Lennox LSM40EN-PV, LSM45EN-PV User Manual

CARE AND OPERATION INSTRUCTIONS

▪

F

▪

R

▪

E

▪

E

▪

▪

See Page 2 For Details

▪

SAFETY

GUARD

PROTECTS AGAINST BURNS

AVERTISSEMENT : Assurez-vous de bien suivre les
instructions données dans cette notice pour réduire au
minimum le risque d’incindie ou d’explosion ou pour
éviter tout dommage matériel, toute blessure ou la mort.

WARNING: If the information in these instructions
is not followed exactly, a fire or explosion may
result, causing property damage, personal injury,
or death.

WARNING /AVERTISSEMENT/AVISO

• HOT GLASS WILL CAUSE
BURNS.

• DO NOT TOUCH GLASS
UNTIL COOLED.

• NEVER ALLOW CHILDREN
TO TOUCH GLASS.

• UNE SURFACE VITRÉE CHAUDE
PEUT CAUSER DES BRÛLURES.

• LAISSER REFROIDIR LA SURFACE
VITRÉE AVANT D'Y TOUCHER.

• NE PERMETTEZ JAMAIS À UN ENFANT
DE TOUCHER LA SURFACE VITRÉE.

• EL VIDRIO CALIENTE
CAUSARÁ QUEMADURAS.

• USTED DEBE NUNCA
TOCAR EL VIDRIO CALIENTE.

• LOS NIÑOS DEBEN NUNCA
TOCAR EL VIDRIO.

- Do not store or use gasoline or other flammable

vapors and liquids in the vicinity of this or any other
appliance.

- WHAT TO DO IF YOU SMELL GAS:

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any

phone in your building.

• Immediately call your gas supplier from a

neighbor’s phone. Follow the gas supplier’s
instructions.

• If you cannot reach your gas supplier, call the fire

department.

- Installation and service must be performed by a
qualified installer, service agency or the gas supplier.

- Ne pas entreposer ni utilizer d’essence ni d’autres vapeurs
ou liquides inflammables dans le voisinage de cet appareil
ou de tout autre appareil.

- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ :

• Ne pas tenter d’allumer d’appareil.

• Ne touchez à aucan interrupteur. Ne pas vous servir des

téléphones se trouvant dans le bâtiment où vous trouvez.

• Appelez immédiatement votre fournisseur de gaz depuis

un voisin. Suivez les instructions du fournisseur.

• Si vous ne pouvez rejoindre le fournisseur de gaz,

appelez le service des incindies.

- L’installation et l’entretien doivent être assurés par un
installateur ou un service d’entretien qualifié ou par le
fournisseur de gaz.

P/N 506025-02 Rev. C 06/2011

This manual is one of a set of two supporting this product.
Refer to P/N 506023-09 for Installation Instructions.

Ce manuel est disponible en francais, simplement
en faire la demande. Numéro de la pièce 506223-30.

WHAT'S INSIDE

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Safety and Your Fireplace. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

FREE Safety Guard Offer (Protects Against Burns) . . . . . . . . . . . . . . . . . 2

Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Attaching the Safety-in-Operation Warnings . . . . . . . . . . . . . . . . . . . . . 5

[EN FRANÇAIS] L’information de sûreté importante . . . . . . . . . . . . . . . 3–4

Apposition des mises en garde relatives à la sécurité d’utilisation . . . . 5

[EN ESPAÑOL] Información importante de seguridad . . . . . . . . . . . . . . 3–4

Colocación de advertencias de seguridad en operación . . . . . . . . . . . . 5

Wait...

DON’T
THROW
IT AWAY!

This manual contains

important operating

and safety

information.

INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.

INSTALLATEUR : Laissez cette notice avec l'appareil.
CONSOMMATEUR : Conservez cette notice pour consultation ultérieure.

Montebello Power Vent
DV Gas Fireplaces

MODELS

LSM40EN-PV LSM45EN-PV

US

OTL Report No. 116-F-22-5

ELECTRONIC:

Portland

TM

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

Thank you for your purchase. We appreciate your business!
Please carefully read and follow all instructions in this manual.

Pay special attention to all warnings and safety information.

Following these safety, care, and operation instructions will help
ensure many years of dependable and enjoyable service from
your fireplace.

Safety and

Your Fireplace

All parts of your Lennox

•

FREE

severe burns and injuries by preventing direct contact

To receive your FREE SAFETY GUARD, call 1-800-786-7976

or visit www.lennox.com

SAFETY GUARD

The Lennox® SAFETY GUARD protects against

with the front glass surface of your fireplace.

(Lennox Hearth Products / Owner Resources)

OFFER

TABLE OF CONTENTS

Safety and Your Fireplace. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Attaching the Safety-in-Operation Warnings . . . . . . . . . . . . . . . . . . . . . 5

Appliance Installation, Service, and Maintenance Notices . . . . . . . . . . . . . 6

Appliance Operation Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

BTU Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Gas Pressure Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Orifice Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Burn-In Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Operation and Care of Your Appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Appliance Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Gas Controls / Control Compartment Access . . . . . . . . . . . . . . . . . . . . . 8

Purge Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Lighting Electronic Appliances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Power Vent Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Variable Flame Height Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Front Glass Enclosure Panel Removal/Installation . . . . . . . . . . . . . . . . . . 11

Log, Volcanic Stone, and Glowing Ember Placement . . .. . . .. . . . . . . . . . 12

Burner Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Flame Appearance and Sooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Air Shutter Adjustment Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Burner Air Shutter Adjustment Procedure . . . . . . . . . . . . . . . . . . . . . . 15

Electronic Appliance Checkout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Ordering Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Product Reference Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Accessory Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Operating (Lighting) Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Troubleshooting Guide: Electronic Gas Control System . . . . . . . . . . . . . . 22

Troubleshooting Guide: Power Vent System . . . . . . . . . . . . . . . . . . . . . . 23

Replacement Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Replacement Parts Illustrations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Power Vent Replacement Parts and Illustrations . . . . . . . . . . . . . . . . . . . . 26

•

Hearth Products fireplace

get EXTREMELY HOT!

 To prevent severe burns and injuries, install

a screen or physical barrier to prevent direct
contact with the glass.

To order a FREE Lennox® SAFETY GUARD
for your fireplace, see details at left.

 Follow the safety instructions below

and be sure everyone in your household
understands this burn hazard:

•The surfaces on your fireplace get
EXTREMELY HOT!

•The glass on the front
of the fireplace reaches
EXTREMELY HIGH
temperatures and can
cause severe burns if touched.

•Keep children away from an operating
fireplace. Closely supervise children in
any room where a fireplace is operating
to prevent contact with glass.

•Keep clothing, furniture,
gasoline, and other
flammable liquids away
from the fireplace.

•Even after the gas is turned off, fireplace
surfaces remain extremely hot.

 Be sure to attach the enclosed Safety-in-

Operation Warnings where you turn on your

fireplace, to help remind everyone of the
dangers associated with high temperatures
(see Page 5).

 Read Important Safety Information on

Page 4.

2

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

[FRENCH] [SPANISH]

La sécurité et

votre foyer

Toutes les parties de votre foyer

Lennox Hearth Products deviennent

EXTRÊMEMENT CHAUDES !

 Afin d'éviter de vous brûler gravement ou de

vous blesser, installez une grille ou une barrière
physique pour empêcher tout contact direct
avec la vitre.

Pour commander un PANNEAU DE PROTECTION
Lennox® GRATUIT pour votre foyer, consultez
les détails dans la partie gauche.

 Suivez les instructions de sécurité ci-dessous

et veillez à ce que tous les membres de votre
famille soient conscients du danger de brûlure
encouru :

•Les surfaces de votre foyer deviennent
EXTRÊMEMENT CHAUDES !

•La vitre située à l'avant du foyer
atteint des températures
EXTRÊMEMENT ÉLEVÉES et peut causer
de graves blessures en cas de contact.

•Tenez les enfants à l'écart du foyer lorsqu'il
fonctionne. Surveillez attentivement
les enfants dans les pièces où un foyer
est utilisé afin d'éviter qu'ils ne soient
en contact avec la vitre.

•Tenez tous les vêtements, les
meubles, l'essence et tout autre
liquide inflammable à l'écart du foyer.

•Même après fermeture du gaz, les surfaces
du foyer restent extrêmement chaudes.

Seguridad y

su chimenea

¡Todas las partes de la chimenea

Lennox Hearth Products se ponen

MUY CALIENTES!

 Instale una malla o barrera física para evitar

el contacto directo con el vidrio y prevenir
las quemaduras y lesiones graves.

Ver los detalles a la izquierda para ordenar
un Lennox® SAFETY GUARD GRATIS
para su chimenea.

 Siga las instrucciones de seguridad a

continuación y asegúrese de que todos
en su hogar sepan acerca de este peligro
de quemadura:

•¡Las superficies de la chimenea se ponen
MUY CALIENTES!

•El vidrio delante de la chimenea alcanza
temperaturas EXTREMADAMENTE ALTAS y
puede causar quemaduras graves si se toca.

•Mantenga a los niños alejados de la
chimenea en funcionamiento. Supervise
en forma cercana a los niños en cualquier
cuarto donde haya una chimenea
funcionando para impedir el contacto
con el vidrio.

•Mantenga la ropa, mobiliario, gasolina
y otros líquidos inflamables alejados
de la chimenea.

•Aún después de haber apagado el gas,
las superficies de la chimenea permanecen
extremadamente calientes.

 Veillez à coller les Étiquettes de mise en garde

relatives à la sécurité d'utilisation à l'endroit

où vous utilisez le foyer, pour rappeler à tous les
utilisateurs les dangers liés aux températures
élevées (voir Page 5).

 Lisez la section Informations importantes

relatives à la sécurité, Page 4.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

 Asegúrese de colocar las Etiquetas de

advertencia de seguridad de operación en

el lugar donde enciende la chimenea, para
que todos recuerden los peligros asociados
con las altas temperaturas (ver la página 5).

