Broadcom NetXtreme Gigabit Ethernet Adapters

Product Guide

The Broadcom NetXtreme Gigabit Ethernet Adapters are a family of high performance PCI Express
adapters. The adapters are available with either two ports or four ports and are supported on ThinkSystem
and System x servers.

Figure 1 shows the Broadcom NetXtreme I Quad Port GbE Adapter.

Figure 1. Broadcom NetXtreme I Quad Port GbE Adapter

Did you know?

The NetXtreme Quad Port Ethernet Adapter is an ideal way to implement a virtualization solution using your
existing Gigabit Ethernet network. With four copper-based Gigabit ports on a single PCI Express 2.0 x4
interface, the adapter provides the density and capacity you need to support large numbers of virtualized
systems on one server.

Click here to check for updates

Broadcom NetXtreme Gigabit Ethernet Adapters 1

Part number information

The following table lists the ordering information for the adapters.

Table 1. Ordering information

Part
number

Feature
code Description

ThinkSystem options

7ZT7A00482 AUZX Lenovo ThinkSystem NetXtreme PCIe 1Gb 2-Port RJ45 Ethernet Adapter By

Broadcom

7ZT7A00484 AUZV Lenovo ThinkSystem NetXtreme PCIe 1Gb 4-Port RJ45 Ethernet Adapter By

Broadcom

System x options

90Y9370 A2V4 Broadcom NetXtreme I Dual Port GbE Adapter

90Y9352 A2V3 Broadcom NetXtreme I Quad Port GbE Adapter

42C1780* 2995 Broadcom NetXtreme 2xGbE BaseT Adapter

39Y6066* 1485 Broadcom NetXtreme 1xGbE BaseT Adapter

* Withdrawn from marketing

The part numbers for the adapters include the following items:

One Ethernet adapter with full-height (4.75-inch) bracket

Low profile (3.13-inch) bracket

Documentation flyer

Features and specifications

The adapters have the following features:

One, two, or four 10/100/1000 copper ports with RJ45 for Cat 5e/6 cabling

Full line-rate performance across all ports

Low-profile form factor - supported by the majority of System x and iDataPlex servers

PCI Express 2.0 host interface (39Y6066 is PCI Express 1.1)

Jumbo Frames support (9600 bytes frames)

IEEE 802.1q VLAN support - provides enhanced network management and efficiency

I/O virtualization (IOV) support for VMWare NetQueue and Microsoft VMQ - improves network
performance in virtualized environments

IEEE 802.3x flow control support

Receive and transmit side scaling

TCP, IP, and UDP checksum offload

Message Signaled Interrupts (MSI) and MSI-X support - Maximizes server processing performance
by reducing CPU overhead and lowering interrupt latency

On-chip temperature monitor (NetXteme I only)

IEEE 802.3az Energy Efficient Ethernet (EEE) compliant - Reduces adapter power consumption by
up to 42% through intelligent adaptive power management, adjusting power based on data traffic
load. (NetXtreme I only)

IEEE 802.3z (Clause 30) - Statistics for SNMP MIB II, Ethernet like MIB, and Ethernet MIB

Broadcom NetXtreme Gigabit Ethernet Adapters 2

(NetXtreme I only)

IEEE 1588 Precision Time Control and 802.1AS time synchronization support - Provides greater
accuracy of data packet delivery within the network (NetXtreme I only)

Management using Broadcom Advanced Control Suite (BACS), Windows Management
Instrumentation (WMI), and Broadcom Management API (BMAPI)

The following table compares the features of the cards.

Table 2. Features

ThinkSystem
4-port

ThinkSystem
2-port

NetXtreme I
quad-port

NetXtreme I
dual-port

NetXtreme
2xGbE*

NetXtreme
1xGbE*

Part number 7ZT7A00484 7ZT7A00482 90Y9352 90Y9370 42C1780 39Y6066

Chipset BCM5719 BCM5720 BCM5719 BCM5720 BCM5709C BCM5708C

RJ45 connectors 4 2 4 2 2 1

Host interface PCIe 2.0 PCIe 2.0 PCIe 2.0 PCIe 2.0 PCIe 2.0 PCIe 1.1

PCIe Lanes x4 x1 x4 x1 x4 x4

TOE support No No No No Yes

(both ports)

Yes

iSCSI offload No (SW

Initiator)

No (SW
Initiator)

No (SW
Initiator)

No (SW
Initiator)

Yes No (SW

Initiator)

Stateless offloads Yes Yes Yes Yes Yes Yes

Jumbo Frames Yes Yes Yes Yes Yes Yes

IEEE 802.1Q VLAN support Yes Yes Yes Yes Yes Yes

PXE Boot Yes Yes Yes Yes Yes Yes

iSCSI Boot Yes Yes Yes Yes Yes Yes

NIC Teaming Yes Yes Yes Yes Yes Yes

On-chip temperature
monitor

Yes Yes Yes Yes No No

IEEE 802.3az (Energy
Efficient Ethernet, EEE)

