english

THANK YOU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

ABOUT YOUR JABRA BT8030 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

WHAT YOUR JABRA BT8030 CAN DO . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

CHARGE YOUR HEADSET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

TURN ON YOUR HEADSET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

PAIRING WITH A PHONE OR OTHER DEVICE . . . . . . . . . . . . . . . . . . . . 5

WEARING YOUR JABRA BT8030. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

TRANSFORMING THE JABRA BT8030 FROM . . . . . . . . . . . . . . . . . . . . 6

HEADSET MODE TO SPEAKER MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

HOW TO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

WHAT THE LIGHTS MEAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

HOW TO PLAY MUSIC IN STEREO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

USING THE JABR A BT8030 WITH YOUR PC . . . . . . . . . . . . . . . . . . . . . . 8

TROUBLESHOOTING & FAQ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

NEED MORE HELP?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

TAKING CARE OF YOUR HEADSET . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

WARNING! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

CERTIFICATION AND SAFETY APPROVALS . . . . . . . . . . . . . . . . . . . . .13

GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

Thank you

Thank you for purchasing the Jabra BT8030 combined Bluetooth® Headset and Speaker. We hope you enjoy it! This instruction manual will get you started and ready to make the most of your headset.

abouT your Jabra bT8030

The Jabra BT8030 can function both as a Bluetooth Stereo Headset, Bluetooth Stereo Speakers and as a Bluetooth Speaker phone. This way you will always have the bedst possible solution at hand when you want listen to music or have an important call.

On/o/pairing button

Volume Up (+)

Volume Down (-)

Answer/End button

Play/Pause button

Fig. 1

Skip Next (>>)

Skip Previous (<<)

Safety Release buttons

Microphone

LED Light Indicators

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

Fig. 2

WhaT your Jabra bT8030 can do

The Jabra BT8030 lets you connect to one or two devices (see page 5) for phone and music features in both headset and speaker mode:

Specications:

• Headset mode: Up to 32 hours of talktime or 8 hours of music

- standby time up to 240 hours

• Speaker mode: Up to 32 hours of talktime or 8 hours of music

• Rechargeable battery with charging from the AC power supply or car charger (car charger not included)

• USB cable for connection to PC and for upgrading rmware

• Operating range up to 33 feet (10 meters)

• Advanced Audio Distribution Prole (A2DP), Audio Video Remote Controle Prole (AVRCP) as well as Headset and Handsfree Bluetooth proles

• Bluetooth specication 2.0 (See glossary page 14)

• Operating range up to 33 feet (approx. 10 meters)

• Headset and hands-free Bluetooth proles

• Bluetooth specication (see glossary) version 1.2

geTTing sTarTed

The Jabra BT8030 is easy to operate. The buttons performs dierent functions depending on how long you press them:

Instruction Duration of press

Tap

Press Approx: 1 second

Press and hold Approx: 5 seconds

Press briey and let go

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

Phone features

• Answer calls

• End calls

• Reject calls*

• Voice dialing*

• Last number redialing*

• Call waiting*

• Put call on hold*

* Phone dependent

Music features

• Play music

• Pause music

• Stop music

• Pause music and answer call*

• Fast Forward*

• Rewind*

• Jump to next track

• Jump to previous track

* Device dependent

charge your headseT

Make sure that your Jabra BT8030 is fully charged before you start using it. Use only the charger provided in the box – do not use chargers from any other devices as this might damage your Jabra BT8030.

Connect the headset as shown of g. 2 to the AC adaptor for the power socket. When the indicator lights are solid red, your headset is charging. When the lights turn to green, the headset is fully charged.

Turn on your headseT

• Press the on/o/pairing button to turn on your headset – when the headset is on the LED indicator light will ash.

• Press and hold the on/o/pairing button to turn the device o. The led ash red to indicate that the headset is turned o.

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

Pairing WiTh a Phone or oTher device

• Before you use your Jabra BT8030 you must pair it up with a mobile phone or/and another Bluetooth

• enabled music device. If you have not paired your headset with a mobile phone before, your headset will

• automatically go into pairing mode. Otherwise use the follow ing procedure:

1. Put the headset into pairing mode:

• Make sure headset is turned o.

• Press and hold the on/o/pairing button until the indicator light is solid blue.

• The headset is now in paring mode.