 Lea la Información importante de seguridad

en la página 4.

3

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

Important Safety Information

1. WARNING: Do not operate appliance with the glass front
removed, cracked or broken. Replacement of the glass
should be done by a licensed or qualified service person .

2. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect
the appliance and to replace any part of the control system
and any gas control which has been under water.

3. Due to high temperatures, the appliance should be located
out of traffic and away from furniture and draperies.

4. Children and adults should be alerted to the hazards of
high surface temperature and should stay away to avoid
burns or clothing ignition.

5. Clothing or other flammable material should not be placed
on or near the appliance.

6. Young children should be carefully supervised when they
are in the same room as the appliance. Toddlers, young
children, and others may be susceptible to accidental
contact burns. A physical barrier is recommended if there
are at-risk individuals in the house. To restrict access to a
fireplace or stove, install an adjustable safety gate to keep
toddlers, young children, and other at-risk individuals out
of the room and away from hot surfaces.

7. Any safety screen or guard removed for servicing an
appliance must be replaced prior to operating the
appliance.

8. Installation and repair should be done by a qualified
service person. The appliance should be inspected
before use and at least annually by a professional service
person. More frequent cleaning may be required due to
excessive lint from carpeting, bedding material, et cetera.
It is imperative that control compartments, burners, and
circulating air passageways of the appliance be kept
clean. See maintenance instructions on Page 10.

L'information de sûreté importante

1. AVERTISSEMENT. Ne pas utiliser l’appareil si le panneau frontal
en verre n’est pas en place, est craqué ou brisé. Confiez le
remplacement du panneau à un technicien agréé

2. Ne pas utiliser cet appareil s’il a été plongé, même partiellement,
dans l’eau. Appeler un technicien qualifié pour inspecter
l’appareil et remplacer toute partie du système de commande
et toute commande qui a été plongée dans l’eau.

3. En raison des températures élevées, l’appareil devrait être
installé dans un endroit où il y a peu de circulation et loin du
mobilier et des tentures.

4. Les enfants et les adultes devraient être informés des dangers
que posent les températures de surface élevées et se tenir à
distance afin d’éviter des brûlures ou que leurs vêtements ne
s’enflamment.

5. On ne devrait pas placer de vêtements ni d’autres matières
inflammables sur l’appareil ni à proximité.

6. Les jeunes enfants devraient être surveillés étroitement lorsqu’ils
se trouvent dans la même pièce que l’appareil. Les tout petits,
les jeunes enfants ou les adultes peuvent subir des brûlures s’ils
viennent en contact avec la surface chaude. Il est recommandé
d’installer une barrière physique si des personnes à risques
habitent la maison. Pour empêcher l’accès à un foyer ou à un
poêle, installez une barrière de sécurité ; cette mesure empêchera
les tout petits, les jeunes enfants et toute autre personne à risque
d’avoir accès à la pièce et aux surfaces chaudes.

7. Tout écran ou protecteur retiré pour permettre l’entretien de
l’appareil doit être remis en place avant de mettre l’appareil en
marche.

8. L’installation et la réparation devrait être confiées à un technicien
qualifié. L’appareil devrait faire l’objet d’une inspection par un
technicien professionnel avant d’être utilisé et au moins une
fois l’an par la suite. Des nettoyages plus fréquents peuvent
être nécessaires si les tapis, la literie, et cetera produisent
une quantité importante de poussière. Il est essentiel que les
compartiments abritant les commandes, les brûleurs et les
conduits de circulation d’air de l’appareil soient tenus propres.
Voyez les instructions d’entretien à la Page 10.

[SPANISH]

Información importante de seguridad

1. ADVERTENCIA: No opere el artefacto con el frente de vidrio quitado,
agrietado o roto. Un técnico de servicio licenciado o capacitado
debe reemplazar el vidrio.

2. No use este artefacto si alguna de sus partes ha estado bajo agua.
Llame de inmediato a un técnico de servicio calificado para que
inspeccione el artefacto y reemplace cualquier parte del sistema
de control y cualquier control de gas que haya estado bajo agua.

3. Debido a las altas temperaturas, el artefacto debe situarse fuera
de las áreas de tráfico y lejos del mobiliario y cortinas.

4. Se debe alertar a los niños y adultos sobre los peligros de
las altas temperaturas en la superficie y que se mantengan
alejados para evitar quemaduras o ignición de la ropa.

5. No debe colocarse ropa u otros materiales inflamables

4

sobre y cerca del artefacto.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

6. Se debe supervisar de cerca a los niños cuando estén en el mismo
cuarto que el artefacto. Los niños pequeños, los jóvenes y otras
personas pueden ser susceptibles a quemaduras por contacto
accidental. Se recomienda instalar una barrera física si hay
personas en riesgo en la casa. Para restringir el acceso a una
chimenea o estufa, instale una puerta de seguridad ajustable
para mantener a los niños pequeños, jóvenes y otras personas
en riesgo fuera del cuarto y lejos de las superficies calientes.

7. Cualquier malla o resguardo de seguridad quitado para dar servicio
a un artefacto, debe reinstalarse antes de operar el artefacto.

8. Una persona de servicio competente debe realizar la instalación y
reparación. Una persona de servicio profesional debe inspeccionar
el artefacto antes de usar al menos una vez por año. Se puede
requerir limpieza más frecuente debido a la pelusa excesiva
del alfombrado, del material de cobijas, etc. Es imprescindible
mantener limpios los compartimientos de control, los quemadores
y los pasajes de circulación del aire del artefacto. Ver las
instrucciones de mantenimiento en la página 10.

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

HOMEOWNER’S INSTRUCTIONS - ATTACHING SAFETY-IN-OPERATION WARNINGS

ATTACHING SAFETY-IN-OPERATION
WARNINGS

Your fireplace has been furnished with safety instruc­tion labels that are to be affixed to the operation and
control point of the fireplace. A safety instruction
label should be affixed to the wall switch plate where
the fireplace is turned on and off (See Figure A) or
wall thermostat (See Figure B) and if used on the
remote control handheld transmitter (Figure C).
The warnings should already have been put in place
when the fireplace initial set-up was completed.
If they are not affixed at these spots, locate the
multi-lingual adhesive labels provided with these
instructions and proceed as follows:

1. Locate the wall switch or wall thermostat that
controls the fireplace (verify the switch operates
the fireplace by turning it on and off). Clean the
wall switch plate or wall thermostat thoroughly
to remove any dust and oils. Affix the label to
the surface of the plate of the wall switch that
controls the fireplace (Figure A) or the wall
thermostat (Figure B). Choose the language
primarily spoken in the home.

2. If a remote control is used to control the fireplace,
locate the transmitter and clean it thoroughly
to remove any dust and oils. Affix the label to
the surface of handheld transmitter (Figure C).
Choose the language primarily spoken in the
home.

3. If you are unable to locate the labels, please call
Lennox Hearth Products or your nearest Lennox
Hearth Products dealer to receive additional
safety instruction labels free of charge.

Cat. No. H8024 Replacement Label Kit

LENNOX HEARTH PRODUCTS
1-800-9-LENNOX

Note: English is red text on clear label. French and
Spanish are white text on black label.

APPOSITION DES MISES EN GARDE RELATIVES
À LA SÉCURITÉ D’UTILISATION

Votre foyer a été livré avec des étiquettes de sécurité qui
doivent être collées à côté des dispositifs de contrôle
du foyer. Une étiquette de sécurité doit être collée sur
la plaque de l’interrupteur contrôlant l’allumage du
foyer (voir Figure A) ou sur le thermostat mural (voir
Figure B) et, le cas échéant, sur le boîtier de la télé-
commande (Figure C). Les mises en garde auraient dû
être collées au moment de l’installation initiale du foyer.
Si ce n’est pas le cas, prenez les étiquettes adhésives
multilingues fournies avec ces instructions et procédez
comme suit:

1. Repérez l’interrupteur ou le thermostat mural
qui contrôle le foyer (vérifiez que l’interrupteur
contrôle le fonctionnement du foyer en le faisant
basculer de Marche à Arrêt, et vice-versa). Nettoyez
soigneusement la plaque murale de l’interrupteur
ou le thermostat mural pour éliminer la poussière
et les traces de graisse ou d’huile. Collez l’étiquette
sur la surface de la plaque de l’interrupteur mural
qui contrôle le foyer (Figure A) ou du thermostat
mural (Figure B). Choisissez la langue qui est
principalement parlée dans la résidence du
propriétaire.

2. Si une télécommande est utilisée pour contrôler
le foyer, nettoyez la soigneusement pour éliminer
la poussière et les traces de graisse ou d’huile.
Collez l’étiquette sur le boîtier de la télécommande
(Figure C). Choisissez la langue qui est principale-
ment parlée dans la résidence du propriétaire.

3. Si vous ne trouvez pas les étiquettes, veuillez
appeler Lennox Hearth Products ou votre distribu­teur Lennox Hearth Products local pour recevoir
gratuitement des étiquettes supplémentaires.

Étiquettes de remplacement, n° cat. H8024

LENNOX HEARTH PRODUCTS
1-800-9-LENNOX

Remarque : Le texte anglais est rouge sur un support
transparent. Le texte français et espagnol est blanc
sur un support noir.

