INSTRUCTION MANUAL

FM RADIO WITH BLUETOOTH RECEPTION

MODEL: SR-500BT

Please read following instructions prior to operating your unit.

Manufacturer of this unit follows a principle of continuous improvement and has no responsibility for any changes that are made to the unit or any liability for these changes. Thanks for your choice of our products.

For information and support, www.lenco.com

MAIN UNIT

1. FM ANTENNA

2. BLUETOOTH INDICATOR

3. HANDLE

4. SPEAKERS

5. MEMORY BUTTON

6. FUNCTION BUTTON

7. REMOTE SENSOR

8. LCD DISPLAY

9. STANDBY BUTTON

10. TUNE/PAIR BUTTON

11. CH- BUTTON

12. VOL- BUTTON

13. VOL+ BUTTON

14. CH+ BUTTON

15. BATTERY COMPARTMENT

16. AUX IN JACK

4 5 6 7 8 9

11 12 13 14

17. DC IN JACK

1. PAIR BUTTON

2. MUTE BUTTON

3. BT BUTTON

4. PLAY/PAUSE BUTTON

5. PREVIOUS BUTTON

6. CH+/- BUTTON

7. TUNE+/- BUTTON

8. FAST BACKWARD BUTTON

9. MEM BUTTON

10. ST/MO BUTTON

11. STANDBY BUTTON

12. FM BUTTON

13. AUX IN BUTTON

14. NEXT BUTTON

15. VOL+/- BUTTON

16. FAST FORWARD BUTTON

17. SLEEP BUTTON

POWER SUPPLY

Plug the adapter to the unit and the main power. NOTE: During playback, if not any operation in about 4 hours, the unit will switch to standby mode automatically.

BATTERY INSTALLATION

1. Remove the battery compartment cover gently.

2. Install 6 x 'C' size batteries (UM-2 or equivalent) while observing the correct polarities.

3. Replace the battery compartment cover.

NOTE:



The AC/DC adapter must be detached from the DC IN jack of the player for battery operation.



Leaking batteries may damage the battery cabinet and the player as a whole, so they should be removed from the cabinet when becoming flat or when the player is not to be played on batteries for some time.

BLUETOOTH OPERATING

This unit can receive stereo audio signal from a BLUETOOTH stereo audio source device.

1. Press the STANDBY button on the unit or on the remote to power on the unit, switch to BLUETOOTH mode by pressing the FUNCTION button repeatedly on the unit or press the BT button on the remote.

2. LED indicator rapid blinking while it is pairing.

3. Pair and connect to SR-500 BT on the BLUETOOTH audio source device. If prompted for passcode, enter “0000”.

4. Pairing successful (LED indicator lights stably), ready to stream music.

5. Press the PLAY/PAUSE button on the remote to pause/resume the playback.

6. During playback, press once the NEXT button on the remote to skip to the next track; press twice the PREVIOUS button on the remote to skip to the previous track.

7. During playback, press and hold the FAST FORWARD button or the FAST BACKWARD button on the remote to search through the track forward or backward.

Note:

•

Pairing mode is exiting about 1.5 minutes. The pairing mode can be entered again possibly by pressing the PAIR button on the remote or the TUNE/PAIR button on the unit.

•

The above are generic steps to pair a BLUETOOTH device, for more specific instructions on BLUETOOTH connectivity for your device, please consult your manufacturer’s manual.

•

After the first connection, the unit will detect your last paired BLUETOOTH device and connect to it automatically.

RE-CONNECT TO THE BLUETOOTH AUDIO SOURCE DEVICE

If the device is already paired with the SR-500 BT, but became unconnected even with both Bluetooth devices turned on. You can re-connect them by following steps:

1. Press the TUNE/PAIR button on the unit or the PAIR button on the unit to re-link the audio source device. The Bluetooth indicator will blink for about 1.5 minutes for connecting.

2. Select SR-500 BT on the audio source device for connecting. Bluetooth indicator will turn to solid blue if the SR-500 BT and the device have been re-connected successfully

FM RADIO TUNING THE FM RADIO

1. Power on the unit, switch to RADIO mode by pressing the FUNCTION button on the unit repeatedly or pressing the FM button on the remote.

2. Press the TUNE+/- button on the remote to fine tune the radio station. Press and hold the TUNE+/buttons on the remote to auto search radio station forward or backward respectively or press the TUNE button on the unit to tune the radio station automatically. When an available station will be found, the unit will broadcast it immediately and the searching will be stopped.

3. Press the ST/MO button on the remote to switch between FM mono and FM stereo modes (The button is available when the FM radio station is broadcasting.).

STORING YOUR FAVORITE RADIO STATION

1. During playback, press the MEM button on the remote or press the MEMORY button on the unit, “MEM” flashes on the screen with a memory cell number..

2. Press the CH+/- button on the unit or on the remote to select the corresponding memory cell among P01-P20 for storing the station.

3. Press the MEM button on the remote or the MEMORY button on the unit to store the current station to the selected memory cell.

4. During radio playback, press the CH+/- button to recall the stored stations.

MUTE

During playback, press MUTE button to switch off the audio, press the button again to resume the audio.

VOLUME LEVEL JUSTMENT

During playback, press VOL +/- button to adjust the volume output level.

SLEEP TIMER SETTING

Following the below instructions to set the sleep time at power on mode: During playback, press the SLEEP button repeatedly to cycle through the sleep time options:

90 ➨ 60 ➨ 30 ➨ 15 ➨ 05 ➨ OFF

Once the options you want shows on the screen, release the sleep button. After setting the sleep time, you can operate the unit freely. When the set sleep time has expired, the unit will automatically power off.
