PRODUCT INFORMATION PACKET
Model No: CZ6T34TK1D
Catalog No: 117118.00
..1/2HP..3450RPM.56.TENV.208-230/460V.3PH.60HZ.CONT.40C.1.15SF.RIGID
C.CZ6T34TK1.....EXTREME DUCK.NOT.......
Encapsulated
Regal and Leeson are trademarks of Regal Beloit Corporation or one of its affiliated companies.
©2018 Regal Beloit Corporation, All Rights Reserved. MC017097E
1 of 6
Product Information Packet: Model No: CZ6T34TK1D, Catalog No:117118.00 ..1/2HP..3450RPM.56.TENV.208-
230/460V.3PH.60HZ.CONT.40C.1.15SF.RIGID C.CZ6T34TK1.....EXTREME DUCK.NOT.......
Nameplate Specifications
Output HP
Frequency 60 Hz Voltage 208-230/460 V
Current
Service Factor
Efficiency 82.5 % Duty Continuous
Insulation Class
KVA Code M Frame 56C
Enclosure Totally Enclosed Non Ventilated Overload Protector No
Ambient Temperature
Opp Drive End Bearing Size 6205 UL Recognized
CSA
IP Code
0.50 Hp
1.7-1.6/0.80 A
1.15
F
40 °C
Y
69
Output KW
Speed
Phase
Design Code
Drive End Bearing Size
CE
0.37 kW
3450 rpm
3
B
6205
Y
Technical Specifications
Electrical Type
Poles 2 Rotation Reversible
Squirrel Cage Induction Run
Starting Method
Across The Line
Mounting
Drive End Bearing BALL Opp Drive End Bearing BALL
Frame Material Stainless Steel Shaft Type NEMA 56
Overall Length
Shaft Diameter 0.625 in Shaft Extension 1.88 in
Assembly/Box Mounting
Outline Drawing
Rigid base
10.47 in
F1 ONLY
028767-525
Motor Orientation
Frame Length
Connection Diagram
HORIZONTAL
5.25 in
005010.52
This is an uncontrolled document once printed or downloaded and is subject to change without notice. Date Created: 10/15/2018
2 of 6
R BC PROP RIE TAR Y AN D C ONF IDEN TIA L INF ORM ATION
This docume nt is the prop erty of RE GAL B ELOIT COR POR ATIO N ("R BC ") incl uding
its s ubsidi aries an d divis ions and con tains proprietary inform ation of RB C. This d ocumen t
is loa ned on t he exp ress c onditio n that neither i t nor t he inform ation contain ed therei n shall
be dis closed to ot hers w ithout the ex press writt en cons ent of RBC , and that the inf ormation
shall be used by t he recip ient only as approved expres sly b y RB C. This docum ent sh all be
returned to RB C up on its request . Th is doc ument may b e subje ct to certai n restri ctions
under U .S. export control laws and regul ations.
"AD"
"C" .06
.004 A
2.06
1.94.13
1.875.06
45°
45°
3/4" HEX DRIVER
FOR COVER REMOVAL
1/2-14 NPT
CONDUIT HOLE
NAMEPLATE
.34
4.75
REVISIONNO
THIRD ANGLE
PROJECTION
6.56
2.753.00
1.41
FULL
DEPTH
.19 SQ. X 1.38 KEY
4.500
4.497
.004 A
.6250
.6245
.002 A
(4) 3/8-16 UNC-2B X .56
DEEP ON A 5.875
B.C.
DASH
NO
525 10.47 4.44
"C" "AD"
550 10.72 4.69
575 10.97 4.94
600 11.22 5.19
625 11.47 5.44
650 11.72 5.69
675 11.97 5.94
700 12.22 6.19
725 12.47 6.44
750 12.72 6.69
775 12.97 6.94
UNLESS SPECIFIED
DEC
.X
.XX
.XXX
.XXXX
CHK
BY & DATE
ANG
RFP
NETWORK FILE NAME
TOLERANCES
INCHES
±.1
±.03
±.005
±.0005
±1/2°
A
TITLE
OUTLINE 56C FRAME
TENV RIGID "C"
MAT'L
FINISH
PREV
2.47
1.22
4.94
6.50
SHAFT
SEAL
6.78
3.50
3.44
.130
DRAWN
LST 9/9/09
CHK
APPR
SCALE
1:2
REF
FMF
OF
PAGE
B
028767
REVSIZE DRAWING NO
You created this PDF from an application that is not licensed to print to novaPDF printer (http://www.novapdf.com)
1/19/2012 11:50:36 AM - Converted by Connexus
3 of 6
VIEW FROM OUTSIDE OF MOTOR AT SWITCH END.
Uncontrolled Copy
LINE LEADS
YELLOW (T1)
WHITE (T2)
ORANGE(T3)
BLUE (T4)
BLACK (T5)
PURPLE (T6)
PINK (T7)
RED (T8)
GRAY (T9)
GRAY
(T9)
ORANGE
(T3)
BLUE
(T4)
YELLOW
(T1)
PINK
(T7)
BLACK
(T5)
PURPLE
(T6)
WHITE
(T2)
RED
(T8)
RBC PROPRIETARY AND CONFIDENTIAL INFORMATION
This document is the property of REGAL BELOIT CORPORATION ("RBC") including
its subsidiaries and divisions and contains proprietary information of RBC. This document
is loaned on the express condition that neither it nor the information contained therein shall
be disclosed to others without the express written consent of RBC, and that the information
shall be used by the recipient only as approved expressly by RBC. This document shall be
returned to RBC upon its request. This document may be subject to certain restrictions
under U.S. export control laws and regulations.
