Lenovo TAB 2 A7
Lenovo TAB 2 A7-10F
Lenovo TAB 2 A7-20F
User Guide V1.0
Please read the safety precautions and important notes
in the supplied manual before use.
Chapter 01
Lenovo TAB 2 A7 Overview
1-1 Appearance
1-2 Buttons
1-3 Activating/Deactivating the display
1-4 Screen lock/unlock
1-5 Navigation tips
1-6 Home screen
1-7 Status bar
1-8 Recent apps
1-9 Application management
1-10 Entering text
Tips
Model & Version
Model Version
Lenovo TAB 2 A7-10F WLAN
Lenovo TAB 2 A7-20F WLAN
1-1 Appearance
Images are for reference purposes only, and may differ from your Lenovo TAB 2 A7.
NOTE: Only Lenovo TAB 2 A7-20F has a rear camera.
1-2 Buttons
On/Off button
To turn on your tablet, press and hold this button for about 3 seconds, then release it.
If your tablet is turned on, press this button to deactivate the display. If the display is
deactivated, press this button to activate the display.
To turn off your tablet, press and hold this button for about 1 second, then select OK
in the Power off pop-up window to shut down your tablet.
To restart your tablet, press and hold this button until the Lenovo logo appears.
NOTE: When connecting to a computer with a USB cable, make sure that the battery power
is sufficient for normal operation; otherwise, charge with the AC power adaptor before
making the USB connection.
Volume controls
Press the Volume up or Volume down button to adjust the volume.
1-3 Activating/Deactivating the display
Activating the display
With the display deactivated, press the On/Off button on the tablet to activate the display.
The tablet's display will then illuminate, indicating that it has been activated.
Deactivating the display
If you do not need to use your tablet temporarily, you can press the On/Off button to
deactivate the display. Your tablet will then enter standby mode to save power.
1-4 Screen lock/unlock
Screen lock
Auto-lock
You can set screen timeout by tapping
operation within the pre-set standby time, the display will automatically deactivate and your
tablet will be locked automatically.
Manual lock
If you do not need to use your tablet temporarily, you can press the On/Off button for
about 1 second to deactivate the display. Your tablet will then be locked, and will enter
standby mode.
Settings > Display > Sleep. If there is no
Screen unlock
When in standby mode, press the On/Off button on your tablet to activate the display.
Then, tap and hold the lock icon and drag the slider over the unlock icon, as shown in the
illustration below.
Screen lock pattern setting
You can set the screen lock pattern by tapping Settings > Security > Screen lock
> Pattern. After this function has been enabled, you will be required to trace a personalised
unlock pattern to unlock the screen before you can use your tablet.
1-5 Navigation tips
1 - Back 2 - Home
3 - Recent apps 4 - Advanced menu
Back : Return to the previous screen.
Home : Return to the Home screen.
Recent apps : Display recently used apps.
Advanced menu : Display shortcuts such as Add, Theme, Wallpaper, Screen
manager, Desktop settings and Settings.
1-6 Home screen
This desktop enables you to quickly view and open all your applications.
In the Home screen, you can add widgets and change your wallpaper.
To add a shortcut to the Home screen, tap and hold the icon of the other screen until it
is added to the Home screen.
To change your wallpaper, tap > Wallpaper to choose a wallpaper from Local
wallpaper.
To delete something from the Home screen, tap and hold the selected item for about 2
seconds until appears beside the item, then tap area to remove it.
Switching Home screens
Your tablet has multiple desktops.
Move through screens by sliding your finger across the display. Icons can be moved from
one panel to another.
1-7 Status bar
System messages, if any, will be displayed in the status bar.
Information about WLAN connections and reception, power levels, charging status and other
notifications are displayed in the status bar.
Drop down the status bar to display the notification panel, which contains the Airplane mode
switch, WLAN setting shortcut, Auto-rotate screen switch, Brightness adjustment toolbar,
Settings shortcut etc.
1-8 Recent apps
Your tablet remembers apps you have used recently.