COLOCACIÓN DE ADVERTENCIAS DE SEGURIDAD
EN OPERACIÓN

Su chimenea incluye etiquetas de instrucciones de
seguridad que deben colocarse en el punto de operación
y control de la chimenea. Se debe colocar una etiqueta de
instrucciones de seguridad en la placa del interruptor de
pared desde el cual se enciende y se apaga la chimenea

(ver la Figura A) o en el termostato de pared (ver la Figura
B) y en el transmisor de control remoto (Figura C) si

se usa. Las advertencias ya deben haberse colocado
cuando se completó la instalación inicial de la chimenea.
Si no están colocadas en estos lugares, encuentre las
etiquetas adhesivas multilingües proporcionadas con
estas instrucciones y prosiga de la siguiente manera:

1. Identifique el interruptor o el termostato de pared
que controla la chimenea (verifique que el interruptor
opera la chimenea encendiéndola y apagándola).
Limpie bien la placa del interruptor o el termostato de
pared para quitar el polvo y aceite. Pegue la etiqueta
en la superficie de la placa del interruptor que controla
la chimenea (Figura A) o en el termostato de pared
(Figura B). Seleccione el idioma que más se habla
en la casa.

2. Si se usa un control remoto para controlar la
chimenea, encuentre el transmisor y límpielo bien
para quitar el polvo y aceite. Pegue la etiqueta en la
superficie del transmisor (Figura C). Seleccione el
idioma que más se habla en la casa.

3. Si no puede encontrar las etiquetas, sírvase llamar a
Lennox Hearth Products o al distribuidor de Lennox
Hearth Products más cercano para recibir etiquetas
de instrucciones de seguridad adicionales gratuitas.

Juego de etiquetas de repuesto - Nº de cat. H8024

LENNOX HEARTH PRODUCTS
1-800-9-LENNOX

Nota: La etiqueta en inglés es transparente con texto
rojo. Las etiquetas en francés y español son negras
con texto blanco.

SAFETY LABEL

DIAGRAMS

DIAGRAMMES DES ÉTIQUETTES

DE SÉCURITÉ

Figure A Figure B Figure C

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

DIAGRAMAS DE ETIQUETAS

DE SEGURIDAD

5

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

APPLIANCE INSTALLATION, SERVICE,
AND MAINTENANCE NOTICES

IMPORTANT: Improper installation,
adjustment, alteration, service, or
maintenance can cause injury or property
damage. Refer to this manual. For
assistance or additional information,
consult a qualified installer, service
agency or the gas supplier.

Only trim kit(s) supplied by the manufac­turer shall be used in the installation of
this appliance.

Draft relief openings must not be covered
or blocked.

These appliances must not be connected
to a chimney or flue serving a separate
solid fuel burning appliance.

Any change to this appliance and/or
its operating controls is dangerous.
Improper installation or use of this
appliance can cause serious injury or
death from fire, burns, explosion or
carbon monoxide poisoning.

CARBON MONOXIDE POISONING: Early
signs of carbon monoxide poisoning are
similar to the flu with headaches, dizzi­ness and/or nausea. If you have these
signs, obtain fresh air immediately.
Turn off the gas supply to the appliance
and have it serviced by a qualified
professional, as it may not be operating
correctly. Some people are more
affected by carbon monoxide than others,
including pregnant women, people with
heart or lung disease or anemia, those
under the influence of alcohol, and those
at high altitudes.

APPLIANCE OPERATION NOTICES

Do not operate appliance with the glass
front removed, cracked, or broken.

These fireplaces are vented gas appli­ances. Do not burn wood or other
material in these appliances.

This appliance is only for use with the
type of gas indicated on rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.

These appliances are designed to operate
on natural gas or propane gas only. The
use of other fuels or combinations of
fuels will degrade the performance of this
system and may be dangerous.

Provide adequate clearances around
air openings and adequate accessibility
clearance for service and proper opera­tion. Never obstruct the front openings
of the appliance.

Do not use this appliance if any part has
been under water. Immediately call a
qualified service technician to inspect
the appliance and to replace any part of
the control system and any gas control
that has been under water.

These fireplaces are designed as supple­mental heaters. Therefore, it is advisable
to have an alternate primary heat source
when installed in a dwelling.

WARRANTY INFORMATION

Your gas appliance is covered by a limited
twenty-year warranty. You will find a copy of
the warranty accompanying this manual. Please
read the warranty to be familiar with its coverage.

Retain this manual. File it with your other docu­ments for future reference.

Failure to comply with the installation
and operating instructions provided
will result in an improperly installed
and operating appliance, voiding its
warranty.

Do not attempt to alter or modify
the construction of the appliance or
its components. Any modification
or alteration may void the warranty,
certification, and listings of this unit.

Turn off gas and electrical power to the
fireplace and allow it to cool before
cleaning or servicing the appliance.

The vent termination is hot while in
operation and for a period of time fol­lowing the use of the fireplace. Young
children should be carefully supervised
when they are in the same area as a hot
termination

6

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

GENERAL INFORMATION

The fireplace models covered in this manual are
direct-vent, sealed combustion gas fireplaces
designed for residential application. Direct­vent appliances operate with the combustion
chamber completely isolated from the indoor
environment.

All air for combustion is brought in from the
outside and exhaust gases are vented through
the same direct-vent, co-axial (intake/exhaust)
vent system.

These electronic appliances are designed to
operate on natural gas or propane and have
an electronic intermittent pilot ignition system.
External 120 Volt AC electrical power is is
required to operate these units.

These appliances comply with National Safety
Standards and are tested and listed by OMNI­Test Laboratories, Inc. (Report No. 116-F-22-5)
to ANSI Z21.50b in the USA.

The Installation must conform to local codes or,
in the absence of local codes, with the National

Fuel Gas Code, ANSI Z223.1/NFPA 54 - latest
edition. The appliance, when installed, must

be electrically grounded in accordance with
local codes or, in the absence of local codes,
with the National Electrical Code, ANSI/NFPA
70 - latest edition.

BTU Input

Electronic models come standard with a
manually-modulated gas valve; flame appear­ance and heat output can be controlled at the
gas valve. The BTU Input for these appliances
is shown in Table 1.

Input (BTU/HR) - All Models

Model No. Input (BTU/Hr)

Natural Gas

LSM40EN-PV 32,500 to 42,000
LSM45EN-PV 32,500 to 42,000

Propane Gas (if field converted)

LSM40EN-PV field-

converted to propane

LSM45EN-PV field-

converted to propane

30,000 to 40,500

30,000 to 40,500

Table 1

Gas Pressure Requirements - All Models

Tables 2 and 3 show the appliances' gas pres-
sure requirements.

Inlet Gas Supply Pressure

(all models)

Fuel # Minimum Maximum

Natural Gas

Propane

5.5" WC

(1.37 kPa)

11.0" WC

(2.74 kPa)

10.5" WC

(2.61 kPa)

13.0" WC

(3.23 kPa)

Table 2

Manifold Gas Supply Pressure

(all models)

Fuel # Low High

Natural

Gas

Propane

(Lo) 2.2" WC

(.55 kPa)

(Lo) 6.3" WC

(1.57 kPa)

(Hi) 3.5" WC

(.87 kPa)

(Hi) 10.0" WC

(2.49 kPa)

Table 3

Test gauge connections are provided on the
front of the gas control valve, identified IN for
the inlet and OUT for the manifold side (see
Figure 3 on Page 6). The control valve has a
3/8" (10 mm) NPT thread inlet and outlet side
of the valve.

These appliances must be isolated from
the gas supply piping system (by closing
their individual manual shut-off valve)
during any pressure testing of the gas
supply piping system at test pressures
equal to or less than 1/2 psig (3.5 kPa).

These appliances and their individual
shut-off valves must be disconnected
from the gas supply piping system dur­ing any pressure testing of that system
at pressures greater than 1/2 psig (3.5
kPa).

Orifice Sizes - Sea Level to High Altitude

(All Models): These appliances are tested and

approved for installations at elevations of 0-2000
feet (0-610 meters) above sea level using the
standard burner orifice sizes (marked with an
asterisk [*] in Table 4).

At the time of installation, it must be determined
if the appliance needs to be derated. Contact
your local gas supplier for deration requirements
for your area.

Burner Orifice Size

Elevation 0-2000 ft. (0-610m)

Model Natural Gas Propane Gas

LSM40-PV

LSM45-PV

Table 4

Deration

At higher elevations, the amount of BTU fuel
value delivered must be reduced by either using
gas that has been derated by the gas company
or by changing the burner orifice to a smaller
size as regulated by the local authorities having
jurisdiction and by the (USA) National Fuel Gas
Code NFPA 54/ANSI Z223.1 - latest edition.

.125" (1/8") *

H7924•

.125" (1/8") *

H7924•

* Standard size installed at factory

•Part/Cat.Number

.073" (#49)

•

H7936

.073" (#49)

•

H7936

Burn-in Period

During the first few fires of this appliance there
will be some odor due to the curing of the
paint and burning off of lubricants used in the
manufacturing process. Depending on your
use, the burn-in period may take a few hours
or a few days.

KEEP YOUR HOUSE WELL VENTILATED
DURING THE CURING PROCESS. THE ODOR
AND HAZE EMITTED DURING THE CURING
PROCESS CAN BE QUITE NOTICEABLE AND
MAY SET OFF A SMOKE DETECTOR.

NOTICE: A white film may develop

on the glass enclosure panel during
the first few fires as part of the burn-in
process.

The first few times you use the
fireplace, clean the glass after each use
(AFTER THE GLASS HAS COMPLETELY
COOLED); otherwise, the white film
will bake onto the glass and become
difficult to remove.

See glass cleaning instructions on
Page 8.

7

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

OPERATION AND CARE OF YOUR APPLIANCE

WARNING

Young children should be carefully supervised when they are in the
same room as the appliance. Toddlers, young children and others
may be susceptible to accidental contact burns. A physical barrier is
recommended if there are at risk individuals in the house. To restrict
access to a fireplace or stove, install an adjustable safety gate to keep
toddlers, young children and other at risk individuals out of the room
and away from hot surfaces.

