¥LEGEND





Consolidated Catalo

ES & FITTINGS

HYPERPURE

®  O

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

Guaranteed Performance

Every order is processed in 24 hours or 5% off the order; 100% line item ll rate or 5% off the backorder; 100% line item order accuracy or 5% off the error; the Legendary 5/25 product warranty; no minimum order; no case pack quantity requirement; and material may be returned with no re-stocking fees.

Legendary Customer Service

You will always talk to a human, no voice mail or automated assistance. Trained customer service representatives to support you and your business striving to achieve 100% problem resolution in one call.

Expert Engineering

A fully-functioning and staffed laboratory for product development and design; quality assurance; and product testing assuring you and your customers the best quality products.

On Demand Technical Support

Degreed engineers, master plumbers and technical advisers with decades of PVF and hydronic experience are on demand to support your business.

Comprehensive Training

Expert staff as course instructors for distributor and contractor training classes scheduled throughout the year.

Legend Guarantee is the best in the industry

Our 5/25 warranty replaces any valve proven to be defective within ve years of installation and reimburses the installing contractor $25.00.

Wholesale Terms and Conditions of Sale

Terms of Payment 2% 30 Days, Net 45 - Cash discount is to be

calculated on the total amount of the invoice before additions for transportation. A 1-1/2% service charge per month will be added to past due balances.

Freight Policy

Freight charges will be prepaid on orders of $1,500.00 net or more (see exceptions below) to one destination in the Continental United States. Otherwise, freight terms are F.O.B. Auburn Hills, Michigan or Reno, Nevada. Call Legend Customer Service at 800-752-2082 for shipments to Alaska and Hawaii.

Freight Policy Freight charges will be prepaid on orders to one destination in the Continental United States as follows: orders of $2,500.00 net or more for Cast & Ductile Iron valves; orders of $2,500.00 net or more for QuickTherm® and VersaTherm® radiant panels; and orders of $3,500.00 net or more for HyperPure® PE-RT Tubing 10’ and 20’ sticks. All Legend products may be combined to reach either the $2,500.00 or $3,500.00 net. Otherwise, freight terms are F.O.B. Auburn Hills, Michigan or Reno, Nevada.

Minimum Order

Legend has no minimum order requirement.

Order Acceptance

All orders are subject to acceptance by Legend Valve & Fitting, Inc. Possession of our catalog or price list by any person should not be construed as an offer to sell to that person. All prices are subject to change without notice.

Signature Series

Private label ball valves allow you to customize the handle, including using your logo. This program is available for select ball valves. For more information, call Legend Customer Service.

Oxygen Cleaning

For most valves and ttings oxygen cleaning

is available. Material is cleaned, tagged

and bagged. Lead time is ve business days.

For more information, call Legend Customer Service.

A Legendary Guarantee

5 year / $25 warranty. For complete details of this legendary warranty please call Legend Customer Service at 1-800-752-2082, or visit www.legendvalve.com.

We’ve got your back. Top row: Nathan, Katie, Larry, Lori, Kevin, Tasha, Jason. Bottom row: Sue, Nancy, Marge, Dave, Kelly

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

No Lead Product Identiﬁcation

Product meets National and state no lead plumbing laws.

1/4” T-2000 No Lead

www.legendvalve.com

3/4”

NO LEAD FULL PORT BALL VALVE

Product meets National and state no lead plumbing laws.

1/4” T-2000 No Lead

www.legendvalve.com

3/4”

NO LEAD FULL PORT BALL VALVE

1/4” T-2000

www.legendvalve.com

Product not legal for use in potable water systems after January 4, 2014.

Product meets National and state no lead plumbing laws.

3/4”

FULL PORT BALL VALVE

1/4” T-2000 No Lead

3/4” T-2000 No Lead / 101-411NL

www.legendvalve.com

NO LEAD

This product has been 3rd party certified to contain less than 0.25% lead by weighted average on wetted surface

areas and can be used on all potable water systems

3/4”

NO LEAD FULL PORT BALL VALVE

SAMPLE

Legend No Lead brass or bronze valves and ttings are easy to identify and order.

Legend No Lead valves and ttings comply with the Federal No Lead Law 111-380 and are third-party certied.

All No Lead brass and bronze alloy valves and ttings are highlighted in gray shading throughout this price list. Legend also adds the sufx “NL” to both the model and item number to identify the No Lead version of

each product offered. Brass and bronze items not highlighted in gray are available in traditional alloy only.

T-2000 No Lead

1/4” T-2000 No Lead

NO LEAD FULL

3/4”

PORT BALL VALVE

Product meets National and state no lead plumbing laws.

www.legendvalve.com

NO LEAD

This product has been 3rd party certified to contain less than 0.25% lead by weighted average on wetted surface

areas and can be used on all potable water systems

3/4” T-2000 No Lead / 101-411NL

SAMPLE

101-414NL

NO LEAD

IDENTIFICATION

Example: If selecting a 3/4” size T-2000 ball valve, the item number 101-414 is for the traditional brass version and item number 101-414NL is for the no lead brass T-2000NL.

As many brass alloy valves and ttings have multiple uses (ie. gas, process piping, hydronics), Legend traditional brass and bronze valves and ttings for non-potable water applications are marked and identied.

We’ve got your back. Visit legendvalve.com for list price sheets in PDF and Excel format, submittals,

instruction manuals, tech bulletins and new product features.

3/4”

Product not legal for use in potable water systems after January 4, 2014.

T-2000

FULL PORT BALL VALVE

www.legendvalve.com

1/4” T-2000

FULL PORT BALL VALVE

WARNING: Wetted surface area has a weighted average lead

content greater than 0.25%. It is unlawful to use this product to install

or repair any system that provides water intended for human

consumption in the United States (Effective 1/4/2014).

3/4” T-2000 / 101-411

101-414

SAMPLE

TABLE OF CONTENTS

BALL VALVES

LegendPress Ball Valves ..........................................10

P-200, P-200NL Legend Press .............................. 10

Full Port Ball Valves ............................................. 10-14

T/S-1001, T/S-1001NL Ball Valves ..................10-11

T/S-1004, T/S-1004NL Pro Pattern ..................11-12

T/S-1002, T/S-1002NL Gland Follower Design ......12

T/S-2000, T/S-2000NL Ball Valves .......................13

T/S-2001NL Ball Valves ........................................14

Bronze Ball Valves .....................................................14

T/S-901, T/S-901NL Bronze .................................... 14

Specialty Ball Valves ........................................... 15-18

T/S-1100, T/S-1100NL, T/S-1102, T/S-1102NL,

T/S-2102NL with Drain ............................................ 15

T-1002ST SS Ball & Stem .....................................15

T-1002STLD SS Ball & Stem, Locking Device .......16

T-1002LD Locking Device ......................................16

T-1007 FNPT x Sweat ...........................................16

T-1001LD, T-1001LDNL Locking Device ................16

T/S-1001T, T/S-1001TNL Tee Handle ...................17

T-1009NL Compression .........................................17

T-2009NL Compression .........................................17

T-2002NL Compression with Drain .......................17

T-2100 Three-way .................................................17

T-1002CC with Cap & Chain..................................17

T-2010NL Insert Barb Full Port Ball Valve .............18

T-2000NL MNPT x Sweat......................................18

Insta-Loc II™ Push Fit Ball Valves ..........................18

P-2200NL No Lead ............................................... 18

P-2200NL Drop Ear Push Fit Ball Valve .................18

P-2200NL Push x FNPT .......................................... 18

PEX Ball Valves ..................................................... 19-20

T-806NL PEX End ..................................................19

T-805NL MNPT/Sweat x PEX ................................19

T-2006NL F1807 PEX End ......................................19

T-2006NL F1807 PEX with Tee Handle ..................19

T-2007NL F1807 PEX with Tee & Drain .................19

T-2005NL F1807 PEX MNPT x PEX ........................19

T-2008NL F1807 PEX with Drop Ear ......................19

T-1960NL F1960 PEX End ......................................20

T-1960NL F1960 PEX with Drop Ear ......................20

T-1960NL F1960 PEX MNPT x PEX ........................20

T-1960SNL F1960 PEX x Sweat.............................20

T-1960DENL F1960 PEX with Drop Ear .................20

Mini Ball Valves .................................................... 20-22

T-900, T-900NL MNPT x FNPT Large Port .............20

T-900T, T-900TNL MNPT x FNPT Tee Handle .......21

T-810 Micro Ball™.................................................21

T-800T, T-800TNL Micro Ball™..............................21

T-801NL Test Cocks, Screwdriver Slot ..................21

Chome Plated Brass FNPT x FNPT ........................ 21

Chome Plated Brass FNPT x MNPT ......................21

T-710T, T-710MxF-T Stainless Steel .....................22

Ball Valves Accessories .................................. 22-23

Locking Device, Handle Extensions, Memory Stop, T-Handle, Lever Handle, Stainless Steel Lever

& T- Handles .....................................................22-23

T-717 Replacement PTFE Packing Seats ...............23

Stainless Steel Ball Valves - Investment Cast ...24

T-717 3-Piece 316 Stainless Steel .......................24

T-712 2-Piece 316 Stainless Steel .......................24

T-715 2-Piece 316 Stainless Steel Large Port ......24

T-710 1-Piece 316 Stainless Steel Conv. Port .......24

Carbon Steel Ball Valves - Investment Cast .......25

T-730 2-Piece Carbon Steel ..................................25

T-725 2-Piece Carbon Steel Large Port ................25

T-720 1-Piece Carbon Steel Conv. Port ................25

Gas Ball Valves .................................................. 26-27

Drip Leg Kits .......................................................... 26

Blue Top™ Patented One-Piece Design ...........26-27

Red Top™ Economy Gas Ball Valves .....................27

T-408X Cross Handle Gate Valve ..........................31

T/S-400, T/S-400NL Compact Pattern ................. 31

Brass Cross Handles ............................................. 31

Globe Valves ............................................................32

T/S-421, T/S-421NL Bronze Globe .......................32

T-422 Union Bonnet Bronze Globe ........................32

T-752 316 Stainless Steel Globe...........................32

Check Valves ..................................................... 32-35

T/S-451, T/S-451NL Swing Check ...................32-33

P-451NL LegendPress™ Swing ............................. 33

T/S-453, T/S-453NL Bronze Y-Pattern

Swing Check .........................................................34

T/S-455, T/S-455NL In-Line Check ..................34-35

T-450NL In-Line Check ..........................................35

Stainless Steel Check Valves ................................36

T-750 316 Stainless Steel Check ..........................36

Foot Check Valves ...................................................36

T-448NL Bronze Foot Valves .................................36

T-756 304 Stainless Steel Foot Valves .................36

Y-Strainers.......................................................... 36-40

T/S-15, T/S-15NL Bronze Y-Strainers ..............36-37

T-16, T-16NL Compact Y-Strainer .....................37-38

Y-Strainer Screens ...........................................38-39

T-17 Cast Iron Y- Strainers ....................................39

T-19 Flanged Cast Iron Y- Strainers ......................39

T-758 316 Stainless Steel Y-Strainers ..................40

For everything you need behind the wallTM see product listing by part number in the index on page 160.

Frostfree Sillcocks ............................................ 40-44

GATE, CHECK, & LOW PRESSURE

Stainless Steel Gate Valves ..................................28

T-751 316 Stainless Steel ....................................28

Bronze Gate Valves .......................................... 28-29

T-416 Rising Stem .................................................28

T/S-414 Screw-Over Bonnet ................................. 28

T/S-415 Inserted Bonnet ..................................28-29

T-420 Quick Opening Gate Valve ..........................29

T-420 Brass Handle ...............................................29

Brass Gate Valves ............................................. 29-31

T/S-401, T/S-401NL Brass Gate ......................29-30

T/S-408, T/S-408NL Economy Brass ....................30

T-550, T-550NL 1/4 Turn ........................................40

T-550 Replacement Parts ......................................41

T-552 Close Coupled .............................................41

TM-550, TM-550NL Multi-turn .......................41-42

TM-550 Replacement Parts .................................. 42

T-550, TM-550 Repair Kit ......................................42

T-552, T-552NL ......................................................43

T-552 Repair Accessories......................................43

T-551, T-551 NL Multi-turn ....................................44

1/4-Turn Plumbing Valves ................................ 44-46

R-670, R-670NL, R-672, R672NL, Boiler Drain .....44

R-673, R673NL, R-674, R-674NL Sillcock .......44-45

R-671, R-671NL No Kink Hose Bibb ...................... 45

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

T-537, T-537NL, T-537L , T-537LNL Hose Bibb ...... 45

T-540 Water Heater Drain Valve ...........................45

T/S-541FLG Flanged Sillcock ................................ 45

T/S-541CFL Chrome Flanged Sillcock ................... 46

T-547RB Commercial Ball Type Sillcock ................46

T-548 Satin Commercial Ball Type Sillcock ...........46

T-549CP Commercial Ball Type Sillcock ................46

Low Pressure Plumbing Valves ...................... 47-52

Stop Valve .............................................................. 47

T/S-501NL, T-501X, S-501PNL ..............................47

Long Bonnet Stop ................................................... 47

T/S-504, T/S-504NL, T/S-505,

T/S-505NL ............................................................. 47

Angle Stop .............................................................. 47

T/S-503NL ............................................................. 47

Stop & Waste Valves .............................................. 48

T/S-511NL, T-512NL, S-511PNL ...........................48

Boiler Drain Valves .................................................. 48

T/S-521, T/S-521NL, T-522, T-522NL, S-524,

S-524NL ................................................................48

T-523NL, S-521P, S-521PNL, T-206,

T-206NL .................................................................48

Hose Bibbs..............................................................49

T-531, T-531NL, T-532, T-532NL ............................ 49

T-532CP, T-532CPNL Chrome .................................49

T-533, T-533NL, T-534, T-534NL ............................ 49

S-535, S-535NL ..................................................... 49

Heavy Pattern Hose Bibbs ....................................... 50

T-531HP, T-531HPNL .............................................50

T-533HP, T-533HPNL, T-534HP, T-534HPNL,

S-535HP, S-535HPNL............................................. 50

T-536HP, T-536HPNL ..............................................50

Sillcocks Valves .................................................50-51

T/S-541, T/S-541NL,T/S-541LS,

T/S-541LSNL Sillcocks .......................................... 50

S-211, S-211NL Sillcocks ...................................... 51

T-514P, T-514PNL - F1807PEX ...............................51

T-514P, T-514PNL - F1960 PEX .............................51

Commercial Sillcocks, Chrome ................................. 51

T-545VB, T-545VBNL, T-546VB, T-546VBNL ......... 51

Bent Nose Garden Valves ........................................ 52

T-543, T-543NL, T-544, T-544NL ........................... 52

Water Heater Drain Valves……………………………….52

T-539, T-539NL ...................................................... 52

Supply Stops - 1/4 Turn .................................... 52-54

Insta-Loc™ T-595NL, T-596NL ............................... 52

T-595NL, T-595PBNL, T-593NL Angle ...................53

T-596NL, T-596PBNL, T-594NL Straight ................53

T-597NL Dual Outlet..............................................54

T-598NL No Lead Brass Dual Handle 1/4 turn......54

Supply Stops - Traditional Style ...................... 54-56

T/S-581NL, S-581ETNL, T/S-581LS,

T/S-581LSNL Angle Valves ..............................54-55

T/S-582NL, S-582ETNL, T/S-583NL,T-584NL

Straight Valves .................................................55-56

T-587 Dual Outlet ..................................................56

THERMOPLASTIC VALVES

PVC Buttery Valves ...............................................58

S-650, S-651 .........................................................58

PVC Ball Valves ................................................. 58-61

S-643 Grey PVC Flanged True

Union ..................................................................... 58

T/S-603 Grey PVC True Union ...............................58

T/S-603V Grey PVC True Union Viton O-rings .......59

T/S-645 Grey PVC Single Union ............................ 59

T/S-602, S-602EZ Grey PVC

Compact ................................................................ 59

T/S-600, T/S-601, S-601EZ PVC

Compact Ball Valves .............................................60

S-608 ABS Compact - Black .................................. 61

PVC Check Valves ...................................................61

T/S-655 Grey PVC Ball Check ...............................61

Grey PVC Foot Valve Screens ................................61

T/S-611 PVC In-Line .............................................. 61

Backwater Valves ...................................................62

S-640, S-641, S-660, S-661 .................................62

Sump Pump Check Valves .....................................62

S-613, S-614, S-670, S-672 ..................................62

CPVC Ball Valves .....................................................63

S-605, S-606 .........................................................63

S-607 Schedule 80 CPVC ...................................... 63

Plastic Low Pressure Valves ........................... 63-64

CPVC, PVC, Celcon Low Pressure Valves ........ 63-64

PVC & CPVC Unions.......................................... 64-65

PVC Schedule 80, Schedule 40 Unions ................. 64

CPVC Unions .........................................................64

PVC Male, PVC Spigot Adapters ........................... 65

CAST IRON VALVES

Cast Iron Valves ......................................................66

T-303 OS & Y Gate Valves ....................................66

T-301 Non-Rising Stem Gate Valves .....................66

T-311 Swing Check Valves ....................................66

T-19 Flanged Cast Iron Y- Strainers ...................... 66

Ductile Iron Wafer Check Valves .........................67

T-312 Wafer Check Valves ....................................67

T-312 SS Disc Wafer Check Valves.......................67

T-312 Ductile Iron Wafer Check Valves ................67

Ductile Iron Buttery Valves ........................... 67-73

Wafer Type .................................................... 67-70

T-335AB EPDM Seat - Lever Handle .....................67

T-335AB-G EPDM Seat - Gear Operator ...............68

T-337AB Buna-N-Seat - Lever Handle ..................68

T-337AB-G Buna-N-Seat Gear Operator ...............68

T-335DI EPDM Seat - Lever Handle .....................69

T-335DI-G EPDM Seat - Gear Operator.................69

T-337DI Buna-N-Seat - Lever Handle....................69

T-337DI-G Buna-N-Seat - Gear Operator..………69

T-335SS - Stainless Steel Disc EPDM ..................70

T-337SS - Stainless Steel Disc Buna-N-Seat .......70

Lug Type ..........................................................70-72

T-365AB EPDM Seat - Lever Handle .....................70

T-365AB-G EPDM Seat - Gear Operator ...............70

T-367AB Buna-N-Seat - Lever Handle ..................71

T-367AB-G Buna-N-Seat Seat - Gear Operator ...71

T-365DI EPDM Seat - Lever Handle …………..71

T-365DI-G EPDM Seat - Gear Operator.................71

T-367DI Buna-N-Seat - Lever Handle…………..72

T-367DI-G Buna-N-Seat - Gear Operator……….72

T-365SS - Stainless Steel Disc EPDM ..................72

T-367SS - Stainless Steel Disc Buna-N Seat........72

Gear Operator .......................................................73

SPECIALTY PRODUCTS

Backow Valves ......................................................74

T-459 Backow Preventers, Atmospheric Vent .....74

T-457, T/S-457NL Dual Check ...............................74

Vacuum Breakers ...................................................74

T-553, T-553NL, T-553C, T-553CNL, T-554 ..........74

T-557, T-557C Self Draining ................................ 74

TABLE OF CONTENTS

SPECIALTY PRODUCTS CONTINUED

Log Lighter Valves ............................................. 74-75

T-3500, T-3500PB Straight Pattern, Ball ............... 74

T-3501, T-3501PB Angle Pattern, Ball ................... 74

T-3200, T-3200PB Straight Pattern, Globe ............ 75

T-3201, T-3201PB Angle Pattern, Globe ................ 75

Escutcheon and Key Accessories .........................75

T-3205 Natural Gas Burner Bar .............................75

T-3200, T-3200PB, T-3201, T-3201PB, T-3500

, T-3500PB, T-3501, T-3501PB, Log Lighter Kits ......75

Meter Valves ............................................................76

T-441NL, T-442NL Bronze Angle

Meter Valves .........................................................76

T-443NL Meter Angle Ball Valve ..........................76

Washing Machine Valves ......................................76

T/S-11, T/S-11NL Valves ......................................76

T-12, T-12NL Chrome plated ................................. 76

Dishwasher Elbow .................................................. 76

No Lead Dishwasher Elbow .................................. 76

Pressure Relief Valves ...........................................77

T-50NL Pressure Relief Valve ................................77

Float Valves ..............................................................77

T-30, T-31, T-32 Bronze Float Valves .....................77

Float Rods .............................................................77

Copper & Plastic Floats ......................................... 77

Evaporative Cooler Valves .....................................78

T-542, T-542NL ...................................................... 78

T-34 Standard Cooler Valve ..................................78

T-35 Compact Cooler Valve ...................................78

Anti-Sweat Valves ..................................................78

T-20, T-20A Anti-Sweat Valves ............................. 78

Dielectric Fittings .............................................. 78-80

T-575 Dielectric Nipples........................................78

T-578 Dielectric Couplings ....................................78

T-571NL Forged Steel Dielectric Unions ...............79

T-572 Galvanized x Galvanized

Dielectric Unions ................................................... 79

T-573NL Galvanized x Brass Dielectric Unions .....79

T-574 Black Gas Service Dielectric Unions ...........79

Rubber Gaskets ..................................................... 80

Gaskets & Inserts For Steam ................................ 80

Compression Repair Fittings ........................... 80-81

Galvanized Compression Couplings ...................... 80

Brass Compression Couplings ..............................81

PVC Compression Couplings ................................. 81

CPVC Compression Couplings ............................... 81

PVC Expansion Repair Couplings .......................... 81

Transition Fittings ....................................................82

PEX x CPVC Adapters ............................................ 82

No Lead Brass x CPVC Transition Fittings.............82

Stainless Steel x CPVC Transition Fittings............82

Specialty Brass Fittings ......................................... 83

Raised Square Head Plugs .................................... 83

Countersunk Plugs ................................................83

Brass Trap Connectors ..........................................83

Brass Fire Hose Fittings ................................... 83-84

Female x Male Brass Hydrant Adapters ............... 83

Double Male Hex Nipples ..................................... 84

MANIFOLDS

Manifolds.......................................................... 98-125

M-8000 Modular Manifolds ..........................98-101

M-8000 Components ..................................101-102

M-8100 Plastic Manifolds ...........................103-104

M-8100 Components ...................................104-106

M-8200 Precision Brass Manifolds .............107-110

M-8200 Accessories ....................................110-113

M-8220 High Capacity Manifolds ................114-115

M-8220 Accessories ....................................116-117

M-8400 Geothermal Manifolds ...................118-119

VersaTherm and QuickTherm worksheet on page 150

Female x Male Hex Nipples .................................. 84

Female x Male Swivel Adapters ........................... 84

Caps & Plugs with Chains ..................................... 84

RADIANT PANEL SYSTEMS

Radiant Panel Systems .................................... 88-90

VersaTherm Floor System ................................88-89

QuickTherm Floor System ..................................... 90

Tubing Installation Accessories ..................... 90-94

Tube Holding Pins ..................................................90

Bend Supports ....................................................... 91

Heat Transfer Plates..............................................91

Tube Track, Mounting Rail .................................... 92

Tube Repair ...........................................................93

Tube Talon Fasteners ............................................ 93

Tube Clamps ..........................................................93

Snapp Rail / Clip System ...................................... 94

ST-100 Staple Tool ................................................ 94

LEGENDFLEXTM TUBING

LegendFlex Heating Tube ................................ 95-96

LegendFlex PEX Tubing ....................................95-96

M-8330 Stainless Steel Manifolds ..............120-121

M-8300E Economy Stainless Steel ..................... 122

M-8300EV Economy Manifold with Valves ........122

Stainless Steel Manifold Accessories .........123-125

HYDRONIC SYSTEM COMPONENTS

Hydronic System Components.................... 126-137

Legend Connect System & Components .....126-127

T-88 Air & Debris Eliminator ........................128-129

HS-808 Hydraulic Separator ............................... 130

T-88 & HS-808 Accessories ................................131

LMV-3 Three-Way Mixing Valve .........................132

AF-480 Auto Fill BackFlow Preventer .................133

HX-100 , HX-200, HX-300 Heat Exchangers ....... 134

HX-100B, HX-160B, HX-200B

Compact Heat Exchangers .................................. 134

LZV-2 Two Way Zone Valves ...............................135

LZV-3 Three Way Zone Valves ............................135

T-825 Temperature & Pressure Gauges ....... 136-137

T-820 Test Gauges ............................................... 137

HEATING VALVES

Bronze Heating & Radiator Valves ............. 138-139

T-431, T-431YB Steam Angle Radiator Valves .... 138

T/S-437 Hot Water Angle Valves .......................138

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

T-435, T-435YB Radiator Gate Valves ................. 138

T-433, T-433YB Convector Steam Angle Valves .. 139

T/S-438 Union Elbows ........................................ 139

S-464 Purge & Balancing Valves ........................139

S-439 Balancing Valves ......................................139

T/S-425 Straight Circulator Valves .....................139

Radiator Valve Handles .......................................139

Heating Specialties....................................... 140-144

T/S-1002FLG Isolation Ball Valves - Flanged ......140

T/S-2011RFLG, P-2011 Isolation Ball Valves -

Rotating Flange ................................................... 140

T/S-2012RFLG Isolation Ball Valves -

Rotating Flange & Purge ..................................... 140

Tankless Water Heater Valve Kits ...............140-141

Pressure Relief Valves ........................................141

T-565, T-566 Oil Tank Valves ...............................141

T-60, T-60A, T-61, T-63, T-65

Chrome Steam Air Vents .....................................142

T-90, T-90A, T-91, T-93, T-95

Chrome Economy Air Vent ..................................142

T-70 Automatic Hot Water Air Vents ..................142

T-70H High Capacity Auto Air Vent .....................142

T-73 Automatic Air Vents ....................................142

T-75 Manual Adjustable Air Vent .......................143

T-77 Coin Key Air Vent ........................................143

T-80 Air Purgers...................................................143

Carbon Steel Boiler Manifold Headers ........143-144

T-570, T-570NL Mono-Flow Tees ........................144

T-569 Venturi Tees ...............................................144

SOLAR PUMP SYSTEM

Solar Pump Systems..................................... 148-149

SunStation Solar Pump System ...................148-149

FLOORING ESTIMATE SHEET

Floor System Material Estimate Worksheet .....150

VersaTherm and QuickTherm Worksheet ...........150

HYPERPURE® TUBE

HyperPure PE-RT .......................................... 152-155

HyperPure Coils, Sticks ................................152-155

TOOLS & ACCESSORIES

Tools ............................................................... 156-158

Accessories ..................................................156-157

LDPE Plastic Tubing .............................................158

INDEX

AMBIANCETM CEILING PANELS

Ceiling Panels ........................................................ 146

Ambiance ............................................................ 146

CUSTOM MECHANICAL PANELS

Mechanical Panels ............................................... 147

Mechanical Panels .............................................. 147

We’ve got your back. Traci and Melissa

Index By Part Number .......................................... 160

LEGENDPRESSTM BALL VALVES

No lead brass and bronze alloy items are highlighted in gray.

