Lec U50262W User Manual

USER GUIDE

U50262W

Thank you for buying this high quality appliance

This handbook is designed to help you through each step of owning your
new appliance, from installation to use.

Please read through this handbook carefully before you start using your
appliance, as we have endeavoured to answer as many questions as
possible, and provide you with as much support as possible.

If, however, you find something missing or not covered, please contact
our Customer Care Centre, using the number at the back of this
handbook, who will be only too happy to help you.

Our policy is one of constant development and improvement, therefore
we cannot guarantee the strict accuracy of all our illustrations and
specifications, changes may have been made subsequent to publishing.

EN - 1 -

Index

BEFORE USING THE APPLIANCE ........................................................................3

Safety Instructions ........................................................................................................ 3

Recommendations ....................................................................................................... 4

Installation and Switching On The Appliance .............................................................. 5

Before Switching On..................................................................................................... 5

THE VARIOUS FUNCTION AND POSSIBILITIES..................................................6

Thermostat Setting ....................................................................................................... 6

ARRANGING FOOD IN THE APPLIANCE..............................................................7

CLEANING AND MAINTENANCE ...........................................................................8

Defrosting the Freezer compartment .......................................................................... 9

TRANSPORTATION AND CHANGING OF INSTALLATION POSITION .............. 10

BEFORE CALLING YOUR AFTER SALES SERVICE .......................................... 11

Technical data............................................................................................................. 12

THE PARTS OF THE APPLIANCE AND THE COMPARTMENT ..........................13

Changing of Door Opening Direction ........................................................................ 14

EN - 2 -

PART- 1. BEFORE USING THE APPLIANCE

Safety Instructions

• The model, which contains R600a-see name plate under refrigerant (the coolant
isobutane), naturals gas that, is very environmentally friendly but also combustible.
When transporting and installing the unit care must be taken to ensure that none of
the refrigeration circuit components become damaged. In the event of damage avoid
naked flames or ignition sources and ventilate the room in which the unit is placed
for a few minutes.

• Warning: Keep ventilation openings in appliance enclosure or in structure for building
in, clear of obstruction.

• Do not use mechanical devices or other artificial means to accelerate the defrosting
process.

• Do not use electrical appliances in the freezer compartment of the appliance.

• If this appliance is to replace an old refrigerator with a lock; break or remove the lock
as a safety measure before storing it, to protect children while playing might lock
themselves inside.

• Old refrigerators and freezers contain insulation gases and refrigerant, which must
be disposed of properly. Entrust the disposal of a scrap unit categorically to
competence of your local waste disposal service and contact your local authority or
your dealer if you have any questions. Please ensure that the pipe of work of your
refrigerating unit does not get damaged prior to being picked-up by the relevant waste
disposal service.

Important note:

Please read this booklet before installing and switching on this appliance. The
manufacturer assumes no responsibility for incorrect installation and usage as described
in this booklet.

Please ask your municipal authority about the disposal of the WEEE for
the reuse, recycle and recovery purposes.

EN - 3 -

Recommendations

Warning: Do not use mechanical devices or other means to accelerate the defrosting

process, other than those recommended by the manufacturer. Do not use electrical
appliances inside the food storage compartments of the appliance, unless they are of
the type recommended by the manufacturer. Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of obstruction. Do not damage the refrigerant
circuit.

• Do not use adapters or shunts which could cause overheating
or burning.

• Do not plug old, warped power supply cables.

• Do not twist and bend the cables.

• Do not allow children to play with the appliance. Children must
NEVER sit on drawers/shelves or hang from the door.

• Do not use sharp metal objects for removing ice on the freezer
compartment; they could puncture the refrigerator circuit and
cause unrepairable damage to the unit. Use the plastic scraper
provided.

• Do not plug the power supply with wet hands.

• Do not place containers (glass bottles or tin containers) of liquids
into the freezer especially gassy liquids as they could cause
the container to burst during freezing.

• Bottles that contain a high percentage of alcohol must be sealed
well and placed vertically in the freezer.

• Do not touch the cooling surfaces, especially with wet hands as
you could be burnt or hurt.

• Do not eat ice, which have just been removed from the freezer.

• The appliance is not intended for use by people (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by
a person responsible for their safety. Children should be supervised to ensure that
they don’t play with the appliance.

• If the supply cord is damaged it must be replaced by the manufacturer or service
agent or similary qualified people in order to avoid a hazard.

EN - 4 -