Tap
Tap the app left or right to end it.
to display a list of your recently used apps. Tap an app from the list to open it.
1-9 Application management
Slide your finger on the Home screen to open the applications list.
Tap
Settings > Apps
to manage all your apps.
Uninstall
1. Tap the app you want to uninstall under the Downloaded tab.
2. Tap Uninstall at the top.
3. Tap OK.
Stop a running app
1. Tap Running tab.
2. Tap the running app you want to stop.
3. Tap Stop.
4. Tap OK.
1-10 Entering text
You can easily enter text from the virtual keyboard directly on the touch screen, such as
when adding contact information in the Contacts application. You can input English letters
and numeric symbols directly on the touch screen.
Virtual keyboard
Tap
the virtual keyboard.
on the bottom bar to hide the virtual keyboard. Tap the text input box to display
Switch input method
Tap / to toggle letters and numbers.
Tap to enter a capital letter. Or tap and hold until it changes into
to turn caps lock on. Tap it again to unlock.
In number input mode, tap to input symbols and special characters. Tap
to go back to number input mode.
Input options
Tap Settings > Language & input to open the KEYBOARD & INPUT
METHODS menu. You can select Google Keyboard or Google voice typing in this
menu.
Cover: Lenovo TAB 2 A7 user guide
Chapter 02: Connecting to the
Internet
Chapter 02
Connecting to the Internet
2-1 Browser
2-1 Browser
Network support is required to access the Internet with the web
browser. If you have problems accessing your network, please
consult your network operator or service provider directly.
The web browser in your tablet can access the Internet via a WLAN for
business and/or personal use.
Tap
The browser supports the following functions:
Chrome in the home screen to open the browser.
Entering web addresses
Tap the address bar, and input a web address using the pop-up virtual
keyboard.
Tap GO on the virtual keyboard to open the web page.
Exiting the browser
Tap on the bottom bar to exit the browser and return to the
Home screen.
BOOKMARKS:
Displays a list of all the web pages that you have added to
BOOKMARKS. To add a bookmark, tap
to add the current
web page to BOOKMARKS. To edit a bookmark, tap and hold the
bookmark to open a pop-up window. From the window, you can
open, edit, copy, share or delete the selected website, create a
shortcut for it, set it as your homepage or perform other operations.
HISTORY:
Displays a list of all the web pages you have visited recently.
SAVED PAGES:
Displays a list of all the web pages you have saved for offline reading.
Tabbed browsing
You can open several web pages in the same window to multiply your
web surfing fun. Tap to open a new tab. To switch to another
web page, just tap its tab. Tap on the tab to close it.
Additional functions
Tap to manually refresh a web page.
Refresh:
Backwards/Forwards: Tap
previous page or to go to the next page.
or to return to the
Select text: Select text in the current page for copying, sharing,
finding and web searching.
More options: Tap
include Bookmarks/History, Downloads/Files, My Videos, Scan QR
Code, Share, Find in page, Request Desktop sites, Settings, Exit.
Chapter 01: Lenovo TAB 2 A7
Overview
to display an option list. These options
Chapter 03: Applications
Chapter 03
Applications
3-1 Calendar
3-2 Camera
3-3 Clock
3-4 Email
Slide your finger to the left on the Home screen to open the
applications list.
3-1 Calendar
Tap Calendar in the applications list to open the calendar.
New Calendar event
Tap in the Calendar view to create a new event. You can also
create a new event by tapping and holding a time in the Week or Day
view.
Manage Calendar events
You can switch between Day, Week, Month and Year by tapping the
appropriate tab at the top of the page.
Day view: Tap an event in Day view to view, edit, delete or share the
event.
Week view: Tap an event in Week view to view, edit, delete or share
the event.
Month view: Manage events in the last view from Month view by
tapping any date in the Month view.
Year view: Tap to view events across a range of years.
Tap
current day.
in the Calendar view to access the calendar for the
3-2 Camera
Tap Camera in the applications list to open the camera interface.
