Lectrosonics UCR511 User Manual

UCR511
UHF RECEIVER
(Includes IFB Compatibility Mode)
Featuring Digital Hybrid Wireless™ Technology
(US Patent Pending)
OPERATING INSTRUCTIONS
Rio Rancho, NM, USA www.lectrosonics.com
UCR511
2
UHF Wireless Digital HybridTM Receiver
DIGITAL HYBRID WIRELESS
(US Patent Pending)
The Lectrosonics Digital Hybrid Wireless™ uses innova­tive technology to combine the new advantages of digital audio with the classic advantages of analog RF trans­mission, thus delivering the superior sound quality of a digital system and the excellent range of an analog system. A proprietary algorithm encodes the digital audio information into an analog format which can be transmitted in a robust manner over an analog FM wireless link. The receiver employs the latest filters, RF amplifiers, mixers and detector to capture the encoded signal and a DSP recovers the original digital audio.
TABLE OF CONTENTS
GENERAL TECHNICAL DESCRIPTION ...................................................................................................... 5
COMPATIBILITY MODES ............................................................................................................................................... 5
DIVERSITY RECEPTION .............................................................................................................................................. 5
RF FREQUENCY TRACKING FRONT-END AND MIXER ............................................................................................ 5
MICROCONTROLLER, PLL AND VCO CIRCUITS ....................................................................................................... 5
IF AMPLIFIERS AND SAW FILTERS ............................................................................................................................. 5
DIGITAL PULSE COUNTING DETECTOR .................................................................................................................... 6
DSP-BASED PILOT TONE ............................................................................................................................................. 6
SMART SQUELCH™ ..................................................................................................................................................... 6
SMART NOISE REDUCTION (SmartNR™) .................................................................................................................. 6
RF-CONTROLLED DIGITAL NOISE FILTER ................................................................................................................. 7
OUTPUT LEVEL ADJUST ............................................................................................................................................. 7
TEST TONE .................................................................................................................................................................... 7
BATTERIES .................................................................................................................................................................... 7
POWER SUPPLY ........................................................................................................................................................... 7
LCD DISPLAY ................................................................................................................................................................. 7
POWER UP SEQUENCE ............................................................................................................................................... 7
POWER OFF .................................................................................................................................................................. 7
FRONT PANEL CONTROLS AND FUNCTIONS ......................................................................................... 8
SEL Up/Down ................................................................................................................................................................. 8
MENU ............................................................................................................................................................................. 8
REAR PANEL FEATURES ............................................................................................................................ 8
XLR AUDIO OUTPUT JACK .......................................................................................................................................... 8
POWER ON/OFF ........................................................................................................................................................... 8
LCD ................................................................................................................................................................................. 8
POWER INPUT JACK .................................................................................................................................................... 8
MAIN WINDOW (LCD) ................................................................................................................................... 9
PILOT TONE INDICTOR ........................................................................................................................................... 9
ANTENNA PHASE INDICATOR ................................................................................................................................ 9
RF LEVEL .................................................................................................................................................................. 9
AUDIO LEVELS ......................................................................................................................................................... 9
BATTERY LEVELS .................................................................................................................................................... 9
FREQUENCY WINDOW .............................................................................................................................................. 10
MENU SELECTIONS FROM MAIN WINDOW ............................................................................................ 10
BATTERY LEVEL WINDOW ......................................................................................................................................... 10
SETUP WINDOW ......................................................................................................................................................... 10
LEVEL ...................................................................................................................................................................... 11
TONE ....................................................................................................................................................................... 11
TXBAT ...................................................................................................................................................................... 11
PHASE ..................................................................................................................................................................... 11
SmtNR ..................................................................................................................................................................... 11
TUNING ................................................................................................................................................................... 11
User Programmable Frequency Group Behavior ................................................................................................. 12
Adding/Deleting User Programmable Frequency Group Entries .......................................................................... 12
COMPAT .................................................................................................................................................................. 12
FREQUENCY SCAN MODE ........................................................................................................................ 13
ANTENNA USE AND PLACEMENT ........................................................................................................... 14
INSTALLATION AND OPERATING INSTRUCTIONS ............................................................................... 15
FINDING CLEAR FREQUENCIES .............................................................................................................................. 15
LOCKING AND UNLOCKING THE UCR511 FRONT PANEL CONTROLS ................................................................ 16
TO REPLACE THE BATTERIES ................................................................................................................. 17
Frequency Coordination ............................................................................................................................ 18
Compatible Frequency Chart ........................................................................................................................................ 18
Rule No. 1 ................................................................................................................................................................ 18
This digital/analog hybrid technique has some very beneficial properties. Because the information being transmitted is digitally encoded, immunity to noise is much higher than a compandor can offer. Because the encoded audio is sent in analog format, spectral and power efficiency and operating range are not compro­mised. Under weak RF conditions, the received signal degrades gracefully, like an analog system, delivering as much usable audio as possible at maximum range. Because the audio is not companded, no compandor artifacts are present at any audio or RF signal level. This greatly reduces the pumping and breathing problems commonly found in wireless systems with compandors.
Rio Rancho, NM – USA
3
UCR511
Rule No. 2 ................................................................................................................................................................ 18
Rule No. 3 ................................................................................................................................................................ 20
Using the Scan Function .............................................................................................................................................. 20
Call Lectrosonics .......................................................................................................................................................... 20
UCR511 REPLACEMENT PARTS AND ACCESSORIES ......................................................................... 21
TROUBLESHOOTING ................................................................................................................................. 22
INITIAL POWER ON .................................................................................................................................................... 22
PILOT TONE SQUELCH .............................................................................................................................................. 22
ANTENNAS AND RF SIGNAL STRENGTH ................................................................................................................ 22
AUDIO SIGNAL QUALITY ............................................................................................................................................ 23
SPECIFICATIONS AND FEATURES .......................................................................................................... 24
SERVICE AND REPAIR ............................................................................................................................... 25
LIMITED ONE YEAR WARRANTY .............................................................................................................. 28
4
UHF Wireless Digital HybridTM Receiver

GENERAL TECHNICAL DESCRIPTION

The UCR511 is a portable, high performance, triple­conversion, frequency synthesized, UHF receiver fully compatible with all Lectrosonics 500 series transmitters (and some other transmitter types – see Compatibility Modes for details.) The RF performance is extremely stable over a very wide temperature range, making the UCR511 perfectly suited to the rough environmental conditions found in the field. The proprietary audio processing includes a digital signal processor for very low distortion and a superior signal to noise ratio.
The UCR511 features a menu-driven LCD graphic display and three control buttons to conveniently view and alter user settings. The main window, for example, displays the pilot tone indicator, antenna diversity phase, RF level, audio level, receiver battery status and trans­mitter battery status. It is also possible to bypass the pilot tone/squelch from the main display window. Other display windows show operating frequency, audio output level, battery voltage and test tone status. The fre­quency scan mode provides a spectrum analyzer for a graphical means of observing all signals “on the air” within the frequency range of the receiver in order to find operating frequencies that are free of interference.
COMPATIBILITY MODES
The UCR511 receiver was designed to operate with Lectrosonics 500 Series transmitters and will yield the best performance when doing so. However, due to the flexibility of digital signal processing, the UCR511 is also able to operate with Lectrosonics 300 Series, Lectroson­ics 100 Series, and certain non-Lectrosonics transmitters in special compatibility modes.
DIVERSITY RECEPTION
The UCR511 technology with SMART Diversity™ mini­mizes dropouts in situations where multi-path reflections can cause serious problems. The phase diversity network and PIN diode RF switches are controlled by the microprocessor using a sophisticated algorithm to use both antennas simultaneously. This design keeps the receiver compact enough for camera mounting or
shoulder bag applications, yet provides effective diversity reception.

RF FREQUENCY TRACKING FRONT-END AND MIXER

The receiver is frequency agile and can be set to operate on any one of 256 frequencies within its tuning range. To significantly reduce unwanted interference and inter­modulation problems, the UCR511 has a frequency selective front-end section that tracks and tunes to the desired signal frequency and rejects or “tunes out” unwanted interfering signals. The design consists of four varactor tuned ceramic transmission line resonators controlled by the microprocessor to provide excellent selectivity. The low noise high current RF amplifier was designed with feedback regulation for stability and precise gain in order to handle stronger RF signals without output overload. The first mixer is of new GaAs technology that has a very high third order intercept point. This produces a robust front-end that is as selec­tive as fixed single frequency designs and is suitable for use in close proximity to other receivers and transmitters commonly used in field production “bag” systems.

MICROCONTROLLER, PLL AND VCO CIRCUITS

The 8-bit microprocessor is truly the “heart” of the UCR511 receiver. It monitors user command inputs from the front panel control buttons and numerous other internal signals such as RF level, audio levels, pilot tone levels and external/internal power voltages. Outputs from the microcontroller drive the LCD display and backlight, control the squelch and audio output attenua­tor, and operate the front-end tuning, the PLL/VCO circuits and the antenna phase switch. The UCR511 design and the advanced technology of the microproces­sor control arguably set a new standard in wireless microphone development.

IF AMPLIFIERS AND SAW FILTERS

The first IF low noise amplifier is controlled with feed­back regulation and drives the first of two quartz SAW
RF MODULE
ANTENNA
COMBINING
uP uP
LCD
Display
Panel
Smart Diversity
FILTER
PLL
SYNTHESIZER
CERAMIC
HI-LEVEL
MIXER
SAW
FILTER
244 MHz
IF AMP
PILOT TONE
DETECT
Attenuation
FILTER
MIXER
10.7 MHZ
SAW
FILTER
244 MHz
AMP
LC
Filter
1st
FILTER
VCO
2
E PROM
uP
FILTER
IF AMP
2nd
VCO
FILTER
Rio Rancho, NM – USA
XTAL
CONTROLLED
3rd
OSCILLATOR
2ND
3RD MIXER
AND
IF AMP
COUNTING DETECTOR
50KHz
LP FILTER
A-D
CONVERTER
DIGITAL SIGNAL
PROCESSOR
D-A
CONVERTER
UCR511
BLOCK DIAGRAM
Output
Level
Adjust
AUDIO
AMP
Digital
Attenuator
XLR OUT
50
5K
1 (COMMON)
5K
50
2 (HI)
3 (LO)
5
UCR511
(Surface Acoustical Wave) filters. The 244 MHz SAW filters combine sharp tuning, constant group delay, wide bandwidth and excellent temperature stability, far supe­rior to conventional LC filters. The 244 MHz first IF signal is converted down to 10.7 MHz, filtered through two ceramic filters for sharp selectivity, then converted to 300 kHz.

DIGITAL PULSE COUNTING DETECTOR

The UCR511 receiver uses an elegantly simple, yet highly effective digital pulse detector to demodulate the FM signal, rather than a conventional quadrature detec­tor. This unusual design eliminates thermal drift, im­proves AM rejection, and provides very low audio distortion.

