Gemplus GemPC Smart Card Reader from Lenovo

User’ s Guid e

Gemplus GemPC Smart Card Reader from Lenovo

User’ s Guid e

Note: Before using this information and the product it supports, read the information in “Service and Support” on page 9 and “Lenovo Statement of Limited Warranty” on page 11

First Edition (December 2005) © Copyright Lenovo 2005.

U.S. GOVERNMENT USERS – RESTRICTED RIGHTS: Our products and/or services are provided with RESTRICTED RIGHTS. Use, duplication or disclosure by the Government is subject to the GSA ADP Schedule contract with Lenovo Group Limited, if any, or the standard terms of this commercial license, or if the agency is unable to accept this Program under these terms, then we provide this Program under the provisions set forth in Commercial Computer Software–Restricted Rights at FAR 52.227-19, when applicable, or under Rights in Data-General, FAR 52.227.14 (Alternate III).

Preface . . . . . . . . . . . . . . .v

Registering your option . . . . . . . . . .v

Chapter 1. Introduction . . . . . . . .1

Chapter 2. Installation . . . . . . . . .3

Installing the Gemplus GemPC Smart Card reader

writer . . . . . . . . . . . . . . . . .3

Windows XP and Windows 2000 . . . . . . .3

Installing and using the Gemplus SmartDiag

diagnostic tool . . . . . . . . . . . . . .4

Chapter 3. Uninstalling the Gemplus

SmartDiag diagnostic tool . . . . . . .5

Specifications . . . . . . . . . . . .7

Service and Support . . . . . . . . .9

Online technical support . . . . . . . . . .9

Telephone technical support . . . . . . . . .9

Lenovo Statement of Limited Warranty 11

Part 1 - General Terms . . . . . . . . . . .11

Part 2 - Country-unique Terms . . . . . . . .13

Part 3 - Warranty Information . . . . . . . .23

Warranty Period . . . . . . . . . . . .23

Types of Warranty Service . . . . . . . .23

Worldwide telephone list . . . . . . . . .24

Guarantee supplement for Mexico . . . . . . .27

Notices . . . . . . . . . . . . . .29

Trademarks . . . . . . . . . . . . . .30

Electronic emission notices . . . . . . . . .30

iv Gemplus GemPC Smart Card Reader from Lenovo: User ’s Guide

Preface

This user’s guide provides information on the Gemplus GemPC Smart Card Reader from Lenovo.

Your option package contains the following:

v Gemplus GemPC Smart Card Reader from Lenovo v Gemplus GemPC Smart Card Reader from Lenovo CD containing the device drivers,

the Gemplus SmartDiag diagnostic tool, and this user’s guide

v Quick Installation Guide

Contact

your place of purchase if an item is missing or damaged. Be sure to retain

your proof of purchase and packing material. They might be required to receive warranty service.

Registering your option

Thank you for purchasing this Lenovo register your product and provide us with information that will help Lenovo to better serve you in the future. Your feedback is valuable to us in developing products and services that are important to you, as well as in developing better ways to communicate with you. Register your option on the following We b site:

http://www.lenovo.com/register

Lenovo will send you information and updates on your registered product unless you indicate on the Web site questionnaire that you do not want to receive further information.

™

product. Please take a few moments to

vi Gemplus GemPC Smart Card Reader from Lenovo: User ’s Guide

Chapter 1. Introduction

The Gemplus GemPC Smart Card Reader from Lenovo incorporates smart cards into IBM compatible PC’s equipped with a PC Card slot. The smart card reader writer is a high-performance, compact and lightweight device that can handle a wide range of functions for various applications, such as computer security, network security, banking, and telecommunications.

The Gemplus GemPC Smart Card Reader from Lenovo supports most memory and microprocessor cards currently on the market and because of its general-purpose architecture, embossed cards can be used. The smart card reader writer is compatible with all cards that meet ISO 7816-1, -2, -3, and 7811 standards (embossed card) with T=0 and T=1 protocols. With its Plug and Play installation, the smart card reader writer is ready for use with Microsoft Windows 2000 Professional.

The device driver supports the following operating systems:

v Windows 2000 Professional v Windows XP

Windows

XP and

2 Gemplus GemPC Smart Card Reader from Lenovo: User ’s Guide

Chapter 2. Installation

This chapter provides instructions for installing the Gemplus GemPC Smart Card Reader from Lenovo and the Gemplus SmartDiag diagnostic tool. This chapter also includes instructions on updating the device driver.

Installing the Gemplus GemPC Smart Card reader writer

This section contains instructions for installing the Gemplus GemPC smart card reader writer for Microsoft Windows XP and Microsoft Windows 2000 Professional.

Note: To verify if newer versions of this installation software are available, visit

the Lenovo Web site at http://www.lenovo.com/think/support for the latest software and documentation.

Windows XP and Windows 2000

To install the Gemplus GemPC smart card reader writer for Windows XP or Windows 2000, complete the following procedure:

1. Insert the CD for the Gemplus GemPC Smart Card Reader from Lenovo that comes with your option in the computer.

2. After inserting the CD, the User’s Guide Software CD screen automatically opens. On the left side of the screen, click Software.

3. Click on Install Device Drivers. The Gemplus GemPC Smart Card Reader Installer Window will pop up.

4. Click Next.

5. Read through the End User Licensing Agreement and if you agree with the

terms and conditions of the agreement, select ″I accept the terms in the agreement″, and click Next.

6. Choose an install directory and click Next.

7. Click Finish.

8. Insert the Gemplus GemPC Smart Card Reader from Lenovo in your computer,

(As shown below).

Smart

Card

Reader

9. Your option is ready for use.

information on the Gemplus SmartDiag diagnostic tool, see “Installing and

For using the Gemplus SmartDiag diagnostic tool” on page 4.

Installing and using the Gemplus SmartDiag diagnostic tool

The Gemplus SmartDiag diagnostic tool reports software or hardware problems and provide troubleshooting information. If the displayed information does not solve the problem, you can generate a diagnostic report for technical support.

The diagnostic tool verifies the availability of the following:

v Operating system services that support smart cards v Gemplus GemPC Smart card readers v Gemplus GemPC Smart cards

install the Gemplus SmartDiag diagnostic tool, complete the following

To procedure:

1. Insert the Lenovo Smart Card Reader Writer CD into the CD-ROM drive.

2. From the computer desktop, click Start → Run.

3. In the Open: field, type d:\smartdiag\setup, where d is the CD-ROM drive.

4. Click OK.

5. Follow the instructions on the screen to continue the installation.

start the diagnostic tool, click Start → Programs → Gemplus → SmartDiag →

SmartDiag .

Note: To view the Help documentation for the diagnostic tool, click Start →

Programs → Gemplus → SmartDiag → SmartDiag →Help.

4 Gemplus GemPC Smart Card Reader from Lenovo: User ’s Guide

Chapter 3. Uninstalling the Gemplus SmartDiag diagnostic tool

This chapter provides instructions for uninstalling the Gemplus SmartDiag diagnostic tool.

To remove the Gemplus SmartDiag diagnostic tool, complete the following procedures:

1. From the computer desktop, click Start → Settings → Control Panel.

2. Double-click Add/Remove Programs.

3. Select Lenovo Smart Card Reader Tools.

4. Click Add/Remove or Change/Remove.