DRAWING REVISION
C
ECO
ECO-0049985
ECO DESCRIPTION
COPYRIGHT REGAL BELOIT AMERICA, INC. ALL RIGHTS RESERVED.
PROPRIETARY AND CONFIDENTIAL INFORMATION - THIS DOCUMENT IS THE PROPERTY OF
REGAL BELOIT AMERICA, INC. ("OWNER") AND CONTAINS OWNER'S PROPRIETARY
INFORMATION. ANY PERSON, CORPORATION OR OTHER FIRM RECEIVING IT IS DEEMED,
BY RECEIVING IT, TO AGREE THAT IT, AND/OR ANY PART OF IT, SHALL NOT BE DISCLOSED
TO ANY PERSON, CORPORATION OR OTHER ENTITY, DUPLICATED, AND/OR USED, EXCEPT
AS EXPRESSLY APPROVED IN WRITING IN ADVANCE BY OWNER. THIS DOCUMENT SHALL
BE RETURNED TO OWNER UPON REQUEST. IT MAY BE SUBJECT TO CERTAIN
RESTRICTIONS UNDER APPLICABLE EXPORT CONTROL LAWS AND REGULATIONS.
REVISION BY
PVR
APPROVED BY
JD
UPDATED PER ECO-0049985
DATE
04/23/14
DATE
04/23/14
TOLERANCES UNLESS
OTHERWISE SPECIFIED:
DEC.
INCH
mm
.X
.XX
XXX
.XXXX
REMOVE BURRS & BREAK SHARP
EDGES: .003/.015 [.076/.381]
CORNER FILLETS: .02 [.51]
MACHINED SURFACES:
INCH mm
mm SHOWN IN [BRACKETS]
0.1 [ 2.5]
0.01 [
0.005 [ 0.127]
0.0005 [ 0.0127]
0.25]
125
ANGLE
DRAWN BY
DATE
0.5
APPROVED BY
DATE
PROCESS/FINISH
3.2
THIRD ANGLE
PROJECTION
LST
4/3/14
VOLTAGE
HIGH
LOW
L1 L2 L3
T1 T2 T3
T1,T7 T2,T8 T3,T9
TM
INSULATE
Regal Beloit America, Inc.
DESCRIPTION
LEAD ASSY
EXT. WIRING DIA. 3 PH. W/O PROT.
MATERIAL
SIZE
DRAWING NUMBER
A
4 of 6
00501052
JOIN &
(T4,T7)
(T5,T8)
(T6,T9)
T4,T5,T6
SHEET
1 OF 1
Uncontrolled Copy
5 of 6
Date:
Speed (RPM)
Data Sheet
Current (Amps)
P
E
0.0
0.5
1.0
1.5
0 500 1000 1500 2000 2500 3000 3500 4000
TORQU
2.0
2.5
3.0
3.5
4.0
30.0
40.0
50.0
0% 20% 40% 60% 80% 100% 120% 140%
F
60.0
70.0
EFF
80.0
100.0
90.0
Torque (ft-lb)
Efficiency (%) P.F. (%) Current (Amps)
2.53 2.30 3.6 0.75 0.00 3600
7.0 6.4 4.2 0.80 0.43 0.5
0 400 2700 3510 3600
P.F. (%)
3600 3576 3556 3535 3510 3,502 3489 0
0.43 0.46 0.53 0.63 0.80 0.83 0.86 7.0
0.00 0.19 0.37 0.56 0.75 0.85 0.94 2.53
24.5 42.8 61.1 71.9 79.0 81.1 83.2 0.0
LR Pull-Up BD Rated Idle
1/17/2018 117118.00
Load 0% 25% 50% 75% 100% 115% 125% LR
Current (Amps)
Torque (ft-lb)
RPM
Efficiency (%)
Motor Speed Data
LOAD
Torque Amps
61.5 72.4 77.9 82.5 82.1 81.7
Uncontrolled Copy
Speed -Torque Curve
Motor Load Data
RPM
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
A
M
P
S
0
0
0.0000 0.0000 0.0000 0.0000 0.0000
R1 R2 X1 X2 Xm
EQUIV CKT (OHMS / PHASE)
Outline Dwg 028767-525
Conn. Diag 005010.52
Additional Specifications:
Ref Wdg
Sound Pressure @ 1M
VFD Rating
Rotor/Shaft wk²
Ambient
Elevation
T632165 NR
LR Code letter
Service Factor
Temp Rise @ FL
Duty
Voltage
Frequency
Design
Construction
HP
Sync. RPM
Frame
Enclosure
Information Block
208-230/460#190/380
65 dBA
NONE
CONT
1,000
0.04
1.15
60
40
60
M
B
TENV
TTW
140
Data @
feet
Lb-Ft²
0.0
1.0
2.0
3.0
4.0
5.0
6.0
7.0
8.0
A
M
P
S
°
°
C
C
Hz
V
460
v