VALVES & FITTINGS

LegendPress Ball Valve

Traditional & no lead forged brass ISO 9002 600 CWP (1/2”, 3/4”), 500 CWP (1”, 1-1/4”) 400 CWP (1-1/2” - 4”) ANSI/NSF 61 (P-200NL)

P-200

Part No. Size Conﬁguration Model No. Cs/Ct

101-003 1/2” Press x Press P-200 50/5

101-003NL 1/2” Press x Press P-200NL 50/5

101-004 3/4” Press x Press P-200 30/5

101-004NL 3/4” Press x Press P-200NL 30/5

101-005 1” Press x Press P-200 18/3

101-005NL 1” Press x Press P-200NL 30/3

101-006 1-1/4” Press x Press P-200 12/2

101-006NL 1-1/4” Press x Press P-200NL 12/2

101-007 1-1/2” Press x Press P-200 10/2

101-007NL 1-1/2” Press x Press P-200NL 10/2

101-008 2” Press x Press P-200 8/2

101-008NL 2” Press x Press P-200NL 8/2

101-009 2-1/2” Press x Press P-200 2/1

101-009NL 2-1/2” Press x Press P-200NL 2/1

101-010 3” Press x Press P-200 2/1

101-010NL 3” Press x Press P-200NL 2/1

101-011 4” Press x Press P-200 1/1

101-011NL 4” Press x Press P-200NL 1/1

FULL PORT BALL VALVES

Full Port Ball Valve

Traditional & no lead forged brass ISO 9002, 600 CWP 400 CWP (2-1/2” - 4”), 150 WSP ANSI/NSF 61 (T/S-1001NL) UL listed (1/4” - 2” T-1001/T-1001NL)

CSA certied 1/2, 5, 125 psig

(1/4" & 1/2"-2" T-1001/T-1001NL)

FM approved (1/2” - 2” T-1001/T-1001NL)

T-1001

101-300 1/8” FNPT x FNPT T-1001 200/20

101-300NL 1/8” FNPT x FNPT T-1001NL 200/20

101-101 1/4” FNPT x FNPT T-1001 200/20

101-101NL 1/4” FNPT x FNPT T-1001NL 200/20

101-102 3/8” FNPT x FNPT T-1001 100/10

101-102NL 3/8” FNPT x FNPT T-1001NL 100/10

101-023 1/2” FNPT x FNPT T-1001 100/10

101-023NL 1/2” FNPT x FNPT T-1001NL 100/10

101-024 3/4” FNPT x FNPT T-1001 100/10

101-024NL 3/4” FNPT x FNPT T-1001NL 100/10

101-025 1” FNPT x FNPT T-1001 50/10

101-025NL 1” FNPT x FNPT T-1001NL 50/10

101-026 1-1/4” FNPT x FNPT T-1001 20/10

101-026NL 1-1/4” FNPT x FNPT T-1001NL 20/10

101-027 1-1/2” FNPT x FNPT T-1001 20/4

101-027NL 1-1/2” FNPT x FNPT T-1001NL 20/4

101-028 2” FNPT x FNPT T-1001 20/4

101-028NL 2” FNPT x FNPT T-1001NL 20/4

101-109 2-1/2” FNPT x FNPT T-1001 6/2

101-109NL 2-1/2” FNPT x FNPT T-1001NL 6/2

101-110 3” FNPT x FNPT T-1001 4/2

101-110NL 3” FNPT x FNPT T-1001NL 4/2

101-111 4” FNPT x FNPT T-1001 2/1

101-111NL 4” FNPT x FNPT T-1001NL 2/1

FULL PORT BALL VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

VALVES & FITTINGS

Full Port Ball Valve

Traditional & no lead forged brass ISO 9002, 600 CWP 400 CWP (2-1/2” - 4”), 150 WSP ANSI/NSF 61 (T/S-1001NL) UL listed (1/4” - 2” T-1001/T-1001NL)

CSA certied 1/2, 5, 125 psig

(1/4" & 1/2"-2" T-1001/T-1001NL)

FM approved (1/2” - 2” T-1001/T-1001NL)

S-1001

101-043 1/2” Sweat x Sweat S-1001 100/10

101-043NL 1/2” Sweat x Sweat S-1001NL 100/10

101-044 3/4” Sweat x Sweat S-1001 60/10

101-044NL 3/4” Sweat x Sweat S-1001NL 60/10

101-045 1” Sweat x Sweat S-1001 36/6

101-045NL 1” Sweat x Sweat S-1001NL 36/6

101-046 1-1/4” Sweat x Sweat S-1001 24/4

101-046NL 1-1/4” Sweat x Sweat S-1001NL 24/4

101-047 1-1/2” Sweat x Sweat S-1001 16/4

101-047NL 1-1/2” Sweat x Sweat S-1001NL 16/4

101-048 2” Sweat x Sweat S-1001 10/2

101-048NL 2” Sweat x Sweat S-1001NL 10/2

101-209 2-1/2” Sweat x Sweat S-1001 6/2

101-209NL 2-1/2” Sweat x Sweat S-1001NL 6/2

101-210 3” Sweat x Sweat S-1001 4/2

101-210NL 3” Sweat x Sweat S-1001NL 4/2

101-211 4” Sweat x Sweat S-1001 4/1

4” S-1001 is conventional port.

Full Port Ball Valve, Pro Pattern

Traditional & no lead forged brass ISO 9002, 600 CWP, 150 WSP ANSI/NSF 61 (T/S-1004NL)

CSA certied 1/2, 5, 125 psig (1/2"-2" T-1004) 5, 125 psig (1/2"-2" T-1004NL)

UL listed (1/2” - 2” T-1004)

FM approved (1/2” - 2” T-1004 / T-1004NL)

101-013 1/2” FNPT x FNPT T-1004 100/10

101-013NL 1/2” FNPT x FNPT T-1004NL 100/10

101-014 3/4” FNPT x FNPT T-1004 100/10

101-014NL 3/4” FNPT x FNPT T-1004NL 100/10

101-015 1” FNPT x FNPT T-1004 50/10

101-015NL 1” FNPT x FNPT T-1004NL 50/10

101-016 1-1/4” FNPT x FNPT T-1004 20/10

101-016NL 1-1/4” FNPT x FNPT T-1004NL 20/10

101-017 1-1/2” FNPT x FNPT T-1004 20/4

101-017NL 1-1/2” FNPT x FNPT T-1004NL 20/4

101-018 2” FNPT x FNPT T-1004 20/4

101-018NL 2” FNPT x FNPT T-1004NL 20/4

101-019 2-1/2” FNPT x FNPT T-1004 4/2

101-020 3” FNPT x FNPT T-1004 2/1

Cubic Ball

T-1004

101-021 4” FNPT x FNPT T-1004 2/1

101-033 1/2” Sweat x Sweat S-1004 100/10

101-033NL 1/2” Sweat x Sweat S-1004NL 100/10

101-034 3/4” Sweat x Sweat S-1004 60/10

101-034NL 3/4” Sweat x Sweat S-1004NL 60/10

101-035 1” Sweat x Sweat S-1004 36/6

101-035NL 1” Sweat x Sweat S-1004NL 36/6

101-036 1-1/4” Sweat x Sweat S-1004 24/4

S-1004

Cubic Ball

101-036NL 1-1/4” Sweat x Sweat S-1004NL 24/4

101-037 1-1/2” Sweat x Sweat S-1004 16/4

101-037NL 1-1/2” Sweat x Sweat S-1004NL 16/4

FULL PORT BALL VALVES

No lead brass and bronze alloy items are highlighted in gray.

VALVES & FITTINGS

Full Port Ball Valve, Pro Pattern

Traditional & no lead forged brass ISO 9002, 600 CWP, 150 WSP ANSI/NSF 61 (T/S-1004NL)

CSA certied 1/2, 5, 125 psig (1/2"-2" T-1004) 5, 125 psig (1/2"-2" T-1004NL)

UL listed (1/2” - 2” T-1004)

FM approved (1/2” - 2” T-1004 / T-1004NL)

Full Port Ball Valve, Gland Follower Design

Traditional & no lead forged brass ISO-9002, 600 CWP, 150 WSP ANSI/NSF 61 (T/S-1002NL)

CSA certied 1/2, 5, 125 psig

(1/2"-2" T-1002/T-1002NL) UL listed (1/2” - 2” T-1002)

FM approved (1/2” - 2” T-1002) Third party certied

T-1002

Part No. Size Conﬁguration Model No. Cs/Ct

101-038 2” Sweat x Sweat S-1004 10/2

101-038NL 2” Sweat x Sweat S-1004NL 10/2

101-039 2-1/2” Sweat x Sweat S-1004 6/2

101-040 3” Sweat x Sweat S-1004 2/1

101-061 1/4” FNPT x FNPT T-1002 180/10

101-061NL 1/4” FNPT x FNPT T-1002NL 180/10

101-062 3/8” FNPT x FNPT T-1002 180/10

101-062NL 3/8” FNPT x FNPT T-1002NL 180/10

101-063 1/2” FNPT x FNPT T-1002 120/10

101-063NL 1/2” FNPT x FNPT T-1002NL 120/10

101-064 3/4” FNPT x FNPT T-1002 90/10

101-064NL 3/4” FNPT x FNPT T-1002NL 90/10

101-065 1” FNPT x FNPT T-1002 60/6

101-065NL 1” FNPT x FNPT T-1002NL 60/6

101-066 1-1/4” FNPT x FNPT T-1002 36/4 101-066NL 1-1/4” FNPT x FNPT T-1002NL 36/4 101-067 1-1/2” FNPT x FNPT T-1002 24/4 101-067NL 1-1/2” FNPT x FNPT T-1002NL 24/4

101-068 2” FNPT x FNPT T-1002 12/2 101-068NL 2” FNPT x FNPT T-1002NL 12/2 101-069 2-1/2” FNPT x FNPT T-1002 8/2 101-069NL 2-1/2” FNPT x FNPT T-1002NL 8/2 101-070 3” FNPT x FNPT T-1002 6/2 101-070NL 3” FNPT x FNPT T-1002NL 6/2

101-082 3/8” Sweat x Sweat S-1002 180/10 101-082NL 3/8” Sweat x Sweat S-1002NL 180/10 101-083 1/2” Sweat x Sweat S-1002 120/10 101-083NL 1/2” Sweat x Sweat S-1002NL 120/10 101-084 3/4” Sweat x Sweat S-1002 90/10 101-084NL 3/4” Sweat x Sweat S-1002NL 90/10 101-085 1” Sweat x Sweat S-1002 60/6 101-085NL 1” Sweat x Sweat S-1002NL 60/6 101-086 1-1/4” Sweat x Sweat S-1002 36/4 101-086NL 1-1/4” Sweat x Sweat S-1002NL 36/4 101-087 1-1/2” Sweat x Sweat S-1002 24/4 101-087NL 1-1/2” Sweat x Sweat S-1002NL 24/4 101-088 2” Sweat x Sweat S-1002 12/2

S-1002

101-088NL 2” Sweat x Sweat S-1002NL 12/2 101-089 2-1/2” Sweat x Sweat S-1002 8/2 101-089NL 2-1/2” Sweat x Sweat S-1002NL 8/2 101-090 3” Sweat x Sweat S-1002 6/2 101-090NL 3” Sweat x Sweat S-1002NL 6/2

FULL PORT BALL VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

VALVES & FITTINGS

Full Port Ball Valve

Traditional & no lead forged brass ISO-9002, 600 CWP (1/4" - 2"), 400 CWP (2-1/2” - 4”) 150 WSP

ANSI/NSF 61 (T/S-2000NL) UPC 250 psi max. CSA certied 1/2, 5, 125 psig

(1/4"- 4" T-2000) (1/4"- 2" T-2000NL) UL listed LP Gas (1/2”- 2” T-2000/T-2000NL) UPC/IAMPO

FM approved (1/2”- 2” T-2000/T-2000NL) Third party certied

T-2000NL

101-090NL 3” Sweat x Sweat S-1002NL 479.19 6/2

101-411 1/4” FNPT x FNPT T-2000 120/12 101-411NL 1/4” FNPT x FNPT T-2000NL 120/12 101-412 3/8” FNPT x FNPT T-2000 120/12 101-412NL 3/8” FNPT x FNPT T-2000NL 120/12 101-413 1/2” FNPT x FNPT T-2000 100/10 101-413NL 1/2” FNPT x FNPT T-2000NL 100/10 101-414 3/4” FNPT x FNPT T-2000 64/8 101-414NL 3/4” FNPT x FNPT T-2000NL 64/8 101-415 1” FNPT x FNPT T-2000 30/6 101-415NL 1” FNPT x FNPT T-2000NL 30/6 101-416 1-1/4” FNPT x FNPT T-2000 24/6 101-416NL 1-1/4” FNPT x FNPT T-2000NL 24/6 101-417 1-1/2” FNPT x FNPT T-2000 16/4 101-417NL 1-1/2” FNPT x FNPT T-2000NL 16/4 101-418 2” FNPT x FNPT T-2000 8/2 101-418NL 2” FNPT x FNPT T-2000NL 8/2 101-419 2-1/2” FNPT x FNPT T-2000 6/3 101-419NL 2-1/2” FNPT x FNPT T-2000NL 4/2 101-420 3” FNPT x FNPT T-2000 4/2 101-420NL 3” FNPT x FNPT T-2000NL 4/2 101-421 4” FNPT x FNPT T-2000 2/1 101-421NL 4” FNPT x FNPT T-2000NL 2/1

S-2000NL

101-423 1/2” Sweat x Sweat S-2000 100/10

101-423NL 1/2” Sweat x Sweat S-2000NL 100/10

101-424 3/4” Sweat x Sweat S-2000 64/8

101-424NL 3/4” Sweat x Sweat S-2000NL 64/8

101-425 1” Sweat x Sweat S-2000 30/6

101-425NL 1” Sweat x Sweat S-2000NL 30/6

101-426 1-1/4” Sweat x Sweat S-2000 24/6

101-426NL 1-1/4” Sweat x Sweat S-2000NL 24/6

101-427 1-1/2” Sweat x Sweat S-2000 16/4

101-427NL 1-1/2” Sweat x Sweat S-2000NL 16/4

101-428 2” Sweat x Sweat S-2000 8/2

101-428NL 2” Sweat x Sweat S-2000NL 8/2

101-429 2-1/2” Sweat x Sweat S-2000 4/2

101-429NL 2-1/2” Sweat x Sweat S-2000NL 4/2

101-430 3” Sweat x Sweat S-2000 4/2

101-430NL 3” Sweat x Sweat S-2000NL 4/2

101-431 4” Sweat x Sweat S-2000 2/1

101-431NL 4” Sweat x Sweat S-2000NL 2/1

FULL PORT BALL VALVES

No lead brass and bronze alloy items are highlighted in gray.

VALVES & FITTINGS

Full Port Ball Valve

No lead & DZR forged brass 600 CWP ANSI/NSF 61

Third party certied

BRONZE BALL VALVES

Bronze Full Port Ball Valve

ISO 9002, 600 CWP, 150 WSP ANSI/NSF 61 (T/S-901NL)

Third party certied

S-2001NL

T-2001NL

T-901

Part No. Size Conﬁguration Model No. Cs/Ct

101-323NL 1/2" FNPT x FNPT T-2001NL 100/10 101-324NL 3/4" FNPT x FNPT T-2001NL 64/8 101-325NL 1" FNPT x FNPT T-2001NL 30/6 101-326NL 1-1/4" FNPT x FNPT T-2001NL 24/6 101-327NL 1-1/2" FNPT x FNPT T-2001NL 16/4 101-328NL 2" FNPT x FNPT T-2001NL 8/2

101-333NL 1/2" Sweat x Sweat S-2001NL 100/10 101-334NL 3/4" Sweat x Sweat S-2001NL 64/8 101-335NL 1" Sweat x Sweat S-2001NL 30/6 101-336NL 1-1/4" Sweat x Sweat S-2001NL 24/6 101-337NL 1-1/2" Sweat x Sweat S-2001NL 16/4 101-338NL 2" Sweat x Sweat S-2001NL 8/2

101-221 1/4” FNPT x FNPT T-901 180/10 101-221NL 1/4” FNPT x FNPT T-901NL 180/10 101-222 3/8” FNPT x FNPT T-901 180/10 101-222NL 3/8” FNPT x FNPT T-901NL 180/10 101-223 1/2” FNPT x FNPT T-901 120/10 101-223NL 1/2” FNPT x FNPT T-901NL 120/10 101-224 3/4” FNPT x FNPT T-901 90/10 101-224NL 3/4” FNPT x FNPT T-901NL 90/10 101-225 1” FNPT x FNPT T-901 60/6 101-225NL 1” FNPT x FNPT T-901NL 60/10 101-226 1-1/4” FNPT x FNPT T-901 36/4 101-226NL 1-1/4” FNPT x FNPT T-901NL 144/4 101-227 1-1/2” FNPT x FNPT T-901 24/4 101-227NL 1-1/2” FNPT x FNPT T-901NL 96/4 101-228 2” FNPT x FNPT T-901 12/2 101-228NL 2” FNPT x FNPT T-901NL 24/2 101-229 2-1/2” FNPT x FNPT T-901 8/2 101-230 3” FNPT x FNPT T-901 6/2

101-233 1/2” Sweat x Sweat S-901 120/10 101-233NL 1/2” Sweat x Sweat S-901NL 120/10 101-234 3/4” Sweat x Sweat S-901 90/10 101-234NL 3/4” Sweat x Sweat S-901NL 90/10 101-235 1” Sweat x Sweat S-901 60/6 101-235NL 1” Sweat x Sweat S-901NL 60/10 101-236 1-1/4” Sweat x Sweat S-901 36/4 101-236NL 1-1/4” Sweat x Sweat S-901NL 144/4

S-901

101-237 1-1/2” Sweat x Sweat S-901 24/4 101-237NL 1-1/2” Sweat x Sweat S-901NL 96/4 101-238 2” Sweat x Sweat S-901 12/2 101-238NL 2” Sweat x Sweat S-901NL 24/2

SPECIALTY BALL VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

VALVES & FITTINGS

Full Port Ball Valve With Drain

Traditional & no lead forged brass ISO 9002, 500 CWP

ANSI/NSF 61 (NL only)

S-1100

T-1100

101-503 1/2” FNPT x FNPT T-1100 100/10

101-503NL 1/2” FNPT x FNPT T-1100NL 100/10

101-504 3/4” FNPT x FNPT T-1100 60/10

101-504NL 3/4” FNPT x FNPT T-1100NL 60/10

101-505 1” FNPT x FNPT T-1100 36/6

101-505NL 1” FNPT x FNPT T-1100NL 36/6

101-513 1/2” Sweat x Sweat S-1100 100/10

101-513NL 1/2” Sweat x Sweat S-1100NL 100/10

101-514 3/4” Sweat x Sweat S-1100 60/10

101-514NL 3/4” Sweat x Sweat S-1100NL 60/10

101-515 1” Sweat x Sweat S-1100 36/6

101-515NL 1” Sweat x Sweat S-1100NL 36/6

101-606NL 1/2” FNPT x FNPT T-1102NL 120/10

101-607NL 3/4” FNPT x FNPT T-1102NL 60/10

101-608NL 1” FNPT x FNPT T-1102NL 36/6

S-1102

No lead & DZR forged brass ISO 9002, 600 CWP ANSI/NSF 61

T-2102NL

S-2102NL

Full Port Ball Valve, SS Ball & Stem

Traditional forged brass ISO 9002, 600 CWP, 150 WSP

CSA certied, UL listed, FM approved

T-1002ST

T-1102

101-603NL 1/2” Sweat x Sweat S-1102NL 144/12

101-604NL 3/4” Sweat x Sweat S-1102NL 60/10

101-605NL 1” Sweat x Sweat S-1102NL 36/6

101-703NL 1/2" FNPT x FNPT T-2102NL 120/10

101-704NL 3/4" FNPT x FNPT T-2102NL 60/10

101-705NL 1" FNPT x FNPT T-2102NL 36/6

101-706NL 1/2" Sweat x Sweat S-2102NL 120/10

101-707NL 3/4" Sweat x Sweat S-2102NL 60/10

101-708NL 1" Sweat x Sweat S-2102NL 36/6

101-723 1/2” FNPT x FNPT T-1002ST 120/10

101-724 3/4” FNPT x FNPT T-1002ST 90/10

101-725 1” FNPT x FNPT T-1002ST 60/6

101-726 1-1/4” FNPT x FNPT T-1002ST 36/4

101-727 1-1/2” FNPT x FNPT T-1002ST 24/4

101-728 2” FNPT x FNPT T-1002ST 12/2

304 Stainless Steel Ball & Stem. Stainless steel handle sold separately.

SPECIALTY BALL VALVES

No lead brass and bronze alloy items are highlighted in gray.

VALVES & FITTINGS

Full Port Ball Valve, SS Ball & Stem w / LD

Traditional forged brass ISO 9002, 600 CWP, 150 WSP

CSA certied, UL listed FM approved

Full Port Ball Valve, Locking Device

Traditional forged brass ISO 9002, 600 CWP, 150 WSP

CSA certied, UL listed (1/2" - 2") FM approved (1/2" - 2")

T-1002LD

T-1002STLD

Part No. Size Conﬁguration Model No. Cs/Ct

101-733 1/2” FNPT x FNPT T-1002STLD 120/10

101-734 3/4” FNPT x FNPT T-1002STLD 90/10

101-735 1” FNPT x FNPT T-1002STLD 6/1

101-736 1-1/4” FNPT x FNPT T-1002STLD 4/1

101-737 1-1/2” FNPT x FNPT T-1002STLD 24/4

101-738 2” FNPT x FNPT T-1002STLD 12/2

304 Stainless Steel Ball & Stem with locking device.

101-611 1/4” FNPT x FNPT T-1002LD 180/10

101-612 3/8” FNPT x FNPT T-1002LD 180/10

101-613 1/2” FNPT x FNPT T-1002LD 120/10

101-614 3/4” FNPT x FNPT T-1002LD 90/10

101-615 1” FNPT x FNPT T-1002LD 60/6

101-616 1-1/4” FNPT x FNPT T-1002LD 36/4

101-617 1-1/2” FNPT x FNPT T-1002LD 24/4

101-618 2” FNPT x FNPT T-1002LD 12/2

FNPT x Sweat Full Port Ball Valve

Traditional forged brass ISO 9002, 600 CWP, 150 WSP

T-1007

Full Port Ball Valve, Locking Device

Traditional & no lead forged brass ISO 9002, 600 CWP (1/2”- 2"), 400 CWP (2-1/2” - 4”) 150 WSP ANSI/NSF 61 (T/S-1001NL) UL listed (1/4” - 2” T-1001/T-1001NL)

CSA certied 1/2, 5, 125 psig

(1/4" & 1/2"-2" T-1001/T-1001NL)

FM approved (1/2” - 2” T-1001/T-1001NL)

T-1001LD

For Connecting Boilers to Copper Tube

101-623 1/2” FNPT x Sweat T-1007 120/10

101-624 3/4” FNPT x Sweat T-1007 90/10

101-625 1” FNPT x Sweat T-1007 60/6

101-053 1/2” FNPT x FNPT T-1001LD 100/10

101-053NL 1/2” FNPT x FNPT T-1001LDNL 100/10

101-054 3/4” FNPT x FNPT T-1001LD 100/10

101-054NL 3/4” FNPT x FNPT T-1001LDNL 100/10

101-055 1” FNPT x FNPT T-1001LD 50/10

101-055NL 1” FNPT x FNPT T-1001LDNL 50/10

101-056 1-1/4” FNPT x FNPT T-1001LD 20/10

101-056NL 1-1/4” FNPT x FNPT T-1001LDNL 20/10

101-057 1-1/2” FNPT x FNPT T-1001LD 20/4

101-057NL 1-1/2” FNPT x FNPT T-1001LDNL 20/4

101-058 2” FNPT x FNPT T-1001LD 20/4

101-058NL 2” FNPT x FNPT T-1001LDNL 20/4

SPECIALTY BALL VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

VALVES & FITTINGS

Full Port Ball Valve with T-Handle

Traditional & no lead forged brass ISO 9002, 600 CWP, 150 WSP ANSI/NSF 61 (T/S-1001NL) UL listed (1/2”- 1” T-1001T/T-1001TNL)

CSA certied 1/2, 5, 125 psig

(1/4" & 1/2"-2" T-1001/T-1001NL)

FM approved

(1/2” - 2” T-1001/T-1001NL)

T-1001T

S-1001T

No Lead Full Port Ball Valve, Compression

No lead forged brass ISO 9002, 600 CWP ANSI/NSF 61

T-1009NL

101-653 1/2” FNPT x FNPT T-1001T 100/10

101-653NL 1/2” FNPT x FNPT T-1001TNL 100/10

101-654 3/4” FNPT x FNPT T-1001T 100/10

101-654NL 3/4” FNPT x FNPT T-1001TNL 100/10

101-655 1” FNPT x FNPT T-1001T 50/5

101-655NL 1” FNPT x FNPT T-1001TNL 50/5

101-633 1/2” Sweat x Sweat S-1001T 100/10

101-633NL 1/2” Sweat x Sweat S-1001TNL 100/10

101-634 3/4” Sweat x Sweat S-1001T 60/10

101-634NL 3/4” Sweat x Sweat S-1001TNL 60/10

101-635 1” Sweat x Sweat S-1001T 36/6

101-635NL 1” Sweat x Sweat S-1001TNL 36/6

101-643NL 1/2” Comp x Comp T-1009NL 100/10

101-644NL 3/4” Comp x Comp T-1009NL 60/10

101-645NL 1” Comp x Comp T-1009NL 36/6

No lead DZR forged brass ISO 9002, 600 CWP ANSI/NSF 61 UPC/IAPMO, 150 WSP

No lead DZR forged brass ISO 9002, 600 CWP ANSI/NSF 61 UPC/IAPMO

T-2009NL

Full Port Three-Way Ball Valve

Forged brass ISO 9002, 600 CWP, 150 WSP

L-port style

T-2100

T-2002NL

With Drain

101-453NL 1/2” Comp x Comp T-2009NL 96/12

101-454NL 3/4” Comp x Comp T-2009NL 64/8

101-455NL 1” Comp x Comp T-2009NL 36/6

With Drain

101-433NL 1/2” Comp x Comp T-2002NL 80/10

101-434NL 3/4” Comp x Comp T-2002NL 48/6

101-435NL 1” Comp x Comp T-2002NL 24/6

101-441 1/4” FNPT x FNPT T-2100

101-442 3/8” FNPT x FNPT T-2100

101-443 1/2” FNPT x FNPT T-2100

101-444 3/4” FNPT x FNPT T-2100

101-445 1” FNPT x FNPT T-2100

101-446 1-1/4” FNPT x FNPT T-2100

101-447 1-1/2” FNPT x FNPT T-2100

101-448 2” FNPT x FNPT T-2100

100/10

12/6

48/6

12/6

16/2

12/2

6/2

Full Port Ball Valve with Cap & Chain

Forged brass ISO 9002, 600 CWP

T-1002CC

101-570 3/4” FNPT x MGHT T-1002CC 50/10

SPECIALTY BALL VALVES

No lead brass and bronze alloy items are highlighted in gray.

VALVES & FITTINGS

T-2010NL FNPT x Insert Barb Full Port Ball Valve

No lead, DZR brass, 600 CWP ANSI/NSF 61

Part No. Size Conﬁguration Model No. Cs/Ct

101-314NL 3/4" FNPT x Insert T-2010NL 48/8

101-315NL 1" FNPT x Insert T-2010NL 36/6

101-316NL 1-1/4" FNPT x Insert T-2010NL 16/4

T-2000 MxSNL Full Port Ball Valve

No lead DZR forged brass 600 CWP, 150 WSP ANSI/NSF 61

Third party certied IAPMO

T-2000MxSNL

PUSH FIT BALL VALVES

Insta-Loc II™ Push Fit Ball Valve

No lead DZR forged brass

200 CWP, max. temp 250˚F, DZR brass ANSI/NSF 61, NSF 14, ASSE 1061

ISO 9002, UPC/IAPMO

P-2200NL

T-2010NL

For connecting polyethylene pipe (SIDR 7 & 11) on well systems.

101-684NL 3/4" MNPT x Sweat T-2000MxSNL

64/8

456-003NL 1/2” Push x Push P-2200NL 100/10

456-004NL 3/4” Push x Push P-2200NL 100/10

456-005NL 1” Push x Push P-2200NL 50/5

Insta-Loc II™ Push Fit Ball Valve

No lead DZR forged brass, ISO 9002

200 CWP, Max. temp. 250˚F ANSI/NSF 61, NSF 14, ASSE 1061

UPC/IAPMO

P-2200NL

Drop Ear

P-2200NL

Insta-Loc II™ No Lead Drop Ear For Push Fit Ball Valve

456-023NL 1/2” Push x Push

456-024NL 3/4” Push x Push

456-025NL 1” Push x Push

P-2200NL Drop Ear

100/10

50/5

456-013NL 1/2” Push x FNPT P-2200NL 100/10

456-014NL 3/4” Push x FNPT P-2200NL 100/10

456-015NL 1” Push x FNPT P-2200NL 50/5

PEX BALL VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

VALVES & FITTINGS

PEX End Ball Valve

No lead forged brass ANSI/NSF 61 ASTM F 1807, ISO 9002 400 CWP

101-582NL 3/8” PEX x PEX T-806NL 100/10

101-585NL 1/2” PEX x PEX T-806NL 100/10

101-586NL 3/4” PEX x PEX T-806NL 100/10

101-587NL 1” PEX x PEX T-806NL 50/5

T-806NL

101-583NL 1/2” Sweat x PEX T-805NL 100/50

101-584NL 3/4” Sweat x PEX T-805NL 100/50

T-805NL

Sweat x PEX

PEX End Ball Valve

No lead DZR forged brass 400 CWP, DZR, ANSI/NSF 61, NSF 14, ISO 9002, ASTM F 1807

T-2006NL

Tee handle

No lead DZR forged brass 400 CWP, ANSI/NSF 61, NSF 14, ASTM F 1807, ISO 9002

T-2007NL

PEX x PEX

T-805NL

MNPT x PEX

T-2006NL

PEX x PEX

101-580NL 1/2” MNPT x PEX T-805NL 100/1

101-581NL 3/4” MNPT x PEX T-805NL 100/50

101-593NL 1/2” PEX x PEX T-2006NL 100/10

101-594NL 3/4” PEX x PEX T-2006NL 100/10

101-595NL 1” PEX x PEX T-2006NL 60/12

101-588NL 1-1/4” PEX x PEX T-2006NL 40/10

101-573NL 1-1/2” PEX x PEX T-2006NL 16/4

101-574NL 2” PEX x PEX T-2006NL 8/2

Tee Handle

101-579NL 1/2” PEX x PEX T-2006NL 100/10

101-589NL 3/4” PEX x PEX T-2006NL 100/10

Tee Handle & Drainable

101-596NL 1/2” PEX x PEX T-2007NL 80/8

101-597NL 3/4” PEX x PEX T-2007NL 80/8

101-598NL 1" PEX x PEX T-2007NL 64/8

101-600NL 1/2” Sweat x PEX T-2007NL 100/10

101-601NL 3/4” Sweat x PEX T-2007NL 80/8

101-602NL 1” Sweat x PEX T-2007NL 48/6

T-2007NL

Sweat x PEX

101-590NL 1/2” MNPT x PEX T-2005NL 100/10

101-591NL 3/4” MNPT x PEX T-2005NL 80/8

T-2005NL

MNPT x PEX

101-592NL 1” MNPT x PEX T-2005NL 48/6

Drop Ear

101-576NL 1/2” PEX x PEX T-2008NL 80/8

T-2008NL

PEX x PEX

101-577NL 3/4” PEX x PEX T-2008NL 64/8

101-578NL 1” PEX x PEX T-2008NL 36/6

PEX BALL VALVES

No lead brass and bronze alloy items are highlighted in gray.

