IBM System x3550 M5

IBM Redbooks Product Guide

Designed in a compact, versatile 1U two-socket rack server, the IBM® System x3550 M5 rack server
fuels almost any workload from infrastructure to high-performance computing (HPC) to cloud or big data
with leadership security, efficiency, and reliability. Integrated with up to two Intel Xeon processors of the
E5-2600 v3 product family with faster, energy-efficient TruDDR4 Memory, the x3550 M5 delivers
exceptional performance. Storage can include up to 12 drives in an impressive selection of sizes and
types. This IBM Redbooks® Product Guide describes the System x3550 M5.

Suggested use

management, enterprise applications, collaboration/email, streaming media, web, and HPC.

The following figure shows the System x3550 M5.

Figure 1. The System x3550 M5

: Database, virtualization and cloud computing, infrastructure security, systems

Did you know?

The x3550 M5 incorporates energy smart features for minimized costs and efficient performance. Dual fan
zones support operation in up to 40°C environments. 80 PLUS Titanium power supply units (PSUs) can
deliver 96% efficiency at 50% load.

The x3550 M5 has outstanding memory performance that is achieved by supporting
two-RDIMM-per-channel configurations at speeds up to 12% faster than the Intel specification, while still
maintaining world-class IBM reliability.

System x® servers achieved the highest reliability of any x86 servers (ITIC 2014-2015 Global Server
Hardware, Server OS Reliability Survey:

http://public.dhe.ibm.com/common/ssi/ecm/en/xsl03126usen/XSL03126USEN.PDF).

The x3550 M5 integrates leadership security and reliability. System x Trusted Platform Assurance, an
exclusive set of System x features and practices, establishes a foolproof security foundation for your
workloads. Enterprise-class data protection is provided with optional self-encrypting drives and simple,
centralized key management through IBM Security Key Lifecycle Management. Diagnostic tools facilitate
reduced downtime and costs.

IBM System x3550 M5 1

Key features

The System x3550 M5 is a cost- and density-balanced 1U, 2-socket business-critical server, offering
improved performance and pay-as-you grow flexibility along with new features that improve server
management capability. New, innovative, energy-smart design with powerful high-performance
processors, a large capacity of high-performing DDR4 memory, and an improved feature set are ideal for
business-critical applications and cloud deployments.

Combining balanced performance and flexibility, the x3550 M5 is a great choice for small and medium
businesses and up to the large enterprise. It can provide outstanding uptime to keep business-critical
applications and cloud deployments running safely. Ease-of-use and comprehensive systems
management tools make it easy to deploy. Outstanding reliability, availability, and serviceability (RAS)
and high-efficiency design improve your business environment and help save operational costs.

Scalability and performance

The x3550 M5 offers numerous features to boost performance, improve scalability, and reduce costs:



Improves productivity by offering superior system performance with up to 18-core processors, up to
45 MB of L3 cache, and up to 9.6 GT/s QPI interconnect links.



Supports up to two processors, 36 cores, and 72 threads to maximize the concurrent execution of
multithreaded applications.



Intelligent and adaptive system performance with energy efficient Intel Turbo Boost Technology
allows CPU cores to run at maximum speeds during peak workloads by temporarily going beyond
processor TDP.



Intel Hyper-Threading Technology boosts performance for multithreaded applications by enabling
simultaneous multithreading within each processor core, up to two threads per core.



Intel Virtualization Technology integrates hardware-level virtualization hooks that allow operating
system vendors to better utilize the hardware for virtualization workloads.



Intel Advanced Vector Extensions 2.0 (AVX 2.0) enable acceleration of enterprise-class workloads,
such as databases, enterprise resource planning, and others.



Up to 2133 MHz memory speeds with two DIMMs per channel running at 2133 MHz to help maximize
system performance.



Up to 1.5 TB of memory capacity with 64 GB Load Reduced DIMMS (LRDIMMs) (support for 64 GB
LRDIMMs is planned for a later date).



12 Gbps serial-attached SCSI (SAS) internal storage connectivity doubles the data transfer rate
compared to 6 Gb SAS solutions to maximize performance of storage I/O-intensive applications.



Flexible and scalable internal storage configurations for up to 24 TB of storage capacity in a dense 1U
rack form factor.



The use of solid-state drives (SSDs) instead of or along with traditional spinning hard disk drives
(HDDs) can significantly improve I/O performance. An SSD can support up to 100 times more I/O
operations per second (IOPS) than a typical HDD.



The server has four integrated Gigabit Ethernet ports and optional 10 Gb Ethernet ports with
mezzanine LOM (ML2) adapters.



The server offers up to four PCI Express (PCIe) 3.0 I/O expansion slots in a dense 1U rack form
factor.



With Intel Integrated I/O Technology, the PCI Express 3.0 controller is integrated into the Intel Xeon
processor E5 family. This helps to dramatically reduce I/O latency and increase overall system
performance.

IBM System x3550 M5 2

Availability and serviceability

The x3550 M5 provides many features to simplify serviceability and increase system uptime:



The server offers memory mirroring and memory rank sparing for redundancy in the event of a
non-correctable memory failure.



Tool-less cover removal provides easy access to upgrades and serviceable parts, such as
processors, memory DIMMs, and adapter cards.



The server offers hot-swap drives supporting RAID redundancy for data protection and greater
system uptime.



The server offers redundant hot-swap power supplies and hot-swap redundant fans to provide
availability for business-critical applications.



The new next-gen light path diagnostics LCD display panel simplifies servicing, speeds up problem
resolution, and helps improve system availability.



Predictive Failure Analysis (PFA) detects when system components (processors, VRMs, memory,
disks, fans, and power supplies) operate outside standard thresholds and generates proactive alerts
in advance of possible failure, therefore increasing uptime.



SSDs offer significantly better reliability than traditional mechanical HDDs for greater uptime.



Built-in Integrated Management Module II (IMM2) continuously monitors system parameters, triggers
alerts, and performs recovery actions in case of failure, to minimize downtime.



Built-in diagnostics using Dynamic Systems Analysis (DSA) Preboot speed up troubleshooting tasks
to reduce service time.



Three-year customer replaceable unit and onsite limited warranty, next business day 9x5. Optional
service upgrades available.

Manageability and security

Powerful systems management features simplify local and remote management of the x3550 M5 and
deliver enterprise-class data protection:



The server includes an Integrated Management Module II (IMM2) to monitor server availability and
perform remote management.



An integrated industry-standard Unified Extensible Firmware Interface (UEFI) enables improved
setup, configuration, and updates, and simplifies error handling.



IBM Systems Director offers comprehensive systems management tools to help increase uptime,
reduce costs, and improve productivity through advanced server management capabilities.



Two integrated Trusted Platform Modules (TPMs) support the enablement of advanced cryptographic
functionality, such as digital signatures and remote attestation.



System x Trusted Platform Assurance, an exclusive set of System x security features and practices,
establishes a foolproof security foundation for workloads by delivering firmware that is securely built,
tested, digitally signed, and verified prior to execution.



The server offers enterprise-class data protection with optional self-encrypting drives and simple,
centralized key management through IBM Security Key Lifecycle Management.



There is industry-standard AES NI support for faster, stronger encryption.



Intel Execute Disable Bit functionality can help prevent certain classes of malicious buffer overflow
attacks when combined with a supporting operating system.

IBM System x3550 M5 3



Intel Trusted Execution Technology provides enhanced security through hardware-based resistance
to malicious software attacks, allowing an application to run in its own isolated space protected from
all other software running on a system.

Energy efficiency

The x3550 M5 offers the following energy-efficiency features to save energy, reduce operational costs,
increase energy availability, and contribute to a green environment:



Energy-efficient planar components help lower operational costs.



High-efficiency power supplies with 80 PLUS Platinum and Titanium certifications.



Intel Intelligent Power Capability powers individual processor elements on and off as needed, to
reduce power draw.



Low-voltage Intel Xeon processors draw less energy to satisfy the demands of power and thermally
constrained data centers and telecommunication environments.



Low-voltage 1.2 V DDR4 memory DIMMs consume up to 20% less energy compared to 1.35 V DDR3
DIMMs.



The server uses hexagonal ventilation holes, a part of IBM Calibrated Vectored Cooling™ technology.
Hexagonal holes can be grouped more densely than round holes, providing more efficient airflow
through the system.



IBM Systems Director Active Energy Manager™ and Intel Node Manager provide advanced data
center power notification and management to help achieve lower heat output and reduced cooling
needs.

Locations of key components and connectors

The following figure shows the front of the server.

Figure 2. Front view of the System x3550 M5

IBM System x3550 M5 4

The following figure shows the rear of the x3550 M5 server with three PCIe low profile slots.

Figure 3. Rear view of the System x3550 M5

The following figure shows the locations of key components inside the server.

Figure 4. Inside view of the System x3550 M5

IBM System x3550 M5 5

Standard specifications

The following table lists the standard specifications.

Table 1. Standard specifications (part 1)

Components Specification

Form factor 1U Rack.

Processor Up to two Intel Xeon processor E5-2600 v3 product family CPUs with 18 cores (2.3 GHz core

speeds) or up to 12 cores (up to 2.6 GHz core speeds). Two QPI links up to 9.6 GT/s each. Up
to 2133 MHz memory speed. Up to 45 MB L3 cache.

Chipset Intel C612.

Memory Up to 24 DIMM sockets (12 DIMMs per processor). RDIMMs and LRDIMMs (Load Reduced

DIMMs) are supported.. Memory types cannot be intermixed. Memory speed up to 2133 MHz.

Memory
maximums



With RDIMMs: Up to 384 GB with 24x 16 GB RDIMMs and two processors



With LRDIMMs: Up to 1.5 TB with 24x 64 GB LRDIMMs and two processors (support for
64 GB LRDIMMs is planned for a later date)

Memory protection Error correction code (ECC), Chipkill (for x4-based memory DIMMs), memory mirroring, and

memory rank sparing.

Disk drive bays Up to 12x 2.5" hot-swap SAS/SATA HDDs, or up to 8x 2.5" Simple Swap SATA HDDs, or up to

4x 3.5" hot-swap SAS/SATA HDDs, or up to 4x 3.5" Simple Swap SATA HDDs.

Maximum internal
storage

Up to 14.4 TB with 1.2 TB 2.5" SAS HDDs, or up to 12 TB with 1 TB 2.5" NL SAS/SATA HDDs,
or up to 11.2 TB with 960 GB 2.5" SATA SSDs, or up to 24 TB with 6 TB 3.5" NL SAS/SATA
HDDs. Intermix of SAS/SATA is supported.

Storage controller Onboard 6 Gb SATA: no RAID support





12 Gb SAS/SATA RAID: RAID 0, 1, 10 with M1215 or M5210. Optional upgrade to RAID 5,
50 is available for M1215. Optional upgrade to RAID 5, 50 is available for M5210
(zero-cache; 1 GB non-backed cache; 1 GB, 2 GB, or 4 GB flash-backed cache). Optional
upgrade to RAID 6, 60 is available for M5210 with memory cache upgrades. Optional SSD
Caching and Performance Accelerator feature upgrades are available.



12 Gb SAS/SATA non-RAID: N2215 HBA

Optical drive bays One, optional, for models with 4 or 8 drive bays (models with 10 drive bays do not support an

internal optical drive). Support for DVD-ROM or Multiburner.

Tape drive bays None.

Network interfaces Four integrated RJ-45 Gigabit Ethernet 1000BASE-T ports (BCM5719); optional Mezzanine

LOM (ML2) slot for dual-port 10 GbE cards with SFP+ or RJ-45 connectors or quad-port GbE
cards with RJ-45 connectors.

PCI Expansion
slots

Up to four slots, depending on the riser cards installed. The slots are as follows:



Slot 1: PCIe 3.0 x16 or ML2; low profile, half-length (not present if the HDD Rear Kit is
installed)



Slot 2: PCIe 3.0 x16 or PCIe 3.0 x8; low profile or full-height, half-length (PCIe 3.0 x16 slot
requires the second processor to be installed) (not present if the HDD Rear Kit is installed)



Slot 3: PCIe 3.0 x16 or PCIe 3.0 x8; low profile, half-length



Slot 4: PCIe 3.0 x8 (dedicated for an internal RAID controller)

IBM System x3550 M5 6

Table 1. Standard specifications (part 2)

Components Specification

Ports Front: 1x USB 3.0, 1x USB 2.0 (8x 2.5" drive bay models) or 2x USB 2.0 (4x 3.5" and 10x

Cooling IBM Calibrated Vectored Cooling with up to eight redundant hot-swap fans (six standard,

Power supply Up to two redundant hot-swap 550 W, 750 W, or 900 W High Efficiency Platinum AC power

Hot-swap parts Hard drives, power supplies, and fans.

