Lenovo 8159, 9211, 8116, 8156, 8215 User Manual

User Guid e
Ty pe s 8099, 8116, 8155, 8156
Ty pe s 8157, 8158, 8159, 8160
Ty pe s 8215, 9210, 9211

User Guid e
Ty pe s 8099, 8116, 8155, 8156
Ty pe s 8157, 8158, 8159, 8160
Ty pe s 8215, 9210, 9211

Note

Before using this information and the product it supports, be sure to read the “Important safety information” on page v and
Appendix D, “Notices,” on page 45.

Third Edition (October 2005)

© Copyright Lenovo 2005.
Portions © Copyright International Business Machines Corporation 2005.
All rights reserved.

U.S. GOVERNMENT USERS – RESTRICTED RIGHTS: Our products and/or services are provided with
RESTRICTED RIGHTS. Use, duplication or disclosure by the Government is subject to the GSA ADP Schedule
contract with Lenovo Group Limited, if any, or the standard terms of this commercial license, or if the agency is
unable to accept this Program under these terms, then we provide this Program under the provisions set forth in
Commercial Computer Software–Restricted Rights at FAR 52.227-19, when applicable, or under Rights in
Data-General, FAR 52.227.14 (Alternate III).

Contents

Important safety information . . . . . .v

Conditions that require immediate action . . . . .v

General safety guidelines . . . . . . . . . .vi

Service . . . . . . . . . . . . . . .vi

Power cords and power adapters . . . . . . vii

Extension cords and related devices . . . . . vii

Plugs and outlets . . . . . . . . . . . viii

Batteries . . . . . . . . . . . . . . viii

Heat and product ventilation . . . . . . .ix

CD and DVD drive safety . . . . . . . . .ix

Additional safety information . . . . . . . . .x

Lithium battery notice . . . . . . . . . . .x

Modem safety information . . . . . . . . .xi

Laser compliance statement . . . . . . . . .xi

Power supply statement . . . . . . . . . . xii

Overview . . . . . . . . . . . . . xiii

Information resources . . . . . . . . . . . xiii

Chapter 1. Installing options . . . . . .1

Features . . . . . . . . . . . . . . . .1

Available options . . . . . . . . . . . . .4

Specifications . . . . . . . . . . . . . .5

Supported operating positions . . . . . . . .6

Tools required . . . . . . . . . . . . . .6

Handling static-sensitive devices . . . . . . . .6

Installing external options . . . . . . . . . .7

Locating controls and connectors on the front of

your computer . . . . . . . . . . . . .7

Locating connectors on the rear of your computer 8

Obtaining device drivers . . . . . . . . .9

Opening the cover . . . . . . . . . . . .10

Locating components . . . . . . . . . . .11

Accessing system board components and drives . .12

Identifying parts on the system board . . . . .13

Installing memory . . . . . . . . . . . .14

Installing PCI adapters . . . . . . . . . .15

Installing internal drives . . . . . . . . . .16

Drive specifications . . . . . . . . . . .17

Installing a drive in bay 2 . . . . . . . .18

Installing a diskette drive in bay 3 . . . . . .19

Connecting drives . . . . . . . . . . . .21

Connecting an optical drive or a parallel ATA

hard disk drive . . . . . . . . . . . .21

Connecting an additional serial ATA hard disk

drive . . . . . . . . . . . . . . .22

Security features . . . . . . . . . . . . .22

Integrated cable lock . . . . . . . . . .23

Password protection . . . . . . . . . .23

Changing the battery . . . . . . . . . . .23

Erasing a lost or forgotten password (clearing

CMOS) . . . . . . . . . . . . . . . .24

Closing the cover and connecting the cables . . .25

Chapter 2. Using the Setup Utility . . .27

Starting the Setup Utility program . . . . . . .27

Viewing and changing settings . . . . . . . .27

Using passwords . . . . . . . . . . . .27

Password considerations . . . . . . . . .28

User Password . . . . . . . . . . . .28

Administrator Password . . . . . . . . .28

IDE Drive User Password . . . . . . . .28

IDE Drive Master Password . . . . . . . .29

Setting, changing, and deleting a password . . .29
Resetting the hard disk drive and power-on

password . . . . . . . . . . . . . .29

Using Security Profile by Device . . . . . . .30

Selecting a startup device . . . . . . . . . .30

Selecting a temporary startup device . . . . .30

Changing the startup device sequence . . . .30

Advanced settings . . . . . . . . . . . .31

Exiting from the Setup Utility program . . . . .31

Appendix A. Updating system

programs . . . . . . . . . . . . .33

System program . . . . . . . . . . . . .33

Updating (flashing) BIOS from a diskette or

CD-ROM . . . . . . . . . . . . . . .33

Updating (flashing) BIOS from your operating

system . . . . . . . . . . . . . . . .34

Recovering from a POST/BIOS update failure . . .34

Appendix B. Cleaning the mouse . . .35

Cleaning an optical mouse . . . . . . . . .35

Cleaning a mouse with a ball . . . . . . . .35

Appendix C. Manual modem

commands . . . . . . . . . . . . .37

Basic AT commands . . . . . . . . . . .37

Extended AT commands . . . . . . . . . .39

MNP/V.42/V.42bis/V.44 commands . . . . . .40

Fax Class 1 commands . . . . . . . . . .41

Fax Class 2 commands . . . . . . . . . .41

Voice commands . . . . . . . . . . . . .42

Appendix D. Notices . . . . . . . . .45

Television output notice . . . . . . . . . .46

Trademarks . . . . . . . . . . . . . .46

Index . . . . . . . . . . . . . . .47

© Lenovo 2005. Portions © IBM Corp. 2005. iii

iv User Guide

Important safety information

Note

Please read important safety information first.

This information can help you safely use your ThinkCentre

personal computer. Follow and retain all information included with your computer.
The information in this document does not alter the terms of your purchase
agreement or the Lenovo

Customer safety is important. Our products are developed to be safe and effective.
However, personal computers are electronic devices. Power cords, power adapters,
and other features can create potential safety risks that can result in physical injury
or property damage, especially if misused. To reduce these risks, follow the
instructions included with your product, observe all warnings on the product and
in the operating instructions, and review the information included in this
document carefully. By carefully following the information contained in this
document and provided with your product, you can help protect yourself from
hazards and create a safer computer work environment.

™

Statement of Limited Warranty.

®

or ThinkPad

®

Note: This information includes references to power adapters and batteries. In

addition to mobile personal computers, some products (such as speakers
and monitors) ship with external power adapters. If you have such a
product, this information applies to your product. In addition, your
computer product may contain a coin-sized internal battery that provides
power to your system clock even when the machine is unplugged, so the
battery safety information applies to all computers.

Conditions that require immediate action

Products can become damaged due to misuse or neglect. Some product damage
is serious enough that the product should not be used again until it has been
inspected and, if necessary, repaired by an authorized servicer.

As with any electronic device, pay close attention to the product when it is
turned on. On very rare occasions, you might notice an odor or see a puff of
smoke or sparks vent from your machine. Or you might hear sounds like
popping, cracking or hissing. These conditions might merely mean that an
internal electronic component has failed in a safe and controlled manner. Or,
they might indicate a potential safety issue. However, do not take risks or
attempt to diagnose the situation yourself.

Frequently inspect your computer and its components for damage or wear or
signs of danger. If you have any question about the condition of a component,
do not use the product. Contact the Customer Support Center or the product
manufacturer for instructions on how to inspect the product and have it
repaired, if necessary.

In the unlikely event that you notice any of the conditions listed below, or if
you have any safety concerns with your product, stop using the product and

© Lenovo 2005. Portions © IBM Corp. 2005. v

unplug it from the power source and telecommunication lines until you can
speak to the Customer Support Center for further guidance. See “Information
resources” on page xiii.

v Power cords, plugs, power adapters, extension cords, surge protectors, or power

supplies that are cracked, broken or damaged.

v Signs of overheating, smoke, sparks or fire.

v Damage to a battery (such as cracks, dents, creases), discharge from a battery, or

a buildup of foreign substances on the battery.

v A cracking, hissing or popping sound, or strong odor that comes from the

product.

v Signs that liquid has been spilled or an object has fallen onto the computer

product, the power cord or power adapter.

v The computer product, the power cord or power adapter has been exposed to

water.

v The product has been dropped or damaged in any way.

v The product does not operate normally when you follow the operating

instructions.

If you notice these conditions with a product (such as an extension cord)

Note:

that is not manufactured for or by Lenovo, stop using that product until you
can contact the product manufacturer for further instructions, or until you
get a suitable replacement.

General safety guidelines

Always observe the following precautions to reduce the risk of injury and property
damage.

Service

Do not attempt to service a product yourself unless instructed to do so by the
Customer Support Center. Use only a service provider who is approved to repair
your particular product.

Note: Some parts can be upgraded or replaced by the customer. These parts are

referred to as Customer Replaceable Units, or CRUs. Lenovo expressly
identifies CRUs as such, and provides documentation with instructions
when it is appropriate for customers to replace those parts. You must closely
follow all instructions when performing such replacements. Always make
sure that the power is turned off and that the product is unplugged from
any power source before you attempt the replacement. If you have any
questions or concerns, contact the Customer Support Center.

Although there are no moving parts in your computer after the power cord has
been disconnected, the following warnings are required for proper UL certification.

vi User Guide

Danger

Hazardous moving parts. Keep fingers and other body parts away.

Attention

Before replacing any CRUs, turn off the computer and wait three to five
minutes to let the computer cool before opening the cover.

