Lenovo 3000 G530 User Manual

Lenovo 3000 G430/G530 UG V1.0 cover_en_1-4

Lenovo 3000 G430/

New World. New Thinking.

www.lenovo.com

P/N: 147001852 Printed in China

©Lenovo China 2008

G530

User Guide V1.0

Note

Before using this information and the product it supports, be sure to read the following:

• Chapter 6. Safety, Use, and Care Information on page 61.

• Appendix D. Notices on page 109.

• OneKey Rescue System User Guide included in the package with this publication.

Lenovo 3000 G430/G530 UG V1.0 cover_en_2-3

If your product is not working correctly,

DO NOT RETURN IT TO THE STORE.

For technical assistance, contact a Lenovo support specialist 24 hours a day by calling toll free 1-877-4

LENOVO (1-877-453-6686).

First Edition (May 2008)

U.S. GOVERNMENT USERS – RESTRICTED RIGHTS: Our products and/or services are provided with RESTRICTED RIGHTS. Use, duplication or disclosure by the Government is subject to the GSA ADP Schedule contract with Lenovo, if any, or the standard terms of this commercial license, or if the agency is unable to accept this Program under these terms, then we provide this Program under the provisions set forth in Commercial Computer Software–Restricted Rights at FAR 52.227-19, when applicable, or under Rights in Data-General, FAR

52.227.14 (Alternate III).

Additionally, you can find support information and updates on the Lenovo Web site located at

http://consumersupport.lenovo.com.

* Only for the users from the United States.

Lenovo 3000 G430-G530 UG V1.0_en.book Page 1 Tuesday, July 1, 2008 7:51 PM

ENERGY STAR model information

ENERGY STAR® is a joint program of the U.S. Environmental Protection Agency and the U.S. Department of Energy aimed at saving money and protecting the environment through energy efficient products and practices.

Lenovo is proud to offer our customers products with an ENERGY STAR compliant designation. Lenovo computers of the following machine types, if the ENERGY STAR mark is affixed, have been designed and tested to conform to the ENERGY STAR 4.0 program requirements for computers.

• 20003, 4153

• 20004, 4151

By using ENERGY STAR compliant products and taking advantage of the power-management features of your computer, you reduce the consumption of electricity. Reduced electrical consumption contributes to potential financial savings, a cleaner environment, and the reduction of greenhouse gas emissions.

Lenovo 3000 G430-G530 UG V1.0_en.book Page 2 Tuesday, July 1, 2008 7:51 PM

For more information about ENERGY STAR, visit http://www.energystar.gov. Lenovo encourages you to make efficient use of energy an integral part of your day-to-day operations. To help in this endeavor, Lenovo has preset the following power-management features to take effect when your computer has been inactive for a specified duration:

Table 1. ENERGY STAR power-management features, by operating system

Windows XP Windows Vista

•Turn off monitor: After 10 minutes

•Turn off hard disks: After 30 minutes

•System standby: After 20 minutes

•System hibernates: After 2 hours

Power plan: Balanced

•Turn off the display: After 10 minutes

•Put the computer to sleep: After 25 minutes

•Advanced power settings:

- Turn off hard disks: After 20

minutes

- Hibernate: After 1 hour

To awaken your computer from a Sleep or System Standby mode, press any key on your keyboard. For more information about these settings, refer to your Windows Help and Support information system.

Lenovo 3000 G430-G530 UG V1.0_en.book Page 3 Tuesday, July 1, 2008 7:51 PM

Explanation of Hard Disk Capacity

Dear user, While using your computer, you may discover that the nominal hard disk capacity indicated is somewhat different from the disk capacity displayed by the operating system. For example, a nominal 80GB hard disk will appear as less than 80GB in the operating system. This discrepancy is not an error in hard disk installation nor any other problem, but a normal phenomenon of computers. This phenomenon is primarily due to the following reasons:

I. Different standards used by the manufacturer and operating

system when calculating hard disk capacity

Hard disk manufacturers use a radix of 1000, i.e. 1G = 1,000MB, 1MB = 1,000KB, 1KB = 1,000 bytes. However, when identifying hard disk capacity, operating systems use a radix of 1024, i.e. 1GB = 1,024MB, 1MB = 1,024KB, 1KB = 1,024 bytes. The standard adopted by your computer is that of the hard disk manufacturers. Since the standards adopted by the hard disk manufacturer and operating system are different, the hard disk capacity displayed by the operating system will be different from the nominal hard disk capacity.

