FEATURES & BENEFITS:
• EPEAT Gold rating for the industry’s greenest monitor
• Low power consumption is up to 35% lower than previous
model (L171) for greater TCO
• 17-inch (432.0 mm) viewable image size
• Native resolution of 1280x1024
• Adjustable tilt stand for viewing comfort
• Direct access for automatic image setup, brightness, and
easy monitor setup
• Detachable stand for wall or arm mounting
• Available in business black
The ThinkVision L174 monitor is
proof of Lenovo’s commitment
to be the industry leader for
environmentally friendly and
responsible products. The L174
is an EPEAT Gold rated monitor
and is Lenovo’s rst low power
monitor. The L174 uses up to 35% less power
than its preceding model (L171), providing an
even greater TCO position. This monitor is best
suited for general business applications such as
word processing, spreadsheets, data entry, and
business graphics.
Lenovo ThinkVision L174
LCD Panel
Screen Size/Type 17" Analogue
Aspect Ratio 5:4
Resolution 1280 x 1024
Viewable Area "/mm 17/432
Screen Pitch mm 0.264
Panel Type TN
H/V Viewing Angleso 160/160
Brightness cd/m2 250
Contrast Ratio 700:1
Response Time ms 5
Power Consumption
Maximum Consumption W < 20
Power Off (max) W < 2
Internal Power Supply Yes
Signal Input
Video Inputs Analogue
Video Cable(s) Supplied VGA
Sync-on-Green No
OSD Menu Yes
Preset/User Modes 16/20
Lockable Controls Yes
OSD (Languages) 7
Compliance
Emissions TCO-03 (9227AG1)
TCO-99 (9227AE1)
EPEAT Gold
ENERGY STAR 4.1
RoHS (EU 2002/95/EC) Yes
Windows Vista® Compliance Basic
Plug and Play DDC/CI
Image Quality Capability ISO 13406-2
Mechanical
Tilt (front/back)o 4/30
Lift Swivel (left/right) Pivot VESA Mount mm 100
Kensington Lock Slot Yes
USB Hub Multimedia Optional Soundbar
Colour Business Black
Dimensions
Size (Unpacked, HxWxD) mm/" 387x371x173
15.3x14.6x6.8
Bezel Width mm/" 14/0.6
Weight (Unpacked) kg/lbs 4.2/9.3
Warranty
Warranty 3 Years
Part Numbers
Part Number T27AGxx
MTM/PN 9227-AG1
9227-AE1
EAN EMEA 883609492151
UPC US 883609805173
UPC ASEAN 0883609805197
UPC ANZ 883609805203
UPC Japan -
Availability: Specications and availability may change without notice. Lenovo is not responsible for photographic or typographic errors. International Warranty Service: available
for most models in any country in which this product is sold and serviced. Service delivery methods and parts availability vary by country, may be different from that in the country of
purchase, and are subject to change without notice. Fees and restrictions may apply in some countries. Warranty statements for all products are available for download from www.
lenovo.com. Lenovo makes no representation or warranty regarding third party products or services. Energy Star: As an Energy Star Partner, Lenovo has determined that this product
meets the Energy Star guidelines for energy efciency. Trademarks: Lenovo, the Lenovo logo and ThinkVision are trademarks of Lenovo. All rights reserved. Microsoft, Windows and Vista
are registered trademarks of Microsoft Corporation. Other company, product and service names may be trademarks or service marks of others. Energy Star is a U.S. registered trademark.
Lenovo ThinkVision L174
TechnicalSpecications