Systems
management

Security features Power-on password, administrator's password, two Trusted Platform Modules (TPMs): on the

Video Matrox G200eR2 with 16 MB memory integrated into the IMM2. Maximum resolution is

Operating
systems
supported



2.5" drive bay models), and 1x DB-15 video.



Rear: 2x USB 3.0, 1x USB 2.0, 1x DB-15 video, 1x RJ-45 systems management, 4x RJ-45
GbE network ports. Optional 1x DB-9 serial port.



Internal: 1x USB port (for embedded hypervisor).

additional two with the second processor or with the x3550 M5 Thermal Solution Kit); dual fan
zones with N+1 fan redundancy; each fan has two motors.

supplies, or 750 W High Efficiency Titanium AC power supplies.

Unified Extensible Firmware Interface (UEFI), IBM Integrated Management Module II (IMM2.1)
based on Renesas SH7758, Predictive Failure Analysis, light path diagnostics, Automatic
Server Restart, IBM ToolsCenter, IBM Systems Director and Active Energy Manager, and Intel
Node Manager. Optional IBM Advanced Management Module Advanced Upgrade for remote
presence (graphics, keyboard and mouse, virtual media).

IMM2 (TPM 1.2) and on the host (TPM 1.2/2.0). Optional lockable front bezel.

1600x1200 at 75 Hz with 16 M colors.

Microsoft Windows Server 2012 R2, 2012, and 2008 R2, Red Hat Enterprise Linux 6 and 7,
SUSE Linux Enterprise Server 11, VMware vSphere (ESXi) 5.1 and 5.5.

Limited warranty Three-year customer-replaceable unit and onsite limited warranty with 9x5/Next Business Day

(NBD).

Service and
support

Dimensions Height: 43 mm (1.7 in), width: 429 mm (16.9 in), depth: 734 mm (28.9 in)

Weight Minimum configuration: 13.8 kg (30.5 lb), maximum: 19.3 kg (42.7 lb)

Optional service upgrades are available through IBM ServicePac®: 4-hour or 2-hour response
time, 8 hours fix time, one-year or two-year warranty extension, remote technical support for
IBM hardware and selected IBM and third-party (Microsoft, Linux, VMware) software.

The x3550 M5 servers are shipped with the following items:



Statement of Limited Warranty



Important Notices



Rack Installation Instructions



Documentation CD containing



IBM System x3550 M5 Slide Kit G4



2.8 m C13-C14 power cord (one for models with one power supply and two for models with two power

Installation and User's Guide

supplies)

Note: Cable Management Arm (CMA) is not included. See the "Rack options" section for ordering
information.

IBM System x3550 M5 7

Standard models

The following table lists the standard models of the x3550 M5.

Table 2. Standard models

MTM* Intel Xeon processor†

(2 maximum)

Models announced September 2014

5463-A2x 1x E5-2603 v3 6C 1.6GHz

15MB 1600MHz 85W

5463-B2x 1x E5-2609 v3 6C 1.9GHz

15MB 1600MHz 85W

5463-C2x 1x E5-2620 v3 6C 2.4GHz

15MB 1866MHz 85W

5463-C4x 1x E5-2620 v3 6C 2.4GHz

15MB 1866MHz 85W

5463-D2x 1x E5-2630 v3 8C 2.4GHz

20MB 1866MHz 85W

5463-H2x 1x E5-2630L v3 8C 1.8GHz

20MB 1866MHz 55W

5463-F2x 1x E5-2640 v3 8C 2.6GHz

20MB 1866MHz 90W

5463-G2x 1x E5-2650 v3 10C 2.3GHz

25MB 2133MHz 105W

5463-62x 1x E5-2670 v3 12C 2.3GHz

30MB 2133MHz 120W

Memory
(RDIMMs)

1x 8GB
2133MHz§

1x 8GB
2133MHz§

1x 16GB
2133MHz§

1x 16GB
2133MHz§

1x 16GB
2133MHz§

1x 16GB
2133MHz§

1x 16GB
2133MHz§

1x 16GB
2133MHz

1x 16GB
2133MHz

RAID Drive

M1215 4x 2.5"

M1215 4x 3.5"

M1215 4x 2.5"

M1215 4x 3.5"

M5210
1GB Flash

M5210
1GB Flash

M5210
1GB Flash

M5210
1GB Flash

M5210
2GB Flash

bays

SS / 8

SS / 4

HS / 8

HS / 4

4x 2.5"
HS / 8

4x 2.5"
HS / 8

4x 2.5"
HS / 8

10x 2.5"
HS / 12

4x 2.5"
HS / 8

Drives Onboard

Open
bay

Open
bay

Open
bay

Open
bay

Open
bay

Open
bay

Open
bay

Open
bay

Open
bay

NIC

4x GbE 2 / 4 Optional 1x 550 W

4x GbE 2 / 4 Optional 1x 550 W

4x GbE 2 / 4 Optional 1x 550 W

4x GbE 2 / 4 Optional 1x 550 W

4x GbE 2 / 4 Optional 1x 550 W

4x GbE 2 / 4 Optional 1x 550 W

4x GbE 2 / 4 Optional 1x 550 W

4x GbE 2 / 4 None 1x 550 W

4x GbE 2 / 4 Optional 1x 750 W

I/O
slots
(std /
max)

Optical
drive

Power
supply
(std /
max)

HS / 2

HS / 2

HS / 2

HS / 2

HS / 2

HS / 2

HS / 2

HS / 2

HS / 2

5463-J2x 1x E5-2680 v3 12C 2.5GHz

30MB 2133MHz 120W

5463-L2x 1x E5-2690 v3 12C 2.6GHz

30MB 2133MHz 135W

5463-M2x 1x E5-2699 v3 18C 2.3GHz

45MB 2133MHz 145W

1x 16GB
2133MHz

1x 16GB
2133MHz

1x 16GB
2133MHz

M5210
2GB Flash

M5210 4x 2.5"

M5210 4x 2.5"

4x 2.5"
HS / 8

HS / 8

HS / 8

Open
bay

Open
bay

Open
bay

4x GbE 2 / 4 Optional 1x 750 W

HS / 2

4x GbE 2 / 4 Optional 1x 750 W

HS / 2

4x GbE 2 / 4 Optional 1x 900 W

HS / 2

* x in the Machine Type Model (MTM) represents a country-specific letter (for example, the EMEA MTM is 5463-A2G,
and the US MTM is 5463-A2U). Ask an IBM representative for specifics.
† Processor detail: Processor quantity and model, cores, core speed, L3 cache, memory speed, and thermal design
power (TDP).

§ For these models, the standard DIMM is rated at 2133 MHz, but operates at a lower speed to match the processor
memory speed. Actual memory speed maximums depend on several factors, as described in "Memory options".

Refer to the Specifications section for information about standard features of the server.

IBM System x3550 M5 8

Express models

The following table lists the express models of the x3550 M5.

Table 3. Express models (Part 1: United States, Canada, Latin America)

MTM Intel Xeon processor†

(2 maximum)

United States, Canada

5463-EAU 1x E5-2609 v3 6C 1.9GHz

15MB 1600MHz 85W

5463-EBU 1x E5-2620 v3 6C 2.4GHz

15MB 1866MHz 85W

5463-EEU 2x E5-2620 v3 6C 2.4GHz

15MB 1866MHz 85W

5463-ECU 1x E5-2640 v3 8C 2.6GHz

20MB 1866MHz 90W

5463-EDU 1x E5-2650 v3 10C 2.3GHz

25MB 2133MHz 105W

5463-EFU 2x E5-2650 v3 10C 2.3GHz

25MB 2133MHz 105W

Latin America

5463-EMU1x E5-2609 v3 6C 1.9GHz

15MB 1600MHz 85W

5463-ENU 1x E5-2609 v3 6C 1.9GHz

15MB 1600MHz 85W

Memory
(RDIMMs)

1x 8GB
2133MHz§

1x 16GB
2133MHz§

2x 16GB
2133MHz§

1x 16GB
2133MHz§

1x 16GB
2133MHz

4x 16GB
2133MHz

1x 8GB
2133MHz§

1x 8GB
2133MHz§

RAID Drive

M1215 4x 2.5"

M5210 4x 2.5"

M5210
2GB Flash

M5210 4x 2.5"

M5210 4x 2.5"

M5210
4GB Flash

M1215 4x 3.5"

M5210
1GB Flash

bays

HS / 8

HS / 8

4x 2.5"
HS / 8

HS / 8

HS / 8

8x 2.5"
HS / 8

SS / 4

4x 2.5"
HS / 8

Drives Onboard

Open
bay

Open
bay

Open
bay

Open
bay

Open
bay

Open
bay

Open
bay

2x
300GB
10K

NIC

4x GbE 2 / 4 Multi

4x GbE 2 / 4 Multi

4x GbE 2 / 4 Multi

4x GbE 2 / 4 Multi

4x GbE 2 / 4 Multi

4x GbE 2 / 4 Multi

4x GbE 4 / 4 Multi

4x GbE 4 / 4 Multi

I/O
slots
(std /
max)

Optical
drive

burner

burner

burner

burner

burner

burner

burner

burner

Power
supply
(std /
max)

1x 550 W
HS / 2

1x 550 W
HS / 2

2x 550 W
HS / 2

1x 550 W
HS / 2

1x 750 W
HS / 2

2x 550 W
HS / 2

1x 550 W
HS / 2

2x 550 W
HS / 2

5463-ERU 1x E5-2609 v3 6C 1.9GHz

15MB 1600MHz 85W

5463-ESU 1x E5-2620 v3 6C 2.4GHz

15MB 1866MHz 85W

5463-EOU 1x E5-2620 v3 6C 2.4GHz

15MB 1866MHz 85W

5463-EPU 1x E5-2640 v3 8C 2.6GHz

20MB 1866MHz 90W

5463-EQU 2x E5-2680 v3 12C 2.5GHz

30MB 2133MHz 120W

1x 8GB
2133MHz§

1x 8GB
2133MHz§

1x 8GB
2133MHz§

2x 16GB
2133MHz§

2x 16GB
2133MHz

M1215 4x 2.5"

M5210
1GB Flash

M5210
1GB Flash

M5210
1GB Flash

M5210
2GB Flash

SS / 8

4x 2.5"
SS / 8

4x 3.5"
SS / 4

4x 2.5"
HS / 8

8x 2.5"
HS / 8

Open
bay

Open
bay

Open
bay

Open
bay

Open
bay

4x GbE 4 / 4 Multi

burner

4x GbE 4 / 4 Multi

burner

4x GbE 4 / 4 Multi

burner

4x GbE 4 / 4 Multi

burner

4x GbE 4 / 4 Multi

burner

1x 550 W
HS / 2

2x 550 W
HS / 2

2x 550 W
HS / 2

2x 550 W
HS / 2

2x 750 W
HS / 2

† Processor detail: Processor quantity and model, cores, core speed, L3 cache, memory speed, TDP.

§ For these models, the standard DIMM is rated at 2133 MHz, but operates at a lower speed to match the processor
memory speed. Actual memory speed maximums depend on several factors, as described in "Memory options".