DSP-BASED PILOT TONE

The above description applies only in 500 Series mode. In 300 Series mode, only one pilot tone frequency is used on all channels, emulating the original crystal-based system. In other compatibility
modes, no pilot tone is used.
The 500 Series system design uses a DSP generated ultrasonic pilot tone to control the receiver audio muting (squelch). Brief delays (preset into the UCR511 cir­cuitry) eliminate thumps, pops or other transients that can occur when thewhen the associated 500 Series transmitter is turned on or off. The pilot tone frequency is different for each of the 256 frequencies in the tuning range of a system (frequency block.) This eliminates squelch problems in multichannel systems where a pilot tone signal can appear in the wrong receiver via inter­modulation products. The DSP generated pilot tone also eliminates the need for fragile crystals, allowing the receiver to survive shocks and mishandling much better than older analog-based pilot tone systems.
SMART SQUELCH
The UCR511 employs a sophisticated squelching system in an attempt to deliver the cleanest possible audio during marginal conditions of reception. Any squelching system faces inevitable trade-offs: squelch too much and valuable audio information may be lost, squelch too little and excessive noise may be heard; respond too rapidly and the audio sounds “choppy,” respond too sluggishly and syllables or entire words can be cut off.
The UCR511 combines several techniques to achieve an optimal balance, removing distracting noise, without the squelching action itself becoming a distraction. One of these techniques involves waiting for a word or syllable to complete before squelching. Another incorporates recent squelching history and recent signal strength, adjusting squelching behavior dynamically for the most serviceable result under variable conditions. Using these
Note
and other techniques, the UCR511 can deliver accept­able audio quality from otherwise unusable signals.
In the Pilot Tone Bypass mode, the squelch system is disabled. Received audio remains unmuted at all times with this setting. (See Front Panel Controls and Func­tions.)

SMART NOISE REDUCTION (SmartNR™)

The SmartNR setting is user selectable only in 500 Series mode. In other modes, noise reduction is applied in such a way as to emulate the original analog system as accurately as possible and is not user
The UCR511 has been meticulously designed using the best available low noise components and techniques. Nonetheless, the wide dynamic range of digital hybrid technology, combined with flat response to 20 kHz, makes it possible to hear the -120 dBV noise floor in the mic preamp, or the (usually) greater noise from the microphone itself. (To put this in perspective, the noise generated by the recommended 4 k Ohm bias resistor of many electret lavaliere mics is –119 dBV and the noise level of the microphone’s electronics is much higher.) In order to reduce this noise and thus increase the effective dynamic range of the system, the UCR511 is equipped with a Smart Noise Reduction algorithm, which removes hiss without sacrificing high frequency response.
The Smart Noise Reduction algorithm works by attenuat­ing only those portions of the audio signal that fit a statistical profile for randomness or “electronic hiss”. Because it isn’t simply the same sophisticated variable low pass filter as in Lectrosonics’s 300 Series designs, much greater transparency is thus obtained. Desired high frequency signals having some coherence such as speech sibilance and tones are not affected.
The Smart Noise Reduction algorithm has three modes, selectable from a user setup screen - OFF/NORMAL/
FULL.
OFF, no noise reduction is performed and
complete transparency is preserved. All signals presented to the transmitter’s analog front end, including any faint microphone hiss, will be faithfully reproduced at the receiver.
NORMAL, the factory default setting, enough noise reduction is applied to remove most of the hiss from the mic preamp and some of the hiss from lavaliere microphones. The noise reduction benefit is dramatic in this position, yet the degree of transparency maintained is exceptional.
FULL, enough noise reduction is applied to remove most of the hiss from nearly any signal source of reasonable quality, assuming levels are set properly at the transmitter. This additional noise reduction comes at the cost of some transparency for low-level room noise, yet the
Note
adjustable.
6
UHF Wireless Digital HybridTM Receiver
algorithm remains undetectable under most circumstances.

RF-CONTROLLED DIGITAL NOISE FILTER

In addition to SmartNRTM, the UCR511 contains an RF sensitive variable frequency filter, which reduces high frequency response under extremely weak RF condi­tions. This filter does nothing until the RF signal strength drops below 3 uV at which point it begins to roll off high frequencies. Usable audio remains unaffected, but noise-ups or “hits” occurring near the fringe of reception sound much less harsh.

OUTPUT LEVEL ADJUST

One of several setup screens is provided for adjusting the audio output level in 1 dB steps from -50 to +5 dBu using the SEL Up and Down buttons on the front panel.

TEST TONE

To assist in matching the audio levels of equipment connected to the UCR511, a 1 kHz audio test tone, adjustable from -50 to +5 dBu in 1 dB increments, is available at the XLR connector. This tone is available through the TONE display window.

BATTERIES

The UCR511 operates on two 9 V alkaline or lithium batteries. Access to the battery compartment is gained by lifting one end and turning the rear panel door.
Do not use an alkaline and a lithium in the same unit. Standard or
“heavy duty” batteries are not recommended.
Note

POWER SUPPLY

The UCR511 may be operated from an external (Nega­tive Ground) DC power source (see Specifications and Features section for allowed voltages.) The receiver has a built-in Poly-Fuse to protect the unit. This fuse resets if the power supply is disconnected for about 15 seconds. The power section also has protection circuits that prevent damage to the receiver if a positive ground power source is applied.

LCD DISPLAY

The display has four primary windows: Main, Setup, Battery Level, Frequency. Pressing the MENU button rotates through each of these windows.
If the battery gets low on either transmitter or receiver, a message will interrupt the display every few seconds and flash a low battery warning.
After power is turned off and back on again, the unit defaults to the Main Window and to the most recent frequency, audio level, transmitter battery type and other user settings. These settings are retained even if the batteries are removed. After five minutes of no key activity, the LCD backlight goes off and the display reverts back to the Main Window.

POWER UP SEQUENCE

The power up sequence consists of four messages that appear automatically over a period of a few seconds after the power is switched on.
1) UCR511 BLK xx (xx is the frequency block number)
2) VERSION
3) COMPAT mode (mode is one of the following:
500 - native 500 Series mode 100 - Lectrosonics 100 Series compatibility 300 - Lectrosonics 300 Series compatibility MODE 3 - compatible with certain non-
IFB - compatible with all Lectrosonics IFB
4) TUNING mode (mode is one of the following:
NORMAL - tune in single channel increments GRP x - tune in precoordinated intermod-free frequencies (x is A, B, C or D))
The Main Window will appears after these introductory messages are displayed.
The UCR511 is fully operational during the power up sequence and will immediately respond to button pushes made before the automatic sequence is completed. If a valid transmitter signal is already present when the receiver is turned on, the audio output will typically be engaged somewhere in the middle of the power-up sequence, following a brief delay to allow the audio circuits to stabilize.
R.R/A.A (R.R is the RF board firmware version, A.A is the audio board firmware version)
Lectrosonics transmitters)
transmitters.

POWER OFF

When the Front Panel Power ON/OFF switch is moved to the OFF position the audio output is instantly muted (squelched) and the message “POWERING OFF...” is displayed briefly before switching off.
Rio Rancho, NM – USA
7
UCR511
Pilot
Div RF Aud Rx Tx
BAT
-40 -20 0 dB
1000
100
10
1
uV
OFF
ON

MENU

SEL
1 2
LECTRO
UCR 5 1 1

FRONT PANEL CONTROLS AND FUNCTIONS

SEL Up
LCD
MENU
SEL Down

SEL Up/Down

The SEL Up and Down pushbutton switches are used in conjunction with the MENU pushbutton to move through the submenus and set operating conditions and param­eters. (See also Menu Selections From Main Window.)
MENU
The MENU pushbutton is used to rotate through the various set up menus of the UCR511.(See also Menu Selections From Main Window.)

REAR PANEL FEATURES

BATTERY DOOR
To open lift this edge and turn door
AUDIO
OUT
1 2
Power OFF/ON

POWER ON/OFF

The Power ON/OFF switch is used to apply or remove power from the UCR511.
LCD
The LCD is used to provide feedback to the user on menu selections and system operating conditions.
Audio Output XLR Jack
10-18
VDC
3
Power Input Connector

XLR AUDIO OUTPUT JACK

This is a standard XLR configuration with pin 2 “positive” with reference to hand-held and plug-on transmitters. With lavalier microphones and belt-pack transmitters, however, phase will vary with different types of micro­phones (2-wire vs. 3-wire for example). The audio output is balanced but not floating, so an unbalanced signal is available using pin 1 as ground and pin 2 as signal,
UCR511 Simplified Audio Output
Output
Level
Adjust
AUDIO
AMP
8
25V
Non-Polar
Caps
5K
5K
XLR OUT
50
1 (COMMON)
50
2 (HI)
3 (LO)
leaving pin 3 open. (See Installation and Operating Instructions.)

POWER INPUT JACK

The power input jack can accept 10-18 VDC - the center pin is positive and sleeve is ground. The input is diode protected to prevent damage if the power is applied with reversed polarity, but the unit will not work until the condition is fixed. Strain relief to avoid accidental disconnection can be provided with the included small
UHF Wireless Digital HybridTM Receiver
Pilot
Div RF Aud Rx Tx
BAT
-40 -20 0 dB
1000
100
10
1
uV
OFF
ON
MENU
SEL
1 2
LECTRO
UCR 5 1 1

MAIN WINDOW (LCD)

RF levels - reference for RF
level screen icon
The Main Window displays information concerning the condition of the Pilot Tone, antenna phase, RF and audio signal levels and battery conditions for both the receiver and the associated transmitter. It is also the access
Icon Description

PILOT TONE INDICTOR

A steady “P” icon will be displayed when a pilot tone from the transmitter is present. (The “P” will appear only in those compatibility modes which use pilot tone: 300 Series and the native 500 Series mode.) The icon will flash if no pilot tone is detected and will change to a small “b” if the pilot tone has been bypassed. To bypass the pilot tone, hold MENU and press the UP button. Hold MENU and press UP again to restore normal pilot tone squelch. Bypassing the pilot tone also disables the squelch, so the “pilot tone bypass” function has an effect even in those compatibility modes that do not use pilot tone.
Audio Levels - reference levels for audio signal
modulation from transmitter
LCD
portal to menu selections for setting up the receiver and searching for clear frequency channels. (See Menu Selections from Main Window and Frequency Scan Mode.)

ANTENNA PHASE INDICATOR

This icon shows antenna phase switching activity. As the antenna phase is switched, the symbol will flip
vertically.

RF LEVEL

This icon changes in size vertically to indicate the strength of the incoming RF signal. RF levels are engraved from 1uV to 1000uV on the bezel to the left of the LCD.

AUDIO LEVELS

This icon changes in size horizontally to indicate the audio level (modulation) of the signal received from the transmitter. The icon display will change to a solid rectangular block when the audio signal is being limited in the transmitter. Levels in dB are engraved into the bezel above the LCD.

