Leeson 192260.00 Product Information Packet

PRODUCT INFORMATION PACKET

Model No: 192260.00

Catalog No: 192260.00

1.50 HP General Purpose, 1 phase, 3600 RPM, 115/230 V, 80 Frame, TEFC
Aluminium TEFC Motors

Regal and Leeson are trademarks of Regal Beloit Corporation or one of its affiliated companies.

©2019 Regal Beloit Corporation, All Rights Reserved. MC017097E

1 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 31 of 3

Product Information Packet: Model No: 192260.00, Catalog No:192260.00 1.50 HP General Purpose, 1 phase, 3600 RPM, 115/230 V, 80 Frame, TEFC

Nameplate Specifications

Output HP 1.50 Hp Output KW 1.1 kW
Frequency 60 Hz Voltage 115/230 V
Current 12.8/6.4 A Speed 3450 rpm
Service Factor 1.15 Phase 1
Efficiency 77 % Power Factor 98
Duty Continuous Insulation Class F
Design Code N KVA Code F
Frame D80 Enclosure Totally Enclosed Fan Cooled
Thermal Protection Manual Ambient Temperature 40 °C
Drive End Bearing Size 6204 Opp Drive End Bearing Size 6203
UL Recognized CSA Y
CE Y IP Code 55

Technical Specifications

Electrical Type Capacitor Start Capacitor Run Starting Method Across The Line
Poles 2 Rotation Selective Clockwise
Resistance Main 2.418 Ohms Mounting B3
Motor Orientation Horizontal Drive End Bearing Ball
Opp Drive End Bearing Ball Frame Material Aluminum
Shaft Type IEC Overall Length 11.10 in
Shaft Diameter 0.750 in Shaft Extension 1.57 in
Assembly/Box Mounting F3

This is an uncontrolled document once printed or downloaded and is subject to change without notice. Date Created:01/11/2019