IBM System x3550 M5 9

Table 3. Express models (Part 2: Asia Pacific, Japan, Europe, Middle East and Africa)

MTM Intel Xeon processor†

(2 maximum)

Asia Pacific (Australia and New Zealand only)

5463-EGM1x E5-2609 v3 6C 1.9GHz

15MB 1600MHz 85W

5463-EHM1x E5-2609 v3 6C 1.9GHz

15MB 1600MHz 85W

5463-EIM 1x E5-2620 v3 6C 2.4GHz

15MB 1866MHz 85W

5463-EJM 1x E5-2620 v3 6C 2.4GHz

15MB 1866MHz 85W

5463-EKM 1x E5-2630 v3 8C 2.4GHz

20MB 1866MHz 85W

5463-ELM 2x E5-2650 v3 10C 2.3GHz

25MB 2133MHz 105W

Japan

5463-E5J 1x E5-2603 v3 6C 1.6GHz

15MB 1600MHz 85W

5463-E6J 1x E5-2609 v3 6C 1.9GHz

15MB 1600MHz 85W

Memory
(RDIMMs)

1x 8GB
2133MHz§

1x 8GB
2133MHz§

2x 8GB
2133MHz§

2x 8GB
2133MHz§

2x 8GB
2133MHz§

2x 16GB
2133MHz

1x 8GB
2133MHz§

1x 8GB
2133MHz§

RAID Drive

M1215 4x 3.5"

M5210
1GB Flash

M1215 4x 3.5"

M5210
1GB Flash

M5210
1GB Flash

M5210 8x 2.5"

M5210
1GB Flash

M5210
1GB Flash

bays

SS / 4

4x 2.5"
HS / 8

SS / 4

4x 2.5"
HS / 8

4x 2.5"
HS / 8

HS / 8

4x 2.5"
HS / 8

4x 2.5"
HS / 8

Drives Onboard

Open
bay

2x
300GB
10K

Open
bay

2x
300GB
10K

Open
bay

Open
bay

Open
bay

Open
bay

NIC

4x GbE 4 / 4 Multi

4x GbE 4 / 4 Multi

4x GbE 4 / 4 Multi

4x GbE 4 / 4 Multi

4x GbE 4 / 4 Multi

4x GbE 4 / 4 Multi

4x GbE 4 / 4 Optional 1x 550 W

4x GbE 4 / 4 Optional 1x 550 W

I/O
slots
(std /
max)

Optical
drive

burner

burner

burner

burner

burner

burner

Power
supply
(std /
max)

1x 550 W
HS / 2

1x 550 W
HS / 2

1x 550 W
HS / 2

1x 750 W
HS / 2

1x 750 W
HS / 2

2x 750 W
HS / 2

HS / 2

HS / 2

5463-E7J 1x E5-2620 v3 6C 2.4GHz

15MB 1866MHz 85W

Europe, Middle East and Africa

5463-E1G 1x E5-2603 v3 6C 1.6GHz

15MB 1600MHz 85W

5463-E2G 1x E5-2620 v3 6C 2.4GHz

15MB 1866MHz 85W

5463-E3G 1x E5-2630 v3 8C 2.4GHz

20MB 1866MHz 85W

5463-E4G 1x E5-2640 v3 8C 2.6GHz

20MB 1866MHz 90W

1x 8GB
2133MHz§

1x 8GB
2133MHz§

1x 8GB
2133MHz§

1x 8GB
2133MHz§

1x 16GB
2133MHz§

M5210
1GB Flash

M1215 4x 2.5"

M5210
1GB Flash

M5210
1GB Flash

M5210
1GB Flash

4x 2.5"
HS / 8

HS / 8

8x 2.5"
HS / 8

4x 2.5"
HS / 8

8x 2.5"
HS / 8

Open
bay

Open
bay

Open
bay

Open
bay

Open
bay

4x GbE 4 / 4 Optional 1x 550 W

4x GbE 2 / 4 Multi

burner

4x GbE 2 / 4 Multi

burner

4x GbE 2 / 4 Multi

burner

4x GbE 2 / 4 Multi

burner

HS / 2

1x 550 W
HS / 2

1x 550 W
HS / 2

2x 550 W
HS / 2

1x 550 W
HS / 2

† Processor detail: Processor quantity and model, cores, core speed, L3 cache, memory speed, TDP.

§ For these models, the standard DIMM is rated at 2133 MHz, but operates at a lower speed to match the processor
memory speed. Actual memory speed maximums depend on several factors, as described in "Memory options".

Refer to the Specifications section for information about standard features of the server.

IBM System x3550 M5 10

Processor options

The x3550 M5 supports the processor options listed in the following table. The server supports up to two
processors. This table shows which server models have each processor standard. If there is no
corresponding
Configure-to-order (CTO). The processor part numbers include a CPU, a heatsink, and two system fans.

Table 4. Processor options

Part
number

00KA070 A5BF / A5BV Intel Xeon Processor E5-2603 v3 6C 1.6GHz 15MB Cache 1600MHz 85W A2x

00KA071 A5BG / A5BW Intel Xeon Processor E5-2609 v3 6C 1.9GHz 15MB Cache 1600MHz 85W B2x

00KA067 A5BC / A5BS Intel Xeon Processor E5-2620 v3 6C 2.4GHz 15MB Cache 1866MHz 85W C2x, C4x

00KA068 A5BD / A5BT Intel Xeon Processor E5-2630 v3 8C 2.4GHz 20MB Cache 1866MHz 85W D2x

00KA077 A5BN / A5C2 Intel Xeon Processor E5-2630L v3 8C 1.8GHz 20MB Cache 1866MHz 55W H2x

00KA069 A5BE / A5BU Intel Xeon Processor E5-2640 v3 8C 2.6GHz 20MB Cache 1866MHz 90W F2x

00KA072 A5BH / A5BX Intel Xeon Processor E5-2650 v3 10C 2.3GHz 25MB Cache 2133MHz 105W G2x

00KA074 A5BK / A5BZ Intel Xeon Processor E5-2670 v3 12C 2.3GHz 30MB Cache 2133MHz 120W 62x

where used

Feature
codes*

model for a particular processor, this processor is only available through

Description

Standard
models
where
used

00KA075 A5BL / A5C0 Intel Xeon Processor E5-2680 v3 12C 2.5GHz 30MB Cache 2133MHz 120W J2x

00KA076 A5BM / A5C1 Intel Xeon Processor E5-2690 v3 12C 2.6GHz 30MB Cache 2133MHz 135W L2x

00KF584 ARZ8 / ARZ9 Intel Xeon Processor E5-2699 v3 18C 2.3GHz 45MB Cache 2133MHz 145W M2x

* The first feature code is for the first processor; the second feature code is for the second processor.

IBM System x3550 M5 11

Memory options

The IBM System x3550 M5 supports IBM TruDDR4 Memory. IBM TruDDR Memory uses the
highest-quality components sourced from Tier 1 DRAM suppliers and only memory that meets our strict
requirements is selected. It is compatibility tested and tuned on every IBM System x server to maximize
performance and reliability. IBM TruDDR4 Memory will have a unique signature programmed into the
DIMM, which will enable IBM System x servers to verify whether the memory installed is
qualified/supported by IBM. Because the IBM TruDDR4 Memory is authenticated, certain extended
memory performance features can be enabled to extend performance over industry standards. From a
service and support standpoint, IBM memory automatically assumes the IBM system warranty, and IBM
provides service and support worldwide.

The server supports up to 12 DIMMs when one processor is installed and up to 24 DIMMs when two
processors are installed. Each processor has four memory channels, and there are three DIMMs per
channel.

The following rules apply when selecting the memory configuration:



The server supports RDIMMs and LRDIMMs.



Mixing different types of memory (RDIMMs and LRDIMMs) is not supported.



The maximum quantity of DIMMs that can be installed in the server depends on the number of
processors.



All DIMMs in the server operate at the same speed, which is determined as the lowest value of the
following speeds:



Memory speed that is supported by the specific processor.



Lowest of maximum operating speeds for selected memory configuration that depends on
quantity of DIMMs per channel, as shown under "Maximum operating speed" in Table 5.

The following memory protection technologies are supported:



ECC



Chipkill (for x4-based memory DIMMs)



Memory mirroring



Memory rank sparing

Chipkill works only in independent channel mode (the default is operational mode) and supports only
x4-based memory DIMMs.

If memory mirroring is used, DIMMs must be installed in pairs (a minimum of one pair per each
processor), and both DIMMs in a pair must be identical in type and size.

If memory rank sparing is used, a minimum of one quad-rank LRDIMM or two single-rank or dual-rank
RDIMMs must be installed per populated channel (the DIMMs do not need to be identical). In rank sparing
mode, one rank of a DIMM in each populated channel is reserved as spare memory. The size of a rank
varies depending on the DIMMs installed.

Chipkill, memory mirroring, and memory rank sparing modes are mutually exclusive. Only one operational
memory mode can be enabled on a server, and it is a system-wide setting.

IBM System x3550 M5 12

The following table shows the characteristics of the supported DIMMs. Table cells highlighted with a gray
background indicate when the number of DIMMs per channel still allows the DIMMs to operate at a rated
speed.

Table 5. Maximum memory speeds

DIMM specification RDIMM LRDIMM

Rank Single rank Dual rank Quad rank

Part numbers 46W0784 (4 GB)

46W0788 (8 GB)

Rated speed 2133 MHz 2133 MHz 2133 MHz 2133 MHz

Rated voltage 1.2 V 1.2 V 1.2 V 1.2 V

Maximum quantity supported** 24 24 24 24

Maximum DIMM capacity 8 GB 8 GB 16 GB 64 GB

Maximum memory capacity 192 GB 192 GB 384 GB 1.5 TB

Maximum memory at rated
speed

Maximum operating speed

1 DIMM per channel 2133 MHz 2133 MHz 2133 MHz 2133 MHz

2 DIMMs per channel 2133 MHz 2133 MHz 2133 MHz 2133 MHz

3 DIMMs per channel 1600 MHz 1600 MHz 1866 MHz 1866 MHz

* Support for 64 GB LRDIMMs is planned for a later date.
** The maximum quantity that is supported is shown for two processors installed.

128 GB 128 GB 256 GB 512 GB

46W0792 (8 GB) 46W0796 (16 GB) 46W0800 (32 GB)

95Y4812 (64 GB)*

IBM System x3550 M5 13

The following table lists memory options available for the x3550 M5 server.

Table 6. Memory options

Part
number

RDIMMs - 2133 MHz

46W0784 A5B6 4GB TruDDR4 Memory (1Rx8, 1.2V)

46W0788 A5B5 8GB TruDDR4 Memory (1Rx4, 1.2V)

46W0792 A5B8 8GB TruDDR4 Memory (2Rx8, 1.2V)

46W0796 A5B7 16GB TruDDR4 Memory (2Rx4, 1.2V)

LRDIMMs - 2133 MHz

46W0800 A5B9 32GB TruDDR4 Memory (4Rx4, 1.2V)

95Y4812 A5UK 64GB TruDDR4 Memory (4Rx4,1.2V)

* Support for 64 GB LRDIMMs is planned for a later date.

Feature
code

Description Maximum

PC4-17000 CL15 2133MHz LP RDIMM

PC4-17000 CL15 2133MHz LP RDIMM

PC4-17000 CL15 2133MHz LP RDIMM

PC4-17000 CL15 2133MHz LP RDIMM

PC417000 CL15 2133MHz LP LRDIMM

PC4-17000 CL15 2133MHz LP LRDIMM

supported

24 (12 per
CPU)

24 (12 per
CPU)

24 (12 per
CPU)

24 (12 per
CPU)

24 (12 per
CPU)

24 (12 per
CPU)

Standard models where
used

-

-

A2x, B2x

62x, C2x, C4x, D2x, F2x,
G2x, H2x, J2x, L2x, M2x

-

-

IBM System x3550 M5 14

Internal storage

The System x3550 M5 server supports the following internal drive bay configurations:

1.

4x 2.5-inch SAS/SATA hot-swap drive bay server models that can be upgraded to 8x 2.5-inch
SAS/SATA hot-swap drive bays

2.

10x 2.5-inch SAS/SATA hot-swap drive bay server models that can be upgraded to 12x 2.5-inch
SAS/SATA hot-swap drive bays (10x front drive bays and 2x rear drive bays)

3.

4x 2.5-inch SATA Simple Swap drive bay server models that can be upgraded to 8x 2.5-inch SATA
Simple Swap drive bays

4.

4x 3.5-inch SAS/SATA hot-swap drive bay server models

5.

4x 3.5-inch SATA Simple Swap drive bay server models

The following figure shows some of these configurations.

Figure 5. Internal drive configurations

Optical drive support: Four- and eight-drive bay models of the x3550 M5 support an optional internal
optical drive.

IBM System x3550 M5 15

The following table shows the internal storage options available for the x3550 M5 server.

Table 7. Internal storage options

Part
number

Base drive kits

None* A59W System x3550 M5 4x 2.5" HS HDD Kit 1 62x, C2x, D2x,

None* A5A4 System x3550 M5 4x 3.5" HS HDD Kit 1 C4x

None* A5A0 System x3550 M5 10x 2.5" HS HDD Kit 1 G2x

None** A59Y System x3550 M5 4x 2.5" SS HDD Kit, Non-Raid 1 -

None** A5A5 System x3550 M5 4x 3.5" SS HDD Kit, Non-Raid 1 -

None* A5A6 System x3550 M5 4x 2.5" SS HDD Kit, HW RAID 1 A2x

None* A5A8 System x3550 M5 4x 3.5" SS HDD Kit, HW RAID 1 B2x

Upgrade drive kits (require the base drive kit)

00KA058 A5A2 System x3550 M5 2x 2.5" HS HDD Rear Kit 1 -

00KA055 A59X System x3550 M5 4x 2.5" HS HDD Kit PLUS 1 -

00KA056 A59Z System x3550 M5 4x 2.5" SS HDD Kit PLUS, Non-Raid 1 -

00KA060 A5A7 System x3550 M5 4x 2.5" SS HDD Kit PLUS, HW RAID 1 -

Feature
code

Description Maximum

supported

Standard models
where used

F2x, H2x, J2x,
L2x, M2x

* Available in standard or CTO models.
** Available in CTO models only.