VALVES & FITTINGS

PEX End Ball Valve (Cold Expansion)

No lead DZR forged brass 400 CWP, ISO 9002, UPC/IAPMO ANSI/NSF 61, NSF 14

ASTM F 1960 cold expansion

Drop Ear & Drain

T-1960NL

Part No. Size Conﬁguration Model No. Cs/Ct

101-543NL 1/2” PEX x PEX T-1960NL 100/10

101-544NL 3/4” PEX x PEX T-1960NL 100/10

101-545NL 1” PEX x PEX T-1960NL 60/12

101-546NL 1-1/4” PEX x PEX T-1960NL 24/6

101-547NL 1-1/2” PEX x PEX T-1960NL 16/4

101-548NL 2” PEX x PEX T-1960NL 8/2

NEW

101-549NL 2-1/2" PEX x PEX T-1960NL 4/2

NEW

101-560NL 3" PEX x PEX T-1960NL 2/1

Drainable with Drop Ear

101-563NL 1/2” PEX x PEX T-1960NL 48/6

101-564NL 3/4” PEX x PEX T-1960NL 48/6

101-565NL 1” PEX x PEX T-1960NL 36/6

MNPT x PEX

T-1960SNL

T-1960DENL

MINI BALL VALVES

MNPT x FNPT Large Port Ball Valve

ISO 9002, 600 CWP (1/8"- 3/4"), 500 CWP (1” only)

150 WSP

CSA certied (1/2” - 1”) UL listed (1/2” - 1”) - T-900 only not NL

ANSI/NSF 61 (T-900NL)

T-900

MNPT x FNPT

101-463NL 1/2” MNPT x PEX T-1960NL 100/10

101-464NL 3/4” MNPT x PEX T-1960NL 80/8

101-465NL 1” MNPT x PEX T-1960NL 48/6

101-473NL 1/2" Sweat x CE PEX T-1960SNL 100/10

101-474NL 3/4" Sweat x CE PEX T-1960SNL 80/8

101-475NL 1" Sweat x CE PEX T-1960SNL 48/6

With Drop Ear

101-483NL 1/2" CE PEX x CE PEX T-1960DENL 48/6

101-484NL 3/4" CE PEX x CE PEX T-1960DENL 48/6

101-485NL 1" CE PEX x CE PEX T-1960DENL 36/6

101-520 1/8” MNPT x FNPT T-900MxF 200/20

101-520NL 1/8” MNPT x FNPT T-900MxFNL 200/20

101-521 1/4” MNPT x FNPT T-900MxF 200/20

101-521NL 1/4” MNPT x FNPT T-900MxFNL 200/20

101-522 3/8” MNPT x FNPT T-900MxF 100/10

101-522NL 3/8” MNPT x FNPT T-900MxFNL 100/10

101-523 1/2” MNPT x FNPT T-900MxF 100/10

101-523NL 1/2” MNPT x FNPT T-900MxFNL 100/10

101-524 3/4” MNPT x FNPT T-900MxF 60/10

101-524NL 3/4” MNPT x FNPT T-900MxFNL 60/10

101-525 1” MNPT x FNPT T-900MxF 36/6

101-525NL 1” MNPT x FNPT T-900MxFNL 36/6

MINI BALL VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

VALVES & FITTINGS

MNPT x FNPT Ball Valve with Tee Handle

ISO 9002, 400 CWP, 150 WSP ANSI/NSF 61, (T-900TNL)

T-900

MNPT x FNPT-TNL

MICRO BALL™ Lever Handle

ISO 9002, 400 CWP, 125 WSP

101-530 1/8” MNPT x FNPT T-900MxF-T 200/20

101-530NL 1/8” MNPT x FNPT T-900MxF-TNL 200/20

101-531 1/4” MNPT x FNPT T-900MxF-T 200/20

101-531NL 1/4” MNPT x FNPT T-900MxF-TNL 200/20

101-532 3/8” MNPT x FNPT T-900MxF-T 100/10

101-532NL 3/8” MNPT x FNPT T-900MxF-TNL 100/10

101-533 1/2” MNPT x FNPT T-900MxF-T 100/10

101-533NL 1/2” MNPT x FNPT T-900MxF-TNL 100/10

101-534 3/4” MNPT x FNPT T-900MxF-T 60/10

101-534NL 3/4” MNPT x FNPT T-900MxF-TNL 60/10

101-535 1” MNPT x FNPT T-900MxF-T 36/6

101-535NL 1” MNPT x FNPT T-900MxF-TNL 36/6

101-000 1/8” FNPT x FNPT T-810 200/20

101-001 1/4” FNPT x FNPT T-810 200/20

T-810

MICRO BALL™ Tee Handle

ISO 9002, 400 CWP, 125 WSP ANSI/NSF 61, (T-800TNL)

T-800T

Ball Valve Test Cock, Screwdriver Slot

ISO 9002, 600 CWP, 150 WSP ANSI/NSF 61

Third party certied

T-801NL

Chrome Plated Brass Mini Ball Valve

Traditional brass, 400 CWP

FNPT x FNPT

101-540 1/8” FNPT x FNPT T-800T 200/20 101-540NL 1/8” FNPT x FNPT T-800TNL 200/20 101-541 1/4” FNPT x FNPT T-800T 100/10 101-541NL 1/4” FNPT x FNPT T-800TNL 200/20

101-550NL 1/4” x 1/8” FNPT x MNPT T-801NL 200/20 101-551NL 1/4” FNPT x MNPT T-801NL 200/20

101-340 1/8" FNPT x FNPT Mini Ball Valve 120/30 101-341 1/4" FNPT x FNPT Mini Ball Valve 120/30 101-342 3/8" FNPT x FNPT Mini Ball Valve 80/20 101-343 1/2" FNPT x FNPT Mini Ball Valve 80/20

101-346 1/8" FNPT x MNPT Mini Ball Valve 120/30 101-347 1/4" FNPT x MNPT Mini Ball Valve 120/30 101-348 3/8" FNPT x MNPT Mini Ball Valve 80/20

FNPT x MNPT

101-349 1/2" FNPT x MNPT Mini Ball Valve 80/20

MINI BALL VALVES

No lead brass and bronze alloy items are highlighted in gray.

VALVES & FITTINGS

Stainless Steel Mini Ball Valve

ISO 9002, 800 CWP, 150 WSP with tee handle

Naturally lead free

T-710

MNPT x FNPT-T

BALL VALVE ACCESSORIES

Accessories

4" Locking device

T-710T

Locking device

Part No. Size Conﬁguration Model No. Cs/Ct

113-301 1/4” FNPT x FNPT T-710T 120/10

113-311 1/4” MNPT x FNPT T-710MxF-T 120/10

Fits Models 1001, 1004, 1100, 1009, 806, P-200. Does not t T-handle ball valves

101-954 1/4”- 1/2” Locking Device - / -

101-955 3/4”- 1-1/4” Locking Device - / -

101-956 1-1/2”- 2” Locking Device - / -

101-957 2-1/2" - 3" Locking Device - / -

101-950 4" Locking Device - / -

Memory stop

T/S-2000 Handle

Extension

Stem extension

T/S-2006NL

Handle Extension

Fits Models 1001, 1004, 1100, 1009, 806, P-200

101-951 1/4”- 1/2” Memory Stop - / -

101-952 3/4”- 1-1/4” Memory Stop - / -

101-953 1-1/2”- 2” Memory Stop - / -

Fits Models 1001, 1004, 1100, 1009, 806, 805, P-200

101-958* 3/8”- 1/2” Stem Extension - / -

101-959 3/4”- 1-1/4” Stem Extension - / -

101-960 1-1/2”- 2” Stem Extension - / -

101-964 2-1/2” - 3” Stem Extension - / -

101-965 4” Stem Extension - / -

*101-958 ts 1/2" & 3/4" T-806 PEX ball valves

Handle Extension Assembly for T/S-2000 Ball Valves

101-993 1/2" - 3/4" Brass Stem & Aluminum Extension 100/10

101-994 1" Brass Stem & Aluminum Extension 80/8

101-995 1-1/4" Brass Stem & Aluminum Extension 40/4

101-996 2" Brass Stem & Aluminum Extension 20/5

Handle Extension Assembly for T-2006NL PEX Ball Valves

101-903 1/2" - 3/4" Brass Stem & Aluminum Extension 100/10

101-904 1" Brass Stem & Aluminum Extension 80/8

101-905 1-1/4" Brass Stem & Aluminum Extension 40/4

101-906 2" Brass Stem & Aluminum Extension 20/5

BALL VALVE ACCESSORIES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

VALVES & FITTINGS

Accessories

Extension handle

T-Handle

T/S-2001NL SS

T-Handle

Fits Models 1001, 1004, 1100, 1009, 806, 805, P-200

101-931 3/8”- 1/2” Extension Handle - / -

101-932 3/4”- 1-1/4” Extension Handle - / -

101-933 1-1/2”- 2” Extension Handle - / -

Fits Models 1001, 1004, 1100, 1009, 806, 805, P-200

101-961 1/8”- 1/4” T-Handle - / -

101-962 3/8”- 1/2” T-Handle - / -

101-963 3/4”- 1-1/4” T-Handle - / -

.304 Stainless Steel T-Handle for T/S-2001NL Ball Valve

101-943 1/2" Stainless Steel T-Handle with Vinyl Ends 100/10

101-944 3/4" Stainless Steel T-Handle with Vinyl Ends 100/10

101-945 1" Stainless Steel T-Handle with Vinyl Ends 100/10

T/S-2000BVL

SS Lever-Handle

Level Handle & nut

Replacement PTFE Packing and Seats for T-717

T-717 Replacement PTFE Packing Seats

Fits Model 2000

101-922 1/2" - 3/4" Stainless Steel Handle & Nut 10

101-923 1" Stainless Steel Handle & Nut 100/10

101-924 1-1/4" - 1-1/2" Stainless Steel Handle & Nut 100/10

101-925 2" Stainless Steel Handle & Nut 100/10

Fits Model T/S-1002

101-982 1/4”- 1/2” Stainless Steel Handle & Nut - / -

101-983 3/4”- 1” Stainless Steel Handle & Nut - / -

101-984 1-1/4”- 1-1/2” Stainless Steel Handle & Nut - / -

101-985 2”- 3” Stainless Steel Handle & Nut - / -

113-991 1/4" PTFE Packing Gland & Seats, Bagged 25/1

113-992 3/8" PTFE Packing Gland & Seats, Bagged 25/1

113-993 1/2" PTFE Packing Gland & Seats, Bagged 25/1

113-994 3/4" PTFE Packing Gland & Seats, Bagged 25/1

113-995 1" PTFE Packing Gland & Seats, Bagged 25/1

113-996 1-1/4" PTFE Packing Gland & Seats, Bagged 25/1

113-997 1-1/2" PTFE Packing Gland & Seats, Bagged 25/1

113-998 2" PTFE Packing Gland & Seats, Bagged 25/1

STAINLESS STEEL BALL VALVES - INVESTMENT CAST

No lead brass and bronze alloy items are highlighted in gray.

VALVES & FITTINGS

3-Piece 316 Stainless Steel Full Port Ball Valve

113-161 1/4” FNPT x FNPT T-717 48/12

ISO 9002, 1000 CWP, 150 WSP

Naturally lead free

T-717

2-Piece 316 Stainless Steel Full Port Ball

ISO 9002, 1000 CWP, 150 WSP

Naturally lead free

T-712

Part No. Size Conﬁguration Model No. Cs/Ct

113-162 3/8” FNPT x FNPT T-717 48/12

113-163 1/2” FNPT x FNPT T-717 36/9

113-164 3/4” FNPT x FNPT T-717 32/8

113-165 1” FNPT x FNPT T-717 24/6

113-166 1-1/4” FNPT x FNPT T-717 16/4

113-167 1-1/2” FNPT x FNPT T-717 8/2

113-168 2” FNPT x FNPT T-717 8/2

113-141 1/4” FNPT x FNPT T-712 80/10

113-142 3/8” FNPT x FNPT T-712 80/10

113-143 1/2” FNPT x FNPT T-712 60/10

113-144 3/4” FNPT x FNPT T-712 60/10

113-145 1” FNPT x FNPT T-712 36/6

113-146 1-1/4” FNPT x FNPT T-712 24/6

113-147 1-1/2” FNPT x FNPT T-712 12/2

113-148 2” FNPT x FNPT T-712 8/2

113-109 2-1/2” FNPT x FNPT T-712 2/1

113-110 3” FNPT x FNPT T-712 2/1

113-111 4” FNPT x FNPT T-712 1/1

2-P

iece

316 Stainless Steel Large Port Ball Valve

ISO 9002, 150 WSP 2000 CWP (1/4” - 1”) 1500 CWP (1-1/4” - 2”)

Naturally lead free

1-P

iece

316 Stainless Steel Conv. Port Ball Valve

ISO 9002, 800 CWP, 150 WSP

Naturally lead free

T-715

T-710

113-101 1/4” FNPT x FNPT T-715 80/10

113-102 3/8” FNPT x FNPT T-715 80/10

113-103 1/2” FNPT x FNPT T-715 60/10

113-104 3/4” FNPT x FNPT T-715 60/10

113-105 1” FNPT x FNPT T-715 36/6

113-106 1-1/4” FNPT x FNPT T-715 24/4

113-107 1-1/2” FNPT x FNPT T-715 16/4

113-108 2” FNPT x FNPT T-715 8/2

113-120* 1/8” FNPT x FNPT T-710 160/10

113-121 1/4” FNPT x FNPT T-710 160/10

113-122 3/8” FNPT x FNPT T-710 160/10

113-123 1/2” FNPT x FNPT T-710 100/10

113-124 3/4” FNPT x FNPT T-710 80/10

113-125 1” FNPT x FNPT T-710 48/6

113-126 1-1/4” FNPT x FNPT T-710 24/6

113-127 1-1/2” FNPT x FNPT T-710 16/4

113-128 2” FNPT x FNPT T-710 8/2

* Note: 1/8" not locking

CARBON STEEL BALL VALVES - INVESTMENT CAST

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

VALVES & FITTINGS

2-Piece Carbon Steel Full Port Ball Valve

ISO 9002, 150 WSP 2000 CWP (1/4” - 1”) 1500 CWP (1-1/4” - 2”) MSS-SP110

Naturally Lead Free

T-730

2-Piece Carbon Steel Large Port Ball Valve

ISO 9002, 150 WSP 2000 CWP (1/4” - 1”) 1500 CWP (1-1/4” - 2”)

Naturally Lead Free

T-725

113-221 1/4” FNPT x FNPT T-730 80/10

113-222 3/8” FNPT x FNPT T-730 80/10

113-223 1/2” FNPT x FNPT T-730 60/10

113-224 3/4” FNPT x FNPT T-730 60/10

113-225 1” FNPT x FNPT T-730 36/6

113-226 1-1/4” FNPT x FNPT T-730 24/6

113-227 1-1/2” FNPT x FNPT T-730 12/2

113-228 2” FNPT x FNPT T-730 8/2

113-211 1/4” FNPT x FNPT T-725 80/10

113-212 3/8” FNPT x FNPT T-725 80/10

113-213 1/2” FNPT x FNPT T-725 60/10

113-214 3/4” FNPT x FNPT T-725 60/10

113-215 1” FNPT x FNPT T-725 36/6

113-216 1-1/4” FNPT x FNPT T-725 24/4

113-217 1-1/2” FNPT x FNPT T-725 16/4

113-218 2” FNPT x FNPT T-725 8/2

1-Piece Carbon Steel Conv. Port Ball Valve

ISO 9002, 2000 CWP 150 WSP

Naturally Lead Free

T-720

Did you know? Legend’s corporate mission is to create customer astonishment.

113-201 1/4” FNPT x FNPT T-720 160/10

113-202 3/8” FNPT x FNPT T-720 160/10

113-203 1/2” FNPT x FNPT T-720 60/10

113-204 3/4” FNPT x FNPT T-720 40/10

113-205 1” FNPT x FNPT T-720 36/6

113-206 1-1/4” FNPT x FNPT T-720 24/6

113-207 1-1/2” FNPT x FNPT T-720 16/4

113-208 2” FNPT x FNPT T-720 8/2

GAS BALL VALVES

No lead brass and bronze alloy items are highlighted in gray.

VALVES & FITTINGS

Drip Leg Kits

Blue Top™ Patented One-Piece Design

Forged brass, 175 psi CSA Certied, UL listed (1/2" & 3/4" only)

ISO 9002

Flare x FNPT

T-3000

Part No. Size Conﬁguration Model No. Cs/Ct

Includes 1/2" x 3" & 1/2" X 6" Black Nipples, 1/2" Union, Tee, Cap & Valve

102-836 1/2" Kit with T-3000 1/1

102-837 1/2" Kit with T-3005 1/1

102-102 3/8” FNPT x FNPT T-3000 100/10

102-103 1/2” FNPT x FNPT T-3000 100/10

102-104 3/4" FNPT x FNPT T-3000 100/10

See T-1001 on page 10 for 1-1/4" to 3" CSA gas ball valves

102-112 3/8” x 1/2” Flare x FNPT T-3000 100/10

102-113 1/2” x 1/2” Flare x FNPT T-3000 100/10

102-118 1/2” x 3/4” Flare x FNPT T-3000 100/10

102-121

5/8” (15/16-16) x 1/2”

Flare x FNPT T-3000 100/10

102-114 5/8” (7/8-14) x 3/4” Flare x FNPT T-3000 100/10

102-115

5/8” (15/16-16) x 3/4”

Flare x FNPT T-3000 100/10

Flare x Flare

T-3000

Flare x FNPT T-3000

Flare x MNPT

T-3000

FNPT x Texas

attern T

-3000

T-3000A Angle

102-212 3/8” x 1/2” Flare x MNPT T-3000 100/10

102-213 1/2” x 1/2” Flare x MNPT T-3000 100/10

102-312 3/8” x 3/8” Flare x Flare T-3000 100/10

102-313 1/2” x 1/2” Flare x Flare T-3000 100/10

102-314 5/8” x 5/8” Flare x Flare T-3000 100/10

102-413 1/2” x 1/8” FNPT x Texas T-3000 100/10

102-414 3/4” x 1/8” FNPT x Texas T-3000 100/10

102-119

3/8” (9/16-24) x 1/2”

Flare x FNPT

T-3000 Heater Valve

100/10

Angle Valve

102-122 3/8” x 1/2” Flare x FNPT T-3000A 100/10

102-120

5/8” (15/16-16) x 3/4”

Flare x FNPT T-3000A 100/10

GAS BALL VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

VALVES & FITTINGS

Blue Top™ Patented One-Piece Design

Forged brass

175 psi, CSA Certied

UL Listed (1/2" & 3/4")

Massachusetts code compliant

ISO 9002

T-3001

102-612 3/8” FNPT x FNPT T-3001 T-handle 100/10

102-613 1/2” FNPT x FNPT T-3001 T-handle 100/10

102-614 3/4” FNPT x FNPT T-3001 T-handle 100/10

102-615 1” FNPT x FNPT T-3001 T-handle 36/6

102-616 1-1/4” FNPT x FNPT T-3001 T-handle 24/4

102-617 1-1/2” FNPT x FNPT T-3001 T-handle 24/4

102-618 2” FNPT x FNPT T-3001 T-handle 12/2

T-3002

Flare x Flare

T-3100

Red Top™ Economy Gas Ball Valve

Forged brass

175 psi, CSA Certied

UL Listed (1/2" & 3/4") Massachusetts code compliant ISO 9002

T-3005

FNPT x FNPT

T-3100

102-713 1/2” FNPT x FNPT T-3002 Flathead 100/10

102-714 3/4” FNPT x FNPT T-3002 Flathead 100/10

102-513 1/2” FNPT x FNPT T-3100 Sidetap 100/10

102-514 3/4” FNPT x FNPT T-3100 Sidetap 100/10

102-515 1” FNPT x FNPT T-3100 Sidetap 36/6

102-522 3/8” Flare x Flare T-3100 Sidetap 100/10

102-523 1/2” Flare x Flare T-3100 Sidetap 100/10

102-903 1/2” FNPT x FNPT T-3005 144/12

102-904 3/4” FNPT x FNPT T-3005 144/12

102-905 1” FNPT x FNPT T-3005 60/6

Did you know? Legend does not have a minimum order.

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

STAINLESS STEEL GATE VALVES

316 Stainless Steel Gate Valve

600 CWP, 125 WSP Naturally lead free

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

BRONZE GATE VALVES

Rising Stem

300 CWP, 150 WSP, conforms to MSS SP-80

Screw-Over Bonnet

ISO 9002, 200 CWP, 125 WSP, conforms to MSS SP-80

113-403 1/2” FNPT x FNPT T-751 48/12

113-404 3/4” FNPT x FNPT T-751 48/12

113-405 1” FNPT x FNPT T-751 40/10

113-406 1-1/4” FNPT x FNPT T-751 20/5

113-407 1-1/2” FNPT x FNPT T-751 8/2

T-751

113-408 2” FNPT x FNPT T-751 8/2

104-613 1/2” FNPT x FNPT T-416 84/6

104-614 3/4” FNPT x FNPT T-416 50/5

104-615 1” FNPT x FNPT T-416 35/5

104-616 1-1/4” FNPT x FNPT T-416 28/4

104-617 1-1/2” FNPT x FNPT T-416 16/4

T-416

104-618 2” FNPT x FNPT T-416 12/3

104-653 1/2” FNPT x FNPT T-414 120/6

104-654 3/4” FNPT x FNPT T-414 84/6

104-655 1” FNPT x FNPT T-414 60/5

104-656 1-1/4” FNPT x FNPT T-414 40/4

104-657 1-1/2” FNPT x FNPT T-414 28/4

104-658 2” FNPT x FNPT T-414 18/3

S-414

Inserted Bonnet

ISO 9002, 200 CWP, 125 WSP

T-415

T-414

104-663 1/2” Sweat x Sweat S-414 120/6

104-664 3/4” Sweat x Sweat S-414 84/6

104-665 1” Sweat x Sweat S-414 60/5

104-666 1-1/4” Sweat x Sweat S-414 40/4

104-667 1-1/2” Sweat x Sweat S-414 28/4

104-668 2” Sweat x Sweat S-414 18/3

104-501 1/4” FNPT x FNPT T-415 120/10

104-502 3/8” FNPT x FNPT T-415 120/10

104-503 1/2” FNPT x FNPT T-415 120/10

104-504 3/4” FNPT x FNPT T-415 90/10

104-505 1” FNPT x FNPT T-415 60/5

104-506 1-1/4” FNPT x FNPT T-415 40/5

104-507 1-1/2” FNPT x FNPT T-415 32/4

104-508 2” FNPT x FNPT T-415 20/2

104-509 2-1/2” FNPT x FNPT T-415 12/2

104-510 3” FNPT x FNPT T-415 8/1

104-511 4” FNPT x FNPT T-415 4/1

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

BRONZE GATE VALVES

Inserted Bonnet

ISO 9002, 200 CWP, 125 WSP

S-415

T-420 Quick Opening Gate Valve

TPR coated handle 200 CWP

T-420

104-603 1/2” Sweat x Sweat S-415 120/10

104-604 3/4” Sweat x Sweat S-415 90/10

104-605 1” Sweat x Sweat S-415 60/5

104-606 1-1/4” Sweat x Sweat S-415 40/5

104-607 1-1/2” Sweat x Sweat S-415 32/4

104-608 2” Sweat x Sweat S-415 20/2

104-609 2-1/2” Sweat x Sweat S-415 10/2

104-610 3” Sweat x Sweat S-415 6/2

104-611 4” Sweat x Sweat S-415 4/1

104-416 3” FNPT x FNPT T-420 4/1

104-417 4” FNPT x FNPT T-420 4/1

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

T-420 Brass Handle

Replacement handle for T-420 quick opening gate valve.

T-420

BRASS GATE VALVES

Brass Gate Valve

Traditional & no lead brass ISO 9002, 200 CWP ANSI/NSF 61-G (T/S-401NL)

T-401

104-414 3" Handle T-420 50/10

104-415 4" Handle T-420 50/10

104-301 1/4” FNPT x FNPT T-401 120/10

104-302 3/8” FNPT x FNPT T-401 120/10

104-303 1/2” FNPT x FNPT T-401 120/10

104-303NL 1/2” FNPT x FNPT T-401NL 120/10

104-304 3/4” FNPT x FNPT T-401 90/10

104-304NL 3/4” FNPT x FNPT T-401NL 90/10

104-305 1” FNPT x FNPT T-401 60/5

104-305NL 1” FNPT x FNPT T-401NL 60/5

104-306 1-1/4” FNPT x FNPT T-401 40/5

104-306NL 1-1/4” FNPT x FNPT T-401NL 40/5

104-307 1-1/2” FNPT x FNPT T-401 32/4

104-307NL 1-1/2” FNPT x FNPT T-401NL 32/4

104-308 2” FNPT x FNPT T-401 20/2

104-308NL 2” FNPT x FNPT T-401NL 20/2

104-309 2-1/2” FNPT x FNPT T-401 12/2

104-310 3” FNPT x FNPT T-401 8/1

104-311 4” FNPT x FNPT T-401 4/1

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

BRASS GATE VALVES

Brass Gate Valve

Traditional & no lead brass ISO 9002, 200 CWP ANSI/NSF 61-G (T/S-401NL)

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

Economy Brass Gate Valve

Traditional & no lead brass ISO 9002, 200 CWP NSF 61-G (T/S-408NL)

S-401

T-408

104-403 1/2” Sweat x Sweat S-401 120/10 104-403NL 1/2" Sweat x Sweat S-401NL 120/10 104-404 3/4” Sweat x Sweat S-401 90/10 104-404NL 3/4" Sweat x Sweat S-401NL 90/10 104-405 1” Sweat x Sweat S-401 60/5 104-405NL 1" Sweat x Sweat S-401NL 60/5 104-406 1-1/4” Sweat x Sweat S-401 40/5 104-406NL 1-1/4" Sweat x Sweat S-401NL 40/5 104-407 1-1/2” Sweat x Sweat S-401 32/4 104-407NL 1-1/2" Sweat x Sweat S-401NL 32/4 104-408 2” Sweat x Sweat S-401 20/2 104-408NL 2" Sweat x Sweat S-401NL 20/2 104-409 2-1/2” Sweat x Sweat S-401 12/2 104-410 3” Sweat x Sweat S-401 8/1

104-703 1/2” FNPT x FNPT T-408 144/12 104-703NL 1/2” FNPT x FNPT T-408NL 120/10 104-704 3/4” FNPT x FNPT T-408 80/10 104-704NL 3/4” FNPT x FNPT T-408NL 80/10 104-705 1” FNPT x FNPT T-408 60/5 104-705NL 1” FNPT x FNPT T-408NL 60/5 104-706 1-1/4” FNPT x FNPT T-408 40/5 104-706NL 1-1/4” FNPT x FNPT T-408NL 40/5 104-707 1-1/2” FNPT x FNPT T-408 30/5 104-707NL 1-1/2” FNPT x FNPT T-408NL 30/5 104-708 2” FNPT x FNPT T-408 24/2 104-708NL 2” FNPT x FNPT T-408NL 24/2 104-709 2-1/2” FNPT x FNPT T-408 10/1 104-709NL 2-1/2” FNPT x FNPT T-408NL 10/1 104-710 3” FNPT x FNPT T-408 6/1 104-710NL 3” FNPT x FNPT T-408NL 6/1 104-711 4” FNPT x FNPT T-408 4/1 104-711NL 4” FNPT x FNPT T-408NL 4/1

S-408

104-723 1/2” Sweat x Sweat S-408 120/10 104-723NL 1/2” Sweat x Sweat S-408NL 120/10 104-724 3/4” Sweat x Sweat S-408 80/10 104-724NL 3/4” Sweat x Sweat S-408NL 80/10 104-725 1” Sweat x Sweat S-408 60/5 104-725NL 1” Sweat x Sweat S-408NL 60/5 104-726 1-1/4” Sweat x Sweat S-408 40/5 104-726NL 1-1/4” Sweat x Sweat S-408NL 40/5

104-727 1-1/2” Sweat x Sweat S-408 30/5 104-727NL 1-1/2” Sweat x Sweat S-408NL 30/5 104-728 2” Sweat x Sweat S-408 24/2 104-728NL 2” Sweat x Sweat S-408NL 24/2

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

BRASS GATE VALVES

Cross Handle Gate Valve

200 CWP ISO 9002

T-408X

Compact Pattern Conventional Port

Traditional & no lead brass ISO 9002, 200 CWP ANSI/NSF 61-G (T/S-400NL)