In this interface, you can perform the following operations:
Switch Camera modes
Your tablet provides you with three camera modes. In the camera
interface, tap
other modes to take pictures.
to switch to Normal mode. You can also tap
Photos
Taking Photos
In the photo interface, tap
Tap
Viewing Photos
A thumbnail image of the latest taken photo will be displayed on the
lower-right corner. Tap the image to open the photo-viewing
interface. You can set and play photo slideshows.
to set the camera properties.
to take a picture.
Photo saving location
Any photos you have taken will be saved in the Gallery application.
Tap
you have taken.
Gallery in the home screen to open a list of all the photos
Videos
Recording Videos
Tap
to stop recording.
in the video interface to start recording, or tap
Viewing Videos
A thumbnail image of the latest recorded video will be displayed on
the lower-right corner. Tap the image to open the video player.
3-3 Clock
Tap Clock in the applications list to open the Clock.
To add an alarm, tap
editing the alarm, tap Done to activate the alarm.
To restart an already set alarm, tap
When an alarm sounds, drag
or to
to delay it for 5 minutes.
and then . After you have finished
to status.
to to deactivate the alarm,
3-4 Email
Network support is required to use your tablet's mailbox. If you have
problems accessing your network, please consult your network
operator or service provider directly.
Tap
Email
Chapter 02: Connecting to the
in the home screen.
Internet
Chapter 04: Settings
Chapter 04
Settings
4-1 WIRELESS & NETWORKS
4-2 DEVICE
4-3 PERSONAL
4-4 SYSTEM
Tap
Settings
interface.
in the applications list to open the Settings
4-1 WIRELESS & NETWORKS
This setting module includes: WLAN, Bluetooth, Data usage, and
More... (Airplane mode,Tethering , VPN, USB Internet).
WLAN
This setting allows you to enable/disable WLAN connections.
When WLAN is enabled, your tablet will automatically scan for
available wireless networks, displaying them in the WLAN network
list.
The network status icon,
no password, and can be connected to directly. However,
indicates that the network has been encrypted, and can be connected
to only after the required password is entered.
You can select any network you want from the list. After selecting the
network, enter the password and tap Connect to connect directly.
Alternatively, select the tick box before Show advanced options to
adjust the proxy and IPv4 settings in the pop-up text box, and then
indicates that the network requires
tap Connect to connect to a network. You can also select Add
network to manually add a network. Tap
advanced WLAN settings.
Network notification: When activated, the system will notify
you if there are any open networks available.
Keep WLAN on during sleep: During sleep, keep WLAN on
Always, Only when plugged in or Never (increases data
usage).
Scanning always available: Let Google's service and other
apps scan for networks, even when WLAN is off.
Avoid poor connections: Don't use WLAN network unless it
has a good Internet connection.
Install certificate: You can install the certificate.
WLAN optimisation: When activated, the system will minimise
battery usage when WLAN is on.
MAC address: View the MAC address.
IP address: View the IP address.
Bluetooth
> Advanced for
You can establish a wireless connection with any other Bluetoothcompatible device using Bluetooth technology. Examples of Bluetoothcompatible devices can include stereo earphones, keyboard etc.
Since a Bluetooth-enabled device communicates with other devices by
radio waves, you do not have to position your tablet directly towards
the other device. However, please note that the Bluetooth connection
can sometimes be interrupted by obstacles, such as walls or other
electronic devices.
Your tablet supports Bluetooth V4.0. To ensure effective operation of
your tablet and another Bluetooth-enabled devices, please use only
Lenovo-approved accessories compatible with your tablet. Also, check
with the manufacturer of the other device to determine whether the
device is compatible with your tablet.
In some cases, the use of Bluetooth may be restricted. Please consult
with local authorities or your service provider.
Using applications that require Bluetooth technology or running such
applications in the background will consume the battery power of
your tablet at a faster rate, and reduce the service life of your
battery. You can perform the following in Bluetooth settings:
AVAILABLE DEVICES: After Bluetooth has been activated, your
tablet will automatically display a list of any Bluetooth-enabled
devices it can find within the effective range (i.e. scan for
devices).