Base drive kits are always factory installed in either standard or custom (CTO) models. Upgrade drive kits
can be factory installed or can be installed as a field upgrade for supported standard or custom models.

Note: The HDD Rear Kit (00KA058) is installed in place of the PCIe slots 1 and 2 (see the "I/O expansion
options" section), and it includes a special riser that provides PCIe 3.0 x16 slot 3. No other riser cards can
be used when the HDD Rear Kit is installed. The HDD Rear Kit is connected to the SAS expander on the
10-drive backplane.

IBM System x3550 M5 16

The following table lists possible internal storage configurations.

Table 8. Internal storage configurations (FC=Feature Code, PN=Part Number, qty=quantity) (Part 1)

Drive
bay

Drive bay type

qty

Storage controller Drive kits required

2.5-inch SAS/SATA
hot-swap

4 1x M1215; or

8 1x M1215; or

10 1x M1215; or

12 1x M1215; or





1x M5210; or



1x N2215





1x M5210; or



1x N2215





1x M5210; or



1x N2215





1x M5210; or



1x N2215

Factory installed:



1x System x3550 M5 4x 2.5" HS HDD Kit (FC
A59W)

Factory installed:



1x System x3550 M5 4x 2.5" HS HDD Kit (FC
A59W); and



1x System x3550 M5 4x 2.5" HS HDD Kit PLUS
(FC A59X)

Field upgrade for the 4-drive bay model:



1x System x3550 M5 4x 2.5" HS HDD Kit PLUS
(PN 00KA055)

Factory installed:



1x System x3550 M5 10x 2.5" HS HDD Kit (FC
A5A0)

Factory installed:



1x System x3550 M5 10x 2.5" HS HDD Kit (FC
A5A0); and



1x System x3550 M5 2x 2.5" HS HDD Rear Kit (FC
A5A2)

Field upgrade for the 10-drive bay model:



1x System x3550 M5 2x 2.5" HS HDD Rear Kit (PN
00KA058)

IBM System x3550 M5 17

Table 8. Internal storage configurations (FC=Feature Code, PN=Part Number, qty=quantity) (Part 2)

Drive
bay

Drive bay type

2.5-inch SATA Simple
Swap

qty

4

8

Storage controller Drive kits required



Integrated 8-port
6 Gbps SATA
(no RAID support)



1x M1215; or



1x M5210; or



1x N2215



Integrated 8-port
6 Gbps SATA
(no RAID support)

Factory installed:



1x System x3550 M5 4x 2.5" SS HDD Kit,
Non-Raid (FC A59Y)

Factory installed:



1x System x3550 M5 4x 2.5" SS HDD Kit, HW
RAID (FC A5A6)

Factory installed:



1x System x3550 M5 4x 2.5" SS HDD Kit,
Non-Raid (FC A59Y); and



1x System x3550 M5 4x 2.5" SS HDD Kit PLUS,
Non-Raid (FC A59Z)

Field upgrade for the 4-drive bay model:



1x System x3550 M5 4x 2.5" SS HDD Kit PLUS,
Non-Raid (PN 00KA056)



1x M1215; or



1x M5210; or



1x N2215

Factory installed:



1x System x3550 M5 4x 2.5" SS HDD Kit, HW
RAID (FC A5A6); and



1x System x3550 M5 4x 2.5" SS HDD Kit PLUS,
HW RAID (FC A5A7)

3.5-inch SAS/SATA
hot-swap

3.5-inch SATA Simple
Swap

4 1x M1215; or

4





1x M5210; or



1x N2215



Integrated 8-port
6 Gbps SATA
(no RAID support)



1x M1215; or



1x M5210; or



1x N2215

Field upgrade for the 4-drive bay model:



1x System x3550 M5 4x 2.5" SS HDD Kit PLUS,
HW RAID (PN 00KA060)

Factory installed:



1x System x3550 M5 4x 3.5" HS HDD Kit (FC
A5A4)

Factory installed:



1x System x3550 M5 4x 3.5" SS HDD Kit,
Non-Raid (FC A5A5)

Factory installed:



1x System x3550 M5 4x 3.5" SS HDD Kit, HW
RAID (FC A5A8)

IBM System x3550 M5 18

Controllers for internal storage

The following table lists the RAID controllers and the additional options used for the internal storage of the
x3550 M5 server. The controllers are installed into a dedicated PCIe slot.

Table 9. RAID controllers and HBAs for internal storage

Part
number

12 Gb SAS/SATA controllers

46C9110 A3YZ ServeRAID M5210 SAS/SATA Controller 1 62x, D2x, F2x,

46C9114 A45W ServeRAID M1215 SAS/SATA Controller 1 A2x, B2x, C2x,

47C8675 A3YY N2215 SAS/SATA HBA 1 -

Hardware upgrades for the M5210

47C8656 A3Z0 ServeRAID M5200 Series 1GB Cache/RAID 5 Upgrade 1 -

47C8660 A3Z1 ServeRAID M5200 Series 1GB Flash/RAID 5 Upgrade 1 D2x, F2x, G2x,

47C8664 A3Z2 ServeRAID M5200 Series 2GB Flash/RAID 5 Upgrade 1 62x, J2x

47C8668 A3Z3 ServeRAID M5200 Series 4GB Flash/RAID 5 Upgrade 1 -

Features on Demand upgrades for the M5210

47C8708 A3Z6 ServeRAID M5200 Series Zero Cache/RAID 5 Upgrade 1 -

47C8706 A3Z5 ServeRAID M5200 Series RAID 6 Upgrade 1* -

Feature
code

Description Maximum

supported

Standard models
where used

G2x, H2x, J2x,
L2x, M2x

C4x

H2x

47C8710 A3Z7 ServeRAID M5200 Series Performance Accelerator 1* -

47C8712 A3Z8 ServeRAID M5200 Series SSD Caching Enabler 1* -

Features on Demand upgrades for the M1215

00AE930 A5H5 ServeRAID M1200 Zero Cache/RAID 5 Upgrade for IBM

Systems FOD

* Requires cache memory upgrade (47C8656, 47C8660, 47C8664, or 47C8668).

1 -

IBM System x3550 M5 19

The ServeRAID M1215 SAS/SATA Controller has the following specifications:



Eight internal 12 Gbps SAS/SATA ports



Up to 12 Gbps throughput per port



Two internal mini-SAS HD connectors (SFF-8643)



Supports connections to SAS/SATA HDDs and SSDs



LSI SAS3008 12 Gbps RAID on Chip (ROC) controller



Support for RAID levels 0, 1, and 10 standard; support for RAID 5, 50 with optional FoD upgrade



Zero Controller Cache, no battery/flash backup



Optional support for self-encrypting drives (SEDs) with MegaRAID SafeStore (with RAID 5 upgrade)



Fixed stripe size of 64 KB

The ServeRAID M5210 SAS/SATA Controller has the following specifications:



Eight internal 12 Gbps SAS/SATA ports



Up to 12 Gbps throughput per port



Two x4 HD mini-SAS internal connectors (SFF-8643)



Supports connections to SAS/SATA HDDs and SSDs and SAS Expanders



Supports RAID 0, 1, and 10



Supports RAID 5 and 50 with optional M5200 Series RAID 5 upgrades



Supports RAID 6 and 60 with the optional M5200 Series RAID 6 upgrade



Optional support for self-encrypting drives (SEDs) with MegaRAID SafeStore (with RAID 5 upgrade)



Supports 1 GB non-backed cache or 1 GB, 2 GB, or 4 GB flash-backed cache



PCIe 3.0 x8 host interface



Based on the LSI SAS3108 12 Gbps ROC controller

The IBM N2215 SAS/SATA HBA has the following specifications:



Eight internal 12 Gbps SAS/SATA ports



Up to 12 Gbps throughput per port



Two x4 HD mini-SAS internal connectors (SFF-8643)



Supports connections to SAS/SATA HDDs and SSDs



Optimized for SSD performance



No RAID support



PCIe 3.0 x8 host interface



Based on the LSI SAS3008 12 Gbps controller

For more information, see the list of IBM Redbooks® Product Guides in the RAID adapters category:

http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=raid

IBM System x3550 M5 20

Internal drive options

The following table lists hard drive options for internal disk storage of the x3550 M5 server.

Table 10. Drive options for internal disk storage (Part 1)

Part
number

3.5-inch hot-swap HDDs - NL SAS

00FN188 A5VP IBM 2TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e HDD 4

00FN208 A5VQ IBM 4TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e HDD 4

00FN228 A5VR IBM 6TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e HDD 4

3.5-inch hot-swap SEDs - NL SAS

00FN238 A5VS IBM 2TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e SED 4

00FN248 A5VT IBM 4TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e SED 4

00FN258 A5VU IBM 6TB 7.2K 12Gbps NL SAS 3.5" G2HS 512e SED 4

3.5-inch hot-swap HDDs - NL SATA

00FN113 A5VD IBM 2TB 7.2K 6Gbps NL SATA 3.5" G2HS 512e HDD 4

00FN128 A5VF IBM 3TB 7.2K 6Gbps NL SATA 3.5" G2HS 512e HDD 4

00FN143 A5VH IBM 4TB 7.2K 6Gbps NL SATA 3.5" G2HS 512e HDD 4

00FN158 A5VK IBM 5TB 7.2K 6Gbps NL SATA 3.5" G2HS 512e HDD 4

00FN173 A5VM IBM 6TB 7.2K 6Gbps NL SATA 3.5" G2HS 512e HDD 4

3.5-inch simple-swap HDDs - NL SATA

Feature
code

Description Maximum

supported

00FN118 A5VE IBM 2TB 7.2K 6Gbps NL SATA 3.5" G2SS 512e HDD 4

00FN133 A5VG IBM 3TB 7.2K 6Gbps NL SATA 3.5" G2SS 512e HDD 4

00FN148 A5VJ IBM 4TB 7.2K 6Gbps NL SATA 3.5" G2SS 512e HDD 4

00FN163 A5VL IBM 5TB 7.2K 6Gbps NL SATA 3.5" G2SS 512e HDD 4

00FN178 A5VN IBM 6TB 7.2K 6Gbps NL SATA 3.5" G2SS 512e HDD 4

IBM System x3550 M5 21

Table 10. Drive options for internal disk storage (Part 2)

Part
number

2.5-inch hot-swap 10K HDDs - SAS

00AJ096 A4TL IBM 300GB 10K 6Gbps SAS 2.5" G3HS HDD 12

00AJ091 A4TM IBM 600GB 10K 6Gbps SAS 2.5" G3HS HDD 12

00AJ071 A4TN IBM 900GB 10K 6Gbps SAS 2.5" G3HS HDD 12

00AJ146 A4TP IBM 1.2TB 10K 6Gbps SAS 2.5" G3HS HDD 12

2.5-inch hot-swap 15K HDDs - SAS

00AJ081 A4TR IBM 300GB 15K 6Gbps SAS 2.5" G3HS HDD 12

00AJ126 A4TS IBM 600GB 15K 6Gbps SAS 2.5" G3HS HDD 12

2.5-inch hot-swap HDDs - NL SAS

00AJ121 A4TT IBM 500GB 7.2K 6Gbps NL SAS 2.5" G3HS HDD 12

00AJ086 A4TU IBM 1TB 7.2K 6Gbps NL SAS 2.5'' G3HS HDD 12

2.5-inch hot-swap HDDs - NL SATA

00AJ136 A4TW IBM 500GB 7.2K 6Gbps NL SATA 2.5" G3HS HDD 12

00AJ141 A4TX IBM 1TB 7.2K 6Gbps NL SATA 2.5" G3HS HDD 12

2.5" hot-swap SAS SSDs - Enterprise

Feature
code

Description Maximum

supported

00AJ217 A4UC IBM 800GB SAS 2.5" MLC G3HS Enterprise SSD 12

2.5" hot-swap SATA SSDs - Enterprise Value

00AJ161 A4U4 S3700 400GB SATA 2.5" MLC G3HS Enterprise SSD for IBM System x 12

00AJ405 A579 IBM 480GB SATA 2.5" MLC G3HS Enterprise Value SSD 12

00FN347 AS0J IBM 960GB SATA 2.5" MLC G3HS Entry SSD 12

2.5" simple-swap SSDs - Enterprise Value

00FN475 AS5Z IBM 960GB SATA 2.5" MLC G3SS Entry SSD 8

IBM System x3550 M5 22

Internal backup units

The x3550 M5 server does not support internal tape drive options or other internal backup units. However,
it can be attached to the external tape drives using SAS or Fibre Channel connectivity (see Table 30).