Yes Yes Yes Yes No No

IEEE 1588/802.1AS
(Precision Time Protocol,
PTP)

Yes Yes Yes Yes No No

VMware NetQueue &
Microsoft VMQ

Yes Yes Yes Yes Yes No

Statistics for SNMP MIB II Yes Yes Yes Yes No No

Form Factor Low-profile Low-profile Low-profile Low-profile Low-profile Low-profile

* Withdrawn from marketing

Broadcom NetXtreme Gigabit Ethernet Adapters 3

Physical specifications

The adapters have the following physical specifications:

Broadcom NetXtreme I Dual Port GbE Adapter and ThinkSystem 2-port adapter

Length: 109 mm (4.3")
Height: 69 mm (2.7")
Depth: 19 mm (0.74 in)

Broadcom NetXtreme I Quad Port GbE Adapter and ThinkSystem 4-port adapter

Length: 132 mm (5.2")
Height: 69 mm (2.7")
Depth: 19 mm (0.74 in)

Broadcom NetXtreme 2xGbE BaseT Adapter:

Length: 118 mm (4.66 in)
Height: 64 mm (2.53 in)
Depth: 19 mm (0.74 in)

Broadcom NetXtreme 1xGbE BaseT Adapter:

Length: 149 mm (5.875 in)
Height: 70 mm (2.75 in)
Depth: 18 mm (0.70 in)

The following figure shows the Broadcom NetXtreme I Dual Port GbE Adapter

Figure 2. Broadcom NetXtreme I Dual Port GbE Adapter

Broadcom NetXtreme Gigabit Ethernet Adapters 4

Operating environment

The adapters are supported in the following environment:

ThinkSystem NetXtreme PCIe 1Gb 4-Port RJ45 Ethernet Adapter By Broadcom
ThinkSystem NetXtreme PCIe 1Gb 2-Port RJ45 Ethernet Adapter By Broadcom
Broadcom NetXtreme I Quad Port GbE Adapter:
Broadcom NetXtreme I Dual Port GbE Adapter:

Temperature:

Operating at 0 to 914 m (0 to 3,000 ft): 10° to 35°C (50° to 95°F)
Operating at 914 m to 2133m (3,000 to 7,000 ft): 10° to 32°C (50° to 90°F)

Relative humidity: 20% to 80% (non-condensing)

Broadcom NetXtreme 2xGbE BaseT Adapter:
Broadcom NetXtreme 1xGbE BaseT Adapter:

Temperature: 0° to 55°C (32° to 131°F)

Relative humidity: 10% to 90%

Warranty

One-year limited warranty. When installed in a Lenovo server, these cards assume the server’s base
warranty and any warranty upgrade.

Server support - ThinkSystem

The following table lists the ThinkSystem servers that are compatible.

Table 3. ThinkSystem server support

Part
number Description

2S Rack & Tower

4S

Rack

Dense/

Blade

7ZT7A00482 ThinkSystem NetXtreme PCIe 1Gb 2-Port RJ45

Ethernet Adapter

Y Y Y Y Y Y Y Y Y Y N N N N

7ZT7A00484 ThinkSystem Broadcom NetXtreme PCIe 1Gb 4-Port

RJ45 Ethernet Adapter

Y Y Y Y Y Y Y Y Y Y N N N N

ST550 (7X09/7X10)

SR530 (7X07/7X08)

SR550 (7X03/7X04)

SR570 (7Y02/7Y03)

SR590 (7X98/7X99)

SR630 (7X01/7X02)

SR650 (7X05/7X06)

SR850 (7X18/7X19)

SR860 (7X69/7X70)

SR950 (7X11/12/13)

SD530 (7X21)

SD650 (7X58)

SN550 (7X16)

SN850 (7X15)

Broadcom NetXtreme Gigabit Ethernet Adapters 5

Server support - System x

The adapters are supported in the servers identified in the following tables.

Support for System x and dense servers with Xeon E5/E7 v4 and E3 v5 processors

Table 4. Support for System x and dense servers with Xeon E5 v4 and E5 v5 processors

Part
number Description

90Y9370 Broadcom NetXtreme I Dual Port GbE Adapter Y Y Y Y Y Y N

90Y9352 Broadcom NetXtreme I Quad Port GbE Adapter N N Y Y Y Y N

42C1780 Broadcom NetXtreme 2xGbE BaseT Adapter N N Y Y N N N

39Y6066 Broadcom NetXtreme 1xGbE BaseT Adapter N N N N N N N

Support for System x and dense servers with Intel Xeon E5/E7 v3 and E3 v4 processors

