LT-EL138 LED Flashlight
Page 2
1
If you need to mount the ashlight onto a rearm, make sure rearm is not loaded before
installation. Remove magazine and examine chamber. Use safe handling procedures
at all times.
Tactical ashlights produce substantial heat during operation. Do not leave activated
ashlight unattended. Do not set activated ashlight face down. Do not place activated
ashlight against combustible material or material that could be damaged by heat. Do
not hold bezel or lens of activated ashlight against any portion of human body. Keep
away from children.
Ensure that the ashlight cannot be turned on when stored or being transported. If the
lamp is activated while in a case or any container, the lamp could overheat and cause
damage to surrounding materials.
Examine battery quality and appearance before use each time and make sure that there
is no leaking or any deformation. Dispose appropriately if there is a problem.
The batteries are pre-charged by the manufacturer, and cannot be recharged.
Recharging can cause battery leakage or, in some cases, high-pressure rupture.
Inadvertent charging can occur if a battery is installed backwards.
Do not use re-chargeable batteries in the light. Only non-rechargeable batteries should
be used with the light.
Install batteries by aligning the + and – signs marked on the battery with the + and
– signs marked on the battery chamber in the light.
!
CAUTION!
Turn off the light when not in use to conserve battery power.
Make sure to turn off the light or disconnect the pressure switch before inspecting bulb
and battery if the light cannot be turned on.
Keep batteries cool and dry. Always remove batteries from light after use. Leaving
battery in the light without use for long period of time may cause damage or danger.
Always replace batteries with the exact type and size specied for the light.
Always replace the whole set of batteries at the same time. Never mix new and used
batteries in the same light.
Never deliberately short circuit batteries. Prolonged short circuit will cause the battery to
lose energy and result in signicant temperature increase.
Keep battery compartment clean and keep any metallic object away from the battery.
Lithium batteries can explode or cause burns if disassembled, shorted, recharged,
exposed to water, re, or high temperatures. Do not place loose batteries in a pocket,
purse, or other container containing metal objects. Do not mix new with used batteries or
mix required batteries with other types of battery. Do not store batteries with hazardous
or combustible materials. Store in cool, dry, ventilated area. Follow applicable laws and
regulations for disposal.
2
Page 3
3
T-6 Aircraft Aluminum Main Body
Law Enforcement Rated
Rolling Stop Shoulder
Water Resistant
Protective Lens
Combat Tactical
Front Head
(Specic Models Only)
Allen Wrench 3mm
Component Illustration
EL138 (Model Number)
AQN0040UB49U (Example Serial Number)
Velcro Pad
for Pressure Switch
LED IRB*
Battery
Compartment
Pressure Switch
(Length: 10” - 25”)
Offset Angled
Tactical Mount
(45° Offset, 30mm Diameter)
LT-EL138
Length
Main Body Diameter 27.2mm (1.07”)
Weight with Battery
Bulb Type IRB* with Cree XML LED
Specs
Voltage 3V
Max. Output 200 lumens
Focus Preset Spot
Battery Operating Time 60mins
Battery/Qty CR123A x 1
Pressure Switch Included
Accessory
Offset Angled Tactical Mount Included
The purpose of the diagram is to provide a better understanding of the
superior internal structure of the ashlight. Please do NOT disassemble
the product which will void its warranty unless it is for replacing battery.
!
116.8mm (4.6”)
199g (7oz)
4
Page 4
5
Battery Installation
1. Unscrew the end cap and install a CR123A lithium battery (Fig.1.1).
2. Replace and tighten the end cap (Fig.1.2).
Two Operation Modes
1. Push Button Operation
1). Ensure the end cap is properly tightened (Fig.2.1).
2. Pressure Switch Operation
Installation & Operation
2). Press and release the button in the center of the end cap to
turn the light on or off (Fig.2.2).
1). Unscrew and remove the push button end cap (Fig.2.3).
Make sure to keep the cap in a safe place for replacement
when Pressure Switch is not used.
2). Screw the end cap from the Pressure Switch onto the light
and tighten snugly (Fig.2.4).
3). Depress the Press Pad of the switch to turn on the light and
release to turn off (Fig.2.5).
Fig.1.1
Fig.1.2
Fig.2.1
Fig.2.2
Fig.2.3
Fig.2.4
Fig.2.5
Fig.3.1
Fig.3.2
Fig.3.3
Fig.3.4
Fig.3.5
Mounting the Flashlight
Offset Angled Tactical Flashlight Ring Mount (RG-FL138)
1). Remove the top half of the ring by loosening the screws and
slowly backing them out (Fig.3.1).
2). Place the ashlight on the ring base (Fig.3.2).
3). Replace the top ring half on the ashlight (Fig.3.3).
4). Tighten the screws evenly with included Allen wrench to ensure
a rm grip on the ashlight (Fig.3.4).
5). Attach the ring base to the rail mount of the rie. Hand tighten
the quick lock/release Thumb Nut for proper tension and t
against the rail (Fig.3.5).
Recommended torque value: 20-inch-lb.
Do not over tighten the screws as you
could cause damage to the ashlight body.
!
6
Page 5
7
8
Replacement
Parts
Contact your
distributor for
information:
Lithium Battery Pressure Switch
1PC of CR123A
Lithium Battery
RG-FL138
UTG Offset Angled Low Prole
Tactical Flashlight Ring
Maintenance
1. Maintain the metal surface of the ashlight by removing any dirt or sand with a
soft brush to avoid scratching the nish.
2. Store the ashlight in a cool dry place when not in use. Be careful to avoid
contact with acid, alkaline or corrosive chemicals.
3. Replace the batteries in your ashlight every few months if it was not used
for long period of time. This insures good working batteries for your light and
prevents battery leakage.
4. Keep a fresh package of batteries next to your ashlight. This gives you
back-up power for your light.
5. Do not store your ashlight in high temperatures. This would damage your
ashlight and may result in battery leakage.
6. Do not put the ashlight head against any surface especially paper or human
skin for it has heat and may result in accidents.
7. Do not leave your ashlight under the seat in your car, or in direct sunlight to
avoid over-heating.
8. Do not attempt to lubricate any part of the ashlight.
9. Do not disassemble the ashlight other than replacing battery or pressure
switch. Do not loosen or remove screws or parts. Any such or similar actions
will void the warranty.
