Leica Geosystems 887891 User manual

Leica DISTOTM X4

The original laser distance meter

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Overview 2
Technical data 4
Instrument Set-up 6
Settings 10
Operations 27
Message Codes 53
Care 54
Warranty 55
Safety instructions 56

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

1

Overview

Overview

Components

The Leica DISTO™ is a laser distance meter oper­ating with a class2 laser. See chapter Technical

data for scope of use.

5Add/ Navigate left

6Enter/ Equal

7Selection keyslinked to symbols
above

8Functions

9Subtract/ Navigate right

10Measuring reference/ Navigate
downwar ds

Basic result screen

1Status bar

2Main line

3Active function

4Favorites

1Display

2ON/ Measure

3Clear/ OFF

4Zoom/ Navigate upwards

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

2

Overview

Basic measuring screen

1Status bar

3Active function

4Favorites

5Zoom stage

6Cross hair

Selection screen

1Function/ Settings

2Settings

3Help function

4Page indicator

Icons on status bar

Scrolldown for further results

Battery power

Bluetooth® isswitched on

Bluetooth® connection established

Measuring reference

Device is measuring

Offset is activated and adds/substracts
the defined value from measuring dis­tance

Device is levelled

Device is not levelled

Zoom

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

3

Technical data

Tech nicaldata

General
Accuracywith favourable conditions * 1 mm / 0.04" ***
Accuracywith unfavourable conditions ** 2 mm / 0.08" ***
Range with favourable conditions* 0.05 - 150m / 0.16 - 500ft ***
Range with unfavourable conditions** 0.05 - 80m / 0.16 - 260ft ***
Smallest unit displayed 0.1 mm / 1/32 in
X-Range Power Technology yes
Laser class 2
Laser type 635 nm, <1 mW
ø laser point | at distances 6 /30 /60 mm | 10/ 50/ 100 m
Tilt measuring tolerance to laser beam **** ± 0.2°
Tilt measuring tolerance to housing **** ± 0.2°
Tilt measuring range **** 360°
Protection class IP65 (dust- and splash water protected)
Auto. laser switch off after 90 s
Auto. power switch off after 180 s

Bluetooth® Smart Bluetooth® v4.0

Power of Bluetooth® Smart 0.71 mW

Frequency of Bluetooth® Smart 2400 - 2483.5 MHz

Range of Bluetooth® Smart <10m

Battery durability(2 x AA) up to 4000 measurements

Dimension (H x D x W) 132 x 56 x 29 mm | 5.2 x 2.2 x 1.1 in

Weight (with batteries) 184 g/ 6.49 oz

Temperature range Storage | Operation -25 to 70°C/ -13 to 158°F | -10 to 50°C/ 14 to 122°F

* favourable conditions are: white anddiffuse reflecting target (white painted w all), l ow background illu-

minationand moderate temperatures.

** unfavourable conditions are: targets with l ower or higher reflectivity or highbackground il lumination or

temperatures at the upper or lower end of the specified temperature r ange.

*** Tolerances apply from 0.05 m to 10 m with a confidence level of 95%.

With favourable conditions thetolerancem ay deteriorate by 0.10 m m/m for distances above 10 m .

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

With unfavourable conditions thetolerance may deteriorate by 0.15m m/m for distances above 10 m .

**** after user calibration. Additional anglerelated deviation of +/-0.01° per degreeup to +/-45° in each quad-

rant.

Applies at room temperature. For the whole operating temperature rangethem aximum deviation

increases by +/-0.1°.

4

Technical data

Func tions
Distance measuring yes
Min/Max measuring yes
Permanent measuring yes
Stake out yes
Addition/Subtraction yes
Area yes
Room angle yes
Volume yes
Painter function (area with partial measurem.) yes
Pythagoras 3-point
Smart HorizontalMode / Indirect height yes
Level yes
Memory yes
Beep yes
Illuminated colour display yes

Bluetooth® Smart yes

Personalized Favorites yes

Timer yes

Point to point function/ distance yes *****

Smart Area yes *****

Height tracking yes

***** In combination wi th Leica DST 360 adapter

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

5

Instrument Set-up

InstrumentSet-up

Introduction

The safety instructions (see Safety

Instructions) and the user manual

should be read through carefully
before the product is used for the first
time.