BATTERY LEVELS

The icon above the Rx symbol indicates the receiver battery condition and will flash when approximately one hour of operating time is remaining. When external power is being used, the Rx battery icon changes to look like a power plug. The area above the Tx symbol features either a transmitter battery status icon or the transmitter battery timer, depending on the TXBAT setting. The transmitter battery status icon is available only in compatibility modes supporting battery telemetry (500 and 300 Series). In such cases, the transmitter battery status icon appears 5 to 10 seconds after the transmitter signal is acquired. If selected in the TXBAT setup screen, the transmitter battery timer is available in any compat­ibility mode. It accumulates hours and minutes that the communications link is active, retaining the timing even when the receiver is off. To reset the battery timer, hold MENU and DOWN together for one second.
Rio Rancho, NM – USA
9
UCR511

MENU SELECTIONS FROM MAIN WINDOW

SETUP
Press
UP
Press
UP
TX BAT
Press
UP
Press
UP
Press
UP
TUNING
Press
UP
COMPAT
LEVEL
SETUP
TONE
SETUP
SETUP
PHASE
SETUP
SmtNR
SETUP
SETUP
P
r
e
s
s
U
P
Press MENU
Press MENU
Press MENU
Press MENU
Press MENU
Press MENU
Press MENU
Level
LEVEL
00 dBu
(Press UP / DOWN to adjust)
Audio Test Tone
TONE?
00 dBu
(Press UP / DOWN to select)
(Press UP / DOWN to select)
(Press UP / DOWN to select)
(Press UP / DOWN to select)
(Press UP / DOWN to select)
Press UP
Tx Battery Type
TXBAT
9V ALK
Output Phase
PHASE
INVERT
Noise Reduction
SmtNR
NORMAL
Tuning Mode
TUNING NORMAL
Compatibility Mode
COMPAT
500
Pilot Off/On
Press UP
Press MENU
Audio Test Tone
LVL 1K 00 dBu
(Press UP / DOWN to adjust)
Press MENU
Press MENU
Press MENU
Press MENU
Press MENU
Press MENU
Hold MENU & press UP

Setup Window

SETUP
EXIT
Main Window
U
N
E
M
s
s
e
r
P
P
r
e
s
s
M
E
N
U
TX 7.2V RX 8.2V
Battery Level
Window
P
r
e
s
M
s
s
e
r
P
Press All Buttons
Press & Hold MENU
s
M
E
N
U
U
N
E
Frequency
TV41 AE
631.800
Window
Frequency
Scan Mode
SELECT
Lock/Unlock
From the Main Window, you can navigate to the Fre­quency, Battery Level and Setup windows in a circular sequence by pressing the MENU button.

FREQUENCY WINDOW

TVxx - which television broadcast
channel this frequency falls within.
Transmitter switch settings (AE in the illustration) - these are the
correct switch settings for the frequency switches on your transmitter - see your transmitter instructions.
Frequency - Press the SEL Up or Down buttons to change the frequency of the receiver.
Note
Be certain to change the transmitter frequency select switches to
match the settings shown in the upper right hand corner of the
Frequency Window display.
When the TUNING mode is set to NORMAL, the SEL Up or Down buttons tune in single channel increments. In the group tuning modes, the UP and DOWN buttons move among the selected intermod-free frequencies.
10
TV41 AE
631.800
Tuning short-cuts: In NORMAL tuning mode, MENU+Up and MENU+Down tune in 16 channel increments for faster tuning. In the group tuning modes, MENU+Up jumps to the first frequency in the group and MENU+Down jumps to the last one in the group.

BATTERY LEVEL WINDOW

This window shows the transmitter (TX) and receiver (RX) battery voltage. These levels will flash when the voltages drop below suggested opti­mum working levels. Typically, there
TX 7.2V RX 8.2V
will be about one hour operating time remaining after the indicators begin to flash. The RX voltage changes to EX when operating on external power and displays the external power source voltage. (
guarantee 0.1 Volt accuracy.
)
Disclaimer: We don’t
SETUP WINDOW
In the SETUP window, the SEL Up or Down buttons scroll through a list of eight possible destinations: EXIT,
SETUP
EXIT
UHF Wireless Digital HybridTM Receiver
LEVEL, TONE, TXBAT, PHASE, SmtNR (in 500 Series mode only), TUNING and COMPAT. Each of these destinations allows a variety of settings to customize the receiver operating parameters. Press MENU at the screen shown here to return to the main window.

LEVEL

The LEVEL setup screen shows the audio output level of the receiver in dBu. Use the SEL Up or Down buttons to change the level. Range is from -50 to +5 dBu in 1 dB steps. Press MENU to leave this screen.
LEVEL
-50 dBu

TONE

The TONE setup screen enables an audio test tone at the receiver output for precise level matching with other equipment. The first screen prompts you to press the UP button to enable the tone at the receiver output jack. The next screen that appears allows the level to be adjusted in 1dB steps using the SEL Up or Down buttons. When the audio test tone is enabled, the received audio is muted and an internally generated 1 kHz test tone is routed to the XLR connector. Since there is only one audio output level setting for both received audio and tone, the level set here will be retained in the receive mode (it will supersede the setting made in the LEVEL setup screen). The test tone has 1% distortion and is intended for confirmation of output levels only. To exit the test tone screen and stop the tone press the MENU button.
TONE? 00 dBu
LVL 1K 00 dBu

TXBAT

The TXBAT setup screen allows you to select the exact battery being used in the transmitter to provide more accurate battery level monitor­ing. Four different types of batteries are commonly used in Lectrosonics transmitters: 9 Volt alkaline, 9 Volt lithium, AA alkaline, and AA lithium. Correctly set, this will ensure that adequate warning will be provided in ad­vance of battery failure. Press MENU to leave this screen.
In native 500 Series mode as well as in the 300 Series compatibility mode, the TXBAT menu offers six choices:
9V ALK - Transmitter uses a 9V alkaline battery. Monitor voltage with battery icon in main window.
9V LTH - Transmitter uses a 9V lithium battery. Monitor voltage with battery icon in main window.
9V TIM - Transmitter uses a 9V battery. Display its voltage normally in the battery level window but monitor its status with the battery timer in the main window.
AA ALK - Transmitter uses a AA alkaline battery. Monitor voltage with battery icon in main window.
TXBAT
9V ALK
AA LTH - Transmitter uses a AA lithium battery. Monitor voltage with battery icon in main window.
AA TIM - Transmitter uses an AA battery. Display its voltage normally in the battery level window but monitor its status with the battery timer in the main window.
The 9V TIM and AA TIM settings are most useful for NiMH batteries as they do not exhibit reliably identifiable voltage drops as they discharge.
In compatibility modes other than 500 Series and 300 Series, no battery telemetry information is available so the TXBAT setup screen offers only two choices:
NOTIMER - Display no transmitter battery status in the main window.
TIMER - Monitor the transmitter battery status with the battery timer in the main window. To reset the timer, hold MENU and DOWN for one second.

PHASE

The output PHASE setup screen allows the audio output phase to be inverted. The SEL Up or Down buttons can be used to toggle between normal and inverted phase. Press MENU to leave this screen.
PHASE
INVERT

SmtNR

The SmtNR setup screen (available in 500 Series compatibility mode only) places the Smart Noise Reduc­tion algorithm in one of three modes. In the OFF position, no noise reduc­tion is applied, for complete transpar­ency. In the NORMAL position (factory default setting), a moderate amount of noise reduction is applied, dramatically reducing hiss with virtually no discernible side effects. In the FULL position, the transpar­ency is superior to the Lectrosonics noise reduction system used for many years in the 300 series sys­tems. Try switching between the three modes to decide what setting is correct for your application. Refer to the Smart Noise Reduction section in the GENERAL TECHNICAL DESCRIPTION chapter for more detailed information about this feature.
SmtNR
NORMAL
SmtNR
FULL
SmtNR
OFF

TUNING

The Tuning Setup Screen allows selection of one of four factory set frequency groups (Groups A through D), two user programmable fre­quency groups (Groups U and V) or the choice to not use groups at all.
In the four factory set frequency groups, eight frequen­cies per group are preselected. These frequencies are chosen to be free of intermodulation products. (See Frequency Coordination.)
TUNING NORMAL
Rio Rancho, NM – USA
11
UCR511
In the two user programmable frequency groups, up to 16 frequencies can be programmed per group.
The Tuning Setup Screen only selects the tuning mode (NORMAL or
Group Tuning) and not the operating frequency. Actual operating
frequencies are chosen through the Frequency Window.
Note
If NORMAL tuning mode is selected, the SEL Up and Down buttons select the operating frequency in single channel (100 kHz) increments and the MENU+Up and MENU+Down shortcuts tune in 16 channel (1.6 MHz) increments.
There are two group tuning modes: factory present groups (Grp A through D) and user programmable frequency groups (Grp U and V).
In these modes, the SEL Up and Down buttons navigate among the selected intermod-free frequencies in the group and the MENU+Up and MENU+Down shortcuts jump to the first and last frequencies in the group.
Also, a lower case a, b, c, d, u or v will be displayed to the immediate left of the transmitter switch settings in the Frequency Window. The letter identifies the selected factory or user tuning group.
Any time the currently tuned frequency is not in the current tuning group, the group tuning mode indicator will blink. Any time the currently tuned frequency is in the current turning group, the group tuning mode indica­tor will give a steady (non-blinking) indication.
If a factory tuning group has been selected, pressing either the SEL Up or Down button will select the nearest factory selected frequency in that group above or below the current frequency.

User Programmable Frequency Group Behavior

The user programmable frequency groups work very similar to the factory groups with a few exceptions. The most obvious difference is the ability to add or remove frequencies from the group. Less obvious is the behav­ior of a user programmable frequency group with only one, or no entries.
A user programmable frequency group with only one entry will only display that one frequency regardless of how many times the SEL Up or Down buttons are pressed (providing the MENU button is not pressed at the same time).
A user programmable frequency group with no entries reverts to non-group-mode behavior, i.e., access is allowed to all 256 available frequencies in the selected
receiver module's frequency block. However, once a frequency has been added to the tuning group, this behavior changes to group-mode behavior where the MENU button must be pressed and held while either the SEL Up or Down buttons are pressed to access frequen­cies that are not part of the current tuning group.

Adding/Deleting User Programmable Frequency Group Entries

Each User Programmable Frequency Group (“u” or “v”) has
separate contents. It is suggested to review the section titled
Frequency Coordination prior to adding frequencies inorder to
minimize potential intermodulation problems.
Note
1. Start from the Frequency Window and verify that a lower case “u” or “v” is present next to the transmitter switch settings.
2. While pressing and holding the MENU button press either the SEL Up or Down button to move to one of the 256 available frequencies in the block. Whenever the selection comes to rest on a frequency that is in the current group, the group tuning mode indicator (letter "u" or "v") will give a steady indication. On frequencies that are not in the group, the indicator will blink.
3. To add or remove the displayed frequency from the group, hold down the MENU button while pressing and holding the SEL Up button. The group tuning mode indicator will stop blinking to show that the frequency has been added to the group, or begin blinking to indicate that the frequency has been removed from the group.T

COMPAT

The COMPAT setup screen selects the type of transmitter used with the UCR511. The available modes are:
500 - Lectrosonics 500 Series.
This is the default setting and should be used if your transmitter supports it. This mode offers the best audio quality.
100 - Lectrosonics 110 Series compatibility mode.
300 - Lectrosonics 300 Series compatibility mode.
MODE 3 - Compatible with certain non-Lectrosonics
transmitters.
IFB - Compatible with Lectrosonics IFB transmitters.
COMPAT
500
12

