Ledj Spectra Bank 4, Spectra Bank 6, Spectra Bank 8 User Manual

www.prolight.co.uk

SPECTRA BANK 4, 6 & 8

(ORDER CODES: LEDJ60/LEDJ61/LEDJ62)

USER MANUAL

LEDJ SPECTRA BANK 4, 6, 8 SAFETY

WARNING

FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOUR INITIAL START-UP!

Keep this equipment away from rain,

CAUTION!

Moisture and liquids.

SAFETY INSTRUCTIONS

Every person involved with the installation, operation & maintenance of this
equipment should:

- Be competent

- Follow the instructions of this manual

CAUTION! TAKE CARE USING THIS EQUIPMENT!

HIGH VOLTAGE-RISK OF ELECTRIC SHOCK!!

Before your initial start-up, please make sure that there is no damage caused during
transportation. Should there be any, consult your dealer and do not use the equipment.

To maintain the equipment in good working condition and to ensure a safe operation, it is
necessary for the user to follow the safety instructions and warning notes written in this
manual.

Please note that damages caused by user modifications to this equipment are not
subject to warranty.

LEDJ SPECTRA BANK 4, 6, 8 SAFETY

IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused

by the non-observance of this manual or any unauthorised modification to the
equipment.

• Never let the power-cable come into contact with other cables. Handle the
power-cable and all mains voltage connections with particular caution!

• Never remove warning or informative labels from the equipment.

• Do not open the equipment and do not modify the equipment.

• Do not connect this equipment to a dimmer-pack.

• Do not switch the equipment on and off in short intervals, as this will

reduce the system’s life.

• Only use the equipment indoors.

• Do not expose to flammable sources, liquids or gases.

• Always disconnect the power from the mains, when equipment is not in

use or before cleaning! Only handle the power-cable by the plug. Never
pull out the plug by pulling the power-cable.

• Make sure that the available voltage is between 220v/240v.

• Make sure that the power-cable is never crimped or damaged. Check the

equipment and the power-cable from time to time.

• If the equipment is dropped or damaged, disconnect the mains power supply
immediately. Have a qualified engineer inspect the equipment

before operating again.

• If the equipment has been exposed to drastic temperature fluctuation (e.g.
after transportation), do not switch it on immediately. The arising
condensation might damage the equipment. Leave the equipment switched
off until it has reached room temperature.

• If your product fails to function correctly, discontinue use immediately. Pack
the unit securely (preferably in the original packing material), and return it to
your Prolight dealer for service.

• Only use fuses of same type and rating.

• Repairs, servicing and electric connection must only be carried out by a

qualified technician.

• THIS UNIT CONTAINS NO USE R SERVICEABL E PARTS…

• WARRANTY; One year from date of purchase.

OPERATING DETERMINATIONS

If this equipment is operated in any other way, than those described in this manual,
the product may suffer damage and the warranty becomes void.

Incorrect operation may lead to danger e.g.: short-circuit, burns, electric shocks,
lamp failure etc.

Do not endanger your own safety and the safety of others!
Incorrect installation or use can cause serious damage to people and property!

LEDJ SPECTRA BANK 4, 6, 8 DESCRIPTION

Description of the equipment

Features

The Spectra Bank is a high output LED spot bank.

• Spectra Bank 4 – 4 Spots

• Spectra Bank 6 – 6 Spots

• Spectra Bank 8 – 8 Spots

• Built-in microphone

• Linkable

• DMX

FRONT VIEW

1) Hanging Brackets

2) Floor/ceiling mounts

Fig 1
