Chapter 1. Getting to Know Your Computer

Top View - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

* The illustrations in this manual may differ from the actual product.















Lenovo 3000 N500 UG V1.0_en.book Page 2 Monday, September 1, 2008 9:44 AM

Chapter 1. Getting to Know Your Computer

Integrated camera (Specific Models only) ..................................... 19

Computer display

The color display with TFT technology provides clear and brilliant text and graphics.

Lenovo CareSM button..................................................................... 16

Power button

Use the Power button to turn on the computer.

System status indicators

The system status indicators show the current status of your computer.

Microphone (built-in)

The built-in microphone can be used for video conferencing, voice narration, or simple audio recordings.

Touch sensor and volume buttons................................................. 15

Lenovo 3000 N500 UG V1.0_en.book Page 3 Monday, September 1, 2008 9:44 AM

Chapter 1. Getting to Know Your Computer

Left-side View - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -















Lenovo 3000 N500 UG V1.0_en.book Page 4 Monday, September 1, 2008 9:44 AM

Chapter 1. Getting to Know Your Computer

Fan louvers

The fan louvers allow heated air to exit the computer.

Important:



Make sure that paper, books, clothing, cables or other objects do not block any of the fan louvers otherwise, overheating of the computer may occur.

LAN port............................................................................................ 20

VGA port ........................................................................................... 40

PCI Express card slot ...................................................................... 38

Security keyhole

Your computer comes with a security keyhole. You can purchase a security cable and lock to fit this keyhole.

Note:



Before purchasing any security product, verify that it is compatible with this type of security keyhole.

HDMI port (Specific models only)

USB 2.0 port ..................................................................................... 37









Lenovo 3000 N500 UG V1.0_en.book Page 5 Monday, September 1, 2008 9:44 AM

Chapter 1. Getting to Know Your Computer

Right-side View - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

b da c

Modem Port (Specific models only) ............................................... 22

USB 2.0 port ..................................................................................... 37

Optical drive ..................................................................................... 17

AC power adapter jack

Connect the power adapter here to supply power to the computer and charge the internal battery.

Note:



To prevent damage to the computer and battery pack, use the supplied AC adapter only.











Lenovo 3000 N500 UG V1.0_en.book Page 6 Monday, September 1, 2008 9:44 AM

Chapter 1. Getting to Know Your Computer

Front View - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

a ab c de

Speakers

Built-in speakers for rich powerful sound.

Wireless device switch (Specific models only)

Use this switch to simultaneously turn on or turn off Wireless LAN and

Bluetooth

Microphone jack (external).............................................................. 42

Headphone (external) ...................................................................... 41

Multi-media reader slot (Specific models only) ............................ 18

devices.

Lenovo 3000 N500 UG V1.0_en.book Page 7 Monday, September 1, 2008 9:44 AM

Chapter 1. Getting to Know Your Computer

Bottom View - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

edf











Lenovo 3000 N500 UG V1.0_en.book Page 8 Monday, September 1, 2008 9:44 AM

Chapter 1. Getting to Know Your Computer

Battery latch - manual

The manual battery latch is used to keep the battery pack secured. Move the manual battery latch to the unlocked position to insert or remove the battery pack. Move the manual latch to the locked position after inserting the battery pack.

Battery pack ..................................................................................... 32

Battery latch - spring loaded

The spring-loaded battery latch keeps the battery pack secured in place. When you insert a battery pack, this latch automatically secures the battery in place. To remove the battery, hold this latch in the unlocked position.

WLAN card compartment

The wireless network card (Specific models only) can be secured in this compartment for easy access.

Central processing Unit (CPU)/ Memory (RAM) compartment

 Central processing Unit (CPU)

The CPU compartment provides space for the CPU and the radiator.



Lenovo 3000 N500 UG V1.0_en.book Page 9 Monday, September 1, 2008 9:44 AM

Chapter 1. Getting to Know Your Computer

Important:



Do not replace the CPU! Visit an authorized service center or retailer for replacement.

 Memory (RAM) compartment

The memory compartment provides expansion capabilities for additional memory. The BIOS automatically detects the amount of memory in the system and configures CMOS accordingly during the Power-On Self-Test (POST) process. There is no hardware or software (including BIOS) setup required after the memory is installed.

Note:



(1) Only purchase expansion modules from authorized retailers of

this computer to ensure maximum compatibility and reliability.

(2) If you only insert one memory card in the compartment, plug it

into the slot near the mainboard.

Hard Disk Drive compartment

The hard disk drive is secured in this compartment.

Lenovo 3000 N500 UG V1.0_en.book Page 10 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

Putting Your Computer to Sleep or Shutting It Down

When you finish working with your computer, you can put it to sleep or shut it down.

 Putting Your Computer to Sleep

If you will be away from your computer for only a short time, put the computer to sleep. When the computer is in sleep state, you can quickly wake it to resume use,

and bypass the startup process.

To put the computer to sleep, do one of the following.

 Click Start and select Sleep from the Start menu.  Press Fn + F4.

Warning:



Wait until the power indicator light starts blinking (indicating that the computer is in sleep state) before you move your computer. Moving your computer while the hard disk is spinning can damage the hard disk, causing loss of data.

To wake the computer, do one of the following.

 Press the Power button.  Press any key.

 Shutting Down Your Computer

If you are not going to use your computer for a day or two, shut it down. To shut down your computer, click

Start

and select

Shut down

from the Start menu.