Data usage
You can check your data usage status for a specified period.
More...
Airplane mode: When Airplane mode is enabled, all wireless
connections on your tablet will be disabled.
Tethering: You can share your tablet's cellular data connection
through USB, Bluetooth or act as a Portable WLAN hotspot.
VPN: These settings allow you to add and set up various types of
VPNs (Virtual Private Networks).
USB Internet: Sharing Windows PC internet via USB cable.
4-2 DEVICE
Audio profile
Tap Settings > DEVICE > Audio profiles to enter the profile
settings interface. The Profile setting include General, Silent,
Meeting and Outdoor. Tap General, Settings include GENERAL
(Power audio playback and Volume), NOTIFICATION (Notification
Ringtone) and SYSTEM ( Touch sounds, screen lock sound and
vibrate on touch).
Display
Tap Settings > DEVICE > Display to enter the display settings
interface. Display settings include Brightness, Sleep, Daydream,
Font size and Cast screen.
Brightness: You can manually adjust the brightness.
Sleep: This option allows you to select how long your tablet's screen
will remain activated without any operation before it is automatically
locked to save power. You can set the time to 15 seconds, 30
seconds, 1 minute, 2 minutes, 5 minutes, 10 minutes or 30
minutes.
Daydream: This option allows you to set the interactive screen
savers.
Font size: This option allows you to set the font size from Small,
Normal, Large or Huge.
Cast screen: You can cast the screen to a TV.
Storage
Tap Settings > Storage to view internal storage.
Nominal capacity calculation method: 1 GB = 1,000 MB = 1,000,000
KB = 1,000,000,000 bytes
Operating system calculation method: 1 GB = 1,024 MB = 1,048,576
KB = 1,073,741,824 bytes
The system itself occupies some space; therefore, available space will
be less than that calculated.
Battery
Tap Settings > Battery to check battery usage data, remaining
power status and battery usage history details.
Apps
Tap Settings > Apps, to easily manage and delete selected
applications.
You can also filter any running applications or applications provided by
third-party software developers in the applications list.
After selecting an application, you will then be able to see its details
and related information. You will also be able to perform functions
such as Force stop, Uninstall, Clear cache and Clear data etc.
4-3 PERSONAL
This setting includes: Location, Security, Language & input and
Backup & reset.
Location access
Tap Settings > PERSONAL > Location, you can enable apps to use
your location information and select how your tablet determines its
location.
Security
Tap Settings > Security to access security settings, which include:
SCREEN SECURITY, ENCRYPTION,PASSWORDS, DEVICE
ADMINISTRATION and CREDENTIAL STORAGE.
SCREEN SECURITY: You can set the screen lock method and owner
information to be displayed on the lock screen.
Screen lock: You can unlock the display in one of four ways:
Slide, Pattern, PIN and Password. You can also deactivate
the screen lock by selecting None as well.
Tap Pattern, use your finger on the screen (as illustrated)
to draw an unlock pattern. Once you have set the unlock
pattern, you will then be able to toggle Make pattern
visible on/off.
After you have set and activated the pattern unlock
function, the unlock keypad will be displayed whenever
the display is to be unlocked. Use your finger to trace
your pre-set pattern on the keypad. After the pre-set
pattern has been correctly entered, the screen will be
unlocked.
Tap PIN to input the PIN code (minimum 4 digits) you will
use to unlock the display.
Tap Password to input the password (minimum 4
characters) you will use to unlock the display.
PASSWORDS: Under this option, you can decide whether or not your
chosen password will be visible when you input it. If the tick box is
selected, then the password will be visible. If it is not selected, then
your password will only be displayed as ···· when you input it,
thereby keeping your password more secure.
DEVICE ADMINISTRATION: Set to administrate your tablet and
allow to install apps from unknown sources.
Device administrators: These functions are not available to
ordinary users.