The person responsible for the
product must ensure that all users
understand these directions and
adhere to them.

The symbols used have the following
meanings:

WARNING

Indicatesa potentiallyhazardous situ­ation or an unintended use which,if
not avoided, will resultin death or ser­ious injury.

CAUTION

Indicatesa potentiallyhazardous situ­ation or an unintended use which,if
not avoided, may result in minor injury
and/or appr eciablematerial, financial
and environmental damage.

Important par agraphs which
must be adhered to in practice
as they enable the product to be
used in a technically correct and
efficient manner.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

6

Instrument Set-up

Insert batteries

To ensure a reliable use, we
recommend using high quality
Alkaline batteries. Change bat­teries when battery symbol is
flashing.

Switching ON/OFF

Device is turned OFF.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

7

Instrument Set-up

Clear

Undo last action. Leave actualfunction, go to default

operation mode.

Message Codes

If the message "i" appears with
a number, observe the instruc­tions in Message Codes section.
Example:

Leica DISTO™ X4

8

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Instrument Set-up

Multifunctional endpiece

When measuring with 90°
flipped-out endpiece please
meake sure that it lies plane
against the edge you measure
from.

The orientation of the endpiece
isautomatically detected and
the zero point is adjusted accord­ingly.

Adjusting measuring reference

Leica DISTO™ X4

a) Distance is measured from the
rear of the device (standard setting).

b) Distance is measured from the
front of the device.

c) Distance is measured from the tri­pod thread.

d) Distance is measured from a Leica
DISTO Adapter FTA 360.

Confirm setting.

If device is switched off, ref­erence goes back to standard
setting (r ear of the device).

9

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Settings

Settings

Overview

Tilt units

Distance units

Turning screen**

Beep

Bluetooth®

Bluetooth® settings

Illumination

Favorites

Keypad lock

Tilt calibration

Information / Serial number

Offset

Calibration of DST 360*

Reset

* Activatedw hen connected to Leica DST 360

adapter

** Firmware update might be requiredthrough the

Leica DISTO™ Plan Appto get this feature

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

10

Settings

Tilt units

Switch between the following units:

360.0°

0.00 %

Confirm setting. Exitsettings.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

11

Settings

Distance units

Switch between the following units:

0.00 m 0 in 1/32

0.000 m 0 in 1/16 *

0.0000 m 0 in 1/8 *

0.0 mm 0 in 1/4 *

0'00" 1/32 0.00 f t

0'00" 1/16 * 0.000 in

0'00" 1/8 *

0'00" 1/4 *

* Available in devices purchased in USA and

Canada

Confirm setting. Exitsettings.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

12

Settings

Turning screen ON/OFF*

* Firmware update might be requiredthroughthe

Leica DISTO™ Plan Appto get this feature

To switch ON, repeat procedure. Exitsettings.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

13

Settings

Beep ON/OFF

To switch ON, repeat procedure. Exitsettings.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

14

Settings

Bluetooth® ON/OFF

Bluetooth® isswitched on and
blackBluetooth® icon is dis­played in status bar. If con­nection is established the color
of the icon changes to blue.

To switch ON, repeat procedure. Exitsettings.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

15

Settings

Bluetooth® Settings

Confirm setting. Select kind of decimal point for trans-

mitted value.

If activated in measuring mode, it
allowsthe arrow keys to move the
cursor on your computer.

Short press:send the value of the
main line to your computer.
Long press: send all measurements
and results to your computer.

Select ON or OFF.

If device is connected, the favor­ites disappear and two softkeys
appear:

Confirm setting. Select if unit is transmitted or not.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

16

Settings

Confirm setting. Select termination of transmission. Confirm setting. Select if value istransmitted auto-

matically or manually.