Lenovo 3000 N500 UG V1.0_en.book Page 11 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

Using the Touch Pad - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

The touch pad consists of a pad and two click buttons at the bottom of the keyboard. To move the cursor on the screen, slide your fingertip

over the pad in the direction in which you want the cursor to move. The functions of the left and right click buttons correspond to those of

the left and right mouse buttons on a conventional mouse.

Lenovo 3000 N500 UG V1.0_en.book Page 12 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

Note:



You can also attach and use a USB mouse through the USB connector. For details,

page 37

see “Connecting a Universal Serial Bus (USB) Device” on

Using the Keyboard - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Your computer has a numeric keypad and function keys incorporated in the standard keyboard.

 Numeric Keypad

The keyboard has keys that, when enabled, work as a 10-key numeric keypad. To enable the numeric keypad, press Fn+Delete. To disable it, press Fn+NmLk.

* The illustrations in this manual may differ from the actual product.





Lenovo 3000 N500 UG V1.0_en.book Page 13 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

 Function Key Combinations

Through the use of the function keys, perform useful operations more efficiently. To use this feature, press and hold the Fn key , then press one of the function keys .

Lenovo 3000 N500 UG V1.0_en.book Page 14 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

The following describes the features of each function key.

Fn + Esc: Mute computer sound. Fn + F1: Decrease computer volume. Fn + F2: Increase computer volume. Fn + F4: Put your computer in sleep mode. Fn + F5: Enable/disable the built-in wireless device feature. Fn + F7: Shift to other connected display devices. Fn + F10: Decrease display brightness. Fn + F11: Increase display brightness. Fn + F12: Put your computer in hibernation mode. Fn + Insert/ScrLk: Enable/disable Scroll Lock. Fn + Delete/NmLk: Enable/disable the Numeric keypad. Fn + P

rtSc/SysRq: System request. Fn + up arrow: Stop Media Player playback. Fn + down arrow: Play/pause Media Player playback. Fn + left arrow: Skip to the previous track. Fn + right arrow: Skip to the next track. Fn + PgUp: Move the cursor to the head of the line. Fn + PgDn: Move the cursor to the end of the line.









Lenovo 3000 N500 UG V1.0_en.book Page 15 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

Special Keys and Buttons - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Your computer has several special keys and buttons.

 Touch sensor and volume buttons

abcd

* The illustrations in this manual may differ from the actual product.

Mute/unmute the sound. Vol u me d o wn Vol u me u p Enable/disable the touch pad.

Lenovo 3000 N500 UG V1.0_en.book Page 16 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

 Lenovo CareSM button

Press the Lenovo Care button to enter the main interface of Rescue and Recovery while the power is off.

Attention:



When you press Lenovo Care button to turn on the computer, ensure that your computer is not connected with other peripherals (such as USB storage device, etc.), otherwise the system may not operate properly.

Note:



When your computer is running Windows Vista, and if you have the Lenovo Care application installed, you can start the application by pressing the Lenovo Care button.

Lenovo 3000 N500 UG V1.0_en.book Page 17 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

Using the Optical Drive - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

 Playing CDs/DVDs Disc Media

You can play your CDs/DVDs with various applications, such as Windows Media Player, Windows Media Center, etc.

Lenovo 3000 N500 UG V1.0_en.book Page 18 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

Using Memory Cards (Specific models only) - - - - - - - -

Your computer comes with one Multi-media Reader slot (Specific models only) used to insert a memory card, such as a SD Card, a Multi-media card, a Memory Stick or a Memory Stick Pro card.

Note:



Only use memory cards of the type listed above; for more information about the usage, read the instructions supplied with the memory card.

Lenovo 3000 N500 UG V1.0_en.book Page 19 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

 Inserting a Memory Card

1 Push the slot cover in and remove the cover. 2 Slide the memory card in until it clicks into place.

 Removing a Memory Card

1 Push the memory card until you hear a click. 2 Gently pull the memory card out of the Multi-media reader slot.

Using the Integrated Camera (Specific models only)

With the built-in camera, you can take photos or movies and use with various applications, such as EasyCapture, MSN or Yahoo! Messenger, and so on.

Note:



If you use Windows Vista, you need to install a separate third party dedicated application, because Windows Vista does not include a program for taking pictures or movies with the integrated camera.

- - - - - - - - -

Lenovo 3000 N500 UG V1.0_en.book Page 20 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

Using the Internet - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Your computer comes with a LAN port for high-speed DSL/cable modem connection and local area network (LAN), wireless LAN for wireless connection and modem port for dial-up connection.

 Using LAN Port

The LAN port accepts a standard RJ-45 connector, and allows you to connect the computer to a high-speed DSL/cable modem connection and local area network (LAN).

Lenovo 3000 N500 UG V1.0_en.book Page 21 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

Attention:



As the voltage of a telephone connection is higher than that of a network, do not attempt to connect a telephone cable to the LAN port as a short circuit in the computer might occur.

 Using wireless LAN (Specific models only)

A isotropic antenna system is built into the display for optimal reception, enabling wireless communication wherever you are.

To enable wireless communications, do the following;

1 Slide the Wireless device switch (Specific models only) to the right. 2 Press Fn + F5, set Wireless to Enable.

Lenovo 3000 N500 UG V1.0_en.book Page 22 Monday, September 1, 2008 9:44 AM

Chapter 2. Using Your Computer

 Using Modem Port (Specific models only)

The modem port accepts a standard telephone cable with one RJ-11 connector, and allows dial up access to an Internet service provider (ISP).

Important:



Do not connect the modem port to a digital circuit cable, as the current in the digital circuit may damage the modem.

+ 118 hidden pages
