Lenovo 0C19868, 65W User Manual

Lenovo AC Adapter User's Guide

First edition (Jun 2009)
© Copyright Lenovo 20 . All rights reserved.
LENOVO products, data, computer software, and services have been developed exclusively
at private expense and are sold to governmental entities as commercial items as defi ned by
48 C.F.R. 2.101 with limited and restricted rights to use, reproduction and disclosure.
LIMITED AND RESTRICTED RIGHTS NOTICE: If products, data, computer software, or
services are delivered pursuant a General Services Administration “GSA” contract, use,
reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.

1

2

Contents

Safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .v

General safety guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii

Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .vii

Power cords and power adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii

Plugs and outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Heat and product ventilation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . viii

Power supply statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ix

About this book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xv

Installation and user’s guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Product description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Using the adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Connecting the adapter to a standard AC electrical outlet. . . . . . . . . . . . . . . . . . . . . 1

Appendix A.Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Appendix B. Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

China ROHS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Recycling information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

UL Listings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Appendix C. Important information for the European Directive

2002/96/EC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Appendix D. Electronic emission notices . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Federal Communications Commission (FCC) Statement . . . . . . . . . . . . . . . . . . .37

iii

iv

Safety information

Before installing this product, read the Safety Information.

Antes de instalar este produto, leia as Informações de Segurança.

Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí.

Læs sikkerhedsforskrifterne, før du installerer dette produkt.

Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety
Information.

Avant d’installer ce produit, lisez les consignes de sécurité.

Vor der Installation dieses Produkts die Sicherheitshinweise lesen.

Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.

Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette
produktet.

v

Antes de instalar este produto, leia as Informações sobre Segurança.

Antes de instalar este producto lea la información de seguridad.

Läs säkerhetsinformationen innan du installerar den här produkten.

vi

General safety guidelines

Always observe the following precautions to reduce the risk of injury and
property damage.

Service

Do not attempt to service a product yourself unless instructed to do so by the
Customer Support Center. Use only a service provider who is approved to
repair your particular product.

Note

: Some parts can be upgraded or replaced by the customer. These parts
are referred to as Customer Replaceable Units, or CRUs. Lenovo expressly
identifi es CRUs as such, and provides documentation with instructions when
it is appropriate for customers to replace those parts. You must closely follow
all instructions when performing such replacements. Always make sure that
the power is turned off and that the product is unplugged from any power
source before you attempt the replacement. If you have any questions or
concerns, contact the Customer Support Center.

Power cords and power adapters

Use only the power cords and power adapters supplied by the product
manufacturer.

Never wrap a power cord around the power adapter or other object. Doing
so can stress the cord in ways that can cause the cord to fray, crack or crimp.
This can present a safety hazard.

Always route power cords so that they will not be walked on, tripped over,
or pinched by objects.

Protect the cord and power adapters from liquids. For instance, do not leave
your cord or power adapter near sinks, tubs, toilets, or on fl oors that are
cleaned with liquid cleansers. Liquids can cause a short circuit, particularly
if the cord or power adapter has been stressed by misuse. Liquids can also
cause gradual corrosion of the power cord terminals and/or the connector
terminals on the adapter which can eventually result in overheating.

Always connect power cords and signal cables in the correct order and ensure
that all power cord connectors are securely and completely plugged into
receptacles.

vii

Do not use any power adapter that shows corrosion at the ac input pins
and/or shows signs of overheating (such as deformed plastic) at the ac
input or anywhere on the power adapter.

Do not use any power cords where the electrical contacts on either end
show signs of corrosion or overheating or where the power cord appears to
have been damaged in any way.

Plugs and outlets

If a receptacle (power outlet) that you intend to use with your computer
equipment appears to be damaged or corroded, do not use the outlet until it
is replaced by a qualifi ed electrician.

Do not bend or modify the plug. If the plug is damaged, contact the
manufacturer to obtain a replacement.

Some products are equipped with a three-pronged plug. This plug fi ts only
into a grounded electrical outlet. This is a safety feature. Do not defeat this
safety feature by trying to insert it into a non-grounded outlet. If you cannot
insert the plug into the outlet, contact an electrician for an approved outlet
adapter or to replace the outlet with one that enables this safety feature.
Never overload an electrical outlet. The overall system load should not
exceed 80 percent of the branch circuit rating. Consult an electrician for more
information if you have questions about power loads and branch circuit
ratings.

