Personal Systems Reference Lenovo® ThinkVision® Monitors
March 2012 - Version 413
ThinkVision L2321x Wide Monitor
Visit www.lenovo.com/psref for the latest version
Lenovo® D186 Wide
Personal Systems Reference (PSREF)
Dimensions (HxWxD)
Power supply
D186 Wide Flat Panel Monitor Business black 2580-AB1
TFT-LCD, twisted nematic (TN), CCFL backlight
18.5" (470mm) diagonal
16.1" x 9.1" / 409.8mm x 230.4mm 1366x768 at 60Hz 1366x768 at 60Hz (135MHz max pixel rate) 16:9 .300mm 85 dpi 200 nits or cd/m2 (typical) 600:1 (typical) 5ms (typical) 67% Anti-refl ective, anti-glare 90° (+/- 45°) horizontal, 50° (+/- 25°) vertical Tilt adjustable stand Sides:
0.61" (15.6mm)
; top: 0.67" (17.1mm);
bottom: 1.19" (30.1mm)
14.6" H x 17.4" W x 8.3" D; 370mm H x 442mm W x 210mm D 16 watts typical, 24 watts maximum, <1 watts standby/suspend, universal,
integrated (no external brick-like power supply) Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Pixel defect Emission standards Environmental
Preset resolutions
7.28 lb; 3.3kg
3 years (includes backlight)
January 2010
VESA DDC2B/CI, VESA DPMS-compliant
None
ISO 9241-307
ISO 9241-307 pixel defect standard
FCC Class B
WEEE, RoHS (EU Directive 2002/95/EC),
VGA: 640x350, 640x480, 720x400
SVGA: 800x600
XGA: 1024x768
WXGA: 1280x720, 1280x768
1360x768, 1366x768
Presets
Viewing adjustments Rotating screen On screen display Control features USB hub Multiple input Monitor connectors Signal cables Mounting features Security
Ship group
Standard presets: 20; user settings: 16
Tilt: 20° back, -5° forward; no lift; no swivel; detachable stand
None
On screen display with digital user controls (8 languages)
Direct access (control buttons on front) for automatic image setup and adjustment for brightness
None
None
VGA
15-pin D-shell,
Detachable, VGA
analog,
blue
15-pin D-shell at each end, analog, 1.8 meter Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount) Security keyhole for attachment of optional cable lock (Kensington lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
Features
• Widescreen 18.5-inch monitor
• High Defi nition (HD) ready; 1366x768 resolution
• Detachable stand tilts for comfortable viewing
• Supports VESA mount (100mm)
• 50% less mercury
• Kensington
®
lock slot ready for enhanced security
Lenovo D186 Wide Monitor
Accessories
Kensington MicroSaver® Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
See footnotes for important warranty information US model announced January 12, 2010
(D186) January 2010
© Lenovo
Lenovo® L2021 Wide
Personal Systems Reference (PSREF)
L2021 Wide Flat Panel Monitor Business black 4449-HB1
TFT-LCD, twisted nematic (TN), CCFL backlight
20.0" / 508mm (diagonal)
17.4" x 9.8" / 443mm x 249mm 1600x900 at 60Hz 16:9
0.277mm 92 dpi 250 nits or cd/m2 (typical) 1000:1 (typical) 5ms (typical) 72% Anti-refl ective, anti-glare 50 to 75 Hz 31 to 81 kHz 178° (+/- 89°) horizontal, 170° (+/- 85°) vertical 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt adjustable stand Sides:
0.48" (12.1mm)
;
top: 0.47" (11.9mm); bottom: 0.39" (10.1mm)
Dimensions (HxWxD)
Power supply
14.1" H x 18.7" W x 5.9" D;
357.5mm H x 475.9mm W x 151.2mm D 22 watts typical, 27 watts maximum, <1 watts standby/suspend, universal, integrated (no external brick-like power supply)
Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
9.24 lb; 4.2kg
3 years
(includes backlight) September 2010
VESA DDC2B/CI, VESA DPMS-compliant ENERGY STAR
®3
5.0 ISO 9241-307 MPR-2, FCC Class B EPEAT™ Gold rating, TCO (TCO Displays 5.0), WEEE, RoHS (EU Directive 2002/95/EC)
Preset resolutions
VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 WXGA: 1280x720, 1280x768, 1280x800, 1366x768 SXGA: 1280x1024
Presets / user settings
Viewing adjustments Rotating screen On screen display Control features USB hub Multiple input Monitor connectors
Signal cables
Mounting features Security
Ship group
WXGA+: 1440 x 900, 1600x900 Standard presets: 25; user settings: 20
Tilt: 20° back, -5° forward; detachable stand None On screen display with digital user controls (8 languages) Direct access (control buttons on front) for automatic image setup None Multiple input (two different PCs attach to two different connectors; one PC shows image; select via button) (1) VGA (2) (1) detachable, VGA
15-pin D-shell,
analog,
blue
Digital Visual Interface (DVI-D) for digital attach [white], HDCP-compliant
15-pin D-shell at each end, analog, 1.8 meter (2) detachable, DVI-D at each end (for digital connector), 1.8 meter Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (75mm mount) Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, analog signal cable, digital signal cable, 1.8m power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced September 21, 2010
Features
pose 20-inch wide fl at panel LCD monitor
• All-pur
• Vie
w images in a 16x9 wide aspect ratio
• High-bandwidth Digital Content Protection (HDCP)-compliant
• Tilt and cable management stand
• Compliance with ENERGY STAR 5.0
• 50% less mercury
• Microsoft
®
Windows® 7 certifi ed
Lenovo
L2021 Wide
Monitor
Lenovo
L2021 Wide
Monitor
rear view
with cable
management
Accessories
ThinkVision Soundbar 45K1263 Kensington
®
MicroSaver® Cable Lock 73P2582
Kensington Twin Head Cable Lock 45K1620
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(L2021) October 2010
© Lenovo
Lenovo® LS1922 Wide
Personal Systems Reference (PSREF)
Dimensions (HxWxD)
Power supply
Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
Preset resolutions
Presets / user settings
Viewing adjustments Rotating screen On screen display Control features Multiple input Monitor connectors Signal cables Mounting features Security
LS1922 Wide Flat Panel Monitor Business black 2580-AF1
TFT
-LCD, twisted nematic (TN), White LED backlight
18.5" (470mm) diagonal
16.1" x 9.1" / 409.8mm x 230.4mm
1366x768
16:9
• Widescreen 18.5-inch monitor
• Supports HD 1366x768 resolution
• Supports VESA mount (100mm)
• Mercury free panel and arsenic free glass
• Kensington
• Microsoft
®
lock slot ready for enhanced security
®
Windows® 7 certifi ed
Features
.300mm 85 dpi 250 nits or cd/m 1000:1 (typical)
2
(typical)
5ms (typical) 72% 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt adjustable stand Sides:
0.61" (15.6mm)
; top: 0.67" (17.1mm);
bottom: 1.19" (30.1mm)
14.54" H x 17.38" W x 8.25" D;
370.1mm H x 442.2mm W x 210.0mm D 18 watts typical, 24 watts maximum, <1 watts standby/suspend, universal, integrated (no external brick-like power supply)
6.55 lb; 2.97 kg 3 year (includes backlight) February 2012
VESA DDC2B/CI, VESA DPMS-compliant ENERGY STAR
®
5.1 ISO 9241-307 FCC Class B TCO (TCO Displays 5.2), WEEE, RoHS
VGA: 640x350, 640x480, 720x400 SVGA: 800x600 XGA: 1024x768 WXGA: 1280x720, 1280x768, 1360x768, 1366x768
Standard presets: 16 (VGA); user settings: 16
Lenovo LS1922 Wide Monitor
Tilt: 20° backward, -5° forward None On screen display with digital user controls (8 languages) Direct access (control buttons on front) for automatic image setup and adjustment for brightness None
