Leeson 811627.00 Product Information Packet

PRODUCT INFORMATION PACKET

Model No: 811627.00

Catalog No: 811627.00

7.50 HP Variable Speed Motor, 3 phase, 1200 RPM, 230/460 V, 254TC Frame, TENV
1000:1 Speed Ratio Motors

Regal and Leeson are trademarks of Regal Beloit Corporation or one of its affiliated companies.

©2019 Regal Beloit Corporation, All Rights Reserved. MC017097E

1 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 41 of 4

Product Information Packet: Model No: 811627.00, Catalog No:811627.00 7.50 HP Variable Speed Motor, 3 phase, 1200 RPM, 230/460 V, 254TC
Frame, TENV

Nameplate Specifications

Output HP 7.50 Hp Output KW 5.6 kW
Frequency 60 Hz Voltage 230/460 V
Current 22.0/11.0 A Speed 1170 rpm
Service Factor 1 Phase 3
Efficiency 87.5 % Power Factor 73
Duty Continuous Insulation Class F
Design Code INV KVA Code L
Frame 254TC Enclosure Totally Enclosed Non Ventilated
Thermal Protection No Ambient Temperature 40 °C
Drive End Bearing Size 6309 Opp Drive End Bearing Size 6206
UL Recognized CSA Y
CE Y IP Code 43

Technical Specifications

Electrical Type Squirrel Cage Inverter Duty Starting Method Inverter Only
Poles 6 Rotation Reversible
Resistance Main .825 Ohms Mounting Rigid base
Motor Orientation Horizontal Drive End Bearing Ball
Opp Drive End Bearing Ball Frame Material Aluminum
Shaft Type T Overall Length 24.81 in
Frame Length 13.25 in Shaft Diameter 1.625 in
Shaft Extension 4 in Assembly/Box Mounting F1/F2 CAPABLE

This is an uncontrolled document once printed or downloaded and is subject to change without notice. Date Created:01/11/2019

2 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 42 of 4

Regal Beloit America, Inc.

TM

COPYRIGHT REGAL BELOIT AMERICA, INC. ALL RIGHTS RESERVED.

PROPRIETARY AND CONFIDENTIAL INFORMATION - THIS DOCUMENT IS THE PROPERTY OF

REGAL BELOIT AMERICA, INC. ("OWNER") AND CONTAINS OWNER'S PROPRIETARY

INFORMATION. ANY PERSON, CORPORATION OR OTHER FIRM RECEIVING I T IS DEEMED,
BY RECEIVING IT, TO AGREE THAT IT, AND/OR ANY PART OF IT, SHALL NOT BE DISCLOSED
TO ANY PERSON, CORPORATION OR OTHER ENTITY, DUPLICATED, A ND/ OR USED, EXCEPT

AS EXPRESSLY APPROVED IN WRITING IN ADVANCE BY OWNER. THIS DOCUMENT SHALL

BE RETURNED TO OWNER UPON REQUEST. IT MAY BE SUBJECT TO CERTAIN

RESTRICTIONS UNDER APPLICABLE EXPORT CONTROL LAWS AND REGULATIONS.

TOLERANCES UNLESS
OTHERWISE SPECIFIED:
DEC.

INCH mm ANGLE
.X 0.1 [ 2.5] 7' 30"
.XX 0.03 [ 0.76]
XXX 0.005 [ 0.127]
.XXXX 0.0005 [ 0.0127]
REMOVE BURRS & BREAK SHARP
EDGES: .003/.015 [.076/.381] X 45
CORNER FILLETS: R.02 [.51]
MACHINED SURFACES:

200 5.1

INCH mm
mm SHOWN IN [BRACKETS]

12

43

A

B

2

43

1

A

B

ECO DESCRIPTION

DATEAPPROVED BY

DATEREVISION BY

ECO

DRAWING REVISION

REFERENCE

MATERIAL

SHEET

DRAWING NUMBERSIZE

DESCRIPTION

THIRD ANGLE
PROJECTION

DRAWN BY

DATE

DATE

APPROVED BY

PROCESS/FINISH

B

1 OF 1

SS330110

MJK

04-18-2005

CGD

08-18-2005

F W. JOERGER 01-19-2018

ECO-0131008 E. HEIL 01-19-2018

REMOVED 256 FRAME DASH -1475

OUTLINE

210 FR. - 254 MTG - ALUMINUM FRAME

NOTES:

1. CONDUIT BOX CAN BE ROT AT ED IN 90 STEPS.

2. SEE CHART FOR "F 2 " C APABILITY. IF YES, BOX CAN BE MO UN TED ON
OPPOSITE SIDE BY REMOVING BRACKETS AND TURNING FRAME 180 .