Be sure that the power outlet you are using is properly wired, easily
accessible, and located close to the equipment. Do not fully extend power
cords in a way that will stress the cords.

Connect and disconnect the equipment from the electrical outlet carefully

Heat and product ventilation

Computers, ac power adapters, and many accessories can generate heat
when turned on and when batteries are charging. Always follow these basic
precautions:

• Do not leave your computer, ac power adapter, or accessories in contact
with your lap or any part of your body for an extended period when the
products are functioning or when the battery is charging. Your computer,
ac power adapter, and many accessories produce some heat during normal
operation. Extended contact with the body could cause discomfort or,
potentially, a skin burn.

• Do not charge the battery or operate your computer, ac power adapter, or
accessories near fl ammable materials or in explosive environments.

viii

• The adapter will produce a lot of heat during operation. Be sure to
expose the adapter to air. Do not cover the adapter with anything that
would prevent heat from dissipating.

Attention

•

:

Place the power adapter out of reach of children.

Power supply statement

Never remove the cover on a power supply or any part that has the
following label attached.

Verwijder nooit de klep van een voedingseenheid of een ander onderdeel
waarop het volgende etiket is geplakt.

Nunca remova a cobertura de uma fonte de alimentação ou qualquer peça
que tenha a seguinte etiqueta anexada.

Fjern aldrig dækslet på en strømforsyningsenhed eller nogen anden del,
hvor følgende mÆrkat sidder på:

Verwijder nooit de klep van een voedingseenheid of een ander onderdeel
waarop het volgende etiket is geplakt.

Älä irrota virtalähteen suojakuorta tai muita osia, joissa on seuraava tarra.

Ne retirez jamais le couvercle d’une alimentation électrique ou de toute
pièce sur laquelle l’étiquette suivante est apposée.

Die Abdeckung des Netzteils oder einer Komponente, die mit dem
folgenden Etikett versehen ist, darf niemals entfernt werden.

ix

Non rimuovere il coperchio di un alimentatore o qualsiasi parte su cui è posta
la seguente etichetta.

NenoƼemiet barošanas bloka vƗku vai citu daƺu, uz kuras atrodas šƯ uzlƯme.

Niekada nenuimkite maitinimo ar kitos dalies, prie kurios priklijuotas šis lipdukas, dangtelio.

Du må aldri ta av dekselet på en strømforsyningsenhet eller del som har dette
merket:

Nunca retire a tampa de uma fonte de alimentação ou de qualquer
componente que apresente a seguinte etiqueta.

No retire nunca la cubierta de una fuente de alimentación o componente
que muestre la etiqueta siguiente.

Ta aldrig bort kåpan från nätaggregatet eller från någon annan del som är
märkt med följande etikett:

x

Hazardous voltage, current, and energy levels are present inside any
component that has this label attached. There are no serviceable parts inside
these components. If you suspect a problem with one of these parts, contact
a service technician.

Er zijn gevaarlijke spannings-, stroom-, en energieniveaus aanwezig in iedere
component waarop dit etiket is geplakt. In deze componenten bevinden zich
geen onderdelen die kunnen worden gerepareerd of vervangen. Als er een
probleem is met een van deze componenten, neemt u contact op met een
onderhoudstechnicus.

Voltagem perigosa, corrente elétrica e níveis de energia estão presentes dentro
de qualquer componente que tenha essa etiqueta anexada. Não há peças
passíveis de manutenção dentro desses componentes. Se suspeitar que há
problemas com uma dessas peças, entre em contato com um técnico de serviço.

xi

Der er farlig spænding, strøm og farlige energiniveauer i alle komponenter,
hvor denne mærkat sidder på. Disse komponenter indeholder ingen dele, der
kan udskiftes eller repareres. Kontakt en servicetekniker, hvis du mener, der
er problemer med en af disse dele.

Er zijn gevaarlijke spannings-, stroom-, en energieniveaus aanwezig in iedere
component waarop dit etiket is geplakt. In deze componenten bevinden zich
geen onderdelen die kunnen worden gerepareerd of vervangen. Als er een
probleem is met een van deze componenten, neemt u contact op met een
onderhoudstechnicus.

Osissa, joissa on tämä tarra, on vaarallinen jännite. Näissä osissa ei ole
huollettaviksi tarkoitettuja komponentteja. Jos epäilet näiden osien olevan
viallisia, ota yhteys huoltoteknikkoon.