FREQUENCY SCAN MODE

Press All 3 Buttons
Fine View
B8
P
e
r
M
s
s
Scan
u
n
e
Press Menu
UHF Wireless Digital HybridTM Receiver
B8
P
r
e
s
s
A
n
y
B
u
t
t
o
n
View
B8
To use the integrated scanning function, press both UP/ DOWN buttons and the MENU button at the same time. The display will switch to the SCAN WINDOW and start scanning immediately. Data gathered during a scan is stored until it is purposely erased or the power is turned off. Previous data will remain and subsequent scans can be made to search for additional signals or to accumu­late higher peaks.
Scan & VIEW WINDOW Elements
Cursor - shows relative position of the scanner within the 25Mhz band of the receiver.
Switch Settings - shows the transmitter switch settings - will change rapidly while the unit is scanning.
B8
Scan level indications
showing relative level of RF activity across the 25MHz bandwidth of the receiver.
-
To stop scanning, press the MENU button once. The scanning will stop immediately, and the display will switch to the VIEW window. In this window, each vertical band of the display represents eight frequencies (800 kHz). Pressing the SEL Up or Down buttons will scroll the cursor coarsely across the tuning range. The trans­mitter switch settings matching the frequency indicated by the cursor are shown in the upper right corner of the screen.
Spectrum data is collected only when the receiver is scanning. Successive scanning with repeated passes through the tuning range will accumulate the highest peaks encountered to aid in finding clear frequencies. To clear the scan memory without leaving scan mode, turn the power switch off and back on quickly.
Pressing the MENU button once will shift the display to the FINE VIEW window which will show an expanded portion of the spectrum around the cursor.
In the FINE VIEW window, each vertical band represents one frequency the UCR511 is capable of tuning. The upper right corner shows the transmitter switch settings
Remaining unscanned part of band.
for the frequency indicated by the cursor. In this screen, a vertical center bar is the cursor. Underneath the switch settings are two arrows to remind you that this is a partial picture of the spectrum and that you can scroll left or right to view the entire spectrum of the receiver by pressing the SEL Up or Down buttons.
Fine VIEW WINDOW Elements
Transmitter
Cursor (center bar)
Switch Settings
B8
RF Level indicators
Pressing the SEL Up button will make the display scroll left, showing higher frequencies. Pressing the SEL Down button will make the display scroll right, showing lower frequencies. The cursor remains in place while the display scrolls left or right
In addition to assessing the congestion within the RF tuning range of the receiver, the scanning mode is also used to find a clear operating frequency. Scroll through the screen and find a frequency where no RF signals are present (or in the worst case, only very weak RF sig­nals). With the cursor on this frequency, press the SEL Up, SEL Down and MENU buttons at the same time to leave the scan mode.
When leaving the scan mode, you are given the option of using the frequency the unit was on before entering the scan mode, or using the frequency just selected in the scan mode. The display shows USE OLD and USE NEW to prompt you to make a frequency selection. To accept the new frequency just selected in the scan mode, press the DOWN button for USE NEW. To return to the frequency you were using before entering the scan mode, press the UP button for USE OLD. (The MENU button defaults to USE OLD).
Once you leave the scan mode, the Frequency Window will be displayed. Set your transmitter switches to the same settings as shown on the display and your system will be ready for operation.
SCROLL reminders
Rio Rancho, NM – USA
13
UCR511

ANTENNA USE AND PLACEMENT

The receiver is supplied with two straight BNC antennas. In some circumstances remote antennas such as the SNA600 or ALP700 may be useful for improving recep­tion. Position remote antennas at least three or four feet apart and so that they are also not within three or four feet of large metal surfaces. If this is not possible, try to position the antennas so that they are as far away from the metal surface as is practical. It is also good to position the receiver so that there is a direct “line of sight” between the transmitter and the receiver antenna. In situations where the operating range is less than about 100 feet, the antenna positioning is much less critical. The antennas can also be configured with one whip mounted directly onto the panel of the receiver, and the other one mounted remotely.
Be careful about the length of cabling from antenna to receiver.
Long cable runs can have serious signal loss. Lectrosonics has in-
line RF amplifiers suitable for compensating for long cable runs.
Contact your dealer or the factory for more information.
Note
A wireless transmitter sends a radio signal out in all directions. This signal will often bounce off nearby walls, ceilings, etc. and a strong reflection can arrive at the receiver antenna along with the direct signal. If the direct and reflected signals are out of phase with each other a cancellation may occur. The result would be a
“dropout.” A dropout sounds like either audible noise (hiss), or in severe cases, may result in a complete loss of the carrier and the sound when the transmitter is positioned in certain locations. A UHF dropout normally sounds like a very brief “hiss” or a “swishing” sound. Moving the transmitter (or the receiver’s antennas) even a few inches will change the sound of the dropout, or eliminate it. A dropout situation may be either better or worse as the crowd fills and/or leaves the room, or when the transmitter or receiver is operated in a different location.
The receiver offers a sophisticated diversity design which overcomes dropout problems in almost any situation. In the event, however, that you do encounter a dropout problem, first try moving the receiver’s antennas at least three or four feet from their original location. This may alleviate the dropout problem at that location. If dropouts are still a problem, try moving the unit to an entirely different location in the room or moving the receiver if antennas are attached, or the receiver’s antennas in closer to the transmitter location.
Lectrosonics transmitters radiate power very efficiently, and the receivers are very sensitive. This reduces dropouts to an insignificant level. If, however, you do encounter dropouts frequently, call the factory or consult your dealer. There is probably a simple solution.
TRANSMITTER
PHASE CANCELLATION
REFLECTIVE SURFACE
INDIRECT SIGNAL
DIRECT SIGNAL
RECEIVER
DIRECT SIGNAL
INDIRECT SIGNAL
14
MULTI-PATH DROPOUT
UHF Wireless Digital HybridTM Receiver

INSTALLATION AND OPERATING INSTRUCTIONS

1. Install a fresh battery or connect an external
power source to the UCR511 and attaach the antennas.
2. Unless frequency settings have been previously assigned, scan for an open frequency and set both the receiver and transmitter to that frequency. (See Finding Clear Frequencies.)
3. Connect the audio cable to the Receiver Audio Out XLR jack.
4. Set the Power ON/OFF switch to ON and verify that the LCD panel activates.
5. Adjust the transmitter gain.
THIS IS PERHAPS THE MOST IMPORTANT STEP IN THE SET UP PROCEDURE.
Refer to your transmitter manual’s Operating Instructions section for details on how to adjust the transmitter gain. In general, adjust the transmitter gain so that the voice peaks will cause the audio modulation indicators on the receiver and transmitter to show full modulation on the loudest peak audio levels. Normal levels should cause the UCR511’s audio level icon to fluctuate fully. This will result in the best possible signal to noise ratio for the system.
A common mistake at this point is to use the transmitter audio gain
control to set the overall audio level of the entire audio system. The
transmitter gain control is not a volume control and must be set
independently of the overall system audio level. The transmitter
gain control is only used to set the proper modulation of the
transmitter. To explain it another way, it is used to match the
transmitter to the type of microphone and the sound levels that will
be present at that microphone. We encourage users to either
disconnect the rest of the sound system or turn the sound system
gain to minimum to prevent feedback or overload as the transmitter
gain is set. That way, feedback from the sound system or overload of
other equipment does not get in the way of setting the transmitter
gain properly. Only after the transmitter gain control is set should
the gain of the rest of the audio system be adjusted to achieve the
desired sound or signal levels.
Note
6. Adjust the Audio Output according to the type of input on your equipment. Use the LEVEL menu and adjust the level with the SELECT Up and Down buttons The input levels of different cameras, VCRs, and PA equipment vary, which may require that you adjust the AUDIO OUT to an intermediate position. Try different settings and listen to the results. If the output of the receiver is too high, you may hear distortion or a loss of the natural dynamics of the audio signal. If the output is too low, you may hear steady noise (hiss) along with the audio. The UCR511 audio output is designed to drive any audio input
Output
AUDIO
AMP
Level
Adjust
Squelch
Non-Polar
25V
Caps
50
2K
2K
50
XLR OUT
2 (HI)
1 (COMMON)
3 (LO)
UCR411a Simplified Audio Output Circuit
device from microphone level to +10 dBu line level.
The test tone output is especially useful for an exact level match.
With the test tone running, adjust for the maximum desired peak
level using the metering on the connected device.
Note

FINDING CLEAR FREQUENCIES

The folllowing procedure will help you identify RF signals in the area and find clear channels for operating the wireless system.
1. Ensure transmitter is turned off. Turn on the receiver and wait a few seconds until the Main Window appears on the LCD
Pilot Tone Indicator
Pilot
-40 -20 0 dB
1000
100
10
1
uV
2. Ensure the receiver is not in PILOT TONE BYPASS mode. (A “P” will be blinking in the upper left corner of the Main Window.)
1 2
Pilot
10
1
Div
LECTRO
-40 -20 0 dB
RF Aud Rx Tx
SEL
1000
100
uV
Press all three buttons at the same time and the
receiver will start scanning.
3. Simultaneously press the MENU and SELECT Up and Down buttons to enter Scan Mode.
4. View the LCD while the receiver is scanning. The vertical marker will move across the
BAT
BAT
MENU
ON
OFF
Rio Rancho, NM – USA
15
UCR511
Vertical marker moves left to right
Scan
1000
100
10
uV
1
B8
RF activity
Strength of RF activity is
indicated in microvolts with
markings on the front panel
display from left to right. RF activity will be indicated by dark areas in the display.
5. RF signal strength is indicated by markings in microvolts on the front panel to the left of the LCD. Look for clear channels in the spectrum
Scan
1000
100
10
uV
1
B8
in scanning.
Press the SEL Up arrow button to select USE OLD and return to the frequency that was set before scanning.

LOCKING AND UNLOCKING THE UCR511 FRONT PANEL CONTROLS

1 2
Pilot
1000
100
SEL
Use the SEL Up and Down arrow buttons to select the old
-40 -20 0 dB
10
1
uV
RF Aud Rx Tx
Div
LECTRO
or new frequency.
BAT
MENU
OFF
ON
No RF activity (clear channel)
where there is no RF activity. Scanning will repeat and continue until a button is pressed.
B8
Fine adjustment can be made when zoomed closer
6. If necessary, press the MENU button to zoom in for greater detail for fine adjustment.
8. Then press the SEL Up and Down arrows to move the marker to the middle of a clear area
1000
100
10
1
uV
Move marker to area with no RF activity
B8
where there is no RF activity. If an area with no RF activity cannot be found anywhere in the spectrum, locate one with the least amount of RF activity.
9. Press all three buttons (SEL Up and Down and MENU) to move to the next screen. Two options will be shown.
Press the SEL Down arrow button to select the USE NEW option and set the receiver to the new frequency just found
.
The front panel panel controls can be “LOCKED” to prevent accidental changes being made during operation and handling.
To LOCK the UCR511 - Press and hold the MENU button until a bar tracks horizontally across the LCD screen and the word “LOCKED” appears. If the MENU button is released before the word “LOCKED” appears, the unit will remain UNLOCKED. When in a LOCKED state, the pilot tone bypass toggle is also defeated.
In LOCKED state, the use of the MENU and SEL Up/ Down buttons are limited to “view only” and any attempts to change selections will result in a LCD screen display­ing the word “LOCKED.” The unit cannot be used for RF scanning when it is set in the LOCKED state.
To UNLOCK the UCR511 - Press and hold the MENU button until a bar tracks horizontally across the screen and the word “UNLOCKED” is displayed on the LCD screen. When the unit is UNLOCKED, all settings can be altered.
The UCR511 can only be LOCKED or UNLOCKED from any of the main windows. (There are four of them.) Also, it cannot be switched between LOCKED and UNLOCKED modes when it is in a scanning mode or from other subordinate screens.
16