AVERTISSEMENT

Les jeunes enfants devraient être surveillés étroitement lorsqu’ils se trou­vent dans la même pièce que l’appareil. Les tout petits, les jeunes enfants
ou les adultes peuvent subir des brûlures s’ils viennent en contact avec
la surface chaude. Il est recommandé d’installer une barrière physique
si des personnes à risques habitent la maison. Pour empêcher l’accès
à un foyer ou à un poêle, installez une barrière de sécurité; cette mesure
empêchera les tout petits, les jeunes enfants et toute autre personne à
risque d’avoir accès à la pièce et aux surfaces chaudes.

Gas Controls / Control Compartment
Access

The gas controls can be found on the right hand
side of the appliance as shown in Figure 1.

The standard controls for appliance operation
are located behind the panel on the right side as
shown in Figure 1. Optional control switches
are also available (see Page 15 - remote wall
switch, remote control or wall thermostat).

Right Side

Modesty Panel

Access Plate

Hi-Lo

Extension Knob

Gas Valve

Appliance Operation

To light the appliance refer to the detailed lighting
instructions (see Pages 17 and 18). The appli-
ance lighting instructions may also be found on
the pull out lighting instruction labels attached
to the gas control valve.

These appliance are fitted with an ON/OFF rocker
switch for appliance ON/OFF control. See Figure
1 for its location. Once the pilot is lit, the ON/
OFF rocker switch will control the appliance ON/
OFF operation. To operate: Toggle the switch
between its ON and OFF positions.

If your appliance is equipped with an optional
remote switch kit, wall switch, remote control or
wall thermostat, the appliance main burner may
be turned on and off using the optional switch.

Note: To prevent excessive resistance in burner
circuit (which can cause burner operation prob­lems), only one burner control switch should
be wired to valve.

PURGE CYCLE

This is a power vented fireplace that
requires household electrical power
to operate. It will not operate during
a power failure. When the fireplace
is turned off, the exhaust blower will
continue to operate for approximately
one to two minutes after shutdown
to expel the exhaust gases from the
venting system.

ON/OFF Switch

Control
Compartment
Access

Figure 1

8

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

16.17

(411 mm)

15.92

(404 mm)

10.00

(254 mm)

(284 mm)

HI

LO

Lighting Electronic Appliances

To light electronic appliances refer to the detailed lighting instructions found on Page 17 of these
instructions respectively. Electronic appliance lighting instructions may also be found on the
pull out lighting instruction labels attached to the gas control valve.

Electronic appliances are fitted with an ON/OFF rocker switch for appliance ON/OFF control. See
Figure 1 for its location.

Once the pilot is lighted, the ON/OFF rocker switch will control the appliance ON/OFF operation. To
operate: Toggle the switch between its ON and OFF positions.

POWER VENT OPERATING INSTRUCTIONS

Power Vent Control Sequences

Turn On

1. Turn On The Thermostat Or On/Off Switch.

2. Blower Should Start Immediately.

3. Igniter Starts Sparking And Pilot Will Light.

4. Burner Should Light After A Few Seconds.

5. Fireplace Should Run Continuously Until Thermostat Or On/Off Switch Is Turned Off.

Turn Off

1. Turn Off The Thermostat Or On/Off Switch.

2. Burner And Pilot Should Be Off Immediately.

3. Blower Will Continue To Run For About 90 Seconds And Then The Blower Will Stop.

Gas Supply Inlet

Inlet Pressure
Gauge Port

Manifold
Pressure
Gauge Port

Gas Outlet to Burner

Hi / Lo
Variable Flame
Height
Adjustment

Pilot
Adjustment
Screw

Figure 3 - SIT Electronic Gas Valve

Variable Flame Height Adjustment

These appliances are equipped with a variable
gas control valve. Flame height for these models
may be adjusted through a range between fixed
low and high settings, alternately, while the
appliance is in operation. Use the extension
knob (refer to Figure 1), to adjust the flame
height as desired by sliding the knob over the
variable flame adjustment knob located on the
front of the valve (refer to Figures 1 and 3).
Replace the extension knob back to the hanger
after the adjustment.

15.92

(404 mm)

Figure 2 - Power Vent Specifications

13.50

(343 mm)

Top View

16.17

(411 mm)

Front View

11.19

10.00

Note: Dimensions Are In Inches (mm)

(254 mm)

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

9

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

MAINTENANCE

(See Maintenance Schedule, Page 19)

Refer to the maintenance schedule for
maintenance tasks, procedures, frequency and
by whom they should be performed. Always
verify proper operation of the appliance after
servicing.

WARNING

Turn off gas and electrical power
to the fireplace and allow it to
cool before cleaning or servicing
the appliance.

CAUTION: Wear gloves and safety glasses
for protection while doing required
maintenance.

Verify proper operation after servicing.

S'assurer que l'appareil fonctionne adé­quatement une fois l'entretien terminé.

Before re-lighting the fireplace, refer
to the lighting instructions in this
manual. Instructions are also found on
pull-out panels located in the control
compartment.

Inspect Venting System

The appliance and venting system should be
thoroughly inspected before initial use and
at least annually by a qualified service techni­cian (inspection should include ensuring that
exhaust or intake passages are unobstructed
and vent components are properly assembled
and not damaged). Homeowner must contact

a qualified service technician at once if any
abnormal condition is observed.

If the venting system is disassembled for any
reason, a qualified service technician should
follow vent installation instructions for proper
reassembly and proper sealing of the venting
system components. However, more frequent
periodic inspections and cleanings should be
performed by the homeowner.

Glass Cleaning

(See Front Glass Enclosure Panel, Removal and
Installation on Page 9).

Note: Clean glass after first two weeks of opera-
tion (after Burn-In period is over) and then only
when necessary and when the fireplace is cool.
Wipe surface with clean, dampened, soft cloth.
Follow with a dry, soft towel as desired. Take
care not to scratch the glass surface.

IMPORTANT: Do not use abrasive clean­ers on glass. Never clean the glass when
it is hot.

The viewing glass should be cleaned periodi­cally to remove any build-up caused from the
following:

• During start-up, it is normal for condensa­tion to form on the inside of the glass (this
condensation and fog will usually disappear
in a few minutes). The moisture can cause
lint, dust and other airborne particles to cling
to the glass surface.

• Initial curing of the high temperature paint

and burning off of lubricants used in the
manufacturing process may result in a film
on the glass.

• A white coating may form on the glass as a

result of impurities and minerals in the fuel.

It is recommended that the glass be cleaned
two or three times during each heating season,
depending on the circumstances present. The
following cleaning solutions are approved for use
to clean glass:

• Non-ammonia based household cleaner

• 50%-50% mix of white vinegar & water

• Gas replace/stove glass cleaner

Inspect Glass Gasket - Visually inspect the
gasket on the backside of the glass enclosure
panels. The gasket surface must be clean, free
of irregularities and seated firmly.

Clean Control Compartment

Keep control compartment clean by vacuuming
or brushing at least twice a year. More frequent
cleaning may be required due to excessive lint
from carpeting, bedding materials, etc. It is
important that control compartments, burners
and circulating air passageways of the appliance
be kept clean.

Clean Logs and Burner

Carefully remove the logs (use care when han­dling the fiber logs, as they become quite fragile
after curing). Vacuum out any foreign matter
(lint, carbon, etc.) on the burner. Ensure the
burner ports are “open.” Remove any carbon
deposits from the under side of the logs using
a vacuum cleaner, or a soft bristled brush (i.e.
paint brush).

Replacing Logs

If the logs become damaged by accident or
improper handling and need replacement, use
only the proper replacement logs from manu­facturer (see Pages 22 and 23 for ordering
information).

Re-install Embers, Volcanic stone and Logs

Carefully follow placement instructions on
Pages 10 and 11). All logs should fit onto
corresponding pins and/or log stoppers. This
will ensure a proper flame and safe combustion.

Inspect Wiring

Refer to wiring diagrams on Page 14.

CAUTION: Label all wires prior to discon­nection when servicing controls. Wiring
errors can cause improper and dangerous
operation. Verify proper operation after
servicing.

ATTENTION: Au moment de l'entretien des
commandes, étiquetez tous les fils avant
de les débrancher. des erreurs de cáblage
peuvent entraîner un fonctionnement
inadéquat et dangereux.

Inspect and clean all wire connections. Ensure
that there is no melting or damage. Inspection
should include:

• Terminals at the Valve

• OFF/ON Switch

• (Optional Control Switch) Wall Thermostat,

Remote Control or Remote Wall Switch

Inspect Burner Flame Appearance

Ensure that the burner flame appearance
resembles the flame shown in Figures 13 or

14 and as described in Flame Appearance and
Sooting on Page 12. The Homeowner must

contact a qualified service technician at once
if any abnormal condition is observed.

Small Area Paint Touch-up

Only use a factory supplied paint kit for touch­ups. Paint is available at your local authorized
Lennox Hearth Products dealer. Never attempt
to paint a hot fireplace.

If the surface later becomes stained or marred,
it may be lightly sanded and touched up with
spray paint.

10

Note: Improper positioning of logs can create
carbon build-up and will alter the performance
of the appliance.

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

Front Glass Enclosure Panel Removal
and Installation

WARNING

• When reinstalling the glass

door, the door latch screws
must be securely tightened
to prevent the glass door
from falling out, which could
potentially cause damage and
possible injury.

• Do not attempt to substitute the

materials used on this door,
or replace cracked or broken
glass.

• Handle this glass with extreme

care! Glass is susceptible to
damage – Do not scratch or
handle roughly while reinstall­ing the glass door frame.

• The glass door of this appli-

ance must only be replaced
as a complete unit as provided
by the manufacturer. Do not
attempt to replace broken,
cracked or chipped glass sepa­rately.

• Do not attempt to touch the

front enclosure glass with your
hands while the fireplace is in
use.

WARNING

Do not operate appliance with
the glass front removed, cracked
or broken.

AVERTISSEMENT

Ne pas utiliser l'appareil si le
panneau frontal en verre n'est
pas en place, est craqué ou
brisé.