Power cords and power adapters

Use only the power cords and power adapters supplied by the product
manufacturer.

Never wrap a power cord around the power adapter or other object. Doing so can
stress the cord in ways that can cause the cord to fray, crack or crimp. This can
present a safety hazard.

Always route power cords so that they will not be walked on, tripped over, or
pinched by objects.

Protect the cord and power adapters from liquids. For instance, do not leave your
cord or power adapter near sinks, tubs, toilets, or on floors that are cleaned with
liquid cleansers. Liquids can cause a short circuit, particularly if the cord or power
adapter has been stressed by misuse. Liquids can also cause gradual corrosion of
the power cord terminals and/or the connector terminals on the adapter which can
eventually result in overheating.

Always connect power cords and signal cables in the correct order and ensure that
all power cord connectors are securely and completely plugged into receptacles.

Do not use any power adapter that shows corrosion at the ac input pins and/or
shows signs of overheating (such as deformed plastic) at the ac input or anywhere
on the power adapter.

Do not use any power cords where the electrical contacts on either end show signs
of corrosion or overheating or where the power cord appears to have been
damaged in any way.

Extension cords and related devices

Ensure that extension cords, surge protectors, uninterruptible power supplies, and
power strips that you use are rated to handle the electrical requirements of the

Important safety information vii

product. Never overload these devices. If power strips are used, the load should
not exceed the power strip input rating. Consult an electrician for more
information if you have questions about power loads, power requirements, and
input ratings.

Plugs and outlets

If a receptacle (power outlet) that you intend to use with your computer
equipment appears to be damaged or corroded, do not use the outlet until it is
replaced by a qualified electrician.

Do not bend or modify the plug. If the plug is damaged, contact the manufacturer
to obtain a replacement.

Some products are equipped with a three-pronged plug. This plug fits only into a
grounded electrical outlet. This is a safety feature. Do not defeat this safety feature
by trying to insert it into a non-grounded outlet. If you cannot insert the plug into
the outlet, contact an electrician for an approved outlet adapter or to replace the
outlet with one that enables this safety feature. Never overload an electrical outlet.
The overall system load should not exceed 80 percent of the branch circuit rating.
Consult an electrician for more information if you have questions about power
loads and branch circuit ratings.

Be sure that the power outlet you are using is properly wired, easily accessible,
and located close to the equipment. Do not fully extend power cords in a way that
will stress the cords.

Carefully connect and disconnect the equipment from the electrical outlet.

Batteries

All personal computers manufactured by Lenovo contain a non-rechargeable coin
cell battery to provide power to the system clock. In addition many mobile
products such as ThinkPad notebook PCs utilize a rechargeable battery pack to
provide system power when in portable mode. Batteries supplied by Lenovo for
use with your product have been tested for compatibility and should only be
replaced with approved parts.

Never attempt to open or service any battery. Do not crush, puncture, or incinerate
batteries or short circuit the metal contacts. Do not expose the battery to water or
other liquids. Only recharge the battery pack strictly according to instructions
included in the product documentation.

Battery abuse or mishandling can cause the battery to overheat, which can cause
gasses or flame to “vent” from the battery pack or coin cell. If your battery is
damaged, or if you notice any discharge from your battery or the buildup of
foreign materials on the battery leads, stop using the battery and obtain a
replacement from the battery manufacturer.

viii User Guide

Batteries can degrade when they are left unused for long periods of time. For some
rechargeable batteries (particularly Lithium Ion batteries), leaving a battery unused
in a discharged state could increase the risk of a battery short circuit, which could
shorten the life of the battery and can also pose a safety hazard. Do not let
rechargeable Lithium-Ion batteries completely discharge or store these batteries in a
discharged state.

Heat and product ventilation

Computers generate heat when turned on and when batteries are charging.
Notebook PCs can generate a significant amount of heat due to their compact size.
Always follow these basic precautions:

v Do not leave the base of your computer in contact with your lap or any part of

your body for an extended period when the computer is functioning or when
the battery is charging. Your computer produces some heat during normal
operation. Extended contact with the body could cause discomfort or, potentially,
a skin burn.

v Do not operate your computer or charge the battery near flammable materials or

in explosive environments.

v Ventilation slots, fans and/or heat sinks are provided with the product for safety,

comfort, and reliable operation. These features might inadvertently become
blocked by placing the product on a bed, sofa, carpet, or other flexible surface.
Never block, cover or disable these features.

should inspect your desktop computer for dust accumulation at least once

You
every three months. Before inspecting your computer, turn off the power and
unplug the computer’s power cord from the electrical outlet; then remove any dust
from vents and perforations in the bezel. If you notice external dust accumulation,
you should also examine and remove dust from the inside of the computer
including heat sink inlet fins, power supply vents, and fans. Always turn off and
unplug the computer before opening the cover. If possible, avoid operating your
computer within 2 feet of high-traffic areas. If you must operate your computer in
or near a high-traffic area, you should inspect and, if necessary, clean your
computer more frequently.

For your safety and to maintain optimum computer performance, always follow
these basic precautions with your desktop computer:

v Keep the cover closed whenever the computer is plugged in.

v Regularly inspect the outside of the computer for dust accumulation.

v Remove dust from vents and any perforations in the bezel. More frequent

cleanings might be required for computers in dusty or high-traffic areas.

v Do not block or restrict airflow into the front of the computer.

v Do not block the airflow vents on the back of the computer.

v Do not store or operate your computer inside furniture, as this might increase

the risk of overheating.

v Airflow temperatures into the computer should not exceed 35° C (95° F).

v Do not use non-ThinkCentre air filtration devices.

CD and DVD drive safety

CD and DVD drives spin discs at a high speed. If a CD or DVD is cracked or
otherwise physically damaged, it is possible for the disc to break apart or even
shatter when the CD drive is in use. To protect against possible injury due to this
situation, and to reduce the risk of damage to your machine, do the following:

v Always store CD/DVD discs in their original packaging

v Always store CD/DVD discs out of direct sunlight and away from direct heat

sources

v Remove CD/DVD discs from the computer when not in use

v Do not bend or flex CD/DVD discs, or force them into the computer or their

packaging

Important safety information ix

v Check CD/DVD discs for cracks before each use. Do not use cracked or

damaged discs

Additional safety information

Danger
Electrical current from power, telephone, and communication cables is
hazardous.

To avoid a shock hazard:

v Do not connect or disconnect any cables or perform installation, maintenance,

or reconfiguration of this product during an electrical storm.

v Connect all power cords to a properly wired and grounded electrical outlet.

v Connect to properly wired outlets any equipment that will be attached to this

product.

v When possible, use one hand only to connect or disconnect signal cables.

v Never turn on any equipment when there is evidence of fire, water, or

structural damage.

v Disconnect the attached power cords, telecommunications systems, networks,

and modems before you open the device covers, unless instructed otherwise
in the installation and configuration procedures.

v Connect and disconnect cables as described in the following table when

installing, moving, or opening covers on this product or attached devices.

To connect:

1. Turn everything OFF.

2. First, attach all cables to devices.

3. Attach signal cables to connectors.

4. Attach power cords to outlet.

5. Turn device ON.

Lithium battery notice

Caution
Danger of explosion if battery is incorrectly replaced.

When replacing the battery, use only Part Number 33F8354 or an equivalent type

battery recommended by the manufacturer. The battery contains lithium and can
explode if not properly used, handled, or disposed of.

Do not:

v Throw or immerse into water
v Heat to more than 100°C (212°F)
v Repair or disassemble

To disconnect:

1. Turn everything OFF.

2. First, remove power cords from outlet.

3. Remove signal cables from connectors.

4. Remove all cables from devices.

x User Guide

Dispose

of the battery as required by local ordinances or regulations.

Modem safety information

Caution
To reduce the risk of fire, use only No. 26 AW G or larger
telecommunication line cord.

To reduce the risk of fire, electrical shock, or injury when using telephone

equipment, always follow basic safety precautions, such as:

v Never install telephone wiring during a lightning storm.

v Never install telephone jacks in wet locations unless the jack is specifically

designed for wet locations.

v Never touch uninsulated telephone wires or terminals unless the telephone line

has been disconnected at the network interface.

v Use caution when installing or modifying telephone lines.

v Avoid using a telephone (other than a cordless type) during an electrical storm.

There may be a remote risk of electric shock from lightning.

v Do not use the telephone to report a gas leak in the vicinity of the leak.

Laser compliance statement

Some personal computer models are equipped from the factory with a CD-ROM
drive or a DVD-ROM drive. CD-ROM drives and DVD-ROM drives are also sold
separately as options. CD-ROM drives and DVD-ROM drives are laser products.
These drives are certified in the U.S. to conform to the requirements of the
Department of Health and Human Services 21 Code of Federal Regulations (DHHS
21 CFR) Subchapter J for Class 1 laser products. Elsewhere, these drives are
certified to conform to the requirements of the International Electrotechnical
Commission (IEC) 825 and CENELEC EN 60 825 for Class 1 laser products.

When a CD-ROM drive or a DVD-ROM drive is installed, note the following
handling instructions.

Caution
Use of controls or adjustments or performance of procedures other than
those specified herein might result in hazardous radiation exposure.

Removing the covers of the CD-ROM drive or DVD-ROM drive could result in

exposure to hazardous laser radiation. There are no serviceable parts inside the
CD-ROM drive or DVD-ROM drive. Do not remove the drive covers.

Some CD-ROM drives and DVD-ROM drives contain an embedded Class 3A or
Class 3B laser diode. Note the following statement.