Third party certied Truesdail

T-400

104-733 1/2" FNPT x FNPT T-408X 120/10

104-734 3/4" FNPT x FNPT T-408X 80/10

104-735 1" FNPT x FNPT T-408X 40/5

104-736 1-1/4" FNPT x FNPT T-408X 20/5

104-737 1-1/2" FNPT x FNPT T-408X 30/5

104-738 2" FNPT x FNPT T-408X 16/2

104-463 1/2” FNPT x FNPT T-400 160/10

104-463NL 1/2” FNPT x FNPT T-400NL 160/10

104-464 3/4” FNPT x FNPT T-400 100/10

104-464NL 3/4” FNPT x FNPT T-400NL 100/10

104-465 1” FNPT x FNPT T-400 80/8

104-465NL 1” FNPT x FNPT T-400NL 80/8

104-466 1-1/4” FNPT x FNPT T-400 50/5

104-466NL 1-1/4” FNPT x FNPT T-400NL 50/5

104-467 1-1/2” FNPT x FNPT T-400 40/4

104-467NL 1-1/2” FNPT x FNPT T-400NL 40/4

104-468 2” FNPT x FNPT T-400 30/3

104-468NL 2” FNPT x FNPT T-400NL 30/3

104-469 2-1/2” FNPT x FNPT T-400 20/2

104-470 3” FNPT x FNPT T-400 12/2

104-471 4” FNPT x FNPT T-400 8/1

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

104-473 1/2” Sweat x Sweat S-400 160/10

104-473NL 1/2” Sweat x Sweat S-400NL 160/10

104-474 3/4” Sweat x Sweat S-400 100/10

104-474NL 3/4” Sweat x Sweat S-400NL 100/10

104-475 1” Sweat x Sweat S-400 80/8

104-475NL 1” Sweat x Sweat S-400NL 80/8

104-476 1-1/4” Sweat x Sweat S-400 50/5

S-400

104-476NL 1-1/4” Sweat x Sweat S-400NL 10/1

104-477 1-1/2” Sweat x Sweat S-400 40/4

104-477NL 1-1/2” Sweat x Sweat S-400NL 40/4

104-478 2” Sweat x Sweat S-400 30/3

104-478NL 2” Sweat x Sweat S-400NL 30/3

Brass Cross Handle

Fits 414, 415, 401, 400, & 408 series gate valves

Fits Valve sizes:

104-451 1/4”- 3/4”* Cross Handle 1/1

104-452 1” Cross Handle 1/1

104-453 1-1/4" - 1-1/2" Cross Handle 1/1

104-454 2” Cross Handle 1/1

Cross Handle

104-457 2-1/2" Cross Handle 1/1

104-455 3” Cross Handle 1/1

104-456 4” Cross Handle 1/1 *Fits T-501 stop valve

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

GLOBE VALVES

Bronze Globe Valve

Traditional & no lead bronze 200 CWP, 125 WSP to 350° F max temp ANSI/NSF 372 (T-421NL)

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

Union Bonnet Bronze Globe Valve

300 CWP, 150 WSP, MSS SP-80 Rising stem

T-421

103-103 1/2” FNPT x FNPT T-421 72/12

103-103NL 1/2” FNPT x FNPT T-421NL 72/12

103-104 3/4” FNPT x FNPT T-421 72/12

103-104NL 3/4” FNPT x FNPT T-421NL 72/12

103-105 1” FNPT x FNPT T-421 48/8

103-105NL 1” FNPT x FNPT T-421NL 48/8

103-106 1-1/4” FNPT x FNPT T-421 5/1

103-106NL 1-1/4” FNPT x FNPT T-421NL 5/1

103-107 1-1/2” FNPT x FNPT T-421 24/4

103-107NL 1-1/2” FNPT x FNPT T-421NL 24/4

103-108 2” FNPT x FNPT T-421 12/2

103-108NL 2” FNPT x FNPT T-421NL 12/2

103-113 1/2” FNPT x FNPT T-422 80/8

103-114 3/4” FNPT x FNPT T-422 60/6

103-115 1” FNPT x FNPT T-422 36/6

103-116 1-1/4” FNPT x FNPT T-422 24/4

103-117 1-1/2” FNPT x FNPT T-422 16/4

103-118 2” FNPT x FNPT T-422 9/3

T-422

316 Stainless Steel Globe Valve

Naturally lead free 200 CWP, 125 WSP

T-752

CHECK VALVES

Brass Swing Check Valve

Traditional & no lead brass ISO 9002, 200 CWP ANSI/NSF 372 (T/S-451NL)

T-451

113-473 1/2” FNPT x FNPT T-752 48/12

113-474 3/4” FNPT x FNPT T-752 48/12

113-475 1” FNPT x FNPT T-752 20/5

113-476 1-1/4” FNPT x FNPT T-752 24/6

113-477 1-1/2” FNPT x FNPT T-752 16/4

113-478 2” FNPT x FNPT T-752 8/2

105-101 1/4” FNPT x FNPT T-451 150/25

105-101NL 1/4” FNPT x FNPT T-451NL 150/25 105-102 3/8” FNPT x FNPT T-451 150/25

105-102NL 3/8” FNPT x FNPT T-451NL 150/25 105-103 1/2” FNPT x FNPT T-451 150/25

105-103NL 1/2” FNPT x FNPT T-451NL 150/25 105-104 3/4” FNPT x FNPT T-451 120/20

105-104NL 3/4” FNPT x FNPT T-451NL 120/20 105-105 1” FNPT x FNPT T-451 90/15

105-105NL 1” FNPT x FNPT T-451NL 90/15

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

CHECK VALVES

Brass Swing Check Valve

Traditional & no lead brass ISO 9002, 200 CWP ANSI/NSF 372 (T/S-451NL)

T-451

S-451

105-106 1-1/4” FNPT x FNPT T-451 48/8

105-106NL 1-1/4” FNPT x FNPT T-451NL 48/8

105-107 1-1/2” FNPT x FNPT T-451 36/6

105-107NL 1-1/2” FNPT x FNPT T-451NL 36/6

105-108 2” FNPT x FNPT T-451 18/3

105-108NL 2” FNPT x FNPT T-451NL 18/3

105-109 2-1/2” FNPT x FNPT T-451 12/2

105-109NL 2-1/2” FNPT x FNPT T-451NL 12/2

105-110 3” FNPT x FNPT T-451 6/1

105-110NL 3” FNPT x FNPT T-451NL 6/1 105-111 4” FNPT x FNPT T-451 6/1

105-111NL 4” FNPT x FNPT T-451NL 6/1

105-203 1/2” Sweat x Sweat S-451 150/25

105-203NL 1/2” Sweat x Sweat S-451NL 150/25

105-204 3/4” Sweat x Sweat S-451 120/20

105-204NL 3/4” Sweat x Sweat S-451NL 120/20

105-205 1” Sweat x Sweat S-451 72/12

105-205NL 1” Sweat x Sweat S-451NL 72/12

105-206 1-1/4” Sweat x Sweat S-451 48/8

105-206NL 1-1/4” Sweat x Sweat S-451NL 48/8

105-207 1-1/2” Sweat x Sweat S-451 36/6

105-207NL 1-1/2” Sweat x Sweat S-451NL 36/6

105-208 2” Sweat x Sweat S-451 18/3

105-208NL 2” Sweat x Sweat S-451NL 18/3

105-209 2-1/2” Sweat x Sweat S-451 6/1

105-209NL 2-1/2” Sweat x Sweat S-451NL 6/1

105-210 3” Sweat x Sweat S-451 6/1

105-210NL 3” Sweat x Sweat S-451NL 6/1

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

LegendPress™ Swing Check Valve

No lead DZR & forged brass 200 CWP ANSI/NSF 61-G ISO 9002

105-003NL 1/2” Press x Press P-451NL 150/25

105-004NL 3/4” Press x Press P-451NL 108/18

105-005NL 1” Press x Press P-451NL 72/12

105-006NL 1-1/4” Press x Press P-451NL 48/8

105-007NL 1-1/2” Press x Press P-451NL 36/6

105-008NL 2” Press x Press P-451NL 18/3

P-451NL

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

CHECK VALVES

Y-Pattern Bronze Check Valve

Traditional & no lead bronze 300 CWP, 150 WSP, MSS SP-80 ANSI/NSF 372 (T/S-453NL) Conforms to MSS SP-80 ISO 9002 Max temp 365°F

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

T-453

S-453

105-303 1/2” FNPT x FNPT T-453 150/15

105-303NL 1/2” FNPT x FNPT T-453NL 150/15

105-304 3/4” FNPT x FNPT T-453 100/10

105-304NL 3/4” FNPT x FNPT T-453NL 100/10

105-305 1” FNPT x FNPT T-453 70/7

105-305NL 1” FNPT x FNPT T-453NL 70/7

105-306 1-1/4” FNPT x FNPT T-453 42/7

105-306NL 1-1/4” FNPT x FNPT T-453NL 42/7

105-307 1-1/2” FNPT x FNPT T-453 30/3

105-307NL 1-1/2” FNPT x FNPT T-453NL 30/3

105-308 2” FNPT x FNPT T-453 20/2

105-308NL 2” FNPT x FNPT T-453NL 20/2

105-403 1/2” Sweat x Sweat S-453 150/15

105-403NL 1/2” Sweat x Sweat S-453NL 150/15

105-404 3/4” Sweat x Sweat S-453 100/10

105-404NL 3/4” Sweat x Sweat S-453NL 100/10

105-405 1” Sweat x Sweat S-453 70/7

105-405NL 1” Sweat x Sweat S-453NL 70/7

105-406 1-1/4” Sweat x Sweat S-453 42/7

105-406NL 1-1/4” Sweat x Sweat S-453NL 42/7

105-407 1-1/2” Sweat x Sweat S-453 30/3

105-407NL 1-1/2” Sweat x Sweat S-453NL 30/3

105-408 2” Sweat x Sweat S-453 20/2

105-408NL 2” Sweat x Sweat S-453NL 20/2

In-line Bronze Check Valve

Traditional & no lead bronze 250 CWP, ISO 9002 Max temp 200°F @ 25 psi ANSI/NSF 372 (T/S-455NL)

T-455

105-443 1/2” FNPT x FNPT T-455 224/28

105-443NL 1/2” FNPT x FNPT T-455NL 224/28

105-444 3/4” FNPT x FNPT T-455 144/18

105-444NL 3/4” FNPT x FNPT T-455NL 144/18

105-445 1” FNPT x FNPT T-455 72/18

105-445NL 1” FNPT x FNPT T-455NL 72/18

105-446 1-1/4” FNPT x FNPT T-455 48/12

105-446NL 1-1/4” FNPT x FNPT T-455NL 48/12

105-447 1-1/2” FNPT x FNPT T-455 32/8

105-447NL 1-1/2” FNPT x FNPT T-455NL 32/8

105-448 2” FNPT x FNPT T-455 24/6

105-448NL 2” FNPT x FNPT T-455NL 24/6

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

CHECK VALVES

In-line Bronze Check Valve

Traditional & no lead bronze 250 CWP Max temp 200°F @ 25 psi ANSI/NSF 372 (T/S-455 NL) ISO 9002

S-455

105-463 1/2” Sweat x Sweat S-455 204/34

105-463NL 1/2” Sweat x Sweat S-455NL 204/34

105-464 3/4” Sweat x Sweat S-455 120/40

105-464NL 3/4” Sweat x Sweat S-455NL 120/40 105-465 1” Sweat x Sweat S-455 72/18 105-465NL 1” Sweat x Sweat S-455NL 72/18 105-466 1-1/4” Sweat x Sweat S-455 48/12 105-466NL 1-1/4” Sweat x Sweat S-455NL 48/12 105-467 1-1/2” Sweat x Sweat S-455 36/12 105-467NL 1-1/2” Sweat x Sweat S-455NL 36/12 105-468 2” Sweat x Sweat S-455 48/12 105-468NL 2” Sweat x Sweat S-455NL 48/12

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

No lead bronze 200 CWP ANSI/NSF 372 Max temp 200°F ISO 9002

105-423NL 1/2” FNPT x FNPT T-450NL 80/1

105-424NL 3/4” FNPT x FNPT T-450NL 60/1

105-425NL 1” FNPT x FNPT T-450NL 48/1

105-426NL 1-1/4” FNPT x FNPT T-450NL 36/1

105-427NL 1-1/2” FNPT x FNPT T-450NL 24/1

105-428NL 2” FNPT x FNPT T-450NL 12/1

T-450NL

105-430NL 3” FNPT x FNPT T-450NL 4/1

105-431NL 4” FNPT x FNPT T-450NL 2/1

Did you know? Legend ships every order in 24 hours, guaranteed or you get 5% off the order.

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

STAINLESS STEEL CHECK VALVES

316 Stainless Steel Check Valve

600 CWP, 125 WSP Naturally lead free

T-750

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

FOOT VALVES

Bronze Foot Valve

No lead bronze ISO 9002, 250 CWP ANSI/NSF 372

T-448NL

113-433 1/2” FNPT x FNPT T-750 100/25

113-434 3/4” FNPT x FNPT T-750 80/20

113-435 1” FNPT x FNPT T-750 60/15

113-436 1-1/4” FNPT x FNPT T-750 40/10

113-437 1-1/2” FNPT x FNPT T-750 24/6

113-438 2” FNPT x FNPT T-750 16/4

105-474NL 3/4” FNPT T-448NL 100/10

105-475NL 1” FNPT T-448NL 100/10

105-476NL 1-1/4” FNPT T-448NL 50/5

105-477NL 1-1/2” FNPT T-448NL 40/5

105-478NL 2” FNPT T-448NL 20/1

304 Stainless Steel Foot Valve

250 CWP Naturally lead free

Y-STRAINERS

Bronze Y-Strainer

Traditional & no lead bronze 300 CWP, 150 WSP ANSI/NSF 372 (T/S-15NL) 20 mesh 304 stainless steel screen Square head closure plug included

T-15

113-465 1” FNPT T-756 60/10

113-466 1-1/4” FNPT T-756 40/5

T-756

105-501 1/4” FNPT x FNPT T-15 48/12

105-501NL 1/4” FNPT x FNPT T-15NL 48/12

105-502 3/8” FNPT x FNPT T-15 48/12

105-502NL 3/8” FNPT x FNPT T-15NL 48/12

105-503 1/2” FNPT x FNPT T-15 48/12

105-503NL 1/2” FNPT x FNPT T-15NL 48/12

105-504 3/4” FNPT x FNPT T-15 48/8

105-504NL 3/4” FNPT x FNPT T-15NL 48/8

105-505 1” FNPT x FNPT T-15 32/8

105-505NL 1” FNPT x FNPT T-15NL 32/8

105-506 1-1/4” FNPT x FNPT T-15 24/6

105-506NL 1-1/4” FNPT x FNPT T-15NL 24/6 105-507 1-1/2” FNPT x FNPT T-15 16/2 105-507NL 1-1/2” FNPT x FNPT T-15NL 16/2 105-508 2” FNPT x FNPT T-15 8/2 105-508NL 2” FNPT x FNPT T-15NL 8/2

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

Y-STRAINERS

Bronze Y-Strainer

Traditional & no lead bronze 300 CWP, 150 WSP ANSI/NSF 372 (T/S-15NL) 20 mesh 304 stainless steel screen Square head closure plug included

S-15

2-1/2” & 3” With 304 Stainless Steel 1/16" Perforated Strainer

105-509 2-1/2” FNPT x FNPT T-15 6/1

105-509NL 2-1/2” FNPT x FNPT T-15NL 6/1

105-510 3” FNPT x FNPT T-15 4/1

105-510NL 3” FNPT x FNPT T-15NL 4/1

105-513 1/2” Sweat x Sweat S-15 48/12

105-513NL 1/2” Sweat x Sweat S-15NL 48/12

105-514 3/4” Sweat x Sweat S-15 48/8

105-514NL 3/4” Sweat x Sweat S-15NL 48/8

105-515 1” Sweat x Sweat S-15 24/6

105-515NL 1” Sweat x Sweat S-15NL 24/6

105-516 1-1/4” Sweat x Sweat S-15 24/6

105-516NL 1-1/4” Sweat x Sweat S-15NL 24/6

105-517 1-1/2” Sweat x Sweat S-15 16/2

105-517NL 1-1/2” Sweat x Sweat S-15NL 16/2

105-518 2” Sweat x Sweat S-15 8/2

105-518NL 2” Sweat x Sweat S-15NL 8/2

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

Compact Y-Strainer

Traditional & no lead brass 300 CWP, 150 WSP ANSI/NSF 372 (T/S-16NL) 20 mesh 304 stainless steel screen No closure plug ISO 9002

T-16

2-1/2” & 3” With 304 Stainless Steel 1/16" Perforated Strainer

105-519 2-1/2” Sweat x Sweat S-15 6/1 105-519NL 2-1/2” Sweat x Sweat S-15NL 6/1 105-520 3” Sweat x Sweat S-15 4/1 105-520NL 3” Sweat x Sweat S-15NL 4/1

105-703 1/2” FNPT x FNPT T-16 48/12

105-703NL 1/2” FNPT x FNPT T-16NL 64/8

105-704 3/4” FNPT x FNPT T-16 48/8

105-704NL 3/4” FNPT x FNPT T-16NL 64/8

105-705 1” FNPT x FNPT T-16 40/8

105-705NL 1” FNPT x FNPT T-16NL 40/8

105-706 1-1/4” FNPT x FNPT T-16 4/1

105-706NL 1-1/4” FNPT x FNPT T-16NL 24/6

105-707 1-1/2” FNPT x FNPT T-16 16/2

105-707NL 1-1/2” FNPT x FNPT T-16NL 16/2

105-708 2” FNPT x FNPT T-16 8/2

105-708NL 2” FNPT x FNPT T-16NL 8/2

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

Y-STRAINERS

Compact Y-Strainer

Traditional & no lead brass 300 CWP, 150 WSP ANSI/NSF 372 (T/S-16NL) 20 mesh 304 stainless steel screen No closure plug ISO 9002

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

Y-Strainers Screen

304 stainless steel

2-1/2” & 3” With 304 Stainless Steel 1/16" Perforated Strainer

105-709 2-1/2” FNPT x FNPT T-16 6/1 105-709NL 2-1/2” FNPT x FNPT T-16NL 6/1 105-710 3” FNPT x FNPT T-16 4/1 105-710NL 3” FNPT x FNPT T-16NL 4/1

20 Mesh Stainless Steel Screen

900-090 1/4” - 1/2” Fits T/S-15 20 Mesh SS 1/1

900-091 3/4” Fits T/S-15 20 Mesh SS 1/1

900-092 1” Fits T/S-15 20 Mesh SS 1/1

900-093 1-1/4” Fits T/S-15 20 Mesh SS 1/1

900-094 1-1/2” Fits T/S-15 20 Mesh SS 1/1

900-095 2” Fits T/S-15 20 Mesh SS 1/1

1/16” Perforated Stainless Steel Strainer

900-096 2-1/2” Fits T/S-15

900-097 3” Fits T/S-15

1/16” Perforated SS

1/1

20 Mesh SS

T/S-15 Screen

40 Mesh Stainless Steel Screen

105-533 1/4” - 1/2” Fits T/S-15 40 Mesh SS 1/1

105-534 3/4” Fits T/S-15 40 Mesh SS 1/1

105-535 1” Fits T/S-15 40 Mesh SS 1/1

105-536 1-1/4” Fits T/S-15 40 Mesh SS 1/1

105-537 1-1/2” Fits T/S-15 40 Mesh SS 1/1

105-538 2” Fits T/S-15 40 Mesh SS 1/1

80 Mesh Stainless Steel Screen

105-543 1/4 “ -1/2” Fits T/S-15 80 Mesh SS 1/1

105-544 3/4” Fits T/S-15 80 Mesh SS 1/1

105-545 1” Fits T/S-15 80 Mesh SS 1/1

105-546 1-1/4” Fits T/S-15 80 Mesh SS 1/1

105-547 1-1/2” Fits T/S-15 80 Mesh SS 1/1

105-548 2” Fits T/S-15 80 Mesh SS 1/1

20 Mesh Stainless Steel Screen

105-733 1/2” Fits T-16 20 Mesh SS 1/1

105-734 3/4” Fits T-16 20 Mesh SS 1/1

105-735 1” Fits T-16 20 Mesh SS 1/1

105-736 1-1/4” Fits T-16 20 Mesh SS 1/1

105-737 1-1/2” Fits T-16 20 Mesh SS 1/1

105-738 2” Fits T-16 20 Mesh SS 1/1

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

Y-STRAINERS

Y-Strainers Screen

304 stainless steel

40 Mesh SS

1/16” Perforated Stainless Steel Strainer

105-719 2-1/2” Fits T-16

105-720 3” Fits T-16

1/16” Perforated SS

1/1

40 Mesh Stainless Steel Screen

105-713 1/2” Fits T-16 40 Mesh SS 1/1

105-714 3/4” Fits T-16 40 Mesh SS 1/1

105-715 1” Fits T-16 40 Mesh SS 1/1

105-716 1-1/4” Fits T-16 40 Mesh SS 1/1

105-717 1-1/2” Fits T-16 40 Mesh SS 1/1

105-718 2” Fits T-16 40 Mesh SS 1/1

80 Mesh Stainless Steel Screen

105-723 1/2” Fits T-16 80 Mesh SS 1/1

105-724 3/4” Fits T-16 80 Mesh SS 1/1

105-725 1” Fits T-16 80 Mesh SS 1/1

105-726 1-1/4” Fits T-16 80 Mesh SS 1/1

105-727 1-1/2” Fits T-16 80 Mesh SS 1/1

105-728 2” Fits T-16 80 Mesh SS 1/1

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

Cast Iron Y-Strainer

ISO 9002, 500 CWP, 250 WSP to 310°F 20 mesh 304 stainless steel screen (1/4"- 2") 304 stainless steel 1/16" round perforated strainer (2-1/2"- 3") Naturally lead free Square head closure plug included

T-17

Flanged Cast Iron Y-Strainer

200 CWP, 125 WSP to 340° F Naturally lead free Square head closure plug included

T-19

105-521 1/4” FNPT x FNPT T-17 96/24

105-522 3/8” FNPT x FNPT T-17 20/1

105-523 1/2” FNPT x FNPT T-17 80/20

105-524 3/4” FNPT x FNPT T-17 40/10

105-525 1” FNPT x FNPT T-17 24/12

105-526 1-1/4” FNPT x FNPT T-17 72/6

105-527 1-1/2” FNPT x FNPT T-17 10/1

105-528 2” FNPT x FNPT T-17 6/3

105-529 2-1/2” FNPT x FNPT T-17 3/1

105-530 3” FNPT x FNPT T-17 2/1

With 1/16” Perforated 304 Stainless Steel Strainer

105-611 2” Flanged T-19 1/1 105-612 2-1/2” Flanged T-19 1/1 105-613 3” Flanged T-19 1/1 105-614 4” Flanged T-19 1/1

With 1/8” Perforated 304 Stainless Steel Strainer

105-615 5” Flanged T-19 1/1 105-616 6” Flanged T-19 1/1 105-617 8” Flanged T-19 1/1

Due to the large freight cost, the anged Y-Strainers are classied as Cast Iron for freight minimum.

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

Y-STRAINERS

316 Stainless Steel Y-Strainer

600 CWP, 150 WSP Naturally lead free Stainless steel closure plug included

T-758

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

FROSTFREE SILLCOCKS

1/4 Turn Frostfree Sillcock, Patented Design

Traditional & no lead brass 125 CWP

ISO 9002, ASSE 1019A Certied

1/4 turn Softouch™ handle, patented with integrated anti-siphon, brass cap ANSI/NSF 61G

T-550 MNPT/Sweat

With 1/32” perforated 304 stainless steel strainer

113-493 1/2” FNPT x FNPT T-758 80/20 113-494 3/4” FNPT x FNPT T-758 60/15 113-495 1” FNPT x FNPT T-758 48/12 113-496 1-1/4” FNPT x FNPT T-758 32/8 113-497 1-1/2” FNPT x FNPT T-758 24/6 113-498 2” FNPT x FNPT T-758 8/2

1/2" T-550 is Combination 1/2" MNPT and 1/2" Sweat

108-153A 1/2” x 8” MNPT / Sweat T-550 20/1

108-153NL 1/2” x 8” MNPT / Sweat T-550NL 20/1

108-154A 1/2” x 10” MNPT / Sweat T-550 20/1

108-154NL 1/2” x 10” MNPT / Sweat T-550NL 20/1

108-155A 1/2” x 12” MNPT / Sweat T-550 20/1

108-155NL 1/2” x 12” MNPT / Sweat T-550NL 20/1

108-156A 1/2” x 14” MNPT / Sweat T-550 20/1

108-156NL 1/2” x 14” MNPT / Sweat T-550NL 20/1

T-550 PEX

T-550CPVC

T-550 MNPT/FNPT

108-003A 1/2” x 8” PEX (F 1807) T-550P 20/1

108-003NL 1/2” x 8” PEX (F 1807) T-550PNL 20/1

108-004A 1/2” x 10” PEX (F 1807) T-550P 20/1

108-004NL 1/2” x 10” PEX (F 1807) T-550PNL 20/1

108-005A 1/2” x 12” PEX (F 1807) T-550P 20/1

108-005NL 1/2” x 12” PEX (F 1807) T-550PNL 20/1

108-006A 1/2” x 14” PEX (F 1807) T-550P 20/1

108-006NL 1/2” x 14” PEX (F 1807) T-550PNL 20/1

108-173A 1/2” x 8” CPVC T-550CPVC 20/1

108-174A 1/2” x 10” CPVC T-550CPVC 20/1

108-175A 1/2” x 12” CPVC T-550CPVC 20/1

3/4" T-550 is Combination 3/4" MNPT and 1/2" FNPT

108-158A 3/4” x 8” MNPT / FNPT T-550 20/1

108-158NL 3/4” x 8” MNPT / FNPT T-550NL 20/1

108-159A 3/4” x 10” MNPT / FNPT T-550 20/1

108-159NL 3/4” x 10” MNPT / FNPT T-550NL 20/1

108-160A 3/4” x 12” MNPT / FNPT T-550 20/1

108-160NL 3/4” x 12” MNPT / FNPT T-550NL 20/1

T-550 MNPT/Sweat

3/4" T-550 is Combination 3/4" MNPT and 3/4" Sweat

108-166A 3/4” x 8” MNPT / Sweat T-550 20/1

108-167A 3/4” x 10” MNPT / Sweat T-550 20/1

108-168A 3/4” x 12” MNPT / Sweat T-550 20/1

108-169A 3/4” x 14” MNPT / Sweat T-550 20/1

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

FROSTFREE SILLCOCKS

T-550 Replacement Parts

T-550 Cartridge & stem

T-552 Close Coupled Sillcock

Multi-turn with integrated anti-siphon and SoftouchTM handle

T-552

Handle, Screw & Disc

108-162

Handle, Screw & Disc

T-550 & T-550NL

100/1

T-550 Cartridge & Stem

108-904A 4” Cartridge & Stem T-550 & T-550NL 20/10

108-906A 6” Cartridge & Stem T-550 & T-550NL 20/10

108-908A 8” Cartridge & Stem T-550 & T-550NL 20/10

108-910A 10” Cartridge & Stem T-550 & T-550NL 20/10

108-912A 12” Cartridge & Stem T-550 & T-550NL 20/10

108-914A 14” Cartridge & Stem T-550 & T-550NL 20/10

108-120 1/2” x 2-7/8” MNPT x Sweat T-552 20/1

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

TM-550 Multi-Turn Frostfree Sillcock

Traditional & no lead brass ISO 9002, 125 CWP

ASSE 1019 certied

ANSI/NSF 61-G (NL models) Multi-turn Softouch™ handle, patented with integrated anti-siphon, brass cap

TM-550 MNPT/Sweat

TM-550 MNPT/FNPT

1/2" TM-550 is Combination 1/2" MNPT and 1/2" Sweat

108-021 1/2” x 4” MNPT / Sweat TM-550 20/1 108-021NL 1/2” x 4” MNPT / Sweat TM-550NL 20/1 108-022 1/2” x 6” MNPT / Sweat TM-550 20/1 108-022NL 1/2” x 6” MNPT / Sweat TM-550NL 20/1 108-023 1/2” x 8” MNPT / Sweat TM-550 20/1 108-023NL 1/2” x 8” MNPT / Sweat TM-550NL 20/1 108-024 1/2” x 10” MNPT / Sweat TM-550 20/1 108-024NL 1/2” x 10” MNPT / Sweat TM-550NL 20/1 108-025 1/2” x 12” MNPT / Sweat TM-550 20/1 108-025NL 1/2” x 12” MNPT / Sweat TM-550NL 20/1 108-026 1/2” x 14” MNPT / Sweat TM-550 20/1 108-026NL 1/2” x 14” MNPT / Sweat TM-550NL 20/1

3/4" TM-550 is Combination 3/4" MNPT and 1/2" FNPT

108-027 3/4” x 4” MNPT / FNPT TM-550 20/1

108-027NL 3/4” x 4” MNPT / FNPT TM-550NL 20/1

108-028 3/4” x 6” MNPT / FNPT TM-550 20/1

108-028NL 3/4” x 6” MNPT / FNPT TM-550NL 20/1

108-029 3/4” x 8” MNPT / FNPT TM-550 20/1

108-029NL 3/4” x 8” MNPT / FNPT TM-550NL 20/1

108-030 3/4” x 10” MNPT / FNPT TM-550 20/1

108-030NL 3/4” x 10” MNPT / FNPT TM-550NL 20/1

108-031 3/4” x 12” MNPT / FNPT TM-550 20/1

108-031NL 3/4” x 12” MNPT / FNPT TM-550NL 20/1

108-032 3/4” x 14” MNPT / FNPT TM-550 20/1

108-032NL 3/4” x 14” MNPT / FNPT TM-550NL 20/1

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

FROSTFREE SILLCOCKS

TM-550 Multi-Turn Frostfree Sillcock

Traditional & no lead brass ISO 9002, 125 CWP

ASSE 1019 certied

ANSI/NSF 61-G (NL models) Multi-turn Softouch™ handle, patented with integrated anti-siphon, brass cap

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

TM-550PNL

TM-550P1960 Mutli-Turn Frostfree Faucet

Traditional & no lead brass 125 CWP, ASTM F 1960 Cold Expansion PEX Inlet ANSI/NSF 61-G (NL models) Multi-turn Softouch™ handle, patented with integrated anti-siphon, brass cap