Table 5. Support for servers with Intel Xeon E5 v3 and E3 v4 processors

Part
number Description

90Y9370 Broadcom NetXtreme I Dual Port GbE Adapter Y Y Y Y Y Y Y

90Y9352 Broadcom NetXtreme I Quad Port GbE Adapter Y N Y Y Y Y Y

42C1780 Broadcom NetXtreme 2xGbE BaseT Adapter N N Y Y Y N N

39Y6066 Broadcom NetXtreme 1xGbE BaseT Adapter N N N N Y N N

x3250 M6 (3943)

x3250 M6 (3633)

x3550 M5 (8869)

x3650 M5 (8871)

x3850 X6/x3950 X6 (6241, E7 v4)

nx360 M5 (5465, E5-2600 v4)

sd350 (5493)

x3100 M5 (5457)

x3250 M5 (5458)

x3500 M5 (5464)

x3550 M5 (5463)

x3650 M5 (5462)

x3850 X6/x3950 X6 (6241, E7 v3)

nx360 M5 (5465)

Broadcom NetXtreme Gigabit Ethernet Adapters 6

Support for servers with Intel Xeon v2 processors

Table 6. Support for servers with Intel Xeon v2 processors

Part
number Description

90Y9370 Broadcom NetXtreme I Dual Port GbE Adapter Y Y Y Y Y Y Y Y

90Y9352 Broadcom NetXtreme I Quad Port GbE Adapter Y Y Y Y Y Y Y Y

42C1780 Broadcom NetXtreme 2xGbE BaseT Adapter Y Y Y Y Y Y N N

39Y6066 Broadcom NetXtreme 1xGbE BaseT Adapter Y Y Y Y Y N N N

See ServerProven for the latest information on the adapters supported by each System x server type:

http://www.lenovo.com/us/en/serverproven/xseries/lan/matrix.shtml

Connectors and LEDs

Figure 4 shows the LEDs on the Broadcom NetXtreme I Dual Port GbE Adapter.

Figure 3. Broadcom NetXtreme I Dual Port GbE Adapter connectors and LEDs

x3300 M4 (7382)

x3500 M4 (7383, E5-2600 v2)

x3550 M4 (7914, E5-2600 v2)

x3630 M4 (7158, E5-2400 v2)

x3650 M4 (7915, E5-2600 v2)

x3650 M4 BD (5466)

x3750 M4 (8753)

x3850 X6/x3950 X6 (6241, E7 v2)

Broadcom NetXtreme Gigabit Ethernet Adapters 7

Regulatory compliance

The adapters conform to the following international standards:

EN55022
EN55024
EN60950 / CE
EN 61000-3-2
EN 61000-3-3
ICES-003, Issue-004
IEC 950 CB Scheme
FCC 47 CFR Part 15 Class A
UL 1950
CSA C22.2 950-95
VCCI
AS/NZSCISPR 22 / C-tick
RRL for KC
BSMI
UL 94-/V
RoHS

Broadcom NetXtreme Gigabit Ethernet Adapters 8

Operating system support

The ThinkSystem adapters support the following operating systems:

Microsoft Windows Server 2012 R2
Microsoft Windows Server 2016
Red Hat Enterprise Linux 6 Server x64 Edition
Red Hat Enterprise Linux 7
SUSE Linux Enterprise Server 11 for AMD64/EM64T
SUSE Linux Enterprise Server 12
VMware vSphere 6.0 (ESXi)
VMware vSphere 6.5 (ESXi)

The System x adapters support the following operating systems:

Microsoft Windows Server 2008 HPC Edition, Windows 2008HPC
Microsoft Windows Server 2008 R2
Microsoft Windows Server 2008, Datacenter x64 Edition
Microsoft Windows Server 2008, Enterprise x64 Edition
Microsoft Windows Server 2008, Enterprise x86 Edition
Microsoft Windows Server 2008, Standard x64 Edition
Microsoft Windows Server 2008, Standard x86 Edition
Microsoft Windows Server 2008, Web x64 Edition
Microsoft Windows Server 2008, Web x86 Edition
Microsoft Windows Server 2012
Microsoft Windows Server 2012 R2
Microsoft Windows Server 2016
Microsoft Windows Small Business Server 2008 Premium Edition
Microsoft Windows Small Business Server 2008 Standard Edition
Red Hat Enterprise Linux 5 Server Edition
Red Hat Enterprise Linux 5 Server with Xen x64 Edition
Red Hat Enterprise Linux 5 Server x64 Edition
Red Hat Enterprise Linux 6 Server Edition
Red Hat Enterprise Linux 6 Server x64 Edition
Red Hat Enterprise Linux 7
SUSE LINUX Enterprise Server 10 for AMD64/EM64T
SUSE LINUX Enterprise Server 10 for x86
SUSE LINUX Enterprise Server 10 with Xen for AMD64/EM64T
SUSE LINUX Enterprise Server 11 for AMD64/EM64T
SUSE LINUX Enterprise Server 11 for x86
SUSE LINUX Enterprise Server 11 with Xen for AMD64/EM64T
SUSE LINUX Enterprise Server 12
VMware ESX 4.1
VMware ESXi 4.1
VMware vSphere 5.0 (ESXi)
VMware vSphere 5.1 (ESXi
VMware vSphere 5.5 (ESXi)
VMware vSphere 6.0 (ESXi)