WARNING

Any safety screen or guard
removed for servicing the appli­ance must be replaced prior to
operating the appliance.

AVERTISSEMENT

Tout écran ou protecteur retiré
pour permettre l’entretien de
l’appareil doit être remis en
place avant de mettre l’appareil
en marche.

Only doors certified with the appliance
shall be used.

Seules des portes certifiées pour cet
appareil doivent être utilisées.

CAUTION: DO NOT abuse glass door by
striking or slamming shut.

These are direct-vent appliances. They are
designed to operate only when the front glass
enclosure panel is installed. Generally the front
glass enclosure panel should not be removed
except to gain access to the components within
the firebox.

Removing Glass Enclosure Panel
(see Figure 4)

To remove the firescreens, lift up the center of
the rod to disengage it from the center bracket,
bend down at center, hold left side with hand
until it disengages from left side, being careful
not to scratch paint. Slowly remove the rod
from the right side.

Remove the door modesty shield from the top
flange glass door by pulling it up firmly with both
hands until it is disengaged. Using a phillips
screwdriver, unfasten two (2) screws located
at the top of the glass frame.

Tilt the glass frame at the top away from the
unit. Lift it carefully off the bottom door track
and set the door aside, protecting it from in­advertent damage.

To install the front glass door assembly,
proceed as follows:

1. Retrieve the glass door assembly. Visually

inspect the gasket on the backside of the
panel. The gasket surface must be clean,
free of irregularities and seated firmly.

2. Position the door frame in front of the firebox

opening and engage the bottom flange over
the rail at the bottom of the firebox opening.

3. Swing the door up and back. Ensure the

gasket seats evenly as the door draws shut.
Engage the nut insert and fasten with two
screws to secure the door.

4. Install the door modesty shield on top flange

glass door as follows: grab the door modesty
shield with both hands, with the open hem
going down and engage it with the upper lip
of the glass door frame by pushing it all the
way down. Make sure the installed shield
is firmly in place.

5. With the firescreen hanging on the screen

rod, drop in the right side of the rod to the
right modesty panel. Then drop in the left
side of the rod through the slot of the left
modesty panel. Make sure that the rod is
supported by the bracket in the center of the
fireplace.

Top Flange Glass Door
Frame Assembly

Screws

Firebox Floor

Glass Door Assembly

Figure 4

Glass Door Latch (2)

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

11

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

LOG, VOLCANIC STONE AND GLOWING EMBER PLACEMENT

WARNING

• DO NOT attempt to install the logs until the

appliance installation has been completed, the
gas line connected and tested for leaks and the
initial burner operation has been checked out.
The size and position of the log set was engi-

•

neered to give the appliance a safe, reliable
and attractive flame pattern. Any attempt to use
a different log set in the fireplace will void the
warranty and will result in incomplete combus­tion, sooting, and poor flame quality.
Logs get very hot and will remain hot up to one

•

hour after gas supply is turned off. Handle only
when logs are cool. Turn off all electricity to
the appliance before you install grate, volcanic
stone, embers and logs.
This appliance is not designed to burn wood.

•

Any attempt to do so could cause irreparable
damage to the appliance and prove hazardous
to your safety.
If logs are not installed according to the log

•

installation instructions, flame impingement and
improper combustion could occur and result in soot
and/or excessive production of carbon monoxide
(CO), a colorless, odorless, toxic gas.

REFERENCE - Firebox Accessories / Parts

Cat. No. Model Description

88L53 FGE Bag of Glowing Embers
80L42 FDVS Bag of Volcanic Stone

Figure 5

For Propane Gas Only, Do Not Place Embers On Main Ports

Step 1. Install the ceramic panels, if necessary, per the instructions

provided in kit (reference form #750182M).

Step 2. Place the volcanic stone around the burner as shown in Figure

7.

Step 3. Separate the glowing embers (rockwool) into pieces about the size

of a quarter (see Figure 5). Keep the pieces fluffed, not matted.
Distribute these pieces over the burner as shown in Figure 6.
Do not use more than necessary. When properly positioned,

the Glowing Embers will cover approximately 75% of the burner

on natural gas. For propane gas, do not place embers on main
ports.

Note: Excessive use of embers may result in sooting or poor flame.
This appliance is provided with enough Glowing Embers for several
applications, do not feel compelled to use all that is in a new bag. For
best glowing effect, replace the ember material annually. Replacement
Glowing Embers are available (Catalog Number 88L53).

Step 4. Position the individual logs as shown in Figures 8 through 12.

Logs should be placed in the order shown. Place logs 2 and 3
against the pins on the grate, NOT over them.

Proper log and twig placement is critical to encourage outstand-

ing flame appearance and prevent sooting. When positioned
properly as shown, twigs will be positioned between flame
peaks and will not impinge any flames. Positioning is the same
for all colors of log sets.

Glowing Embers (Rockwool)

Figure 6

Volcanic Stone

Figure 7 - (LSM45-PV Shown)

12

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

LSM40-PV & LSM45-PV Log Placement

2

6

Figure 8

3

7

5

1

Log Number Description

1 Log, Center
2 Log, Rear
3 Log, Center/Left
4 Log, Center/Right
5 Log, Rear/Top
6 Log, Front/Left
7 Log, Front/Center

2

4

Figure 10

Align Groove At The Bottom Of Log (2) Over
The Grate And Push It Towards The Rear.

3

4

Figure 9

1

Align Two Holes At Bottom Of Log (1)
Over The Pins On The Gas Burner.

Engage Logs (3 & 4) With The Grate Pins And Align Groves At
The Bottom Of The Logs Over The Grate.

Figure 11

6 5

Engage Log (6) With The Grate Pin
And Align Groove At The Bottom Of
The Log Over The Grate.

Align Hole At Bottom Of Log (5)
Over The Pin On Log (2).

Engage Log (7) With
The Pin On Log (4).

Figure 12

7

2

4

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

13

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

BURNER ADJUSTMENTS

(QUALIFIED TECHNICIANS ONLY)

Flame Appearance and Sooting

Proper flame appearance is a flame which is
blue at the base and becomes yellowish-orange
in the body of the flame. When the appliance
is first lit, the entire flame may be blue and will
gradually turn yellowish-orange during the first
15 minutes of operation. After 15 minutes of
operation, if the flame is blue, or if the flame is
orange with evidence of sooting (black tip), the
air shutter opening may need to be adjusted.

If the air shutter opening is closed too far,
sooting may develop. Sooting is indicated by
black puffs developing at the tips of very long
orange flames. Sooting results in black deposits
forming on the logs, appliance inside surfaces
and on exterior surfaces adjacent to the vent
termination. Sooting is caused by incomplete
combustion in the flames and lack of combustion
air entering the air shutter opening. To achieve
a warm yellowish-orange flame with an orange
body that does not soot, the shutter opening
must be adjusted between these two extremes.

Air Shutter Adjustment Guidelines

• If there is smoke or soot present, rst

check the log set positioning to ensure that
the flames are not impinging on any of the
logs. If the log set is properly positioned
and a sooting condition still exists, then the
air shutter opening should be increased.

• The more offsets in the vent system, the larger

the air shutter opening will need to be.

• An appliance operated with the air shutter

opened too far, may have flames that appear
blue and transparent. These weak, blue and
transparent flames are termed anemic.

• Propane models may exhibit ames which

candle or appear stringy. If this is present
and persists, adjust the air shutter to a more
closed position, then operate the appliance
for a few more minutes to ensure that the
flame normalizes and the flames do not
appear sooty.

(Birch Logs Shown) LSM40-PV

Figure 13 - Burner Flame Appearance

(Rustic Oak Logs Shown) LSM45-PV

The following chart is provided to aid you in
achieving the correct air shutter adjustment
for your installation.

Air Shutter Adjustment Guidelines

Amount of

Primary Air

If air shutter is
closed too far

If air shutter is
open too far

Flame

Color

Flame will
be orange

Flame will
be blue

14

Figure 14 - Burner Flame Appearance

:

Air Shutter

Adjustment

Air shutter
gap should be
increased

Air shutter
gap should be
decreased

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

Burner Air Shutter Adjustment Procedure

WARNING

• Air shutter adjustment should
only be performed by a quali­fied professional service
technician.

• Ensure that the front glass

door assembly is in place and
sealed After adjustment.

CAUTION

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

Soot will be produced if the air
shutter is closed too much. Any
damage due to carboning result­ing from improperly setting the
air shutter is not covered under
the warranty.

The following paragraphs address burner
adjustment concerns and procedures.

When lit for the first time, this appliance will emit
a slight odor for an hour or two. This is due to
the “burn-in” of internal paints and lubricants
used in the manufacturing process.

Air Shutter
Opening

Venturi

Burner

Main Burner Factory Air Shutter

Opening Setting - Inches (millimeter)

Model Natural

LSM40-PV

LSM45-PV

Venturi

Orifice

Gas Valve

Propane

Gas

1/8 (3.18) 1/4 (6.35)
1/8 (3.18) 1/4 (6.35)

Gas

Figure 15

Electronic Appliance Checkout

To light the burner, refer to the lighting instruc­tions on Page 17. Ensure the igniter lights the
pilot. The pilot flame should engulf the flame
sensor as shown in Figure 16.

ELECTRONIC PILOT ASSEMBLY

Proper Pilot Flame Appearance

Pilot Hood

Flame
Sensor

Pilot
Nozzels

Igniter
Rod

Figure 16

Adjustment

To adjust the flame, move the adjustment air
shutter (located on the lower venturi) back or
forward to increase or reduce the air shutter
opening, respectively. Position the air shut-

ter to the factory setting as shown in Figure

15. Allow the burner to operate for at least 15

minutes. Observe the flame continuously. If it
appears weak or sooty as previously described,
adjust the air shutter until the flame appearance
is as desired.

