Leeson 191528.00 Product Information Packet
PRODUCT INFORMATION PACKET
Model No: C6T11NK6A
Catalog No: 191528.00
..1HP..1200RPM.145TC.TEFC.230/460V.3PH.60HZ.CONT.40C..RIGID-C..............
Paint Free
Regal and Leeson are trademarks of Regal Beloit Corporation or one of its affiliated companies.
©2018 Regal Beloit Corporation, All Rights Reserved. MC017097E
1 of 5
Product Information Packet: Model No: C6T11NK6A, Catalog No:191528.00
..1HP..1200RPM.145TC.TEFC.230/460V.3PH.60HZ.CONT.40C..RIGID-C..............
Nameplate Specifications
Output HP |
1 Hp |
Output KW |
0.75 kW |
Frequency |
60 Hz |
Voltage |
208-230/460 V |
Current |
3.8-3.8/1.9 A |
Speed |
1150 rpm |
Service Factor |
1.15 |
Phase |
3 |
Efficiency |
82.5 % |
Duty |
Continuous |
Insulation Class |
F |
Design Code |
B |
KVA Code |
K |
Frame |
145TC |
Enclosure |
Totally Enclosed Fan Cooled |
Overload Protector |
No |
Ambient Temperature |
40 °C |
Drive End Bearing Size |
6205 |
Opp Drive End Bearing Size |
6205 |
UL |
Recognized |
CSA |
Y |
CE |
Y |
IP Code |
43 |
|
|
Technical Specifications
Electrical Type |
Squirrel Cage Induction Run |
Starting Method |
Across The Line |
Poles |
6 |
Rotation |
Reversible |
Mounting |
Rigid base |
Motor Orientation |
HORIZONTAL |
Drive End Bearing |
BALL |
Opp Drive End Bearing |
BALL |
Frame Material |
Stainless Steel |
Shaft Type |
T |
Overall Length |
13.20 in |
Frame Length |
7.99 in |
Shaft Diameter |
0.875 in |
Shaft Extension |
2.25 in |
Assembly/Box Mounting |
F1 ONLY |
|
|
Outline Drawing |
OL191528 |
Connection Diagram |
005010.01 |
This is an uncontrolled document once printed or downloaded and is subject to change without notice. Date Created: 10/15/2018
2 of 5