TM-550P1960 PEX

108-033 1/2” x 4” PEX (F1807) TM-550P 20/1

108-033NL 1/2” x 4” PEX (F1807) TM-550PNL 20/1

108-034 1/2” x 6” PEX (F1807) TM-550P 20/1

108-034NL 1/2” x 6” PEX (F1807) TM-550PNL 20/1

108-035 1/2” x 8” PEX (F1807) TM-550P 20/1

108-035NL 1/2” x 8” PEX (F1807) TM-550PNL 20/1

108-036 1/2” x 10” PEX (F1807) TM-550P 20/1

108-036NL 1/2” x 10” PEX (F1807) TM-550PNL 20/1

108-037 1/2” x 12” PEX (F1807) TM-550P 20/1

108-037NL 1/2” x 12” PEX (F1807) TM-550PNL 20/1

108-038 1/2” x 14” PEX (F1807) TM-550P 20/1

108-038NL 1/2” x 14” PEX (F1807) TM-550PNL 20/1

108-041 1/2” x 4” 1960 PEX TM-550P1960 20/1

108-041NL 1/2” x 4” 1960 PEX TM-550PNL1960 20/1

108-042 1/2” x 6” 1960 PEX TM-550P1960 20/1

108-042NL 1/2” x 6” 1960 PEX TM-550PNL1960 20/1

108-043 1/2” x 8” 1960 PEX TM-550P1960 20/1

108-043NL 1/2” x 8” 1960 PEX TM-550PNL1960 20/1

108-044 1/2” x 10” 1960 PEX TM-550P1960 20/1

108-044NL 1/2” x 10” 1960 PEX TM-550PNL1960 20/1

108-045 1/2” x 12” 1960 PEX TM-550P1960 20/1

108-045NL 1/2” x 12” 1960 PEX TM-550PNL1960 20/1

108-046 1/2” x 14” 1960 PEX TM-550P1960 20/1

108-046NL 1/2” x 14” 1960 PEX TM-550PNL1960 20/1

TM-550 Replacement Part

ANSI/NSF 61-G

TM-550 Brass Cup Assembly & Spring

T-550, TM-550 Repair Kit

Seat Washer, Brass Cup Assembly & Spring

108-550 TM-550 200/50

108-550NL TM-550NL 200/50

Vacuum breaker repair kit for T-550 & TM-550

108-903 T-550 / TM-550 100/1

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

FROSTFREE SILLCOCKS

T-552 Multi-Turn Frostfree Sillcock

Traditional & no lead brass ISO 9002, 125 CWP

ASSE 1019A certied CSA Certied (Canada)

ANSI/NSF 61-G (NL models) with integrated anti-siphon

Third party certied Truesdail

T-552

T-552 MNPT/FNPT

1/2" T-552 is Combination 1/2" MNPT and 1/2" Sweat

108-121 1/2” x 4” MNPT / Sweat T-552 40/10

108-121NL 1/2” x 4” MNPT / Sweat T-552NL 40/10 108-122 1/2” x 6” MNPT / Sweat T-552 40/10

108-122NL 1/2” x 6” MNPT / Sweat T-552NL 40/10

108-123 1/2” x 8” MNPT / Sweat T-552 40/10 108-123NL 1/2” x 8” MNPT / Sweat T-552NL 40/10 108-124 1/2” x 10” MNPT / Sweat T-552 40/10 108-124NL 1/2” x 10” MNPT / Sweat T-552NL 40/10 108-125 1/2” x 12” MNPT / Sweat T-552 40/10 108-125NL 1/2” x 12” MNPT / Sweat T-552NL 40/10 108-126 1/2” x 14” MNPT / Sweat T-552 40/10 108-126NL 1/2” x 14” MNPT / Sweat T-552NL 40/10

3/4" T-552 is Combination 3/4" MNPT and 1/2" FNPT

108-133 3/4” x 8” MNPT / FNPT T-552 40/10 108-133NL 3/4” x 8” MNPT / FNPT T-552NL 40/10 108-134 3/4” x 10” MNPT / FNPT T-552 40/10 108-134NL 3/4” x 10” MNPT / FNPT T-552NL 40/10 108-135 3/4” x 12” MNPT / FNPT T-552 40/10 108-135NL 3/4” x 12” MNPT / FNPT T-552NL 40/10

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

T-552 PEX

T-552 Repair Accessories

Stem Repair Kit

Vacuum Breaker

Repair Kit

108-141 1/2” x 4” PEX (F 1807) T-552P 40/10 108-141NL 1/2” x 4” PEX (F 1807) T-552PNL 40/10 108-142 1/2” x 6” PEX (F 1807) T-552P 40/10 108-142NL 1/2” x 6” PEX (F 1807) T-552PNL 40/10 108-143 1/2” x 8” PEX (F 1807) T-552P 40/10 108-143NL 1/2” x 8” PEX (F 1807) T-552PNL 40/10 108-144 1/2” x 10” PEX (F 1807) T-552P 40/10 108-144NL 1/2” x 10” PEX (F 1807) T-552PNL 40/10 108-145 1/2” x 12” PEX (F 1807) T-552P 40/10 108-145NL 1/2” x 12” PEX (F 1807) T-552PNL 40/10 108-146 1/2” x 14” PEX (F 1807) T-552P 40/10 108-146NL 1/2” x 14” PEX (F 1807) T-552PNL 40/10

Vacuum Breaker Repair Kit

108-138 VB Repair Kit T-552 & T-552NL 1/1

Stem Repair Kit

108-139 Stem Repair Kit T-552 & T-552NL 100/1

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

FROSTFREE SILLCOCKS

T-551 Standard Multi-Turn Frostfree Sillcock

Traditional & no lead brass ISO 9002, 125 CWP

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

T-551

1/2" T-551 is Combination 1/2" MNPT and 1/2" Sweat

108-101 1/2” x 4” MNPT / Sweat T-551 60/2 108-101NL 1/2” x 4” MNPT / Sweat T-551NL 60/2 108-102 1/2” x 6” MNPT / Sweat T-551 60/2 108-102NL 1/2” x 6” MNPT / Sweat T-551NL 60/2 108-103 1/2” x 8” MNPT / Sweat T-551 60/2 108-103NL 1/2” x 8” MNPT / Sweat T-551NL 60/2 108-104 1/2” x 10” MNPT / Sweat T-551 60/2 108-104NL 1/2” x 10” MNPT / Sweat T-551NL 60/2 108-105 1/2” x 12” MNPT / Sweat T-551 60/2 108-105NL 1/2” x 12” MNPT / Sweat T-551NL 60/2 108-106 1/2” x 14” MNPT / Sweat T-551 60/2 108-106NL 1/2” x 14” MNPT / Sweat T-551NL 60/2

3/4" T-551 is Combination 3/4" MNPT and 1/2" FNPT

108-113 3/4” x 8” MNPT / FNPT T-551 60/2 108-113NL 3/4” x 8” MNPT / FNPT T-551NL 60/2 108-114 3/4” x 10” MNPT / FNPT T-551 60/2 108-114NL 3/4” x 10” MNPT / FNPT T-551NL 60/2 108-115 3/4” x 12” MNPT / FNPT T-551 60/2 108-115NL 3/4” x 12” MNPT / FNPT T-551NL 60/2

1/4 TURN PLUMBING VALVES

1/4 Turn Ball Valve Boiler Drain

Traditional & no lead forged brass ISO 9002, 200 CWP ANSI/NSF 61-G (NL only)

R-672

1/4 Turn Ball Valve Sillcock

Traditional & no lead forged brass

CSA Certied USA and Canada

ISO 9002, 200 CWP ANSI/NSF 61-G (NL only)

R-673NL

R-670

1/2" R-670 & R-670NL is Combination 1/2" MNPT and 1/2" Sweat

107-543 1/2” MNPT R-670 100/10 107-543NL 1/2” MNPT R-670NL 100/10 107-544 3/4” MNPT R-670 100/10 107-544NL 3/4” MNPT R-670NL 100/10

107-554 1/2” FNPT R-672 100/10 107-554NL 1/2” FNPT R-672NL 100/10 107-555 3/4” FNPT R-672 100/10 107-555NL 3/4” FNPT R-672NL 100/10

107-574 1/2” FNPT R-673 100/10 107-574NL 1/2” FNPT R-673NL 100/10 107-575 3/4” FNPT R-673 100/10 107-575NL 3/4” FNPT R-673NL 100/10

107-584 1/2” Sweat R-674 100/10 107-584NL 1/2” Sweat R-674NL 100/10

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

1/4 TURN PLUMBING VALVES

1/4 Turn Ball Valve Sillcock

Traditional & no lead forged brass

CSA Certied USA and Canada

ISO 9002, 200 CWP ANSI/NSF 61-G (NL only)

1/4 Turn No Kink Hose Bibb

Traditional & no lead forged brass ISO 9002, 200 CWP ANSI/NSF 61-G (NL only)

1/4 Turn Ball Valve Hose Bibb

Traditional & no lead forged brass ISO 9002, 200 CWP ANSI/NSF 61-G (NL only)

R-674NL

R-671

T-537NL

107-585 3/4” Sweat R-674 100/10

107-585NL 3/4” Sweat R-674NL 100/10

1/2" R-671 is Combination 1/2" MNPT and 1/2" Sweat

107-567 1/2” MNPT R-671 100/10 107-567NL 1/2” MNPT R-671NL 100/10 107-568 3/4” MNPT R-671 100/10 107-568NL 3/4” MNPT R-671NL 100/10

1/2” T-537, T-537L & T-540 is Combination 1/2" MNPT and 1/2" Sweat

107-167 1/2” MNPT T-537 100/10

107-167NL 1/2” MNPT T-537NL 100/10

107-168 3/4” MNPT T-537 100/10

107-168NL 3/4” MNPT T-537NL 100/10

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

T-537L

Lever Handle

T-540

1/4 Turn Ball Valve Flanged Sillcock

Forged brass 125 CWP ISO 9002

T-541FLG

S-541FLG

1/2” T-537, T-537L & T-540 is Combination 1/2" MNPT and 1/2" Sweat

107-162 1/2” MNPT T-537L 100/10

107-162NL 1/2” MNPT T-537LNL 100/10

107-163 3/4” MNPT T-537L 100/10

107-163NL 3/4” MNPT T-537LNL 100/10

Water Heater Drain Valve

107-169 3/4” MNPT T-540 100/10

107-169NL 3/4” MNPT T-540NL 100/10

Lever Handle

107-464 1/2” FNPT T-541FLG 72/12 107-465 3/4” FNPT T-541FLG 72/12

107-474 1/2” Sweat S-541FLG 72/12 107-475 3/4” Sweat S-541FLG 72/12

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

1/4 TURN PLUMBING VALVES

1/4 Turn Ball Valve Flanged Sillcock, Chrome Plated

Forged brass 125 CWP

107-464CP 1/2" FNPT T-541CFL 72/12 107-465CP 3/4" FNPT T-541CFL 72/12

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

T-547RB Commercial Ball Valve Sillcock

S-541CFL

125 psi max temp 180°F ASSE 1011, CSA B62.2.2 (Canada) ISO 9002

T-548 Satin Commercial Ball Type Sillcock

125 psi max temp 180°F ASSE 1011, CSA B62.2.2 (Canada) ISO 9002

T-541CFL

T-547RB

107-474CP 1/2" Solder S-541CFL 72/12 107-475CP 3/4" Solder S-541CFL 72/12

Quarter-turn, includes a Softouch

handle and loose key

107-431 1/2" FNPT x MGHT T-547RB 24/1

107-432 3/4" FNPT x MGHT T-547RB 24/1

Quarter-turn, includes a Softouch

handle and loose key

107-441 1/2" FNPT x MGHT T-548 24/1

107-442 3/4" FNPT x MGHT T-548 24/1

T-548

T-549CP Commercial Ball Type Sillcock

125 psi max temp 180°F ASSE 1011, CSA B62.2.2 ISO 9002

T-549CP

Did you know? Legend ships every order complete or you will receive 5% off the backorder.

Quarter-turn, includes a Softouch

handle and loose key

107-451 1/2" FNPT x MGHT T-549CP 24/1

107-452 3/4" FNPT x MGHT T-549CP 24/1

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

LOW PRESSURE PLUMBING VALVES

Stop Valves

Traditional & no lead brass ISO 9002, 125 CWP ANSI/NSF 61-G (NL only)

Third party certied Truesdail

T-501NL

107-103NL 1/2” FNPT x FNPT T-501NL 100/10

107-104NL 3/4” FNPT x FNPT T-501NL 100/10

107-113NL 1/2” Sweat x Sweat S-501NL 100/10

107-114NL 3/4” Sweat x Sweat S-501NL 100/10

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

S-501NL

S-501PNL

Long Bonnet Stop Valve

Traditional & no lead brass ISO 9002, 125 CWP ANSI/NSF 61-G (NL only) 15 WSP (T/S 505 only)

Third party certied Truesdail

T-505

S-504

T-501X

107-106 1/2” FNPT x FNPT T-501X 144/12

107-107 3/4” FNPT x FNPT T-501X 144/12

107-110NL 1/2” PEX x PEX S-501PNL 100/10

107-111NL 3/4” PEX x PEX S-501PNL 100/10

Straight

107-253 1/2” FNPT x FNPT T-504 100/10

107-253NL 1/2” FNPT x FNPT T-504NL 100/10

107-255 1/2” Sweat x Sweat S-504 100/10

107-255NL 1/2” Sweat x Sweat S-504NL 100/10

107-256 3/4” Sweat x Sweat S-504 100/10

107-256NL 3/4” Sweat x Sweat S-504NL 100/10

Angle

107-257 1/2” FNPT x FNPT T-505 100/10

107-257NL 1/2” FNPT x FNPT T-505NL 100/10

107-259 1/2” Sweat x Sweat S-505 100/10

S-505

107-259NL 1/2” Sweat x Sweat S-505NL 100/10

Angle Stop Valve

No lead brass ISO 9002, 125 CWP ANSI/NSF 61-G

Third party certied Truesdail

107-116NL 1/2” FNPT x FNPT T-503NL 100/10

107-117NL 3/4” FNPT x FNPT T-503NL 100/10

107-118NL 1/2” Sweat x Sweat S-503NL 100/10

107-119NL 3/4” Sweat x Sweat S-503NL 100/10

T-503NL

S-503NL

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

LOW PRESSURE PLUMBING VALVES

Stop and Waste Valve

No lead brass ISO 9002, 125 CWP ANSI/NSF 61-G

Third party certied Truesdail

107-123NL 1/2” FNPT x FNPT T-511NL 100/10

107-124NL 3/4” FNPT x FNPT T-511NL 100/10

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

Boiler Drain

Traditional & no lead brass ISO 9002, 125 CWP ANSI/NSF 61-G (NL only) CSA (Canada)

Third party certied Truesdail

S-521NL

S-511NL

S-511PNL

T-511NL

T-512NL

T-522

T-521

107-133NL 1/2” Sweat x Sweat S-511NL 100/10

107-134NL 3/4” Sweat x Sweat S-511NL 100/10

107-316NL 1/2” Comp x Comp T-512NL 100/10

107-317NL 3/4” Comp x Comp T-512NL 100/10

107-130NL 1/2” PEX x PEX S-511PNL 100/10

107-131NL 3/4” PEX x PEX S-511PNL 100/10

1/2" Male T-521 is Combination 1/2" MNPT and 1/2" Sweat

107-143 1/2” MNPT T-521 100/10 107-143NL 1/2” MNPT T-521NL 100/10 107-144 3/4” MNPT T-521 100/10 107-144NL 3/4” MNPT T-521NL 100/10

107-146 3/4” Sweat S-521 144/12 107-146NL 3/4” Sweat S-521NL 144/12

107-154 1/2” FNPT T-522 100/10 107-154NL 1/2” FNPT T-522NL 100/10 107-155 3/4” FNPT T-522 100/10 107-155NL 3/4” FNPT T-522NL 100/10

107-148 1/2” Fitting S-524 144/12 107-148NL 1/2” Fitting S-524NL 144/12

S-524

T-523NL

S-521P

T-206

107-157NL 1/2” Compression T-523NL 144/12

107-159 1/2” PEX S-521P 100/10 107-159NL 1/2” PEX S-521PNL 100/10

No Stufng Box

107-327 1/2” MNPT T-206 100/10 107-327NL 1/2” MNPT T-206NL 100/10 107-328 3/4” MNPT T-206 100/10 107-328NL 3/4” MNPT T-206NL 100/10

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

LOW PRESSURE PLUMBING VALVES

Hose Bibb

Traditional & no lead brass ISO 9002, 125 CWP ANSI/NSF 61-G (NL only)

Third party certied Truesdail

T-531

T-532

T-532CP

1/2” Male T-531 is Combination 1/2" MNPT and 1/2” Sweat

107-164 1/2” MNPT T-531 100/10 107-164NL 1/2” MNPT T-531NL 100/10 107-165 3/4” MNPT T-531 100/10 107-165NL 3/4” MNPT T-531NL 100/10

Plain End Sampling Valve

1/2” Male T-532 is Combination 1/2" MNPT and 1/2” Sweat

107-173 1/2” MNPT T-532 144/12 107-173NL 1/2” MNPT T-532NL 144/12 107-171 3/4” MNPT T-532 144/12 107-171NL 3/4” MNPT T-532NL 144/12

Chrome Plated Plain End Valve 1/2” Male T-532CP is Combination 1/2" MNPT and 1/2” Sweat

107-423 1/2” MNPT T-532CP 144/12 107-423NL 1/2” MNPT T-532CPNL 144/12 107-424 3/4” MNPT T-532CP 144/12 107-424NL 3/4” MNPT T-532CPNL 144/12

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

T-533

S-535

No Kink

1/2” Male T-533 is Combination 1/2" MNPT and 1/2” Sweat

107-203 1/2” MNPT T-533 144/12 107-203NL 1/2” MNPT T-533NL 144/12 107-204 3/4” MNPT T-533 144/12 107-204NL 3/4” MNPT T-533NL 144/12

107-213 1/2” FNPT T-534 144/12 107-213NL 1/2” FNPT T-534NL 144/12 107-214 3/4” FNPT T-534 144/12 107-214NL 3/4” FNPT T-534NL 144/12

T-534

S-535 is Combination 3/4" Fitting and 1/2" Sweat

107-223 3/4”/ 1/2” FTG / Sweat S-535 144/12 107-223NL 3/4”/ 1/2” FTG / Sweat S-535NL 144/12

Did you know? Legend guarantees error-free transactions or you will receive 5% off the error.

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

LOW PRESSURE PLUMBING VALVES

Heavy Pattern Hose Bibb

Traditional & no lead brass ISO 9002, 125 CWP ANSI/NSF 61-G (NL only)

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

T-533HP

1/2” Male T-531HP is Combination 1/2" MNPT and 1/2” Sweat

107-263 1/2” MNPT T-531HP 72/12 107-263NL 1/2” MNPT T-531HPNL 72/12 107-264 3/4” MNPT T-531HP 72/12 107-264NL 3/4” MNPT T-531HPNL 100/10

T-531HP

107-265 1” MNPT T-531HP 72/12 107-265NL 1” MNPT T-531HPNL 72/12

No Kink

107-267 1/2” MNPT T-533HP 144/12 107-267NL 1/2” MNPT T-533HPNL 144/12 107-268 3/4” MNPT T-533HP 144/12 107-268NL 3/4” MNPT T-533HPNL 144/12 107-270 1/2” FNPT T-534HP 144/12 107-270NL 1/2” FNPT T-534HPNL 144/12 107-271 3/4” FNPT T-534HP 144/12

T-534HP

107-271NL 3/4” FNPT T-534HPNL 144/12

T-536HP

Sillcock

Traditional & no lead brass ISO 9002, 125 CWP CSA (Canada) no lead only ANSI/NSF 61-G (NL only)

S-541

S-535HP

T-541

T-541LS

S-535HP is Combination 3/4" Fitting and 1/2" Sweat

107-275 3/4”/ 1/2” FTG / Sweat S-535HP 100/10 107-275NL 3/4”/ 1/2” FTG / Sweat S-535HPNL 100/10

107-277 1/2” Compression T-536HP 100/10 107-277NL 1/2” Compression T-536HPNL 100/10

107-174 1/2” FNPT T-541 100/10

107-174NL 1/2” FNPT T-541NL 100/10

107-175 3/4” FNPT T-541 100/10

107-175NL 3/4” FNPT T-541NL 100/10

107-184 1/2” Sweat S-541 100/10

107-184NL 1/2” Sweat S-541NL 100/10

107-185 3/4” Sweat S-541 100/10

107-185NL 3/4” Sweat S-541NL 100/10

With Lockshield

107-187 1/2” FNPT T-541LS 100/10

107-187NL 1/2” FNPT T-541LSNL 100/10

107-188 3/4” FNPT T-541LS 100/10

107-188NL 3/4” FNPT T-541LSNL 100/10

107-189 1/2” Sweat S-541LS 100/10

107-189NL 1/2” Sweat S-541LSNL 100/10

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

LOW PRESSURE PLUMBING VALVES

Sillcock

Traditional & no lead brass ISO 9002, 125 CWP CSA (Canada) no lead only ANSI/NSF 61-G (NL only)

S-211

Sillcock

Traditional & no lead brass

107-179P 1/2" T-514P Sillcock - F1807 PEX T-514P 120/20

ISO 9002, 125 CWP CSA (Canada) no lead only ANSI/NSF 61-G (NL only)

S-211 is Combination 3/4" Fitting and 1/2" Sweat

107-347 3/4”/ 1/2” FTG / Sweat S-211 144/12

107-347NL 3/4”/ 1/2” FTG / Sweat S-211NL 144/12

NEW

107-179PNL 1/2" T-514PNL Sillcock - F1807 PEX T-514PNL 120/20

NEW

107-180P 3/4" T-514P Sillcock - F1807 PEX T-514P 120/20

NEW

107-180PNL 3/4" T-514PNL Sillcock - F1807 PEX T-514PNL 120/20

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

T-514PNL F1807

T-514PNL F1960

Commercial Sillcock, Chrome Plated

Traditional & no lead brass ISO 9002, 125 CWP CSA (Canada) no lead only ANSI/NSF 61-G (NL only)

T-545

T-546

NEW

107-181P 1/2" T-514P Sillcock - F1960 PEX T-514P 120/20

NEW

107-181PNL 1/2" T-514PNL Sillcock - F1960 PEX T-514PNL 120/20

NEW

107-182P 3/4" T-514P Sillcock - F1960 PEX T-514P 120/20

NEW

107-182PNL 3/4" T-514PNL Sillcock - F1960 PEX T-514PNL 120/20

107-403 1/2” FNPT T-545 144/12

107-403NL 1/2” FNPT T-545NL 144/12

107-404 3/4” FNPT T-545 144/12

107-404NL 3/4” FNPT T-545NL 144/12

With Lockshield

107-407 1/2” FNPT T-546 144/12

107-407NL 1/2” FNPT T-546NL 144/12

107-408 3/4” FNPT T-546 144/12

107-408NL 3/4” FNPT T-546NL 144/12

Key only for T-546

107-410 Key for T-546 50/10

Key

With Assembled Chrome Plated Vacuum Breaker

107-413 1/2” FNPT T-545VB 72/12

107-413NL 1/2” FNPT T-545VBNL 144/12

107-414 3/4” FNPT T-545VB 72/12

T-545VB

107-414NL 3/4” FNPT T-545VBNL 72/12

With Lockshield & Assembled Chrome Plated Vacuum Breaker

107-417 1/2” FNPT T-546VB 72/12

107-417NL 1/2” FNPT T-546VBNL 72/12

107-418 3/4” FNPT T-546VB 72/12

T-546VB

107-418NL 3/4” FNPT T-546VBNL 144/12

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

LOW PRESSURE PLUMBING VALVES

Bent Nose Garden Valve

Traditional & no lead brass ISO 9002, 125 CWP ANSI/NSF 61-G (NL only)

Third party certied Truesdail

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

T-544

Water Heater Drain Valve

Traditional & no lead brass ISO 9002, 125 CWP NSF 372 (NL)

107-243 1/2” FNPT T-543 100/10

107-243NL 1/2” FNPT T-543NL 100/10

107-244 3/4” FNPT T-543 100/10

107-244NL 3/4” FNPT T-543NL 100/10

107-245 1” FNPT T-543 100/10

107-245NL 1” FNPT T-543NL 100/10

Inverted

T-543

107-246 3/4” FNPT T-544 72/12

107-246NL 3/4” FNPT T-544NL 72/12

107-192 3/4” MNPT T-539 144/12

107-192NL 3/4” MNPT T-539NL 144/12

T-539

SUPPLY STOPS - 1/4 TURN

Insta-Loc® 1/4 Turn Push-Fit CP Supply Stop

No lead forged brass ISO 9002, 125 CWP, max temp 120° ANSI/NSF 61-G

Third party certied Truesdail

T-596NL

Push x OD

T-596NL

Push x OD

T-595NL

Push x OD

T-595NL

Push x OD

Angle Valves

114-903NL 1/2” x 3/8” Push x OD T-595NL 120/5

114-904NL 1/2” x 1/4” Push x OD T-595NL 120/5

Straight Valves

114-913NL 1/2” x 3/8“ Push x OD T-596NL 120/5

114-914NL 1/2” x 1/4” Push x OD T-596NL 120/5

Removable Angle Valves

114-943NL 1/2" x 3/8" Push x OD T-595NL 120/5

114-944NL 1/2" x 1/4" Push x OD T-595NL 120/5

Removable Straight Valves

114-953NL 1/2" x 3/8" Push x OD T-596NL 120/5

114-954NL 1/2" x 1/4" Push x OD T-596NL 120/5

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

SUPPLY STOPS - 1/4 TURN

1/4 Turn Angle Valve

No lead forged brass ISO 9002, 125 CWP ANSI/NSF 61-G

Third party certied Truesdail

OD x OD T-595NL

FNPT x OD

T-595NL

CPVC x OD

T-595NL

114-602NL 3/8“ x 3/8” FNPT x OD T-595NL 120/5

114-603NL 1/2” x 3/8” FNPT x OD T-595NL 120/5

114-604NL 5/8” x 3/8” OD x OD T-595NL 120/5

114-607NL 1/2” x 3/8” CPVC x OD T-595NL 120/5

114-609NL 1/2” x 3/8” PEX x OD T-595NL 120/5

114-606NL 1/2” x 3/8” PEX (F 1960) x OD T-595NL 60/5

114-613NL 1/2” x 3/8” Sweat x OD T-595NL 120/5

Icemaker Valve

114-614NL 5/8” x 1/4” OD x OD T-595NL 120/5

114-615NL 1/2" x 1/4" PEX x OD T-595NL 60/5

114-605NL 1/2" x 1/4" PEX (F 1960) x OD T-595NL 60/5

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

PEX x OD

T-595NL

OD x SJ T-593NL

1/4 Turn Straight Valve

No lead forged brass ISO 9002, 125 CWP, max temp 120°F ANSI/NSF 61-G

Third party certied Truesdail

CPVC x OD

T-596NL

Sweat x OD

T-596NL

Sweat x OD

T-595NL

FNPT x OD

T-596NL

PEX x OD

T-596NL

FNPT x SJ

T-594NL

Polished Brass

114-624NL 5/8” x 3/8” OD x OD T-595PBNL 120/5

Slip Joint Outlet 1/2” Or 7/16” OD

114-653NL 1/2” FNPT x SJ T-593NL 120/5

114-654NL 5/8” OD x SJ T-593NL 120/5

114-702NL 3/8” x 3/8” FNPT x OD T-596NL 120/5

114-703NL 1/2” x 3/8” FNPT x OD T-596NL 120/5

114-704NL 5/8” x 3/8” OD x OD T-596NL 120/5

114-707NL 1/2” x 3/8” CPVC x OD T-596NL 120/5

114-709NL 1/2” x 3/8” PEX x OD T-596NL 120/5

114-710NL 1/2” x 1/2” PEX x PEX T-596NL 120/5

114-706NL 1/2” x 3/8” PEX (F 1960) x OD T-596NL 120/5

114-713NL 1/2” x 3/8” Sweat x OD T-596NL 120/5

Icemaker Valve

114-714NL 5/8” x 1/4” OD x OD T-596NL 120/5

114-715NL 1/2" x 1/4" PEX x OD T-596NL 60/5

114-705NL 1/2" x 1/4" PEX (F 1960) x OD T-596NL 60/5

Polished Brass

114-724NL 5/8" x 3/8" OD x OD T-596PBNL 120/5

Slip Joint Outlet 1/2” Or 7/16” OD

114-753NL 1/2” FNPT x SJ T-594NL 120/5

114-754NL 5/8" OD x SJ T-594NL 120/5

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

SUPPLY STOPS - 1/4 TURN

1/4 Turn Dual Outlet Valve

No lead forged brass ISO 9002, 125 CWP, max temp 120°F ANSI/NSF 61-G

Third party certied Truesdail

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

T-597NL

PEX x OD x OD

T-598NL No Lead Brass Dual Handle 1/4 Turn Stop Valve

No lead forged brass 125 CWP, ANSI/NSF 61

FNPT x OD x OD

T-597NL

1960 PEX x OD x OD

114-803NL 1/2” x 3/8” x 3/8” FNPT x OD x OD T-597NL 120/5

114-804NL 5/8” x 3/8” x 3/8” OD x OD x OD T-597NL 120/5

114-823NL 1/2” x 3/8” x 1/4” FNPT x OD x OD T-597NL 120/5

114-824NL 5/8” x 3/8” x 1/4” OD x OD x OD T-597NL 120/5 114-805NL 1/2" x 3/8" x 1/4" PEX x OD x OD T-597NL 60/5

114-806NL 1/2" x 3/8" x 3/8" PEX x OD x OD T-597NL 60/5

114-801NL 1/2" x 3/8" x 1/4"

114-802NL 1/2" x 3/8" x 3/8"

PEX (F 1960) x OD x OD

T-597NL 60/5

Angle Stop Valve

114-630NL 5/8" x 3/8" x 1/4" OD x OD x OD T-598NL 100/10

114-631NL 5/8" x 3/8" x 3/8" OD x OD x OD T-598NL 100/10

T-598NL Compression

T-598NL F1807 PEX

T-598NL F1960 PEX

T-598NL Compression

T-598NL F1807 PEX

T-598NL F1960 PEX

SUPPLY STOPS - TRADITIONAL STYLE

Multi-Turn Angle Valve

No lead forged brass ISO 9002, 110 CWP ANSI/NSF 61-G

OD x OD T-581NL

NEW

114-632NL 1/2" x 3/8" x 3/8" F1807 PEX x OD x OD T-598NL 120/20

NEW

114-633NL 1/2" x 3/8" x 1/4" F1807 PEX x OD x OD T-598NL 120/20

NEW

114-634NL 1/2" x 3/8" x 3/8" F1960 PEX x OD x OD T-598NL 120/20

NEW

114-635NL 1/2" x 3/8" x 1/4" F1960 PEX x OD x OD T-598NL 120/20

Straight Stop Valve

114-730NL 5/8" x 3/8" x 1/4" OD x OD x OD T-598NL 100/10

114-731NL 5/8" x 3/8" x 3/8" OD x OD x OD T-598NL 120/10

NEW

114-732NL 1/2" x 3/8" x 3/8" F1807 PEX x OD x OD T-598NL 120/20

NEW

114-733NL 1/2" x 3/8" x 1/4" F1807 PEX x OD x OD T-598NL 120/20

NEW

114-734NL 1/2" x 3/8" x 3/8" F1960 PEX x OD x OD T-598NL 120/20

NEW

114-735NL 1/2" x 3/8" x 1/4" F1960 PEX x OD x OD T-598NL 120/20

114-101NL 3/8” x 3/8” OD x OD T-581NL (CR-1B) 200/10

114-102NL 3/8” x 3/8” FNPT x OD T-581NL (R-15) 200/10

114-103NL 1/2” x 3/8” FNPT x OD T-581NL (R-17) 200/10

114-104NL 5/8” x 3/8” OD x OD T-581NL (CR-19) 200/10

114-107NL 1/2” x 3/8” CPVC x OD T-581NL (R-19) 200/10

CPVC x OD

T-581NL

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

SUPPLY STOPS - TRADITIONAL STYLE

Multi-Turn Angle Valve cont.

