 720x400
SVGA: 800x600
XGA: 1024x768,1152x864
SXGA: 1280x1024
WXGA+: 1440x900
UXGA: 1600x1000
Presets / user settings
Viewing adjustments
Rotating screen
On screen display
Control features
USB hub
Camera
Multiple input
Monitor connectors
Signal cables
Mounting features
Security
Ship group
WSXGA+: 1680x1050
Standard presets: 24; user settings: 20
Tilt: 30° back, 0° forward; lift: 4.3" (110mm); swivel: +/-45°; detachable stand
Screen pivots 90 degrees from landscape to portrait (requires image rotation support from graphics controller)
On screen display with digital user controls (8 languages)
Direct access (buttons on front) for automatic image setup
USB 2.0 Hub (1 port into PC, 3 ports for accessories)
Integrated camera (0.3 megapixel) and microphone
Dual input (two different PCs attach to two different connectors; one PC shows image; select via button)
(1) VGA
(2) DisplayPort, digital, black, HDCP-compliant
(1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DisplayPort at each end, digital, 1.8 meter
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
Monitor, attached stand, cable cover, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide
and monitor installation files, 1.8 meter analog signal cable, 1.8 meter DisplayPort cable, 1.8 meter USB cable,
1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty
➫ International Warranty Service
➫ Replacement normally arrives in two business days, excluding holidays
➫ Lenovo pays all shipping costs for valid warranty claims
➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(Lenovo Services part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
Features
• Widescreen 22-inch monitor with white LED backlight
• Ergonomic stand tilts, swivels, pivots and provides a 4.3"
(110mm) range height adjustment for comfortable viewing
• Detachable rear stand cable cover and clip to hide cables
• Integrated camera (0.3 megapixel) and microphone
• Integrated ambient light sensor and a proximity sensor,
save more energy and make viewing more comfortable
• Low halogen, mercury free, and arsenic free glass,
92% recycled packaging materials
• Privacy Filter Slot
• Microsoft
Windows 7 certified
ThinkVision L2251x Wide Monitor
Accessories
Kensington MicroSaver Cable Lock 73P2582
Kensington Twin Head Cable Lock 45K1620
Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
See footnotes for important warranty information
US model announced October 20, 2009
(L2251X) May 2011
Lenovo
Page 9
Lenovo ThinkVision LS1922 Wide - withdrawn
Product Specifications Reference (PSREF)
Name
Case color
Type-model
Panel
Viewable image size
Max view area (W x H)
Native resolution
Aspect ratio
Pixel pitch (mm)
Dot/Pixel per Inch
Brightness
Contrast ratio
Pixel response time
Color gamut
Viewing angle at 10:1 CR
Stand
Bezel width
Dimensions (HxWxD)
Power supply
Weight
Limited warranty
4
Available date
VESA-compliant
2
Power management
Ergonomics
Emission standards
Environmental
Preset resolutions
Presets / user settings
Viewing adjustments
Rotating screen
On screen display
Control features
Multiple input
Monitor connectors
Signal cables
Mounting features
Security
LS1922 Wide Flat Panel Monitor
Business black
2580-AF1
TFT-LCD, twisted nematic (TN), White LED backlight
18.5" (470mm) diagonal
16.1" x 9.1" / 409.8mm x 230.4mm
1366x768
16:9
.300mm
• Widescreen 18.5-inch monitor
• Supports HD 1366x768 resolution
• Supports VESA mount (100mm)
• Mercury free panel and arsenic free glass
• Kensington lock slot ready for enhanced security
• Microsoft Windows 7 certified
• Support Lenovo Tiny PC via VESA mount
Features
85 dpi
250 nits or cd/m2 (typical)
1000:1 (typical)
5ms (typical)
72%
170° (+/- 85°) horizontal, 160° (+/- 80°) vertical
Tilt adjustable stand
Sides:
0.61" (15.6mm)
; top: 0.67" (17.1mm);
bottom: 1.19" (30.1mm)
14.54" H x 17.38" W x 8.25" D;
370.1mm H x 442.2mm W x 210.0mm D
14 watts typical, 18 watts maximum,
<1 watts standby/suspend, universal,
integrated (no external brick-like power supply)
6.55 lb; 2.97 kg
3 year (includes backlight)
February 2012
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR
5.1
ISO 9241-307
FCC Class B
TCO (TCO Displays 5.2), WEEE, RoHS
VGA: 640x350, 640x480, 720x400
SVGA: 800x600
XGA: 1024x768
WXGA: 1280x720, 1280x768, 1360x768,
1366x768
Standard presets: 16 (VGA);
user settings: 16
ThinkVision LS1922 Wide Monitor
Tilt: 20° backward, -5° forward
None
On screen display with digital user controls (8 languages)
Direct access (control buttons on front) for automatic image setup and adjustment for brightness
None
15-pin D-shell,
VGA
detachable, VGA
analog,
blue
15-pin D-shell at each end, analog, 1.8 meter
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
Ship group
Monitor, attached stand, Setup poster with Safety and Warranty Information, CD with multilingual User's Guide and
monitor installation files, 1.8 meter analog signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty
➫ International Warranty Service
➫ Replacement normally arrives in two business days, excluding holidays
➫ Lenovo pays all shipping costs for valid warranty claims
➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(Lenovo Services part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information
US model announced February 28, 2012
Accessories
Kensington
Kensington Twin Head Cable Lock 45K1620
6
Lenovo Security Cable Lock 57Y4303
Lenovo Easy Reach Monitor Stand 55Y9258
ThinkCentre Extend Arm
MicroSaver Cable Lock 73P2582
57Y4352
See details at www.lenovo.com/support/monitoraccessories
4
See all monitors at www.lenovo.com/thinkvision
(LS1922) August 2012
Lenovo
Page 10
Lenovo ThinkVision LS2023 Wide - withdrawn
Product Specifications Reference (PSREF)
Name
Case color
Type-model
Panel
Viewable image size
Max view area (W x H)
Native resolution
Aspect ratio
Pixel pitch (mm)
Dot/Pixel per Inch
Brightness
Contrast ratio
Pixel response time
Color gamut
Viewing angle at 10:1 CR
Stand
Bezel width
Dimensions (HxWxD)
Power supply
Weight
Limited warranty
4
Available date
VESA-compliant
2
Power management
Ergonomics
Emission standards
Environmental
Preset resolutions
Presets / user settings
Viewing adjustments
Rotating screen
On screen display
Control features
Multiple input
Monitor connectors
Signal cables
Mounting features
Security
Ship group
LS2023 Wide Flat Panel Monitor
Business black
3778-HB2
TFT-LCD, twisted nematic (TN), White LED backlight
20.0" (508mm) diagonal
17.4" x 9.8" (443mm x 249mm)
1600x900
16:9
.276mm
• Widescreen 20-inch monitor
• Supports 1600x900 resolution
• Includes dual input connection for attachment to two
systems concurrently (analog and digital)
• Arsenic free glass
• EPEAT Gold certified
• Microsoft Windows 7 certified
Features
92 dpi
250 nits or cd/m2 (typical)
1000:1 (typical)
5ms (typical)
72%
170° (+/- 85°) horizontal, 160° (+/- 80°) vertical
Tilt adjustable stand
Sides: 0.598" (15.2mm);
top: 0.606" (15.4mm);
bottom: 1.020" (25.9mm)
14.28" H x 18.71" W x 6.19" D;
362.8mm H x 475.1mm W x 157.4mm D
19 watts typical, 22 watts maximum,
<0.5 watts standby/suspend, universal,
integrated (no external brick-like power supply)
7.01 lb; 3.18 kg
3 year (includes backlight)
September 2012
VESA DDC2B/CI
ENERGY STAR
qualified
ISO 9241-307
FCC Class B
TCO (TCO Displays 6.0), WEEE, RoHS,
EPEATTM Gold rating
VGA: 640x350, 640x480, 720x400
SVGA: 800x600
XGA: 1024x768
WXGA: 1280x800, 1280x768, 1280x720,
1360x768
WXGA+: 1440x900, 1600x900
Standard presets: 16
user settings: 16
ThinkVision LS2023 Wide Monitor