Optical drives

The x3550 M5 server supports the optical drive options listed in the following table. Server models with ten

2.5-inch drive bays on the front do not support an internal optical drive; a supported external optical drive
can be used instead.

Table 11. Optical drives

Part
number

00AM066 A5KG Ultraslim 9.5mm SATA DVD-ROM 1 -

00AM067 A5KH Ultraslim 9.5mm SATA Multi Burner 1 -

Feature
code

Description

Maximum
supported

Standard models
where used

Ultraslim 9.5mm SATA DVD-ROM (part number 00AM066) supports the following media and speeds for
reading:



CD-ROM 24X



CD-DA (DAE) 24X



CD-R 24X



CD-RW 24X



DVD-ROM 8X



DVD-R 8X



DVD+R 8X



DVD-R DL 6X



DVD+R DL 8X



DVD-RW 8X



DVD+RW 8X



DVD-RAM (4.7 GB) 5X

Ultraslim 9.5mm SATA Multi Burner (part number 00AM067) supports the same media and speeds for
reading as DVD-ROM (part number 00AM066). This drive also supports the following media and speeds
for writing:



CD-R 24X



CD-RW 4X



High-Speed CD-RW 10X



Ultra Speed CD-RW 24X



DVD-R 8X



DVD+R 8X



DVD-R DL 6X



DVD+R DL 6X



DVD-RW 6X



DVD+RW 8X



DVD-RAM 5X

IBM System x3550 M5 23

I/O expansion options

The x3550 M5 server supports up to four PCIe slots: one on the system planar that is dedicated for an
internal RAID controller and up to three with different riser cards installed into two riser sockets on the
system planar (one riser socket supports the installation of one riser card). The slot form factors are listed:



Slot 1: PCIe 3.0 x16 or ML2; low profile, half-length (not present if the HDD Rear Kit is installed)



Slot 2: PCIe 3.0 x16 or PCIe 3.0 x8; low profile or full-height, half-length (PCIe 3.0 x16 slot requires
the second processor to be installed) (not present if the HDD Rear Kit is installed)



Slot 3: PCIe 3.0 x16 or PCIe 3.0 x8; low profile, half-length



Slot 4: PCIe 3.0 x8 (dedicated for an internal RAID controller)

The locations of the PCIe slots are shown in the following figure.

Figure 6. PCIe slot locations

IBM System x3550 M5 24

Riser 1 supplies slot 1, and riser 2 supplies slots 2 and 3. All standard models have one riser card (Riser

1) installed, which provides one low profile PCIe x16 Gen 3 slot (riser option part number 00KA061). You
can replace the first riser card or add a second riser card with the riser card options that are listed in the
following table (or configure these riser cards to be factory-integrated using special bid or CTO).

Table 12. PCI riser card options

Part
number

Riser 1 (supplies slots 1)

00KA061 A5AG System x3550 M5 PCIe Riser 1 (1x LP x16 CPU0) 1 62x, J2x, A2x, B2x,

00KA063 A5AH System x3550 M5 PCIe Riser 1 (1x ML2 x16 CPU0) 1 -

Riser 2 (supplies slots 2 and 3)

Feature
code

Description

Maximum
supported

Standard models
where used

C2x, C4x, D2x, F2x,
G2x, H2x, L2x, M2x

00KA062 A5AC System x3550 M5 PCIe Riser 2, 1 CPU (2xLP, LP x8

CPU0 + LP x8 CPU0)

None* A5AD System x3550 M5 PCIe Riser 2, 1-2 CPU (FHHL x16

CPU1 + LP x16 CPU0)

None* A5AE System x3550 M5 PCIe Riser 2, 1 CPU (FHHL x8

CPU0 +LP x8 CPU0)

00KA066 A5AF System x3550 M5 PCIe Riser 2, 1-2 CPU (LP x16

CPU1 + LP x16 CPU0)

* Only available via CTO or special bid.

1 -

1 -

1 -

1 -

Note: The HDD Rear Kit (00KA058; see the "Internal storage" section) is installed in place of the PCIe
slots 1 and 2, and it includes a special riser that provides PCIe 3.0 x16 slot 3. No other riser cards can be
used when the HDD Rear Kit is installed.

The x3550 M5 Thermal Kit, part number 00KA059, contains two fans. It provides the seventh and eighth
system fans needed for the following options when only one processor is installed:



Intel X540 ML2 Dual Port 10GbaseT Adapter for IBM System x



QLogic 8200 Dual Port 10GbE SFP+ VFA for IBM System x

The x3550 M5 Thermal Kit is not needed if two processors are installed, because the second processor
includes these fans.

The COM Port Bracket, part number 00KA161, is used for mounting the external serial port on the rear of
the x3550 M5. This option includes the bracket and the cable. The COM Port option is mounted in place
of the PCIe slot 3, and only PCIe slots 1 and 2 remain available.

The following table lists the x3550 M5 Thermal Kit and COM Port Bracket part numbers.

Table 13. Miscellaneous options

Part
number

00KA059 A5AJ System x3550 M5 Thermal Kit 1

00KA161 A5AN COM Port Bracket 1

IBM System x3550 M5 25

Feature
code

Description Maximum

supported

Network adapters

The x3550 M5 supports four integrated Gigabit Ethernet ports.

The integrated network interface controller (NIC) has the following features:



A Broadcom BCM5719 chip



Four Gigabit Ethernet ports



NIC Teaming (load balancing and failover)



Ethernet features:



Compliant with 1 Gb Ethernet IEEE 802.3, 802.3u, and 802.3ab PHY specifications



Integrated PHY for 10/100/1000 Mbps for multispeed, full, and half-duplex auto-negotiation



Automatic MDI crossover



IEEE 802.3x-compliant flow control support



IEEE 1588 protocol and 802.1AS time synchronization implementation



IEEE802.3az - Energy Efficient Ethernet (EEE)



I/O Virtualization features:



I/O Virtualization support for VMware NetQueue and Microsoft virtual machine queue (VMQ)



Function Level Reset (FLR)



IEEE 802.1q Virtual Local Area Network (VLAN) tagging support



Stateless offload and performance features:



TCP, IP, and User Datagram Protocol (UDP) checksum offload



TCP segmentation offload (TCO)



Large Send Offload (LSO)



Receive Side Scaling (RSS) and Transmit Side Scaling (TSS)



Message Signal Interrupt (MSI) and Message Signal Interrupt Extension (MSI-X) support



Support for jumbo frames up to 9600 bytes

Optionally, the x3550 M5 server supports ML2 adapters that are installed in the custom ML2 slot provided
by the PCIe ML2 riser card (part number 00KA063). This slot supports adapters with either two 10 Gb
ports or four Gigabit ports and supports direct connectivity to the IMM2 service processor for out-of-band
systems management.

IBM System x3550 M5 26

The following table lists additional supported network adapters.

Table 14. Network adapters

Part
number

10 Gb Ethernet - ML2

00D2026 A40S Broadcom NetXtreme II ML2 Dual Port 10GbaseT for IBM System x 1

00D2028 A40T Broadcom NetXtreme II ML2 Dual Port 10GbE SFP+ for IBM System x* 1

00D1996 A40Q Emulex VFA5 ML2 Dual Port 10GbE SFP+ Adapter for IBM System x* 1

00D8544 A4NZ Emulex VFA5 ML2 FCoE/iSCSI License for IBM System x (FoD)

00D1994 A40P Intel X540 ML2 Dual Port 10GbaseT Adapter for IBM System x 1

1 Gb Ethernet - ML2

00D1998 A40R Intel I350-T4 ML2 Quad Port GbE Adapter for IBM System x 1

40 Gb Ethernet / FDR InfiniBand - PCIe

00D9550 A3PN Mellanox ConnectX-3 40GbE / FDR IB VPI Adapter for IBM System x* 3

10 Gb Ethernet - PCIe

44T1370 A5GZ Broadcom NetXtreme 2x10GbE BaseT Adapter for IBM System x 3

94Y5180 A4Z6 Broadcom NetXtreme Dual Port 10GbE SFP+ Adapter for IBM System x* 3

49Y7960 A2EC Intel x520 Dual Port 10GbE SFP+ Adapter for IBM System x* 3

Feature
code

Description Maximum

(Features on Demand upgrade for 00D1996 - one for each adapter)

supported

1

00D9690 A3PM Mellanox ConnectX-3 10 GbE Adapter for IBM System x* 3

90Y4600 A3MR QLogic 8200 Dual Port 10GbE SFP+ VFA for IBM System x* 3

00Y5624 A3MT QLogic 8200 VFA FCoE/iSCSI License for IBM System x (FoD)

(Features on Demand upgrade for 90Y4600 - one for each adapter)

1 Gb Ethernet - PCIe

90Y9370 A2V4 Broadcom NetXtreme I Dual Port GbE Adapter for IBM System x 3

90Y9352 A2V3 Broadcom NetXtreme I Quad Port GbE Adapter for IBM System x 3

00AG510 A56L Intel I350-T2 2xGbE BaseT Adapter for IBM System x 3

00AG520 A56M Intel I350-T4 4xGbE BaseT Adapter for IBM System x 3

* SFP+ and QSFP+ based adapters require supported transceivers or DAC cables that must be purchased separately.

3

For more information, see the list of IBM Redbooks Product Guides in the Networking adapters category:

http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=networkadapters

IBM System x3550 M5 27

Storage host bus adapters

The following table lists storage HBAs supported by the x3550 M5 server.

Table 15. Storage adapters

Part
number

Fibre Channel - 16 Gb

81Y1675 A2XV Brocade 16Gb FC Dual-port HBA for IBM System x 3

81Y1668 A2XU Brocade 16Gb FC Single-port HBA for IBM System x 3

81Y1662 A2W6 Emulex 16Gb FC Dual-port HBA for IBM System x 3

81Y1655 A2W5 Emulex 16Gb FC Single-port HBA for IBM System x 3

00Y3337 A3KW QLogic 16Gb FC Single-port HBA for IBM System x 3

00Y3341 A3KX QLogic 16Gb FC Dual-port HBA for IBM System x 3

Fibre Channel - 8 Gb

46M6050 3591 Brocade 8Gb FC Dual-port HBA for IBM System x 3

46M6049 3589 Brocade 8Gb FC Single-port HBA for IBM System x 3

42D0494 3581 Emulex 8Gb FC Dual-port HBA for IBM System x 3

42D0485 3580 Emulex 8Gb FC Single-port HBA for IBM System x 3

42D0510 3579 QLogic 8Gb FC Dual-port HBA for IBM System x 3

42D0501 3578 QLogic 8Gb FC Single-port HBA for IBM System x 3

SAS

Feature
code

Description Maximum

supported

00AE912 A5M0 N2225 SAS/SATA HBA for IBM System x 3

00AE916 A5M1 N2226 SAS/SATA HBA for IBM System x 1

For more information, see the list of IBM Redbooks Product Guides in the Host bus adapters category:

http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=hba

PCIe SSD adapters

Currently, the x3550 M5 server does not support the High IOPS SSD adapters.

IBM System x3550 M5 28

GPU adapters

The x3550 M5 server supports a graphics processing units (GPUs) listed in the following table.

Table 16. GPU adapters

Part
number

None* A3WH NVIDIA Quadro K600 1

* These GPU adapters are available via Special Bid or CTO only.

Feature
code

Description Maximum

supported

If the NVIDIA Quadro K600 is installed, the maximum memory that can be installed is 1 TB.

Power supplies

The x3550 M5 server supports up to two redundant power supplies, and is capable of N+N redundancy
depending on the configuration. Standard models come with one power supply. The following table lists
the power supplies.

Table 17. Power supplies

Part
number

00KA094 A5AX System x 550W High Efficiency Platinum AC

00KA096 A5AY System x 750W High Efficiency Platinum AC

00KA097 A5AZ System x 750W High Efficiency Titanium AC

Feature
code

Description

Power Supply

Power Supply

Power Supply (200-240V)

Maximum
supported

2 A2x, B2x, C2x, C4x,

2 62x, J2x

2 L2x

Standard models
where used

D2x, F2x, G2x, H2x

00KA098 A5B0 System x 900W High Efficiency Platinum AC

Power Supply

General power supply rules are listed:



Minimum of one and maximum of two power supplies per system



If two are installed, power supplies must be identical

550W power supply restrictions



GPUs not supported



120 W, 135 W, and 145 W processors not supported



Maximum eight RDIMMs or four LRDIMMs



Maximum eight drives

750W power supply restrictions



145 W processors:



Maximum 16 RDIMMs or eight LRDIMMs



Other than 145 W processors:



Maximum 12 LRDIMMs



Maximum eight drives

2 M2x

IBM System x3550 M5 29

A power supply ships without a power cable. It must be ordered separately (see the following table).