Confirm setting. Exitsettings.

Leica DISTO™ X4

17

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Settings

Illumination

Select brightness. Confirm setting.

Exitsettings.

To save power reduce bright­ness if not necessary.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

18

Settings

Personalized favorites

Exitsettings.

Leica DISTO™ X4

Select favorite function. Press selection key left or right. Func-

tion is set as favorite above the cor­responding selection key.

Select your favorite functions for
quickaccess.
Short cut:
Press 2 sec on a selection-key in
the measuring mode. Select
your favorite function and press
again short on the cor­responding selection key.

19

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Settings

De-/Activate keylock

Leica DISTO™ X4

To deactivate, repeat procedure. The
keylock is active if device is switched
off.

Exitsettings.

20

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Settings

Calibration of tilt sensor (Tilt Calibration)

Placedeviceon absolutelyflat sur­face.

Turn the device horizontallyby 180°
and place it again on absolutely flat
surface.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Placedeviceon absolutelyflat sur­face.

21

Settings

Turn the device horizontallyby 180°
and place it again on absolutely flat
surface.

Leica DISTO™ X4

After 2 sec the device goes back
to the basicmode.

22

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Settings

Information

Exitinformation screen. Exit settings.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

23

Settings

Offset

Select digit. Adjust digit.

Approve value. Exitsettings.

An offset adds or subtractsa
specified value automaticallyto
or from all measurements. This
function allows tolerancesto be
taken into account. The offset
icon is displayed.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

24

Settings

Calibration of Leica DST 360 adapter*

* Function is activated when connectedto theLeica

DST 360 adapter.

Define a point to be measured in a dis­tance more than 8 m. Aim at defined
point and press DIST button to start
the 5 secondscountdown to meas­ure.

Turn the device vertically by 180°. Turn the device by 180°. Aim again at

defined point and pressDIST button
to start the 5 seconds countdown to
measure.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Get more accurate results of the
device in combination with the
Leica DST 360 adapter.

25

Settings

Reset

Reset returns the instrument to
the factory settings. All cus­tomized settings and memories
are lost.

Second confirmation with selection
keys:
a) Refuse
b) Confirm

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

26

Operations

Operations

Overview

Singledistance measurement

Area

Volume

Room angle

Smart HorizontalMode

Level

Pythagoras (3-point)

Stake out

Timer

Height tracking**

Memory

Point to point measurement*
Point to point measurement lev-

elled*
Smart area measurement*/**

* Activatedw hen connected to Leica DST 360

adapter

** Firmware update might be requiredthrough the

Leica DISTO™ Plan Appto get this feature

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

27

Operations

Pointfinder

This is a great help for outdoor
measuring. The integrated point­finder (viewscreen) shows the
target on the display. The device
measures in the middle of the
cross hair, even if the laser dot is
not visible.
Parallax errors occur when the
pointfinder camera is used on
close targets, with the effect that
the laser appears displaced in
the crosshair. In this case rely on
the real laser dot. When using
the point to point functions and
smart area measurement the
error is automaticallycorrected

with a shift of the crosshair.
The pointfinder is always on,
when the laser beam is on.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

28

Operations

Measuring single distance

Target surfaces: Measuring
errors can occur when meas­uring to colourlessliquids, glass,
styrofoam or permeable sur­faces or when aiming at high
glosssurfaces. Against dark sur­faces the measuring time
increases.

Aim active laser at target.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

29

Operations

Permanent / Minimum-Maximum measuring

Use Down navigation key to
take over values in the main line
for sending via Bluetooth®
Smart.

Leica DISTO™ X4

Used to measure room diagonals
(maximum values) or horizontal dis­tance (minimum values).

The minimum and maximum distance
measured is displayed (min, max.).
The last value measured is displayed
in the main line.

Stops permanent / minimum-max­imum measuring.