Tilt: 21° backward, -5° forward
None
On screen display with digital user controls (8 languages)
Direct access (buttons on front) for automatic image setup, dual input and brightness
Dual input (two different PCs attach to two different connectors; one PC shows image; select via button)
(1) VGA
(2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant
(1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DVI-D at each end, digital, 1.8 meter
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor
installation files, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty
➫ International Warranty Service
➫ Replacement normally arrives in two business days, excluding holidays
➫ Lenovo pays all shipping costs for valid warranty claims
➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(Lenovo Services part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information
US model announced September 18, 2012
Accessories
Kensington
Kensington Twin Head Cable Lock 45K1620
6
MicroSaver Cable Lock 73P2582
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(LS2023) September 2012
Lenovo
Page 11
Lenovo ThinkVision LS2223 Wide - withdrawn
Product Specifications Reference (PSREF)
Name
Case color
Type-model
Panel
Viewable image size
Max view area (W x H)
Native resolution
Aspect ratio
Pixel pitch (mm)
Dot/Pixel per Inch
Brightness
Contrast ratio
Pixel response time
Color gamut
Viewing angle at 10:1 CR
Stand
Bezel width
LS2223 Wide Flat Panel Monitor
Business black
3783-HB2
TFT-LCD, twisted nematic (TN), White LED backlight
21.5" (546mm) diagonal
18.76" x 10.55" (476.6mm x 268.1mm)
1920x1080
16:9
.248mm
103 dpi
250 nits or cd/m2 (typical)
1000:1 (typical)
5ms (typical)
72%
170° (+/- 85°) horizontal, 160° (+/- 80°) vertical
Tilt adjustable stand
Sides: 0.591" (15.0mm);
top: 0.701" (17.8mm);
bottom: 0.996" (25.3mm)
Dimensions (HxWxD)
Power supply
15.08" H x 20.00" W x 6.19" D;
383.0mm H x 508.0mm W x 157.4mm D
21 watts typical, 25 watts maximum,
<0.5 watts standby/suspend, universal,
integrated (no external brick-like power supply)
Weight
Limited warranty
4
Available date
VESA-compliant
2
Power management
Ergonomics
Emission standards
Environmental
7.74 lb; 3.51 kg
3 year (includes backlight)
September 2012
VESA DDC2B/CI
ENERGY STAR
qualified
ISO 9241-307
FCC Class B
TCO (TCO Displays 6.0), WEEE, RoHS,
EPEATTM Gold rating
Preset resolutions
VGA: 640x350, 640x480, 720x400
SVGA: 800x600
XGA: 1024x768
SXGA: 1280x1024
WXGA: 1280x800, 1280x768, 1280x720,
1360x768
WXGA+: 1440x900, 1600x900
WSXGA+: 1680x1050
Presets / user settings
Full HD: 1920x1080
Standard presets: 16
user settings: 16
Viewing adjustments
Rotating screen
On screen display
Control features
Multiple input
Monitor connectors
Signal cables
Mounting features
Security
Ship group
Tilt: 21° backward, -5° forward
None
On screen display with digital user controls (8 languages)
Direct access (buttons on front) for automatic image setup, dual input and brightness
Dual input (two different PCs attach to two different connectors; one PC shows image; select via button)
(1) VGA
(2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant
(1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DVI-D at each end, digital, 1.8 meter
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor
installation files, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty
➫ International Warranty Service
➫ Replacement normally arrives in two business days, excluding holidays
➫ Lenovo pays all shipping costs for valid warranty claims
➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(Lenovo Services part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
Features
• Widescreen 21.5-inch monitor
• Supports Full HD 1920x1080 resolution