15-pin D-shell,
VGA detachable, VGA
analog,
blue
15-pin D-shell at each end, analog, 1.8 meter Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount) Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Ship group
Monitor, attached stand, Setup poster with Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced February 28, 2012
Accessories
®
Kensington Kensington Twin Head Cable Lock 45K1620
MicroSaver® Cable Lock 73P2582
Lenovo Security Cable Lock 57Y4303 Lenovo Easy Reach Monitor Stand 55Y9258 ThinkCentre Extend Arm
57Y4352
See details at www.lenovo.com/support/monitoraccessories
4
See all monitors at www.lenovo.com/thinkvision
(LS1922) March 2012
© Lenovo
Lenovo® LS2221 Wide
Personal Systems Reference (PSREF)
Power supply
Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
Preset resolutions
Presets / user settings
Viewing adjustments Rotating screen On screen display Control features Multiple input Monitor connectors
Signal cables
Mounting features Security
Ship group
LS2221 Wide Flat Panel Monitor High gloss black 5453-LS1
TFT-LCD, twisted nematic (TN), White LED backlight
21.5" (546mm) diagonal
18.76" x 10.55" (476.6mm x 268.1mm)
1920x1080
16:9 .248mm 103 dpi 250 nits or cd/m
2
(typical)
• Widescreen 21.5-inch monitor
• Supports Full HD 1920x1080 resolution
• Ergonomic stand tilts
• Includes dual input connection for attachment to two
systems concurrently (analog and digital)
• Mercury free panel and arsenic free glass
• Microsoft® Windows® 7 certifi ed
Features
1000:1 (typical) 10000000:1 5ms (typical) 72% 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt adjustable stand Sides: 0.925" (23.5mm)
15.38" H x 20.67" W x 7.08" D;
390.7mm H x 525.0mm W x 179.8mm D 18 watts typical, 30 watts maximum, <1 watts standby/suspend, universal, integrated (no external brick-like power supply)
8.69 lb; 3.95 kg 3 year (includes backlight) August 2011
VESA DDC2B/CI, VESA DPMS-compliant ENERGY STAR ISO 9241-307
®
5.1
FCC Class B TCO (TCO Displays 5.2), WEEE, RoHS
VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1280x800, 1280x768, 1366x768 WXGA+: 1440x900, 1600x900 WSXGA+: 1680x1050 Full HD: 1920x1080 Standard presets: 32 (VGA), 32 (DVI); user settings: 20
Lenovo LS2221 Wide Monitor
Tilt: 20° backward, -5° forward None On screen display with digital user controls (8 languages) Direct access (buttons on front) for automatic image setup, dual input and NOVO vision Dual input (two different PCs attach to two different connectors; one PC shows image; select via button) (1) VGA (2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant (1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DVI-D at each end, digital, 1.8 meter Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount) Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced August 2, 2011
Accessories
Kensington® MicroSaver® Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Easy Reach Monitor Stand 55Y9258
ThinkCentre Extend Arm
57Y4352
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(LS2221) August 2011
© Lenovo
Lenovo® LS2421p Wide
Personal Systems Reference (PSREF)
Power supply
Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
Preset resolutions
Presets / user settings
Viewing adjustments Rotating screen On screen display Control features USB hub Multiple input Monitor connectors
Signal cables
Mounting features Security
Ship group
LS2421p Wide Flat Panel Monitor High gloss black 4015-LS1
TFT-LCD, twisted nematic (TN), White LED backlight
23.6" (598mm) diagonal
20.52" x 11.54" (521.3mm x 293.2mm)
1920x1080
16:9 .272mm 93 dpi 300 nits or cd/m
2
(typical)
• Widescreen 23.6-inch monitor
• Supports Full HD 1920x1080 resolution
• Ergonomic
• Includes dual input connection for attachment to two
stand tilts
systems concurrently (analog and digital)
• Mercury free panel and arsenic free glass
• Microsoft
®
Windows® 7 certifi ed
Features
1000:1 (typical) 10000000:1 5ms (typical) 72% 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt adjustable stand Sides: 0.968" (24.6mm)
13.78" H x 22.44" W x 7.47" D;
350.0mm H x 572.0mm W x 189.8mm D 30 watts typical, 35 watts maximum, <1 watts standby/suspend, universal, integrated (no external brick-like power supply)
9.79 lb; 4.44 kg 3 year (includes backlight) August 2011
VESA DDC2B/CI, VESA DPMS-compliant ENERGY STAR® 5.1 ISO 9241-307 FCC Class B TCO (TCO Displays 5.2), WEEE, RoHS
VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1280x800, 1280x768, 1366x768 WXGA+: 1440x900, 1600x900 WSXGA+: 1680x1050 Full HD: 1920x1080 Standard presets: 30 (VGA), 27 (HDMI);
Lenovo LS2421p Wide Monitor
user settings: 20 Tilt: 20° backward, -5° forward
None On screen display with digital user controls (8 languages) Direct access (buttons on front) for automatic image setup, dual input, brightness and NOVO vision USB 2.0 Hub (1 port into PC, 4 ports for accessories) Dual input (two different PCs attach to two different connectors; one PC shows image; select via button) (1) VGA (2) HDMI (1.3), digital, black, HDCP-compliant (1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, HDMI at each end, digital, 1.8 meter Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount) Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced August 2, 2011
Accessories
Kensington® MicroSaver® Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Easy Reach Monitor Stand 55Y9258
ThinkCentre Extend Arm 57Y4352
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(LS2421P) August 2011
© Lenovo
Lenovo® ThinkVision® LT1421 Wide Mobile Monitor
Personal Systems Reference (PSREF)
Power supply
Weight
Limited warranty
4
Available date
VESA-compliant
2
Power management Emission standards Environmental Preset resolutions
LT1421 Wide Mobile Monitor Raven black 1452-DS6 (with Protective Screen Cover)
TFT
-LCD, twisted nematic (TN), White LED backlight
14.0" (355.6mm) diagonal
12.2" x 6.9" (310.8mm x 175.3mm) 1366x768 16:9 .227mm 112 dpi 200 nits or cd/m 400:1 (typical)
2
(typical)
8ms (typical) 45% 90° (+/- 45°) horizontal, 50° (+/- 25°) vertical Tilt adjustable stand Sides: 0.476" (12.1mm)
8.58" H x 13.19" W x 0.37-0.85" D;
217.9mm H x 335mm W x 9.3-21.5mm D
4.2 watts typical, 5 watts maximum, <0.1 watts standby/suspend, universal, USB 2.0 cable (no external brick-like power supply)
monitor only: 1.91 lb; 0.87 kg; with Protective Screen Cover: 2.31 lb; 1.05 kg
3 year (includes backlight) September 2011
VESA DDC2B/CI, VESA DPMS-compliant ENERGY STAR
®3
5.1 FCC Class B WEEE, RoHS Display mode and resolution auto setup
Features
• Widescreen 14-inch mobile monitor designed for ThinkPad Light and Slim
•
• Super low power (<5 watts)
• Supports 1366x768 resolution
• Ergonomic stand tilts, provides a 12° - 40° backward tilt
adjustment for comfortable viewing
• Detachable USB cable for power and signal
• Microsoft
®
Windows® 7 certifi ed
ThinkVision LT1421 Wide Mobile Monitor
Protective Screen Cover
Polycarbonate Snap-On Cover protects the LCD Screen while not in use