30

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

Add / Subtract

Leica DISTO™ X4

The next measurement is added to
the previous one, respectively sub­tracted from the pr evious one.

This processcan be repeated
as required. The same process
can be used for adding or sub­tracting areas or volumes.

31

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

Area

The area is calculated based on the
mathematic ter m multiplying 2 dis­tances.

Leica DISTO™ X4

Aim laser at second target point. a) First distance

b) Second distance
c) Circumference
d) Area

Aim laser at first tar get point.

The resultis shown in the main
lineand the measured value
above. Painter function: Press +
or - after starting the first meas­urement. Measure and add or
subtract wall lengths. Measure
finally height for second length
to get the wall area.
Use Down navigation key to
take over values in the main line
for sending via Bluetooth®
Smart.

32

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

Volume

The volume iscalculated based on
the mathematic ter m multiplying 3 dis­tances.

Leica DISTO™ X4

Aim laser at first tar get point.

Aim laser at second target point. Aim laser at third target point.

33

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

Use Down navigation key to
show more resultsor to take
over valuesin the main line for
sending via Bluetooth® Smart.

a) First distance
b) Second distance
c) Third distance
d) Volume

Leica DISTO™ X4

a) Ceiling/floor area
b) Wall areas
c) Circumference

34

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

Room angle

The angle is calculated based on the
cosine rule with 3 known side lengths
of a triangle.

Leica DISTO™ X4

Aim laser at first tar get point.

Aim laser at second target point. Aim laser at third target point.

35

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

Use Down navigation key to
show more resultsor to take
over valuesin the main line for
sending via Bluetooth® Smart.

a) First distance
b) Second distance
c) Third distance
d) Angle between first and second
measurement

Leica DISTO™ X4

a) Circumference
b) Tr iangular area

36

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

Smart Horizontal Mode

The horizontaldistance is calculated
based on the trigonimetric function
cosine with 1 known length and 1
known angle.

Use Down navigation key to
take over values in the main line
for sending via Bluetooth®
Smart.

Leica DISTO™ X4

Aim laser at target (up to 360° and a
transverse tiltof ±10°).

37

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

Level

Displays inclinations of 360°.
Instrument beeps at 0° and 90°.
Ideal for horizontal or vertical
adjustments.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

38

Operations

Pythagoras (3-point)

The distance is calculated based on
the Pythagorean theorem with 3
known lengths of 2 right-angled tri­angles.

Leica DISTO™ X4

Aim laser at first tar get.

Aim laser at second target. Aim laser at third target.

39

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

The resultis shown in the main
lineand the measured distance
above. Pressing the measuring
key for 2 sec in the function activ­ates automatically Minimum or
Maximum measurement.
We r ecommend to use the
pythagoras only for indirect hori­zontal measuring. For height
measuring (vertical) it is more
precise to use a function with
inclination measurement.
Use Down navigation key to
take over values in the main line
for sending via Bluetooth®

Smart.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

40

Operations

Stake out

Two different distances (a and
b) can be entered to mar k off
defined measured lengths.

Select digit. Adjust digit. Approve value "a". Adjust value "b".

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

41

Operations

Approve value "b" and start meas­urement.

When approaching a stake out
point to less than 18 mm the
value of the stake out point is
frozen and the arrows on the
side change their colour to red
for marking purposes.

Leica DISTO™ X4

Move device slowlyalong the stake
out line. The distance to the next
stake out point is displayed.

The function can be stopped by
pressing the CLEAR/OFF but­ton.

a) Distance to first stake out point
b) Actual position to measured target
c) Distance to second stake out point

42

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

Timer

Select release time. Confirm setting.

The self release starts if
ON/Measure key is pr essed.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

43

Operations

Height tracking*

* Firmware update might be requiredthroughthe

Leica DISTO™ Plan Appto get this feature.

The height is calculated based on tri­gonimetric functions with 1 known
length and 1 measured angle.

Aim laser at lower point.