• Includes dual input connection for attachment to two
systems concurrently (analog and digital)
• Arsenic free glass
• EPEAT Gold certified
• Microsoft Windows 7 certified
ThinkVision LS2223 Wide Monitor
Accessories
Kensington
Kensington Twin Head Cable Lock 45K1620
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
MicroSaver Cable Lock 73P2582
See footnotes for important warranty information
US model announced September 18, 2012
(LS2223) September 2012
Lenovo
Page 12
Lenovo ThinkVision LS2323 Wide - withdrawn
Product Specifications Reference (PSREF)
Name
Case color
Type-model
Panel
Viewable image size
Max view area (W x H)
Native resolution
Aspect ratio
Pixel pitch (mm)
Dot/Pixel per Inch
Brightness
Contrast ratio
Pixel response time
Color gamut
Viewing angle at 10:1 CR
Stand
Bezel width
LS2323 Wide Flat Panel Monitor
Raven black
3794-HB1
TFT-LCD, twisted nematic (TN), White LED backlight
23" (584mm) diagonal
20.04" x 11.28" (509.2mm x 286.4mm)
1920x1080
16:9
.265mm
96 dpi
250 nits or cd/m2 (typical)
1000:1 (typical)
5ms (typical)
72%
170° (+/- 85°) horizontal, 160° (+/- 80°) vertical
Tilt adjustable stand
Sides: 0.709" (18.0mm);
top: 0.709" (18.0mm);
bottom: 1.197" (30.4mm)
Dimensions (HxWxD)
Power supply
15.92" H x 21.57" W x 7.67" D;
403.9mm H x 547.8mm W x 194.9mm D
30 watts typical, 35 watts maximum,
<0.5 watts standby/suspend, universal,
integrated (no external brick-like power supply)
Weight
Limited warranty
4
Available date
VESA-compliant
2
Power management
Ergonomics
Emission standards
Environmental
8.20 lb; 3.72 kg
3 year (includes backlight)
September 2012
VESA DDC/CI, VESA DPMS-compliant
ENERGY STAR
qualified
ISO 9241-307
FCC Class B
TCO (TCO Displays 5.2), RoHS,
EPEATTM Gold rating
Preset resolutions
VGA: 640x350, 640x480, 720x400, 700x570
SVGA: 800x600, 832x624
XGA: 1024x768, 1152x864
SXGA: 1280x1024
WXGA: 1366x768
WXGA+: 1440x900, 1600x900
WSXGA+: 1680x1050
Presets / user settings
Full HD: 1920x1080
Standard presets: 26;
user settings: 26
Viewing adjustments
Rotating screen
On screen display
Control features
Multiple input
Monitor connectors
Signal cables
Mounting features
Security
Ship group
Tilt: 21° backward, -5° forward
None
On screen display with digital user controls (8 languages)
Direct access (buttons at the middle bottom of the front bezel) for automatic image setup and brightness
Dual input (two different PCs attach to two different connectors; one PC shows image; select via button)
(1) VGA
(2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant
(1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DVI-D at each end, digital, 1.8 meter
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
Monitor, tooless detachable stand, Quick start and safety poster, CD with multilingual User's Guide, setup test pattern
and monitor installation files, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty
➫ International Warranty Service
➫ Replacement normally arrives in two business days, excluding holidays
➫ Lenovo pays all shipping costs for valid warranty claims
➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(Lenovo Services part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
Features
• Widescreen 23-inch monitor
• Supports Full HD 1920x1080 resolution
• Includes dual input connection for attachment to two
systems concurrently (analog and digital)
• Arsenic free glass
• EPEAT Gold certified
• Microsoft Windows 7 certified
ThinkVision LS2323 Wide Monitor
Accessories
Kensington
Kensington Twin Head Cable Lock 45K1620
MicroSaver Cable Lock 73P2582
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
See footnotes for important warranty information
US model announced September 18, 2012
(LS2323) September 2012
Lenovo
Page 13
Lenovo ThinkVision LT1712p - withdrawn
