PARTS GUIDE MANUAL
APRIL 2008
pagepro 4650EN
A0DX011
INFORMATION FOR PARTS GUIDE MANUAL
To find correct Parts No., refer to the “HOW TO MAKE THE BEST USE OF THIS MANUAL” in the following page.
HOW TO MAKE THE BEST USE OF THIS MANUAL
1 When you order, please check the proper figures beforehand that are on Our Parts Guide Manual, and order with the appropriate figures.
2 For screws, Nuts, Washers, retaining rings and Pins which are used in this model, one letter is shown on the Standard parts column of Parts list and
exploded diagrams.
3 In order to maintain safety of the product, some specific parts composed of this product are set up as "essential safety parts".
4 The assigned parts number for the "essential safety parts" is indicated as "SP00-****".
When replacing these parts, follow precautions for disassembling and installing which are listed in the Service Manual.
Do not use any parts that are not set up as
5 means that there are exclusive parts for each destination.
Please check the appropriate destination when you order.
6 Revision Mark
Marked as on the illustration shows that the revision has been made.
7 All rights reserved. (any reprints or quotations are prohibited.)
Use of this parts guide manual should be strictly supervised to avoid disclosure of confidential information.
10/22/2007
SYSTEM OUTLINE
Parts Guide Manual "pagepro 4650EN" includes PF-505, AD-508 and SF-603.
OPTION PF-505
OPTION SF-603
OPTION AD-508
1
2
3
pagepro 4650EN
GENERAL CONTENTS
No. Description Model
1
2
3
4
PRINTER B/W pagepro 4650EN
PRINTER B/W pagepro 5650EN
OTHER OPTION HD-512
OTHER OPTION MK-717
pagepro 4650EN
DIAGRAM OF MAIN PARTS SECTION
pagepro 4650EN
CONTENTS
No. DESCRIPTION PAGE No.
1 EXTERNAL PARTS P1
2 150 PAPER CASSETTE P2
3 550 PAPER CASSETTE P3
4 PAPER FEED SECTION P4 P5
5 P/H FUSING SECTION P6
6 PAPER EXIT SECTION P7 P8
7 DRIVE SECTION P9
8 ELECTRICAL COMPONENTS P10
9 PF-505 P11 P12 P13
10 AD-508 P14
11 SF-603 P15
pagepro 4650EN
INDEX
1/1
Parts No. Page No.
A00F 9420 00 1-10
A0DX 9401 00 1-11
A0DX M710 05 10-6
A0DX M71A 01 1-1
A0DX PP00 00 11-5
A0DX PP01 00 2-5
A0DX PP02 00 12-4
A0DX PP03 00 5-8
A0DX PP06 00 5-1
A0DX PP07 00 5-7
A0DX PP08 00 15-2
A0DX PP09 00 3-3
A0DX PP09 00 13-3
A0DX PP0A 00 2-4
A0DX PP0B 01 15-12
A0DX PP0E 00 15-10
A0DX PP0F 00 15-4
A0DX PP0H 00 6-2
A0DX PP0J 00 8-1
A0DX PP0K 00 2-6
A0DX PP0M 00 3-4
A0DX PP0N 00 10-2
A0DX PP0P 01 10-2
A0DX PP0S 00 15-7
A0DX PP0T 00 10-3
A0DX PP0U 00 10-4
A0DX PP0V 00 11-3
A0DX PP0W 00 1-3
A0DX PP0Y 00 5-2
A0DX PP10 00 4-2
A0DX PP10 00 5-6
A0DX PP11 00 4-1
A0DX PP11 00 5-4
A0DX PP11 00 12-2
A0DX PP12 00 15-8
A0DX PP13 00 14-3
A0DX PP14 00 14-6
A0DX PP15 00 10-5
A0DX PP18 00 11-1
A0DX PP19 00 9-1
Parts No. Page No.