Unknown sources: Select this option to allow to install apps
from unknown sources.
Verify apps: Select this option to disallow or warn about
installation of apps that may cause harm.
CREDENTIAL STORAGE: This function allows your tablet to access
web pages and LANs for which a specific security certificate or
another certificate is required.
Storage type: Show the storage type of the certificates.
Trusted credentials: Select this option to display all the
trusted CA certificates.
Install from SD card: Install certificates from SD cards.
Clear credentials: Select this option to delete all your currently
saved certificates.
Language & input
Language: Select the language you wish to use to operate your
tablet.
Spell checker: Toggle spelling correction on/off.
Personal dictionary: You can add new words or terms here to your
tablet's dictionary.
KEYBOARD & INPUT METHODS: This option allows you to select
and set the input methods (including Google Keyboard and Google
voice typing.
）
SPEECH: This option allows you to set the Voice control and search
and general settings for text-to-speech output.
MOUSE/TRACKPAD: Under this option you can adjust the pointer
speed.
Backup & reset
This option allows you to back up your data, clear all DRM licences
and reset your tablet to the factory default settings.
4-4 SYSTEM
Date & time
These settings allow you to set a number of time-related options, such
as system time.
You can enable automatic time and time zone updates via a network
(which requires network support), select a time zone, set a specific
date and time, and display format for date and time.
Accessibility
SERVICES: This option allows you to turn on Talkback.
SYSTEM: This option allows you to set a Magnification gestures and a
large text, whether to allow the installation of web scripts and to
toggle Auto-rotate screen ON/OFF.
About tablet
Under this option, you can view System Update, Status, Legal
information, Model number, Android version, Baseband
version, Kernel version, Build number, CPU, RAM, Internal
storage etc.
Chapter 03: Applications Chapter 05: Appendix
Chapter 05
To avoid personal injury, property damage, or accidental damage to the product, read all of the
this section before using the product. For additional tips to help you operate your device safely
Do not drop, bend, or puncture your device; do not insert foreign objects into or place heavy ob
Your device screen is made of glass. The glass might break if the device is dropped on a hard s
subject of a high impact, or is crushed by a heavy object. If the glass chips or cracks, do not to
glass or attempt to remove it from the device. Stop using the device immediately and contact L
When using your device, keep it away from hot or high-voltage environments, such as electric
electric heating equipment, or electric cooking equipment. Use your device only in the tempera
Your device is a sealed unit. There are no end-user serviceable parts inside. All internal repairs
a Lenovo-authorized repair facility or a Lenovo-authorized technician. Attempting to open or m
Tip: if the tablet fails to turn on due to accidental improper operation or other reasons
in the power adapter and then pressing the power button for 10 seconds to activate t
Do not attempt to replace the internal rechargeable lithium ion battery. Contact Leno
Appendix
5-1 Important safety and handling information
5-2 Electronic emission notices
5-3 Environmental, recycling, and disposal information
5-1 Important safety and handling information
http://www.lenovo.com/safety.
Handle your device with care
device. Sensitive components inside might become damaged.
support for repair, replacement, or disposal information.
0°C (32°F)—40°C (104°F)(storage -20°C (-4°F)—60 °C (140°F)) to avoid damage.
Do not disassemble or modify your device
will void the warranty.
Built-in rechargeable battery notice
DANGER:
factory replacement.
Plastic bags can be dangerous. Keep plastic bags away from babies and children to av
Do not immerse your device in water or leave your device in a location where it can get saturate
You can use any of the following charging methods to safely recharge the internal battery of yo
D
Supporte
Supporte
battery
Charging devices might become warm during normal use. Ensure that you have adequate venti
Lenovo is not responsible for the performance or safety of products not manufactured
Your device has a headphone connector. Always use the headphone connector for headphones (
Excessive sound pressure from earphones and headphones can cause hearing loss. Ad
the equalizer to maximum increases the earphone and headphone output voltage and
pressure level. Therefore, to protect your hearing, adjust the equalizer to an appropr
Plastic bag notice
DANGER:
suffocation.