Propane models may exhibit a flame pattern
that may candle or appear stringy. If this is
problematic or persists as the appliance is
continually operated, adjust the air shutter
open as described in the previous paragraphs.
Operate the appliance for a period of time as the
effect diminishes, ensuring that the appliance
does not develop sooty flames.

When satisfied that the appliance operates
properly, proceed to finish the installation. Leave
the control knob in “ON” position and turn the
remote switch “OFF.”

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

15

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

ORDERING REPLACEMENT PARTS

A complete parts list is found at the end of
this manual. Use only parts supplied from the
manufacturer.

With proper care and maintenance, your appli­ance will provide many years of enjoyment. If
you should experience any problem, first refer
to the troubleshooting guide in this manual. If
problem persists, contact your Lennox Hearth
Products dealer or distributor.

Normally, all parts should be ordered through
your Lennox Hearth Products distributor or
dealer. Parts will be shipped at prevailing prices
at time of order.
When ordering repair parts, always give the
following information:

1. The model number of the appliance.

2. The serial number of the appliance.

3. The part number.

4. The description of the part.

5. The quantity required.

6. The installation date of the appliance.

WIRING DIAGRAMS

Wiring diagrams are provided here for reference
purposes only. This information is also provided
on schematics attached directly to the appliance
on a pullout panel located within the control
compartment.

If you encounter any problems or have any

PRODUCT REFERENCE INFORMATION

questions concerning the installation or ap­plication of this system, please contact your
dealer or distributor.

LENNOX HEARTH PRODUCTS

We recommend that you record the important
reference information about your fireplace in
the space provided below.

1508 Elm Hill Pike, Suite 108
Nashville, TN 37210
visit us at www.Lennox.com
1-800-9-LENNOX

Please call Lennox Hearth Products for the
phone number of your nearest Lennox Hearth
Products dealer who will answer your questions
or address your concerns.

Fireplace Model Number ________________________________________________

Fireplace Serial Number _________________________________________________

Date Installed _________________________________________________________

Type of Gas Used in Fireplace ____________________________________________

Dealer Name _________________________________________________________

CAUTION: LABEL ALL WIRES PRIOR TO
DISCONNECTION WHEN SERVICING
CONTROLS. WIRING ERRORS CAN
CAUSE IMPROPER AND DANGEROUS
APPLIANCE OPERATION.

ATT ENTION: AU MOM ENT DE
L'ENTRETIEN DES COMMANDES,
ÉTIQUETEZ TOUS LES FILS AVANT DE
LES DÉBRANCHER. DES ERREURS
DE CÁBLAGE PEU-VENT ENTRAÎNER
UN FONCTIONNEMENT INADÉQUAT
ET DANGEREUX.

Pilot Burner
Igniter-Sensor
Assembly

Connector

Blue (20)

Ground

Green (12)

Purple (9)

Electronic Ignition

Control Board

White (6)

EV2 EV1

White (20)

Orange (20)

Black (20)

Green LED

Gas Valve

Item 45
Wire #2

Junction Box

Black

White

White (6)

Appliance Mounted

On/Off Switch

Wall-Mounted On/Off Switch (optional)

120 VAC

Transformer

120 V.

24 V.

Item 32 Wire #3

Black
White
Ground

Black (16)

Pressure

Switch

Red

Red

Black

Black

Field Installed

Exhaust
Blower
Control
Module

N/A

Item 63

Exhaust

Blower

Blower

(Field Installed)

To Igniter
Module

16

Figure 17 - Electronic Wiring Diagram

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

ACCESSORY COMPONENTS

Product Reference Information

Cat.

No.

H7773 LSM40EN-PV 307 lb. 57 cu. ft.

H7920 LSMPVK 32 lb. 7 cu. ft.

H7774 LSM45EN-PV 307 lb. 57 cu. ft.

H7920 LSMPVK 32 lb. 7 cu. ft.

Model Ship.

Wt.

LSM40EN-PV (2 boxes)

LSM45EN-PV (2 boxes)

Ship.

Volume

Standard Remote Control System

The Model RCL (Standard) Remote Control System,
features a simple OFF/ON control function for the
fireplace. This model includes a hand-held transmitter,
a remote receiver with wall-mount cover plate, and
all hardware required to install the unit. The remote
receiver can be wall or hearth mounted.

The transmitter has ON and OFF functions that are
activated by pressing either button on the face of
the transmitter. When a button on the transmitter
is pressed, a signal light illuminates briefly to verify
that a signal has been sent.

Model RCL is designed to operate with these electronic
ignition systems. The RCL offers ease of installation
and allows you to execute on-off commands to the
fireplace effortlessly with one simple motion.

The Model RCL comes complete with detailed operat­ing instructions.

Deluxe Remote Control System

The Model RCL-STAT (Deluxe) Remote Control
System has all of the features of the standard system
along with a larger LCD screen that presents access
to many enhancements, including battery power
level indicator, timer, mode of operation, thermo­static display including room temperature in either
metric of English units, flame indicator and clock.
Fully programmable, the Model RCL-STAT allows
for virtual command over nearly all operational and
temperature variables, using the hand held remote
control transmitter.

The Model RCL-STAT (Deluxe) remote control sys­tem is installed in the same manner as the standard
system and may be operated with these electronic
systems. The RCL-STAT comes complete with detailed
operating instructions.

Digital Wall Thermostat

The wall thermostat kit provides temperature control
for optimum comfort.

Wall Thermostat

Cat. No. Model No. Description

H4635 DWTK Wall Thermostat Kit,

White

ON/OFF Wall Switch Kit

The ON/OFF wall switch kit may be used to control the
operation of the fireplace burner as an alternative to
the unit mounted ON/OFF switch. Install the ON/OFF
wall switch in a convenient location near the fireplace.

ON/OFF Wall Switch Kit

Cat. No. Model Description

85L87 FWSK Wall Switch

Remote Control Kit, Standard

Cat. No. Model No. Description

H0249 RCL Remote Control System

(Standard)

(ref. Kit Instruction P/N 750127M)

Bag of Glowing Embers
Bag of Volcanic Stone

Replacement ember material and volcanic stone are
available for use with these appliances. Order them to
replace materials as part of the periodic maintenance
of the appliance.

Firebox Accessories

Cat. No. Model Description

88L53 FGE Bag of Glowing Embers
80L42 FDVS Bag of Volcanic Stone

(ref. FDVS Kit Instruction P/N 750010M)

Remote Control Kit, Deluxe

Cat. No. Model No. Description

H0251 RCL-STAT Remote Control System

(ref. Kit Instruction P/N 750129M)

(Deluxe)

P

T

A

N

I

Touch-Up Paint Kit

Repair of minor scratches and discoloration
of the appliances black painted surfaces may
be accomplished with the touch-up paint kit.

Touch-Up Paint (Black) Kit

Cat. No. Model Description

90L73 FTPK-B Black Paint Kit

(ref. Kit Instruction P/N 750050M)

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

17

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

ACCESSORY COMPONENTS CONTINUED

Brick Liner Kits

The brick panel liner kits include ceramic panels
of the side and rear walls. The panels have
brick-like features in relief.

Brick Liner Kits

LSM40-PV
H2219 BLKR-LSM40 Buff Rustic
H4801 BLK-REDR-LSM40 Red Rustic
H2220 BLKH-LSM40 Buff Herringbone
H4803 BLK-REDH-LSM40 Red Herringbone
H2221 BLKC-LSM40 Red Old Cottage
H2222 BLKB-LSM40 Black

LSM45-PV
H2223 BLKR-LSM45 Buff Rustic
H2224 BLKH-LSM45 Buff Herringbone
H2225 BLKC-LSM45 Red Old Cottage
H2226 BLKB-LSM45 Black
H4802 BLK-REDR-LSM45 Red Rustic
H4804 BLK-REDH-LSM45 Red Herringbone

(ref. Kit Instruction P/N 750182M)

Andiron Door Kits

The andiron kits attach to the grate assembly
without the use of hardware.

Log Sets

Choose from two finely crafted log sets with
detailing that replicates the natural look of
real wood.

Birch Logs

Rustic Oak

Log Sets

Cat. No. Model Description

LSM40-PV and LSM45-PV

H4799 LOG-OAK-LSM-2 Oak Log Set
H4800 LOG-BIR-LSM-2 Birch Log Set

Barrier Screen Kits

These Barrier Screen Panel kits can be installed
on the glass enclosure panel to help prevent
direct human contact with the hot glass surface.

Dual Arch Screen Kits

These Dual Arch screen kits can be installed
on the glass enclosure panel to help prevent
direct human contact with the hot glass surface.

Dual Arch Screen Kits

Cat. # Model Description
H5051 DASK-LSM40-2 Dual Arch Screen
H5054 DASK-LSM45-2 Dual Arch Screen

(ref. Kit Instruction P/N 750,184M)

Arch Screen Kits

These Arch Screen kits can be installed on the
glass enclosure panel to help prevent direct
human contact with the hot glass surface.

Arch Screen Kits

Cat. No. Model Description

H5053 ASK-LSM40-2 Arch Screen Kit
H5056 ASK-LSM45-2 Arch Screen Kit

(ref. Kit Instruction P/N 750,184M)

Fits Fireplace

Models

LSM40-PV &

LSM45-PV

(ref. Kit Instruction P/N 750,183M)

18

MISSION

Andiron Door Kits

CLASSIC

Catalog No. (Model)

Mission Classic

H2227

(AKM-LSM)

H2228

(AKC-LSM)

Barrier Screen Kits

Cat. No. Model Description

LSM40-PV

H4805 BSK40 Barrier Screen

LSM45-PV

H4806 BSK45 Barrier Screen

(ref. Kit Instruction P/N 750,184M)

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

Classic Screen Kits

These Screen kits can be installed on the glass
enclosure panel to help prevent direct human
contact with the hot glass surface.