No lead forged brass ISO 9002, 110 CWP ANSI/NSF 61-G

PEX x OD T-581PNL

114-113NL 1/2” x 3/8” Sweat x OD S-581NL (R-19) 200/10

114-109NL 1/2” x 3/8” PEX x OD T-581PNL 200/10

Icemaker Valve

114-116NL 5/8” x 1/4” OD x OD T-581NL (CR-09) 200/10

GATE, CHECK, LOW PRESSURE

VALVES & Y-STRAINERS

Sweat x OD

S-581ETNL

Sweat x OD

S-581RBNL

OD x SJ

T-583NL

OD x OD

T-581RBNL

OD x OD

T-581PBNL

With 5” Extension Tube & Bell Escutcheon

114-115NL 1/2” x 3/8” Sweat x OD

S-581ETNL (CS-40B)

100/10

Rough Brass Stops

114-153NL 1/2” x 3/8” FNPT x OD

114-154NL 5/8” x 3/8” OD x OD

T-581RBNL (R-17R)

T-581RBNL (CR19R)

200/10

114-163NL 1/2” x 3/8” Sweat x OD S-581RBNL (R19R) 200/10

Polished Brass

114-304NL 5/8” x 3/8” OD x OD T-581PBNL 200/10

1/2" OD Outlet

114-123NL 1/2” x 1/2” FNPT x OD T-581NL (R-37) 200/10

114-124NL 5/8” x 1/2” OD x OD (CR-39) T-581NL (CR-39) 200/10

114-126NL 1/2” x 1/2” Sweat x OD S-581NL (R-39) 200/10

Slip Joint Outlet 1/2” or 7/16” OD

114-133NL 1/2" FNPT x SJ T-583NL 200/10

114-134NL 5/8” OD x SJ T-583NL (3341) 200/10

114-136NL 1/2” Sweat x SJ S-583NL (3321) 200/10

With Lockshield

114-143NL 1/2” x 3/8” FNPT x OD T-581LSNL 200/10

114-144NL 5/8” x 3/8” OD x OD T-581LSNL 200/10

Sweat x OD

S-581LSNL

114-146NL 1/2” x 3/8” Sweat x OD S-581LSNL 200/10

Multi-Turn Straight Valve

No lead forged brass ISO 9002, 110 CWP ANSI/NSF 61 G

114-200NL 1/4” x 1/4” OD x OD T-582NL 200/10

114-201NL 3/8” x 3/8” OD x OD T-582NL (CR-11) 200/10

114-202NL 3/8” x 3/8” FNPT x OD T-582NL (R-10) 200/10

114-203NL 1/2” x 3/8” FNPT x OD T-582NL (R-12) 200/10

114-204NL 5/8” x 3/8” OD x OD T-582NL (CR-14) 200/10

CPVC x OD

T-582NL

114-207NL 1/2” x 3/8” CPVC x OD T-582NL (PR-14) 200/10

114-209NL 1/2” x 3/8” PEX x OD T-582PNL 200/10

114-513NL 1/2” x 1/2" PEX x PEX T-591PNL 200/10

PEX x OD T-591PNL

114-213NL 1/2” x 3/8” Sweat x OD S-582NL (R-14) 200/10

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

SUPPLY STOPS - TRADITIONAL STYLE

Multi-Turn Straight Valve

No lead forged brass ISO 9002, 110 CWP ANSI/NSF 61 G

Sweat x OD

S-582ETNL

VALVES & Y-STRAINERS

GATE, CHECK, LOW PRESSURE

FNPT x SJ

T-584NL

Multi-Turn Dual Outlet Valve

Traditional & no lead forged brass ISO 9002, 110 CWP ANSI/NSF 61-G

With 5” Extension Tube & Bell Escutcheon

114-215NL 1/2” x 3/8” Sweat x OD

S-582ETNL (CS-41B)

1/2" OD Outlet

114-231NL 1/2” x 1/2” OD x OD T-582NL (CR-3A) 200/10

114-233NL 1/2” x 1/2” FNPT x OD T-582NL (CR-3C) 200/10

114-234NL 5/8” x 1/2” OD x OD T-582NL (CR-34) 200/10

OD x OD

T-582NL

114-236NL 1/2” x 1/2” Sweat x OD S-582NL (R-34) 200/10

Slip Joint Outlet 1/2” Or 7/16” OD

114-253NL 1/2” FNPT x SJ T-584NL (3305) 200/10

114-254NL 5/8” OD x SJ T-584NL (3345) 200/10

114-256NL 1/2” Sweat x SJ S-584NL (3321) 200/10

114-402NL 3/8” x 3/8” x 3/8” FNPT x OD x OD T-587NL (R1501) 200/10

114-403NL 1/2” x 3/8” x 3/8” FNPT x OD x OD T-587NL (R1701) 200/10

100/10

OD x OD x OD

T-587NL

114-404NL 5/8” x 3/8” x 3/8” OD x OD x OD T-587NL (CR1901) 200/10

FNPT x OD x OD

T-587NL

114-413NL 1/2” x 3/8” x 1/2” FNPT x OD x OD T-587NL (R1703R) 200/10

114-423NL 1/2” x 3/8” x 1/4" FNPT x OD x OD T-587NL (R1700) 200/10

114-424NL 5/8” x 3/8” x 1/4” OD x OD x OD T-587NL (CR1900) 200/10

114-406NL 1/2” x 3/8” x 3/8” PEX x OD x OD T-587PNL 200/10

Did you know? Legend allows you to return non-obsolete materials without a restocking charge.

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

Downstream Thinking guarantees you

the right product at the right time.

PVC BUTTERFLY VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

THERMOPLASTIC VALVES

Wafer Type PVC Butterﬂy Valve

ISO 9002 150 psi @ 73°F w/ EPDM seat and O-rings Naturally lead free

S-651

Gear Operator

PVC BALL VALVES

Grey PVC Flanged True Union Ball Valve

ISO 9002, 150 psi @ 73°F Naturally lead free

S-643

S-650

Lever Handle

7- Position Lever Handle

201-263

201-264

201-265

201-266

201-268

201-269

2” Flanged S-650 2/1

2-1/2” Flanged S-650 4/2

3” Flanged S-650 4/1

4” Flanged S-650 4/1

6” Flanged S-650 4/1

8” Flanged S-650 1/1

Gear Operator

201-270

201-271

201-272

8” Flanged S-651 1/1

10” Flanged S-651 1/1

12” Flanged S-651 1/1

201-233 1/2” Flanged S-643 24/1

201-234 3/4” Flanged S-643 24/1

201-235 1” Flanged S-643 12/1

201-236 1-1/4” Flanged S-643 12/1

201-237 1-1/2” Flanged S-643 12/1

201-238 2” Flanged S-643 12/1

201-239 2-1/2” Flanged S-643 4/1

201-240 3” Flanged S-643 2/1

201-241 4” Flanged S-643 1/1

Grey PVC True Union Ball Valve

ISO 9002, 150 psi @ 73°F With both solvent and threaded adapters (1/2"- 2") Naturally lead free

T/S-603

S-603

201-203 1/2” FNPT / Solvent T/S-603 48/1

201-204 3/4” FNPT / Solvent T/S-603 36/1

201-205 1” FNPT / Solvent T/S-603 24/1

201-206 1-1/4” FNPT / Solvent T/S-603 24/1

201-207 1-1/2” FNPT / Solvent T/S-603 24/1

201-208 2” FNPT / Solvent T/S-603 12/1

With solvents Ends Only

201-209 2-1/2” Solvent S-603 6/1

201-210 3” Solvent S-603 6/1

201-211 4” Solvent S-603 1/1

FNPT Adapters

201-229 Fits 2-1/2” FNPT S-603 1/1

201-230 Fits 3” FNPT S-603 1/1

201-231 Fits 4” FNPT S-603 1/1

Threaded adapters sold as individual pieces.

PVC BALL VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

THERMOPLASTIC VALVES

Grey PVC True Union Ball Valve

ISO 9002, 150 psi @ 73°F With both solvent and threaded adapters (1/2"- 2") Naturally lead free

T/S-603V

Grey PVC Single Union Ball Valve

ISO 9002, 150 CWP Naturally lead free

T-645

With Both End Adapters - Viton O-Rings Design

201-183 1/2” FNPT / Solvent T/S-603V 48/1

201-184 3/4” FNPT / Solvent T/S-603V 36/1

201-185 1” FNPT / Solvent T/S-603V 24/1

201-186 1-1/4” FNPT / Solvent T/S-603V 24/1

201-187 1-1/2” FNPT / Solvent T/S-603V 24/1

201-188 2” FNPT / Solvent T/S-603V 12/1

201-243 1/2” FNPT x FNPT T-645 48/1

201-244 3/4” FNPT x FNPT T-645 36/1

201-245 1” FNPT x FNPT T-645 24/1

201-246 1-1/4” FNPT x FNPT T-645 24/1

201-247 1-1/2” FNPT x FNPT T-645 24/1

201-248 2” FNPT x FNPT T-645 12/1

201-253 1/2” Solvent x Solvent S-645 48/1

201-254 3/4” Solvent x Solvent S-645 36/1

201-255 1” Solvent x Solvent S-645 24/1

201-256 1-1/4” Solvent x Solvent S-645 24/1

201-257 1-1/2” Solvent x Solvent S-645 24/1

201-258 2” Solvent x Solvent S-645 12/1

Grey PVC Compact Ball Valve

ISO 9002, 150 psi @ 73°F NSF Listed (1/2"- 2")

Teon seats, for schedule 80 use

Naturally lead free

201-423 1/2” FNPT x FNPT T-602 100/1

201-424 3/4” FNPT x FNPT T-602 100/1

201-425 1” FNPT x FNPT T-602 100/1

201-426 1-1/4” FNPT x FNPT T-602 100/1

T-602

201-427 1-1/2” FNPT x FNPT T-602 48/1

201-428 2” FNPT x FNPT T-602 24/1

201-433 1/2” Solvent x Solvent S-602 100/1

201-434 3/4” Solvent x Solvent S-602 100/1

201-435 1” Solvent x Solvent S-602 100/1

S-602

201-436 1-1/4” Solvent x Solvent S-602 100/1

201-437 1-1/2” Solvent x Solvent S-602 48/1

201-438 2” Solvent x Solvent S-602 24/1

Two-Piece E-Z Turn Valves

201-439 2-1/2” Solvent x Solvent S-602EZ 12/1

201-440 3” Solvent x Solvent S-602EZ 8/1

201-441 4” Solvent x Solvent S-602EZ 2/1

S-602EZ

PVC BALL VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

THERMOPLASTIC VALVES

PVC Compact Ball Valve

ISO 9002, 150 psi @ 73°F NSF Listed (T/S-600)

With EPDM seats, ts schedule 40 or 80 pipe

Naturally lead free

201-443 1/2” FNPT x FNPT T-600 100/1

201-444 3/4” FNPT x FNPT T-600 100/1

201-445 1” FNPT x FNPT T-600 100/1

201-446 1-1/4” FNPT x FNPT T-600 100/1

201-447 1-1/2” FNPT x FNPT T-600 48/1

201-448 2” FNPT x FNPT T-600 24/1

S-600

T-601 Lever-Handle

S-601 Lever-Handle

T-600

T-601

S-601

201-453 1/2” Solvent x Solvent S-600 100/1

201-454 3/4” Solvent x Solvent S-600 100/1

201-455 1” Solvent x Solvent S-600 100/1

201-456 1-1/4” Solvent x Solvent S-600 100/1

201-457 1-1/2” Solvent x Solvent S-600 48/1

201-458 2” Solvent x Solvent S-600 24/1

201-301 1/4” FNPT x FNPT T-601 100/10

201-303 1/2” FNPT x FNPT T-601 100/1

201-304 3/4” FNPT x FNPT T-601 100/1

201-305 1” FNPT x FNPT T-601 100/1

201-306 1-1/4” FNPT x FNPT T-601 100/1

201-307 1-1/2” FNPT x FNPT T-601 48/1

201-308 2” FNPT x FNPT T-601 24/1

201-309 2-1/2” Lever Handle FNPT x FNPT T-601 12/1

201-310 3” Lever Handle FNPT x FNPT T-601 12/1

201-311 4” Lever Handle FNPT x FNPT T-601 6/1

201-403 1/2” Solvent x Solvent S-601 100/1

201-404 3/4” Solvent x Solvent S-601 100/1

201-405 1” Solvent x Solvent S-601 100/1

201-406 1-1/4” Solvent x Solvent S-601 100/1

201-407 1-1/2” Solvent x Solvent S-601 100/1

201-408 2” Solvent x Solvent S-601 24/1

201-409 2-1/2” Lever Handle Solvent x Solvent S-601 12/1

201-410 3” Lever Handle Solvent x Solvent S-601 12/1

201-411 4” Lever Handle Solvent x Solvent S-601 6/1

S-601EZ

Two-Piece E-Z Turn Valves

201-417 2-1/2” Solvent x Solvent S-601EZ 12/1

201-418 3” Solvent x Solvent S-601EZ 8/1

201-419 4” Solvent x Solvent S-601EZ 2/1

PVC BALL VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

THERMOPLASTIC VALVES

ABS Compact Ball Valve - Black

ISO 9002, 150 psi @ 73°F

S-608

PVC CHECK VALVES

Grey PVC Ball Check Valve

ISO 9002, 150 psi @ 73°F Naturally lead free

T-655

201-467 1-1/2” Solvent x Solvent S-608 48/1

201-273 1/2” FNPT x FNPT T-655 150/1

201-274 3/4” FNPT x FNPT T-655 100/1

201-275 1” FNPT x FNPT T-655 50/1

201-277 1-1/2” FNPT x FNPT T-655 24/1

201-278 2” FNPT x FNPT T-655 12/1

201-283 1/2” Solvent x Solvent S-655 150/1

201-284 3/4” Solvent x Solvent S-655 100/1

201-285 1” Solvent x Solvent S-655 50/1

201-287 1-1/2” Solvent x Solvent S-655 24/1

201-288 2” Solvent x Solvent S-655 12/1

Grey PVC Foot Valve Screen

Naturally lead free

201-293 Fits 1/2” T/S-655 only Foot Valve Screen 1/1

201-294 Fits 3/4” T/S-655 only Foot Valve Screen 1/1

201-295 Fits 1” T/S-655 only Foot Valve Screen 1/1

201-297 Fits 1-1/2” T/S-655 only Foot Valve Screen 1/1

Screen

PVC In-Line Check Valve

ISO 9002, 150 psi @ 73°F 1/2 psi cracking pressure 304 SS Spring Naturally lead free

201-298 Fits 2” T/S-655 only Foot Valve Screen 1/1

Changes T/S-655 ball check into foot valve

203-103 1/2” FNPT x FNPT T-611 120/1

203-104 3/4” FNPT x FNPT T-611 120/1

203-105 1” FNPT x FNPT T-611 80/1

203-106 1-1/4” FNPT x FNPT T-611 60/1

203-107 1-1/2” FNPT x FNPT T-611 60/1

203-108 2” FNPT x FNPT T-611 40/1

203-203 1/2” Solvent x Solvent S-611 120/1

203-204 3/4” Solvent x Solvent S-611 120/1

T-611

203-205 1” Solvent x Solvent S-611 80/1

203-206 1-1/4” Solvent x Solvent S-611 60/1

203-207 1-1/2” Solvent x Solvent S-611 60/1

203-208 2” Solvent x Solvent S-611 40/1

BACKWATER VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

THERMOPLASTIC VALVES

Backwater Valve

ISO 9002

S-641

SUMP PUMP CHECK VALVES

S-640

S-660

PVC Backwater Valve

202-251 1-1/2” Solvent S-640 48/1

202-252 2” Solvent S-640 48/1

202-253 3” Solvent S-640 18/1

202-254 4” Solvent S-640 12/1

202-255 6” Solvent S-640 2/1

With 16” Access Sleeve

202-262 2” Solvent S-641 4/1

202-263 3” Solvent S-641 1/1

202-264 4” Solvent S-641 1/1

ABS Backwater Valve

202-273 3” Solvent S-660 18/1

202-274 4” Solvent S-660 12/1

With 16” Access Sleeve

202-283 3” Solvent S-661 1/1

202-284 4” Solvent S-661 1/1

Sump Pump Swing Check Valve

S-613: 25 psi @ 130°F All other models: 150 psi @ 73°F

S-614

S-672

S-613

S-670

Full Flow - Stainless Steel Clamps

203-227 1-1/4” - 1-1/2” S-613 60/10

203-228 2” S-613 48/6

Body Only

203-230 1-1/4” - 1-1/2” 90/15

PVC Compression Swing Check Valves

203-237 1-1/4” - 1-1/2” Comp S-614 64/8

203-238 2” Comp S-614 16/4

PVC Check / Ball Combination Valves

203-257 1-1/2” Solvent x Comp S-670 24/4

203-258 2” Solvent x Comp S-670 12/1

PVC True Union Swing Check Valves

203-247 1-1/2” Solvent S-672 32/4

203-248 2” Solvent S-672 16/4

CPVC BALL VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

THERMOPLASTIC VALVES

CPVC Compact Ball Valve

ISO 9002, 150 psi @ 73°F NSF listed Naturally lead free

S-605

S-607

Copper Tube Size - Bone color Copper Tube Size - Bone color

202-403* 1/2” Solvent x Solvent S-605 100/10 202-404* 3/4” Solvent x Solvent S-605 100/5 202-405* 1” Solvent x Solvent S-605 100/1 202-406 1-1/4” Solvent x Solvent S-605 100/1 202-407 1-1/2” Solvent x Solvent S-605 48/1 202-408 2” Solvent x Solvent S-605 24/1

*Full Port Design

With Drain

202-423 1/2” Solvent x Solvent S-606 100/10 202-424 3/4” Solvent x Solvent S-606 100/5 202-425 1” Solvent x Solvent S-606 100/1

S-606

For Schedule 80 Pipe - Grey color

202-413 1/2” Solvent x Solvent S-607 100/1 202-414 3/4” Solvent x Solvent S-607 100/1 202-415 1” Solvent x Solvent S-607 100/1 202-416 1-1/4” Solvent x Solvent S-607 100/1 202-417 1-1/2” Solvent x Solvent S-607 48/1 202-418 2” Solvent x Solvent S-607 24/1

PLASTIC LOW PRESSURE VALVES

Plastic Low Pressure Valve

125 CWP Naturally lead free

S-615

S-617

S-619

S-621

CPVC Stop Valves

202-503 1/2” Solvent x Solvent S-615 108/12

202-504 3/4” Solvent x Solvent S-615 108/12

CPVC Stop & Waste Valves

202-513 1/2” Solvent x Solvent S-617 108/12

202-514 3/4” Solvent x Solvent S-617 108/12

CPVC Boiler Drains

202-523 1/2” Solvent x Solvent S-619 108/12

202-524 3/4” Solvent x Solvent S-619 108/12

PVC Stop Valves

202-533 1/2” Solvent x Solvent S-621 108/12

202-534 3/4” Solvent x Solvent S-621 108/12

PVC Stop & Waste Valves

202-535 1/2” Solvent x Solvent S-622 108/12

202-536 3/4” Solvent x Solvent S-622 108/12

T-623

S-622

Celcon

Stop Valves

202-543 1/2” FNPT x FNPT T-623 108/12

202-544 3/4” FNPT x FNPT T-623 108/12

PLASTIC LOW PRESSURE VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

THERMOPLASTIC VALVES

Plastic Low Pressure Valve

125 CWP

Naturally lead free

T-624

Celcon® Stop & Waste Valves

202-545 1/2” FNPT x FNPT T-624 108/12

202-546 3/4” FNPT x FNPT T-624 108/12

Celcon® Boiler Drain Valves

202-553 1/2” MNPT T-625 108/12

202-554 3/4” MNPT T-625 108/12

PVC & CPVC UNIONS

Thermoplastic Union

ISO 9002, 150 psi @ 73°F NSF Listed Naturally lead free

T-625

T-627

PVC Schedule 80 Union

T-628

T-626

Celcon® Boiler Drain Valves

202-555 1/2” FNPT T-626 108/12

202-556 3/4” FNPT T-626 108/12

Celcon® Hose Bibbs

202-563 1/2” MNPT T-627 108/12

202-564 3/4” MNPT T-627 108/12

Celcon® Sillcocks

202-573 1/2” FNPT T-628 108/12

202-574 3/4” FNPT T-628 108/12

Celcon® is a registered trademark of the Celanese Corp.

PVC Schedule 80 Unions

204-173 1/2” Solvent x Solvent 288/36

204-174 3/4” Solvent x Solvent 144/24

204-175 1” Solvent x Solvent 96/12

204-176 1-1/4” Solvent x Solvent 96/12

204-177 1-1/2” Solvent x Solvent 64/8

204-178 2” Solvent x Solvent 48/4

204-180 3” Solvent x Solvent 2/1

ISO 9002, 150 psi @ 73°F Naturally lead free

PVC Schedule 40 Union

ISO 9002, 150 psi @ 73°F NSF Listed

CPVC Union

PVC Schedule 40 Unions

204-193 1/2” Solvent x Solvent 288/36

204-194 3/4” Solvent x Solvent 144/24

204-195 1” Solvent x Solvent 96/12

204-196 1-1/4” Solvent x Solvent 96/12

204-197 1-1/2” Solvent x Solvent 64/8

204-198 2” Solvent x Solvent 48/4

CPVC Union

204-133 1/2” Solvent x Solvent 288/36

204-134 3/4” Solvent x Solvent 288/36

PVC & CPVC UNIONS

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

THERMOPLASTIC VALVES

Thermoplastic Adapter

150 psi @ 73°F Naturally lead free

PVC Male Adapter

PVC Male Adapters

204-214 3/4" MNPT 18/1

204-216 1" MNPT 25/1

150 psi @ 73°F

PVC Spigot Adapters

204-234 3/4" Spigot 18/1

204-235 1" Spigot 18/1

PVC Spigot Adapter

Did you know? Legend allows you to return non-obsolete materials without a restocking charge.

CAST IRON VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

CAST IRON VALVES

OS & Y Gate Valve

200 CWP, 125 WSP, Class 125 IBBM design Meets MSS SP-70

Non-Rising Stem Gate Valve

200 CWP, 125 WSP, Class 125 IBBM design Meets MSS SP-70

T-303

T-301

116-121 2” Flanged T-303 1/1

116-122 2-1/2” Flanged T-303 1/1

116-123 3” Flanged T-303 1/1

116-124 4” Flanged T-303 1/1

116-125 5” Flanged T-303 1/1

116-126 6” Flanged T-303 1/1

116-127 8” Flanged T-303 1/1

116-128 10” Flanged T-303 1/1

116-129 12” Flanged T-303 1/1

116-101 2” Flanged T-301 1/1

116-102 2-1/2” Flanged T-301 1/1

116-103 3” Flanged T-301 1/1

116-104 4” Flanged T-301 1/1

116-105 5” Flanged T-301 1/1

116-106 6” Flanged T-301 1/1

116-107 8” Flanged T-301 1/1

116-108 10” Flanged T-301 1/1

116-109 12” Flanged T-301 1/1

Swing Check Valve

200 CWP, 125 WSP, Class 125 IBBM design Meets MSS SP-71

Flanged Cast Iron Y- Strainer

200 CWP, 125 WSP, Class 125

Closure plug included

T-19

T-311

304 Stainless Steel 1/16” Perforated Strainer

116-201 2” Flanged T-311 1/1

116-202 2-1/2” Flanged T-311 1/1

116-203 3” Flanged T-311 1/1

116-204 4” Flanged T-311 1/1

116-205 5” Flanged T-311 1/1

116-206 6” Flanged T-311 1/1

116-207 8” Flanged T-311 1/1

304 Stainless Steel 1/16” Perforated Strainer

105-611 2” Flanged T-19 1/1

105-612 2-1/2” Flanged T-19 1/1

105-613 3” Flanged T-19 1/1

105-614 4” Flanged T-19 1/1

304 Stainless Steel 1/8” Perforated Strainer

105-615 5” Flanged T-19 1/1

105-616 6” Flanged T-19 1/1

105-617 8” Flanged T-19 1/1

Cast & ductile iron valves full freight allowance is $2500 net

DUCTILE IRON WAFER CHECK VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

CAST IRON VALVES

Wafer Check Valve Bronze Disc

200 CWP, 200°F max temp

Ductile iron body Twin disc silent check valve Aluminum bronze disc, EPDM seat, Spring actuated ANSI B16.1, API 594

T-312

Wafer Check Valve, Stainless Steel Disc

200 CWP, 200°F max temp

Ductile iron body Twin disc silent check valve Stainless steel bronze disc, EPDM seat, Spring actuated ANSI B16.1, API 594

T-312 Stainless

Steel Disc

116-221 2” Wafer T-312 1/1

116-222 2-1/2” Wafer T-312 1/1

116-223 3” Wafer T-312 1/1

116-224 4” Wafer T-312 1/1

116-225 5” Wafer T-312 1/1

116-226 6” Wafer T-312 1/1

116-227 8” Wafer T-312 1/1

116-228 10” Wafer T-312 1/1

116-229 12” Wafer T-312 1/1

116-231 2" Wafer T-312 SS Disc 18/1

116-232 2-1/2" Wafer T-312 SS Disc 12/1

116-233 3" Wafer T-312 SS Disc 6/1

116-234 4" Wafer T-312 SS Disc 4/1

116-235 5" Wafer T-312 SS Disc 1/1

116-236 6" Wafer T-312 SS Disc 1/1

116-237 8" Wafer T-312 SS Disc 1/1

116-238 10" Wafer T-312 SS Disc 1/1

116-239 12" Wafer T-312 SS Disc 1/1

Wafer Check Valve, Ductile Iron Disc

200 CWP, 200°F max temp

Ductile iron body Twin disc silent check valve Ductile iron bronze disc, EPDM seat, Spring actuated ANSI B16.1, API 594

116-241 2" Wafer T-312 Ductile Iron 18/1

116-242 2-1/2" Wafer T-312 Ductile Iron 12/1

116-243 3" Wafer T-312 Ductile Iron 6/1

116-244 4" Wafer T-312 Ductile Iron 4/1

116-245 5" Wafer T-312 Ductile Iron 1/1

116-246 6" Wafer T-312 Ductile Iron 1/1

116-247 8" Wafer T-312 Ductile Iron 1/1

116-248 10" Wafer T-312 Ductile Iron 1/1

T-312 Ductile Iron Disc

116-249 12" Wafer T-312 Ductile Iron 1/1

DUCTILE IRON BUTTERFLY VALVES

Wafer Type Aluminum Bronze Disc

EPDM Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & aluminum bronze disc

416 SS Stem

T-335AB

Lever Handle - 10 Position

116-401 2” Wafer T-335AB 1/1

116-402 2-1/2” Wafer T-335AB 1/1

116-403 3” Wafer T-335AB 1/1

116-404 4” Wafer T-335AB 1/1

116-405 5” Wafer T-335AB 1/1

116-406 6” Wafer T-335AB 1/1

116-407 8” Wafer T-335AB 1/1

116-408 10” Wafer T-335AB 1/1

116-409 12” Wafer T-335AB 1/1

Cast & ductile iron valves full freight allowance is $2500 net

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

CAST IRON VALVES

DUCTILE IRON BUTTERFLY VALVES

Wafer Type Aluminum Bronze Disc

EPDM Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & aluminum bronze disc

416 SS Stem

T-335AB-G

Gear Operator

116-441 2” Wafer T-335AB-G 1/1

116-442 2-1/2” Wafer T-335AB-G 1/1

116-443 3” Wafer T-335AB-G 1/1

116-444 4” Wafer T-335AB-G 1/1

116-445 5” Wafer T-335AB-G 1/1

116-446 6” Wafer T-335AB-G 1/1

116-447 8” Wafer T-335AB-G 1/1

116-448 10” Wafer T-335AB-G 1/1

116-449 12” Wafer T-335AB-G 1/1

Buna-N-Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & aluminum bronze disc