TO REPLACE THE BATTERIES

Lift and open the bottom battery door cover with your thumb, rotate the door until it is perpendicular with the case and allow the batteries to fall out of the compart­ment into your hand. It is difficult to install a battery backwards. Observe the large and small holes in the battery contact pad before inserting new batteries. Insert the contact end of the battery first, making sure the contacts are aligned with the holes in the contact pad, and then swing the door closed. You will feel it snap into place when it is fully closed.
UHF Wireless Digital HybridTM Receiver
Lithium batteries will expand and swell if allowed to go into a deep
CAUTION
discharge. Be sure to remove lithium batteries as soon as possible
after warnings. If lithium batteries are allowed to fully discharge
while still inside the battery compartment, they will be very difficult
to remove.
Stuck lithium batteries can be avoided by removing the label
wrapping around the battery before use. This will allow the battery
to swell but will still leave enough room in the compartment for the
battery to fall out normally.
1
To open the battery compartment door, push the door up and away from the case with your thumb, then swing open.
2
Rio Rancho, NM – USA
17
UCR511

Frequency Coordination

Intermodulation interference is a problem constantly lurking in the background, especially when working in environments were multiple productions are taking place simultaneously in relative close proximity. In these cases, proper frequency coordination is a must. There are basically three methods coordinate frequencies:
Use the Compatible Frequency Chart Scan for clear channels (See Frequency Scan Mode
and Using The Scan Function)
Call Lectrosonics

Compatible Frequency Chart

The Compatible Frequency Chart was designed to assist in minimizing intermodulation problems for multiple channel wireless systems. It does this by identifying potential intermodulation problems and listing compatible frequencies and frequency groups. This chart can be used with all Digital Hybrid Wireless
receivers.
The Compatible Frequency Chart divides the frequency blocks used in the North American market into Row 1 and Row 2, then further divides each row into two groups of eight frequencies each. These frequency groups are
Compatible Frequency Chart
labeled A and B and C and D, and correspond to the factory set frequency groups (Groups A, B, C and D) described in the Tuning Setup Screen. (See Compatible Frequency Chart.)
Understanding and using the Compatible Frequency Chart is not as difficult as it first appears. There are a few basic rules to follow:
Refer to the Compatibility Frequency Chart's Compatible and
Incompatible frequency combinations. (Only frequency blocks 21
and 22 are shown for illustrative purposes.)
Note

Rule No. 1

Row 1 and Row 2 live in two different worlds. The frequencies in Row 1 are not compatible with the fre­quencies in Row 2. If you are forced to use frequencies from Row 1 with frequencies from Row 2, be aware that intermodulation problems may exist.