Danger
Laser radiation when open. Do not stare into the beam, do not view
directly with optical instruments, and avoid direct exposure to the beam.

Important safety information xi

Power supply statement

Never remove the cover on a power supply or any part that has the following
label attached.

Hazardous voltage, current, and energy levels are present inside any component
that has this label attached. There are no serviceable parts inside these components.
If you suspect a problem with one of these parts, contact a service technician.

xii User Guide

Overview

Thank you for selecting this computer. Your computer incorporates many of the
latest advances in computer technology and can be upgraded as your needs
change.

Adding hardware options to your computer is an easy way to increase its
capabilities. Instructions for installing external and internal options are included in
this publication. When adding an option, use these instructions along with the
instructions that come along with the option.

Information resources

The Quick Reference that comes with your computer provides information for
installing your computer and starting the operating system. It also includes basic
troubleshooting information, software recovery procedures, help and service
information, and warranty information.

The ThinkVantage
to more information about your computer.

™

Productivity Center program, on your desktop, provides a link

If you have Internet access, the most up-to-date information for your computer is
available from the World Wide Web.

You can find the following information:

v CRU removal and installation instructions
v Publications
v Troubleshooting information
v Parts information
v Downloads and drivers
v Links to other useful sources of information
v Support phone list

To access this information, point your browser to:
http://www.lenovo.com/think/support/

© Lenovo 2005. Portions © IBM Corp. 2005. xiii

xiv User Guide

Chapter 1. Installing options

Features

This chapter provides an introduction to the features and options that are available
for your computer. You can expand the capabilities of your computer by adding
memory, adapters, or drives. When installing an option, use these instructions
along with the instructions that come with the option.

Important

Before you install or remove any option, read “Important safety information”
on page v. These precautions and guidelines will help you work safely.

Note: Use only the parts provided by Lenovo.

This section provides an overview of the computer features and preinstalled
software.

System information

The following information covers a variety of models. For information for
your specific model, use the Setup Utility. See Chapter 2, “Using the Setup
Utility,” on page 27.

Microprocessor

®

v Intel

Pentium

®

4 processor with HyperThreading Technology

v Intel Pentium D processor

© Lenovo 2005. Portions © IBM Corp. 2005. 1

®

v Intel Celeron

D processor

v Internal cache (size varies by model type)

Memory

v Support for two double data rate dual inline memory modules (DDR DIMMs)

v 6 Mbits flash memory for system programs

Internal

drives

v 3.5-inch, half-inch (slim) diskette drive (some models)

v Serial Advanced Technology Attachment (SATA) internal hard disk drive

v Optical drive (some models)

subsystem

Video

v An integrated graphics controller for a Video Graphics Array (VGA) monitor

v Intel Graphics Media Accelerator 950 with dual display support

subsystem

Audio

The integrated HD audio controller provides four audio connectors.

v Microphone and headphone connectors on the front panel

v Line in and line out connectors on the rear panel

v Mono internal speaker (some models)

Connectivity

v 10/100/1000 Mbps integrated Ethernet controller (some models)

v Peripheral Component Interconnect (PCI) V.90 Data/Fax modem (some models)

System

management features

v Remote Program Load (RPL) and Dynamic Host Configuration Protocol (DHCP)

®

v Wake on LAN

v Wake on Ring (in the Setup Utility program, this feature is called Serial Port

Ring Detect for an external modem)

v Remote Administration

v Automatic power-on startup

v System Management (SM) BIOS and SM software

v Ability to store power-on self-test (POST) hardware test results

2 User Guide

Input/output

features

v 25-pin Extended Capabilities Port (ECP)/Extended Parallel Port (EPP)

v Two 9-pin serial connectors

v Eight USB connectors (two on front panel and six on rear panel)

v Standard mouse connector

v Standard keyboard connector

v Ethernet connector

v VGA monitor connector

v Two audio connectors (line in and line out) on rear panel

v Two audio connectors (microphone and headphone) on front panel

Expansion

v Three drive bays

v One 32-bit PCI adapter connector

v One PCI Express x1 adapter connector

Power

v 230 Watt power supply with manual voltage selection switch

v Automatic 50/60 Hz input frequency switching

v Advanced Power Management support

v Advanced Configuration and Power Interface (ACPI) support

Security

features

v User and administrator passwords for BIOS access

v Support for the addition of an integrated cable lock (Kensington lock)

v Keyboard with fingerprint reader (some models, see the ThinkVantage

Productivity Center program for more information)

v Startup sequence control

v Startup without diskette drive, keyboard, or mouse

v Unattended start mode

v Diskette and hard disk I/O control

v Serial and parallel port I/O control

v Security profile by device

Preinstalled

computer might come with preinstalled software. If it does, an operating

Your

software

system, device drivers to support built-in features, and other support programs are
included.

Operating systems, preinstalled (varies by model)

Note: Not all countries or regions have these operating systems.

v Microsoft

Windows

®

XP Home

®

v Microsoft Windows XP Professional

1

Operating

v Linux

®

systems, certified or tested for compatibility

(varies by model)

v Microsoft Windows 2000

1. The operating systems listed here are being certified or tested for compatibility at the time this publication goes to press.
Additional operating systems might be identified by Lenovo as compatible with your computer following the publication of this
booklet. Corrections and additions to this list are subject to change. To determine if an operating system has been certified or
tested for compatibility, check the Web site of the operating system vendor.

Chapter 1. Installing options 3

Available options

The following are some available options:

v External options

Internal options

v

For
Web pages:

v http://www.lenovo.com/think/us/en/

v http://www.lenovo.com/think/support/

– Parallel port devices, such as printers and external drives

– Serial port devices, such as external modems and digital cameras

– Audio devices, such as external speakers for the sound system

– USB devices, such as printers, joysticks, and scanners

– Security devices, such as an integrated cable lock

– Monitors

– System memory, called dual inline memory modules (DIMMs)

– Peripheral component interconnect (PCI) adapter

– PCI Express x1 adapter

– Optical drive, such as CD drives and DVD drives (some models)

– Hard disk drive

the latest information about available options, see the following World Wide

You can also obtain information by calling the following telephone numbers:

v Within the United States, call 1-800-426-7378, your Lenovo reseller, or Lenovo

marketing representative.

v Within Canada, call 1-800-565-3344 or 1-800-426-4968.

v Outside the United States and Canada, contact your Lenovo reseller or Lenovo

marketing representative.

4 User Guide

Specifications

This section lists the physical specifications for your computer.

Dimensions

Width: 310 mm (12.2 in.)

Height: 87.5 mm (3.45 in.)

Depth: 358 mm (14.1 in.)

Weight

Minimum configuration as shipped: 7.3 kg (16 lbs)

Maximum configuration: 8.5 kg (18.7 lbs)

Environment

Air temperature:

Humidity:

Maximum altitude: 7000 ft (2133.6 m)

Electrical

Input voltage:

High range:

Input kilovolt-amperes (kVA) (approximate):

Operating at 0 - 3000 ft (914.4 m): 10° to 35°C (50°
to 95°F)

Operating at 3000 ft - 7000 ft (2134 m): 10° to 32°C
(50° to 89.6°F)

Non-operating: 10° to 43°C (50° to 110°F)

Operating: 8% to 80%

Non-operating: 8% to 80%

Transit: 8% to 90%

input

Low range:

Minimum: 100 V ac

Maximum: 127 V ac

Input frequency range: 50/60 Hz

Voltage switch setting: 115 V ac

Minimum: 200 V ac

Maximum: 240V ac

Input frequency range: 50/60 Hz

Voltage switch setting: 230 V ac

Minimum configuration as shipped: 0.09 kVA

Maximum configuration: 0.19-0.34 kVA
Note: The actual maximum configuration
value may vary depending on the
microprocessor, configuration, and software.

Heat output (approximate) in British thermal units (Btu)
per hour:

Minimum configuration: 256 Btu/hr (75 watts)

Maximum configuration: 904 Btu/hr (265 watts)

Airflow

Approximately 16 cubic feet (0.45 cubic meters) per
minute

Acoustical

noise-emission values

Note: In this computer, fan speed is controlled by
temperature, configuration, and software. Actual
noise-emission values might be different from the stated
values depending on the number of fans and the speed
of the fans.

Average sound-pressure levels:

At operator position (0.5 meters):

Idle: 29 dBA

Operating: 34 dBA

At bystander position - 1 meter (3.3 ft):

Idle: 26 dBA

Operating: 29 dBA

Declared (upper limit) sound-power levels:

Idle: 4.0 bels

Operating: 4.3 bels

These levels were measured in controlled

Note:

acoustical environments according to the procedures
specified by the American National Standards Institute
(ANSI) S12.10 and ISO 7779 and are reported in
accordance with ISO 9296. Actual sound-pressure levels
in a given location might exceed the average values
stated because of room reflections and other nearby noise
sources. The declared sound-power levels indicate an
upper limit, below which a large number of computers
will operate.

Chapter 1. Installing options 5

Supported operating positions

To provide proper air flow to internal components, you must position your
computer in one of the positions as illustrated below.

Note: A floor stand should be used when placing your computer in the vertical

position.

Tools required

To install some options in your computer, you might need a flat-blade or Phillips
screwdriver. Additional tools might be needed for certain options. See the
instructions that come with the option.

Handling static-sensitive devices

Static electricity, although harmless to you, can seriously damage computer
components and options.

When you add an option, do not open the static-protective package containing the
option until you are instructed to do so.

When you handle options and other computer components, take these precautions
to avoid static electricity damage:

v Limit your movement. Movement can cause static electricity to build up around

you.

v Always handle components carefully. Handle adapters and memory modules by

the edges. Never touch any exposed circuitry.

v Prevent others from touching components.