Product Specifications Reference (PSREF)
Name
Case color
Type-model
Panel
Viewable image size
Max view area (W x H)
Optimum resolution
Aspect ratio
Pixel pitch (mm)
Dot/Pixel per Inch
Brightness
Contrast ratio
Pixel response time
Color gamut
Viewing angle at 10:1 CR
Stand
Bezel width
Dimensions
(HxWxD, excluding stand)
Dimensions
(HxWxD, including stand)
Power supply
Weight
Limited warranty
4
Available date
VESA-compliant
2
Power management
Ergonomics
Emission standards
Environmental
Preset resolutions
Presets / user settings
LT1712p Flat Panel Monitor
Business black
5047-HC2
TFT-LCD, twisted nematic (TN), CCFL backlight
17.0" (432mm) diagonal
13.3" x 10.6" (337.9mm x 270.3mm)
1280x1024
5:4
0.264mm
96 dpi
250 nits or cd/m2 (typical)
1000:1 (typical)
5ms (typical)
72%
170° (+/- 85°) horizontal, 160° (+/- 80°) vertical
Tilt height adjustable stand
Sides: 0.60" (15.3mm);
top: 0.72" (18.4mm);
bottom: 1.11" (28.1mm)
12.5" H x 14.6" W x 2.1" D;
318.3mm H x 370.0mm W x 53.0mm D
16.0" H x 14.6" W x 6.1" D;
405.7mm H x 370.0mm W x 155.2mm D
15.5 watts typical, 19.0 watts maximum,
<0.5 watts standby/suspend, universal,
integrated (no external brick-like power supply)
9.35 lb; 4.24kg
3 year (includes backlight)
January 2013
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR
6.0
ISO 9241-307
MPR-2. FCC Class B
TCO Displays 6.0, TCO Certified Edge 1.1, WEEE,
RoHS, EPEAT Gold rating
VGA: 640x350, 640x480, 720x400
SVGA: 800x600
XGA: 1024x768
SXGA: 1280x1024
Standard presets: 17;
user settings: 22
Features
• 17-inch Square LCD monitor
• Supports SXGA 1280x1024 resolution
• Ergonomic stand tilts and provides a 4.3" (110mm)
range height adjustment for comfortable viewing
• Includes dual input connection for attachment to two
systems concurrently (analog and digital)
• Arsenic free glass
• Supports Lenovo Tiny PC and 3rd party thin client via optional
Lenovo bracket
• Microsoft
Windows 7 certified
ThinkVision LT1712p Monitor
Viewing adjustments
Rotating screen
On screen display
Control features
Multiple input
Monitor connectors
Signal cables
Mounting features
Security
Ship group
Tilt: 20° back, -3° forward; lift: 4.3" (110mm); detachable stand
None
On screen display with digital user controls (8 languages)
Direct access (buttons on front) for automatic image setup
Dual input (two different PCs attach to two different connectors; one PC shows image; select via button)
(1) VGA
(2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant
(1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DVI-D at each end, digital, 1.8 meter
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor
installation files, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
See details at http://support.lenovo.com/en_US/guides-and-manuals/detail.page?DocID=UM008281
See footnotes for important warranty information
US model announced July 3, 2012
Accessories
Kensington MicroSaver Cable Lock 73P2582
Kensington Twin Head Cable Lock 45K1620
Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
Lenovo
(LT1712P) April 2013
Page 14
Legal Information and Trademarks
Availability: All offers subject to avail-
ability. Lenovo reserves the right to alter
product offerings and specifications at
any time, without notice. Lenovo is not
responsible for photographic or typographic errors.
Warranty: For a copy of applicable
product warranties, write to: Warranty Information, P.O. Box 12195, RTP, NC, 27709,
Attn: Dept ZPYA/B676. Lenovo makes no
representation or warranty regarding third
party products or services.
1
ISO-compliant: Compliance with ISO
9241 Part 3, ISO Part 7, ISO Par t 8, and/
or ISO 13406 Part 2 is dependent on
a complete ISO-capable platform of a
system unit, monitor, video subsystem,
operating system and fonts.