Classic Screen Kits

Cat. No. Model Description

H5052 SK-LSM40-2 Classic Screen Kit

H5055 SK-LSM45-2 Classic Screen Kit

(ref. Kit Instruction P/N 750,184M)

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

OPERATING INSTRUCTIONS — ELECTRONIC

FOR YOUR SAFETY READ BEFORE OPERATING

WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY

RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

A. This appliance is equipped with an ignition device which

automatically lights the pilot. Do not try to light the pilot
by hand.

B. BEFORE OPERATING smell all around the appliance area

for gas. Be sure to smell next to the floor because some
gas is heavier than air and will settle on the floor.

WHAT TO DO IF YOU SMELL GAS

• Do not try to light any appliance.

• Do not touch any electric switch; do not use any phone

in your building.

OPERATING INSTRUCTIONS

1. STOP! Read the safety information above on this page.

2. Turn remote wall switch to "OFF" or set the thermostat to

lowest setting, if applicable.

3. Turn the ON/OFF switch to "OFF" if Step 2 is applicable,

this ON/OFF switch should always be in the "OFF" posi­tion.

4. Verify main line shut-off valve is open.

• Immediately call your gas supplier from a neighbor’s

phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the fire depart-

ment.

C. If any portion of this appliance does not operate as the

instructions indicate, do not try to repair it, call a qualified
service technician. Do not use tools. Force or attempted
repair may result in a fire or explosion.

D. Do not use this appliance if any part has been under

water. Immediately call a qualified service technician
to inspect the appliance and to replace any part of the
control system and any gas control which has been under
water.

6. Turn "ON" all electrical power to appliance (remote wall

switch), or set the thermostat to the desired setting, if ap­plicable.

7. Turn the ON/OFF switch on the appliance to "ON", if

Step 6 is not applicable.

8. If the appliance will not operate, follow the instructions

"To Turn Off Gas To Appliance" and call your service tech­nician or gas supplier.

HI

LO

Gas Valve

5. Wait five (5) minutes to clear out any gas. Then smell

for gas, including near the floor. If you smell gas, STOP!
Follow “B” in the safety information above (to the left) on
this label. If you don’t smell gas, go to the next step.

TO TURN OFF GAS TO APPLIANCE

1. For complete shut-down, turn remote wall switch to "OFF" or

set the thermostat to the lowest setting, if applicable.

2. Turn the ON/OFF switch to “OFF”, if Step 1 is not applicable.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

TO SHUT OFF

1. Turn off all electrical power

to the appliance (remote wall
switch) or set the thermostat to
the lowest setting, if applicable.

3. Close the main line shut-off valve.

19

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

INSTRUCTIONS D’ALLUMAGE — ELECTRONIC

POUR PLUS DE SÉCURITÉ LIRE AVANT DE METTRE EN MARCHE

AVERTISSEMENT. QUICONQUE NE RESPECTE PAS À LA LETTRE LES INSTRUCTIONS DANS LA PRÉSENTE NOTICE RISQUE
DE DÉCLENCHER UN INCENDIE OU UNE EXPLOSION ENTRAÎNANT DES DOMMAGES, DES BLESSURES OU LA MORT.

A. Cet appareil est muni d’un dispositif d’allumage qui allume

automatiquement la veilleuse. Ne tentez pas d’allumer la veil­leuse manuellement.

B. AVANT DE FAIRE FONCTIONNER: reniflez tout autour de

l’appareil pour déceler une odeur de gaz. Reniflez près du
plancher, car certains gaz sont plus lourds que l’air et peuvent
s’accumuler au niveau du sol.

QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ :

• Ne pas tenter d’allumer d’appareil.

• Ne touchez à aucun interrupteur; ne pas vous servir des

téléphones se trouvant dans le bâtiment.

INSTRUCTIONS DE MISE EN MARCHE

1. ARRÊTEZ ! Lisez les instructions de sécurité sur la portion

supérieure (à gauche) de cette étiquette.

2. Tournez l’interrupteur mural à la position d’arrêt “OFF” ou plaez

le thermostat

3. Tournez l’interrupteur "marche/arrêt"

à plssible, si requis.

à la position "arrêt" (Off) si

l'etape 2 est appropriee. Cet interrupteur "marche/arrêt" devrait
toujours être en position

"arrêt" (Off).

4. Assurez-vous que la soupape d "arrêt" de la canalisation prin-

cipale est ouverte.

HI

LO

• Appelez immédiatement votre fournisseur de gaz depuis un

voisin. Suivez les instructions du fournisseur.

• Si vous ne pouvez rejoindre le fournisseur, appelez le service

des incendies.

C. Si un élément de cette unité ne fonctionne pas tel que

décrit dans les instructions, n’essayez pas de le réparer,
appelez un technicien qualifié. N’utilisez-pas d’outils. Le
fait de forcer la manette ou de la réparer peut déclencher
une explosion ou un incendie.

D. N’utilisez pas cet appareil s’il a été plongé dans l’eau,

même partiellement. Faites inspecter l’appareil par un
technicien qualifié et remplacez toute partie du système
de contrôle et toute commande qui ont été plongés dans
l’eau.

6. Tournez l'interrupteur mural à distance à la position "marche"

(On) ou placez le thermostat à la temperature désarée, si
requis.

7. Tournez l'interupteur "marche/arrét" de l'appareil à la

position "marche" (On), si aucune odeur de gaz n a été
détectée à l'étape 6.

8. Si l’appareil ne se met pas en marche, suivre les instruc-

tions intitulées “Pour fermer
le gaz qui alimente l’appareil”
et appeler un technicien ou le
fournisseur de gaz.

POUR ÉTEINDRE L’APPAREIL

20

Vue De Face

5. Attendez cinq (5) minutes pour l’evacuation du gaz. Si vous

décelez une odeur de gaz ARRÊTEZ ! Retournez au point “B”
des consignes de sécurité au verso de cette plaque. Si vous ne
remarquez aucune odeur de gaz, passez à l’étape suivante.

COMMENT COUPER L’ADMISSION DE GAZ DE L’APPAREIL

1. Pour une fermeture complète, tournez l’interrupteur mural à la

position d’arrêt “OFF”.

2. Tournez la manette de réglage du gaz à la position d’arrêt “OFF”.

Ne la forcez pas.

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

1. Coupez tout le courant électrique

qui alimente l’appareil (interrupteur mural) ou placez le
thermostat

à la plus basse température, si requis.

3. Fermez la soupape d’arrêt de la canalisation principale.

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

MAINTENANCE SCHEDULE

Turn off gas and electrical power to the fireplace and allow it to cool before cleaning or servicing the appliance.

Annually (Before the onset of the Burning Season)

MAINTENANCE TASK ACCOMPLISHING PERSON PROCEDURE

Inspect/Clean Burner, Logs
and Controls

Check Flame Patterns and Flame Height Qualified Service Technician Refer to Figures 13 and 14 on Page 12 and verify the flame pattern and

Inspect/Clean Pilot and Burner Qualified Service Technician Refer to Figure 16 on Page 13. Remove any surface build-up on pilot

Check Vent System Qualified Service Technician Inspect the vent system at the top and at the base (within the firebox)

Appliance Checkout Qualified Service Technician Perform the appropriate appliance checkout procedure detailed in this

Replace Glowing Embers Homeowner/Qualified Service

Qualified Service Technician Inspect valve and ensure it is properly operating. Check piping for

leaks. Vacuum the control compartment, fireplace logs and burner area.

height displayed by the appliance conforms to the picture. Flames must
not impinge on the logs. Ensure flames are steady (not lifting or floating).

and burner assembly. Wipe the pilot nozzles, igniter/flame rod and hood.
Ensure the pilot flame engulfs the flame sensor as shown.

for signs of blockage or obstruction. Look for any signs of dislocation
or deterioration of the vent components. Note: Excessive condensation
can cause corrosion of caps, pipe & fittings (excessive condensation can
be caused by long lateral runs, too many elbows and/or exterior portions
of the system being exposed to cold weather). Also inspect wall straps
or plumbers's tape to ensure it is secure and in place.

manual.

Remove old ember materials (rockwool) and vacuum the ember place-

Technician

ment area. Place new embers per instructions on Page 10.

Periodically (After the Burning Season)

MAINTENANCE TASK ACCOMPLISHING PERSON PROCEDURE

Clean Firebox Interior Homeowner Carefully remove logs, rockwool and volcanic stone. Vacuum out interior

of the firebox. Clean firebox walls and log grate. Replace logs, rockwool
and volcanic stone as detailed in this manual.

Check Flame Patterns and Flame Height Homeowner Refer to Figures 13 and 14 on Page 12 and verify the flame pattern and

height displayed by the appliance conforms to the picture. Flames must
not impinge on the logs.

Check Vent System Homeowner Inspect the vent system at the top and at the base (within the firebox)

for signs of blockage or obstruction. Look for any signs of dislocation
of the vent components.

Clean Front Glass Enclosure Panel Homeowner Clean as necessary following the directions provided in this manual. DO

NOT TOUCH OR ATTEMPT TO CLEAN GLASS WHILE HOT.

21

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

TROUBLESHOOTING GUIDE - ELECTRONIC GAS CONTROL SYSTEM

Note: Before troubleshooting the gas control system, Ensure external gas shut off valve, located at gas supply inlet, (and wall

switch, if applicable), is in the “ON” position.

Important: Valve system troubleshooting should only be accomplished by a qualified service technician.

SYMPTOM POSSIBLE CAUSES CORRECTIVE ACTION

1. Nothing happens when ON/OFF switch is

turned on (pilot does not spark).

2. The main burner does not light and the

igniter is sparking.

A. Low voltage/or bad lead wires. Check voltage on AC terminals of module. The value

should be around 24 VAC. Confirm that wire con­nections are secure.

B. Damaged igniter wire. Check for visible cracked casing, cuts, etc.
C. Damaged pilot assembly. Check pilot assembly for visibly broken spark elec-

trode, etc.