Adapter information
Prevent your device and ac adapter from getting wet.
other liquids.
Use approved charging methods only.
Charging method Display on
ac adapter
USB connection between the dc-in
connector on the device and a USB
connector on a personal computer or
other device that comply with the USB
2.0 standards. Users have to use the
connection to USB interfaces with USB
2.0 version or higher.
Notes:
Supported, but the battery will charge
slowly.
Supported, but will compensate power
consumption and the battery will charge
more slowly than usual.
slowly.
Display on: Device on
Display off: Device off or in screen lock mode
charging device. Unplug the charging device if any of the following occurs:
The charging device has been exposed to rain, liquid, or excessive moisture.
The charging device shows signs of physical damage.
You want to clean the charging device.
Warning:
by Lenovo. Use only approved Lenovo ac adapters and batteries.
Prevent hearing damage
headset) or earphones.
CAUTION:
Excessive use of headphones or earphones for a long period of time at high volume can be dan
output of the headphone or earphone connectors do not comply with specifications of EN 50332
The headphone output connector of your device complies with EN 50332-2 Sub clause 7. This s
limits the device's maximum wide band true RMS output voltage to 150 mV. To help protect ag
loss, ensure that the headphones or earphones you use also comply with EN 50332-2 (Clause 7
wide band characteristic voltage of 75 mV. Using headphones that do not comply with EN 5033
If your device came with headphones or earphones in the package, as a set, the combination o
or earphones and the device already complies with the specifications of EN 50332-1. If differen
earphones are used, ensure that they comply with EN 50332-1 (Clause 6.5 Limitation Values).
headphones that do not comply with EN 50332-1 can be dangerous due to excessive sound pre
For the device that is tested in accordance with EN 60950-1: 2006+A11:2009:+A1:2010
mandatory to perform audio tests for EN50332. This device has been tested to comply wi
Pressure Level requirement laid down in the applicable EN 50332-1 and/or EN 50332-2 st
Permanent hearing loss may occur if earphones or headphones are used at high volume f
To prevent possible hearing damage, do not listen at high volume levels for a lon
Always prioritize your safety and the safety of others. Follow the law. Local laws and regulations
how you can use mobile electronic devices, such as your device, while you drive a motor vehicl
When your device reaches the end of its useful life, do not crush, incinerate, immerse in water,
your device in any manner contrary to local laws and regulations. Some internal parts contain s
Your device contains small parts that can be a choking hazard to small children. Additionally, th
Do not delete unknown files or change the name of files or directories that were not created by
Be aware that accessing network resources can leave your device vulnerable to computer virus
spyware, and other malicious activities that might damage your device, software, or data. It is
responsibility to ensure that you have adequate protection in the form of firewalls, antivirus sof
Keep electrical appliances away from your device, such as an electric fan, a radio, high-powere
air conditioner, and a microwave oven. The strong magnetic fields generated by electrical appli
dangerous due to excessive sound pressure levels.
Sound pressure warning statement
periods of time.
Warning statement
time.
Take care when using your device in a motor vehicle or on a bicycle
bicycle.
Dispose according to local laws and regulations
can explode, leak, or have an adverse environmental affect if disposed of incorrectly.
See “Recycling and environmental information” for additional information.
Keep your device and accessories away from small children
can break or crack if dropped on or thrown against a hard surface.
Protect your data and software
your device software might fail to work.
spyware software and keep such software up to date.
damage the screen and the data on the device.