For example, if the hard disk is nominally X G, even when it is completely empty, the capacity displayed by the operating system will be: X × 1000 × 1000 × 1000/ (1024 × 1024 × 1024) ≈ X × 0.931 G

Lenovo 3000 G430-G530 UG V1.0_en.book Page 4 Tuesday, July 1, 2008 7:51 PM

If a portion of the hard disk space has been used for some specific purpose, then the capacity indicated by the operating system will be even less than X × 0.931 G.

II. A portion of the hard disk space is used for specific purposes

Lenovo computers come with preinstalled OneKey Rescue System, so the hard disk has a special portion partitioned before delivery, which is used to store hard disk mirror and OneKey Rescue System program files. The size of the reserved space for this partition varies according to the model, operating system and software of the computer. For the sake of safety, this partition is not evident, which is commonly referred to as a “hidden partition”.

In addition, after the hard disk is partitioned or formatted, the system will assign a certain amount of hard disk space for the system files.

For the above reasons, the available hard disk space indicated by the operating system is always less than the computer’s nominal hard disk capacity.

Lenovo 3000 G430-G530 UG V1.0_en.book Page i Tuesday, July 1, 2008 7:51 PM

Contents

Chapter 1. Getting to Know Your

Computer ...................................... 1

Top View .......................................1

Left-side View...............................3

Right-side View ............................5

Front View.....................................6

Bottom View..................................7

Chapter 2. Using Your

Computer .................................... 10

Putting Your Computer to Sleep

or Shutting It Down ...................10

Using the Touch Pad..................11

Using the Keyboard ...................12

Special Keys and Buttons ..........15

Using the Optical Drive.............17

Using Memory Cards (Specific

model only) .................................18

Using the Integrated Camera

(Specific model only) .................19

Using the Internet.......................20

Securing Your Computer ..........23

Installing Device Drivers...........31

Using the Battery and AC

Adapter ........................................ 32

Chapter 3. Using External

Devices ........................................37

Connecting a Universal Serial Bus

(USB) Device ...............................37

Connecting a PC Card

Device...........................................38

Connecting an External

Display .........................................40

Connecting a Headphone and

Audio Device ..............................41

Connecting an External

Microphone .................................42

Connecting a Bluetooth Device

(Specific model only)..................43

Chapter 4. Troubleshooting .......44

Frequently Asked Questions ....44

Troubleshooting..........................46

Chapter 5. Getting Help and

Service .........................................56

Getting Help and Service ..........56

Getting Help on the Web...........57

Calling the Customer Support

Center ...........................................57

Getting Help Around the

World............................................60

Lenovo 3000 G430-G530 UG V1.0_en.book Page ii Tuesday, July 1, 2008 7:51 PM

Contents

Chapter 6. Safety, Use, and Care

Information.................................. 61

Important Safety

Information ................................. 61

Caring Your Computer ............. 78

Accessibility and Comfort ........ 86

Maintenance................................ 89

Appendix A. Lenovo Limited

Warranty...................................... 93

Warranty Information ............. 101

Lenovo Warranty Service

Telephone Numbers ................104

Appendix B. Customer

Replaceable Units (CRUs) ....... 106

Appendix C. Specifications ..... 107

Specifications ............................107

Appendix D. Notices ................ 109

Notices ....................................... 109

Wireless related

information ............................... 112

Electronic Emissions

Notices ....................................... 115

WEEE and Recycling

Statements ................................. 121

EU WEEE Statements ..............122

Japan Recycling Statements.... 123

Notice for Users in the

U.S.A. ......................................... 125

Notice on Deleting Data from

Your Hard Disk ........................125

Trademarks ............................... 127

Index...........................................128

Lenovo 3000 G430-G530 UG V1.0_en.book Page 1 Tuesday, July 1, 2008 7:51 PM

Chapter 1. Getting to Know Your Computer

Top View - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

* The illustrations in this manual may differ from the actual product.