Rule No. 2

Frequencies within an individual frequency block in the same row are compatible. For example, all 16 frequen­cies within Row 1, Block 21 are compatible, and all
Grp A
Grp B
ROW 1
Grp C
Grp D
ROW 2
BLOCK 21 BLOCK 22 BLOCK 23
FREQ SW SET US TV CH FREQ SW SET US TV CH FREQ SW SET US TV CH
538.100 0,5 tv25 563.700 0,5 tv29 589.300 0,5 tv33
538.700 0,B tv25 564.300 0,B tv29 589.900 0,B tv33
539.600 1,4 tv25 565.200 1,4 tv29 590.800 1,4 tv34
540.200 1,A tv25 565.800 1,A tv29 591.400 1,A tv34
541.500 2,7 tv25 567.100 2,7 tv30 592.700 2,7 tv34
542.400 3,0 tv26 568.000 3,0 tv30 593.600 3,0 tv34
542.900 3,5 tv26 568.500 3,5 tv30 594.100 3,5 tv34
543.700 3,D tv26 569.300 3,D tv30 594.900 3,D tv34
550.100 7,D tv27 575.700 7,D tv31 601.300 7,D tv35
552.300 9,3 tv27 577.900 9,3 tv31 603.500 9,3 tv36
553.000 9,A tv27 578.600 9,A tv32 604.200 9,A tv36
554.300 A,7 tv28 579.900 A,7 tv32 605.500 A,7 tv36
556.100 B,9 tv28 581.700 B,9 tv32 607.300 B,9 tv36
557.000 C,2 tv28 582.600 C,2 tv32 NOT AVAILABLE
559.600 D,C tv28 585.200 D,C tv33 NOT AVAILABLE
561.900 F,3 tv29 587.500 F,3 tv33 NOT AVAILABLE
FREQ SW SET US TV CH FREQ SW SET US TV CH FREQ SW SET US TV CH
544.500 4,5 tv26 570.100 4,5 tv30 595.700 4,5 tv34
545.100 4,B tv26 570.700 4,B tv30 596.300 4,B tv35
546.000 5,4 tv26 571.600 5,4 tv30 597.200 5,4 tv35
546.600 5,A tv26 572.200 5,A tv31 597.800 5,A tv35
547.600 6,4 tv26 573.200 6,4 tv31 598.800 6,4 tv35
548.800 7,0 tv27 574.400 7,0 tv31 600.000 7,0 tv35
549.300 7,5 tv27 574.900 7,5 tv31 600.500 7,5 tv35
549.900 7,B tv27 575.500 7,B tv31 601.100 7,B tv35
555.500 B,3 tv28 581.100 B,3 tv32 606.700 B,3 tv36
556.500 B,D tv28 582.100 B,D tv32 607.700 B,D tv36
557.000 C,2 tv28 582.600 C,2 tv32 NOT AVAILABLE
558.700 D,3 tv28 584.300 D,3 tv32 NOT AVAILABLE
559.400 D,A tv28 585.000 D,A tv33 NOT AVAILABLE
560.000 E,0 tv29 585.600 E,0 tv33 NOT AVAILABLE
560.700 E,7 tv29 586.300 E,7 tv33 NOT AVAILABLE
562.500 F,9 tv29 588.100 F,9 tv33 NOT AVAILABLE
BLOCK 24
FREQ SW SET US TV CH
614.900 0,5 tv38
615.500 0,B tv38
616.400 1,4 tv38
617.000 1,A tv38
618.300 2,7 tv38
619.200 3,0 tv38
619.700 3,5 tv38
620.500 3,D tv39
626.900 7,D tv40
629.100 9,3 tv40
629.800 9,A tv40
631.100 A,7 tv40
632.900 B,9 tv41
633.800 C,2 tv41
636.400 D,C tv41
638.700 F,3 tv42
FREQ SW SET US TV CH
621.300 4,5 tv39
621.900 4,B tv39
622.800 5,4 tv39
623.400 5,A tv39
624.400 6,4 tv39
625.600 7,0 tv39
626.100 7,5 tv40
626.700 7,B tv40
632.300 B,3 tv41
633.300 B,D tv41
633.800 C,2 tv41
635.500 D,3 tv41
636.200 D,A tv41
636.800 E,0 tv41
637.500 E,7 tv41
639.300 F,9 tv42
18
UHF Wireless Digital HybridTM Receiver
Compatible
The following frequency combinations have no intermodulation prob­lems.
Grp A
Grp B
ROW 1
Grp C
Grp D
ROW 2
BLOCK 21 BLOCK 22
FREQ SW SET US TV CH FREQ SW SET US TV CH
538.100 0,5 tv25 563.700 0 tv29
538.700 tv25 564.300 tv29
539.600 1,4 tv25 565.200 1,4 tv29
540.200 1,A tv25 565.800 1,A tv29
Grp A
541.500 2,7 tv25 567.100 2,7 tv30
542.400 3,0 tv26 568.000 3,0 tv30
542.900 3,5 tv26 568.500 3,5 tv30
543.700 3,D tv26 569.300 3,D tv30
550.100 7,D tv27 575.700 7,D tv31
552.300 9,3 tv27 577.900 9,3 tv31
553.000 9,A tv27 578.600 9,A tv32
554.300 A,7 tv28 579.900 A,7 tv32
Grp B
ROW 1
556.100 B,9 tv28 581.700 B,9 tv32
557.000 C,2 tv28 582.600 C tv32
559.600 D,C tv28 585.200 D,C tv33
561.900 F,3 tv29 587.500 F,3 tv33
FREQ SW SET US TV CH FREQ SW SET US TV CH
544.500 4,5 tv26 570.100 tv30
545.100 4,B tv26 570.700 B tv30
546.000 5,4 tv26 571.600 5,4 tv30
546.600 5,A tv26 572.200 5,A tv31
Grp C
547.600 6,4 tv26 573.200 6,4 tv31
548.800 7,0 tv27 574.400 7,0 tv31
549.300 7,5 tv27 574.900 7,5 tv31
549.900 7,B tv27 575.500 7,B tv31
555.500 B,3 tv28 581.100 B,3 tv32
556.500 B,D tv28 582.100 B, D tv32
557.000 C,2 tv28 582.600 C,2 tv32
558.700 D,3 tv28 584.300 D,3 tv32
Grp D
ROW 2
559.400 D,A tv28 585.000 D, A tv33
560.000 E,0 tv29 585.600 0 tv33
560.700 E,7 tv29 586.300 7 tv33
562.500 F,9 tv29 588.100 F,9 tv33
0,B 0,B
,5
,2
4,5
4,
E,
E,
Grp A
Grp B
ROW 1
Grp C
Grp D
ROW 2
BLOCK 21 BLOCK 22
FREQ SW SET US TV CH FREQ SW SET US TV CH
538.100 0,5 tv25 563.700 0,5 tv29
538.700 0,B tv25 564.300 0,B tv29
539.600 1,4 tv25 565.200 1 tv29
,4
540.200 1,A tv25 565.800 tv29
1,A
541.500 2,7 tv25 567.100 2,7 tv30
542.400 3,0 tv26 568.000 3,0 tv30
542.900 3,5 tv26 568.500 3,5 tv30
543.700 3,D tv26 569.300 3,D tv30
550.100 7,D tv27 575.700 7,D tv31
552.300 9,3 tv27 577.900 9,3 tv31
553.000 9,A tv27 578.600 9,A tv32
554.300 A,7 tv28 579.900 A,7 tv32
556.100 B,9 tv28 581.700 B,9 tv32
557.000 C tv28 582.600 C,2 tv32
,2
559.600 D,C tv28 585.200 D,C tv33
561.900 F,3 tv29 587.500 F,3 tv33
FREQ SW SET US TV CH FREQ SW SET US TV CH
544.500 4,5 tv26 570.100 4,5 tv30
545.100 4,B tv26 570.700 4,B tv30
546.000 5,4 tv26 571.600 5,4 tv30
546.600 5,A tv26 572.200 5,A tv31
547.600 6,4 tv26 573.200 6,4 tv31
548.800 7,0 tv27 574.400 7,0 tv31
549.300 7,5 tv27 574.900 7,5 tv31
549.900 7,B tv27 575.500 7,B tv31
555.500 B,3 tv28 581.100 B,3 tv32
556.500 B,D tv28 582.100 B, D tv32
557.000 C,2 tv28 582.600 C,2 tv32
558.700 D,3 tv28 584.300 D,3 tv32
559.400 D,A tv28 585.000 D, A tv33
560.000 E,0 tv29 585.600 E,0 tv33
560.700 E,7 tv29 586.300 E,7 tv33
562.500 F,9 tv29 588.100 F,9 tv33
BLOCK 21 BLOCK 22
FREQ SW SET US TV CH FREQ SW SET US TV CH
538.100 0,5 tv25 563.700 0,5 tv29
538.700 0,B tv25 564.300 0,B tv29
539.600 1,4 tv25 565.200 1,4 tv29
540.200 1,A tv25 565.800 1,A tv29
541.500 2,7 tv25 567.100 2,7 tv30
542.400 3,0 tv26 568.000 3,0 tv30
542.900 3,5 tv26 568.500 3,5 tv30
543.700 3,D tv26 569.300 3,D tv30
550.100 7,D tv27 575.700 7,D tv31
552.300 9,3 tv27 577.900 9,3 tv31
553.000 9,A tv27 578.600 9,A tv32
554.300 A,7 tv28 579.900 A,7 tv32
556.100 B,9 tv28 581.700 B,9 tv32
557.000 C,2 tv28 582.600 C,2 tv32
559.600 D,C tv28 585.200 D,C tv33
561.900 F,3 tv29 587.500 F,3 tv33
FREQ SW SET US TV CH FREQ SW SET US TV CH
544.500 4,5 tv26 570.100 4,5 tv30
545.100 4,B tv26 570.700 4,B tv30
546.000 5,4 tv26 571.600 5,4 tv30
546.600 5,A tv26 572.200 5,A tv31
547.600 6,4 tv26 573.200 6,4 tv31
548.800 7,0 tv27 574.400 7,0 tv31
549.300 7,5 tv27 574.900 7,5 tv31
549.900 7,B tv27 575.500 7,B tv31
555.500 B,3 tv28 581.100 B,3 tv32
556.500 B,D tv28 582.100 B, D tv32
557.000 C,2 tv28 582.600 C,2 tv32
558.700 D,3 tv28 584.300 D,3 tv32
559.400 D,A tv28 585.000 D, A tv33
560.000 E,0 tv29 585.600 0 tv33
E,
560.700 E,7 tv29 586.300 E,7 tv33
562.500 F,9 tv29 588.100 F,9 tv33
Incompatible
The following frequency combinations have intermodulation prob­lems and should not be used.
BLOCK 21 BLOCK 22
FREQ SW SET US TV CH FREQ SW SET US TV CH
538.100 0,5 tv25 563.700 0,5 tv29
538.700 0,B tv25 564.300 0,B tv29
539.600 1,4 tv25 565.200 1,4 tv29
540.200 tv25 565.800 1,A tv29
Grp A
541.500 2,7 tv25 567.100 2,7 tv30
542.400 3,0 tv26 568.000 3,0 tv30
542.900 3,5 tv26 568.500 3,5 tv30
543.700 3,D tv26 569.300 3,D tv30
550.100 7,D tv27 575.700 7,D tv31
552.300 9,3 tv27 577.900 9,3 tv31
553.000 9,A tv27 578.600 9,A tv32
554.300 A,7 tv28 579.900 A,7 tv32
Grp B
ROW 1
556.100 B,9 tv28 581.700 B,9 tv32
557.000 C,2 tv28 582.600 C,2 tv32
559.600 D,C tv28 585.200 D,C tv33
561.900 F,3 tv29 587.500 F,3 tv33
FREQ SW SET US TV CH FREQ SW SET US TV CH
544.500 4,5 tv26 570.100 4,5 tv30
545.100 4,B tv26 570.700 4,B tv30
546.000 5,4 tv26 571.600 5,4 tv30
546.600 5,A tv26 572.200 5,A tv31
Grp C
547.600 6,4 tv26 573.200 6,4 tv31
548.800 7,0 tv27 574.400 7,0 tv31
549.300 7,5 tv27 574.900 7,5 tv31
549.900 7,B tv27 575.500 7,B tv31
555.500 B,3 tv28 581.100 B,3 tv32
556.500 B,D tv28 582.100 B, D tv32
557.000 C,2 tv28 582.600 C,2 tv32
558.700 D,3 tv28 584.300 D,3 tv32
Grp D
ROW 2
559.400 D,A tv28 585.000 D, A tv33
560.000 E,0 tv29 585.600 E,0 tv33
560.700 E,7 tv29 586.300 E,7 tv33
562.500 F,9 tv29 588.100 F,9 tv33
FREQ SW SET US TV CH FREQ SW SET US TV CH
538.100 0,5 tv25 563.700 0,5 tv29
538.700 0,B tv25 564.300 0,B tv29
539.600 1 tv25 565.200 1,4 tv29
540.200 tv25 565.800 1,A tv29
Grp A
541.500 2,7 tv25 567.100 2,7 tv30
542.400 3,0 tv26 568.000 3,0 tv30
542.900 3,5 tv26 568.500 3,5 tv30
543.700 3,D tv26 569.300 3,D tv30
550.100 7,D tv27 575.700 7,D tv31
552.300 9,3 tv27 577.900 9,3 tv31
553.000 9,A tv27 578.600 9,A tv32
554.300 A,7 tv28 579.900 A,7 tv32
Grp B
ROW 1
556.100 B,9 tv28 581.700 B,9 tv32
557.000 C,2 tv28 582.600 C,2 tv32
559.600 D,C tv28 585.200 D,C tv33
561.900 F,3 tv29 587.500 F,3 tv33
FREQ SW SET US TV CH FREQ SW SET US TV CH
544.500 4,5 tv26 570.100 4,5 tv30
545.100 4,B tv26 570.700 4,B tv30
546.000 5,4 tv26 571.600 5 tv30
546.600 5,A tv26 572.200 5,A tv31
Grp C
547.600 6,4 tv26 573.200 6,4 tv31
548.800 7,0 tv27 574.400 7,0 tv31
549.300 7,5 tv27 574.900 7,5 tv31
549.900 7,B tv27 575.500 7,B tv31
555.500 B,3 tv28 581.100 B,3 tv32
556.500 B,D tv28 582.100 B, D tv32
557.000 C,2 tv28 582.600 C,2 tv32
558.700 D,3 tv28 584.300 D,3 tv32
Grp D
ROW 2
559.400 D,A tv28 585.000 D, A tv33
560.000 E tv29 585.600 E,0 tv33
560.700 E,7 tv29 586.300 E,7 tv33
562.500 F,9 tv29 588.100 F,9 tv33
1,A
BLOCK 21 BLOCK 22
,4
1,A
,0
,4
FREQ SW SET US TV CH FREQ SW SET US TV CH
538.100 0,5 tv25 563.700 0,5 tv29
538.700 0,B tv25 564.300 0,B tv29
539.600 1,4 tv25 565.200 1,4 tv29
540.200 1,A tv25 565.800 1,A tv29
Grp A
541.500 2,7 tv25 567.100 2,7 tv30
542.400 3,0 tv26 568.000 3,0 tv30
542.900 3,5 tv26 568.500 3,5 tv30
543.700 3,D tv26 569.300 3,D tv30
550.100 7,D tv27 575.700 7,D tv31
552.300 9,3 tv27 577.900 9,3 tv31
553.000 9,A tv27 578.600 9,A tv32
554.300 A,7 tv28 579.900 A,7 tv32
Grp B
ROW 1
556.100 B,9 tv28 581.700 B,9 tv32
557.000 C,2 tv28 582.600 C,2 tv32
559.600 D,C tv28 585.200 D,C tv33
561.900 F,3 tv29 587.500 F,3 tv33
FREQ SW SET US TV CH FREQ SW SET US TV CH
544.500 4,5 tv26 570.100 4,5 tv30
545.100 4,B tv26 570.700 4,B tv30
546.000 5,4 tv26 571.600 5,4 tv30
546.600 5,A tv26 572.200 5,A tv31
Grp C
547.600 6,4 tv26 573.200 6,4 tv31
548.800 7,0 tv27 574.400 7,0 tv31
549.300 7,5 tv27 574.900 7,5 tv31
549.900 7,B tv27 575.500 7,B tv31
555.500 B,3 tv28 581.100 B,3 tv32
556.500 B,D tv28 582.100 B,D tv32
557.000 C,2 tv28 582.600 C,2 tv32
558.700 D,3 tv28 584.300 D,3 tv32
Grp D
ROW 2
559.400 D,A tv28 585.000 D,A tv33
560.000 E,0 tv29 585.600 E,0 tv33
560.700 E,7 tv29 586.300 E,7 tv33
562.500 F,9 tv29 588.100 F,9 tv33
FREQ SW SET US TV CH FREQ SW SET US TV CH
538.100 0,5 tv25 563.700 0,5 tv29
538.700 0,B tv25 564.300 0,B tv29
539.600 1,4 tv25 565.200 1,4 tv29
540.200 1,A tv25 565.800 1,A tv29
Grp A
541.500 2,7 tv25 567.100 2,7 tv30
542.400 3,0 tv26 568.000 3,0 tv30
542.900 3,5 tv26 568.500 3,5 tv30
543.700 3,D tv26 569.300 3,D tv30
550.100 7,D tv27 575.700 7,D tv31
552.300 9,3 tv27 577.900 9,3 tv31
553.000 9,A tv27 578.600 9,A tv32
554.300 A,7 tv28 579.900 A,7 tv32
Grp B
ROW 1
556.100 B,9 tv28 581.700 B,9 tv32
557.000 C,2 tv28 582.600 C,2 tv32
559.600 D,C tv28 585.200 D,C tv33
561.900 F,3 tv29 587.500 F,3 tv33
FREQ SW SET US TV CH FREQ SW SET US TV CH
544.500 4,5 tv26 570.100 4,5 tv30
545.100 4,B tv26 570.700 4,B tv30
546.000 5,4 tv26 571.600 5,4 tv30
546.600 5,A tv26 572.200 5,A tv31
Grp C
547.600 6,4 tv26 573.200 6,4 tv31
548.800 7,0 tv27 574.400 7,0 tv31
549.300 7,5 tv27 574.900 7,5 tv31
549.900 7,B tv27 575.500 7,B tv31
555.500 B,3 tv28 581.100 B,3 tv32
556.500 B,D tv28 582.100 B,D tv32
557.000 C,2 tv28 582.600 C,2 tv32
558.700 D,3 tv28 584.300 D,3 tv32
Grp D
ROW 2
559.400 D,A tv28 585.000 D,A tv33
560.000 E,0 tv29 585.600 E,0 tv33
560.700 E,7 tv29 586.300 E,7 tv33
562.500 F,9 tv29 588.100 F,9 tv33
BLOCK 21 BLOCK 22
BLOCK 21 BLOCK 22
Compatible Frequency Chart (cont.)
FREQ SW SET US TV CH
538.100 0,5 tv25
538.700 0,B tv25
539.600 1,4 tv25
540.200 1,A tv25
Grp A
541.500 2,7 tv25
542.400 3,0 tv26
542.900 3,5 tv26
543.700 3,D tv26
550.100 7,D tv27
552.300 9,3 tv27
553.000 9,A tv27
554.300 A,7 tv28
Grp B
ROW 1
556.100 B,9 tv28
557.000 C,2 tv28
559.600 D,C tv28
561.900 F,3 tv29
FREQ SW SET US TV CH
544.500 4,5 tv26
545.100 4,B tv26
546.000 5,4 tv26
546.600 5,A tv26
Grp C
547.600 6,4 tv26
548.800 7,0 tv27
549.300 7,5 tv27
549.900 7,B tv27
555.500 B,3 tv28
556.500 B,D tv28
557.000 C,2 tv28
558.700 D,3 tv28
Grp D
ROW 2
559.400 D,A tv28
560.000 E,0 tv29
560.700 E,7 tv29
562.500 F,9 tv29
FREQ SW SET US TV CH FREQ SW SET US TV CH
538.100 0,5 tv25 563.700 0,5 tv29
538.700 0,B tv25 564.300 0,B tv29
539.600 1,4 tv25 565.200 1,4 tv29
540.200 1,A tv25 565.800 1,A tv29
Grp A
541.500 2,7 tv25 567.100 2,7 tv30
542.400 3,0 tv26 568.000 3,0 tv30
542.900 3,5 tv26 568.500 3,5 tv30
543.700 3,D tv26 569.300 3,D tv30
550.100 7,D tv27 575.700 7,D tv31
552.300 9,3 tv27 577.900 9,3 tv31
553.000 9,A tv27 578.600 9,A tv32
554.300 A,7 tv28 579.900 A,7 tv32
Grp B
ROW 1
556.100 B,9 tv28 581.700 B,9 tv32
557.000 C,2 tv28 582.600 C,2 tv32
559.600 D,C tv28 585.200 D,C tv33
561.900 F,3 tv29 587.500 F,3 tv33
FREQ SW SET US TV CH FREQ SW SET US TV CH
544.500 4,5 tv26 570.100 4,5 tv30
545.100 4,B tv26 570.700 4,B tv30
546.000 5,4 tv26 571.600 5,4 tv30
546.600 5,A tv26 572.200 5,A tv31
Grp C
547.600 6,4 tv26 573.200 6,4 tv31
548.800 7,0 tv27 574.400 7,0 tv31
549.300 7,5 tv27 574.900 7,5 tv31
549.900 7,B tv27 575.500 7,B tv31
555.500 B,3 tv28 581.100 B,3 tv32
556.500 B,D tv28 582.100 B,D tv32
557.000 C,2 tv28 582.600 C,2 tv32
558.700 D,3 tv28 584.300 D,3 tv32
Grp D
ROW 2
559.400 D,A tv28 585.000 D,A tv33
560.000 E,0 tv29 585.600 E,0 tv33
560.700 E,7 tv29 586.300 E,7 tv33
562.500 F,9 tv29 588.100 F,9 tv33
BLOCK 21
BLOCK 21 BLOCK 22
BLOCK 25
FREQ
SW SET US TV CH
640.500
641.100
642.000
642.600
643.900
644.800
645.300
646.100
652.500
654.700
655.400
656.700
658.500
659.400
662.000
664.300
FREQ
SW SET US TV CH
646.900
647.500
648.400
649.000
650.000
651.200
651.700
652.300
657.900
658.900
659.400
661.100
661.800
662.400
663.100
664.900
0,5 tv42
0,B tv42
1,4 tv42
1,A tv42
2,7 tv42
3,0 tv43
3,5 tv43
3,D tv43
7,D tv44
9,3 tv44
9,A tv44
A,7 tv45
B,9 tv45
C,2 tv45
D,C tv45/46
F,3 tv46
4,5 tv43
4,B tv43
5,4 tv43
5,A tv43
6,4 tv43/44
7,0 tv44
7,5 tv44
7,B tv44
B,3 tv45
B,D tv45
C,2 tv45
D,3 tv45
D,A tv45
E,0 tv46
E,7 tv46
F,9 tv46
BLOCK 26 BLOCK 27 BLOCK 28 BLOCK 29
FREQ
666.100
666.700
667.600
668.200
669.500
670.400
670.900
671.700
678.100
680.300
681.000
682.300
684.100
685.000
687.600
689.900
FREQ
672.500
673.100
674.000
674.600
675.600
676.800
677.300
677.900
683.500
684.500
685.000
686.700
687.400
688.000
688.700
690.500
SW SET US TV CH
0,5 tv46
0,B tv46
1,4 tv46
1,A tv47
2,7 tv47
3,0 tv47
3,5 tv47
3,D tv47
7,D tv48
9,3 tv49
9,A tv49
A,7 tv49
B,9 tv49
C,2 tv49
D,C tv50
F,3 tv50
SW SET US TV CH
4,5 tv47
4,B tv47
5,4 tv47/48
5,A tv48
6,4 tv48
7,0 tv48
7,5 tv48
7,B tv48
B,3 tv49
B,D tv49
C,2 tv49
D,3 tv50
D,A tv50
E,0 tv50
E,7 tv50
F,9 tv50
FREQ
691.700
692.300
693.200
693.800
695.100
696.000
696.500
697.300
703.700
705.900
706.600
707.900
709.700
710.600
713.200
715.500
FREQ
698.100
698.700
699.600
700.200
701.200
702.400
702.900
703.500
709.100
710.100
710.600
712.300
713.000
713.600
714.300
716.100
SW SET US TV CH
0,5 tv50
0,B tv51
1,4 tv51
1,A tv51
2,7 tv51
3,0 tv51
3,5 tv51
3,D tv51
7,D tv52
9,3 tv53
9,A tv53
A,7 tv53
B,9 tv53
C,2 tv54
D,C tv54
F,3 tv54
SW SET US TV CH
4,5 tv52
4,B tv52
5,4 tv52
5,A tv52
6,4 tv52
7,0 tv52
7,5 tv52
7,B tv52
B,3 tv53
B,D tv54
C,2 tv54
D,3 tv54
D,A tv54
E,0 tv54
E,7 tv54
F,9 tv55
FREQ
717.300
717.900
718.800
719.400
720.700
721.600
722.100
722.900
729.300
731.500
732.200
733.500
735.300
736.200
738.800
741.100
FREQ
723.700
724.300
725.200
725.800
726.800
728.000
728.500
729.100
734.700
735.700
736.200
737.900
738.600
739.200
739.900
741.700
SW SET US TV CH
0,5 tv55
0,B tv55
1,4 tv55
1,A tv55
2,7 tv55
3,0 tv55
3,5 tv56
3,D tv56
7,D tv57
9,3 tv57
9,A tv57
A,7 tv57
B,9 tv58
C,2 tv58
D,C tv58
F,3 tv59
SW SET US TV CH
4,5 tv56
4,B tv56
5,4 tv56
5,A tv56
6,4 tv56
7,0 tv56/57
7,5 tv57
7,B tv57
B,3 tv58
B,D tv58
C,2 tv58
D,3 tv58
D,A tv58
E,0 tv58
E,7 tv58
F,9 tv59
FREQ
742.900
743.500
744.400
745.000
746.300
747.200
747.700
748.500
754.900
757.100
757.800
759.100
760.900
761.800
764.400
766.700
FREQ
749.300
749.900
750.800
751.400
752.400
753.600
754.100
754.700
760.300
761.300
761.800
763.500
764.200
764.800
765.500
767.300
SW SET US TV CH
SW SET US TV CH
0,5 tv59
0,B tv59
1,4 tv59
1,A tv59
2,7 tv60
3,0 tv60
3,5 tv60
3,D tv60
7,D tv61
9,3 tv61
9,A tv61
A,7 tv62
B,9 tv62
C,2 tv62
D,C tv63
F,3 tv63
4,5 tv60
4,B tv60
5,4 tv60
5,A tv60
6,4 tv61
7,0 tv61
7,5 tv61
7,B tv61
B,3 tv62
B,D tv62
C,2 tv62
D,3 tv62
D,A tv63
E,0 tv63
E,7 tv63
F,9 tv63
Rio Rancho, NM – USA
19
UCR511
frequencies in Row 2 Block 21 are compatible. However, frequencies in Row 1, Block 21 are not compatible with the frequencies in Row 2, Block 21. If possible, it is highly recommeneded to choose frequencies that are in the same row and same group. For example, stick with frequencies in Row 1 Group A, or Row 2 Group D rather than choosing frequencies from Row 1 Groups A and B.
Rule No. 3
Some frequencies in adjacent blocks are compatible and some are not. Refer to the illustration to the left which shows compatible and incompatible frequency relation­ships.
By following the three rules, it is possible to locate a number of potential clear operating frequencies early in the production that are intermodulation free, then refine the list during system setup.
Using the Scan Function
Refer to the section titled "Frequency Scan Mode" for details on how to use the built-in spectrum scanner. Interference can result from a wide variety of sources including TV station signals and other wireless equip­ment in use nearby. The RF spectrum analyzer built into the UCR511 scans the frequency block to identify
channels with little or no interference. After scanning and finding the needed number of clear channels, one final procedure is necessary to verify the compatibility of the chosen frequencies.
Turn on all transmitters and receivers used for the program and verify there is a strong RF signal for each receiver. Turn each transmitter off one at a time and observe the RF level indicator on the matching receiver. The RF level should disappear or drop to a very low level. If it does not, change frequency on that receiver and transmitter and try it again.
Any time a frequency is changed on any of the systems in use, you must start at the beginning and go through this procedure for all systems. This will test for higher order imtermodulation from all signal sources and avoid interference.