Présence de tensions, de courants et de niveaux d’énergie dangereux dans
tout composant sur lequel cette étiquette est apposée. Aucune pièce de ces
composants n’est réparable. Si vous pensez qu’ils peuvent être à l’origine d’un
incident, contactez un technicien de maintenance.

In Komponenten, die dieses Etikett aufweisen, treten gefährliche Spannungen
und Energien auf. Diese Komponenten enthalten keine Teile, die gewartet
werden müssen. Besteht der Verdacht eines Fehlers an einem dieser Teile, ist
ein Kundendiensttechniker zu verständigen.

All’interno di qualsiasi componente che presenta questa etichetta sono presenti
livelli pericolosi di energia, corrente e voltaggio. Non vi sono parti per cui è

xii

prevista assistenza in questi componenti. Se si sospetta un problema con una
di queste parti, contattare un tecnico del servizio di assistenza.

To komponentu iekšpusƝ, uz kuriem atrodas šƯ uzlƯme, ir bƯstams spriegums, strƗva un
jauda. Šajos komponentos nav daƺu, kam bnjtu nepieciešama apkope. Ja ir radušƗskƗdas
daƺas darbƯbas problƝmas, sazinieties ar apkopes tehniƷi.

Komponento, prie kurio priklijuotas šis lipdukas, Ƴtampa, srovơ ir energijos išskyrimo tankis
yra pavojingi. Šiǐ komponentǐ viduje prižinjrimǐ daliǐ nơra. Jei Ƴtariate, kad su viena iš šiǐ
daliǐ kilo problemǐ, kreipkitơs Ƴ aptarnavimo specialistą.

Farlig spenning, strømstyrke og energinivåer er tilstede i komponenter som har
denne etiketten påklistret. Ingen av disse komponentene inneholder deler som
kan repareres. Hvis du får problemer med en av disse delene, må du kontakte
en servicetekniker.

Presença de tensões, corrente e níveis de energia perigosos no interior de
qualquer componente que apresente esta etiqueta. Nenhum componente
existente no interior destes componentes requer qualquer ajuste ou manutenção
por parte do utilizador. Se suspeitar de algum problema relacionado com
algum destes componentes, contacte um técnico do serviço de assistência.

xiii

Los componentes que muestran esta etiqueta presentan niveles de energía,
corriente y voltaje peligrosos. Estos componentes no tienen piezas de
recambio. Si sospecha que existe algún problema en alguna de estas piezas,
póngase en contacto con el servicio técnico.

Det fi nns ström med farlig spänningsnivå och strömstyrka inuti enheter som
är märkta med denna etikett. De här enheterna innehåller inga delar som du
kan justera eller reparera själv. Om det blir fel på någon av dessa enheter
kontaktar du servicetekniker.

xiv

About this book

This manual contains instructions for installing, confi guring, and
troubleshooting the Lenovo
into two parts:

Part 1: Installation and user ’s guide

This guide contains the product description and expanded installation
instructions.

Part 2: Appendixes

The appendixes contain help and service information, as well as the
product warranties and notices.

Note

: The illustrations in this manual might be slightly different from your

hardware.

®

AC Adapter. This manual is divided

xv

xvi

English

Installation and user’s guide

The Lenovo AC Adapter powers your notebook computer using a standard ac
power cord. It also charges your notebook computer baĴ ery.

Product description

This package includes:

• One Lenovo AC Adapter

• One standard AC power cord

• Safety information

• User’s Guide

The adapter has a cable extending from one end of the adapter that connects to
your notebook computer.

Using the adapter

The power adapter can be connected to a standard AC electrical socket. During
operation, if the power adapter detects a fault, such as a short circuit or high
temperature, the power adapter will shut down automatically to prevent damage.

Notes:

1. When the adapter shuts down due to a fault it will be latched oě until the
fault is removed AND the adapter is disconnected from the power source for
at least 10 seconds.

2. The adapter needs adequate ventilation for proper operation. It is normal for
the adapter to be warm to touch during use.

Connecting the adapter to a standard AC electrical outlet

To use the power adapter with a standard electrical outlet, complete these steps:

1. Plug the smaller end of the AC power cord (see

2. Insert the large end of the cord into the standard electrical outlet, (see

illustration below).

3. Insert the smaller, yellow-tipped connector into the power connector of your
notebook computer (see
computer is charging by checking the power icon on the system tray on the
computer display. The icon displays as a plug if the computer is charging or as
a baĴ ery if it is not.

in the illustration below). Make sure the notebook

in the illustration below).

in the

1