3. NAMEPLATE READ FROM CONDUIT BOX SIDE OF MOTO R.

1325 254

25.37

[644.44]

24.81

[630.17]

19.31

[490.50]

13.37

[339.60]

8.25

[209.55]

8.90

[226.06]

YES 8

1475 254

26.87

[682.54]

26.31

[668.27]

20.81

[528.60]

14.87

[377.70]

8.25

[209.55]

10.40

[264.16]

YES 8

DASH FRAME C1 C AG B 2F BS F1/F2

MTG

HOLES

6.12

155.45

AG

3.75

95.27

B

.29
.25

7.37

6.35

8.500

8.497

215.900

215.824

8.75

222.28

C1

2.31

58.67

1.87

47.57

1.625

1.624

41.275

41.250

BS

1.75

44.41

.6250
.6245

15.8750

15.8623

1.38

35.05

2F

2F

.25

6.35

4.75

120.65

C

4.500

4.497

114.300

114.224

.375x.375x2.88
[9.525x9.525x73.15]
KEY

.188x.094x1.62
[4.763x2.381x41.15]
KEYWAY

.004 [.102] A

.004 [.102] A

.004 [.102] A

.004 [.102] A

A

11.12

282.45

2.70

68.57

45° 45°

6.66

169.19

8.55

217.21

14.11

358.44

6.25

6.19

158.75

157.23

13.46

341.88

7.265

7.235

184.531

183.769

.53

13.46

1/2-13 UNC-2B

.88 [22.23] FULL THD

(4) HOLES

5.00

127.00

10.00

254.00

10.75

273.10

1.75 [44.45]

& 2.00 [50.80]

KNOCKOUTS

(1 PLACE)

.53-.58

[13.46-14.73]

SEE CHART FOR

NO. OF MTG HOLES

45°

45°

5.875

149.225

3/8-16 UNC-2B
.62 [15.88] FULL THD.
(4) HOLES

FRONT END VIEW

(SHAFT COVER REMOVED)

F2 VIEW

Regal Beloit America, Inc.

TM

COPYRIGHT REGAL BELOIT AMERICA, INC. ALL RIGHTS RESERVED.

PROPRIETARY AND CONFIDENTIAL INFORMATION - THIS DOCUMENT IS THE PROPERTY OF

REGAL BELOIT AMERICA, INC. ("OWNER") AND CONTAINS OWNER'S PROPRIETARY

INFORMATION. ANY PERSON, CORPORATION OR OTHER FIRM RECEIVING I T IS DEEMED,
BY RECEIVING IT, TO AGREE THAT IT, AND/OR ANY PART OF IT, SHALL NOT BE DISCLOSED
TO ANY PERSON, CORPORATION OR OTHER ENTITY, DUPLICATED, A ND/ OR USED, EXCEPT

AS EXPRESSLY APPROVED IN WRITING IN ADVANCE BY OWNER. THIS DOCUMENT SHALL

BE RETURNED TO OWNER UPON REQUEST. IT MAY BE SUBJECT TO CERTAIN

RESTRICTIONS UNDER APPLICABLE EXPORT CONTROL LAWS AND REGULATIONS.

TOLERANCES UNLESS
OTHERWISE SPECIFIED:
DEC.

INCH mm ANGLE
.X 0.1 [ 2.5] 7' 30"
.XX 0.03 [ 0.76]
XXX 0.005 [ 0.127]
.XXXX 0.0005 [ 0.0127]
REMOVE BURRS & BREAK SHARP
EDGES: .003/.015 [.076/.381] X 45
CORNER FILLETS: R.02 [.51]
MACHINED SURFACES:

200 5.1

INCH mm
mm SHOWN IN [BRACKETS]

12

43

A

B

2

43

1

A

B

ECO DESCRIPTION

DATEAPPROVED BY

DATEREVISION BY

ECO

DRAWING REVISION

REFERENCE

MATERIAL

SHEET

DRAWING NUMBERSIZE

DESCRIPTION

THIRD ANGLE
PROJECTION

DRAWN BY

DATE

DATE

APPROVED BY

PROCESS/FINISH

B

1 OF 1

SS330110

MJK

04-18-2005

CGD

08-18-2005

F W. JOERGER 01-19-2018

ECO-0131008 E. HEIL 01-19-2018

REMOVED 256 FRAME DASH -1475

OUTLINE

210 FR. - 254 MTG - ALUMINUM FRAME

NOTES:

1. CONDUIT BOX CAN BE ROT AT ED IN 90 STEPS.

2. SEE CHART FOR "F 2 " C APABILITY. IF YES, BOX CAN BE MO UN TED ON
OPPOSITE SIDE BY REMOVING BRACKETS AND TURNING FRAME 180 .