6 User Guide

v When you install a new option, touch the static-protective package containing

the option to a metal expansion-slot cover or other unpainted metal surface on
the computer for at least two seconds. This reduces static electricity in the
package and your body.

v When possible, remove the option and install it directly in the computer without

setting the option down. When this is not possible, place the static-protective
package that the option came in on a smooth, level surface and place the option
on it.

v Do not place the option on the computer cover or other metal surface.

Installing external options

This section shows the various external connectors on your computer to which you
can attach external options, such as external speakers, a printer, or a scanner. For
some external options, you must install additional software in addition to making
the physical connection. When adding an external option, use the information in
this section to identify the required connector, and then use the instructions that
come with the option to help you make the connection and install any software or
device drivers that are required for the option.

Locating controls and connectors on the front of your computer

The following illustration shows the locations of the controls and connectors on the
front of your computer.

1 Optical drive 5 USB connectors (2)
2 Hard disk drive activity indicator 6 Microphone connector
3 Power-on indicator 7 Headphone connector
4 Power button 8 Diskette drive

Chapter 1. Installing options 7

Locating connectors on the rear of your computer

The following illustration shows the locations of connectors on the rear of your
computer.

1 Power cord connector 9 Parallel connector
2 Cable lock latch 10 Audio line in connector
3 PCI Express x1 adapter connector 11 Audio line out connector
4 PCI adapter connector 12 USB connectors (4)
5 Serial connectors (2) 13 Standard keyboard connector
6 Ethernet connector 14 Standard mouse connector
7 USB connectors (2) 15 Power supply diagnostic LEDs
8 VGA monitor connector

Note: Some connectors on the rear of your computer are color-coded to help you

determine where to connect the cables on your computer.

8 User Guide

Connector Description

Serial connector Used to attach an external modem, serial printer, or other

devices that use a 9-pin serial connector.

Ethernet connector Used to attach an Ethernet cable for a local area network

(LAN).
Note: To operate the computer within FCC Class B limits, use
a Category 5 Ethernet cable.

USB connectors Used to attach a device that requires a Universal Serial Bus

(USB) connection, such as a USB scanner or USB printer. If you
have more than eight USB devices, you can purchase a USB
hub, which you can use to connect additional USB devices.

Parallel connector Used to attach a parallel printer, parallel scanner, or other

devices that use a 25-pin parallel connector.

Audio line in connector Used to receive audio signals from an external audio device,

such as a stereo system. When you attach an external audio
device, a cable is connected between the audio line out
connector of the device and the audio line in connector of the
computer.

Audio line out connector Used to send audio signals from the computer to external

devices, such as powered stereo speakers (speakers with
built-in amplifiers), headphones, multimedia keyboards, or the
audio line in connector on a stereo system or other external
recording device.

Keyboard connector Used to attach a keyboard that uses a standard keyboard

connector.

Mouse connector Used to attach a mouse, trackball, or other pointing device that

uses a standard mouse connector.

Obtaining device drivers

You can obtain device drivers for operating systems that are not preinstalled at
http://www.lenovo.com/think/support/ on the World Wide Web. Installation
instructions are provided in README files with the device-driver files.

Chapter 1. Installing options 9

Opening the cover

Read “Important safety information” on page v and “Handling
static-sensitive devices” on page 6 before opening the computer cover.

To open the computer cover:

1. Remove any media (diskettes, CDs, or tapes) from the drives, shut down your

2. Unplug all power cords from electrical outlets.

3. Disconnect all cables attached to the computer. This includes power cords,

4. Remove the floor stand, if attached.

5. Remove any locking devices such as a cable lock that secure the cover.

6. Press the buttons on the sides of the computer and pivot the cover upward to

Important

operating system, and turn off all attached devices.

input/output (I/O) cables, and any other cables that are connected to the
computer.

open the computer as shown.

10 User Guide

Locating components

The following illustration will help you locate the various components in your
computer.

1 Diskette drive lock 7 Internal speaker
2 Microprocessor and heat sink 8 Hard disk drive
3 Memory modules (2) 9 Optical drive
4 Battery 10 Optical drive lock
5 PCI riser assembly 11 Diskette drive
6 Power supply assembly

Chapter 1. Installing options 11

Accessing system board components and drives

You might need to pivot the drive bay assembly upward and remove the PCI riser
and adapters to access system board components such as memory, the battery, and
to access the drives.

To access system board components and the drives:

1. Open the computer cover. See “Opening the cover” on page 10.

2. Pivot the drive bay assembly upward as illustrated.

Note: Make sure you note the location of any cables that you disconnect from

the drives or the system board.

3. If any PCI adapters are installed, remove the PCI riser and adapter cards. Do

not remove any adapters from the riser card. See “Installing PCI adapters” on
page 15.

12 User Guide

Identifying parts on the system board

The system board (sometimes called the planar or motherboard) is the main circuit
board in your computer. It provides basic computer functions and supports a
variety of devices that are factory-installed or that you can install later.

The following illustration shows the locations of parts on the system board.

1 Memory connector 1 9 Diskette drive connector
2 Memory connector 2 10 Front panel connector
3 SATA IDE connectors (2) 11 Power supply connector
4 Chassis intrusion switch 12 PATA primary IDE connector
5 PCI riser connector 13 12v power connector
6 Battery 14 Microprocessor
7 Clear CMOS/Recovery jumper 15 Fan connector 2
8 Internal speaker connector 16 Fan connector 1

Chapter 1. Installing options 13

Installing memory

Your computer has two connectors for installing double date rate dual inline
memory modules (DDR DIMMs) that provide up to a maximum of 4 GB of system
memory.

When installing memory modules, the following rules apply:

v Use 1.8 V, 240-pin, double data rate 2 synchronous dynamic random access

v Use 256 MB, 512 MB, 1 GB, or 2 GB DIMMs in any combination.

Note:

To install a memory module:

1. Open the computer cover. See “Opening the cover” on page 10.

2. Access the system board. See “Accessing system board components and drives”

3. Locate the memory connectors. See “Identifying parts on the system board” on

4. Open the retaining clips.

memory (DDR2 SDRAM).

Only DDR2 SDRAM DIMMs can be used.

on page 12.

page 13.

5. Position the memory module over the memory connector. Make sure that the

notch 1 on the memory module aligns correctly with the connector key2 on
the system board. Push the memory module straight down into the connector
until the retaining clips close.

6. Reinstall the PCI riser assembly if it was removed.

14 User Guide

What to do next:

v To work with another option, go to the appropriate section.

v To complete the installation, go to “Closing the cover and connecting the

cables” on page 25.

Installing PCI adapters

This section provides information and instructions for installing and removing PCI
adapters. Your computer has a riser card with one PCI adapter connector and one
PCI Express x1 adapter connector.

To install a PCI adapter:

1. Open the computer cover. See “Opening the cover” on page 10.

2. While holding the left rear of the computer chassis down, pull upward on the

handle provided to remove the PCI riser and any adapters that are currently
installed.

3. Release the adapter latch and remove the connector cover for the appropriate

expansion connector.

4. Remove the adapter from its static-protective package.

Chapter 1. Installing options 15

5. Install the adapter into the appropriate connector in the PCI riser.

Note: The top connector is for the PCI adapter and the bottom connector is for

the PCI Express x1 adapter.

6. Position the adapter latch to retain the adapters.

7. Reinstall the PCI riser assembly.

What to do next:

v To work with another option, go to the appropriate section.

v To complete the installation, go to “Closing the cover and connecting the

cables” on page 25.

Installing internal drives

This section provides information and instructions for installing and removing
internal drives.

Internal drives are devices that your computer uses to read and store data. You can
add drives to your computer to increase storage capacity and to enable your
computer to read other types of media. Some of the different drives that are
available for your computer are:

v Serial Advanced Technology Attachment (SATA) hard disk drives
v Parallel ATA hard disk drives
v Optical drives, such as CD drives or DVD drives
v Removable media drives

These different drives are also referred to as integrated drive electronics

Note:

(IDE) drives.

Internal drives are installed in bays. In this book, the bays are referred to as bay 1,
bay 2, and so on.

16 User Guide

When you install an internal drive, it is important to note what type and size of
drive that you can install in each bay. Also, it is important to correctly connect the
internal drive cables to the installed drive.

Drive specifications

Your computer comes with the following factory-installed drives:

v A 3.5-inch hard disk drive in bay 1
v An optical drive in bay 2 (some models)
v A 3.5-inch diskette drive in bay 3 (some models)

bay that does not have a drive installed has a static shield and bay panel

Any
installed.

The following illustration shows the locations of the drive bays.

The following list describes the types and size of drives you can install in each
bay:

1 Bay 1 - Maximum height: 26.1 mm (1.0 in.) 3.5-inch hard disk drive (preinstalled)
2 Bay 2 - Maximum height: 43.0 mm (1.7 in.) Optical drives, such as CD drive or

DVD drive (preinstalled in some
models)

3.5-inch hard disk drive (requires a
Universal Adapter Bracket, 5.25 to

3.5-inch) *

5.25-inch hard disk drive

3 Bay 3 - Maximum height: 12.7 mm (0.5 in.) 3.5-inch diskette drive (preinstalled in

some models)

* You can obtain a Universal Adapter Bracket, 5.25 to 3.5-inch, from a local computer retailer
or by contacting the Customer Support Center.