Call Lectrosonics

Lectrosonics uses a proprietary computer program to perform thousands of calculations and identify various interfering signals. Potential problems and trouble areas can be identified in advance, and proposed new frequen­cies or other solutions can be suggested. This service is offered to authorized Lectrosonics dealers and other customers who are using LECTRO™ or Lectrosonics wireless microphone and wireless IFB systems.
®
20
UHF Wireless Digital HybridTM Receiver

UCR511 REPLACEMENT PARTS AND ACCESSORIES

Part No. Description
32251 Velcro mounting strips
CCMINI Zippered, padded vinyl system pouch
CH12E AC power supply with US type 2-pin plug on
housing, 110 VAC input; 12 VDC, 2.8 A output.
VSR1 Thin velcro loop for power cable strain relief.
A8U UHF marine phosphor bronze antenna -
straight connector, specify block.
A500RA UHF flexible whip antenna with right angle
BNC connector (470 - 608 MHz)
PS70 A/C power supply with US type 2-pin plug on
housing, 110 VAC input; 12 VDC, 2.8 A output.
UM500 Belt-pack Digital Hybrid Wireless
with over 50 mW power.
UMC200D Rack-mount multicoupler combining antenna
and power distribution for up to four Lectroson­ics wireless microphone receivers. Includes built-in power supply.
SIXPACK Portable multicoupler for field production
combining antenna and power distribution for up to six Lectrosonics wireless microphone receivers. Includes built-in rechargeable battery pack for added mobility.
SNA600 Collapsible dipole antenna adjustable from 550
MHz to 800 MHz. Ideal for situations where a full 360 degree receiving pattern is required as opposed to a directional pattern.
ALP600 “Shark fin” Log Periodic Dipole Array (LPDA)
provides useful directional pattern over 500 to 800 MHz range. Ideal for portable applications including temporary setups for field production. Not intended to be left outdoors permanently.
ALP700A LPDA (Log Periodic Dipole Array) provides
useful directional pattern over a broad fre­quency bandwidth (500 to 800 MHz).
ARG15-ARG100 Coaxial cables for remote antennas are
available from Lectrosonics in a variety of lengths - from 2 to 100 ft. Cables include Velcro tie wraps.
TM
transmitter
Rio Rancho, NM – USA
21
UCR511

TROUBLESHOOTING

Symptom Possible Causes

INITIAL POWER ON

LCD display not active or lit. External power supply disconnected or inadequate.
Main power supply fuse tripped. Turn the receiver off, remove the
cause of the overload and turn the receiver back on.
Wrong polarity power source. The external DC in requires
POSITIVE to be on the center pin.
Battery may be low. Try a fresh battery
Version message shows DSP or COM. This indicates an internal error. Please contact the factory for
assistance. Display indicates CHECK FREQ. This is a warning that a strong signal is present but it’s far enough
away from the center of the channel that the audio is likely to be
distorted. Try relocating to unused frequencies. If this doesn’t
remove the warning mesasge, the transmitter or receiver may
need repair.

