Reciprocating Single- and Two-stage Air Compressors
2-25 hp
2
Reciprocating Compressors
Legendary Performance
For more than a century, Ingersoll Rand
has inspired progress by driving
innovation through revolutionary
technology and talented people.
It’s a legacy of creating new standards for how the world gets work done.
We’re the technology leader in compressed air not only because we develop
best-in-class products, but also because we stand behind our customers in
all aspects of what we do. No matter what your product, process or
location, Ingersoll Rand has the expertise, the technology and the
unmatched service to meet your needs.
1872
Ingersoll Rand
tradition begins with
its first reciprocating
air compressor.
1950s
Updraft air
cleaner added.
1940s
Design enhanced
with large U-frame
motor and
improved piping.
1970s
First units from
Campbellsville, KY
plant establish a new
reputation for
workmanship and
service.
1960s
Modern Type-30 design
emerges with horizontal
cooling fans, smaller T-frame
motor, convex tank heads,
fully-welded construction
and drive-belt guards.
1929
Initial production model
of Type-30 design with
vertical cooling fins;
combination of concave
and convex tank heads.
3
Reciprocating Compressors
Providing Customer-driven
Compressor Solutions
When you’ve been delivering reliable
reciprocating compressor results for more
than 100 years, it’s natural that your
corporate culture supports a strong tradition
of evolutionary enhancements. Every new
generation of employees builds on the
experience and insights of their mentors.
Today’s legendary Ingersoll Rand air
compressors started with an original rock-
solid design and have steadily improved with
added control and performance upgrades over
the years.
1980s
First blue-colored
units feature new
enhancements.
2002
Compact single-
stage compressors
introduced.
2000
Premier Series
packaging adds
dual controls, deluxe
starter, and liquid-filled
pressure gauge.
1990s
Fully packaged
units with E-series
starters and CSA
package certification
are introduced.
They are world-renowned for their impressive
legacy of long-life performance, ease of service
and evolutionary design enhancements.
Efficient. Reliable. Built to last.
Ingersoll Rand has sold millions of
reciprocating compressors worldwide.
2003
Pressure-lubricated model
with industrial-grade two-stage
air cleaner added.
2006
Fully packaged model with
aftercooler, automatic tank
drain, and low-oil-level
shutdown is top choice for
round-the-clock applications.
4
Reciprocating Compressors
Efficiency, Reliability, Built to Last
Time-tested design and enhancements establish
Ingersoll Rand single and two-stage reciprocating
compressors as the benchmark for:
Efficiency and Reliability
With a proven design and stellar track record,
the Ingersoll Rand reciprocating compressor
family has earned worldwide recognition for
reliable, trustworthy performance that saves
money and enhances business success through:
n Lower life-cycle costs
n An ability to thrive in punishing applications
n Optimum solutions for greater efficiency
n Configurations that meet varying needs
Built to Last
Due to the laws of physics, there are certain
aspects of reciprocating compressor design,
construction and performance that have never
changed – like cast-iron durability, copper-
finned cooling coils, reliable splash lubrication
and easy maintenance. That’s where Ingersoll
Rand’s design and operating experience really
pays off in terms of long-term productivity and
return on investment. Ask any one of the
millions of active Ingersoll Rand reciprocating
compressor users around the world.
Ingersoll Rand
Serviceability
Ingersoll Rand designed the reciprocating
compressors to last a lifetime – thanks to quick,
easy maintenance with renewable components.
Easy access to the pump components allows for
quick routine maintenance and replacement of
parts like the stainless steel valve, individually
cast cylinders, piston rings and gaskets, and
long-life bearings. This key serviceability aspect
extends the life of the compressor and lets you
amortize your initial capital cost over a much
longer equipment life span for a superior
payback on your investment.
Innovation
For more than 100 years, Ingersoll Rand has
maintained the delicate balance between
known performance and new developments
by keeping the best features and upgrading
others as new technology becomes available.
The result is higher efficiency for today’s
energy-conscious world and enhanced value
for the extended life of your investment.
Customer-driven Solutions
Another residual benefit of compressor
longevity is our cumulative experience with
how different users prefer, need and operate
their compressors. Years of experience in the
reciprocating compressor business and
servicing a variety of users have taught us
what is most important to compressor users.
And that means more choices for you to
satisfy your specific needs.
Your choices range from the size of the units
and the sophistication of the features to
popular packaged solutions. There are even
gas-powered packages perfect for field service,
fleet maintenance, remote pneumatic
applications or emergency back-up needs.
The Ideal Design for
Applications Where Air
is Taken for Granted
Ingersoll Rand single- and
two-stage reciprocating air
compressors are an ideal
choice for applications that
demand a reliable air supply
for everyday use, but where
running an air compressor
ranks a distant second to
running your business.
n Automotive Shops
n Light Manufacturing
n Construction
n Commercial Applications
n Fabrication
n Pneumatic Equipment
n Processing Lines
Why Ingersoll Rand
Pumps Are Better...
Excellence in Design!
Two-stage Design: Delivers pressures up
to 175 psig
Radial Fins for Maximum Cooling:
Even 360° cooling of barrel cylinders
eliminates hot spots
One-piece Connecting Rod: Fewer
wearing parts
Low Oil Level Switch: Provides constant
protection
Centrifugal Unloader: Ensures loadless
starts, for maximum starter protection
Integral Fan Blade/Finned Copper
Intercooler: Runs cooler, even in the most
demanding conditions
Overhung Crankshaft: Precision balanced
to run smoothly and quietly; simplifies
maintenance and wear-sleeve replacement
Splash Lubrication: Simple and reliable.
100% Cast Iron: Designed for a lifetime
1
1
1
2
3
4
5
6
7
8
9
2
3
4
5
6
7
8
9
Two-stage Gas-powered Air Compressors
Ingersoll Rand’s two-stage gasoline engine driven air
compressors are designed to provide compressed air where
electric power is not readily available. They’re used in fleet
and field service applications, remote pneumatic applications
and emergency production lines.
n Available with easy-starting
Honda, or Kohler engines
n Fuel-efficient idle control
n Advanced safety features
including low oil level shutdown
for gas engines
Electric-Driven Duplex Air Compressors
Ingersoll Rand duplex reciprocating air compressors offer two individual
compressor pumps and two motors mounted on a single tank, providing
100% built-in backup or additional air power for those larger capacity
jobs. Includes the legendary T30 pump with value added features in a
space saving design ideally suited for tight spaces.
n Durable cast iron design for
100% continuous duty application
n Automatic duplexing or
alternating of compressors
n Individually cast cylinders,
overhung crankshaft and
one piece connecting road
for ease of maintenance
n 175 psig maximum operating pressure
Single-stage Air Compressor
Configured in space-saving stationary and portable models,
these durable compressors are a favorite with DIY homeowners
and in the construction industry.
Key features include:
n Industry-leading 5,000-8,000
hour design life
n Industrial-quality cast iron
construction
n Fully-balanced crankshaft that
reduces vibration
n 135 psi max. discharge pressure
n Honda engine-driven wheel
barrow compressor