Chapter 1. Installing options 17

Installing a drive in bay 2

To install an optical drive or an additional hard disk drive in bay 2, do the
following:

1. Open the computer cover. See “Opening the cover” on page 10.

2. Pivot the drive bay assembly upward to gain access to the cable connections.

3. Remove the front bezel by releasing the tab as shown.

4. Lower the drive bay assembly.

5. Remove the metal shield from the drive bay by using a flat-blade screwdriver

to gently pry it loose.

6. If you are installing a drive with accessible media, such as an optical drive,

remove the plastic panel in the bezel by squeezing the plastic tabs that secure
the panel on the inside of the bezel.

18 User Guide

Note: If you are installing a 3.5-inch hard disk drive you must use a

Universal Adapter Bracket, 5.25 to 3.5-inch. You can obtain this bracket
from a local computer retailer or by contacting the Customer Support
Center.

7. Reinstall the front bezel.

8. Slide the optical drive lock to the unlock position. See “Locating components”

on page 11.

9. If you are installing any type of drive other than a serial ATA hard disk drive,

make sure the drive that you are installing is set correctly as either a master
or a slave device.

Note: A serial ATA hard disk drive does not need to be set as either a master

or a slave device.

If you are installing an optical drive or a parallel ATA hard disk drive, set it as
a master device. Refer to the documentation that comes with your drive for
master/slave jumper information.

10. For a 3.5-inch drive, install the drive into the Universal Adapter Bracket, 5.25

to 3.5-inch.

11. Install the drive into the bay until it snaps into position.

12. Slide the optical drive lock 1 to the locked position.

13. Pivot the drive bay assembly upward to gain access to the cable connections.

14. Connect at “Connecting drives” on page 21.

Installing a diskette drive in bay 3

To install a diskette drive in bay 3, do the following:

1. Open the computer cover. See “Opening the cover” on page 10.

Chapter 1. Installing options 19

2. Pivot the drive bay assembly upward to gain access to the cable connections.

3. Remove the front bezel by releasing the tab as shown.

20 User Guide

4. Lower the drive bay assembly.

5. Remove the metal shield from the diskette drive bay by using a flat-blade

screwdriver to gently pry it loose.

6. Remove the plastic panel in the bezel by squeezing the plastic tabs that secure

the panel on the inside of the bezel.

7. Reinstall the front bezel.

8. Slide the diskette drive lock to the unlock position. See “Locating

components” on page 11.

9. Connect the flat cable to the new drive.

10. Install the new drive from the rear of the drive bay assembly and slide the

diskette drive lock 1 to the locked position.

v To work with another option, go to the appropriate section.

v To complete the installation, go to “Closing the cover and connecting the

Connecting drives

The steps to connect a drive are different depending on the type of drive you are
connecting. Use one of the following procedures for your drive connection.

Connecting an optical drive or a parallel ATA hard disk drive

1. Locate the two-connector signal cable that comes with your computer or with

2. Locate the PATA primary IDE connector on the system board. See “Identifying

3. Connect one end of the signal cable to the drive and the other to the P ATA

What to do next:

cables” on page 25.

the new drive.

parts on the system board” on page 13.

primary IDE connector on the system board.

Chapter 1. Installing options 21

4. Locate the extra four-wire power connector labelled P4 and connect it to the

drive.

Connecting an additional serial ATA hard disk drive

A serial hard disk drive can be connected to any available S ATA connector.

1. Locate the signal cable that comes with the new drive.

2. Locate the available SATA connector on the system board. See “Identifying

parts on the system board” on page 13.

3. Connect one end of the signal cable to the drive and the other to the available

SATA connector on the system board.

4. Locate one of the extra five-wire power connectors and connect it to the drive.

Security features

To help prevent hardware theft and unauthorized access to your computer, several
security lock options are available. In addition to a physical lock, unauthorized use
of your computer can be prevented by a software lock that locks the keyboard
until a correct password is typed in.

Make sure that any security cables you install do not interfere with other computer
cables.

What to do next:

v To work with another option, go to the appropriate section.

v To complete the installation, go to “Closing the cover and connecting the

cables” on page 25.

22 User Guide

Integrated cable lock

With an integrated cable lock (sometimes referred to as the Kensington lock), you
can secure your computer to a desk, table, or other non-permanent fixture. The
cable lock attaches to a security slot at the rear of your computer and is operated
with a key. The cable lock also locks the buttons used to open the computer cover.
This is the same type of lock used with many laptop computers. You can order a
security cable directly from Lenovo. Go to
http://www.lenovo.com/think/support/ and search on Kensington.

Password protection

To deter unauthorized use of your computer, you can use the Setup Utility
program to set a password. When you turn on your computer you are prompted to
type the password to unlock the keyboard for normal use.

What to do next:

v To work with another option, go to the appropriate section.

v To complete the installation, go to “Closing the cover and connecting the

cables” on page 25.

Changing the battery

Your computer has a special type of memory that maintains the date, time, and
settings for built-in features, such as parallel-port assignments (configuration). A
battery keeps this information active when you turn off the computer.

The battery normally requires no charging or maintenance throughout its life;
however, no battery lasts forever. If the battery fails, the date, time, and
configuration information (including passwords) are lost. An error message is
displayed when you turn on the computer.

Chapter 1. Installing options 23

Refer to “Lithium battery notice” on page x for information about replacing and
disposing of the battery.

To change the battery:

1. Turn off the computer and disconnect the power cord from the electrical outlet

and from the computer.

2. Open the computer cover. See “Opening the cover” on page 10.

3. Access the system board. See “Accessing system board components and

drives” on page 12.

4. Locate the battery. See “Identifying parts on the system board” on page 13.

5. Remove the old battery.

6. Install the new battery.

7. Reinstall the PCI riser assembly if removed.

8. Close the computer cover, and connect the cables. See “Closing the cover and

connecting the cables” on page 25.

Note: When the computer is turned on for the first time after battery

replacement, an error message might be displayed. This is normal after
replacing the battery.

9. Turn on the computer and all attached devices.

10. Use the Setup Utility program to set the date and time and any passwords.

See Chapter 2, “Using the Setup Utility,” on page 27.

Erasing a lost or forgotten password (clearing CMOS)

This section applies to lost or forgotten passwords. For more information about
lost or forgotten passwords, go to the ThinkVantage Productivity Center program.

Note: If you are enrolled in the Hardware Password Reset program, refer to

“Resetting the hard disk drive and power-on password” on page 29 to reset
your password. If you do clear CMOS or restore Setup Utility defaults, you
will have to re-enroll in the Hardware Password Reset program.

To erase a forgotten password:

1. Open the computer cover. See“Opening the cover” on page 10.

2. Access the system board. See “Accessing system board components and

drives” on page 12.

3. Locate the Clear CMOS/Recovery jumper on the system board. See

“Identifying parts on the system board” on page 13.

24 User Guide

4. Move the jumper from the standard position (pins 1 and 2) to the

maintenance or configure position (pins 2 and 3).

5. Reinstall the PCI riser assembly if removed.

6. Lower the drive bay assembly and reconnect any cables that were

disconnected.

7. Close the computer cover and connect the power cord. See “Closing the cover

and connecting the cables.”

8. Restart the computer, leave it on for approximately 10 seconds. Turn off the

computer by holding the power switch for approximately 5 seconds. The
computer will turn off.

9. Repeat steps 1 through 3 on page 24.

10. Move the Clear CMOS/Recovery jumper back to the standard position (pins 1

and 2).

11. Reinstall the PCI riser assembly if removed.

12. Close the computer cover and connect the power cord. See “Closing the cover

and connecting the cables.”

Closing the cover and connecting the cables

After working with options, you need to install any removed parts, close the
computer cover, and reconnect cables, including telephone lines and power cords.
Also, depending on the option that is installed, you might need to confirm the
updated information in the Setup Utility program.

To close the computer cover and connect cables to your computer:

1. Ensure that all components have been reassembled correctly and that no tools

or loose screws are left inside your computer.

2. Make sure that the cables are routed correctly before lowering the drive bay

assembly.

3. Lower the drive bay assembly and make sure that the drive locks are both in

the locked position. Otherwise, you cannot close the computer cover.

4. Close the computer cover.

5. Install any locking devices such as a cable lock as necessary.

6. If your computer is being placed in the vertical position, attach the floor stand.

7. Reconnect the external cables and power cords to the computer. See “Locating

connectors on the rear of your computer” on page 8.

Chapter 1. Installing options 25

8. To update the configuration, see Chapter 2, “Using the Setup Utility,” on page

27.

26 User Guide

Chapter 2. Using the Setup Utility

The Setup Utility program is stored in the electrically erasable programmable
read-only memory (EEPROM) of your computer. The Setup Utility program is used
to view and change the configuration settings of your computer, regardless of
which operating system you are using. However, the operating-system settings
might override any similar settings in the Setup Utility program.

Starting the Setup Utility program

To start the Setup Utility program, do the following:

1. If your computer is already on when you start this procedure, shut down the

operating system and turn off the computer.

2. Press and hold the F1 key then turn on the computer. When you hear multiple

beeps, release the F1 key.

Notes:

a. If you are using a USB keyboard and the Setup Utility program does not

display using this method, repeatedly press and release the F1 key rather
than leaving it pressed when turning on the computer.

b. If a user password or an administrator password has been set, the Setup

Utility program menu is not displayed until you type your password. See
“Using passwords” for more information.

Setup Utility might start automatically when POST detects that hardware has

The
been removed or new hardware has been installed in your computer.

Viewing and changing settings

The Setup Utility program menu lists items that identify system configuration
topics.

When working with the Setup Utility program menu, you must use the keyboard.
The keys used to perform various tasks are displayed at the bottom of each screen.