Be aware of heat generated by your device
When your device is turned on or the battery is charging, some parts might become hot. The te
they reach depends on the amount of system activity and the battery charge level. Extended co
body, even through clothing, could cause discomfort or even a skin burn. Avoid keeping your h
or any other part of your body in contact with a hot section of the device for any extended time
WARNING: Handling the cord on this product or cords associated with accessories sold with this
expose you to lead, a chemical known to the State of California to cause cancer, and birth defe
This equipment has been tested and found to comply with the limits for a Class B digital device,
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmfu
a residential installation. This equipment generates, uses, and can radiate radio frequency ener
installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
this equipment does cause harmful interference to radio or television reception, which can be d
turning the equipment off and on, the user is encouraged to try to correct the interference by o
Connect the equipment into an outlet on a circuit different from that to which the receiver is c
Lenovo is not responsible for any radio or television interference caused by unauthorized chan
modifications to this equipment. Unauthorized changes or modifications could void the user’s a
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two c
this device may not cause harmful interference, and (2) this device must accept any interferen
The antenna(s) used for this transmitter must not be co-located or operating in conjunction with
Polyvinyl Chloride (PVC) cable and cord notice
reproductive harm. Wash hands after handling.
5-2 Electronic emission notices
Federal Communications Commission (FCC) Declaration of Conformity
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Consult an authorized dealer or service representative for help.
operate the equipment.
including interference that may cause undesired operation.
Responsible Party: Lenovo (United States) Incorporated
1009 Think Place - Building One
Morrisville, NC 27560
Telephone: 1-919-294-5900
FCC Caution
antenna or transmitter.
Industry Canada Class B emission compliance statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
IC Caution
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subjec
(2) this device must accept any interference, including interference that may cause undesired o
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio e
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le broui
European Union-Compliance to the Electromagnetic Compatibility Directive
This product is in conformity with the protection requirements of EU Council Directive 2004/108
approximation of the laws of the Member States relating to electromagnetic compatibility. Leno
responsibility for any failure to satisfy the protection requirements resulting from a nonrecomm
modification of the product, including the installation of option cards from other manufacturers
This product has been tested and found to comply with the limits for Class B Information Techn
according to European Standard EN 55022. The limits for Class B equipment were derived for t
environments to provide reasonable protection against interference with licensed communicatio
Hinweis für Geräte der Klasse B EU-Richtlinie zur Elektromagnetischen Verträglichkeit Dieses Pr
den Schutzanforderungen der EU-Richtlinie 2004/108/EG (früher 89/336/EWG) zur Angleichung
Rechtsvorschriften über die elektromagnetische Verträglichkeit in den EU-Mitgliedsstaaten und
Grenzwerte der EN 55022 Klasse B ein. Um dieses sicherzustellen, sind die Geräte wie in den H
beschrieben zu installieren und zu betreiben. Des Weiteren dürfen auch nur von der Lenovo em
angeschlossen werden. Lenovo übernimmt keine Verantwortung für die Einhaltung der Schutza
wenn das Produkt ohne Zustimmung der Lenovo verändert bzw. wenn Erweiterungskomponent
Einhaltung des Gesetzes über die elektromagnetische Verträglichkeit von Betriebsmitteln Diese
entspricht dem „Gesetz über die elektromagnetische Verträglichkeit von Betriebsmitteln“ EMVG
über die elektromagnetische Verträglichkeit von Geräten“). Dies ist die Umsetzung der EU-Rich
Zulassungsbescheinigung laut dem Deutschen Gesetz über die elektromagnetische Verträglichk
Betriebsmitteln, EMVG vom 20. Juli 2007 (früher Gesetz über die elektromagnetische Verträglic
Geräten), bzw. der EMV EG Richtlinie 2004/108/EC (früher 89/336/EWG), für Geräte der Klasse
Dieses Gerät ist berechtigt, in Übereinstimmung mit dem Deutschen EMVG das EG-Konformität
zu führen. Verantwortlich für die Konformitätserklärung nach Paragraf 5 des EMVG ist die Leno
two conditions:
(1) This device may not cause interference, and
device.
licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
susceptible d'en
Industry Canada Class B Emission Compliance Statement
This Class B digital apparatus complies with Canadian ICES-003.
Avis de conformité à la réglementation d’Industrie Canada
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
EU contact: Lenovo, Einsteinova 21, 851 01 Bratislava, Slovakia
German Class B compliance statement
Deutschsprachiger EU Hinweis:
Fremdherstellern ohne Empfehlung der Lenovo gesteckt/eingebaut werden.