Table 18. Power cables

Part
number

Rack power cables

39Y7932 6263 12ft Power Cable C13-C14

39Y7937 6201 1.5m, 10A/100-250V, C13 to IEC 320-C14 Rack Power Cable

39Y7938 6204 IEC309 C20 to C13 rack jumper cable

Country-specific power cords

39Y7917 6212 European 10A line C13 to CEE 7/7 (2.8M)

39Y7918 6213 Denmark 10A line C13 to DK2-5A (2.8M)

39Y7919 6216 Switzerland 10A line C13 to SEV 1011 (2.8M)

39Y7920 6218 Israel 10A line C13 to SI 32 (2.8M)

39Y7921 6217 Italy 10A line C13 to CEE 7/7 (2.8M)

39Y7922 6214 South Africa 10A line C13 to SABS 164/1 (2.8M)

39Y7923 6215 United Kingdom 10A line C13 to BS 1363 (2.8M)

39Y7924 6211 Australia/NZ 10A line C13 to SAA-AS C112 (2.8M)

39Y7925 6219 Korea 7A line C13 to KETI 15A/250V (2.8M)

39Y7927 6269 India 6A line C13 to Fig 68 (2.8M)

Feature
code

Description

39Y7928 6210 China 6A line C13 to GB 2099.1 (2.8M)

39Y7929 6223 Brazil 10A line C13 to NBR 6147 (2.8M)

39Y7930 6222 Argentina 10A line C13 to IRAM 2063 (2.8M)

39Y7931 6207 Power Cable - C13 / NEMA 5-15P 14ft

00CG265 A53E Power Cord Taiwan AC plug 10A/250V, 2.8M; OPT

00CG267 A53F Power Cord Taiwan AC plug 15A/125V; 2.8M; OPT

46M2592 A1RF 10A/250V C13 to NEMA 6-15P 2.8m line cord

46M2593 A1RE Japan 10A/100V C13 to JIS C-8303 2.8m line cord

IBM System x3550 M5 30

Integrated virtualization

The server supports VMware ESXi installed on a USB memory key. The key is installed in a USB socket
inside the server. The following table lists the virtualization options.

Table 19. Virtualization options

Part
number

41Y8298 A2G0 IBM Blank USB Memory Key for VMware ESXi Downloads 1

Feature
code

Description Maximum

supported

Systems management

The server contains IBM Integrated Management Module II (IMM2.1), which provides advanced
service-processor control, monitoring, and an alerting function. If an environmental condition exceeds a
threshold or if a system component fails, the IMM lights LEDs to help you diagnose the problem, records
the error in the event log, and alerts you to the problem. Optionally, the IMM also provides a virtual
presence capability for remote server management capabilities.

The IMM provides remote server management through industry-standard interfaces:



Intelligent Platform Management Interface (IPMI) Version 2.0



Simple Network Management Protocol (SNMP) Version 3



Common Information Model (CIM)



Web browser

The optional IBM Integrated Management Module Advanced Upgrade is required to enable the remote
presence and blue-screen capture features. The remote presence feature provides the following
functions:



Remotely viewing video with graphics resolutions up to 1600x1200 at 75 Hz with up to 23 bits per
pixel, regardless of the system state



Remotely accessing the server using the keyboard and mouse from a remote client



Mapping the CD or DVD drive, diskette drive, and USB flash drive on a remote client, and mapping
ISO and diskette image files as virtual drives that are available for use by the server



Uploading a diskette image to the IMM memory and mapping it to the server as a virtual drive

The blue-screen capture feature captures the video display contents before the IMM restarts the server
when the IMM detects an operating system hang condition. A system administrator can use the
blue-screen capture to assist in determining the cause of the hang condition. The following table lists the
remote management option.

Table 20. Remote management option

Part
number

90Y3901 A1ML IBM Integrated Management Module Advanced Upgrade 1

IBM System x3550 M5 31

Feature
code

Description Maximum

supported

All standard models ship with basic light path diagnostics, which include the system LEDs on the front of
the server (See Figure 2) and the LEDs near the monitored components (for example, the DIMM error
LED on the system board). Standard models with 2.5-inch drive bays and the basic light path can be
upgraded to a next-gen light path LCD display panel. The LCD display enables you to have quick access
to system status, firmware, network, and health information. Configure-to-order (CTO) customers can also
elect to have a next-gen ligh path LCD panel for models with 2.5-inch drive bays. The following table
shows the LCD display panel ordering information.

Table 21. Light path diagnostics options

Part
number

00KA054 A5AB System x Advanced LCD Light path Kit 1 -

Feature
code

Description

Maximum
supported

Standard models
where used

The following x3550 M5 Express models have the Advanced LCD Light path Kit standard: E1x, E2x, E3x,
E4x, E5x, E6x, E7x, EAx, EBx, ECx, EDx, EEx, EFx, EHx, EJx, EKx, ELx, ENx, EPx, EQx, ERx, and ESx.

IBM Security Key Lifecycle Manager for System x SEDs - FoD (SKLM - FoD) is an optional feature
available in System x environments that centralizes, simplifies, and automates the data encryption key
management process to help minimize risk and reduce operational costs. SKLM - FoD offers a simple and
robust solution for key storage, key serving, and key lifecycle management for IBM self-encrypting drives
(SEDs) in local and distributed System x environments. With the x3550 M5, the feature on demand (FoD)
upgrade can be configured with the ServeRAID M5210 and M1215 RAID controllers paired with SEDs.
The following table lists SKLM-FoD part numbers.

Table 22. Security Key Lifecycle Manager part numbers

Part
number

United States, Canada, Asia Pacific and Japan

00D9998 A5U1 IBM SKLM for System x w/SEDs - FoD per Install w/1Yr S&S 1

00D9999 AS6C IBM SKLM for System x w/SEDs - FoD per Install w/3Yr S&S 1

Latin America, Europe, Middle East and Africa

Feature
code

Description Maximum

supported

00FP648 A5U1 IBM SKLM for System x w/SEDs - FoD per Install w/1Yr S&S 1

00FP649 AS6C IBM SKLM for System x w/SEDs - FoD per Install w/3Yr S&S 1

IBM System x3550 M5 32

Supported operating systems

The server supports the following operating systems:



Microsoft:



Microsoft Windows Server 2012 R2



Microsoft Windows Server 2012



Microsoft Windows Server 2008 R2



Red Hat:



Red Hat Enterprise Linux 7



Red Hat Enterprise Linux 6 Server x64 Edition (Update 5)



SUSE:



SUSE LINUX Enterprise Server 11 for AMD64/EM64T (SP3)



SUSE LINUX Enterprise Server 11 with Xen for AMD64/EM64T (SP3)



VMware:



VMware vSphere 5.5 (ESXi) (planned for later in 2014)



VMware vSphere 5.1 (ESXi) (Update 2)

See the IBM ServerProven® website for the latest information about the specific versions and service
levels supported and any other prerequisites:

http://www.ibm.com/systems/info/x86servers/serverproven/compat/us/nos/matrix.shtml

Physical and electrical specifications

Dimensions and weight (approximate):



Height: 43 mm (1.7 in)



Width: 429 mm (16.9 in)



Depth: 734 mm (28.9 in)



Weight:



Minimum configuration: 13.8 kg (30.5 lb)



Maximum configuration: 19.3 kg (42.7 lb)

Supported environment:



Air temperature:



Server on: 5 °C to 40 °C (41 °F to 104 °F); altitude: 0 to 950 m (3,117 ft); decrease the maximum
system temperature by 1 °C for every 175-m increase in altitude above 950 m.



Server off: 5 °C to 45 °C (41 °F to 113 °F)



Maximum altitude: 3,050 m (10,000 ft), 5 °C to 28 °C (41 °F to 82 °F)



Shipment: -40 °C to +60 °C (-40 °F to 140 °F) at up to 10,700 m (35,105 ft)



Humidity:



Server on: 8% to 85%, maximum dew point 24 °C, maximum rate of change 5 °C/hr



Server off: 8% to 85%, maximum dew point 27 °C

IBM System x3550 M5 33



Design to ASHRAE Class A3, ambient of 40 °C (104 °F), with relaxed support:



Supports cloud-like workload with no performance degradation acceptable (Turbo-Off).



Under no circumstance can any combination of worst case workload and configuration result in
system shutdown or design exposure at 40 °C.



Electrical:



Models with 900 W power supplies:



100 to 127 (nominal) V ac; 50 Hz or 60 Hz; 10.3 A



200 to 240 (nominal) V ac; 50 Hz or 60 Hz; 5.0 A



Input kilovolt-amperes (kVA) (approximately):



Minimum configuration: 0.14 kVA



Maximum configuration: 1.188 kVA



Models with 750 W power supplies:



100 to 127 (nominal) V ac; 50 Hz or 60 Hz; 8.6 A (not supported by the 750 W Titanium
power supply; it supports 200 - 240 V only)



200 to 240 (nominal) V ac; 50 Hz or 60 Hz; 4.2 A



Input kilovolt-amperes (kVA) (approximately):



Minimum configuration: 0.14 kVA



Maximum configuration: 0.994 kVA



Models with 550 W power supplies:



100 to 127 (nominal) V ac; 50 Hz or 60 Hz; 6.5 A



200 to 240 (nominal) V ac; 50 Hz or 60 Hz; 3.3 A



Input kilovolt-amperes (kVA) (approximately):



Minimum configuration: 0.14 kVA



Maximum configuration: 0.725 kVA



BTU output:



Minimum configuration: 461 Btu/hr (135 watts)



Maximum configuration: 4043 Btu/hr (1185 watts)



Noise level:



6.6 bels (operating)



6.4 bels (idle)

Warranty options

The System x3550 M5 has a three-year onsite warranty with 9x5/next business day (NBD) terms. IBM
offers the warranty service upgrades through IBM ServicePac options, discussed in this section. The IBM
ServicePac is a series of prepackaged warranty maintenance upgrades and post-warranty maintenance
agreements with a well-defined scope of services, including service hours, response time, term of service,
and service agreement terms and conditions.

IBM ServicePac offerings are country-specific, that is, each country might have its own service types,
service levels, response times, and terms and conditions. Not all covered types of ServicePacs might be
available in a particular country. For more information about IBM ServicePac offerings available in your
country, visit the IBM ServicePac Product Selector at this website:

https://www-304.ibm.com/sales/gss/download/spst/servicepac

IBM System x3550 M5 34

The following table explains warranty service definitions in more detail.

Table 23. Warranty service definitions

Term Description

IBM onsite
repair (IOR)

24x7x2 hour A service technician is scheduled to arrive at your client’s location within two hours after remote

24x7x4 hour A service technician is scheduled to arrive at your client’s location within four hours after remote

9x5x4 hour A service technician is scheduled to arrive at your client’s location within four business hours after

9x5 next
business day

A service technician will come to the server's location for equipment repair.

problem determination is completed. We provide service around the clock, every day, including IBM
holidays.

problem determination is completed. We provide service around the clock, every day, including IBM
holidays.

remote problem determination is completed. We provide service from 8:00 a.m. to 5:00 p.m. in the
client's local time zone, Monday through Friday, excluding IBM holidays. If after 1:00 p.m., it is
determined that onsite service is required, the client can expect the service technician to arrive the
morning of the following business day. For noncritical service requests, a service technician will
arrive by the end of the following business day.

A service technician is scheduled to arrive at your client’s location on the business day after we
receive your call, following remote problem determination. We provide service from
8:00 a.m. to 5:00 p.m. in the client's local time zone, Monday through Friday, excluding IBM
holidays.

In general, the types of IBM ServicePacs are listed:



Warranty and maintenance service upgrades:



One, two, three, four, or five years of 9x5 or 24x7 service coverage



Onsite repair from next business day to 4 or 2 hours



One or two years of warranty extension



Remote technical support services:



One or three years with 24x7 coverage (severity 1) or 9x5/next business day for all severities



Installation and startup support for System x servers



Remote technical support for System x servers



Software support - Support Line:



Microsoft or Linux software



VMware



IBM Systems Director

IBM System x3550 M5 35

Regulatory compliance

The server conforms to the following regulations:



FCC - Verified to comply with Part 15 of the FCC Rules, Class A



Canada ICES-003, issue 5, Class A



UL/IEC 60950-1



CSA C22.2 No. 60950-1



NOM-019



Argentina IEC60950-1



Japan VCCI, Class A



Australia/New Zealand AS/NZS CISPR 22, Class A; AS/NZS 60950.1



China CCC GB4943.1, GB9254 Class A, GB17625.1



Taiwan BSMI CNS13438, Class A; CNS14336-1



Korea KN22, Class A; KN24



Russia, Belorussia and Kazakhstan, TR CU 020/2011 (for EMC) and TR CU 004/2011 (for safety)



IEC 60950-1 (CB Certificate and CB Test Report)



CE Mark (EN55022 Class A, EN60950-1, EN55024, EN61000-3-2, EN61000-3-3)



CISPR 22, Class A



TUV-GS (EN60950-1/IEC60950-1,EK1-ITB2000)

External disk storage expansion

The server supports attachment to external storage expansion enclosures, such as the EXP2500 series,
by using the ServeRAID M5225 SAS/SATA Controller. The server can also be attached to supported
external storage systems, such as the IBM System Storage® DS3500 series, using the supported HBAs.
The following table shows the RAID controllers and options.