2. Set your mobile phone or other device to ‘discover’ the

Jabra BT8030

• Follow your phones instruction guide . This usually involves going to a ‘setup’, ‘connect’ or ‘Bluetooth’ menu on your phone and selecting the option to discover or add a Bluetooth device. (See example from typical mobile phone in g. 3)

3. Your phone will nd the Jabra BT8030

• Your phone or other device will ask if you want to pair with it,

accept this with “Yes” or “ok” and conrm with the passkey or PIN = 0000 (4 zero’s). Your phone or other device will conrm when pairing is complete. In case of unsuccessful pairing repeat steps 1 to 3.

Fig.3

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

4. Connecting with a second device

You are able to connect your BT8030 with two devices, enabling music playing and phone connectivity at the same time. Refer to your PC/MP3 player/phone manual for details regarding pairing for that device. The procedure for the headset is as described above in step 1.

Wearing your Jabra bT8030

As a headset your Jabra BT8030 is designed to be comfortably worn with the headband on your head. On the side of the headset there is ‘L’ and ‘R’ markings indicating Left and Right position of the headset. The headset can be adjusted for optimal t by expanding the length of the ear pieces.

Used as a speaker the Jabra BT8030 should be placed on a at sur face facing the ear-cushions towards you and having the buttons on top. The Left (L) and Right (R) markings also indicate the right positioning of the speaker.

The microphone is integrated in the left earpiece and Digital Signal Processing (DSP) is used for clear pickup of your voice regardless of use as a headset or a speaker.

Transforming The Jabra bT8030 from headseT mode To sPeaker mode

To switch from headset mode to speaker mode you will need to press the Safety Release buttons (see Fig. 4) on the top of the headband, and press the two earpieces outwards. Please note that you need to press the buttons on each side of the headset to transform to a speaker.

The build-in Safety mechanism is to ensure that the Jabra BT8030 will not go into speaker mode while operating in headset mode.

Fig. 4

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

hoW To

When connected via Bluetooth to a stereo device your Jabra BT8030 realizes its full potential. The right hand side of your Jabra BT8030 is dedicated for use when playing music in stereo. These buttons will work when the device you have connected to is able to support the Bluetooth remote control (AVRCP) prole – See glossary for more information on this.

The large button on the right side of the device is the Play button. On the top there are the skip forward and skip back buttons.

To start Play:

• Make sure your headset is connected in stereo mode (Ad vanced Audio Distribution Prole (A2DP)). Tap the Play button once

To Pause:

• Tap the Play button – tap again to resume playing

To Stop:

• Long Press the Play button

Answer a call when playing music:

• Tap the Answer/end button and the music will be paused and the call will be connected. The music will resume after the call has ended (dependent on your device supporting this feature).

Skip one track forward:

• Tap the Skip Forward button [Skip Forward Symbol]- continue tapping to skip several tracks forward

Skip one track back:

• Tap the skip Back button [Skip Back Symbol] - continue tapping to skip several tracks backward

Fast Forward*:

• Press and hold Skip Forward button [Skip Forward Symbol]

Fast Rewind*:

• Press and hold Skip Back button [Skip Back Symbol] * Device dependent

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

WhaT The lighTs mean

What you see What it means

Flashing blue light Flashing every second: active

Solid blue light

Flashing red light Running low on battery

Solid red light Charging

Solid green light Fully charged

Solid red (left side) & solid blue light (right side)

on a call

Flashing every three seconds: in standby mode

Parring mode

USB stereo mode (connected to PC)

hoW To Play music in sTereo

The large button on the right side of the device is the Play button. On the top there are the skip forward and skip back buttons.

For further details on compatibility and how to connect, please visit: www.jabra.com/bt8030

using The Jabra bT8030 WiTh your Pc

You can connect your Jabra BT8030 with your PC for listening to music or VoIP communication by using a Bluetooth USB stereo adapter - for example the Jabra A320s. For further details on com patibility and how to connect, please visit: www.jabra.com/bt8030

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

Using the headset with the USB cable

You can play in stereo using the USB cable and connect this to a PC that plays in stereo. In order to activate USB stereo:

1. Attach the USB cable to the device and your PC.

2. Wait 10 seconds and then press the ‘answer end’ and ‘play/ pause buttons simultaneously.

TroubleshooTing & faQ

I hear crackling noises

For the best audio quality, always wear your headset on the same side of the body as your mobile phone.