Lenovo 3000 G430-G530 UG V1.0_en.book Page 2 Tuesday, July 1, 2008 7:51 PM

Chapter 1. Getting to Know Your Computer

Integrated camera (Specific model only) ....................................... 19

Computer display

The color display with TFT technology provides clear and brilliant text and graphics.

OneKey Rescue System button...................................................... 16

Power button

Use the Power button to turn on the computer.

System status indicators

The system status indicators show the current status of your computer.

Microphone (built-in)

The built-in microphone can be used for video conferencing, voice narration, or simple audio recordings.

Custom and volume buttons........................................................... 15

Lenovo 3000 G430-G530 UG V1.0_en.book Page 3 Tuesday, July 1, 2008 7:51 PM

Chapter 1. Getting to Know Your Computer

Left-side View - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -















Lenovo 3000 G430-G530 UG V1.0_en.book Page 4 Tuesday, July 1, 2008 7:51 PM

Chapter 1. Getting to Know Your Computer

Fan louvers

The fan louvers allow heated air to exit the computer.

Important:



Make sure that paper, books, clothing, cables or other objects do not block any of the fan louvers otherwise, overheating of the computer may occur.

LAN port............................................................................................ 20

VGA port ........................................................................................... 40

PCI Express card slot ...................................................................... 38

Security keyhole

Your computer comes with a security keyhole. You can purchase a security cable and lock to fit this keyhole.

Note:



Before purchasing any security product, verify that it is compatible with this type of security keyhole.

HDMI port (Specific model only)

USB 2.0 port ..................................................................................... 37









Lenovo 3000 G430-G530 UG V1.0_en.book Page 5 Tuesday, July 1, 2008 7:51 PM

Chapter 1. Getting to Know Your Computer

Right-side View - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

b da c

* G430 has one USB port here.

Modem Port (Specific model only) ................................................. 22

USB 2.0 port ..................................................................................... 37

Optical drive ..................................................................................... 17

AC power adapter jack

Connect the power adapter here to supply power to the computer and charge the internal battery.

Note:



To prevent damage to the computer and battery pack, use the supplied AC adapter only.











Lenovo 3000 G430-G530 UG V1.0_en.book Page 6 Tuesday, July 1, 2008 7:51 PM

Chapter 1. Getting to Know Your Computer

Front View - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

a ab c de

Speakers

Built-in speakers for rich powerful sound.

Wireless device switch (Specific model only)

Use this switch to simultaneously turn on or turn off Wireless LAN and Bluetooth devices.

Microphone jack (external).............................................................. 42

Headphone (external) ...................................................................... 41

Multi-media reader slot (Specific model only) .............................. 18

Lenovo 3000 G430-G530 UG V1.0_en.book Page 7 Tuesday, July 1, 2008 7:51 PM

Chapter 1. Getting to Know Your Computer

Bottom View - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

edf











Lenovo 3000 G430-G530 UG V1.0_en.book Page 8 Tuesday, July 1, 2008 7:51 PM

Chapter 1. Getting to Know Your Computer

Battery latch - manual

The manual battery latch is used to keep the battery pack secured. Move the manual battery latch to the unlocked position to insert or remove the battery pack. Move the manual latch to the locked position after inserting the battery pack.

Battery pack ..................................................................................... 32

Battery latch - spring loaded

The spring-loaded battery latch keeps the battery pack secured in place. When you insert a battery pack, this latch automatically secures the battery in place. To remove the battery, hold this latch in the unlocked position.

WLAN and WWAN cards compartment

The wireless network cards (Specific model only) can be secured in this compartment for easy access.

Central Processor Unit (CPU)/ Memory (RAM) compartment

 Central Processor Unit (CPU)

The CPU compartment provides space for the CPU and the radiator.