D. Batteries Low Check voltage on D.C. terminal of batteries in remote

control. The value should be around 3.0V

A. No fuel supply. Ensure that the gas supply is turned on.
B. Loose sensor wire. Ensure sensor wire connection is secure to purple

wire of ignition control.

C. Loose wires to valve. Ensure blue and white (2) wires connection is secure

to valve.

D. Air in the gas line. Purge gas line of air.
E. Low voltage. Test voltage at AC terminals of module for 24 VAC.

If no voltage, replace module.

Check electrical connections between module and gas
control. If okay, replace gas control (valve).

3. The main burner come "ON" but then go

"OFF".

4. The log and glass soot. A. Flame impingement on the log. Check for proper log placement.

A. Gas supply is turned "OFF". Turned gas supply to "ON".
B. Loose wire connection on valve or

ignition module.

C. Flame does not engulf flame sensor. Check location of sensor.
D. Obstructed vent system. Check vent system for obstructions.

B. Improper air shutter opening. Check for proper air shutter openings.

Check wire connection.

22

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

TROUBLESHOOTING GUIDE: POWER VENT SYSTEM

Important: Service must be performed by a qualified installer, service agency or your gas supplier.

BEFORE COMMENCING TO TROUBLESHOOT THE UNIT:

1. Check if there is power to the unit (fireplace).

2. Check if there is gas to the unit (fireplace).

3. The igniter module in the fireplace is equipped with a lockout device, which will put the unit into a lockout condition. Follow the steps in the
chart below to reset the control: Turn the On/Off switch to the Off position, or turn the thermostat to the Off position.

4. If this is the first time that the unit has been fired, check the wiring of the unit against the wiring diagram before commencing troubleshooting.

START

Power Vent Motor

Is Working?

Yes

On/Off Switch Or Wall Thermostat “On”?

No

Is There 120V Power To The Fireplace?
Are All Wiring Connections Tight?
(Turn Off Power Before Checking)

Is There 120V Power

Yes

To The Motor?

No

Yes

Replace Blower

Replace Control Module

Does The Pilot

Spark?

Yes

Pilot Burner

Lights?

Yes

Does Spark

Stop When Pilot

Lights?

Yes

Does Main Burner

Light?

Yes

No No

Yes

No

No

No

Is The Lead To The

Spark Electrode

Attached Or Arcing

To Ground? Is The

Electrode Cracked?

No

Is Pilot Gas Line

Blocked? Is Pilot

Orifice Blocked?

No

Does Pilot Flame
Cover The Flame

Rod?

No

Check Pilot For Obstruction.
Check Gas Pressure.
Adjust Pilot Flame.

Is There 1V Power

At Terminal 1 (MV)

During Spark Cycle?

No

Yes

Is The Pressure
Switch Closed?

Yes

Replace Control

Module

Replace Ignition Module

Yes

Yes

Replace Pilot

Replace Ignition Module

Is The Flame Rod Corroded?
Is The Pilot Hood Corroded?
Is Flame Rod Insulator Cracked?
Is Wire To Flame Rod Damaged?

Are Wires To Valve

Loose Or Corroded?

Replace Ignition Module

Is There Blockage In The Vent?
Is There Water/Dirt In The Hose From
The Blower To The Pressure Switch?
Are the Hose Connections Loose?
Is The Hose Cracked?

WARNING: Never Jump The Pressure
Switch Out Of This System. Property
Damage, Injury Or Death May Result.

No

Replace Ignition Module

No

Is There Manifold Pressure?

No

Replace Gas Valve

No

Yes

Replace Pressure

Switch

Check Position Of

Pilot. Is Orifice

Blocked?

System Runs
Continuously

Until Switched

Off?

No

Does The Pilot Flame Cover The Flame Rod?
Is The Sensor Wire In Good Condition?
Is There Continuity To Ground From The Pilot Burner?

Yes

Does Pressure Switch Open During Operation?

No

Replace Ignition Module

Yes

Replace Control Module

Replace Pressure Switch

No

Is Vent Partially Blocked?
Is There Water/Dirt In Hose To Pressure Switch?
Are Hose Connections Loose?
Is The Hose Cracked?

No

Does System Run

Continue?

No

Replace Ignition

Module

23

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

REPLACEMENT PARTS LIST

Item

Description LSM40-PV LSM45-PV

No.

1 Brick Liner Kit (a) - Buff Rustic

Brick Liner Kit (b) - Red Rustic
Brick Liner Kit (c) - Buff Herringbone
Brick Liner Kit (d) - Red Herringbone
Brick Liner Kit (e) - Red Old Cottage
Brick Liner Kit (f) - Black

2 Door Modesty Shield H4808 1 H4809 1

3 Log Set (Oak) H4799 1 H4799 1

3 Log Set (Birch) H4800 1 H4800 1

4 Enclosure, Glass Door H2281 1 H2282 1

5 Spring Latch Assembly H2274 2 H2274 2

6 Burner Assembly H4817 1 H4817 1

7 Venturi H1428 1 H1428 1

8 Gasket - Venturi 43K85 1 43K85 1

9 Access Plate H2277 1 H2277 1

10 Screen Rod H2278 1 H2279 1

11 Screen H1427 2 H1169 2

12 Gasket, Access Plate H1452 1 H1452 1

13 Gas Line Tubing H2283 1 H2284 1

14 Connector, Male H2285 1 H2285 1

15 Orifice, Natural Gas H7924 1 H7924 1

15 Orifice, Propane Gas H7936 1 H7936 1

16 Bag of Embers (rockwool) 88L53 1 88L53 1

17 Grate Assembly H4907 1 H4907 1

18 On/Off Control Switch 80L41 1 80L41 1

19 Gas Line, Flexible Connection 93L32 1 93L32 1

20 Modesty Panel, Right Side H3371 1 H3372 1

21 Modesty Panel, Left Side H3373 1 H3374 1

22 Floor Panel H3369 1 H3370 1

23 Bag of Volcanic Stone (lava rock) 80L42 1 80L42 2

24 Barrier Screen Panel H4805 1 H4806 1

25 Adaptor w/Probe H7925 H7925

Cat.
No.

H2219
H4801
H2220
H4803
H2221
H2222

Qty. Cat. No. Qty.

1

H2223

1

H4802

1

H2224

1

H4804

1

H2225

1

H2226

Item

Description Natural Gas Propane Gas

No.

1
1
1
1
1
1

** Gas Train Assembly Electronic

LSM40EN

** Gas Train Assembly Electronic

LSM45EN

40 Gas Valve, SIT 99K88 1 99K89 1
41 Pilot Assembly H2298 1 See Note

42 Transformer 42J32 1 42J32 1
43 Ignition Module (with wire

harness)

uIf a propane gas train assembly is needed, order catalog number H4190 (for

model LSM40-PV) or H4193 (for model LSM45-PV), NG gas train assembly as
well as conversion kit, cat. no. H7934 for models LSM40-PV) and LSM45-PV.

vIf a propane gas pilot assembly is needed, order H2298 (NG pilot assembly) as

well as conversion kit, cat. no. H7934 for models LSM40-PV) and LSM45-PV.

Contact an Authorized Lennox Hearth Products dealer to obtain any of
these parts. Never use substitute materials. Use of non-approved parts
can result in poor performance and safety hazards.

Failure to position the parts in accordance with these
diagrams or failure to use only parts specifically
approved with this appliance may result in property
damage or personal injury.

Risque de dommages ou de blessures si les pièces
ne sont pas installées conformément à ces schémas
et ou si des pièces autres que celles spécifiquement

Gas Controls - SIT Electronic

Part

Qty. Part No. Qty.

No.

H4190 1 See Note

H4193 1 See Note

H1167 1 H1167 1

WARNING

AVERTISSEMENT

approuvées avec cet appareil sont utilisées.

u

1

1

u

1

v

24

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

REPLACEMENT PARTS ILLUSTRATIONS

3

18

13

15

20

8

16

23

6

21

7

40

2

4

14

5

19

HI

LO

17

11

10

9

12

42

43

41

22

24

25

1

1

1

1

(Rustic Pattern Shown)

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

25

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

POWER VENT REPLACEMENT PARTS AND ILLUSTRATIONS

Item

Part Number Description Qty.
1 H7383
2 H7369
3 H7366

4 H7367
5 H7368
6 H7370
7 H7384
8 H7371

15 H7372
16 H7378

Vacuum Hose 1
Wire Harness
Pressure Switch
Control Module
Strain Relief - 3/8”
Ring Terminal - #10
Insulated 1/4” Male Terminal
Hose Clamp - 11/32”
Base Assembly (Power Vent)
Kicker Assembly

19

25

20

Item Part Number

17 H7382
1
1

1
2
2
4
2
1
1

18 H7365

19 H7375

20 H7373

21 H7374

22 H7377

23 H7379

24 H7380

25 H7376

26 H7381

Blower Gasket
Blower Assembly
Wrapper - Top
Wrapper
Wrapper - Bottom
J-Box
Diverter - Front
Diverter - Back
Wrapper Cover
Wire Mesh

Description

Qty.

1
1
1
1
1
1
1
1
1
1

16

17

18

15

8

21

2

5

4

26

6

7

24

23

3

1

9

22

26

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

NOTES

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

27

LENNOX HEARTH PRODUCTS • MONTEBELLO® POWER VENT DV GAS FIREPLACES (LSM40/45EN-PV) • CARE AND OPERATION INSTRUCTIONS

Lennox Hearth Products reserves the right to make changes at any time, without notice, in design,
materials, specifications, and prices, and also to discontinue colors, styles, and products.
Consult your local distributor for fireplace code information.

Printed in U.S.A. © 2009 Lennox Hearth Products

P/N 506025-02 Rev. C 06/2011

28

NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.

1508ElmHillPike,Suite108•Nashville,TN37210
