Leeson E116764.00 Product Information Packet

PRODUCT INFORMATION PACKET

Model No: C6T17DK32B
Catalog No: E116764.00

E116764.00..1.5HP..1750RPM.56C.DP.230/460V.3PH.60HZ.CONT.40C.1.15SF.RIGID C

FACE.C6T17DK32.....GENERAL PURPOSE.NOT.......

Open Drip Proof (ODP)

Regal and Leeson are trademarks of Regal Beloit Corporation or one of its affiliated companies.

©2018 Regal Beloit Corporation, All Rights Reserved. MC017097E

1 of 5

Product Information Packet: Model No: C6T17DK32B, Catalog No:E116764.00
E116764.00..1.5HP..1750RPM.56C.DP.230/460V.3PH.60HZ.CONT.40C.1.15SF.RIGID C

FACE.C6T17DK32.....GENERAL PURPOSE.NOT.......

Nameplate Specifications

Output HP
Frequency 60 Hz Voltage 230/460 V
Current
Service Factor
Efficiency 86.5 % Duty Continuous
Insulation Class
KVA Code L Frame 56C
Enclosure Drip Proof Overload Protector No
Ambient Temperature
Opp Drive End Bearing Size 6203 UL Recognized
CSA
IP Code

1.50 Hp

4.8/2.4 A

1.25

F

40 °C

Y
22

Output KW

Speed
Phase

Design Code

Drive End Bearing Size

CE

1.1 kW

1750 rpm
3

B

6203

Y

Technical Specifications

Electrical Type
Poles 4 Rotation Reversible

Squirrel Cage Inverter Rated

Starting Method

Line Or Inverter

Mounting
Drive End Bearing BALL Opp Drive End Bearing BALL
Frame Material Rolled Steel Shaft Type T
Overall Length
Shaft Diameter 0.625 in Shaft Extension 1.88 in
Assembly/Box Mounting
Outline Drawing

Rigid base

12.87 in

F1 ONLY
607-0193-800

Motor Orientation

Frame Length

Connection Diagram

HORIZONTAL

8.00 in

005010.20

This is an uncontrolled document once printed or downloaded and is subject to change without notice. Date Created: 10/15/2018

2 of 5