See ServerProven for the latest information about the specific versions and service packs supported:

http://www.lenovo.com/us/en/serverproven

Broadcom NetXtreme Gigabit Ethernet Adapters 9

Related publications

For more information, refer to the following resources:

Lenovo ThinkSystem networking options product web page

https://lenovopress.com/lp0765-networking-options-for-thinksystem-servers

Lenovo System x networking options product web page

https://www3.lenovo.com/us/en/data-center/servers/server-options/system-x-options/networking­adapters/system-x-adapters/c/system-x-adapters

ServerProven compatibility page for Ethernet adapters:

http://www.lenovo.com/us/en/serverproven

Related product families

Product families related to this document are the following:

1 Gb Ethernet Connectivity

Ethernet Adapters

Broadcom NetXtreme Gigabit Ethernet Adapters 10

Notices

Lenovo may not offer the products, services, or features discussed in this document in all countries. Consult your
local Lenovo representative for information on the products and services currently available in your area. Any
reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product,
program, or service may be used. Any functionally equivalent product, program, or service that does not infringe
any Lenovo intellectual property right may be used instead. However, it is the user's responsibility to evaluate and
verify the operation of any other product, program, or service. Lenovo may have patents or pending patent
applications covering subject matter described in this document. The furnishing of this document does not give you
any license to these patents. You can send license inquiries, in writing, to:

Lenovo (United States), Inc.
1009 Think Place - Building One
Morrisville, NC 27560
U.S.A.
Attention: Lenovo Director of Licensing

LENOVO PROVIDES THIS PUBLICATION ”AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF NON-INFRINGEMENT,
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions do not allow disclaimer of
express or implied warranties in certain transactions, therefore, this statement may not apply to you.

This information could include technical inaccuracies or typographical errors. Changes are periodically made to the
information herein; these changes will be incorporated in new editions of the publication. Lenovo may make
improvements and/or changes in the product(s) and/or the program(s) described in this publication at any time
without notice.

The products described in this document are not intended for use in implantation or other life support applications
where malfunction may result in injury or death to persons. The information contained in this document does not
affect or change Lenovo product specifications or warranties. Nothing in this document shall operate as an express
or implied license or indemnity under the intellectual property rights of Lenovo or third parties. All information
contained in this document was obtained in specific environments and is presented as an illustration. The result
obtained in other operating environments may vary. Lenovo may use or distribute any of the information you supply
in any way it believes appropriate without incurring any obligation to you.

Any references in this publication to non-Lenovo Web sites are provided for convenience only and do not in any
manner serve as an endorsement of those Web sites. The materials at those Web sites are not part of the materials
for this Lenovo product, and use of those Web sites is at your own risk. Any performance data contained herein
was determined in a controlled environment. Therefore, the result obtained in other operating environments may
vary significantly. Some measurements may have been made on development-level systems and there is no
guarantee that these measurements will be the same on generally available systems. Furthermore, some
measurements may have been estimated through extrapolation. Actual results may vary. Users of this document
should verify the applicable data for their specific environment.

© Copyright Lenovo 2018. All rights reserved.

This document, TIPS0758, was created or updated on March 6, 2018.

Send us your comments in one of the following ways:

Use the online Contact us review form found at:

http://lenovopress.com/TIPS0758

Send your comments in an e-mail to:

[e-mail]

This document is available online at http://lenovopress.com/TIPS0758.

Broadcom NetXtreme Gigabit Ethernet Adapters 11

Trademarks

Lenovo, the Lenovo logo, and For Those Who Do are trademarks or registered trademarks of Lenovo in the
United States, other countries, or both. A current list of Lenovo trademarks is available on the Web at

http://www3.lenovo.com/us/en/legal/copytrade/.

The following terms are trademarks of Lenovo in the United States, other countries, or both:
Lenovo®
ServerProven®
System x®
ThinkSystem
iDataPlex®

The following terms are trademarks of other companies:

Intel® and Xeon® are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the
United States and other countries.

Linux® is a trademark of Linus Torvalds in the United States, other countries, or both.

Microsoft®, Windows Server®, and Windows® are trademarks of Microsoft Corporation in the United
States, other countries, or both.

Other company, product, or service names may be trademarks or service marks of others.

Broadcom NetXtreme Gigabit Ethernet Adapters 12