2
VESA: Requires attachment to suitably
configured system with similarly enabled
operating system.
3
ENERGY STAR: As an ENERGY STAR
partner, Lenovo has determined that this
product meets the ENERGY STAR 4.0 or
4.1 guidelines for energy efficiency. Requires attachment to suitably configured
system.
4
Limited warranty: Support unrelated to
a warranty issue may be subject to additional charges.
5
International Warranty Service is avail-
able in any country in which this product
is sold and serviced. Service delivery
methods and parts availability vary by
country, may be different from that in the
country of purchase, and are subject to
change without notice. Fees and restrictions may apply in some countries.
6
Lenovo pays all shipping costs for
warranty repairs during limited warranty
period.
7
ThinkPlus and Lenovo Care Services: These services are available for
machines normally used for business,
professional, or trade purposes, rather
than personal, family, or household purposes. Not all machine types and models
are covered. Service period begins with
the equipment date of purchase. Service
must be purchased during the original
limited product warranty period. Service
levels are response time objectives
and are not guarantees. If the machine
problem turns out to be a Customer
Replaceable Unit (CRU), a part will be
express shipped to you for quick replacement. Onsite 24x7x2-hour service is
not available in all locations. P&L means
parts and labor. P/U means pick-up. See
terms and conditions for complete details
and restrictions.
8
Telephone support may be subject
to additional charges, even during the
limited warranty period. In the United
States call 1-800-426-7378. Response
times may vary. May exclude some
holidays. If a machine is listed as having
“On-site service for select repairs”, this
means that onsite service is available
only for the replacement of select parts.
For all other warranty repairs, Lenovo will
provide the customer a replacement part
for customer installation. The parts for
which onsite service is available varies by
machine, but may include the processor,
power supply, heat sink, system board, or
base cover. For machines with EasyServ
or Courier service, Lenovo will attempt
to diagnose and resolve the problem
remotely before sending a courier.
10
TAA: Monitor is compliant with the U.S.
Federal Government's country-of-origin
requirements prescribed in 48 C.F.R.
Subpart 25.4; Trade Act Agreement (TAA)
model.
11
Post-warranty annual maintenance
agreement: Service begins at the end
of the base warranty or the end of any
other applied warranty and maintenance
option, whichever occurs last. Service
delivery is not available the same day the
maintenance agreement is purchased.
Maintenance agreements must be
purchased and the registration successfully completed prior to the service being
available.
12
Halogen: Less than 900 Parts Per Million.
Low halogen is defined in accordance
with IPC-401B and draft IPC-J-STD 709
Class 1 requirements.
Trademarks: Lenovo, the Lenovo logo,
New World. New Thinking., Access Connections, Rescue and Recovery, ThinkCentre, ThinkPad, ThinkStation, ThinkVantage, and ThinkVision are trademarks of
Lenovo. Microsoft, Windows, and Vista are
registered trademarks of Microsoft Corporation. Other company, product, or service
names may be trademarks or service
marks of others.
This publication was developed for prod-
ucts and services offered in the United
States. Lenovo may not offer the products, services or features discussed in
this document in other countries. Lenovo
may withdraw an offering at any time.
Information is subject to change without
notice. Consult your local representative
for information on offerings available in
your area.
Lenovo reserves the right to alter speci-
fications and other product information
at any time without prior notice. Lenovo
is not responsible for photographic or
typographical errors. LENOVO PROVIDES
THIS PUBLICATION “AS IS” WITHOUT
WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING THE
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions do
not allow disclaimer of express or implied
warranties in certain transactions; therefore this disclaimer may not apply to you.
This publication was developed in the
US.
Visit www.lenovo.com/safecomputing
periodically for the latest information on
safe and effective computing.
Visit www.lenovo.com/psref
for the latest version of
Product Specifications Reference.
© Lenovo, 2014.
All rights reserved.
Lenovo
1009 Think Place
Morrisville, NC 27560
U.S.A.
lmwbook.pdf
Loading...