Lenovo 3000 G430-G530 UG V1.0_en.book Page 9 Tuesday, July 1, 2008 7:51 PM

Chapter 1. Getting to Know Your Computer

Important:



Do not replace the CPU! Visit an authorized service center or retailer for replacement.

 Memory (RAM) compartment

The memory compartment provides expansion capabilities for additional memory. The BIOS automatically detects the amount of memory in the system and configures CMOS accordingly during the Power-On Self-Test (POST) process. There is no hardware or software (including BIOS) setup required after the memory is installed.

Note:



(1) Only purchase expansion modules from authorized retailers of

this computer to ensure maximum compatibility and reliability.

(2) If you only insert one memory card in the compartment, plug it

into the slot near the mainboard.

Hard Disk Drive compartment

The hard disk drive is secured in this compartment.

Important:



Do not disassemble or replace the hard disk drive! If you should ever need to, ask a Lenovo authorized service center or dealer to provide this service.

Lenovo 3000 G430-G530 UG V1.0_en.book Page 10 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

Putting Your Computer to Sleep or Shutting It Down

When you finish working with your computer, you can put it to sleep or shut it down.

 Putting Your Computer to Sleep

If you will be away from your computer for only a short time, put the computer to sleep. When the computer is in sleep state, you can quickly wake it to resume use,

and bypass the startup process.

To put the computer to sleep, do one of the following.

 Click Start and select Sleep from the Start menu.  Press Fn + F1.

Warning:



Wait until the power indicator light starts blinking (indicating that the computer is in sleep state) before you move your computer. Moving your computer while the hard disk is spinning can damage the hard disk, causing loss of data.

To wake the computer, do one of the following.

 Press the power button.  Press any key.

 Shutting Down Your Computer

If you are not going to use your computer for a day or two, shut it down. To shut down your computer, click

Start

and select

Shut down

from the Start menu.









Lenovo 3000 G430-G530 UG V1.0_en.book Page 11 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

Using the Touch Pad - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

The touch pad consists of a pad and two click buttons at the bottom of the keyboard. To move the cursor on the screen, slide your fingertip

over the pad in the direction in which you want the cursor to move. The functions of the left and right click buttons correspond to those of

the left and right mouse buttons on a conventional mouse.

Lenovo 3000 G430-G530 UG V1.0_en.book Page 12 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

Note:



You can also attach and use a USB mouse through the USB connector. For details,

page 37

see “Connecting a Universal Serial Bus (USB) Device” on

Using the Keyboard - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Your computer has a numeric keypad and function keys incorporated in the standard keyboard.

 Numeric Keypad

The keyboard has keys that, when enabled, work as a 10-key numeric keypad. To enable or disable the numeric keypad, press Fn+Insert/NmLk.

* The illustrations in this manual may differ from the actual product.





Lenovo 3000 G430-G530 UG V1.0_en.book Page 13 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

 Function Key Combinations

Through the use of the function keys, perform useful operations more efficiently. To use this feature, press and hold the Fn key , then press one of the function keys .

G430-G530_UG x-Ch2.fm Page 14 Thursday, July 3, 2008 11:14 AM

Chapter 2. Using Your Computer

The following describes the features of each function key.

Fn + F1: Put your computer in sleep mode. Fn + F2: Turn off/on the LCD screen back light. Fn + F3: Shift to other connected display devices. Fn + F4: Switch between wide screen and normal mode. Fn + F5: Enable/disable the built-in wireless device feature. Fn + F8: Enable/disable the touch pad. Fn + F9: Play/pause Media Player playback. Fn + F10: Stop Media Player playback. Fn + F11: Skip to the previous track. Fn + F12: Skip to the next track. Fn + Insert/NmLk: Enable/disable the Numeric keypad. Fn + Delete/ScrLk: Enable/disable Scroll Lock. Fn + P

rtSc/SysRq: System request.

Fn + Pause/Break: Fn + up/down arrow: Increase/decrease display brightness. Fn + right/left arrow: Increase/decrease computer volume. Fn + PgUp: Move the cursor to the head of the line. Fn + PgDn: Move the cursor to the end of the line.