Aim laser at upper points and
angle/height tracking starts auto­matically.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

Stops height tracking.

44

www.GlobalTestSupply.com

Operations

Heights of buildings or trees
without suitable reflective points
can be determined. At the bot­tom point, distance and tiltis
measured - whichneeds a
reflectivelaser target. The
upper point can be targeted with
the pointfinder / crosshair and
does not need a reflective laser
target as only the inclination is
measured.
Use Down navigation key to
show more resultsor to take
over valuesin the main line for
sending via Bluetooth® Smart.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

45

Operations

Memory (last 20 results)

Leica DISTO™ X4

a) Delete memory
b) Take over value for further actions

Use Down navigation key to show
more detailed results of the specific
measurement.

Use Left/Right navigation keysto
switch between measurements.

46

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

Point to point measurement*

* Function is activated when connectedto theLeica

DST 360 adapter.

The tie distanceis calculated based
on 2 known coordinates with x,y and z
value.

Aim laser at first tar get point.

Aim laser at second target point.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Use Down navigation key to
take over values in the main line
for sending via Bluetooth®
Smart.

47

Operations

If chosen permanent meas­urement for second target point,
the actual tie distance is dis­played.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

48

Operations

Point to point measurement levelled*

* Function is activated when connectedto theLeica

DST 360 adapter.

Use thisPoint to Point measurement
function to get more measuring data.
Do not move device after levelling.
The tie distanceis calculated based

Rotate the device clockwise 90°. Fol­low the instructions on the display.
Levelling isfinished when OK icon
appears on the display.

on 2 known coordinates with x,y and z
value.

Check status line:
a) Indicates proper levelling
b) Indicates insufficient levelling

For levelling, device needs to be in an
inclination range of +/- 5°.

Rotate the device clockwise 90°. Fol­low the instructions on the display.

Aim laser at first tar get point.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

49

Operations

If chosen permanent measurement
for second target point, the actual tie
distanceis displayed.

Leica DISTO™ X4

Aim laser at second target point.

Use Down navigation key to
take over values in the main line
for sending via Bluetooth®
Smart.

50

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

Operations

Smart area measurement*

* Function is activated when connectedto theLeica

DST 360 adapter. Firmware update might be

requiredthrough theLeica DISTO™ Plan App to get

this feature.

The area is calculated based on sev­eral known coordinates with x,y and z
value.

Aim laser at first tar get point.

Aim at and measure additional points
(max. 30).

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

a) Circumference of measured area

Use Down navigation key to
take over values in the main line
for sending via Bluetooth®
Smart.

51

Operations

Bluetooth® Smart

DISTO™ Plan. Use App for
Bluetooth® data transfer. Your
device can be also be updated
through this App.

Bluetooth® Smart is always act­ive when the device is switched
on. Connect the device with
your smart-phone, tablet,
laptop... Measurement values
willbe transferred automatically
right after a measurement if
"Autosend" is activated. To
transfer a result press the fol­lowing softkey:

Bluetooth® switchesoff as soon as
the laser distance meter is switched
off.
The efficient and innovative
Bluetooth® Smart module (with the
new Bluetooth® standard V4.0)
works together with all Bluetooth®
Smart Ready devices.Allother
Bluetooth® devices do not support
the energy saving Bluetooth® Smart
Module, which is integrated in the
device.

We provide no warranty for free
DISTO™ software and offer no
support for it. We accept no liab­ility whatsoever arising from the
use of the free software and we
are not obliged to provide cor­rections nor to develop
upgrades. A wide range of com­mercial software can be found
on our homepage. Apps for
Android® or iOS can be found in
special internet shops. For more
details, see our homepage.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

52

Message Codes

Messa geCode s

No. Cause Correction

156 Transverse tilt gr eater than 10° Hold the instrument without any transverse tilt.

162 Calibration error Make sure the device isplaced on an absolutely horizontal and flat sur-

face. Repeat the calibration procedure. If the error stilloccurs contact
your dealer.