416 SS Stem

Buna-N-Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & aluminum bronze disc

416 SS Stem

T-337AB

T-337AB-G

Lever Handle - 10 Position

116-421 2” Wafer T-337AB 1/1

116-422 2-1/2” Wafer T-337AB 1/1

116-423 3” Wafer T-337AB 1/1

116-424 4” Wafer T-337AB 1/1

116-425 5” Wafer T-337AB 1/1

116-426 6” Wafer T-337AB 1/1

116-427 8” Wafer T-337AB 1/1

116-428 10” Wafer T-337AB 1/1

116-429 12” Wafer T-337AB 1/1

Gear Operator

116-461 2” Wafer T-337AB-G 1/1

116-462 2-1/2” Wafer T-337AB-G 1/1

116-463 3” Wafer T-337AB-G 1/1

116-464 4” Wafer T-337AB-G 1/1

116-465 5” Wafer T-337AB-G 1/1

116-466 6” Wafer T-337AB-G 1/1

116-467 8” Wafer T-337AB-G 1/1

116-468 10” Wafer T-337AB-G 1/1

116-469 12” Wafer T-337AB-G 1/1

Cast & ductile iron valves full freight allowance is $2500 net

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

CAST IRON VALVES

DUCTILE IRON BUTTERFLY VALVES

Wafer Type Ductile Iron Disc

EPDM Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & ductile iron disc

416 SS Stem

T-335DI

Lever Handle - 10 Position

NEW

116-451 2" Wafer T-335DI - / -

NEW

116-452 2-1/2" Wafer T-335DI - / -

NEW

116-453 3" Wafer T-335DI - / -

NEW

116-454 4" Wafer T-335DI - / -

NEW

116-455 5" Wafer T-335DI - / -

NEW

116-456 6" Wafer T-335DI - / -

NEW

116-457 8" Wafer T-335DI - / -

NEW

116-458 10" Wafer T-335DI - / -

NEW

116-459 12" Wafer T-335DI - / -

EPDM Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & ductile iron disc

416 SS Stem

T-335DI-G

Buna-N-Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & ductile iron disc

416 SS Stem

T-337DI

Gear Operator

116-481 2" Wafer T-335DI-G - / -

NEW

116-482 2-1/2" Wafer T-335DI-G - / -

NEW

116-483 3" Wafer T-335DI-G - / -

NEW

116-484 4" Wafer T-335DI-G - / -

NEW

116-485 5" Wafer T-335DI-G - / -

NEW

116-486 6" Wafer T-335DI-G - / -

NEW

116-487 8" Wafer T-335DI-G - / -

NEW

116-488 10" Wafer T-335DI-G - / -

NEW

116-489 12" Wafer T-335DI-G - / -

Lever Handle - 10 Position

116-471 2" Wafer T-337DI - / -

NEW

116-472 2-1/2" Wafer T-337DI - / -

NEW

116-473 3" Wafer T-337DI - / -

NEW

116-474 4" Wafer T-337DI - / -

NEW

116-475 5" Wafer T-337DI - / -

NEW

116-476 6" Wafer T-337DI - / -

NEW

116-477 8" Wafer T-337DI - / -

NEW

116-478 10" Wafer T-337DI - / -

NEW

116-479 12" Wafer T-337DI - / -

Buna-N-Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & ductile iron disc

416 SS Stem

T-337DI-G

Gear Operator

NEW

116-491 2" Wafer T-337DI-G - / -

NEW

116-492 2-1/2" Wafer T-337DI-G - / -

116-493 3" Wafer T-337DI-G - / -

NEW

116-494 4" Wafer T-337DI-G - / -

NEW

116-495 5" Wafer T-337DI-G - / -

NEW

116-496 6" Wafer T-337DI-G - / -

NEW

116-497 8" Wafer T-337DI-G - / -

NEW

116-498 10" Wafer T-337DI-G - / -

NEW

116-499 12" Wafer T-337DI-G - / -

Cast & ductile iron valves full freight allowance is $2500 net

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

CAST IRON VALVES

DUCTILE IRON BUTTERFLY VALVES

Wafer Type Stainless Steel Disc

EPDM Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & 316 stainless steel disc

416 SS Stem

T-335SS

Lever Handle - 10 Position

116-411 2” Wafer T-335SS 1/1

116-412 2-1/2” Wafer T-335SS 1/1

116-413 3” Wafer T-335SS 1/1

116-414 4” Wafer T-335SS 1/1

116-415 5” Wafer T-335SS 1/1

116-416 6” Wafer T-335SS 1/1

116-417 8” Wafer T-335SS 1/1

116-418 10” Wafer T-335SS 1/1

116-419 12” Wafer T-335SS 1/1

Buna-N-Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & 316 stainless steel disc

416 SS Stem

Lug Type Aluminum Bronze Disc

EPDM Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & aluminum bronze disc

416 SS Stem

T-337SS

T-365AB

Lever Handle - 10 Position

116-431 2” Wafer T-337SS 1/1

116-432 2-1/2” Wafer T-337SS 1/1

116-433 3” Wafer T-337SS 1/1

116-434 4” Wafer T-337SS 1/1

116-435 5” Wafer T-337SS 1/1

116-436 6” Wafer T-337SS 1/1

116-437 8” Wafer T-337SS 1/1

116-438 10” Wafer T-337SS 1/1

116-439 12” Wafer T-337SS 1/1

Lever Handle - 10 Position

116-601 2” Lug T-365AB 1/1

116-602 2-1/2” Lug T-365AB 1/1

116-603 3” Lug T-365AB 1/1

116-604 4” Lug T-365AB 1/1

116-605 5” Lug T-365AB 1/1

116-606 6” Lug T-365AB 1/1

116-607 8” Lug T-365AB 1/1

116-608 10” Lug T-365AB 1/1

116-609 12” Lug T-365AB 1/1

EPDM Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & aluminum bronze disc

416 SS Stem

T-365AB-G

Gear Operator

116-641 2” Lug T-365AB-G 1/1

116-642 2-1/2” Lug T-365AB-G 1/1

116-643 3” Lug T-365AB-G 1/1

116-644 4” Lug T-365AB-G 1/1

116-645 5” Lug T-365AB-G 1/1

116-646 6” Lug T-365AB-G 1/1

116-647 8” Lug T-365AB-G 1/1

116-648 10” Lug T-365AB-G 1/1

116-649 12” Lug T-365AB-G 1/1

Cast & ductile iron valves full freight allowance is $2500 net

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

CAST IRON VALVES

DUCTILE IRON BUTTERFLY VALVES

Lug Type Aluminum Bronze Disc

Buna-N-Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & aluminum bronze disc

416 SS Stem

T-367AB

Lever Handle - 10 Position

116-621 2” Lug T-367AB 1/1

116-622 2-1/2” Lug T-367AB 1/1

116-623 3” Lug T-367AB 1/1

116-624 4” Lug T-367AB 1/1

116-625 5” Lug T-367AB 1/1

116-626 6” Lug T-367AB 1/1

116-627 8” Lug T-367AB 1/1

116-628 10” Lug T-367AB 1/1

116-629 12” Lug T-367AB 1/1

Buna-N-Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & aluminum bronze disc

416 SS Stem

Gear Operator

116-661 2” Lug T-367AB-G 1/1

116-662 2-1/2” Lug T-367AB-G 1/1

116-663 3” Lug T-367AB-G 1/1

116-664 4” Lug T-367AB-G 1/1

116-665 5” Lug T-367AB-G 1/1

116-666 6” Lug T-367AB-G 1/1

T-367AB-G

116-667 8” Lug T-367AB-G 1/1

116-668 10” Lug T-367AB-G 1/1

116-669 12” Lug T-367AB-G 1/1

Lug Type Ductile Iron Disc

EPDM Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & ductile iron disc

416 SS Stem

T-365DI

Lever Handle - 10 Position

116-651 2" Lug T-365DI 1/1

NEW

116-652 2-1/2" Lug T-365DI 1/1

NEW

116-653 3" Lug T-365DI 1/1

NEW

116-654 4" Lug T-365DI 1/1

NEW

116-655 5" Lug T-365DI 1/1

NEW

116-656 6" Lug T-365DI 1/1

NEW

116-657 8" Lug T-365DI 1/1

NEW

116-658 10" Lug T-365DI 1/1

NEW

116-659 12" Lug T-365DI 1/1

EPDM Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & ductile iron disc

416 SS Stem

T-365DI-G

Gear Operator

116-681 2" Lug T-365DI-G 1/1

NEW

116-682 2-1/2" Lug T-365DI-G 1/1

NEW

116-683 3" Lug T-365DI-G 1/1

NEW

116-684 4" Lug T-365DI-G 1/1

NEW

116-685 5" Lug T-365DI-G 1/1

NEW

116-686 6" Lug T-365DI-G 1/1

NEW

116-687 8" Lug T-365DI-G 1/1

NEW

116-688 10" Lug T-365DI-G 1/1

NEW

116-689 12" Lug T-365DI-G 1/1

Cast & ductile iron valves full freight allowance is $2500 net

DUCTILE IRON BUTTERFLY VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

No lead brass and bronze alloy items are highlighted in gray.

CAST IRON VALVES

Lug Type Ductile Iron Disc

Buna-N-Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & ductile iron disc

416 SS Stem

T-367DI

Lever Handle - 10 Position

116-671 2" Lug T-367DI 1/1

NEW

116-672 2-1/2" Lug T-367DI 1/1

NEW

116-673 3" Lug T-367DI 1/1

NEW

116-674 4" Lug T-367DI 1/1

NEW

116-675 5" Lug T-367DI 1/1

NEW

116-676 6" Lug T-367DI 1/1

NEW

116-677 8" Lug T-367DI 1/1

NEW

116-678 10" Lug T-367DI 1/1

NEW

116-679 12" Lug T-367DI 1/1

Buna-N-Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & ductile iron disc

416 SS Stem

Lug Type Stainless Steel Disc

EPDM Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & 316 stainless steel disc

416 SS Stem

T-367DI-G

T-365SS

Gear Operator

NEW

116-691 2" Lug T-367DI-G 1/1

NEW

116-692 2-1/2" Lug T-367DI-G 1/1

NEW

116-693 3" Lug T-367DI-G 1/1

NEW

116-694 4" Lug T-367DI-G 1/1

NEW

116-695 5" Lug T-367DI-G 1/1

NEW

116-696 6" Lug T-367DI-G 1/1

NEW

116-697 8" Lug T-367DI-G 1/1

NEW

116-698 10" Lug T-367DI-G 1/1

NEW

116-699 12" Lug T-367DI-G 1/1

Lever Handle - 10 Position

116-611 2” Lug T-365SS 1/1

116-612 2-1/2” Lug T-365SS 1/1

116-613 3” Lug T-365SS 1/1

116-614 4” Lug T-365SS 1/1

116-615 5” Lug T-365SS 1/1

116-616 6” Lug T-365SS 1/1

116-617 8” Lug T-365SS 1/1

116-618 10” Lug T-365SS 1/1

116-619 12” Lug T-365SS 1/1

Buna-N-Seat

ISO 9002, 200 CWP, 125 WSP Meets API 609, EN 593, MSS SP-67, & AWWA C504

Ductile iron body & 316 stainless steel disc

416 SS Stem

T-367SS

Lever Handle - 10 Position

116-631 2” Lug T-367SS 1/1

116-632 2-1/2” Lug T-367SS 1/1

116-633 3” Lug T-367SS 1/1

116-634 4” Lug T-367SS 1/1

116-635 5” Lug T-367SS 1/1

116-636 6” Lug T-367SS 1/1

116-637 8” Lug T-367SS 1/1

116-638 10” Lug T-367SS 1/1

116-639 12” Lug T-367SS 1/1

Cast & ductile iron valves full freight allowance is $2500 net

DUCTILE IRON BUTTERFLY VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

CAST IRON VALVES

Gear Operator with Handle

Gear operator only

Gear operator with

handwheel

Includes Handwheel

116-381 Fits 2”- 3” Gear 1/1

116-382 Fits 4” Gear 1/1

116-383 Fits 5”- 6” Gear 1/1

116-384 Fits 8” Gear 1/1

116-385 Fits 10”-12” Gear 1/1

Cast & ductile iron valves full freight allowance is $2500 net

Did you know? Legend ships every order within 24 hours guaranteed or you will receive 5% off of the order.

We've got your back. Jeff, Joe, David & Jerry

No lead brass and bronze alloy items are highlighted in gray.

BACKFLOW VALVES

Backﬂow Preventer

Backow preventers, atmospheric vent

ISO 9002, 175 psi @ 210°F ASSE 1012, CSA B64.3

T-459

Dual Check Backﬂow Preventer

ISO 9002, 150 psi @ 180°F ASSE 1024, CSA B64.6 ANSI/NSF 61-G (T-457NL) Min operating pressure 10 psi

Vacuum Breaker

ISO 9002, 125 CWP Max temp 180°F ASSE 1011, CSA B64.2 ANSI/NSF 372 (NL Only)

T-457

T-553

Part No. Size Conﬁguration Model No. Cs/Ct

115-113 1/2” FNPT x FNPT T-459

115-114 3/4” FNPT x FNPT T-459

115-117 1/2” Sweat x Sweat S-459

115-118 3/4” Sweat x Sweat S-459

115-103 1/2” FNPT x FNPT T-457

115-103NL 1/2” FNPT x FNPT T-457NL

115-104 3/4” FNPT x FNPT T-457

115-104NL 3/4” FNPT x FNPT T-457NL

115-105 1” FNPT x FNPT T-457

115-105NL 1” FNPT x FNPT T-457NL

107-194 3/4” FGHT x MGHT T-553

107-194NL 3/4” FGHT x MGHT T-553NL

107-195 3/4” FGHT x MGHT T-553C

107-195NL 3/4” FGHT x MGHT T-553CNL

25/1

200/20

T-554

Self Draining Vacuum Breaker

SPECIALTY PRODUCTS

ISO 9002, 125 CWP Max temp 180°F ASSE 1011, CSA B64.2.2 ANSI B1.20.7

T-557C

LOG LIGHTER VALVES

Log Lighter Valve

Forged brass

ISO 9002, CSA Certied

ANSI Z21.15 (1/2 lb. system) Chrome-plated brass escutcheon *PB indicates polished brass escutcheon All log lighter valves are boxed individually with key

T-557

Manual Drain

107-196 3/4” FGHT x MGHT T-554

107-193 3/4” FGHT x MGHT T-557

107-199 3/4” FGHT x MGHT T-557C

400/20

1000/10

Straight Pattern, 1/4 Turn Ball-Type (125 psi max air pressure, non-shock)

102-863 1/2” FNPT x FNPT T-3500 25/1

102-864 1/2” FNPT x FNPT T-3500PB* 25/1

Angle Pattern, 1/4 Turn Ball-Type (125 psi max air pressure, non-shock)

102-873 1/2” FNPT x FNPT T-3501 25/1

102-874 1/2” FNPT x FNPT T-3501PB* 25/1

T-3500

T-3501

LOG LIGHTER VALVES

Part No. Size Conﬁguration Model No. Cs/Ct

SPECIALTY PRODUCTS

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

Log Lighter Valve

Forged brass

ISO 9002, CSA Certied

ANSI Z21.15 (1/2 lb. system) Chrome-plated brass escutcheon *PB indicates polished brass escutcheon All log lighter valves are boxed individually with key

Straight Pattern, Multi-Turn Globe-Type (100 psi max air pressure, non-shock)

102-803 1/2” FNPT x FNPT T-3200 25/1

102-804 1/2” FNPT x FNPT T-3200PB* 25/1

Angle Pattern, Multi-Turn Globe-Type (100 psi max air pressure, non-shock)

102-813 1/2” FNPT x FNPT T-3201 25/1

102-814 1/2” FNPT x FNPT T-3201PB* 25/1

T-3200

T-3201

Accessories

102-820 Chrome Escutcheon 100/1

102-821 Polished Brass Escutcheon 1/1

102-840 1/4 Turn Chrome Escutcheon 1/1

102-841 1/4 Turn Polished Brass Escutcheon 1/1

Chrome Escutcheon

Chrome Key

102-850 Chrome Key 400/50

102-851 Polished Brass Key 400/50

102-823 5/16” - 8” Chrome Key 160/1

102-824 8” Chrome Key 160/1

12" Chrome Key

102-825 8” Polished Brass Key 160/1

102-827 10” Polished Brass key 100/25

102-852 12” Chrome Key 120/60

102-853 12” Polished Brass Key 120/60

Natural Gas Burner Bar

Not for use with LP gas

T-Style with Ash Protector Ledge

102-830 1/2" FNPT T-3205 Call for quote 20/1

T-3205

Log Lighter Kit

CSA Certied

ANSI Z21.15 (1/2 lb. system) Not for use with LP gas

T-3200

With Chrome Straight Pattern Globe Valve

102-833 1/2” FNPT x FNPT T-3200 1/1

With Polished Brass Straight Pattern Globe Valve

102-834 1/2” FNPT x FNPT T-3200PB 1/1

With Chrome Angle Pattern Globe Valve

102-843 1/2” FNPT x FNPT T-3201 1/1

With Polished Brass Angle Pattern Globe Valve

102-844 1/2” FNPT x FNPT T-3201PB 1/1

With Chrome Straight Pattern Ball Valve

102-883 1/2” FNPT x FNPT T-3500 1/1

With Polished Brass Straight Pattern Ball Valve

102-884 1/2” FNPT x FNPT T-3500PB 1/1

With Chrome Angle Pattern Ball Valve

102-893 1/2” FNPT x FNPT T-3501 1/1

With Polished Brass Angle Pattern Ball Valve

102-894 1/2” FNPT x FNPT T-3501PB 1/1

No lead brass and bronze alloy items are highlighted in gray.

METER VALVES

Bronze Angle Meter Valve

ISO 9002, 125 CWP ANSI/NSF 61-G

Part No. Size Conﬁguration Model No. Cs/Ct

111-103NL 3/4” x 1/2” Flare x FNPT T-441NL 48/8

111-104NL 3/4” x 3/4” Flare x FNPT T-441NL 48/8

111-105NL 1” x 3/4” Flare x FNPT T-441NL 36/6

111-106NL 1” x 1” Flare x FNPT T-441NL 24/4

T-442NL

1/4 Turn Meter Angle Ball Valve

ISO 9002, 400 CWP ANSI B1.20.1, NSF 61-G AWWA C800

T-443NL

WASHING MACHINE VALVES

Washing Machine Valve

150 CWP ANSI/NSF 372 (NL only) Max temp 180°F

SPECIALTY PRODUCTS

T-441NL

T-11

With Waste

111-113NL 3/4” x 1/2” Flare x FNPT T-442NL 48/8

111-114NL 3/4” x 3/4” Flare x FNPT T-442NL 48/8

111-115NL 1” x 3/4” Flare x FNPT T-442NL 36/6

111-116NL 1” x 1” Flare x FNPT T-442NL 24/4

111-123NL 3/4” x 3/4” FNPT x Flare T-443NL 20/2

111-124NL 3/4” x 1” FNPT x Flare T-443NL 20/2

111-125NL 1” x 1” FNPT x Flare T-443NL 20/2

1/2" T-11 has combination 1/2" MNPT and 1/2" Sweat inlet connection

111-133 1/2”

111-133NL 1/2”

MNPT / Sweat x MGHT

T-11 40/1

T-11NL 40/1

111-134 1/2” Sweat x MGHT S-11 40/1

111-134NL 1/2” Sweat x MGHT S-11NL 40/1

S-11

T-12

DISHWASHER ELBOW

No Lead Dishwasher Elbow

ANSI/NSF 372

Elbow

111-136 T/S-11 Repair Kit 1/1

Satin Chrome Plated

111-137 5/8” OD x HOSE Comp x MGHT T-12 144/12

111-137NL 5/8” OD x HOSE Comp x MGHT T-12NL 144/12

302-210NL 3/8” x 3/4” OD x FGHT Elbow 100/10

PRESSURE RELIEF VALVE

Part No. Size Conﬁguration Model No. Cs/Ct

SPECIALTY PRODUCTS

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

Pressure Relief Valve

150 psi ISO 9002 ANSI/NSF 61

T-50NL

FLOAT VALVES

Bronze Float Valve

125 CWP

Factory Set @ 75 PSI (Adjustable 75 to 150)

111-302NL 1/2" MNPT x FNPT T-50NL PRV 120/10

111-304NL 3/4" MNPT x FNPT T-50NL PRV 120/10

Factory Set @ 100 PSI (Adjustable 75 to 150)

111-303NL 1/2" MNPT x FNPT T-50NL PRV 120/10

111-305NL 3/4" MNPT x FNPT T-50NL PRV 120/10

Male Inlet - Plain Outlet

111-222 3/8” (1/4" - 20) NPSH T-30 72/12

111-223 1/2” (1/4" - 20) NPSH T-30 72/12

111-224 3/4” (1/4" - 20) NPSH T-30 24/6

T-30

Female Inlet - Plain Outlet

111-235 1” (5/16" - 18) FNPT T-31 36/4

111-236 1-1/4” (3/8" - 16) FNPT T-31 20/2

111-237 1-1/2” (3/8" - 16) FNPT T-31 16/2

111-238 2” (3/8" - 16) FNPT T-31 16/2

T-31

Male Inlet - Male Outlet

111-243 1/2” (1/4" - 20) NPSH x MNPT T-32 72/12

111-244 3/4” (1/4" - 20) NPSH x MNPT T-32 48/6

T-32

Brass Float Rod

111-253 1/4”-20 x 10” Float Rod - / -

111-254 1/4”-20 x 12” Float Rod - / -

111-255 5/16”-18 x 12” Float Rod - / -

111-256 3/8”-16 x 12” Float Rod - / -

Float Rod

FLOAT

Float

Copper - Seamless

111-263 1/4”-20 x 5” Copper- Seamless - / -

111-264 1/4”-20 x 6” Copper- Seamless - / -

111-265 5/16”-18 x 7” Copper- Seamless - / -

Copper Float

111-266 3/8”-16 x 8” Copper- Seamless - / -

Plastic Float

Plastic - Polystyrene

111-273 1/4”-20 x 5”

111-274 1/4”-20 x 6”

111-275 5/16”-18 x 7”

111-276 3/8”-16 x 8”

Plastic - Polystyrene

- / -

No lead brass and bronze alloy items are highlighted in gray.

EVAPORATIVE COOLER VALVES

Evaporative Cooler Valve

125 CWP ANSI/NSF 61-G (T-542NL only)

Part No. Size Conﬁguration Model No. Cs/Ct

107-247 3/4” FGHT x MGHT T-542 144/12

107-247NL 3/4” FGHT x MGHT T-542NL 144/12

Standard Pattern

111-247 1/4” Compression T-34 80/10

T-542

T-34

ANTI-SWEAT VALVES

Anti-Sweat Valves for Toilet Tank

180°F max service temp 125 CWP

T-20A

DIELECTRIC FITTINGS

Dielectric Nipple

425 psi @ 225°F max temp

SPECIALTY PRODUCTS

10 WSP Long pattern Naturally lead free ASTM F 1545-2009 ANSI B1.20.1 ISO 9002

T-35

T-20

T-575

Compact Pattern

111-248 1/4” Compression T-35 20/1

Factory Set @ 30% Hot / 70% Cold Mix

111-152 1/2” MNPT / Comp T-20 100/1

Manually Adjustable from 30% hot to 0% (100% cold)

111-154 1/2” MNPT / Comp T-20A 100/1

Compression Nuts & Ferrules - Set of Three

111-158 1/2” Compression 1/1

301-502 1/2” x 3” MNPT x MNPT T-575 300/50

301-503 3/4” x 3” MNPT x MNPT T-575 200/50

301-504 1” x 4” MNPT x MNPT T-575 120/20

301-505 1-1/4” x 4” MNPT x MNPT T-575 80/10

301-506 1-1/2” x 4” MNPT x MNPT T-575 60/10

301-507 2” x 4” MNPT x MNPT T-575 40/5

Dielectric Coupling

125 CWP, 180°F max. temp

T-578

301-533 1/2" FNPT x FNPT T-578 144/12

301-534 3/4" FNPT x FNPT T-578 144/12

301-535 1" FNPT x FNPT T-578 144/12

301-536 1-1/4" FNPT x FNPT T-578 48/6

301-537 1-1/2" FNPT x FNPT T-578 48/6

301-538 2" FNPT x FNPT T-578 48/6

DIELECTRIC FITTINGS

Part No. Size Conﬁguration Model No. Cs/Ct

SPECIALTY PRODUCTS

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

Forged Steel Dielectric Union

200 CWP, 180°F max temp NSF 372 (T-571NL) ISO 9002

2-1/2”, 3” & 4” are anged

T-571NL

2½", 3" & 4"

T-571M x SNL

T-571NL 1/2" - 2"

Grommet

301-103NL 1/2” FNPT x Sweat T-571NL 144/12

301-104NL 3/4” FNPT x Sweat T-571NL 144/12

301-123NL 3/4” x 1/2" FNPT x Sweat T-571NL 144/12

301-105NL 1” FNPT x Sweat T-571NL 120/12

301-125NL 1” x 3/4" FNPT x Sweat T-571NL 120/12

301-106NL 1-1/4” FNPT x Sweat T-571NL 48/6

301-107NL 1-1/2” FNPT x Sweat T-571NL 48/6

301-108NL 2” FNPT x Sweat T-571NL 24/6

301-119NL 2-1/2” FNPT x Sweat T-571NL 4/1

301-120NL 3" FNPT x Sweat T-571NL 3/1

301-121NL 4" FNPT x Sweat T-571NL 2/1

301-421 For 4" T-571NL Grommet - / -

301-203NL 1/2” MNPT x Sweat T-571M x SNL 144/12

301-204NL 3/4” MNPT x Sweat T-571M x SNL 144/12

301-205NL 3/4” x 1/2" MNPT x Sweat T-571M x SNL 144/12

Galvanized x Galvanized Dielectric Union

200 CWP, 180°F max temp ISO 9002

301-303 1/2” FNPT x FNPT T-572 144/12

301-304 3/4” FNPT x FNPT T-572 120/12

301-305 1” FNPT x FNPT T-572 48/6

301-306 1-1/4” FNPT x FNPT T-572 48/6

T-572

FNPT x FNPT

301-307 1-1/2” FNPT x FNPT T-572 24/6

301-308 2” FNPT x FNPT T-572 20/2

Galvanized x Brass Dielectric Union

200 CWP, 180°F max temp NSF 372 ISO 9002

301-323NL 1/2” FNPT x FNPT T-573NL 144/12

301-324NL 3/4” FNPT x FNPT T-573NL 120/12

301-325NL 1” FNPT x FNPT T-573NL 48/6

T-573NL

FNPT x FNPT

Black Gas Service Dielectric Union

200 CWP, 180°F max temp ISO 9002

301-333 1/2” FNPT x FNPT T-574 144/12

301-334 3/4” FNPT x FNPT T-574 120/12

301-335 1” FNPT x FNPT T-574 48/6

301-336 1-1/4” FNPT x FNPT T-574 48/6

T-574

FNPT x FNPT

301-337 1-1/2” FNPT x FNPT T-574 24/6

301-338 2” FNPT x FNPT T-574 20/2

No lead brass and bronze alloy items are highlighted in gray.

