Legacy Car Audio LSC7 User Manual

TFT-LCD MONITOR
OWNER S M ANUAL
7 INCH COLOUR LCD MONITOR
LSC7
-
MD
-
SEL
AV
TIME
AV
+
VOL
+
SEL
+
POWER
POWER
LSC7
WWW.LEGACYCARAUDIO.COM
1) SUMMARIZE
Respectful users: We appreciate that you choose to use our product TFT-LCD Monitors. Compared with the traditional CRT monitor, this model is light and thin, low radiation, without flashing, without distortion, high efficiency, with the new life concept of environmental, low power consumption, and green healthy. This LCD monitor employ DSP chip, MCU I Ccontrolling technique and
2
7 TFT-LCD monitor, clear picture and true colour. Please read this operating instruction before using our product, so that you can use it in best way.
2) Features: Infrared remote control function OSD Screen Display Setting mode with automating store function NTSC/PAL auto-recognize function
3) Technical Performance: Screen Size: 7.0 (Diagonal) Display Format : 1140 (RGB)(H) 234(V) Effective Display Dimension :154.1 85.5mm Pix Set: Vertical Stripe System: NTSC/PAL (Auto - Recognize) Video Input: 1.0 Vp -p (75 ) Audio Input :-10dB(10k ) Power Supply: DC 11V-14V Rated current : 800mA Rated Power Consumption : 10W Operating Temperature: 5 -40 Storage temperature: -10 -80
1