204 Calculationerror Perform measurement again.

240 Data transfer error Connect deviceand repeat procedure

252 Temperature too high Let device cool down.

253 Temperature too low Warm device up.

255 Received signaltoo weak, measuring time too long Change target surface ( e.g. white paper).

256 Received signaltoo high Change target surface ( e.g. white paper) .

257 Too much background light Shadow target area.

260 Laser beam interrupted Repeat measurement.

301 Device was moved, levelling not valid anymore Perform levelling again. Measuring with invalid levelling is partially pos-

sible, but it affectsthe accuracy.

303 Error with Leica DST 360 adapter Repeat measurement.

* If other messagecodes are displayedfrequently even the instrument has been swi tched off and on, please contact your dealer.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

53

Care

Care

l Clean the device with a damp, soft cloth.

l Never immerse the device in water.

l Never use aggressive cleaning agents or

solvents.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

54

Safety instructions

Safetyinstructions

The person responsible for the instrument
must ensure that allusers understand these
directionsand adhere to them. T he product
ispermitted to use for skilled persons only.

Symbols used

The symbols used have the following meanings:

WARNING

Indicatesa potentiallyhazardous situation or an
unintended use which, if not avoided, willresult in
death or serious injury.

CAUTION

Indicatesa potentiallyhazardous situation or an
unintended use which, if not avoided, may result in
minor injury and/or appreciable material, financial
and environmental damage.

Important par agraphs which must be
adhered to in practice as they enable the
product to be used in a technically correct
and efficient manner .

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

56

Safety instructions

Permitted use

l Measuring distances

l Tilt measurement

l Data transfer with Bluetooth®

Prohibited use

l Using the product without instruction

l Using outside the stated limits

l Deactivation of safety systems and

removal of explanatory and hazard labels

l Opening of the equipment by using tools

(screwdrivers, etc.)

l Use of accessories from other man-

ufacturers without express approval

l Carrying out modification or conversion

of the product

l Deliberate dazzling of third parties; also in

the dark

l Inadequate safeguards at the surveying

site (e.g. when measuring on roads, con­struction sites, etc.)

l Deliberate or irresponsible behaviour on

scaffolding, when using ladders, when
measuring near machines whichare run­ning or near parts of machines or install­ations which are unprotected

l Aiming directlyin the sun

Hazards in use

WARNING

Watch out for erroneous measurements if the
instrument isdefective or if it has been dropped or
has been misused or modified. Carry out periodic
test measurements. Particularlyafter the instru­ment has been subject to abnormal use, and
before, during and after important meas­urements.

CAUTION

Never attempt to repair the product yourself. In
case of damage, contact a localdealer.

WARNING

Changes or modificationsnot expresslyapproved
could void the user´ s authority to operate the
equipment.

CAUTION

Onlyuse chargers r ecommended by the man­ufacturer to charge the batteries.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

57

Safety instructions

Limits of use

Refer to section Technicaldata. The device
isdesigned for use in areas permanently hab­itable by humans. Do not use the product in
explosion hazardous areas or in aggressive
environments.

Areas of responsibility

Responsi bil ities of the manufacturer of the ori­ginal equipment:

Leica GeosystemsAG

Heinrich-Wild-Strasse
CH-9435 Heerbrugg
Internet: www.leica-geosystems.com

The company above is responsible for supplying
the product, including the User Manual in a com­pletelysafe condition.

The company above is not responsible for third
party accessories.

Responsi bil ities of the person in c harge of the
ins trument:

l To understand the safety instructionson

the product and the instructions in the
User Manual.

l To be familiar with local safety regulations

relating to accident prevention.

l Alwaysprevent accessto the product by

unauthorised personnel.

Disposal

CAUTION

Flat batteries must not be disposed of with house­hold waste. Care for the environment and take
them to the collection pointsprovided in accord­ance with national or localregulations.

The product must not be disposed with
household waste. Dispose of the pr oduct
appropriatelyin accordance with the national
regulations in force in your country. Adhere
to the national and country specific reg­ulations.