Viewing adjustments Screen control Input Monitor connectors Signal cables Mounting features Security
Tilt: 12° - 40° backward Brightness (16 levels) USB input USB 2.0 detachable, USB Y-Type cable None
, 1.8 meter
Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Ship group
Monitor, attached tile stand that cannot be removed, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter USB Y-Type cable, Protective Screen Cover
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
ThinkVision LT1421 Wide Mobile Monitor
with ThinkPad Edge E420s
ThinkVision LT1421 with Protective Screen Cover
Accessories
Kensington
®
MicroSaver® Cable Lock 73P2582
Kensington Twin Head Cable Lock 45K1620
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
See footnotes for important warranty information US model announced August 16, 2011
(LT1421) November 2011
© Lenovo
Lenovo® ThinkVision® L1711p
Personal Systems Reference (PSREF)
Dimensions (HxWxD)
Power supply
L1711p Flat Panel Monitor Business black 5047-HB2
TFT-LCD, twisted nematic (TN), CCFL backlight
17.0" (432mm) diagonal
13.3" x 10.6" (337.9mm x 270.3mm) 1280x1024 at 60Hz 1280x1024 at 75Hz (165MHz max pixel rate) 5:4
0.264mm 96 dpi 250 nits or cd/m2 (typical) 1000:1 (typical) 5ms (typical) 72% Anti-refl ective, anti-glare 50 to 75Hz 30 to 83kHz 160° (+/- 80°) horizontal, 160° (+/- 80°) vertical Tilt height adjustable stand
Sides: 0.6" (15.3mm); top: 0.72" (18.4mm); bottom: 1.11" (28.1mm)
16-20.33" H x 14.6" W x 6.1" D;
405.7-515.7mm H x 370mm W x 155.2mm D 18 watts typical, 21 watts maximum, <1 watts standby/suspend, universal,
integrated (no external brick-like power supply) Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
9.3 lb; 4.21kg
3 year (includes backlight)
November 2009
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR
®
5.0 ISO 9241-307 MPR-2. MPR-3A, FCC Class B TCO (TCO Displays 5.0), WEEE, RoHS,
EPEAT™ Gold rating
Preset resolutions
VGA: 640x350, 640x480, 720x400 SVGA: 800x600 XGA: 1024x768
Presets / user settings
SXGA: 1280x1024 Standard presets: 17; user settings: 22
Viewing adjustments Rotating screen On screen display Control features Multiple input Monitor connectors
Signal cables
Mounting features Security
Ship group
Tilt: 20° back, -3° forward; lift: 4.3" (110mm); detachable stand None On screen display with digital user controls (8 languages) Direct access (buttons on front) for automatic image setup Dual input (two different PCs attach to two different connectors; one PC shows image; select via button) (1) VGA (2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant (1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DVI-D at each end, digital, 1.8 meter Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount) Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9215)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced October 20, 2009
Features
• Regular screen 17-inch monitor
• Supports SXGA 1280x1024 resolution
• Ergonomic stand tilts and provides a 4.3" (110mm)
range height adjustment for comfortable viewing
• Includes dual input connection for attachment to two systems concurrently (analog and digital)
• Reduces mercury content by 50% and arsenic free glass
• Up to 70% recycled packaging materials
• Privacy Filter Slot
• Microsoft® Windows® 7 certifi ed
ThinkVision L1711p Monitor
Accessories
ThinkVision Soundbar 45K1263 Kensington
®
MicroSaver® Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(L1711P) October 2009
© Lenovo
Lenovo® ThinkVision® L197 Wide
Personal Systems Reference (PSREF)
Flat Panel Monitors - US model
Rotating screen USB Hub
Optimum resolution Maximum resolution Vertical frequency Horizontal frequency Preset display modes
Presets / user settings Brightness Contrast ratio Pixel response time Color gamut
On screen display Control features Monitor connectors
Signal cables
Anti-refl ective Dimensions Weight Viewing adjustments Mounting features Security
VESA-compliant
2
Power management Ergonomics Pixel defect Emission standards Environmental Ship group
Power supply Limited warranty Available date
4
Features
L197 Wide Flat Panel Monitor Business black 4434-HE1
Tilt stand LCD Active Matrix TFT (Thin Film Transistor)
19.0" / 481mm (diagonal) 16:10 .285mm
16.1" x 10.0" (horizontal x vertical) 408mm x 255mm (horizontal x vertical) 176° vertical, 176° horizontal
• Widescreen 19-inch fl at panel monitor
• EPEAT™ Gold rating
• View images in a 16:10 wide aspect ratio
• Resolution of 1440x900 provides crisp screen images
• Slim 14.3mm (0.56") side bezel
• High-bandwidth Digital Content Protection (HDCP)-compliant
• Includes dual input connection for attachment to two
systems concurrently (analog and digital)
• Complements the ThinkCentre
• Microsoft
®
Windows® Vista™ Premium certifi ed
®
and ThinkPad® systems
160° vertical, 170° horizontal
Digital or analog (two separate connectors) Dual input (two different PCs attach to two different
connectors; one PC shows image; select via button) No pivot None
1440x900 at 60Hz 1440x900 at 75Hz (137MHz maximum pixel rate) 50 to 76Hz 30 to 81kHz VGA: 640x480 60, 66, 72, 75Hz
640x350 70Hz 720x400 70Hz
SVGA: 800x600 56, 60, 72, 75Hz
832x624 75Hz
1024x768 60, 70, 75Hz
XGA:
1152x864 75Hz
SXGA:
1280x1024 60, 70, 75Hz WXGA+: 1440x900 60, 75Hz Standard presets: 20; user settings: 20 250 nits or cd/m 1000:1 (typical) 5ms (typical)
2
(typical)

Lenovo ThinkVision L197 Wide

72%
On screen display with digital user controls (7 languages) Direct access (buttons on front) for automatic image setup Two connectors: (1) analog VGA
15-pin D-shell [blue], (2) Digital Visual Interface (DVI-D) for digital (not analog) attach [white], HDCP-compliant Two cables: (1)
detachable, VGA 15-pin D-shell at each end (for analog connector), 1.8 meter, matches color of monitor (2) detachable digital, DVI-D at each end (for digital connector), 1.8 meter, matches color of monitor Anti-refl ective, anti-glare
15.0"H x 17.3"W x 7.0"D / 381mm height x 440mm width x 179mm depth
9.15lb / 4.15kg Tilt: 30° back, 4° forward / no lift, no swivel, detachable stand Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount) Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
VESA DDC2B/CI, VESA DPMS-compliant ENERGY STAR ISO 13406 Part 2
®3
5.0
1
ISO 13406-2 Class II pixel defect standard MPR-2, MPR-3A, FCC Class B TCO 03, WEEE, RoHS (EU Directive 2002/95/EC), EPEAT™ Gold rating Monitor, attached stand, Setup Guide, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, analog signal cable, digital signal cable, 1.8m black power cord 90-264Vac (universal), integrated (no external brick-like power supply), 22 watts typical, <2 watts standby/suspend 3 year (includes backlight) April 2008
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced April 15, 2008
Accessories
Kensington
®
MicroSaver® Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(L197W) June 2011
© Lenovo
Lenovo® ThinkVision® L1900p
Personal Systems Reference (PSREF)
