Lenovo A7-10F User Manual [es]
Lenovo TAB 2 A7-10F
Safety, Warranty & Quick Start
Guide V1.0
English/Français/Español
English
Read this guide carefully before using your Lenovo TAB 2 A7-10F.
Electronic emission notices
Learn more
Getting support
Legal notices
European Union conformity
Radio and Telecommunications Terminal Equipment
Directive
This product is in complia nce with the essential
requirements and other relevant provisions of the Radio
and Telecommunications Terminal Equipment Directive,
1999/5/EC.
To learn more information abou t your Lenovo TAB 2
A7-10 F functi ons, refer to the “User Guide” from the
Browser favorites in your Lenovo TAB 2 A7-10F.
To obtain the “Regulatory Notic es”, go to
http://support.lenovo.com/.
For support on network service and billing, contact your
wireless network operator. For instructions on how to
use your Lenovo TAB 2 A7-10F, go to
http://support.lenovo.com/.
Lenovo and the Lenovo logo are trademarks of Lenovo in
the United States, other countries, or both.
Other company, product, or ser vice names may be
trademarks or service marks of others.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
LIMITED A ND RESTRICTED RIGHTS NOTICE: If data or
software is delivered pursuant a General Serv ices
Administration “GSA” contract, use, reproduction, or
disclosure is subject to restrictions set for th in Contract
No. GS-35F- 05925.
Technical specifications
Lenovo TAB 2 A7-10F
Model & version
System
①
Dimensions &
Weight
CPU
Camera
Battery
Display
Wireless
communication
① Depending on the measuring method, the dimensions and weight might
vary slightly.
Model: Lenovo TAB 2 A7-10F Version: WLAN
Android
Depth: 9.3 mm (0.36 inch) Width: 105 mm (4.13 inches)
Height: 189 mm (7.44 inches) Weight: 280 g
MT8127
0.3M (front)
3450 mAh
Size: 7 inches
Resolution: 1024 × 600
Bluetooth 4.0 WLAN 802.11 b/g/n GPS
First glance
Earphone jack Speaker
1
Front camera
4
Volume key
7
Micro USB
2
MicroSD card slot
5
8
On/Off button
3
6
Microphone
Preparing your Lenovo TAB 2 A7-10F
Install the MicroSD card as shown.
Step 1. Open the card-slot door.
Step 2. Insert the cards into the respective
slots, push the cards until they are
engaged in place.
Step 3. Close the card-slot door.
Starting to use your Lenovo TAB 2 A7-10F
Before using your Lenovo TAB 2 A7-10F, you might need to charge the battery.
Charge the battery as shown.
Connect your
USB power adapter.
Turning on/off
Taking screenshots
Press and hold the On/Off button and the volume down button at the same time.
Lenovo TAB 2 A7-10F
Low battery
to a power outlet using the included cable and
Fully charged
Press and hold the On/Off button until the
Turn on:
Lenovo logo appears.
: Press and hold the On/Off button for a few
Tur n off
seconds, tap Power
off and the n tap OK.
Charging
Read before using your tablet
The following sections provide critical safety and regulatory info rmation for Lenovo
tablets and instructions on how to access electronic versions of the publications
developed for your tablet.
Read first-Regulatory information
Device models equipped with wireless communications comply with the radio frequency
and safety standards of any country or region in which it has been approved for wireless
use. In addition, if your product contains a telecom modem, it complies with the
requirements for connection to the telephone network in your country.
Be sure to read the Regulatory Notice
devices contained in your device. To obtain a PDF version of the Regulatory Notice
to the “Downloading publications
Downloading publications
Electronic versions of your publications are available from the
http://support.lenovo.com. To download the publications for your device, go to:
http://support.lenovo.com and follow the instructions on the screen.
Accessing your User Guide
Your User Guide
Guide, go to
http://support.lenovo.com and follow the instructions on the screen.
contains detailed information about your device. To access your User
Service and Support information
The following information describes the technical support that is available for your
product, during the warranty period or throughout the life of your product. Refer to the
Lenovo Limited Warranty for a full explanatio n of Lenovo wa rrant y terms. Se e “Lenovo
Limited Warrant y notice” later in this document for deta ils on acc essing the full
warranty.
Online technical support
Online technical support is available during the lifetime of a product at
http://www.lenovo.com/support.
Telephone technical support
You can get help and information from the Customer Support Center by telephone.
Before contacting a Lenovo technical support representative, please have the following
information available: model and serial number, the exact wording of any error
message, and a description of the problem.
Your technical support representative might want to walk you through the problem
while you are at your device during the call.
for your country or region before using the wireless
” section below.
, refer
Worldwide Lenovo Support telephone list
Important: Telephone numbers are subje ct to change without notice. T he most
up-to-date telephone list for the Customer Support Center is always available at
http://www.lenovo.com/support/phone.