Using passwords

By using the Setup Utility program, you can set passwords to prevent
unauthorized persons from gaining access to your computer and data. The
following types of passwords are available:

v User Password

v Administrator Password

v IDE Drive User Password

v IDE Drive Master Password

do not have to set any passwords to use your computer. However, if you

You
decide to set any passwords, read the following sections.

© Lenovo 2005. Portions © IBM Corp. 2005. 27

Password considerations

A password can be any combination of up to twelve characters (a-z and 0-9) and
symbols. For security reasons, it is a good idea to use a strong password that
cannot be easily compromised. Strong passwords typically adhere to the following
rules:

v Have at least eight characters in length

v Contain at least one alphabetic character, one numeric character, and one symbol

v Contain at least one of the following symbols: , . / ` ; ' []

v You can also use the space bar

v Setup Utility program and hard disk drive passwords are not case sensitive

v Not be your name or your user name

v Not be a common word or a common name

v Be significantly different from your previous password

you are setting any of the various types of passwords on your computer, you

If
should read and understand the following information:

v If you type an incorrect password, you will see an error message. If you type an

incorrect password three consecutive times, you must turn the computer off and
start again.

v If you set both a User Password and an IDE Drive User Password to the same

string, you will be prompted for the password only once when you turn on your
computer.

v Do not move an IDE hard disk drive to another computer if an IDE Drive User

Password has been set unless that computer also supports the IDE Drive User
password.

v If your computer is connected to a local area network (LAN), the Wake on LAN

feature will not work unless both a User Password and an IDE Drive User
Password are set using the same password.

User Password

When a User Password is set, the user is prompted to type a valid password each
time the computer is turned on. The computer cannot be used until a valid
password is typed from the keyboard.

Administrator Password

Setting an Administrator Password deters unauthorized persons from changing
configuration settings. If you are responsible for maintaining the settings of several
computers, you might want to set an Administrator Password.

After you set an Administrator Password, a password prompt is displayed each
time you try to access the Setup Utility program.

If both the user and administrator passwords are set, you can type either
password. However, to change any configuration settings, you must use your
administrator password.

IDE Drive User Password

The IDE Drive User Password is used to protect the data on the IDE hard disk
drive(s). When this password is set, you are prompted to type a valid password

28 User Guide

before any hard disk drive can be used. This prompt is displayed each time you
turn on your computer. If your computer has multiple hard disk drives, they all
must use the same password.

Attention

If an IDE Drive User Password is set but no IDE Drive Master Password is
set, there is no recovery in the event that the IDE Drive User Password is lost
or forgotten. The hard disk drive must be replaced. See “IDE Drive Master
Password.”

IDE Drive Master Password

The IDE Drive Master Password is used to recover use of the hard disk drive in
the event that the IDE Drive User Password is lost or forgotten. Only the person
who knows the IDE Drive Master password can reset the IDE Drive User
Password.

Attention

Make sure that the IDE Drive Master password is stored in a safe place. If
both the IDE Drive User password and the IDE Drive Master password are
lost or forgotten, the IDE hard disk drive must be replaced.

If both the IDE Drive User Password and the IDE Drive Master Password are to be

set, the IDE Drive Master Password must be set before setting the IDE Drive User
Password.

Setting, changing, and deleting a password

To set, change, or delete a password, do the following:

Note: A password can be any combination of up to twelve characters (A- Z, a-z,

and 0-9). See “Password considerations” on page 28 for more information.

1. Start the Setup Utility program (see Chapter 2, “Using the Setup Utility,” on

page 27).

2. From the Setup Utility program menu, select Security.

3. Select Set Passwords. Read the information displayed on the right side of the

screen.

Resetting the hard disk drive and power-on password

Note: To enroll in password reset, refer to the ThinkVantage Create Rescue Media

feature under Windows.

To reset the hard disk drive and power-on password, do the following:

1. Start the Setup Utility program (see “Starting the Setup Utility program” on

page 27).

2. From the Setup Utility program menu, select Security.

3. Select Set Passwords.

4. Select Password Reset Service and select the desired setting. Read the

information displayed on the right side of the screen.

Chapter 2. Using the Setup Utility 29

Using Security Profile by Device

Security Profile by Device is used to enable or disable user access to the following
devices:

IDE controller When this feature is set to Disable, all devices connected to the

IDE controller (such as hard disk drives or the CD-ROM drive)
are disabled and will not be displayed in the system
configuration.

Diskette Drive Access When this feature is set to Disable, the diskette drive cannot be

accessed.

Diskette Write Protect When this feature is set to Enable, all diskettes are treated as if

they are write-protected. You can read from the diskette, but you
cannot write to the diskette.

To set Security Profile by Device, do the following:

1. Start the Setup Utility program (see “Starting the Setup Utility program” on

page 27).

2. From the Setup Utility program menu, select Security.

3. Select Security Profile by Device.

4. Select the desired devices and settings and press Enter.

5. Return to the Setup Utility program menu and select Exit and then Save

Settings or Save and exit the Setup Utility.

Note: If you do not want to save the settings, select Exit the Setup Utility

without saving.

Selecting a startup device

If your computer does not start up (boot) from a device such as the CD-ROM,
diskette, or hard disk as expected, use one of the following procedures to select a
startup device.

Selecting a temporary startup device

Use this procedure to startup from any boot device.

Note: Not all CDs, hard disks, and diskettes are startable (bootable).

1. Turn off your computer.

2. Press and hold the F12 key then turn on the computer. When the Startup

Device Menu appears, release the F12 key.

Note: If you are using a USB keyboard and the Startup Device Menu does not

display using this method, repeatedly press and release the F12 key
rather than leaving it pressed when turning on the computer.

3. Select the desired startup device from the Startup Device Menu and press Enter

to begin.

Selecting a startup device from the Startup Device menu does not

Note:

permanently change the startup sequence.

Changing the startup device sequence

To view or permanently change the configured startup device sequence, do the
following:

30 User Guide

1. Start the Setup Utility program (see “Starting the Setup Utility program” on

2. Select Startup.

3. Select Startup Sequence. See the information displayed on the right side of the

4. Select the devices for the Primary Startup Sequence, the Automatic Startup

5. Select Exit from the Setup Utility menu and then Save Settings or Save and

If you have changed these settings and want to return to the default settings, select
Load Default Settings on the Exit menu.

Advanced settings

On some computer models the Advanced settings menu includes a setting to
Enable/Disable HyperThreading. This feature works only with
HyperThreading-aware operating systems such as Microsoft Windows XP. The
default setting for HyperThreading is Enabled. However, if you select Set Defaults
and are using an operating system other than Windows XP, your computer
performance might be degraded. Therefore, you should always set
HyperThreading to Disabled unless you are sure your operating system supports
HyperThreading.

page 27).

screen.

Sequence, and the Error Startup Sequence.

exit the Setup Utility.

Exiting from the Setup Utility program

When you finish viewing or changing settings, press Esc to return to the Setup
Utility program menu (you might have to press Esc several times). If you want to
save the new settings, select Save Settings or Save and exit the Setup Utility.
Otherwise, your changes will not be saved.

Chapter 2. Using the Setup Utility 31

32 User Guide

Appendix A. Updating system programs

This appendix contains information about updating POST/BIOS and how to
recover from a POST/BIOS update failure.

System program

System programs are the basic layer of software that is built into your computer.
They include the power-on self-test (POST), the basic input/output system (BIOS)
code, and the Setup Utility program. POST is a set of tests and procedures that is
performed each time you turn on your computer. BIOS is a layer of software that
translates instructions from other layers of software into electrical signals that the
computer hardware can understand. You can use the Setup Utility program to
view and change the configuration and setup of your computer.

Your computer system board has a module called electrically erasable programmable
read-only memory (EEPROM, also referred to as flash memory). You can easily update
POST, BIOS, and the Setup Utility program by starting your computer using a
flash update diskette or by running a special update program from your operating
system.

Lenovo might make changes and enhancements to the POST/BIOS. When updates
are released, they are available as downloadable files on the World Wide Web (see
the Quick Reference). Instructions for using the POST/BIOS updates are available in
a .txt file that is included with the update files. For most models, you can
download either an update program to create a system-program-update (flash)
diskette or an update program that can be run from the operating system.

Note: You can download a self starting bootable CD image (known as an .iso

image) of the diagnostics program from
http://www.lenovo.com/think/support to support systems without a
diskette drive.

Updating (flashing) BIOS from a diskette or CD-ROM

To update (flash) the BIOS from a diskette or CD-ROM, do the following:

1. Insert a system program update (flash) diskette or CD-ROM into the diskette

drive or optical drive. System program updates are available at
http://www.lenovo.com/think/support on the World Wide Web.

2. Turn on the computer. If it is on already, you must turn it off and back on

again. The update begins.

3. When you are prompted to select a language, press the number on your

keyboard that corresponds to the language and then press Enter.

4. When prompted to change the serial number, press Y.

5. Type in the seven character serial number of your computer and then press

Enter.

6. When prompted to change the machine type/model, press Y.

7. Type in the seven character machine type/model of your computer and then

press Enter.

8. Follow the instructions on the screen to complete the update.

© Lenovo 2005. Portions © IBM Corp. 2005. 33

Updating (flashing) BIOS from your operating system

Note: Due to constant improvements being made to the Web site, Web page

content (including the links referenced in the following procedure) is subject
to change.

1. From your browser, type http://www.lenovo.com/think/support in the

address field and press Enter.