DIELECTRIC FITTINGS

Rubber Gasket

Max temp 180°F Fits models T-571, T-572 & T-573 T-572 & T-573 requires one size larger

Rubber Gasket

Gaskets & Inserts For Steam

Max temp 275°F continuous 300°F intermittent Fits models T-571, (T-572 & T-573 requires one size larger)

Steam Gasket

Part No. Size Conﬁguration Model No. Cs/Ct

301-403 1/2” Rubber Gasket - / -

301-404 3/4” Rubber Gasket - / -

301-405 1” Rubber Gasket - / -

301-406 1-1/4” Rubber Gasket - / -

301-407 1-1/2” Rubber Gasket - / -

301-408 2” Rubber Gasket - / -

301-409 2-1/2” Rubber Gasket - / -

301-410 3” Rubber Gasket - / -

301-411 4” Rubber Gasket - / -

Steam Gaskets

301-433 1/2” Steam Gasket - / -

301-434 3/4” Steam Gasket - / -

301-435 1” Steam Gasket - / -

301-436 1-1/4” Steam Gasket - / -

301-437 1-1/2” Steam Gasket - / -

301-438 2” Steam Gasket - / -

301-439 2-1/2” Steam Gasket - / -

301-440 3” Steam Gasket - / -

301-441 4” Steam Gasket - / -

SPECIALTY PRODUCTS

Steam ABS Insert

COMPRESSION REPAIR COUPLINGS

Galvanized Compression Coupling

125 CWP max temp 210ºF Long pattern

Galvanized

Compression Coupling

Steam ABS Inserts

301-443 1/2” Steam ABS Insert - / -

301-444 3/4” Steam ABS Insert - / -

301-445 1” Steam ABS Insert - / -

301-446 1-1/4” Steam ABS Insert - / -

301-447 1-1/2” Steam ABS Insert - / -

301-448 2” Steam ABS Insert - / -

301-449 2-1/2” Steam ABS Insert - / -

301-450 3” Steam ABS Insert - / -

303-103 1/2”

303-104 3/4”

303-105 1”

303-106 1-1/4”

303-107 1-1/2”

303-108 2”

Comp (IPS) x Comp (IPS)

48/24

24/12

16/8

COMPRESSION REPAIR COUPLINGS

Part No. Size Conﬁguration Model No. Cs/Ct

SPECIALTY PRODUCTS

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

Brass Compression Coupling

125 CWP max temp 180ºF ANSI/NSF 61-G (NL only) Long pattern

Brass

Compression Coupling

303-123 3/8” x 1/2”

303-123NL 3/8” x 1/2”

303-124 1/2” x 3/4”

303-124NL 1/2” x 3/4”

303-125 3/4” x 1”

303-125NL 3/4” x 1”

303-126 1” x 1-1/4”

303-126NL 1” x 1-1/4”

303-127 1-1/4” x 1-1/2”

303-127NL 1-1/4” x 1-1/2”

Comp (IPS) x Comp (CTS)

288/24

24/1

120/12

48/12

303-128 1-1/2”

303-128NL 1-1/2”

303-129 2”

303-129NL 2”

PVC Compression Coupling

Naturally lead free ISO 9002, 150 CWP @ 73°F Long pattern

204-103 1/2”

204-104 3/4”

204-105 1”

204-106 1-1/4”

204-107 1-1/2”

204-108 2”

PVC Coupling

204-109 2-1/2”

204-110 3”

204-111 4”

204-112 6”

CPVC Compression Coupling

Naturally lead free ISO 9002 150 CWP @ 73° ANSI/NSF 61-G listed

Long Pattern

204-123 1/2” Comp x Comp 360/20

204-124 3/4” Comp x Comp 240/20

Comp (IPS) x Comp (IPS)

Comp (CTS) x Comp (CTS)

Comp (IPS) x Comp (IPS)

36/12

100/1

90/1

60/1

40/1

30/1

20/1

10/1

4/1

2/1

6/1

CPVC Coupling

PVC Expansion Repair Coupling

150 CWP @ 73°F Naturally lead free

PVC Expansion

Coupling

204-143 1/2” Spigot x Socket Expansion Coupling 148/37

204-144 3/4” Spigot x Socket Expansion Coupling 92/23

204-145 1” Spigot x Socket Expansion Coupling 48/12

204-146 1-1/4” Spigot x Socket Expansion Coupling 64/16

204-147 1-1/2” Spigot x Socket Expansion Coupling 64/16

204-148 2” Spigot x Socket Expansion Coupling 36/9

No lead brass and bronze alloy items are highlighted in gray.

CPVC TRANSITION FITTINGS

No Lead Brass PEX CPVC Transition Fitting

ANSI/NSF 61-G

Adapter

No Lead Brass CPVC Transition Fitting

100 CWP, max temp 180˚F

ANSI/NSF 61-G, ANSI/NSF 14 ISO 9002

Part No. Size Conﬁguration Model No. Cs/Ct

Adapters

302-423NL 1/2” PEX x CPVC Adapter 400/50

302-424NL 3/4” PEX x CPVC Adapter 300/50

302-425NL 1” PEX x CPVC Adapter 200/25

302-403NL 1/2” MNPT x CPVC

302-404NL 3/4” MNPT x CPVC

302-405NL 1” MNPT x CPVC

302-406NL 1-1/4” MNPT x CPVC

302-407NL 1-1/2” MNPT x CPVC

302-408NL 2” MNPT x CPVC

Transition Fittings

24/1

360/30

150/25

80/10

60/10

20/5

MNPT x CPVC

FNPT x CPVC

304 Stainless Steel CPVC Transition Fittings

100 CWP, max temp 180°F Naturally lead free ANSI/NSF 14

SPECIALTY PRODUCTS

ISO 9002

MNPT x CPVC

Transition Fitting

FNPT x CPVC

Transition Fitting

302-413NL 1/2” FNPT x CPVC

302-414NL 3/4” FNPT x CPVC

302-415NL 1” FNPT x CPVC

302-416NL 1-1/4” FNPT x CPVC

302-417NL 1-1/2” FNPT x CPVC

302-418NL 2” FNPT x CPVC

Transition Fittings

432/24

250/25

150/25

10/1

60/10

20/5

302-433 1/2” MNPT x CPVC Adapter 250/25

302-434 3/4” MNPT x CPVC Adapter 250/25

302-435 1” MNPT x CPVC Adapter 150/25

302-436 1-1/4” MNPT x CPVC Adapter 80/10

302-437 1-1/2” MNPT x CPVC Adapter 60/10

302-438 2” MNPT x CPVC Adapter 20/5

302-443 1/2” FNPT x CPVC Adapter 250/25

302-444 3/4” FNPT x CPVC Adapter 250/25

302-445 1” FNPT x CPVC Adapter 150/25

302-446 1-1/4” FNPT x CPVC Adapter 80/10

302-447 1-1/2” FNPT x CPVC Adapter 60/10

302-448 2” FNPT x CPVC Adapter 20/5

SPECIALTY BRASS FITTINGS

Part No. Size Conﬁguration Model No. Cs/Ct

SPECIALTY PRODUCTS

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

Raised Square Head Plug

Southern Code <10 psi (DWV) CWP

Raised Square Head Plug

Countersunk Plug

Southern Code <10 psi (DWV) CWP

Countersunk Plug

302-603 1-1/4” MNPT 500/100

302-604 1-1/2” MNPT 200/100

302-605 2” MNPT 200/100

302-606 2-1/2” MNPT 200/50

302-607 3” MNPT 160/20

302-608 3-1/2” MNPT 120/20

302-609 4” MNPT 90/15

302-610 5” MNPT 60/10

302-611 6” MNPT 40/10

302-624 1-1/2” MNPT 400/100

302-625 2” MNPT 200/100

302-626 2-1/2” MNPT 200/50

302-627 3” MNPT 160/20

302-628 3-1/2” MNPT 160/20

302-629 4” MNPT 60/10

302-630 5” MNPT 60/10

302-635 5-1/2” MNPT 20/10

302-631 6” MNPT 40/10

302-632 8” MNPT 20/5

Brass Trap Connector

With chrome plated die cast nut MNPT end ID machined for copper sweat installation

Trap Connector

BRASS FIRE HOSE FITTINGS

Female x Male Brass Hydrant Adapter

Forged brass Female NYFD thread pattern Male garden hose

A-75

302-106 1-1/4” x 1-1/4” Slip x MNPT 180/20

302-107 1-1/4” x 1-1/2” Slip x MNPT 200/20

302-108 1-1/2” x 1-1/2” Slip x MNPT 200/20

302-116 1-1/4” x 1-1/4” Slip x FNPT 200/20

302-117 1-1/4” x 1-1/2” Slip x FNPT 200/20

302-118 1-1/2” x 1-1/2” Slip x FNPT 200/20

322-729 1-1/2” x 3/4” NST x MGHT A-75 100/1

322-731 2-1/2” x 3/4” NST x MGHT A-75 40/1

322-744 2-1/2” x 2” NST x NPSH A-75 40/1

322-750 3” x 2-1/2” NST x NST A-75 20/1

322-733 2-1/2” x 3/4” NST x MNPT A-75 40/1

322-734 2-1/2” x 1” NST x MNPT A-75 40/1

322-736 2-1/2” x 1-1/2” NST x MNPT A-75 40/1

322-740 2-1/2” x 2” NST x MNPT A-75 40/1

322-751 3” x 2-1/2” NPSH x NST A-75 20/1

322-730 2-1/2” x 3/4” NYFD x MGHT A-75 50/1

No lead brass and bronze alloy items are highlighted in gray.

BRASS FIRE HOSE FITTINGS

Double Male Hex Nipple

Forged brass

A-92

Female x Male Hex Nipple

Forged brass

A-93

Part No. Size Conﬁguration Model No. Cs/Ct

322-510 1” x 3/4” NPT x MGHT A-92 200/1

322-526 2” x 2” NPT x NPSH A-92 50/1

322-511 1” x 1” NPT x NST A-92 100/1

322-521 1-1/2” x 1-1/2” NPT x NST A-92 100/1

322-533 2” x 2-1/2” NPT x NST A-92 30/1

322-534 2-1/2” x 2-1/2” NPT x NST A-92 24/1

322-523 1-1/2” x 1-1/2” NST x NST A-92 100/1

322-602 1” x 3/4” NPT x MGHT A-93 200/1

322-611 1-1/2” x 1-1/2” NPT x NST A-93 200/1

322-634 2-1/2” x 2-1/2” NPT x NST A-93 20/1

322-644 1-1/2” x 1-1/2” NST x NPT A-93 100/1

322-653 2-1/2” x 2” NST x NPT A-93 20/20

322-664 2-1/2” x 2-1/2” NST x NPT A-93 30/1

322-612 1-1/2” x 1-1/2” NPT x NPSH A-93 100/1

322-614 1-1/2” x 1-1/2” NPSH x NPT A-93 100/1

322-615 1-1/2” x 1-1/2” NPSH x NST A-93 100/1

Female x Male Swivel Adapter

Forged brass All sizes with ball bearing swivel

SPECIALTY PRODUCTS

A-91

Caps & Plugs with Chain

Forged brass

A-80

A-81

GHT - Garden Hose Thread NH (NST) - National Hose Thread or National Standard Thread NPT - National Pipe Tapered Thread NPSH - National Pipe Straight Hose Thread

322-201 1-1/2” x 1-1/2” NST x NPT A-91 10/1

322-233 2-1/2” x 2” NST x NPT A-91 20/1

322-234 2-1/2” x 2-1/2” NST x NPT A-91 10/1

322-235 2-1/2” x 3” NST x NPT A-91 10/1

Caps (Female)

324-101 1-1/2” NST A-80 100/1

324-103 2-1/2” NST A-80 50/1

Plugs (Male)

324-123 2-1/2” NST A-81 50/1

We continually look for ways to improve

Effective Date: October 2018

Phone: 800-752-2082

www.legendvalve.com

quality and add value to our products.

GUARANTEED PERFORMANCE

•

CUSTOMER ASTONISHMENT

•

INNOV

ATION

•

ENGINEERING EXPERTISE•INTEGRITY

HYDRONICS

Legend has a comprehensive oering of radiant ooring products,

Legend has the most comprehensive offering of manifolds and mechanical room

heating tube, manifolds, and mechanical room components for

components for residential and commercial

residential and commercial hydronic systems. From the mechanical

hydronic systems. From the mechanical room

room to the radiant panel, Legend has feature rich products

to the radiant panel, Legend has feature

designed to deliver eciencies in both design and operation.

rich products designed to deliver efciencies

Backed by a team of engineers, Legend oers on-demand

in both design and operation. Backed by a

technical and design support to assist you with your project.

team of engineers Legend offers on-demand technical and design support to assist you with your project.

The innovative VersaTherm oor system is unlike any dry radiant system. The panels snap together in minutes saving signicant labor costs. Basement and 2nd oor retrots are easy because the panels are pre-insulated and naturally

RADIANT PANEL SYSTEM

water resistant. The use of 1/2” pipe allows for greater circuit lengths and is 100% protected by metal, unlike many other dry systems. Thus, the entire surface transfers heat, reducing temperature stratication common in some systems. The panels are only 3/4” thick, minimizing construction problems common in over-pour installations.

Key Features at a Glance

- Labor saving – snaps together

- 1/2” pipe – for longer circuit lengths

- Tubing is protected against damage

- Return Panels are pre-insulated – great for retrots and basements

- Naturally water resistant

- Entire surface transfers heat

- Return Panels are easily cut for tight installations

- Tube spacing is 8” on center

Material worksheet on page 150

VERSATHERM PANELS

Replacement tube shield

(VT-RTS)

Replacement return panel hardware

(VT-RPH)

Replacement return panel cover

(VT-RRC)

Return panel heat transfer plate

(VT-HTRP)

Return panel with cover & hardware

(VT-RP)

VersaTherm panel with two tubing shields (VT-MP)

Main Panel

Includes 2 tube shields

Return Panel

Includes return panel cover (VT-RRC) Return panel hardware (VT-RPH) (2) Return panel heat transfer plates (VT-HTRP)

Part No. Size Conﬁguration Model No. Qty. Case

VT-MP

VT-RP

31-1/2" x 15-3/4" x 3/4"

15-3/4” x 15-3/4” x 3/4”

Main Panel VersaTherm 1 10

Return Panel VersaTherm 1 20

Did you know? Legend guarantees our products for 5 years or the installing contractor will receive $25.00 back.

RADIANT PANEL SYSTEM

Effective Date: October 2018

Phone: 866-752-2055

www.legendvalve.com

VERSATHERM PARTS

Replacement Tube Shield

Used with main panel to protect tubing from damage

Replacement Return Panel Cover

Used with return panel to protect tubing from damage.

Replacement Return Panel Hardware

Includes 4 plastic snap rivets and 1 screw

Part No. Size Conﬁguration Model No. Qty. Case

VT-RTS 31-1/2" x 1-3/8" Replacement Tube

VersaTherm 1 3

Shield

VT-RRC 15-3/4" x 15-3/4" Repl Return Cover VersaTherm 1 -

Used to Fasten Return Panel Cover

VT-RPH Return Hardware VersaTherm 1 -

Return Panel Heat Transfer Plate - Pair

Optional plate increases heat output on return panel

Did you know? Legend has an engineering laboratory for product design and development.

VT-HTRP 7-3/4" x 2-7/8" Transfer Plate VersaTherm 2 -

QuickTherm panels reduce labor costs by making it easy to properly install radiant tubing. There is no need to tie, clip, or staple tubing to the substrate.

RADIANT PANEL SYSTEM

Key Features at a Glance

- One person can quickly put down the panels and install the tubing while walking upright.

- The tube is better protected than in a wire mesh install

- No bending or crawling

- Available in R-5 or R-10

- Eliminates stapling and cable ties

- 2’ x 4’ panels are more accommodating to uneven gravel base and subbase surfaces

- 1/2”, 5/8” or 3/4” radiant tubing can be used with QuickTherm

- QuickTherm panels can reduce installation time by up to 75%.

- QuickTherm panels can be drop shipped directly to the job site. Call for LTL or truck-load discount. Allow up to 3 weeks for delivery.

QUICKTHERM PANELS

(R5)

Interlocking

grooves

(R10)

Material worksheet on page 150

Eliminates stapling & cable

ties

QuickTherm Panels

Part No. Size Model No. Qty. Case

800-QT100R 1" thick (R-5), 2' x 4', 6” & 12” Tube Spacing

QT100R

800-QT100

800-QT200

QT200

TUBING INSTALLATION ACCESSORIES

Tube Holding Pins

Large diameter tube holder pins

Designed to be manually inserted into QuickTherm “knobs” to hold down large diameter tube (typ. 3/4”) in tough spots where additional support may be needed. Works on all sizes of tube and all models of QuickTherm.

(1/2" & 5/8" tubing only)

1" thick (R-5), 2' x 4', 6”, 9”, 12” Tube Spacing

2" thick (R-10), 2' x 4' 6”, 9”, 12” Tube Spacing

Residential Special order only

Call for quote

QuickTherm 1 18

QuickTherm 1 10

800-349 All tube sizes for

QT-100 & 200

Holding Pins 100 Bag

RADIANT PANEL SYSTEM

Effective Date: October 2018

Phone: 866-752-2055

www.legendvalve.com

TUBING INSTALLATION ACCESSORIES

Tube Holding Pins

Heavy duty tube holder pins

Part No. Size Conﬁguration Model No. Qty. Case

800-345

1-1/2" long for panels 1” or thicker

Holding Pins 100 Bag

Tube Bend Support

Tube bend support 90°

Tube Bend Support

Tube bend support 90°

800-348 2" long for panels

Holding Pins 100 Bag

1-1/2" or thicker

Holds tube in a tight radius 90° bend without a tting elbow and without fear of “kinking.” Slide support easily around 1/2” tube while straight, then make bend by clicking tabs together.

800-503 For 1/2" tubing Tube Support 1 -

Used to hold exible tubing in a 90˚ bend without a tting elbow and creates a neat, professional appearance.

800-305

800-304

Fits up to 1/2” tubing

Fits up to 3/4” tubing

Bend Support 1 -

Protection Sleeve

Tube protection sleeve

Heat Transfer Plate

Joist space

Used to protect tubing in a concrete slab at expansion joints. Pre-slit 12” lengths allow for rapid installation after tubing has been installed and before concrete pour.

800-313 12" long Fits 1/2" tubing Sleeve 1 -

800-314 12" long Fits 3/4" tubing Sleeve 1 -

Extruded Aluminum Heat Transfer Plates – For use in radiant oor heating via joist space applications (under sub-oor) with 3/8” or 1/2” PEX tubing. Plates are 3-1/2” x 4’ long and pre-drilled for wood screws to attach underneath sub-oor. PEX tubing is held securely in tube channel on under side of plate.

800-362 3-1/2" x 4' long Fits 3/8" tubing Transfer Plate 1 20

800-364 3-1/2" x 4' long Fits 1/2" tubing Transfer Plate 1 20

TUBING INSTALLATION ACCESSORIES

Tube Track

RADIANT PANEL SYSTEM

Part No. Size Conﬁguration Model No. Qty. Case

Tube Track & Tube Track Duo – Used to hold tubing to rigid foam, wood or concrete. Mounting holes are provided for appropriate fasteners. Clips at end of each piece allow 3-1/4’ (39”) sections to snap together. Use tube holding pins in rigid foam board installations.

Mounting Rail

Use tube holding pins (top) in rigid foam board installations

Tube Bend Support, Plastic

800-323 39” Length

800-324 39” Length

Tube track holding tabs for 3/8” or 1/2” tubing are spaced every 2”

Dual track holding tabs for 3/8” or 1/2” and for 5/8” or 3/4” tubing alternate every 4"

1 -

Tube Mounting Rail – Used to hold tubing to rigid foam, wood or concrete. Mounting holes are provided for appropriate fasteners. 6-1/2’ (78”) rails have prescored “break” lines should shorter lengths be needed. Holding slots are spaced every 2

”.

800-333 78” Length Fits 1/2" tubing 1 -

800-334 78” Length Fits 3/4" tubing 1 -

Bend support made from durable plastic with nail tab for securing to studs or joists when routing plastic tubing in plumbing installations. For 1/2", 3/4" and 1" tubing.

Tube Bend Support, Metal

509-003 1/2"

Plastic Bend Support

1 -

with Nail Tab

509-004 3/4"

Plastic Bend Support

1 -

with Nail Tab

509-005 1"

Plastic Bend Support

1 -

with Nail Tab

Metal bend support for 1/2", 3/4" and 1" exible plastic tubing.

509-013 1/2" Metal Bend Support 1 -

509-014 3/4" Metal Bend Support 1 -

509-023 1/2" Metal Bend Support

1 -

with Nail Flange

RADIANT PANEL SYSTEM

Effective Date: October 2018

Phone: 866-752-2055

www.legendvalve.com

TUBING INSTALLATION ACCESSORIES

Tube Repair Coupler

Part No. Size Conﬁguration Model No. Qty. Case

Tube Talon Fasteners

Tube Isolation Clamps

Repair Adapter for 5/16" to 3/4" Manifold Connectors for PEX Tubing

830-819 3/4" R20 x 3/4" R20 Connector

Note: See page 124 for required tubing connector

Repair Yellow Silicone Tape

830-820 1" x 12' Repair Tape

Plastic talon hook with nail included, secures tubing to wooden surfaces. Ideal for neatly routing and attaching exible plastic tubing to oor joists and wall studs. For CTS 1/2", 3/4" and 1". Sold in Bags of 100.

800-373 1/2" Tube Talon Per Bag -

800-374 3/4" Tube Talon Per Bag -

800-375 1" Tube Talon Per Bag -

Plastic tube fastener for isolating exible plastic tube as it passes through building oor joists and wall studs. Protects tubing from sharp or hard surfaces, ideal for plumbing and hydronic piping. Includes two pre-drilled screw holes, ts CTS 1/2", 3/4" and 1". Sold in Bags of 100.

- 50

1 -

Standard Tube Clamps

Did you know? The Legend technical staff has extensive academic and practical plumbing and heating expertise.

800-513 1/2" Tube Isolation Clamp Per Bag -

800-514 3/4" Tube Isolation Clamp Per Bag -

800-515

Plastic tube fastener for securing exible plastic tube to solid surfaces, oor joists and wall studs. Protects and keeps tubing straight when routing in plumbing and hydronic piping. Includes two pre-drilled screw holes, ts CTS 1/2", 3/4" and 1". Sold in Bags of 100.

800-523 1/2" Standard Tube Clamp Per Bag -

800-524 3/4" Standard Tube Clamp Per Bag -

800-525 1" Standard Tube Clamp Per Bag -

Tube Isolation Clamp Per Bag -

TUBING INSTALLATION ACCESSORIES

Clip Tube Holders

RADIANT PANEL SYSTEM

Part No. Size Conﬁguration Model No. Qty. Case

SnappRAIL™ Clip Holders can be attached to the surface individually with a screw or nail (not included); or attach several in a row to clip holder rail (800-500) with adapter (800-501). Clip holders can quickly and easily secure either exible tubing (PEX or PERT) or rigid copper tubing by pushing the tube into the mounted clip holder rail. Removal of the tubing, if necessary, is easy without damage to either the tubing or the clip holder.

SnappRAIL™ Clip Holders attach to clip holder rail with adapter (800-501). May also be fastened to joist or stud individually without rail.

800-352 3/8" Clip Tube Holder 1 -

800-353 1/2" Clip Tube Holder 1 -

800-351 5/8" Clip Tube Holder 1 -

800-354 3/4" Clip Tube Holder 1 -

800-355 1" Clip Tube Holder 1 -

800-356 1-1/4" Clip Tube Holder 1 -

Clip Holder Rail

Clip Holder Adapter

ST-100 Upright Staple Tool

SnappRAIL™ Clip Holder Rail.

800-500 (39.37") Clip Holder Rail 1 -

SnappRAIL™ Clip Holder Rail Adapter, holds clip tube holders.

800-501

Clip Holder Rail Adapter

1 -

Tube Installation Staple Tool - Upright hand staple tool for installing different sizes of tubing into EPS foam board. Long handle allows installer to easily staple down exible radiant tube to rigid foam insulation while walking upright.

800-340 Upright hand staple tool ST-100 1 1

800-340-34

800-340-40

800-340-55

Plastic staple for rigid foam (1-3/8" long) - holds up to 1/2" tube with min 1/2" thick board.

Plastic staple for rigid foam (1-1/2" long) - holds up to 5/8" tube with min 1" thick board.

Plastic staple for rigid foam (2-1/8" long) - holds up to 3/4" tube with min 2" thick board.

ST-100 30 -

ST-100 25 -

ST-100 30 -

Flex

Highly Flexible PEX heating tube with oxygen barrier.

Manufactured from a proprietary polymer formulation which dramatically increases exibility and maintains high strength. Available in 3/8”, 1/2”, 5/8”, 3/4” and 1” tube sizes. LegendFlex delivers greater performance and exibility than standard PEX. We are so condent in its performance, we back it with a 30 year warranty. LegendFlex is extremely exible and very difcult to kink. In the unlikely event one should occur, simply repair it with a heat gun. No need to cut and use a coupling or replace the tubing. LegendFlex tubing is also compatible with cold expansion type tting systems (compliant with standards ASTM F2080 & ASTM F 1960). Its strength, durability and thermal memory enables proper seal with crimp or expansion style connections.

Residential, commercial and industrial applications include:

- Radiant heating and cooling

- Snow & ice melt

- GeoThermal

- Turf conditioning

LEGENDFLEX TUBING

The externally extruded EVOH oxygen barrier reduces oxygen molecule permeation into the water. Compliant with standard DIN4756 (<0.1 grams/m³/day).

Heating Tube

Meets the requirements of ASTM F876 and F877

Part No. Size Qty. Case

850-125 3/8" x 500' PEX tubing with oxygen barrier, 20 lbs.

1 -

capacity 0.0051 gal./ft.

850-129 3/8" x 1000' PEX tubing with oxygen barrier, 40 lbs.

1 -

capacity 0.0051 gal./ft.

850-203 1/2" x 20' PEX tubing with oxygen barrier, 1 lbs.

1 25

capacity 0.0096 gal./ft.

850-133 1/2" x 300' PEX tubing with oxygen barrier, 15 lbs.

1 -

capacity 0.0096 gal./ft.

850-135 1/2" x 500' PEX tubing with oxygen barrier, 25 lbs.

1 -

capacity 0.0096 gal./ft.

850-139 1/2" x 1000' PEX tubing with oxygen barrier, 50 lbs.

1 -

capacity 0.0096 gal./ft.

850-140 1/2" x 1200' PEX tubing with oxygen barrier, 60 lbs.

capacity 0.0096 gal./ft

1 -

Heating Tube

Part No. Size Qty. Case

LEGENDFLEX TUBING

850-144 5/8" x 400' PEX tubing with oxygen barrier, 28 lbs.

capacity 0.0138 gal./ft.

850-149 5/8" x 1000' PEX tubing with oxygen barrier, 70 lbs.

capacity 0.0138 gal./ft.

850-204 3/4" x 20' PEX tubing with oxygen barrier, 2 lbs.

capacity 0.0189 gal./ft

850-151 3/4" x 100' PEX tubing with oxygen barrier, 10 lbs.

capacity 0.0189 gal./ft.

850-153 3/4" x 300' PEX tubing with oxygen barrier, 30 lbs.

capacity 0.0189 gal./ft.

850-155 3/4" x 500' PEX tubing with oxygen barrier, 50 lbs.

capacity 0.0189 gal./ft.

850-159 3/4" x 1000' PEX tubing with oxygen barrier, 100 lbs.

capacity 0.0189 gal./ft.

1 -

1 25

1 -

850-205 1" x 20' PEX tubing with oxygen barrier, 3.2 lbs.

capacity 0.0312 gal./ft.

850-161 1" x 100' PEX tubing with oxygen barrier, 16 lbs.

capacity 0.0312 gal./ft.

850-165 1" x 500' PEX tubing with oxygen barrier, 80 lbs.

capacity 0.0312 gal./ft.

Did you know? HyperPure® bimodal PE-RT tubing is manufactured by Legend in Michigan. (See page 152)

1 25

1 -

Effective Date: October 2018

Phone: 866-752-2055

www.legendvalve.com

You expect quality, we deliver it.

Integrated Adapter

M-8000

MODULAR

1” 800-857 1-1/4” 800-858

MANIFOLDS

Modular Mounting

Brackets & Collar

Supply End (pair)

1” 8000-10-ES 1-1/4” 8000-14-ES

Expansion 1-1/4”

(Supply & Return pair) 8000-14-XP

Return End (pair)

1” 8000-10-ER 1-1/4” 8000-14-ER

Balancing valves with memory stop. Optional angle isolation valves for tight installations. Can be mounted in any orientation. Available in 1” and 1-1/4” congurations

800-861

End Plug

1” 800-845 1-1/4” 800-846

Carry less inventory and build any conguration you need!

The M-8000 Modular™ manifold series guarantees you’ll always have the manifold you need when you need it. Precision-designed individual components can be easily customized to achieve any solution a project requires EPDM O-rings and CNC machining ensure a perfect seal, guaranteed.

The M-8000 system makes on-site customization, conguration

and installation a snap. By stocking a handful of interchangeable components, any manifold from 1” to 1-1/4”, from 2 to 14 ports, with

or without ll/purge valves can be built in minutes. Our modular system

allows you to carry less inventory, yet stock exactly what you need to get the job done, especially when requirements change on the job site. Many components are compatible with our M-8100, M-8200 and M-8220 manifolds – making the Legend manifold family the most

exible manifold system on the market.

Key Features at a Glance

- Perfect seal - guaranteed

- Easy to assemble - twist & turn

- Flexible circuit orientation - service loops above and below manifold

M-8000 MODULAR MANIFOLD SERIES KIT

M-8000 Kit

ISO 9002

M-8000A Kit

ISO 9002

Part No. Kit Qty.

M-8000 Modular Basic – Includes all required pieces to create basic 2-port 1” modular manifold.

8000-10-2 1" M-8000 Kit

8000-10-ES

1” Supply End- Pair 1

8000-10-ER 1” Return End - Pair 1

800-845 1” Manifold End Plug 2

800-855 1” Manifold Angle Isolation Valve - Pair 1

800-861 Modular Manifold Mounting Bracket & Collar - Pair 1

M-8000A Modular Angle – Includes all required pieces to create basic 2-port 1” modular manifold with angle isolation valve

8000A-10-2 1" M-8000A Kit

8000-10-ES 1” Supply End - Pair 1

8000-10-ER 1” Return End - Pair 1

800-845 1” Manifold End Plug 2

800-825 1” Manifold Angle Isolation Valve - Pair 1

800-861 Modular Manifold Mounting Bracket & Collar - Pair 1

Legend S-1001NL, T-602, TM-550, S-451NL, T-50 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