Dimensions (HxWxD)
Power supply
L1900p Flat Panel Monitor Business black 4431-HE1
TFT-LCD, twisted nematic (TN), CCFL backlight
19.0" (483mm) diagonal
14.8" x 11.85" (376mm x 301mm) 1280x1024 at 60Hz 1280x1024 at 75Hz (135MHz max pixel rate) 5:4 .294mm 86 dpi 250 nits or cd/m2 (typical) 800:1 (typical) 5ms (typical) 72% Anti-refl ective, anti-glare 56 to 76Hz 30 to 81kHz 160° (+/- 80°) horizontal, 160° (+/- 80°) vertical Tilt, swivel, pivot, and height adjustable stand
Sides: 0.6" (15.3mm); top: 0.66" (16.8mm); bottom: 1.05" (26.8mm)
14.9-19.2" H x 16.1" W x 7.4-9.5" D;
378.7-488.7mm H x 408mm W x 188-241.1mm D 17 watts typical, 24 watts maximum, <1 watts standby/suspend, universal,
integrated (no external brick-like power supply) Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Pixel defect Emission standards Environmental
Preset resolutions
12.5 lb; 5.7kg
3 year (includes backlight)
November 2008
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR
ISO 13406 Part 2
ISO 13406-2 Class II pixel defect standard
®3
5.0
1
MPR-2. MPR-3A, FCC Class B
TCO 03, WEEE, RoHS (EU Directive 2002/95/EC),
EPEAT™ Gold rating, GREENGUARD
®
certifi ed
VGA: 640x350, 640x480,
720x400
SVGA: 800x600
XGA: 1024x768
Presets / user settings
SXGA: 1280x1024
Standard presets: 21;
user settings: 17 Viewing adjustments
Rotating screen On screen display Control features Multiple input Monitor connectors
Signal cables
Mounting features Security
Ship group
Tilt: 30° back, 0° forward; lift: 4.3" (110mm); swivel: +/-45°; detachable stand
Screen pivots 90 degrees from landscape to portrait (requires image rotation support from graphics controller)
On screen display with digital user controls (8 languages)
Direct access (buttons on front) for automatic image setup
Multiple input (two different PCs attach to two different connectors; one PC shows image; select via button)
(1) VGA
(2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant
(1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DVI-D at each end, digital, 1.8 meter
Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount)
Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, cable cover, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide
and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced November 11, 2008
Features
• Regular screen 19-inch monitor
• Supports SXGA 1280x1024 resolution
• Ergonomic stand tilts, swivels, pivots and provides a 4.3"
(110mm) range height adjustment for comfortable viewing
• Detachable rear stand cable cover and clip to hide cables
• Microsoft
®
Windows® Vista® certifi ed
ThinkVision L1900p Monitor
with optional ThinkVision Soundbar
Accessories
ThinkVision Soundbar 45K1263 Kensington
®
MicroSaver® Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(L1900P) January 2009
© Lenovo
Lenovo® ThinkVision® L1951p Wide
Personal Systems Reference (PSREF)
Dimensions (HxWxD)
Power supply
L1951p Wide Flat Panel Monitor Business black 2448-HB6
TFT-LCD, twisted nematic (TN), CCFL backlight
19.0" (481mm) diagonal
16.07" x 10.05" (408.2mm x 255.2mm) 1440x900 at 60Hz 1440x900 at 75Hz (137MHz max pixel rate) 16:10 .285mm 89 dpi 250 nits or cd/m2 (typical) 1000:1 (typical) 5ms (typical) 72% Anti-refl ective, anti-glare 50 to 76Hz 30 to 81kHz 160° (+/- 80°) horizontal, 160° (+/- 80°) vertical Tilt and height adjustable stand
Sides: 0.61" (15.6mm); top: 0.67" (17.1mm); bottom: 1.2" (30.5mm)
14.56-17.71" H x 17.36" W x 6.11" D;
369.9-449.9mm H x 440.9mm W x 155.2mm D 19 watts typical, 23 watts maximum, <1 watts standby/suspend, universal,
integrated (no external brick-like power supply) Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
9.37 lb; 4.25kg
3 year (includes backlight)
October 2009
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR
®
5.0 ISO 9241-307 MPR-2. MPR-3A, FCC Class B TCO (TCO Displays 5.0), WEEE, RoHS,
EPEAT™ Gold rating
Preset resolutions
VGA: 640x350, 640x480, 720x400 SVGA: 800x600, 832x624 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA 1280x720, 1360x768
Presets / user settings
WXGA+ 1440x900 Standard presets: 27; user settings: 20
Viewing adjustments Rotating screen On screen display Control features Multiple input Monitor connectors
Signal cables
Mounting features Security
Ship group
Tilt: 20° back, -3° forward; lift: 3.1" (80mm); detachable stand None On screen display with digital user controls (8 languages) Direct access (buttons on front) for automatic image setup Dual input (two different PCs attach to two different connectors; one PC shows image; select via button) (1) VGA (2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant (1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DVI-D at each end, digital, 1.8 meter Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount) Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced October 20, 2009
Features
• Widescreen 19-inch monitor
• Supports WXGA+ 1440x900 resolution
• Ergonomic stand tilts and provides a 3.1" (80mm)
range height adjustment for comfortable viewing
• Includes dual input connection for attachment to two systems concurrently (analog and digital)
• Reduces mercury content by 50% and arsenic free glass
• Up to 70% recycled packaging materials
• Privacy Filter Slot
• Microsoft® Windows® 7 certifi ed
ThinkVision L1951p Wide Monitor
Accessories
ThinkVision Soundbar 45K1263 Kensington
®
MicroSaver® Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(L1951P) October 2009
© Lenovo
Lenovo® ThinkVision® LT1952p Wide
Personal Systems Reference (PSREF)
Dimensions (HxWxD)
Power supply
LT1952p Wide Flat Panel Monitor Business black 2448-MB6
TFT-LCD, twisted nematic (TN), White LED backlight 19" (482.6mm) diagonal
16.07" x 10.05" (408.2mm x 255.2mm)
1440x900
137MHz 16:10
0.2835mm
89.4 dpi 250 nits or cd/m2 (typical) 1000:1 (typical) 5ms (typical) 72% Anti-refl ective, anti-glare 170° horizontal, 160° vertical Tilt, swivel, and height adjustable stand
Sides: 0.61" (15.6mm); top: 0.67" (17.1mm); bottom: 1.2" (30.5mm)
15.66-19.99" H x 17.36" W x 6.74" D;
397.7-507.7mm H x 440.9mm W x 171.3mm D 13 watts typical, 17 watts maximum, <0.5 watts standby/suspend, universal,
integrated (no external brick-like power supply) Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
9.49 lb; 4.30kg
3 year (includes backlight)
September 2011
VESA DDC2B/CI
ENERGY STAR
®
5.1 ISO 9241-307 MPR-2, FCC Class B TCO Displays 5.2, TCO Certifi ed Edge 1.1, WEEE, RoHS, EPEAT™ Gold rating, ULE Gold
Preset resolutions
VGA: 640x350, 640x480, 720x400 SVGA: 800x600 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1280x768, 1366x768
Presets / user settings
WXGA+: 1440x900 Standard presets: 22; user settings: 22
Viewing adjustments Rotating screen On screen display Control features Multiple input Monitor connectors
Signal cables