Table 24. RAID controllers and options for external disk storage expansion

Part number Feature

code

12 Gb RAID controllers

00AE938 A5ND ServeRAID M5225-2GB SAS/SATA Controller 4 -

Feature on Demand (FoD) upgrades for the M5225

47C8706 A3Z5 ServeRAID M5200 Series RAID 6 Upgrade 1* -

47C8710 A3Z7 ServeRAID M5200 Series Performance Accelerator 1* -

47C8712 A3Z8 ServeRAID M5200 Series SSD Caching Enabler 1* -

Description Maximum

supported

Standard models
where used

IBM System x3550 M5 36

The ServeRAID M5225 SAS/SATA Controller has the following specifications:



Eight external 12 Gbps SAS/SATA ports



Supports 12, 6, and 3 Gbps SAS and 6 and 3 Gbps SATA data transfer rates



Two external x4 mini-SAS HD connectors (SFF-8644)



Supports 2 GB flash-backed cache (standard)



Supports RAID levels 0, 1, 5, 10, and 50 (standard)



Supports RAID 6 and 60 with the optional M5200 Series RAID 6 Upgrade



Supports optional M5200 Series Performance Accelerator and SSD Caching upgrades



PCIe x8 Gen 3 host interface



Based on the LSI SAS3108 12 Gbps ROC controller



Supports connectivity to the EXP2512 and EXP2524 storage expansion enclosures

The ServeRAID M5225 SAS/SATA Controller supports connectivity to the IBM System Storage external
expansion enclosures listed in the following table. Up to nine expansion enclosures can be daisy-chained
per one M5225 external port. For better performance, distribute expansion enclosures evenly across both
M5225 ports.

Table 25. IBM System Storage external expansion enclosures

Part number Description Maximum quantity supported per

one M5210

174712X IBM System Storage EXP2512 Express 18

174724X IBM System Storage EXP2524 Express 9

The external SAS cables listed in the following table support connectivity between external expansion
enclosures and the ServeRAID M5225 SAS/SATA Controller.

Table 26. External SAS cables for external storage expansion enclosures

Part number Description Maximum quantity supported per

one enclosure

Server to Expansion enclosure connectivity (Mini-SAS HD x4 to Mini-SAS x4)

00Y2459 0.6m SAS Cable (mSAS HD to mSAS) 1

00Y2461 1.5m SAS Cable (mSAS HD to mSAS) 1

00Y2463 3m SAS Cable (mSAS HD to mSAS) 1

90Y7682 External Expansion Cable - 6M SAS Cable - HD SAS to

Mini SAS

Expansion enclosure to Expansion enclosure connectivity (Mini-SAS x4 to Mini-SAS x4)

39R6529 IBM 1 m SAS Cable 1

39R6531 IBM 3 m SAS Cable 1

1

IBM System x3550 M5 37

The following table lists the drives supported by EXP2512 external expansion enclosures.

Table 27. Drive options for EXP2512 external expansion enclosures

Part number Description Maximum quantity supported per

one enclosure

3.5" NL SAS HS HDDs

49Y1903 1TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12

49Y1902 2TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12

90Y8720 3TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12

46W0975 4TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12

3.5" SAS HS HDDs

49Y1899 300GB 15,000 rpm 6Gb SAS 3.5" HDD 12

49Y1900 450GB 15,000 rpm 6Gb SAS 3.5" HDD 12

49Y1901 600GB 15,000 rpm 6Gb SAS 3.5" HDD 12

The following table lists the hard disk drives supported by EXP2524 external expansion enclosures.

Table 28. Drive options for EXP2524 external expansion enclosures

Part number Description Maximum quantity supported per

one enclosure

2.5" NL SAS HS HDDs

49Y1898 500GB 7,200 rpm 6Gb SAS NL 2.5" HDD 24

81Y9952 1TB 7,200 rpm 6Gb SAS NL 2.5" HDD 24

2.5" SAS HS HDDs

49Y1896 146GB 15,000 rpm 6Gb SAS 2.5" HDD 24

81Y9944 300GB 15,000 rpm 6Gb SAS 2.5" HDD 24

00W1595 600GB 10,000 rpm 6Gb SAS 2.5" HDD 24

46W0970 900GB 10,000 rpm 6Gb SAS 2.5" HDD 24

46W0980 1.2TB 10,000 rpm 6Gb SAS 2.5" HDD 24

2.5" SAS HS SSDs

49Y6072 200GB 6Gb SAS 2.5" SSD 24

49Y6077 400GB 6Gb SAS 2.5" SSD 24

IBM System x3550 M5 38

External disk storage systems

The following table lists the external storage systems that are supported by the server and that can be
ordered through System x sales channel. The server might support other IBM disk systems that are not
listed in this table. Refer to the IBM System Storage Interoperation Center for further information:

http

://www.ibm.com/systems/support/storage/ssic

Table 29. External disk storage systems

Part number Description

1746A2D IBM System Storage DS3512 Express Dual Controller Storage System

1746A2S IBM System Storage DS3512 Express Single Controller Storage System

1746A4D IBM System Storage DS3524 Express Dual Controller Storage System

1746A4S IBM System Storage DS3524 Express Single Controller Storage System

181494H IBM System Storage DS3950 Model 94

181498H IBM System Storage DS3950 Model 98

2071CU2 IBM Storwize® V3500 LFF Dual Control Enclosure

2071CU3 IBM Storwize V3500 SFF Dual Control Enclosure

2072L2C IBM Storwize V3700 LFF Dual Control Enclosure

2072S2C IBM Storwize V3700 SFF Dual Control Enclosure

For more information, see the list of IBM Redbooks Product Guides in the System Storage category:

http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=externalstorage

IBM System x3550 M5 39

External backup units

The server supports the external backup attachment options listed in the following table.

Table 30. External backup options

Part number Description

External tape expansion enclosures for internal tape drives

87651UX 1U Tape Drive Enclosure

87651NX 1U Tape Drive Enclosure (with Nema 5-15P LineCord)

Tape enclosure adapters (with cables)

44E8869 USB Enclosure Adapter Kit

Internal backup drives supported by external tape enclosures

00D2786 IBM RDX Internal USB 3.0 Dock with 320GB Cartridge

00D2787 IBM RDX Internal USB 3.0 Dock with 500GB Cartridge

00D2788 IBM RDX Internal USB 3.0 Dock with 1TB Cartridge

External backup units*

362532Y IBM RDX External USB 3.0 Dock with 320GB Cartridge

362550Y IBM RDX External USB 3.0 Dock with 500GB Cartridge

36251TY IBM RDX External USB 3.0 Dock with 1TB Cartridge

* The external tape drives listed can be ordered through the IBM System x sales channel. The server might support
other IBM tape drives that are not listed in this table. Refer to the IBM System Storage Interoperation Center for
further information.

For more information, see the list of IBM Redbooks Product Guides in the Backup units category:

http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=tape

IBM System x3550 M5 40

Top-of-rack Ethernet switches

The server supports the top-of-rack Ethernet switches from IBM System Networking listed in the following
table.

Table 31. IBM System Networking - Top-of-rack switches

Part number Description

IBM System Networking - 1 Gb top-of-rack switches

7309BAX IBM System Networking RackSwitch™ G7028

7309CAX IBM System Networking RackSwitch G7052

0446013 IBM System Networking RackSwitch G8000R

7309CFC IBM System Networking RackSwitch G8000F

7309G52 IBM System Networking RackSwitch G8052R

730952F IBM System Networking RackSwitch G8052F

IBM System Networking - 10 Gb top-of-rack switches

7309DRX IBM System Networking RackSwitch G8264CS (Rear to Front)

7309DFX IBM System Networking RackSwitch G8264CS (Front to Rear)

7309BR6 IBM System Networking RackSwitch G8124ER

7309BF7 IBM System Networking RackSwitch G8124EF

7309G64 IBM System Networking RackSwitch G8264R

730964F IBM System Networking RackSwitch G8264F

7309CR9 IBM System Networking RackSwitch G8264TR

7309CF9 IBM System Networking RackSwitch G8264TF

IBM System Networking - 40 Gb top-of-rack switches

8036BRX IBM System Networking RackSwitch G8332 (Rear to Front)

8036BFX IBM System Networking RackSwitch G8332 (Front to Rear)

8036ARX IBM System Networking RackSwitch G8316R

8036AFX IBM System Networking RackSwitch G8316F

For more information, see the list of IBM Redbooks Product Guides in the Top-of-rack switches category:

http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=tor

IBM System x3550 M5 41

Uninterruptible power supply units

The server supports attachments to the uninterruptible power supply (UPS) units listed in the following
table.

Table 32. Uninterruptible power supply units

Part number Description

Rack-mounted UPS

53951AX IBM 1500VA LCD 2U Rack UPS (100V/120V)

53951KX IBM 1500VA LCD 2U Rack UPS (230V)

53952AX IBM 2200VA LCD 2U Rack UPS (100V/120V)

53952KX IBM 2200VA LCD 2U Rack UPS (230V)

53953AX IBM 3000VA LCD 3U Rack UPS (100 V/120 V)

53953JX IBM 3000VA LCD 3U Rack UPS (200 V/208 V)

53956AX IBM 6000VA LCD 4U Rack UPS (200 V/208 V)

53956KX IBM 6000VA LCD 4U Rack UPS (230 V)

53959KX IBM 11000VA LCD 5U Rack UPS (200V/208V/230V)

24195KX IBM UPS5000

21303RX IBM UPS 7500XHV

21304RX IBM UPS 10000XHV

For more information, see the list of IBM Redbooks Product Guides in the Power infrastructure category:

http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=power

IBM System x3550 M5 42

Power distribution units

The server supports attachments to the power distribution units (PDUs) listed in the following table.

Table 33. Power distribution units (part 1)

Part number Description

Switched and Monitored PDUs

46M4002 IBM 1U 9 C19/3 C13 Active Energy Manager DPI PDU

46M4003 IBM 1U 9 C19/3 C13 Active Energy Manager 60A 3 Phase PDU

46M4004 IBM 1U 12 C13 Active Energy Manager DPI PDU

46M4005 IBM 1U 12 C13 Active Energy Manager 60A 3 Phase PDU

46M4167 IBM 1U 9 C19/3 C13 Switched and Monitored 30A 3 Phase PDU

46M4116 IBM 0U 24 C13 Switched and Monitored 30A PDU

46M4119 IBM 0U 24 C13 Switched and Monitored 32A PDU

46M4134 IBM 0U 12 C19/12 C13 Switched and Monitored 50A 3 Phase PDU

46M4137 IBM 0U 12 C19/12 C13 Switched and Monitored 32A 3 Phase PDU

Enterprise PDUs

71762MX IBM Ultra Density Enterprise PDU C19 PDU+ (WW)

71762NX IBM Ultra Density Enterprise PDU C19 PDU (WW)

71763MU IBM Ultra Density Enterprise PDU C19 3 Phase 60A PDU+ (NA)

71763NU IBM Ultra Density Enterprise PDU C19 3 Phase 60A PDU (NA)

39M2816 IBM DPI C13 Enterprise PDU without linecord

39Y8923 DPI 60A Three Phase C19 Enterprise PDU with IEC309 3P+G (208 V) fixed line cord

39Y8941 DPI Single Phase C13 Enterprise PDU without line cord

39Y8948 DPI Single Phase C19 Enterprise PDU without line cord

Front-end PDUs

39Y8934 DPI 32 amp/250 V Front-end PDU with IEC 309 2P+Gnd connector

39Y8935 DPI 63amp/250 V Front-end PDU with IEC 309 2P+Gnd connector

39Y8938 30 amp/125 V Front-end PDU with NEMA L5-30P connector

39Y8939 30 amp/250 V Front-end PDU with NEMA L6-30P connector

39Y8940 60 amp/250 V Front-end PDU with IEC 309 60A 2P+N+Gnd connector

IBM System x3550 M5 43

Table 33. Power distribution units (part 2)

Part number Description

Universal PDUs

39Y8951 DPI Universal Rack PDU with US LV and HV line cords

39Y8952 DPI Universal Rack PDU with CEE7-VII Europe LC

39Y8953 DPI Universal Rack PDU with Denmark LC

39Y8954 DPI Universal Rack PDU with Israel LC

39Y8955 DPI Universal Rack PDU with Italy LC

39Y8956 DPI Universal Rack PDU with South Africa LC

39Y8957 DPI Universal Rack PDU with UK LC

39Y8958 DPI Universal Rack PDU with AS/NZ LC

39Y8959 DPI Universal Rack PDU with China LC

39Y8962 DPI Universal Rack PDU (Argentina)

39Y8960 DPI Universal Rack PDU (Brazil)

39Y8961 DPI Universal Rack PDU (India)

0U Basic PDUs

46M4122 IBM 0U 24 C13 16A 3 Phase PDU

46M4125 IBM 0U 24 C13 30A 3 Phase PDU

46M4128 IBM 0U 24 C13 30A PDU

46M4131 IBM 0U 24 C13 32A PDU

46M4140 IBM 0U 12 C19/12 C13 60A 3 Phase PDU

46M4143 IBM 0U 12 C19/12 C13 32A 3 Phase PDU

For more information, see the list of IBM Redbooks Product Guides in the Power infrastructure category:

http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=power

IBM System x3550 M5 44

Rack cabinets

The server supports the rack cabinets listed in the following table.