If the telephone nu mber for your country or region is not listed, contact your Lenovo
resell er or Lenovo marketi ng representati ve.
Important safety and handling information
Plastic bag notice
DANGER:
Plastic b ags can be dangerous. Keep p lastic bags away from babies a nd children to
avoid danger of suf focation.
Built-in rechargeable battery notice
DANGER:
Do not atte mpt to replace the inte rnal rechargeable lithium ion battery. Contact Lenovo
Support for factory replacement.
Polyvinyl Chloride (PVC) cable and cord notice
WARNING: Handling the c ord on this product or cords as sociated with accessor ies
sold with this product will expose you to lead, a chemical known to the State of
California to cause cancer, and birth d efects or other reproducti ve harm. Wash hands
after handling.
Prevent hearing damage
Your device has a headphone connector. Always use the headphone connector for
headphones (also called a headset) or earphones.
CAUTION:
Excessive sound pressure from earphones and headphones can cause hearing loss.
Adjustment of the equalizer to maximum increases the earphone and headphone
output vo ltage and the soun d pressure level. Therefore, to protect your hearing, adjust
the equalizer to an appropriate level.
Excessive use of headphones or earphones for a long period of time at high volume
can be dangerous if the output of the headphone or earphone connectors do not
comply with specifications of EN 50332-2.
The headphone output connector of your device complies with EN 50332-2 Sub
clause 7. This specification limits the device's maximum wide band true RMS output
voltage to 150 mV. To help protect against hearing loss, en sure that the headphones or
earphones you use also comply with EN 50332-2 (Clause 7 limits) for a wide band
characteristic voltage of 75 mV. Using headphones that do not comply with EN
50332-2 can be dangerous due to excessive sound pressure levels.
If your dev ice came with headphones or earphones in the package, as a set, the
combination of the headphones or earphones and the device already complies with
the specifications of EN 50332-1. If different headphones or earphones are used,
ensure that they comply with EN 50332-1 (Clause 6.5 Limitation Values). Using
headph ones that do not comply with EN 50332-1 can be dang erous du e to excessive
sound pressure levels.
Sound pressure warning statement
For the dev ice that is tested in ac cordan ce with EN 60950-1:
2006+A11:2009:+A1:2010+A12:2011, it is mandatory to perform audio tests for
EN50332.
This dev ice has been tested to comply w ith the Sound Pressure Level requirement laid
down in the a pplicable EN 50332-1 and/or EN 50332-2 standards. Pe rmane nt hearing
loss may occur if earphones or headphones are used at high volume for prolonged
periods of time.
Warning statement:
To prevent possible hearing da mage, do not listen at high volume levels fo r a long
period of time.
Warranty information
Lenovo Limited Warranty notice
This product is covered by the te rms of the Lenovo Limited Warranty, version
L505-0010-02 08/2011. Read the Len ovo Limited Warranty (LLW) at
http://www.lenovo.com/warranty/llw_ 02. You can view the LLW in a numbe r of
langua ges from this Web site. If you cann ot view the L LW from the Web site, contact
your local Lenovo of fice or reseller to obtain a pr inted ver sion of the LLW.
Lenovo TAB 2 A7-10F
Model & Ver sion
Model
Lenovo TAB 2 A7-10F
Version
WLAN
Warrant y perio d and typ e of Warranty service
Country or Region Purchase Warranty Period
France, Germany, Italy, Austria,
United Kingdom, Israel, Australia, New
Zealand
Serbia, Costa Rica, Venezuela, Peru,
Uruguay, Ecuador, Colombia, Chile, Argentina,
Indonesia, Vietnam, India, Malaysia, Thailand,
Philippines, Singapore, Hong Kong
Russia, Ukraine, Egypt, Lebanon, Morocco,
South Africa, Tunisia, Mauritius, Mozambique,
Saudi Arabia, United Arab Emirates, Jordan,
Kenya, Nigeria, Uganda, Ghana, Oman,
Tanzania, Namibia
Poland, Hungary, Romania, Bulgaria, Greece,
Croatia, Slovenia, Slovakia, Cyprus, United
States of America, Canada, Mexico, Japan
Panama
Taiwan, South Korea
Brazil
Spain, Switzerland, Portugal, Netherlands,
Belgium, Sweden, Denmark, Norway, Finland,
Estonia, Latvia, Lithuania, Iceland
Czech Republic
Turkey
* Excludes some components. 90-day limited warranty for power adapters, keyboards,
plastics and hinges.