Tilt: 20° back, -3° forward; lift: 4.3" (110mm); swivel: +/-180°; detachable stand None On screen display with digital user controls (8 languages) Direct access (buttons on front) for automatic image setup, input switch, and brightness Triple input (three different PCs attach to three different connectors; one PC shows image; select via button) (1) VGA (2) DisplayPort, digital, black, HDCP-compliant
15-pin D-shell,
analog,
blue
(3) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant (1) detachable, VGA
15-pin D-shell at each end, analog, 1.8 meter
(2) detachable, DVI-D at each end, digital, 1.8 meter
Mounting features Security
Ship group
Note: DisplayPort cable is not included; use optional DisplayPort to DisplayPort Monitor Cable (0A36537) Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount) Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter DVI-D cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced September 13, 2011
Features
• Widescreen 19-inch monitor
• Supports 1440x900 resolution
• Ergonomic stand tilts, swivel, and provides a 4.3" (110mm)
range height adjustment for comfortable viewing
• Cable Management for better user experience
• Mercury and arsenic free glass
• Recycled content in plastic material
• Privacy Filter Slot
• Microsoft
®
Windows® 7 certifi ed
ThinkVision LT1952p Wide Monitor
Accessories
DisplayPort to DisplayPort Monitor Cable 0A36537 ThinkVision Soundbar 45K1263 Kensington MicroSaver Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Security Cable Lock 57Y4303 ThinkCentre Extend Arm 57Y4352 Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(LT1952P) September 2011
© Lenovo
Lenovo® ThinkVision® L2250p Wide
Personal Systems Reference (PSREF)
Dimensions (HxWxD)
Power supply
L2250p Wide Flat Panel Monitor Business black 2572-HB6
TFT-LCD, twisted nematic (TN), CCFL backlight
22.0" (559mm) diagonal
18.7" x 11.7" (473.8mm x 296.1mm) 1680x1050 at 60Hz 1680x1050 at 75Hz (205MHz max pixel rate) 16:10 .282mm 90 dpi 250 nits or cd/m2 (typical) 1000:1 (typical) 5ms (typical) 72% Anti-refl ective, anti-glare 50 to 75Hz 30 to 83kHz 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt and height adjustable stand
Sides: 0.60" (15.3mm); top: 0.79" (20.0mm); bottom: 1.10" (28.0mm)
15.68-18.83" H x 19.92" W x 6.11" D;
398.3-478.3mm H x 506mm W x 155.2mm D 21 watts typical, 28 watts maximum, <1 watts standby/suspend, universal, integrated (no external brick-like power supply)
Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
11.49 lb; 5.21kg 3 year (includes backlight) October 2009
VESA DDC2B/CI, VESA DPMS-compliant ENERGY STAR
®
5.0 ISO 9241-307 MPR-2. MPR-3A, FCC Class B TCO (TCO Displays 5.0), WEEE, RoHS,
EPEAT™ Gold rating
Preset resolutions
VGA: 640x350, 640x480, 720x400 SVGA: 800x600 XGA: 1024x768,1152x864 SXGA: 1280x1024 WXGA+: 1440x900 UXGA: 1600x1000
Presets / user settings
Viewing adjustments Rotating screen On screen display Control features USB hub Camera Multiple input Monitor connectors
Signal cables
Mounting features Security
Ship group
WSXGA+: 1680x1050 Standard presets: 24; user settings: 20
Tilt: 20° back, -3° forward; lift: 3.1" (80mm); detachable stand None On screen display with digital user controls (8 languages) Direct access (buttons on front) for automatic image setup None None Dual input (two different PCs attach to two different connectors; one PC shows image; select via button) (1) VGA (2) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant (1) detachable, VGA (2) detachable, DVI-D at each end, digital,
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
1.8
meter Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount) Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter digital signal cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced October 20, 2009
Features
• Widescreen 22-inch monitor Supports WSXGA+ 1680x1050 resolution
•
• Ergonomic stand tilts and provides a 3.1" (80mm)
range height adjustment for comfortable viewing
• Includes dual input connection for attachment to two
systems concurrently (analog and digital)
• Reduces mercury content by 50% and arsenic free glass
• Up to 65% recycled packaging materials
• Privacy Filter Slot
• Microsoft® Windows® 7 certifi ed
ThinkVision L2250p Wide Monitor
Accessories
ThinkVision Soundbar 45K1263 Kensington MicroSaver
®
Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620
Lenovo Easy Reach Monitor Stand 55Y9258
See details at www
.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(L2250P) October 2009
© Lenovo
Lenovo® ThinkVision® LT2252p Wide
Personal Systems Reference (PSREF)
Dimensions (HxWxD)
Power supply
LT2252p Wide Flat Panel Monitor Business black 2572-MB6
TFT-LCD, twisted nematic (TN), White LED backlight 22" (559mm) diagonal
18.7" x 11.7" (473.8mm x 296.1mm)
1680x1050
205MHz 16:10
0.282mm 90 dpi 250 nits or cd/m2 (typical) 1000:1 (typical) 5ms (typical) 72% Anti-refl ective, anti-glare 170° horizontal, 160° vertical Tilt, swivel, pivot, and height adjustable stand
Sides: 0.60" (15.3mm); top: 0.79" (20.0mm); bottom: 1.10" (28.0mm)
14.46-18.79" H x 19.92" W x 9.50" D;
367.3-477.3mm H x 506mm W x 241.2mm D 20 watts typical, 26 watts maximum, <0.5 watts standby/suspend, universal,
integrated (no external brick-like power supply) Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
12.97lb; 5.89kg
3 year (includes backlight)
September 2011
VESA DDC2B/CI
ENERGY STAR
®3
5.1 ISO 9241-307 MPR-2, FCC Class B TCO Displays 5.2, TCO Certifi ed Edge 1.1, WEEE, RoHS, EPEAT™ Gold rating, ULE Gold
Preset resolutions
VGA: 640x350, 640x480, 720x400 SVGA: 800x600 XGA: 1024x768, 1152x864 SXGA: 1280x1024 WXGA: 1280x768, 1280x800, 1366x768 WXGA+: 1440x900 1600x900
Presets / user settings
WSXGA+: 1680x1050 Standard presets: VGA/DisplayPort: 26; DVI-D: 25; user settings: 25
Viewing adjustments Rotating screen On screen display Control features USB hub Camera Multiple input Monitor connectors
Signal cables
Tilt: 30° back, 0° forward; lift: 4.3" (110mm); swivel: +/-45°; detachable stand Screen pivots 90 degrees from landscape to portrait (requires image rotation support from graphics controller) On screen display with digital user controls (8 languages) Direct access (buttons on front) for automatic image setup, input switch, and brightness None None Triple input (three different PCs attach to three different connectors; one PC shows image; select via button) (1) VGA (2) DisplayPort, digital, black, HDCP-compliant
15-pin D-shell,
analog,
blue
(3) Digital Visual Interface (DVI-D) for digital attach [white], HDCP-compliant (1) detachable, VGA
15-pin D-shell at each end, analog, 1.8 meter
(2) detachable, DVI-D at each end, digital, 1.8 meter
Mounting features Security
Ship group
Note: DisplayPort cable is not included; use optional DisplayPort to DisplayPort Monitor Cable (0A36537) Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, cable cover, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter DVI-D cable,1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced September 13, 2011
Features
• Widescreen 22-inch monitor
• Supports 1680x1050 resolution
• Ergonomic stand tilts, swivels, pivots and provides a 4.3"