Table 34. Rack cabinets

Part number Description

201886X IBM 11U Office Enablement Kit

93072RX IBM 25U Standard Rack

93072PX IBM 25U Static S2 Standard Rack

93634EX IBM 42U 1100mm Dynamic Expansion Rack

93634PX IBM 42U 1100mm Dynamic Rack

93604EX IBM 42U 1200mm Deep Dynamic Expansion Rack

93604PX IBM 42U 1200mm Deep Dynamic Rack

93614EX IBM 42U 1200mm Deep Static Expansion Rack

93614PX IBM 42U 1200mm Deep Static Rack

93084EX IBM 42U Enterprise Expansion Rack

93084PX IBM 42U Enterprise Rack

93074RX IBM 42U Standard Rack

93074XX IBM 42U Standard Rack Extension

93624EX IBM 47U 1200mm Deep Static Expansion Rack

93624PX IBM 47U 1200mm Deep Static Rack

93634BX

93634DX IBM PureFlex System 42U Expansion Rack

93634AX IBM PureFlex System 42U Rack

93634CX IBM PureFlex System 42U Rack

IBM PureFlex® System 42U Expansion Rack

For more information, see the list of IBM Redbooks Product Guides in the Rack cabinets and options
category:

http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=rack

IBM System x3550 M5 45

Rack options

The server supports the rack options listed in the following table.

Table 35. Rack options

Part number Feature code Description

Miscellaneous options for the x3550 M5

00KA606 A5AK System x3550 M5 Slide Kit G4 (included with the server)

00KA607 A5AL System x Enterprise 1U Cable Management Arm (CMA)

00KA500 A5FW System x Gen-II Universal Slides Kit

00KA162 A5AP Lockable Front Bezel

Monitor kits and keyboard trays

17238BX 1723HC1 fc A3EK IBM 1U 18.5" Standard Console

17238EX 1723HC1 fc A3EL IBM 1U 18.5" Enhanced Media Console

Console switches

1754D2X 1754HC2 fc 6695 IBM Global 4x2x32 Console Manager (GCM32)

1754D1X 1754HC1 fc 6694 IBM Global 2x2x16 Console Manager (GCM16)

1754A2X 1754HC4 fc 0726 IBM Local 2x16 Console Manager (LCM16)

1754A1X 1754HC3 fc 0725 IBM Local 1x8 Console Manager (LCM8)

Console cables

43V6147 3757 IBM Single Cable USB Conversion Option (UCO)

39M2895 3756 IBM USB Conversion Option (4 Pack UCO)

46M5383 5341 IBM Virtual Media Conversion Option Gen2 (VCO2)

46M5382 5340 IBM Serial Conversion Option (SCO)

Universal management gateway and cables

3858D3X 3858HC1 fc A4X1 Avocent Universal Management Gateway 6000 for IBM

00AK142 A4X4 UM KVM Module VGA+SD Dual RJ45

For more information, see the list of IBM Redbooks Product Guides in the Rack cabinets and options
category:

http://www.redbooks.ibm.com/portals/systemx?Open&page=pg&cat=rack

IBM System x3550 M5 46

IBM Global Financing

IBM Global Financing can help you obtain the IT solution you need while preserving funding for other
strategic investments and optimizing cash flow. Our Fair Market Value (FMV) lease helps ensure that you
have the latest IBM technology and with our mid-lease upgrade capability, you can increase the capacity
of the system with little to no change in monthly payments. At the end of the lease, take advantage of our
flexible end-of-lease options to fit your changing business needs. IBM Global Financing has the breadth
and depth of offerings, longevity, proven success and global reach to help you develop a robust financing
and asset management strategy that provides you the opportunity to use new technologies and turn your
ambitious vision into a tangible solution.

Here are more reasons why working with us makes solid financial sense:



Expand your purchasing power: Affordable monthly payments allow you to change the technology
acquisition discussion from “what can I afford right now” to “what solution is really right for my
business.” IBM Global Financing allows you to expand your purchase power to get you the right
solution.



Accelerate your project’s cash flow break-even point: Acquire your IBM technology today and begin to
realize its benefits now. An FMV lease can help you get the solution you need now, with low monthly
payments that better align upfront costs with the anticipated return on investment from the technology.



Easy to acquire with affordable rates: We offer one-stop shopping for a total IT solution, so you can
acquire IBM hardware, software, services, and the financing you need — from one IT provider.

Plus, we provide simple, easy-to-understand contracts and quick approvals. As the world’s largest IT
financing provider, with an asset base of US$35.8 billion and over 125,000 clients, IBM Global Financing
offers highly competitive rates that promote low total cost of ownership and low monthly payments.

IBM Global Financing operates in more than 50 countries. Go to http://ibm.com/financing for financing
options in your country and to contact a local financing specialist.

IBM Global Financing offerings are provided through IBM Credit LLC in the United States and other IBM
subsidiaries and divisions worldwide to qualified commercial and government clients. Rates and
availability are subject to the client’s credit rating, financing terms, offering type, equipment, and product
type and options, and may vary by country. Non-hardware items must be one-time, non-recurring charges
and are financed by means of loans. Other restrictions may apply. Rates and offerings are subject to
change, extension or withdrawal without notice, and may not be available in all countries. Contact your
local IBM Global Financing representative for additional details.

IBM System x3550 M5 47

Related publications and links

_

For more information, see these resources:



IBM System x3550 M5 product page

http://www.ibm.com/systems/x/hardware/rack/x3550m5/index.html



IBM US Announcement Letter - September 9, 2014

http://ibm.com/common/ssi/cgi-bin/ssialias?infotype=dd&subtype=ca&&htmlfid=897/ENUS114-141



ServerProven hardware compatibility page for the x3550 M5

http://www.ibm.com/systems/info/x86servers/serverproven/compat/us/xseries/5463.html



IBM Redbooks Product Guides for IBM System x servers and options

http://www.redbooks.ibm.com/portals/systemx?Open&page=pgbycat



Configuration and Option Guide

http://www.ibm.com/systems/xbc/cog/



xRef - IBM System x Reference Sheets

http://www.redbooks.ibm.com/xref



IBM System x Support Portal

http://ibm.com/support/entry/portal/
http://ibm.com/support/entry/portal/Downloads/Hardware/Systems/System



IBM System Storage Interoperation Center

http://www.ibm.com/systems/support/storage/ssic

x/System_x3550_M5

IBM System x3550 M5 48

Notices

This information was developed for products and services offered in the U.S.A.

IBM may not offer the products, services, or features discussed in this document in other countries. Consult your local
IBM representative for information on the products and services currently available in your area. Any reference to an
IBM product, program, or service is not intended to state or imply that only that IBM product, program, or service may
be used. Any functionally equivalent product, program, or service that does not infringe any IBM intellectual property
right may be used instead. However, it is the user's responsibility to evaluate and verify the operation of any non-IBM
product, program, or service. IBM may have patents or pending patent applications covering subject matter described
in this document. The furnishing of this document does not give you any license to these patents. You can send
license inquiries, in writing, to:

IBM Director of Licensing, IBM Corporation, North Castle Drive, Armonk, NY 10504-1785 U.S.A.

The following paragraph does not apply to the United Kingdom or any other country where such provisions are
inconsistent with local law : INTERNATIONAL BUSINESS MACHINES CORPORATION PROVIDES THIS
PUBLICATION "AS IS" WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT
NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. Some states do not allow disclaimer of express or implied warranties in certain
transactions, therefore, this statement may not apply to you. This information could include technical inaccuracies or
typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in
new editions of the publication. IBM may make improvements and/or changes in the product(s) and/or the program(s)
described in this publication at any time without notice.

Any references in this information to non-IBM Web sites are provided for convenience only and do not in any manner
serve as an endorsement of those Web sites. The materials at those Web sites are not part of the materials for this
IBM product and use of those Web sites is at your own risk.IBM may use or distribute any of the information you
supply in any way it believes appropriate without incurring any obligation to you. Information concerning non-IBM
products was obtained from the suppliers of those products, their published announcements or other publicly available
sources. IBM has not tested those products and cannot confirm the accuracy of performance, compatibility or any
other claims related to non-IBM products. Questions on the capabilities of non-IBM products should be addressed to
the suppliers of those products. This information contains examples of data and reports used in daily business
operations. To illustrate them as completely as possible, the examples include the names of individuals, companies,
brands, and products. All of these names are fictitious and any similarity to the names and addresses used by an
actual business enterprise is entirely coincidental.

Any performance data contained herein was determined in a controlled environment. Therefore, the results obtained
in other operating environments may vary significantly. Some measurements may have been made on
development-level systems and there is no guarantee that these measurements will be the same on generally
available systems. Furthermore, some measurement may have been estimated through extrapolation. Actual results
may vary. Users of this document should verify the applicable data for their specific environment.

COPYRIGHT LICENSE:

This information contains sample application programs in source language, which illustrate programming techniques
on various operating platforms. You may copy, modify, and distribute these sample programs in any form without
payment to IBM, for the purposes of developing, using, marketing or distributing application programs conforming to
the application programming interface for the operating platform for which the sample programs are written. These
examples have not been thoroughly tested under all conditions. IBM, therefore, cannot guarantee or imply reliability,
serviceability, or function of these programs.

© Copyright International Business Machines Corporation 2014. All rights reserved.
Note to U.S. Government Users Restricted Rights -- Use, duplication or disclosure restricted by
GSA ADP Schedule Contract with IBM Corp.

IBM System x3550 M5 49

This document was created or updated on September 5, 2014.

Send us your comments in one of the following ways:



Use the online Contact us review form found at:

ibm.com/redbooks



Send your comments in an e-mail to:

[e-mail]



Mail your comments to:
IBM Corporation, International Technical Support Organization
Dept. HYTD Mail Station P099
2455 South Road
Poughkeepsie, NY 12601-5400 U.S.A.

This document is available online at http://www.ibm.com/redbooks/abstracts/tips1194.html .

Trademarks

IBM, the IBM logo, and ibm.com are trademarks or registered trademarks of International Business
Machines Corporation in the United States, other countries, or both. These and other IBM trademarked
terms are marked on their first occurrence in this information with the appropriate symbol (® or ™),
indicating US registered or common law trademarks owned by IBM at the time this information was
published. Such trademarks may also be registered or common law trademarks in other countries. A
current list of IBM trademarks is available on the Web at http://www.ibm.com/legal/copytrade.shtml.

The following terms are trademarks of the International Business Machines Corporation in the United
States, other countries, or both:

Calibrated Vectored Cooling™
IBM®
IBM Systems Director Active Energy Manager™
PureFlex®
RackSwitch™
Redbooks®
Redbooks (logo)®
ServerProven®
ServicePac®
Storwize®
System Storage®
System x®

The following terms are trademarks of other companies:

Intel, Intel Xeon, Intel logo, Intel Inside logo, and Intel Centrino logo are trademarks or registered
trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

Linux is a trademark of Linus Torvalds in the United States, other countries, or both.

Microsoft, Windows, and the Windows logo are trademarks of Microsoft Corporation in the United States,
other countries, or both.

Other company, product, or service names may be trademarks or service marks of others.

IBM System x3550 M5 50