I cannot hear anything in my headset

• Increase the volume on the headset.

• Ensure that the headset is paired with the phone.

• Make sure that the phone is connected to the headset – if it does not connect either from the phone’s Bluetooth menu or by tapping the answer/end button, follow the pairing procedure (see page 5).

I have pairing problems even though my phone indicates otherwise

You may have deleted your headset pairing connection in your mobile phone.

Follow the pairing instructions in page 5.

Will the Jabra BT8030 work with other Bluetooth equipment?

The Jabra BT8030 is designed to work with Bluetooth mobile phones. It can also work with other Bluetooth devices that are compliant with Bluetooth version 1.1 or 1.2 and support a headset and/or hands-free prole.

I cannot use Reject call, call on hold, Redial or voice dialling

These functions are dependent on your phone supporting them. Please check your phone’s manual for further details

need more helP?

Phone 00800 722 52272 support.eu@jabra.com http://www.jabra.com/support

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

Taking care of your headseT

• Always store the Jabra BT8030 with the power o and safely protected.

• Avoid storage at extreme temperatures (above 45°C/113°F – including direct sunlight – or below -10°C/14°F). This can shorten battery life and may aect operation. High tempera tures may also degrade performance.

• Do not expose the Jabra BT8030 to rain or other liquids.

Warning!

Headsets are capable of delivering sounds at loud volumes and high pitched tones. Exposure to such sounds can result in per manent hearing loss damage. The volume level may vary based on conditions such as the phone you are using, its reception and volume settings, and the environment. Please read the safety guidelines below prior to using this headset.

Safety guidelines

1. Prior to using this product follow these steps

• before putting on the headset, turn the volume control to its lowest level,

• put the headset on, and then

• slowly adjust the volume control to a comfortable level.

2. During the use of this product

• Keep the volume at the lowest level possible and avoid using the headset in noisy environments where you may be inclined to turn up the volume;

• If increased volume is necessary, adjust the volume control slowly;

and

• If you experience discomfort or ringing in your ears, immedi ately discontinue using the headset and consult a physician.

With continued use at high volume, your ears may become accustomed to the sound level, which may result in permanent damage to your hearing without any noticeable discomfort.

Using the headset while operating a motor vehicle, motorcycle, watercraft or bicycle may be dangerous, and is illegal in some

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

jurisdictions. Check your local laws. Use caution while using your headset when you are engaging in any activity that requires your full attention. While engaging in any such activity, removing the headset from your ear area or turning o your headset will keep you from being distracted, so as to avoid accident or injury.

3. Keep out of reach of children:

The plastic bags the product and its parts are wrapped in are not toys for children. The bags themselves or the many small parts they contain may cause choking if ingested. Never try to disman tle the product yourself. None of the internal components can be replaced or repaired by users.

Only authorised dealers or service centres may open the product. If any parts of your product require replacement for any reason, including normal wear and tear or breakage, contact your dealer.

Avoid exposing the product to rain or other liquids.

4. ACA TS028 – Ignition of ammable atmospheres

Do not use the Headset in environments where there is a danger of ignition of ammable gases.

WarranT y

Limited (1) -Year Warranty

GN A/S, warrants this product to be free from defects in materials and workmanship (subject to the terms set forth below) for a period of two (2) year from the date of purchase (“Warrenty Period”). During the Warranty Period, GN will repair or replace (at GN’s dis cretion) this product or any defective parts (“Warrenty Service”). If repair or replacement is not commercially practicable or cannot be timely made, GN may choose to refund to you the purchase price paid for the aected product. Repair or replacement under the terms of this warranty does not give right to any extension or a new beginning of the period of warranty.

Claims under the Warranty

To obtain Warranty Service, please contact the GN dealer from which you purchased this product or visit www.jabra.com for further information about customer support.

You will need to return this Product to the dealer or ship it to the dealer or to GN (if so indicated on www.jabra.com) in either its

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

original packaging or packaging aording an equal degree of protection.

You will bear the cost of shipping the product to GN. If the Prod uct is covered by the warranty, GN will bear the cost of shipping product back to you after the completion of service under this warranty. Return shipping will be charged to you for products not covered by the warranty or requiring no warranty repair.

