PRODUCT INFORMATION PACKET
Model No: C4D18WK14A
Catalog No: 109301.00
3/4HP.1800RPM.S56C.TEFC.24VDC.CONT.40C.1.0SF.RIGID C.DC NEMA LOW VOLTAGE.C4D18WK14
WASHDOWN DUTY
Low Voltage
Regal and Leeson are trademarks of Regal Beloit Corporation or one of its affiliated companies.
©2018 Regal Beloit Corporation, All Rights Reserved. MC017097E
1 of 3
Product Information Packet: Model No: C4D18WK14A, Catalog No:109301.00
3/4HP.1800RPM.S56C.TEFC.24VDC.CONT.40C.1.0SF.RIGID C.DC NEMA LOW VOLTAGE.C4D18WK14
WASHDOWN DUTY
Nameplate Specifications
Output HP
Voltage 24 V Current 29.0 A
Speed
Efficiency
Insulation Class F Frame S56C
Enclosure
Ambient Temperature 40 °C Drive End Bearing Size 6203
Opp Drive End Bearing Size 6203 UL Recognized
CSA
0.75 Hp
1800 rpm
77 %
Totally Enclosed Fan Cooled
Y
Output KW
Service Factor
Duty
Overload Protector
CE
0.56 kW
1
Continuous
No
N
Technical Specifications
Rotation
Overall Length 12.82 in Frame Length 5.47 in
Shaft Diameter
Outline Drawing
Reversible
0.625 in
612-0216-000
Mounting
Shaft Extension
Rigid C base
2.06 in
This is an uncontrolled document once printed or downloaded and is subject to change without notice. Date Created: 10/15/2018