parts and labor-1 year
Battery pack -1 year
parts and labor-1 year
Battery pack -1 year
parts and labor-1 year
Battery pack -1 year
parts and labor-1 year
Battery pack -1 year
parts and labor-1 year
Battery pack -1 year
parts and labor-1 year
Battery pack -1 year
parts and labor-1 year
Battery pack -1 year
parts and labor-2 year
Battery pack -1 year
parts and labor-2 year
Batter y pack -1 year
parts and labor-2 year
Batter y pack -1 year
Type of Warranty
Service
1, 3
1, 4
4
1, 5
2, 4
3, 4
2, 5
1, 3
1, 5
3, 4
Types of Warranty Ser vice
1. Customer Replaceable Unit (“CRU”) Service
2. On-site Se rvic e
3. Courier or Depot Service
4. Customer Carry-In Service
5. Mail-in Service
6. Custome r Two-Way Mail-in Service
7. Product Exchange Service
For a full ex planation of the types of warranty servi ce, refer to the full war ranty. See
“Lenovo Limited Warranty n otice
” for details on accessing the full warranty.
Environmental, recycling, and disposal information
General recycling statement
Lenovo encourages owners of information technology (IT) equipment to responsibly
recycle their equipment when it is no longer n eeded. Lenovo offers a variety of
programs and ser vices to assist e quipment owners in recycling their IT products. For
information on recycling Lenovo products, go to: http://www.lenovo.com/recycling.
Important WEEE information
Electr ical and elec tronic equipm ent marked with t he symbol of a cros sed-out
wheel ed bin may not be dis posed as unsor ted municipa l waste. Waste of
electr ical and elec tronic equipm ent (WEEE) sh all be treated se parately using
the collection framework available to customers for the return, recycling, and
treatme nt of WEEE.
Country-specific information is available at：
http://ww w.lenovo.c om/recycling.
Recycling information for Japan
Recycling and disposal information for Japan is available at:
http://ww w.lenovo.c om/recycling/japan.
Additional recycling statements
Additional information about recycling device components and batteries is in your
. See “Accessing your User Guide” for details.
User Guide
Battery recycling marks
The battery recycling informati on of Taiwan
Battery recycling information for the United States and Canada
Battery recycling information for the European Union
Energy efficiency mark
Restriction of Hazardous Substances Directive (RoHS)
Tur kis h
The Lenovo product meets the requirements of the Republic of Turkey Dire ctive on the
Restriction of the Use of Cer tain Ha zardous Substances in Electrical and Electronic
Equipment (EEE).
Ukraine
India
RoHS compliant as per E-Waste (M anagement & Handling) Rules, 2011.
European Union
Lenovo products so ld in the European Union, on or after 3 January 2013 meet the
requirements of Directive 2011/65/EU on the restriction of the use of cer tain ha zardous
substances in electrical and electronic equipment (“RoHS recast” or “RoHS 2”).
For more information about Lenovo progress on RoHS, go to:
http://www.lenovo.com/social_responsibility/us/en/RoHS_Communication.pdf
Notice for users in Mexico
La operación de este equipo está sujeta a las siguientes dos condiciones:
(1) es posible que este equipo o dispositivo no cause inter ferencia perjudicial y
(2) este equipo o dispositivo debe aceptar cualquier inter ferencia, incluyendo la
que pueda causar su operación no deseada.
EurAsia compliance mark
Français
Lisez at tentivement ce guide avant d'utiliser votre Lenovo TAB 2 A7-10F.
Bruits radioélectriques
En savoir plus
Assistance
Mentions légales
Conformité aux directives de l’Union européenne
Directive R&TTE (Équipements radi o et équip ements
terminaux de télécommuni-cation)
Ce produit est conforme aux exigences essentielles
ainsi qu’aux autres dispositions applicables de la
Directive sur les équipe ments radio et équipements
terminaux de télécommunication, 1999/5/CE.
Pour en savoir plus sur les fonctions de votre Lenovo
TAB 2 A7-10F, consultez le «User Guide» dans les
favoris du navigateur de votre Lenovo TAB 2 A7-10F.
Pour lire le docume nt «Regulatory Notice», visitez
http://support.lenovo.com/.
Pour des informations sur les services réseau et la
facturation, contactez votre opérateur de réseau sans fil.
Pour des instructions sur l’utilisati on de votre Le novo
TAB 2 A7-10F, visitez le site http://support.lenovo.com/.
Lenovo et le logo Lenovo sont des marques de Lenovo
en France et/ou dans d’autres pays.
Les autres noms de société, de produit ou de service
sont des m arques ou des marques de se rvice d’autres
sociétés.
Fabriqué sous licence Dolby Laboratories. Dolby et le
symbole double-D sont des marques commerciales de
Dolby Laboratories.
REMARQUE SUR LES DR OITS LIMITÉS ET
RESTREINTS: si les données ou les logiciels sont
fournis conformément à un contrat «G eneral Services
Administration» («GSA»), l’utilisation, la reproduction et
la divulgation sont soumises aux restrictions stipulées
dans le contrat nºGS -35F-05925.
Loading...