(110mm) range height adjustment for comfortable viewing
• Cable Management for better user experience
• Mercury and arsenic free glass
• Recycled content in plastic material
• Privacy Filter Slot
• Microsoft
®
Windows® 7 certifi ed
ThinkVision LT2252p Wide Monitor
®
(100mm mount)
Accessories
DisplayPort to DisplayPort Monitor Cable 0A36537 ThinkVision Soundbar 45K1263 Kensington
®
MicroSaver® Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Security Cable Lock 57Y4303 ThinkCentre Extend Arm 57Y4352 Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(LT2252P) September 2011
© Lenovo
Lenovo® ThinkVision® L2251x Wide
Personal Systems Reference (PSREF)
Dimensions (HxWxD)
Power supply
L2251x Wide Flat Panel Monitor Business black 2578-HB6 TFT-LCD, twisted nematic (TN), white LED backlight
22.0" (559mm) diagonal
18.7" x 11.7" / 473.8mm x 296.1mm 1680x1050 at 60Hz 1680x1050 at 75Hz (205MHz max pixel rate) 16:10 .282mm 90 dpi 250 nits or cd/m2 (typical) 1000:1 (typical) 5ms (typical) 68% Anti-refl ective, anti-glare 50 to 75Hz 30 to 83kHz 170° (+/- 85°) horizontal, 160° (+/- 80°) vertical Tilt, swivel, pivot, and height adjustable stand
Sides: 0.60" (15.3mm); top: 0.79" (20.0mm); bottom: 1.10" (28.0mm)
14.97-19.3" H x 19.92" W x 9.50" D;
380.3-490.3mm H x 506mm W x 241.2mm D 21 watts typical, 28 watts maximum, <1 watts standby/suspend, universal,
integrated (no external brick-like power supply) Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
12.39 lb; 5.63kg
3 year (includes backlight)
November 2009
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY STAR
®3
5.0 ISO 9241-307 MPR-2. MPR-3A, FCC Class B TCO (TCO Certifi ed Edge), WEEE, RoHS,
EPEAT™ Gold rating
Preset resolutions
VGA: 640x350, 640x480, 720x400 SVGA: 800x600 XGA: 1024x768,1152x864 SXGA: 1280x1024 WXGA+: 1440x900 UXGA: 1600x1000
Presets / user settings
Viewing adjustments Rotating screen On screen display Control features USB hub Camera Multiple input Monitor connectors
Signal cables
Mounting features Security
Ship group
WSXGA+: 1680x1050 Standard presets: 24; user settings: 20
Tilt: 30° back, 0° forward; lift: 4.3" (110mm); swivel: +/-45°; detachable stand Screen pivots 90 degrees from landscape to portrait (requires image rotation support from graphics controller) On screen display with digital user controls (8 languages) Direct access (buttons on front) for automatic image setup USB 2.0 Hub (1 port into PC, 3 ports for accessories) Integrated camera (0.3 megapixel) and microphone Dual input (two different PCs attach to two different connectors; one PC shows image; select via button) (1) VGA (2) DisplayPort, digital, black, HDCP-compliant (1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DisplayPort at each end, digital, 1.8 meter Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount) Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, cable cover, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter DisplayPort cable, 1.8 meter USB cable,
1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced October 20, 2009
Features
• Widescreen 22-inch monitor with white LED backlight
• Ergonomic stand tilts, swivels, pivots and provides a 4.3"
(110mm) range height adjustment for comfortable viewing
• Detachable rear stand cable cover and clip to hide cables
• Integrated camera (0.3 megapixel) and microphone
• Integrated ambient light sensor and a proximity sensor,
save more energy and make viewing more comfortable
• Low halogen, mercury free, and arsenic free glass, 92% recycled packaging materials
• Privacy Filter Slot
• Microsoft
®
Windows® 7 certifi ed
ThinkVision L2251x Wide Monitor
Accessories
ThinkVision Soundbar 45K1263 K
ensington® MicroSaver® Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(L2251X) May 2011
© Lenovo
Lenovo® ThinkVision® L2321x Wide
Personal Systems Reference (PSREF)
L2321x Wide Flat Panel Monitor Business black 4014-HB6
TFT-LCD, twisted nematic (TN), CCFL backlight
23.0" (584mm) diagonal
20.04" x 11.28" / 509.2mm x 286.4mm 1920x1080 Function as two monitors (need both VGA and DisplayPort connected), hardware based solution
provies 4 patterns of screen split (2:1, 1:1, 1:2, PIP) Aspect ratio Pixel pitch (mm) Dot/Pixel per Inch Brightness Contrast ratio Pixel response time Color gamut Anti-refl ective Vertical frequency Horizontal frequency Viewing angle at 10:1 CR Stand Bezel width
Dimensions (HxWxD)
Power supply
16:9
.265mm
96 dpi
250 nits or cd/m2 (typical)
1000:1 (typical)
5ms (typical)
72%
Anti-refl ective, anti-glare
50 to 75Hz
30 to 83kHz
170° (+/- 85°) horizontal, 160° (+/- 80°) vertical
Tilt, swivel, pivot, and height adjustable stand
Sides: 0.69" (17.6mm); top: 0.72" (18.2mm);
bottom: 0.79" (20.1mm)
14.72-19.05" H x 21.49" W x 9.49" D;
373.9-483.9mm H x 545.9mm W x 241.1mm D
24 watts typical, 28 watts maximum,
<1 watts standby/suspend, universal,
integrated (no external brick-like power supply) Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
14.75 lb; 6.69kg
3 year (includes backlight)
July 2010
VESA DDC2B/CI, VESA DPMS-compliant
ENERGY ST
AR
®3
5.0 ISO 9241-307 MPR-2, FCC Class B TCO (TCO Certifi ed Edge), WEEE, RoHS,
EPEAT™ Gold rating
Preset resolutions
NTSC, PAL, 640x350, 640x480, 800x600, 832x624, 960x1080, 1024x768, 1152x864, 1280x1024, 1280x1080, 1366x768 1440x900, 1680x1050, 1920x1080
Dual image resolution
(2:1): 1280x1080 + 640x1080 (1:2): 640x1080 + 1280x1080 (1:1): 960x1080 + 960x1080 (PIP): 640x480 in 1920x1080
Presets / user settings
Viewing adjustments Rotating screen
On screen display Control features
USB hub Multiple input Monitor connectors
Signal cables
Mounting features Security
Ship group
Presets: 26(VGA), 25(DisplayPort); user settings: 20 Tilt: 30° back, 0° forward; lift: 4.3" (110mm); swivel: +/-45°; detachable stand
Screen pivots 90 degrees from landscape to portrait (requires image rotation support from graphics controller, do not support image rotation under dual image modes) On screen display with digital user controls (8 languages) Direct access (buttons on front) for automatic image setup and image select (Dual image [2:1, 1:1, 1:2, PIP modes], Swap, Single VGA, and Single DisplayPort) USB 2.0 Hub (1 port into PC, 4 ports for accessories) Dual input (two different PCs attach to two different connectors; one PC shows image; select via button) (1) VGA (2) DisplayPort, digital, black, HDCP-compliant (1) detachable, VGA
15-pin D-shell,
15-pin D-shell at each end, analog, 1.8 meter
analog,
blue
(2) detachable, DisplayPort at each end, digital, 1.8 meter Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI® (100mm mount) Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, analog signal cable, DisplayPort cable, 1.8 meter USB cable, 1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced June 10, 2010
Features
• Widescreen 23-inch monitor
• 1080p full HD support, HDCP-compliant
• Function as two monitors, hardware based solution provies 4
patterns of screen split (2:1, 1:1, 1:2, PIP modes).