2. Locate the Downloadable files for your machine type as follows:

a. Under Use Quick path, type your machine type and click Go.

b. Click Continue.

c. Click Downloads and drivers.

d. Under the BIOS category, click the Flash BIOS update.

e. Click the .txt file that contains the installation instructions for the flash BIOS

update (flash from the operating system version).

Print these instructions. This is very important since they are not on the screen

3.

after the download begins.

4. From your browser, click Back to return to the list of files. Carefully follow the

printed instructions to download, extract, and install the update.

Recovering from a POST/BIOS update failure

If power to your computer is interrupted while POST/BIOS is being updated (flash
update), your computer might not restart correctly. If this happens, perform the
following procedure commonly called Boot-block Recovery.

1. Turn off the computer and any attached devices, such as printers, monitors,

and external drives.

2. Unplug all power cords from electrical outlets, and open the computer cover.

See “Opening the cover” on page 10.

3. Access the system board. See “Accessing system board components and

drives” on page 12.

4. Locate the Clear CMOS/Recovery jumper on the system board. See

“Identifying parts on the system board” on page 13.

5. Remove any cables that impede access to the Clear CMOS/Recovery jumper.

6. Move the jumper from the standard position (pins 1 and 2) to pins 2 and 3.

7. Reinstall the PCI riser assembly if removed.

8. Close the computer cover and reconnect any cables that were disconnected.

See “Closing the cover and connecting the cables” on page 25.

9. Reconnect the power cords for the computer and monitor to electrical outlets.

10. Insert the POST/BIOS update (flash) diskette into drive A, and turn on the

computer and the monitor.

11. The recovery session will take two to three minutes. During this time you will

hear a series of beeps. After the update session is completed, there will be no
video, the series of beeps will end, and the system will automatically turn off.
Remove the diskette from the diskette drive.

12. Repeat steps 2 through 5.

13. Replace the Clear CMOS/Recovery jumper to its original position.

14. Reinstall the PCI riser assembly if removed.

15. Close the computer cover and reconnect any cables that were disconnected.

16. Turn on the computer to restart the operating system.

34 User Guide

Appendix B. Cleaning the mouse

This appendix provides instructions on how to clean your mouse. The procedure
will be different depending on which type of mouse you have.

Cleaning an optical mouse

If you experience some problems with your optical mouse, check the following:

1. Unplug the mouse from the computer.

2. Turn the mouse over and look carefully at the lens area.

a. If there is a smudge on the lens, gently clean the area with a plain

cotton-tipped swab.

b. If there is some debris in the lens, gently blow the debris away from the

area.

3. Check the surface on which you are using the mouse. If you have a very

intricate picture or pattern beneath the mouse it is difficult for the digital signal
processor (DSP) to determine changes in the mouse position.

Cleaning a mouse with a ball

If the pointer on the screen does not move smoothly with the mouse, you might
need to clean the mouse.

Note: The following illustration might be slightly different from your mouse.

1 Retainer ring
2 Ball
3 Plastic rollers
4 Ball cage

© Lenovo 2005. Portions © IBM Corp. 2005. 35

To clean a mouse with a ball:

1. Turn off your computer.

2. Turn the mouse over, with the top side down, and look carefully at the bottom.

Twist the retainer ring1to the unlocked position to remove the ball.

3. Place your hand over the retainer ring and ball2, and then turn the mouse

over, top side up, so that the retainer ring and ball fall out into your hand.

4. Wash the ball in warm, soapy water then dry it with a clean cloth. Blow air

carefully into the ball cage4to dislodge dust and lint.

5. Look for a build up of dirt on the plastic rollers3inside the ball cage. This

build up usually appears as a stripe running across the middle of the rollers.

6. If the rollers are dirty, clean them by using a cotton swab soaked in isopropyl

(rubbing) alcohol. Turn the rollers with your finger and continue swabbing
them until all the dirt is removed. Be sure the rollers are still centered in their
channels after you clean them.

7. Remove any fibers from the swab that might be remaining on the rollers.

8. Replace the ball and the retainer ring.

9. Turn your computer back on.

36 User Guide

Appendix C. Manual modem commands

The following section lists commands for manually programming your modem.

Commands are accepted by the modem while it is in Command Mode. Your
modem is automatically in Command Mode until you dial a number and establish
a connection. Commands can be sent to your modem from a PC running
communication software or any other terminal devices.

All commands sent to the modem must begin with AT and end with ENTER. All
commands can be typed in either upper or lower case, but not mixed. To make the
command line more readable, spaces can be inserted between commands. If you
omit a parameter from a command that requires one, it is just like specifying a
parameter of 0.

Example:

ATH [ENTER]

Basic AT commands

In the following listings, all default settings are printed in bold text.

Command Function

A Manually answer incoming call.

A/ Repeat last command executed. Do not

D_ 0 - 9, A-D, # and *

DS=n Dial one of the four telephone numbers

E_ E0 Commands are not echoed

+++ Escape Characters - Switch from Data Mode

H_ H0 Force modem on-hook (hang up)

precede A/ with AT or follow with ENTER.

L last number redial

P pulse dialing

Note: Pulse dialing is not supported for
Australia, New Zealand, Norway, and South
Africa.

T touch-tone dialing

W wait for second dial tone

, pause

@ wait for five seconds of silence

! flash

; return to Command Mode after dialing

(n=0-3) stored in the modem non-volatile
memory.

E1 Commands are echoed

to Command Mode (T.I.E.S. Command)

© Lenovo 2005. Portions © IBM Corp. 2005. 37

Command Function

H1 Force modem off-hook (make busy)

Note: H1 command is not supported for Italy

I_ I0 Display product-identification code

I1 Factory ROM checksum test

I2 Internal memory test

I3 Firmware ID

I4 Reserved ID

L_ L0 Low speaker volume

L1 Low speaker volume

L2 Medium speaker volume

L3 High speaker volume

M_ M0 Internal speaker off

M1 Internal speaker on until carrier detected

M2 Internal speaker always on

M3 Internal speaker on until carrier detected and

off while dialing

N_ Included for compatibility only, provides no

effect

O_ O0 Return to Data Mode

O1 Return to Data Mode and initiate an equalizer

retrain

P Set Pulse dial as default

Q_ Q0 Modem sends responses

Sr? Read and display value in register r.

Sr=n Set register r to value n (n = 0-255).

T Set Tone Dial as default

V_ V0 Numeric responses

V1 Word responses

W_ W0 Report DTE speed only

W1 Report line speed, error correction protocol,

and DTE speed.

W2 Report DCE speed only

X_ X0 Hayes Smartmodem 300 compatible

responses/blind dialing.

X1 Same as X0 plus all CONNECT

responses/blind dialing

X2 Same as X1 plus dial tone detection

X3 Same as X1 plus busy detection/blind dialing

X4 All responses and dial tone and busy signal

detection

Z_ Z0 Reset and retrieve active profile 0

Z1 Reset and retrieve active profile 1

38 User Guide

Extended AT commands

Command Function

&C_ &C0 Force Carrier Detect Signal High (ON)

&C1 Turn on CD when remote carrier is present

&D_ &D0 Modem ignores the DTR signal

&D1 Modem returns to Command Mode after DTR

toggle

&D2 Modem hangs up, returns to the Command

Mode after DTR toggle

&D3 Resets modem after DTR toggle

&F_ &F Recall factory default configuration

&G_ &G0 Guard tone disabled

&G1 Guard tone disabled

&G2 1800 Hz guard tone

&K_ &K0 Disable flow control

&K3 Enable RTS/CTS hardware flow control

&K4 Enable XON/XOFF software flow control

&K5 Enable transparent XON/XOFF flow control

&K6 Enable both RTS/CTS and XON/XOFF flow

control

&M_ &M0 Asynchronous operation

&P_ &P0 US setting for off-hook-to-on-hook ratio

&P1 UK and Hong Kong off-hook-to-on-hook ratio

&P2 Same as &P0 setting but at 20 pulses per

minute

&P3 Same as &P1 setting but at 20 pulses per

minute

&R_ &R0 Reserved

&R1 CTS operates per flow control requirements

&S_ &S0 Force DSR Signal High (ON)

&S1 DSR off in command mode, on in on-line

mode

&T_ &T0 Ends test in progress

&T1 Perform Local Analog Loopback Test

&T3 Perform Local Digital Loopback Test

&T4 Grant Remote Digital Loopback Test request

by remote modem

&T5 Deny Remote Digital Loopback Test request

&T6 Perform a Remote Digital Loopback Test

&T7 Perform a Remote Digital Loopback Test and

Self-Test

&T8 Perform Local Analog Loopback Test and

Self-Test

&V &V0 Displays Active and Stored Profiles

Appendix C. Manual modem commands 39

Command Function

&V1 Display Last Connection Statistics

&W_ &W0 Stores the active profile as Profile 0

&W1 Stores the active profile as Profile 1

%E_ %E0 Disable auto-retrain

%E1 Enable auto-retrain

+MS? Displays the current Select Modulation

settings

+MS=? Displays a list of supported Select Modulation

options

+MS=a,b,c,e,f Select modulation where: a=0, 1, 2, 3, 9, 10, 11,

12, 56, 64, 69; b=0-1; c=300-56000; d=300­56000; e=0-1; and f=0-1. A, b, c, d, e, f
default=12, 1, 300, 56000, 0, 0. Parameter “a”
specifies the modulation protocol desired
where: 0=V.21, 1=V.22, 2=V.22bis, 3=V.23,
9=V.32, 10=V.32bis, 11=V.34,

12=V.90,K56Flex,V.34......,56=K 56Flex,

V.90,V.34......, 64=Bell 103, and 69=Bell 212.