PILOT TONE SQUELCH

PILOT indicator is solid “P”, but no sound Audio output cable bad or disconnected.
Audio Output level set too low. Use the built-in test tone to verify
levels.
PILOT “P” keeps flashing when transmitter audio switch is turned on Pilot tone detection can take several seconds. Turn on the
transmitter power (and the audio switch on some models) and
wait 3 to 5 seconds for the “P” to indicate steadily. Transmitter and receiver not on same frequency. Receiver compatibility mode does not match the trasmitter in use.
(See Menu Selections from Main Window, COMPAT.)
Noise on audio and Pilot indicator is “b” The pilot tone bypass has been activated. Hold MENU and press
UP to reset (works only from the Main Window). Pilot indicator not present but audio is being received Receiver is set to a compatibility mode that doesn’t use Pilot Tone.
Check that receiver compatibility mode matches the transmitter
in use as any sufficiently strong signal can unsquelch the
receiver in this mode, compatible or not.
In the 500 Series and 300 Series compatibility modes, the
PILOT indicator on the front panel shows as a solid “P” to
indicate that the audio has been turned on at the
transmitter, and that the audio output on the receiver is
enabled. When the “P” is on, the audio is enabled. If the
“P” is flashing the pilot tone is not detected and the audio
In the other compatibility modes, no pilot tone is used and the “P” is never displayed. Audio is present whenever the
receiver detects a sufficiently strong signal.
Regardless of the compatibility mode, activating the “pilot
bypass” function causes a lowercase “b” to appear in the
pilot indicator position on the main window and forcibly
will be muted (squelched).
NOTE:
unsquelches the audio.

ANTENNAS AND RF SIGNAL STRENGTH

RF Level is weak Receiver may need to be moved or reoriented.
Antenna on transmitter may be defective or poorly connected -
double check antenna on transmitter. Improper length of antenna, or wrong antenna on transmitter or
receiver. UHF whip antennas are generally about 3 to 5 inches
22
UHF Wireless Digital HybridTM Receiver
long. UHF helical antennas may be shorter, but are often less efficient.
No RF Signal Make certain frequency switches on transmitter match the
receiver frequency setting.
Check battery in transmitter

AUDIO SIGNAL QUALITY

Poor signal to noise ratio Transmitter gain set too low
The noise may not be in the wireless system. Turn the transmitter
audio gain all the way down and see if the noise remains. If the noise remains, then turn the power off at the transmitter and see if it remains. If the noise is still present, then the problem is not in the transmitter.
If noise is still present when the transmitter is turned off, try
lowering the audio output level on the UCR511 and see if the noise lowers correspondingly. If the noise remains, the problem is not in the receiver.
Receiver output is too low for the input of the device it is feeding.
Try increasing the output level of the UCR511 and lowering the input gain on the device the UCR511 is feeding.
Distortion
Transmitter input gain too high. Check and/or readjust input gain on
transmitter according to the LEDs on the transmitter and then verify the setting with the audio meter in the main window.
Audio output level too high for the device the UCR511 is feeding.
Lower the output level of the UCR511.
Bad frequency response or generally poor audio quality. Ensure the receiver is set to the compatibility mode that matches
the transmitter in use.
Rio Rancho, NM – USA
23
UCR511

SPECIFICATIONS AND FEATURES

Operating Frequencies (MHz):
Block 525:525.000 - 550.500
Block 21: 537.600 - 563.100 Block 22: 563.200 - 588.700 Block 23: 588.800 - 614.300
Block 24: 614.400 - 639.900 Block 25: 640.000 - 665.500 Block 26: 665.600 - 691.100 Block 27: 691.200 - 716.700 Block 28: 716.800 - 742.300 Block 29: 742.400 - 767.900 Block 30: 768.000 - 793.500 Block 31: 793.600 - 805.600 Block 32: 819.200 - 844.700 Block 31: 844.800 - 862.000
Frequency Adj. Range: 25.5 MHz in 100kHz steps
Receiver Type: Triple conversion, superheterodyne, 244
Frequency Stability: ±0.001 %
Front end bandwidth: ±5.5 MHz @ -3 dB
Sensitivity
20 dB Sinad: 0.9 uV (-108 dBm), A weighted
60 dB Quieting: 1.12 uV (-105 dBm), A weighted
Squelch quieting: Greater than 100 dB
AM rejection: Greater than 60 dB, 2 uV to 1 Volt
Modulation acceptance: 60 kHz
Image & spurious rejection:85 dB
Third order intercept: +8 dBm
Diversity method: Phased antenna combining SmartDiversity
FM Detector: Digital Pulse Counting Detector operating at
Antenna inputs: Dual BNC female, 50 Ohm impedance
Audio outputs
Rear Panel XLR: Adjustable from -50 dBu to +5 dBu
Front Panel Controls and Indicators:
LCD control panel
Main window: Pilot tone; antenna phase, receiver battery
Freq. window: Frequency, TV channel Transmitter switch
Audio output level
adjustment: -50 dBu to +5 dBu
Batt. level tracking: Receiver and transmitter (9 V batt.) in 1/10th
MHz, 10.7 MHz and 300 kHz
(Undetectable after processing)
TM
300 kHz
in 1 dB steps. Calibrated into a typical 10 k Ohm balanced load. Can drive 600 Ohm load.
level; transmitter battery status; audio level, RF level
setting
volt steps, accuracy +/- 0.2 V.
Scanning mode: Coarse and fine modes for RF spectrum site
scanning
Audio test tone: 1 kHz, -50 dBu to +5 dBu output, less than
1% THD
Transmitter battery type selection:
9 V alkaline, 9V lithium, AA alkaline, AA lithium, NiMH
Phase invert: Audio output phase normal or inverted
SmartNR
(noise reduction): OFF, NORMAL, FULL modes
(available in 500 Series mode only)
Audio Performance (overall system):
(These specs apply to 500 Series mode only.)
Frequency Response: 32 Hz to 20 kHz (+/- 1dB)
THD: 0.2% (typical)
SNR at receiver output (dB):
(Note: the dual envelope “soft” limiter provides exceptionally good handling of transients using variable attack and release time constants. The gradual onset of limiting in the design begins below full modulation, which reduces the measured figure for
SNR without limiting
SmartNR No Limiting W/ Limiting
OFF 102.0 106.5
NORMAL 105.0 109.5
FULL
106.0
by 4.5 dB)
110.5
Input Dynamic Range: 125 dB (with full Tx limiting)
Rear Panel Controls and features:
XLR audio output jack; External DC input; Battery compartment access
Power Options:
Ext DC: Minimum 10 Volts to maximum 18
VDC; 1.6 W, 180 mA at 12 VDC
Int Batt: 9 Volt alkaline or lithium
(165 mA @ 9 V, 240 mA @ 6 V)
Battery Life:
9V alkaline 6 to 8 hours continuous, up to 12
hours intermittent
9V lithium Up to 20 hours (continuous and
intermittent usage are the same)
Weight: 14 oz. with batteries
Dimensions: 3.23" wide x 1.25" high x 4.64" deep
Specifications subject to change without notice
24
Transmitter (AA battery) x.xxV format, accuracy +/- 0.05 V.
Timer option available when transmitter battery is set to NiMH.
UHF Wireless Digital HybridTM Receiver

SERVICE AND REPAIR

If your system malfunctions, you should attempt to correct or isolate the trouble before concluding that the equipment needs repair. Make sure you have followed the setup procedure and operating instructions. Check out the intercon­necting cords and then go through the TROUBLESHOOTING section in the manual
We strongly recommend that you do not try to repair the equipment yourself and do not have the local repair shop attempt anything other than the simplest repair. If the repair is more complicated than a broken wire or loose con­nection, send the unit to the factory for repair and service. Don’t attempt to adjust any controls inside the units. Once set at the factory, the various controls and trimmers do not drift with age or vibration and never require read­justment. There are no adjustments inside that will make a malfunctioning unit start working.
Rio Rancho, NM – USA
25
UCR511
This product meets the CE Compliance Standards - ETS 300 489; 2002-08, I ETS 300 422; August 2002 and ENG 0950-1; 2001. A copy of the Declaration of Conformity may be requested from your dealer or by contacting the factory directly:
Lectrosonics, Inc. Marketing Department 581 Laser Rd. NE, Rio Rancho, NM 87124 USA tel: 505-892-4501 fax: 505-892-6243 e-mail: marketing@lectrosonics.com
26
UHF Wireless Digital HybridTM Receiver
Rio Rancho, NM – USA
27
UCR511

LIMITED ONE YEAR WARRANTY

LIMITED ONE YEAR WARRANTY
The equipment is warranted for one year from date of purchase against defects in materials or workmanship provided it was purchased from an authorized dealer. This warranty does not cover equipment which has been abused or damaged by careless handling or shipping. This warranty does not apply to used or demonstrator equipment.
Should any defect develop, Lectrosonics, Inc. will, at our option, repair or replace any defective parts without charge for either parts or labor. If Lectrosonics, Inc. cannot correct the defect in your equipment, it will be replaced at no charge with a similar new item. Lectrosonics, Inc. will pay for the cost of returning your equipment to you.
This warranty applies only to items returned to Lectrosonics, Inc. or an authorized dealer, shipping costs prepaid, within one year from the date of purchase.
This Limited Warranty is governed by the laws of the State of New Mexico. It states the entire liablility of Lectrosonics Inc. and the entire remedy of the purchaser for any breach of warranty as outlined above. NEITHER LECTROSONICS, INC. NOR ANYONE INVOLVED IN THE PRODUCTION OR DELIVERY OF THE EQUIPMENT SHALL BE LIABLE FOR ANY INDIRECT, SPECIAL, PUNITIVE, CONSEQUENTIAL, OR INCIDENTAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THIS EQUIPMENT EVEN IF LECTROSONICS, INC. HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL THE LIABILITY OF LECTROSONICS, INC. EXCEED THE PURCHASE PRICE OF ANY DEFECTIVE EQUIPMENT.
This warranty gives you specific legal rights. You may have additional legal rights which vary from state to state.
28
581 LASER ROAD
RIO RANCHO, NM 87124 USA
www.lectrosonics.com
October 22, 2004
Loading...