The Following information must be presented to obtain Warranty Service: (a) the product, and (b) proof of purchase, which clearly indicates the name and address of the seller, the date of purchase and the product type, which is evidence that this product is within the Warranty Period. Please further include (c) your return address. (d) daytime telephone number, and (e) reason for return.

As part of GN/Jabra’s eorts to reduce environmental waste you understand that the product may consist of reconditioned equipment that contains used components, some of which have been reworked. The used components all live up to GN/Jabra’s high quality standards and comply with the GN product performance and reliability specications. You understand that replaced parts or components will become the property of GN.

Limitation of Warranty

This warranty is only valid for the original purchaser and will au tomatically terminate prior to expiration if this product is sold or otherwise transferred to another party. The warranty provided by GN in this statement applies only to products purchased for use, and not for resale. It does not apply to open box purchases, which are sold “as is” and without any warranty.

Specically exempt from warranty are limited-life consumable components subject to normal wear and tear, such as microphone windscreens, ear cushions, modular plugs, ear tips, decorative nishes, batteries, and other accessories.

This warranty is invalid if the factory-applied serial number, date code label, or product label has been altered or removed from this product.

This Warranty does not cover cosmetic damage or damage due to misuse, abuse, negligence, Acts of Nature, accident, disassembling or modication of, or to any part of, the product. This Warranty does not cover damage due to improper operation, maintenance or installation, or attempted repair by anyone other than GN or a GN dealer which is authorized to do GN warranty work. Any unauthorized repairs will void this warranty.

JABRA B T8030 BLUETOOTH STER EO HEADSET

english

REPAIRS OR REPLACEMENTS AS PROVIDED UNDER THIS WARRANTY ARE THE EXCLUSIVE REMEDY OF THE CONSUMER. GN SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY LAW, THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND IMPLIED WARRANTIES WHATSOEVER, INCLUDING BUT NOT LIMITED TO THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PRACTICAL PURPOSE.

NOTE! This warranty gives you specic legal rights. You may have other rights which vary from location to location. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or implied warranties, so the above exclusions may not apply to you. This warranty does not aect your legal (statutory) rights under your applicable national or local laws.

cerTificaTion and safeTy aPProvals

This product is CE marked according to the provisions of the R & TTE Directive (99/5/EC).

Hereby, GN A/S, declares that this product is in compliance with the essential requirements and other relevant provisions of Direc tive 1999/5/EC.

For further information please consult http://www.jabra.com

Within the EU this device is intended to be used in Austria, Bel gium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Poland, Portugal, Rumania, Slovakia, Slovenia, Spain, Sweden, The Netherlands, United Kingdom, and within EFTA in Iceland, Norway and Switzerland

Bluetooth

The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by GN A/S is under license. Other trademarks and trade names are those of their respective owners.

english

JABRA B T8030 BLUETOOTH STER EO HEADSET

glossary

1. Bluetooth is a radio technology that connects devices, such as mobile phones and headsets, without wires or cords over a short distance (approx. 30 feet). Get more information at www. bluetooth.com.

2. Bluetooth proles are the dierent ways that Bluetooth devices communicate with other devices. Bluetooth phones supports either the headset prole, the hands-free prole or both. In order to support a certain prole, a phone manufac turer must implement certain mandatory features within the phone’s software.

3. Pairing creates a unique and encrypted link between two Bluetooth devices and lets them communicate with each other. Bluetooth devices will not work if the devices have not been paired.

4. Passkey or PIN is a code that you enter on your mobile phone to pair it with your Jabra BT8030. This makes your phone and the Jabra BT8030 recognize each other and automatically work together.

5. Standby mode is when the Jabra BT8030 is passively waiting for a call. When you ‘end’ a call on your mobile phone, the headset goes into standby mode.

6. A2DP (Advanced Audio Distribution Prole) is a Bluetooth Prole that enables stereo sound. Both the headset and the device it connects to must support A2DP in order to hear stereo sound in the headset.

7. AVRCP (Audio Video Remote Control Prole) is a Bluetooth prole that enables remote control of the device that the headset is connected to. Both the headset and the device it connects to must support AVRCP in order for AVRCP to work.

english

Dispose of the product according to local standards and regulations.

www.jabra.com/weee

JABRA B T8030 BLUETOOTH STER EO HEADSET

Lennox BT8030 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