Parameter “b” specifies automode operations
where: 0=automode disabled, 1= automode
enabled with V.8/V.32 Annex A. Parameter
“c” specifies the minimum connection data
rate (300- 56000). Parameter “d” specifies the
maximum connection rate (300-56000);
Parameter “e” specifies the codec type (0=
Law, and 1=A-Law). Parameter “f” specifies
“robbed bit” signaling detection (0=detection
disabled 1=detection enabled)

MNP/V.42/V.42bis/V.44 commands

Command Function

%C_ %C0 Disable MNP Class 5 and V.42bis data compression

%C1 Enable MNP Class 5 data compression only

%C2 Enable V.42bis data compression only

%C3 Enable MNP Class 5 and V.42bis data compression

&Q_ &Q0 Direct data link only (same as \N1)

&Q5 V.42 data link with fallback options

&Q6 Normal data link only (same as \N0)

+DS44=0, 0 Disable V.44

+DS44=3, 0 Enable V.44

+DS44? Current values

+DS44=? List of support values

40 User Guide

Fax Class 1 commands

+FAE=n Data/Fax Auto Answer

+FCLASS=n Service Class

+FRH=n Receive data with HDLC framing

+FRM=n Receive data

+FRS=n Receive silence

+FTH=n Transmit data with HDLC framing

+FTM=n Transmit data

+FTS=n Stop transmission and wait

Fax Class 2 commands

+FCLASS=n Services class.

+FAA=n Adaptive answer.

+FAXERR Fax error value.

+FBOR Phase C data bit order.

+FBUF? Buffer size (read only).

+FCFR Indicate confirmation to receive.

+FCLASS= Service class.

+FCON Facsimile connection response.

+FCIG Set the polled station identification.

+FCIG: Report the polled station identification.

+FCR Capability to receive.

+FCR= Capability to receive.

+FCSI: Report the called station ID.

+FDCC= DCE capabilities parameters.

+FDCS: Report current session.

+FDCS= Current session results.

+FDIS: Report remote capabilities.

+FDIS= Current sessions parameters.

+FDR Begin or continue phase C receive data.

+FDT= Data transmission.

+FDTC: Report the polled station capabilities.

+FET: Post page message response.

+FET=N Transmit page punctuation.

+FHNG Call termination with status.

+FK Session termination.

+FLID= Local ID string.

+FLPL Document for polling.

+FMDL? Identify model.

+FMFR? Identify manufacturer.

Appendix C. Manual modem commands 41

+FPHCTO Phase C time out.

+FPOLL Indicates polling request.

+FPTS: Page transfer status.

+FPTS= Page transfer status.

+FREV? Identify revision.

+FSPT Enable polling.

+FTSI: Report the transmit station ID.

Voice commands

#BDR Select Baud Rate

#CID Enable Caller ID detection and reporting format

#CLS Select Data, Fax or Voice/Audio

#MDL? Identify Model

#MFR? Identify Manufacturer

#REV? Identify Revision Level

#TL Audio output transmit level

#VBQ? Query Buffer Size

#VBS Bits per sample (ADPCM or PCM)

#VBT Beep Tone Timer

#VCI? Identify Compression Method

#VLS Voice line select

#VRA Ringback goes away timer

#VRN Ringback never came timer

#VRX Voice Receive Mode

#VSDB Silence deletion tuner

#VSK Buffer skid setting

#VSP Silence detection period

#VSR Sampling rate selection

#VSS Silence deletion tuner

#VTD DTMF tone reporting capability

#VTM Enable timing mark placement

#VTS Generate tone signals

#VTX Voice transmit mode

42 User Guide

Attention Switzerland User:

If your Swisscom phone line does not have Taxsignal switched OFF, modem
function may be impaired. The impairment may be resolved by a filter with
the following specifications:

Telekom PTT SCR-BE
Taximpulssperrfilter-12kHz
PTT Art. 444.112.7
Bakom 93.0291.Z.N

Appendix C. Manual modem commands 43

44 User Guide

Appendix D. Notices

Lenovo may not offer the products, services, or features discussed in this
document in all countries. Consult your local Lenovo representative for
information on the products and services currently available in your area. Any
reference to a Lenovo product, program, or service is not intended to state or
imply that only that Lenovo product, program, or service may be used. Any
functionally equivalent product, program, or service that does not infringe any
Lenovo intellectual property right may be used instead. However, it is the user’s
responsibility to evaluate and verify the operation of any other product, program,
or service.

Lenovo may have patents or pending patent applications covering subject matter
described in this document. The furnishing of this document does not give you
any license to these patents. Yo u can send license inquiries, in writing, to:

Lenovo (United States), Inc.
500 Park Offices Drive, Hwy. 54
Research Triangle Park, NC 27709
U.S.A.
Attention: Lenovo Director of Licensing

LENOVO

GROUP LTD. PROVIDES THIS PUBLICATION “AS IS” WITHOUT

WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some
jurisdictions do not allow disclaimer of express or implied warranties in certain
transactions, therefore, this statement may not apply to you.

This information could include technical inaccuracies or typographical errors.
Changes are periodically made to the information herein; these changes will be
incorporated in new editions of the publication. Lenovo may make improvements
and/or changes in the product(s) and/or the program(s) described in this
publication at any time without notice.

The products described in this document are not intended for use in implantation
or other life support applications where malfunction may result in injury or death
to persons. The information contained in this document does not affect or change
Lenovo product specifications or warranties. Nothing in this document shall
operate as an express or implied license or indemnity under the intellectual
property rights of Lenovo or third parties. All information contained in this
document was obtained in specific environments and is presented as an
illustration. The result obtained in other operating environments may vary.

Lenovo may use or distribute any of the information you supply in any way it
believes appropriate without incurring any obligation to you.

Any references in this publication to non-Lenovo Web sites are provided for
convenience only and do not in any manner serve as an endorsement of those Web
sites. The materials at those Web sites are not part of the materials for this Lenovo
product, and use of those We b sites is at your own risk.

Any performance data contained herein was determined in a controlled
environment. Therefore, the result obtained in other operating environments may

© Lenovo 2005. Portions © IBM Corp. 2005. 45

vary significantly. Some measurements may have been made on development-level
systems and there is no guarantee that these measurements will be the same on
generally available systems. Furthermore, some measurements may have been
estimated through extrapolation. Actual results may vary. Users of this document
should verify the applicable data for their specific environment.

Television output notice

The following notice applies to models that have the factory-installed
television-output feature.

This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or disassembly is
prohibited.

Trademarks

The following terms are trademarks of Lenovo in the United States, other
countries, or both:

Lenovo
ThinkCentre
ThinkPad
ThinkVantage

following terms are trademarks of International Business Machines

The
Corporation in the United States, other countries, or both:

IBM (used under license)
Wake on LAN

Microsoft

and Windows are trademarks of Microsoft Corporation in the United

States, other countries, or both.

Intel, Celeron and Pentium are trademarks of Intel Corporation in the United
States, other countries, or both.

Linux is a trademark of Linus Torvalds in the United States, other countries, or
both.

Other company, product, or service names may be trademarks or service marks of
others.

46 User Guide

Index

A

adapter

connectors 15
installing 15

peripheral component interconnect (PCI) 4
audio line in connector 9
audio line out connector 9
audio subsystem 2

B

battery, changing 23
BIOS, updating (flashing) 33
Boot-block recovery 34

C

cables, connecting 25
changing

changing the battery 23
closing the cover 25
CMOS, clearing 24
components, internal 11
connecting drives 21
connector description 9
connectors

cover

device sequence 30

startup

7

front

rear 8

closing 25

opening 10

D

device drivers 9
drives

17

bays

internal 16

specifications 17
dual inline memory modules (DIMMs) 14

H

hard disk drive recovery 29
hard disk drive security 28

I

information resources xiii
input/output (I/O) features 2
installing options

adapters
internal drives 16
memory modules 14
security features 22

internal drives 2

15

K

keyboard connector 9

L

locating components 11

M

memory

installing

modem commands

Basic
Extended AT 39
Fax Class 1 41
Fax Class 2 41
MNP/V.42/V.42bis/V.44 40

Voice 42
mouse cleaning 35
mouse connector 9

14

AT 37

N

noise level 5

E

environment, operating 5
Ethernet 2
Ethernet connector 9
exiting, Setup Utility 31
expansion adapters 3
external options 7

O

opening the cover 10
options 4

available 4

external 4

internal 4

P

F

features 1

© Lenovo 2005. Portions © IBM Corp. 2005. 47

parallel connector 9
password

administrator 28

erasing 24

IDE drive master 29

IDE drive user 28

password (continued)

lost or forgotten 24
setting, changing, deleting 29
user 28

passwords

considerations

28

PCI adapter 15
physical specifications 5
power

Advanced

Configuration and Power Interface (ACPI)

support 3
Advanced Power Management support 3
features 3

R

recovering from a POST/BIOS update failure 34
resetting

hard disk drive password 29
power-on password 29

riser card 15

S

security

cable lock 23
features 3

selecting

startup device 30
temporary startup device 30

serial connector 9
Setup Utility 27
system board

components,
connectors 13
identifying parts 13
location 13
memory 4, 14

system management 2
system programs 33

accessing 12

U

updating (flashing) BIOS 33
updating system programs 33
USB connectors 9
using

passwords

27

security profile by device 30
Setup Utility 27

V

video subsystem 2

48 User Guide

Part Number: 39J8170

Printed in USA

(1P) P/N: 39J8170