• Ergonomic stand tilts, swivels, pivots and provides a 4.3" (110mm) range height adjustment for comfortable viewing
• Compliance with ENERGY STAR 5.0
• Arsenic free glass
• Microsoft® Windows® 7 certifi ed
ThinkVision L2321x Wide Monitor
Accessories
ThinkVision Soundbar 45K1263 K
ensington® MicroSaver® Cable Lock 73P2582
Kensington Twin Head Cable Lock 45K1620
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(L2321X) June 2010
© Lenovo
Lenovo® ThinkVision® LT2452p Wide
Personal Systems Reference (PSREF)
Dimensions (HxWxD)
Power supply
LT2452p Wide Flat Panel Monitor Business black 4420-MB2
TFT-LCD, e-IPS, White LED backlight 24" (610mm) diagonal
20.4" x 12.8" (518.4mm x 324.0mm)
1920x1200
202.5MHz 16:10
0.270mm 94 dpi 300 nits or cd/m2 (typical) 1000:1 (typical) 7ms (GtG) 72% Anti-refl ective, anti-glare 178° horizontal, 178° vertical Tilt, swivel, pivot, and height adjustable stand
Sides: 0.78" (19.9mm); top: 0.78" (19.9mm); bottom: 1.12" (28.4mm)
15.54-19.87" H x 22" W x 10.13" D;
394.8-504.8mm H x 559.6mm W x 257.3mm D 30 watts typical (w/o USB hub), 40 watts maximum (w/o USB hub), <0.5 watts standby/suspend (w/o USB hub), universal, integrated (no external brick-like power supply)
Weight Limited warranty
4
Available date
VESA-compliant
2
Power management Ergonomics Emission standards Environmental
14.70 lb; 6.67kg 3 year (includes backlight) September 2011
VESA DDC2B/CI ENERGY STAR
®3
5.1 ISO 9241-307 MPR-2, FCC Class B TCO Displays 5.2, TCO Certifi ed Edge 1.1, WEEE, RoHS, EPEAT™ Gold rating, ULE Gold
Preset resolutions
VGA: 640x350, 640x480, 720x400 SVGA: 800x600 XGA: 1024x768,1152x864 SXGA: 1280x1024 WXGA: 1280x768, 1280x800, 1366x768 WXGA+: 1440x900 UXGA: 1600x1200 WSXGA+: 1680x1050 Full HD: 1920x1080
Presets / user settings
WUXGA: 1920x1200 Standard presets: 30; user settings: 20
Viewing adjustments Rotating screen On screen display Control features USB hub Multiple input Monitor connectors
Signal cables
Tilt: 30° back, 0° forward; lift: 4.3" (110mm); swivel: +/-45°; detachable stand Screen pivots 90 degrees from landscape to portrait (requires image rotation support from graphics controller) On screen display with digital user controls (8 languages) Direct access (buttons on front) for automatic image setup, input switch, and brightness USB 2.0 Hub (1 port into PC, 4 ports for accessories) Triple input (three different PCs attach to three different connectors; one PC shows image; select via button) (1) VGA (2) DisplayPort, digital, black, HDCP-compliant
15-pin D-shell,
analog,
blue
(3) Digital Visual Interface (DVI-D), digital, white, HDCP-compliant (1) detachable, VGA
15-pin D-shell at each end, analog, 1.8 meter
(2) detachable, DVI-D at each end, digital, 1.8 meter
Mounting features Security
Ship group
Note: DisplayPort cable is not included; use optional DisplayPort to DisplayPort Monitor Cable (0A36537) Wall or desk mounting using the Extend Arm or third-party accessories meeting the VESA FPMPMI Security keyhole for attachment of optional cable lock (Kensington® lock-compatible)
Monitor, attached stand, cable cover, Setup poster, Safety and Warranty Information, CD with multilingual User's Guide and monitor installation fi les, 1.8 meter analog signal cable, 1.8 meter DVI-D cable, 1.8 meter USB cable,
1.8 meter black power cord
Limited Warranty
➫ 3 year limited warranty ➫ International Warranty Service ➫ Rapid Replacement Service at 1-800-426-7378 ➫ Replacement normally arrives in two business days, excluding holidays ➫ Lenovo pays all shipping costs for valid warranty claims ➫ Service upgrade options:
• 3 year, on site exchange, Mon-Fri 9-5 with next day response
(ThinkPlus™ part number 41C9209)
• 3 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9212)
• 4 year, on site exchange, Mon-Fri 9-5 with next day response (41C9233)
• 4 year, on site exchange, 7 day x 24 hr with 4 hour response (41C9216)
4
5
6
7
• 4 year, mail exchange (51J0589)
• 5 year, mail exchange (51J0590)
➫ 24x78 day toll-free support for warranty issues during the warranty period
See footnotes for important warranty information US model announced September 13, 2011
Features
• Widescreen 24-inch monitor
• Supports 1920x1200 resolution
• High Defi nition (HD) ready; supports 1080p video
• Ergonomic stand tilts, swivels, pivots and provides a 4.3"
(110mm) range height adjustment for comfortable viewing
• Cable Management for better user experience
• Carrying handle
• Recycled content in plastic material
• Microsoft
®
Windows® 7 certifi ed
ThinkVision LT2452p Wide Monitor
®
(100mm mount)
Accessories
DisplayPort to DisplayPort Monitor Cable 0A36537 ThinkVision Soundbar 45K1263 Kensington MicroSaver Cable Lock 73P2582 Kensington Twin Head Cable Lock 45K1620 Lenovo Security Cable Lock 57Y4303 ThinkCentre Extend Arm 57Y4352 Lenovo Easy Reach Monitor Stand 55Y9258
See details at www.lenovo.com/support/monitoraccessories
See all monitors at www.lenovo.com/thinkvision
4
(LT2452P) September 2011
© Lenovo
Kensington® MicroSaver® Cable Lock from Lenovo
(73P2582)
Kensington Twin Head Cable Lock from Lenovo
(45K1620)
Lenovo Security Cable Lock
(57Y4303)
ThinkVision Soundbar
(45K1263)
Lenovo Easy Reach Monitor Stand
(55Y9258)
ThinkCentre Extend Arm
(57Y4352)
Lenovo USB-to-DVI Monitor Adapter
(45K5296)
Lenovo DisplayPort to VGA Monitor Cable
(57Y4393)
Lenovo DisplayPort to Single-link DVI-D Monitor Cable
(45J7915)
Lenovo Mini-DisplayPort to VGA Monitor Cable
(0A36536)
Lenovo DisplayPort to DisplayPort Monitor Cable
(0A36537)
Lenovo® Monitor Accessories
Personal Systems Reference (PSREF)
Monitor Accessories46 (all part numbers listed are US option P/N)
Lenovo USB-to-DVI Monitor Adapter ** 45K5296 ann 05/12/09 Lenovo DisplayPort to VGA Monitor Cable ** 57Y4393 ann 08/04/09 DisplayPort to Single-link DVI-D Cable ** 45J7915 ann 08/05/08 Lenovo Mini-DisplayPort to VGA Monitor Cable ** 0A36536 ann 05/17/11
**
Supports a maximum 1920 x 1200 monitor resolution. Lenovo DisplayPort to DisplayPort Monitor Cable*** 0A36537 ann 09/13/11 ***Hardware requirement: All Lenovo systems and monitors with DisplayPort 1.1a or 1.2 interface.
ThinkVision Soundbar 45K1263 ann 09/16/08 K
ensington® MicroSaver® Cable Lock 73P2582 ann 12/29/03 Kensington Twin Head Cable Lock 45K1620 ann 09/30/08
Lenovo Security Cable Lock 57Y4303 ann 08/24/10
Lenovo Easy Reach Monitor Stand 55Y9258 ann 09/22/09 ThinkCentre Extend Arm 57Y4352 ann 07/06/10
46
Compatible on selected Lenovo and ThinkVision monitors.