A0DX PP1A 00 15-6
A0DX PP1B 00 15-11
A0DX PP1C 00 6-5
A0DX PP1F 00 14-7
A0DX PP1G 00 4-5
A0DX PP1H 00 11-7
A0DX PP1J 00 15-5
A0DX PP1K 00 14-5
A0DX PP1M 01 15-1
A0DX PP1N 00 1-4
A0DX PP1P 00 9-2
A0DX PP1Q 00 4-7
A0DX PP1R 00 2-2
A0DX PP1R 00 3-2
A0DX PP1R 00 4-4
A0DX PP1R 00 5-5
A0DX PP1R 00 12-1
A0DX PP1R 00 13-2
A0DX PP1S 00 6-4
A0DX PP1T 00 6-4
A0DX PP20 00 2-1
A0DX PP20 00 3-1
A0DX PP20 00 13-1
A0DX PP21 00 1-9
A0DX PP22 01 15-3
A0DX PP23 00 1-7
A0DX PP24 00 1-5
A0DX PP25 00 11-6
A0DX PP26 01 14-4
A0DX PP27 01 14-1
A0DX PP28 01 14-2
A0DX PP29 01 14-8
A0DX PP2A 00 6-3
A0DX PP2C 00 2-3
A0DX PP2G 00 11-4
A0DX PP2H 00 4-3
A0DX PP2H 00 5-3
A0DX PP2H 00 7-2
A0DX PP2H 00 12-3
A0DX PP2H 00 15-9
Parts No. Page No.
A0DX PP2M 00 11-2
A0DX PP2N 00 6-1
A0DX PP2P 00 1-6
A0DX PP2Q 00 1-8
A0DX PP2S 01 10-1
A0DX PP2U 00 4-6
A0DX PP2X 01 1-2
A0DX PP2Y 00 7-1
A0DX PP31 00 7-3
A0DX PP33 00 10-8
A0DX PP38 01 10-1
A0FM 011 10-7
A0FM 0Y1 10-7
pagepro 4650EN
EXTERNAL PARTS
P 1
Please refer Page.10-Key.8 for parts described as "S" or "E".
SW3
1
9
4
5
6
10
11
7
2
8
3
pagepro 4650EN
EXTERNAL PARTS
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX M71A 01 OPERATION PANEL 34PPM I1
2 A0DX PP2X 01 KIT TOP COVER C1
3 A0DX PP0W 00 SWITCH I/L ASSY C1
4 A0DX PP1N 00 COVER REAR 34PPM C1
5 A0DX PP24 00 COVER RIGHT C1
6 A0DX PP2P 00 COVER FRONT C1
7 A0DX PP23 00 COVER LEFT C1
8 A0DX PP2Q 00 COVER STOPPER C1
9 A0DX PP21 00 COVER OPEN C1
10 A00F 9420 00 Label Logo Mark C1
11 A0DX 9401 00 Label pagepro4650 C1
Page. 1
pagepro 4650EN
150 PAPER CASSETTE
P 2
Please refer Page.10-Key.8 for parts described as "S" or "E".
1
2
3
5
4
6
pagepro 4650EN
150 PAPER CASSETTE
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP20 00 COVER CST C1
2 A0DX PP1R 00 ROLL ASSY RETARD C1
3 A0DX PP2C 00 SPRING RETARD C1
4 A0DX PP0A 00 GUIDE END 150 C1
5 A0DX PP01 00 HOLDER ASSY RETARD C1
6 A0DX PP0K 00 150 PAPER CASSETTE C1
Page. 2
pagepro 4650EN
550 PAPER CASSETTE
P 3
Please refer Page.10-Key.8 for parts described as "S" or "E".
1
2
3
4
pagepro 4650EN
550 PAPER CASSETTE
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP20 00 COVER CST C1
2 A0DX PP1R 00 ROLL ASSY RETARD C1
3 A0DX PP09 00 GUIDE END 550 C1
4 A0DX PP0M 00 550 PAPER CASSETTE C1
Page. 3
pagepro 4650EN
PAPER FEED SECTION
P 4
Please refer Page.10-Key.8 for parts described as "S" or "E".
PS1
CL3
CL1
1
1
2
3
4
4
6
5
7
pagepro 4650EN
PAPER FEED SECTION
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP11 00 CLUTCH ASSY PH C2
2 A0DX PP10 00 ACTUATOR NO PAPER C1
3 A0DX PP2H 00 SENSOR OCT I1
4 A0DX PP1R 00 ROLL ASSY RETARD C2
5 A0DX PP1G 00 SENSOR TONER ASSEMBLY C1
6 A0DX PP2U 00 KIT CHUTE REGI C1
7 A0DX PP1Q 00 150 FEEDER ASSY C1
Page. 4
pagepro 4650EN
PAPER FEED SECTION
P 5
Please refer Page.10-Key.8 for parts described as "S" or "E".