3. NAMEPLATE READ FROM CONDUIT BOX SIDE OF MOTO R.

1325 254

25.37

[644.44]

24.81

[630.17]

19.31

[490.50]

13.37

[339.60]

8.25

[209.55]

8.90

[226.06]

YES 8

1475 254

26.87

[682.54]

26.31

[668.27]

20.81

[528.60]

14.87

[377.70]

8.25

[209.55]

10.40

[264.16]

YES 8

DASH FRAME C1 C AG B 2F BS F1/F2

MTG

HOLES

Uncontrolled Copy

3 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 43 of 4

Uncontrolled Copy

HIGH VOLTAGE

(U1) T1

(V1) T2

(W1) T3

(U2) T4

(U3) T7

(V2) T5

(V3) T8

(W2) T6

(W3) T9

LOW VOLTAGE

(U1) T1

(U3) T7

(V1) T2

(V3) T8

LOW VOLTAGE

T4 T5 T6

P1

HIGH VOLTAGE

T4 T7 T5 T8 T6 T9

L1

L2

L3

L1 T7 T1 L2 T8 T2 L3 T9 T3

L1 T1 L2 T2 L3 T3

P2

NOTE FOR FACTORY USE ONLY:
TO SURGE TEST FOR COMMON CONNECT:
HIGH VOLT: CONNECT P1 TO T1
THEN P2 TO L1
LOW VOLT: CONNECT P1 TO T1 & T7,
THEN P2 TO L1

L1

L2

P1

P2

PROT.

THREE PHASE

DUAL VOLTAGE MOTOR

PROT.

T1

T4

T7

T9

T6

T3

T8

T5

THERMO-PROTECTORS
CONNECTED IN SERIES

RED
OR

PURPLE

BLACK

BLACK

YELLOW

BROWN

ORANGE

BLACK

BLACK

T2

PURPLE

RED

BLUE

OR
RED

P1 (TB1)

T1 (U1)

T4 (U2)

T9 (W3)

T7 (U3)

T8 (V3)

T6 (W2)

T5 (V2)

T2 (V1)

T3 (W1)

P2 (TB2)

(W1) T3

(W3) T9

L3

(U2) T4

(V2) T5

(W2) T6

DRAWING REVISION

ECO

ECO DESCRIPTION

T

ECO-0159915

ADDED TERMINAL CONNECTION DIAGRAM

COPYRIGHT REGAL BELOIT AMERICA, INC. ALL RIGHTS RESERVED.

PROPRIETARY AND CONFIDENTIAL INFORMATION - THIS DOCUMENT IS THE PROPERTY OF

REGAL BELOIT AMERICA, INC. ("OWNER") AND CONTAINS OWNER'S PROPRIETARY

INFORMATION. ANY PERSON, CORPORATION OR OTHER FIRM RECEIVING IT IS DEEMED,
BY RECEIVING IT, TO AGREE THAT IT, AND/OR ANY PART OF IT, SHALL NOT BE DISCLOSED
TO ANY PERSON, CORPORATION OR OTHER ENTITY, DUPLICATED, AND/OR USED, EXCEPT

AS EXPRESSLY APPROVED IN WRITING IN ADVANCE BY OWNER. THIS DOCUMENT SHALL

BE RETURNED TO OWNER UPON REQUEST. IT MAY BE SUBJECT TO CERTAIN

RESTRICTIONS UNDER APPLICABLE EXPORT CONTROL LAWS AND REGULATIONS.

REVISION BY

ZR

APPROVED BY

DR

NOTE: LEAD'S COLOR CAN BE YELLOW OR WHITE FOR MT2 PLANT

DATE

01-14-2019

DATE

01-15-2019

DRAWN BY

DATE

APPROVED BY

DATE

REFERENCE

THIRD ANGLE
PROJECTION

SMC

05-13-1992

05-13-1992

EE7308/EE7300

PROT.

VIEW OF TERMINAL END

TM

Regal Beloit America, Inc.

TB

DESCRIPTION

CONN DIAGRAM-INTERNAL

MATERIAL

SIZE

DRAWING NUMBER

3 PHASE - DUAL VOLTAGE MOTOR

A

4 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 44 of 4

EE7308T

PROCESS/FINISH

SHEET

1 OF 1