Product specific treatment and waste man­agement can be downloaded from our
homepage.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

58

Safety instructions

Electromagnetic Compatibility

(EMC)

WARNING

The device conforms to the most stringent require­ments of the relevant standards and regulations.
However, the possibility of causing interference in
other devices cannot be totallyexcluded.

FCC statement (applicable in U.S.)

This equipment has been tested and found to com­ply with the limits for a Class B digitalinstrument,
pursuant to part 15 of the FCC rules.These limits
are designed to provide reasonable protection
against harmful interference in a residential install­ation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio com­munications.

However, there is no guarantee that interference
willnot occur in a particular installation. If this equip­ment does cause harmful interference to radio or
television reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:

l Reorient or r elocate the receiving

antenna

l Increase the separation between the

equipment and the receiver

l Connect the equipment into an outlet on

a circuit different from that to which the
receiver isconnected

l Consult the dealer or an experienced radi-

o/TV technician for help

This device complies with part 15 of the FCC
rules. Operation is subjected to the following two
conditions:

l This device may not cause harmful inter-

ference, and

l this device must accept any interference

received, includinginterference that may
cause undesired operation.

FCC Radiati on Expos ure Statement

The radiated rf output power of the instrument is
below the FCC radio frequency exposure limits for
portable devicesaccording to KDB 447498.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

59

Safety instructions

ISED Statement (applicable in

Canada)

This device complies with Industry Canada's
license-exempt RSSs. Operation issubject to the
following two conditions:

l This device may not cause harmful inter-

ference, and

l this device must accept any interference,

including interference that may cause
undesired operation of the device.

Radio F requency ( RF) Expos ure Compliance
Statement

The radiated rf output power of the instrument is
below the Health Canada's Safety Code 6 exclu­sion limit for portable devices (radiated element
separation distancebetween the radiating ele­ment and user and/or bystander is below 20 cm).

Japanese Radio Law Compliance

This device is gr anted pursuant to the Japanese
Radio Law 電 波 法 . This device should not be
modified otherwise the granted designation num­ber will become invalid.

Use of the product with Bluetooth®

WARNING

Electromagnetic radiation can cause disturbances
in other equipment, in installations ( e.g. medical
ones such as pacemakers or hearing aids) and in
aircraft. It can also affect humans and animals.

Precautions :

Although this product conforms to the most strin­gent standards and regulations, the possibility of
harm to people and animals cannot be totally
excluded.

l Do not use the product near petrol sta-

tions, chemicalplants, in areas with a
potentiallyexplosiveatmosphere and
where blasting takesplace.

l Do not use the product near medical

equipment.

l Do not use the product in airplanes.

l Do not use the product near your body

for extended periods.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

60

Safety instructions

Laser classification

The device produces visible laser beams, which
are emitted from the instrument: It is a Class2
laser product in accordance with:

l IEC60825-1 : 2014 „Radiation safety of

laser products“

Laser Class 2 products:

Do not stare into the laser beam or direct it
towards other people unnecessarily. Eye pro­tection is normallyafforded by aversion responses
including the blinkreflex.

WARNING

Looking directly into the beam with opticalaids
(e.g. binoculars, telescopes) can be hazardous.

CAUTION

Looking into the laser beam may be hazardous to
the eyes. Don't dazzle other individuals. Pay par­ticular attention to the direction of the laser beam
when remotely operating the product via an app
or software. A measurement could be triggered at
any time.

Wavelength

620 - 690 nm

Maximum radiant output power for classification

< 1 mW

Pulseduration

> 400 ps

Pulserepetition frequency

320 MHz

Beam divergence

0.16 x 0.6 mrad

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

61

Safety instructions

Labelling

Subject to change (drawings, descriptions and
technicaldata) without prior notice.

Leica DISTO™ X4

Find Quality Products Online at: [e-mail]

www.GlobalTestSupply.com

62