PS4
PS3
CL2
1
4
3
5
5
6
3
2
7
8
pagepro 4650EN
PAPER FEED SECTION
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP06 00 GUIDE TRAY RIGHT D1
2 A0DX PP0Y 00 ACTUATOR C1
3 A0DX PP2H 00 SENSOR OCT I2
4 A0DX PP11 00 CLUTCH ASSY PH C1
5 A0DX PP1R 00 ROLL ASSY RETARD C2
6 A0DX PP10 00 ACTUATOR NO PAPER C1
7 A0DX PP07 00 GUIDE TRAY LEFT C1
8 A0DX PP03 00 550 FEEDER ASSY C1
Page. 5
pagepro 4650EN
P/H FUSING SECTION
P 6
Please refer Page.10-Key.8 for parts described as "S" or "E".
FM2
1
2
3
4
5
pagepro 4650EN
P/H FUSING SECTION
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP2N 00 HARNESS ASSY ROS 34PPM D1
2 A0DX PP0H 00 ROS ASSY 34PPM I1
3 A0DX PP2A 00 BTR ASSY C1
4 A0DX PP1S 00 FUSER ASSY 34PPM 110V B,H C 1
4 A0DX PP1T 00 FUSER ASSY 34PPM 220V C,D,D1,D3,J,K C 1
5 A0DX PP1C 00 FAN SUB B1
Page. 6
pagepro 4650EN
PAPER EXIT SECTION
P 7
Please refer Page.10-Key.8 for parts described as "S" or "E".
PS6
PS7
1
2
2
3
pagepro 4650EN
PAPER EXIT SECTION
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP2Y 00 COVER EXIT 500 C1
2 A0DX PP2H 00 SENSOR OCT I2
3 A0DX PP31 00 500 EXIT ASSY C1
Page. 7
pagepro 4650EN
PAPER EXIT SECTION
P 8
FACE UP TRAY
Please refer Page.10-Key.8 for parts described as "S" or "E".
1
pagepro 4650EN
PAPER EXIT SECTION
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP0J 00 COVER REAR 500 34PPM C1
Page. 8
pagepro 4650EN
DRIVE SECTION
P 9
Please refer Page.10-Key.8 for parts described as "S" or "E".
M1
1
2
pagepro 4650EN
DRIVE SECTION
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP19 00 MAIN MOTOR 34PPM C1
2 A0DX PP1P 00 GEAR ASSY HOUSING 34PPM C1
Page. 9
pagepro 4650EN
ELECTRICAL COMPONENTS
P 10
Please refer Page.10-Key.8 for parts described as "S" or "E".
PRCB
MFPB
FM1
SW2
SW1
DCPU
1
2
3
4
5
6
7
8
pagepro 4650EN
ELECTRICAL COMPONENTS
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP2S 01 HVPS/MCU 34PPM 1200DPI 110V B,H I 1
1 A0DX PP38 01 PWB ESS 34PPM C,D,D1,D3,J,K I 1
2 A0DX PP0N 00 LVPS 110V B,H I 1
2 A0DX PP0P 01 LVPS 220V C,D,D1,D3,J,K I 1
3 A0DX PP0T 00 POWER SWITCH C1
4 A0DX PP0U 00 INTERLOCK S/W REAR C1
5 A0DX PP15 00 FAN MAIN C1
6 A0DX M710 05 Controller PWB assembly I1
7 A0FM 011 Maintenance Kit 110V B,H B 1
7 A0FM 0Y1 Maintenance Kit 220V C,D,D1,D3,J,K B 1
8 A0DX PP33 00 KIT SCREW C1
Page. 10
pagepro 4650EN
PF-505
P 11
Please refer Page.10-Key.8 for parts described as "S" or "E".
SW1
M1
PCCB
1
2
3
4
5
5
6
7
pagepro 4650EN
PF-505
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP18 00 MOTOR FEEDER C1
2 A0DX PP2M 00 HARNESS ASSY FDR2 D1
3 A0DX PP0V 00 OPT ASSY SIZE C1
4 A0DX PP2G 00 FRAME CVR L550 C1
5 A0DX PP00 00 FOOT C2
6 A0DX PP25 00 FRAME CVR R550 C1
7 A0DX PP1H 00 PWBA FEEDER 550 I1
Page. 11
pagepro 4650EN
PF-505
P 12
Please refer Page.10-Key.8 for parts described as "S" or "E".
PS1
CL1
CL2
1
1
2
2
3
4
pagepro 4650EN
PF-505
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP1R 00 ROLL ASSY RETARD C2
2 A0DX PP11 00 CLUTCH ASSY PH C2
3 A0DX PP2H 00 SENSOR OCT I1
4 A0DX PP02 00 550 FEEDER OPTION C1
Page. 12
pagepro 4650EN
PF-505
P 13
Please refer Page.10-Key.8 for parts described as "S" or "E".