Deutschland:
2004/108/EG (früher 89/336/EWG) in der Bundesrepublik Deutschland.
GmbH, Gropiusplatz 10, D-70563 Stuttgart.
Informationen in Hinsicht EMVG Paragraf 4 Abs. (1) 4:
Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022 Klasse B.
Korea Class B compliance statement
情報技術装置です。この装置は、家庭環境で使用することを目的としていますが、この
取扱説明書に従って正
Japan compliance statement for products which connect to the power mains with rated current
Lenovo encourages owners of information technology (IT) equipment to responsibly recycle the
when it is no longer needed. Lenovo offers a variety of programs and services to assist equipm
The Lenovo product meets the requirements of the Republic of Turkey Directive on the Restricti
na Dair Yönetmelik (AEEE)” direktiflerine uygundur. AEEE Yönetme
Descarte de um Produto Lenovo Fora de Uso Equipamentos elétricos e eletrônicos não devem se
em lixo comum, mas enviados à pontos de coleta, autorizados pelo fabricante do produto para
encaminhados e processados por empresas especializadas no manuseio de resíduos industriais
certificadas pelos orgãos ambientais, de acordo com a legislação local. A Lenovo possui um can
para auxiliá-lo no descarte desses produtos. Caso você possua um produto Lenovo em situação
ligue para o nosso SAC ou encaminhe um e-mail para: reciclar@lenovo.com, informando o mod
série e cidade, a fim de enviarmos as instruções para o correto descarte do seu produto Lenovo
Recycling and disposal information for Japan is available at: http://www.lenovo.com/recycling/j
B급 기기(가정용 방송통신기자재)
이 기기는 가정용(B급)전자파적합기기로서 주로 가정에서 사용하는
것을 옥적으로 하며,모든 지역에서 사용할 수 있습니다
Japanese VCCI Class B statement
この装置は、クラス
レビジョン受信機に近接して使用されると、受信障害を引き起こすことがあります。
て下さい。 VCCI-B
equal to 20 A per phase.
日本の定格電流が 20A/相 以下の機器に対する高調波電流規制
高調波電流規格
B
JIS C 61000－3－2
適合品
5-3 Environmental, recycling, and disposal information
General recycling statement
recycling their IT products. For information on recycling Lenovo products, go to:
http://www.lenovo.com/recycling.
General recycling statement
Country-specific information is available at http://www.lenovo.com/recycling.
Turkish statement of compliance
Certain Hazardous Substances in Electrical and Electronic Equipment (WEEE).
Bu Lenovo ürünü, T.C. Çevre ve Orman Bakanlığı’nın “Atık Elektrikli ve Elektronik Eşya Bazı Za
Kullanımının Sınırlandırılması
Declarações de Reciclagem no Brasil Declarações de Reciclagem no Brasil
Recycling information for Japan Recycling information for Japan
Recycling information for India Recycling information for India
Recycling and disposal information for India is available at:
http://www.lenovo.com/social_responsibility/us/en/sustainability/ptb_india.html.
Battery recycling marks Battery recycling marks
The battery recycling information of Taiwan
Battery recycling information for the United States and Canada
Battery recycling information for the European Union
Chapter 04: Settings Chapter 06: Troubleshooting
Chapter 06
Troubleshooting
Insufficient memory prompt appears during app
installation
Please free up some memory and try to install again
Cannot start or system crashed
Please charge the battery for half an hour and then long-press the
power key for over 10 seconds to restart
Press the Reset button behind the micro SD card slot cover, but
please be noted that this method should be used carefully.
Makes no sound when called or is not audible
Please adjust the volume using the volume keys
Cannot access the internet via wireless network
Restart the wireless router or go to Settings and restart WLAN
Cannot wakeup the tablet from sleep mode
Please long-press the power key to restart
Chapter 05：Appendix www.lenovo.com
Loading...
