Leeson 108018.00 Product Information Packet

PRODUCT INFORMATION PACKET

Model No: C4D17FK3J
Catalog No: 108018.00

..3/4HP..1750RPM.S56C.TEFC.90V...CONT.40C.1.0SF.RIGID C.C4D17FK3.....DC NEMA........

SCR

Regal and Leeson are trademarks of Regal Beloit Corporation or one of its affiliated companies.

©2018 Regal Beloit Corporation, All Rights Reserved. MC017097E

1 of 3

Product Information Packet: Model No: C4D17FK3J, Catalog No:108018.00

..3/4HP..1750RPM.S56C.TEFC.90V...CONT.40C.1.0SF.RIGID C.C4D17FK3.....DC NEMA........

Nameplate Specifications

Output HP
Voltage 90 V Current 7.5 A
Speed
Efficiency
Insulation Class F Frame S56C
Enclosure
Ambient Temperature 40 °C Drive End Bearing Size 6203
Opp Drive End Bearing Size 6203 UL Recognized
CSA

0.75 Hp

1750 rpm

82.2 %

Totally Enclosed Fan Cooled

Y

Output KW

Service Factor
Duty

Overload Protector

CE

0.56 kW

1
Continuous

No

N

Technical Specifications

Rotation
Overall Length 13.82 in Frame Length 6.47 in
Shaft Diameter
Outline Drawing

Reversible

0.625 in
031879-108018

Mounting

Shaft Extension

Rigid C base

2.06 in

This is an uncontrolled document once printed or downloaded and is subject to change without notice. Date Created: 10/15/2018

2 of 3