Pause to view the system information during start-up.









Lenovo 3000 G430-G530 UG V1.0_en.book Page 15 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

Special Keys and Buttons - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Your computer has several special keys and buttons.

 Custom and volume buttons

abcd

* The illustrations in this manual may differ from the actual product.

Mute/unmute the sound. Vol u me d ow n Vol u me u p Open user define utility.

Lenovo 3000 G430-G530 UG V1.0_en.book Page 16 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

 OneKey Rescue System button

Press the OneKey Rescue System button to enter the main interface of OneKey Rescue System while the power is off.

Attention:



When you press OneKey Rescue System button to turn on the computer, please ensure that your computer is not connected with other peripherals (such as USB storage device, etc.), otherwise the system may not operate properly. For details, see “OneKey Rescue System User Guide”.

Note:



When your computer is running Windows Vista OneKey Recovery application installed, you can start the application by pressing the OneKey Rescue System button.

, and if you have the

Lenovo 3000 G430-G530 UG V1.0_en.book Page 17 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

Using the Optical Drive - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

 Playing CDs/DVDs Disc Media

You can play your CDs/DVDs with various applications, such as Windows Media Player, Windows Media Center, etc.

 Copying files to CDs/DVDs Discs (Specific model only)

You can copy files to your CDs/DVDs Discs with Power2Go, a software for burning data, music, videos and photos onto CDs, DVDs.

For instructions on Power2Go, see the help file on your software.

Lenovo 3000 G430-G530 UG V1.0_en.book Page 18 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

Using Memory Cards (Specific model only) - - - - - - - - - - -

Your computer comes with one Multi-media Reader slot (Specific model only) used to insert a memory card, such as a SD Card, a Multi-media card, a Memory Stick or a Memory Stick Pro card.

Note:



Only use memory cards of the type listed above; for more information about the usage, read the instructions supplied with the memory card.

Lenovo 3000 G430-G530 UG V1.0_en.book Page 19 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

 Inserting a Memory Card

1 Push the slot cover in and remove the cover. 2 Slide the memory card in until it clicks into place.

 Removing a Memory Card

1 Push the memory card until you hear a click. 2 Gently pull the memory card out of the Multi-media reader slot.

Using the Integrated Camera (Specific model only)

With the built-in camera, you can take photos or movies and use with various applications, such as EasyCapture, MSN or Yahoo! Messenger, and so on.

Note:



If you use Windows Vista, you need to install a separate third party dedicated application, because Vista does not include a program for taking pictures or movies with the integrated camera.

- - - - - - - - - - -

Lenovo 3000 G430-G530 UG V1.0_en.book Page 20 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

Using the Internet - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -

Your computer comes with a LAN port for high-speed DSL/cable modem connection and local area network (LAN), wireless LAN for wireless connection and modem port for dial-up connection.

 Using LAN Port

The LAN port accepts a standard RJ-45 connector, and allows you to connect the computer to a high-speed DSL/cable modem connection and local area network (LAN).

Lenovo 3000 G430-G530 UG V1.0_en.book Page 21 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

Attention:



As the voltage of a telephone connection is higher than that of a network, do not attempt to connect a telephone cable to the LAN port as a short circuit in the computer might occur.

 Using wireless LAN (Specific model only)

A isotropic antenna system is built into the display for optimal reception, enabling wireless communication wherever you are.

To enable wireless communications, do the following;

1 Slide the Wireless device switch latch (Specific model only) to the

right.

2 Press Fn + F5, set Wireless to Enable.

Lenovo 3000 G430-G530 UG V1.0_en.book Page 22 Tuesday, July 1, 2008 7:51 PM

Chapter 2. Using Your Computer

 Using Modem Port (Specific model only)

The modem port accepts a standard telephone cable with one RJ-11 connector, and allows dial up access to an Internet service provider (ISP).

Important:



Do not connect the modem port to a digital circuit cable, as the current in the digital circuit may damage the modem.

+ 108 hidden pages