Compatibility matrix
USB-to-DVI
Adapter
(45K5296)
DisplayPort
to VGA
Cable
(57Y4393)
DisplayPort
to DVI-D
Cable
(45J7915)
Mini-Display-
Port to VGA
Monitor Cable
(0A36536)
DisplayPort to
DisplayPort
Monitor Cable
(0A36537)
ThinkVision
Soundbar
(45K1263)
MicroSaver
Cable
Lock
(73P2582)
Twin Head
Cable
Lock
(45K1620)
Security
Cable
Lock
(57Y4303)
Easy Reach
Monitor
Stand
(55Y9258)
LT1421 73P2582 45K1620 57Y4303 L1711p 45K5296 57Y4393 45J7915 0A36536 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352 D186 L197
45K5296 57Y4393 45J7915 0A36536 73P2582 45K1620 57Y4303 55Y9258 57Y4352
57Y4393 0A36536 73P2582 45K1620 57Y4303 55Y9258 57Y4352
L1900p 45K5296 57Y4393 45J7915 0A36536 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352 L1951p 45K5296 57Y4393 45J7915 0A36536 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352 LT1952p 45K5296 57Y4393 45J7915 0A36536 0A36537 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352 L2021
45K5296 57Y4393 45J7915 0A36536 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352 LS2221 0A36536 73P2582 45K1620 57Y4303 55Y9258 57Y4352 L2250p
L2251p 45K5296 57Y4393 0A36536 0A36537 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352
✂
45K5296 57Y4393 45J7915 0A36536 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352
LT2252p 45K5296 57Y4393 45J7915 0A36536 0A36537 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352 L2251x 45K5296 57Y4393 0A36536 0A36537 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352 L2321x 45K5296 57Y4393 0A36536 0A36537 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352 LS2421p 0A36536 0A36537 73P2582 45K1620 57Y4303 55Y9258 57Y4352
L2440p 45K5296 57Y4393 45J7915 0A36536 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352
✂
L
T2452p 45K5296 57Y4393 45J7915 0A36536 0A36537 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352
LS1922 57Y4393 0A36536 73P2582 45K1620 57Y4303 55Y9258 57Y4352
L2461x 57Y4393 0A36536 73P2582 45K1620 57Y4303 55Y9258 57Y4352
✂
L151 45K5296 57Y4393 73P2582 45K1620 55Y9258
✂
L151p 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
L171 45K5296 57Y4393 73P2582 45K1620 55Y9258
✂
L171p 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
L172 45K5296 57Y4393 73P2582 45K1620 55Y9258
✂
L174 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
L1700p 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
D185 45K5296 57Y4393 45J7915 45K1263 73P2582 45K1620 55Y9258
✂
L190x 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
L191 45K5296 57Y4393 73P2582 45K1620 55Y9258
✂
L192p 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
L193p 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
L194 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
L1940p 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
L200p 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
L201p 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
L2060 45K5296 57Y4393 45J7915 73P2582 45K1620 57Y4303 55Y9258 57Y4352
✂
L215 45K5296 57Y4393 45J7915 45K1263 73P2582 45K1620 55Y9258
✂
L215p 45K5296 57Y4393 45K1263 73P2582 45K1620 55Y9258
✂
L220x 45K5296 57Y4393 73P2582 45K1620 55Y9258
✂
L2230x 45K5296 57Y4393 45K1263 73P2582 45K1620 57Y4303 55Y9258 57Y4352
✂
L2240p 45K5296 57Y4393 45J7915 73P2582 45K1620 55Y9258
✂
L2440x 45K5296 57Y4393 45J7915 45K1263 73P2582 45K1620 55Y9258
✂
✂
Monitors
withdrawn from marketing.
Extend
Arm
(57Y4352)
More information at www.lenovo.com/support/monitoraccessories
Other accessories at www.lenovo.com/accessories
Accessories Guide pdf at
www.lenovo.com/accessoriesguide
© Lenovo
(O-M) March 2012
Availability: All offers subject to avail-
ability. Lenovo reserves the right to alter product offerings and specifi cations at any time, without notice. Lenovo is not responsible for photographic or typo­graphic errors.
Warranty: For a copy of applicable
product warranties, write to: Warranty In­formation, P.O. Box 12195, RTP, NC, 27709, Attn: Dept ZPYA/B676. Lenovo makes no representation or warranty regarding third party products or services.
1
ISO-compliant: Compliance with ISO
9241 Part 3, ISO Part 7, ISO Part 8, and/or ISO 13406 Part 2 is dependent on a complete ISO-capable platform of a system unit, monitor, video subsystem, operating system and fonts.
2
VESA: Requires attachment to suitably
confi gured system with similarly enabled operating system.
3
ENERGY STAR: As an ENERGY STAR
partner, Lenovo has determined that this product meets the ENERGY STAR 4.0 or
4.1 guidelines for energy effi ciency. Re­quires attachment to suitably confi gured system.
4
Limited warranty: Support unrelated to
a warranty issue may be subject to ad­ditional charges.
5
International Warranty Service is avail-
able in any country in which this product is sold and serviced. Service delivery methods and parts availability vary by country, may be different from that in the country of purchase, and are subject to change without notice. Fees and restric­tions may apply in some countries.
6
Lenovo pays all shipping costs for
warranty repairs during limited warranty period.
7
ThinkPlus and Lenovo Care Ser­vices: These services are available for
machines normally used for business, professional, or trade purposes, rather than personal, family, or household pur­poses. Not all machine types and models are covered. Service period begins with the equipment date of purchase. Service must be purchased during the original limited product warranty period. Service levels are response time objectives and are not guarantees. If the machine problem turns out to be a Customer Replaceable Unit (CRU), a part will be express shipped to you for quick re­placement. Onsite 24x7x2-hour service is not available in all locations. P&L means parts and labor. P/U means pick-up. See terms and conditions for complete details and restrictions.
8
Telephone support may be subject
to additional charges, even during the limited warranty period. In the United States call 1-800-426-7378. Response times may vary. May exclude some holidays. If a machine is listed as having “On-site service for select repairs”, this means that onsite service is available only for the replacement of select parts. For all other warranty repairs, Lenovo will provide the customer a replacement part for customer installation. The parts for which onsite service is available varies by machine, but may include the processor, power supply, heat sink, system board, or base cover. For machines with EasyServ or Courier service, Lenovo will attempt to diagnose and resolve the problem remotely before sending a courier.
10
TAA: Monitor is compliant with the U.S. Federal Government's country-of-origin requirements prescribed in 48 C.F.R. Subpart 25.4; Trade Act Agreement (TAA) model.
11
Post-warranty annual maintenance
agreement: Service begins at the end of the base warranty or the end of any other applied warranty and maintenance option, whichever occurs last. Service delivery is not available the same day the maintenance agreement is purchased. Maintenance agreements must be purchased and the registration success­fully completed prior to the service being available.
12
Halogen: Less than 900 Parts Per Million.
Low halogen is defi ned in accordance with IPC-401B and draft IPC-J-STD 709 Class 1 requirements.
Trademarks: Lenovo, the Lenovo logo, New World. New Thinking., Access Con­nections, Rescue and Recovery, Think­Centre, ThinkPad, ThinkStation, ThinkVan­tage, and ThinkVision are trademarks of Lenovo. Microsoft, Windows, and Vista are registered trademarks of Microsoft Corpo­ration. Other company, product, or service names may be trademarks or service marks of others.
This publication was developed for prod-
ucts and services offered in the United States. Lenovo may not offer the prod­ucts, services or features discussed in this document in other countries. Lenovo may withdraw an offering at any time. Information is subject to change without notice. Consult your local representative for information on offerings available in your area.
Lenovo reserves the right to alter speci-
fi cations and other product information at any time without prior notice. Lenovo is not responsible for photographic or typographical errors. LENOVO PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANT­ABILITY OR FITNESS FOR A PARTICU­LAR PURPOSE. Some jurisdictions do not allow disclaimer of express or implied warranties in certain transactions; there­fore this disclaimer may not apply to you. This publication was developed in the US.
Visit www.lenovo.com/safecomputing
periodically for the latest information on safe and effective computing.
Visit www.lenovo.com/psref
for the latest version of Personal Systems Reference.
© Lenovo, 2012.
All rights reserved.
Lenovo 1009 Think Place Morrisville, NC 27560 U.S. A .
March 2012 mbook.pdf
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