1
2
3
pagepro 4650EN
PF-505
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP20 00 COVER CST C1
2 A0DX PP1R 00 ROLL ASSY RETARD C1
3 A0DX PP09 00 GUIDE END 550 C1
Page. 13
pagepro 4650EN
P 14
Please refer Page.10-Key.8 for parts described as "S" or "E".
M1
ADCB
FM1
PS1
1
2
3
4
5
6
7
8
AD-508
pagepro 4650EN
AD-508
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP27 01 COVER TOP C1
2 A0DX PP28 01 COVER LEFT C1
3 A0DX PP13 00 MOTOR DUPLEX C1
4 A0DX PP26 01 COVER HSG DUP C1
5 A0DX PP1K 00 PWBA DUPLEX I1
6 A0DX PP14 00 FAN DUPLEX C1
7 A0DX PP1F 00 SENSOR DUP I1
8 A0DX PP29 01 COVER RIGHT C1
Page. 14
pagepro 4650EN
SF-603
P 15
Please refer Page.10-Key.8 for parts described as "S" or "E".
M1
PS1
SD1
SW1
M2
OCTCB
1
2
3
4
7
6
5
8
9
10
12
11
pagepro 4650EN
SF-603
Key Part No. Description Destinations Class QTY Standard parts
1 A0DX PP1M 01 COVER OCT C1
2 A0DX PP08 00 WEIGHT D1
3 A0DX PP22 01 COVER REAR C1
4 A0DX PP0F 00 ROLL OCT LOWER C1
5 A0DX PP1J 00 PWBA OCT I1
6 A0DX PP1A 00 MOTOR ASSY OFFSET C1
7 A0DX PP0S 00 S/W REAR COVER C1
8 A0DX PP12 00 SOLENOID ASSY GATE C1
9 A0DX PP2H 00 SENSOR OCT I1
10 A0DX PP0E 00 ROLL OCT UPPER C1
11 A0DX PP1B 00 MOTOR ASSY OCT C1
12 A0DX PP0B 01 TRAY ASST OCT C1
Page. 15
pagepro 4650EN
MAINTENANCE LIST
The items with no Page/Key numbers are not handled as spare parts.
1/1
No. Section PM Parts Description Maintenance Cycle (K=1,000) Parts No. Destinations Page/Key Note
1 - Maintenance Kit 110V *3 1 200K *1 A0FM011 for 4650EN, 110 V P10-7 *2
2 Maintenance Kit 220V *3 1 200K *1 A0FM0Y1 for 4650EN, 220 V P10-7 *2
*1: Continuous printing, B/W ratio: 5 %
*2: For details about maintenace procedure of lower feeder unit, see the optional lower feeder unit service manual.
*3: The Maintenance kit includes Rollers(for feed roller, pick-up roller and separation roller),Transfer roller and Fuser unit.
QTY Replace
pagepro 4650EN
DESTINATION
Destination No. Destinations V Hz Model No.
A1 JAPAN 100 50/60
A
A2 JAPAN 200 50/60
B USA, CANADA 120 60 A0DX-011
C EUROPEAN TYPE 220-240 50/60 A0DX-021
D
F
G
D1 S.E ASIA TYPE
D3 OCEANIA TYPE AUSTRALIA, NEW ZEALAND 220-240 50/60 A0DX-041
EPHILIPPINES 220-240 50/60
F1 SAUDI ARABIA 127 60
F2 SAUDI ARABIA 220-240 50/60
G1 C.S AMERICA 220-240 50/60
G2 C.S AMERICA 120 60
HTAIWAN 110 60 A0DX-011
JORDAN, LEBANON, SYRIA, SOUTH AFRICA, IRAQ, IRAN, N.YEMEN, CAME-
I
J CHINA 220-240 50/60 A0DX-041
KKOREA 220-240 50/60 A0DX-041
ROON, UAE, BAHRAIN, OMAN, QATAR, KUWAIT, KENYA, TUNISIA, IVORY
COAST, MOROCCO
THAILAND, SRI LANKA, SINGAPORE, MALAYSIA, HONG
KONG, PAKISTAN, INDIA, BANGLADESH, INDONESIA
220-240 50/60 A0DX-041
220-240 50/60
pagepro 4650EN
Loading...
