LH-A017A 240W Beam Moving Head
User Manual
This manual contains important information.
Please read before operating fixture.
www.leahualight.com 1
1 SECURITY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or
injury to persons, follow these important safety instructions:
non-professionals, not to disassemble the light arbitrarily and
lighting accessories inside.
rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ
(to be selected).
not beam irradiate the flammable materials, flammable materials
and the lamp should be maintained at least 1M over the distance.
lamps used in ambient temperature: -15 ℃ -40 ℃, the highest
temperature of the surface of the lamp: 60 ℃.
to keep away from the liquid substance and humid environment.
before using the lights must ensure the good grounding, can not
install charging and remove any parts.
the installation of lamps, must be fixed screw fasteners with
additional security cable and regular inspection.
lamps consecutive working hours is not recommended more than
10 hours.
should stop using the lights in time when happens unusual
conditions during the process
lamp parts of the rotation, external accessories and paste parts
should be regular inspected, such as the emergence of loose and
rock, should be reinforced in a timely manner to prevent the
accident.
lamps adopt strong winds to refrigerate, it is easy to accumulate the
dust, so you have to clean it weekly especially the cooling air
opening, otherwise the dust will plug leading to poor light
www.leahualight.com 2
2 TECHNOLOGY REFERENCE
Voltage : AC 100~240V/50~60Hz
Power : 280W
Lamp : philips 240w 8R (DMX on/off)
Lumen output:150000LM/10meter
Color Temperature: 8000K
Lens : 3-layer optic glass lens
Prism : 24 Prism rotation
Beam angle parallel beam angel :0-3.8°
Fan : ADDA brand
Gobo : 17 gobos+white
double rotation rainbow effect
shake function
Colors 14 color+white,single rotation rainbow effect, two models
changing(Full color and half color operating) With color offset
adjustment function
With Hall location function
DMX Channel : 16CH
Control DMX512/WDMX mode 3in/5in XLR base
Master-slave mode
Sound activated mode
Stand-alone mode
Auto mode
Head movement:Pan 540º (16bit) Electric correction
Tilt 270º (16bit) Electric correction
with auto-correction function
speed adjustment
Focus :Double automatic focusing
Dimmer:Independent dimmer channel, 0-100% linear dimmer
Strobe:Independent strobe channel, 1-13times/s, speed adjustable
LAMP DMX ON/OFF：LAMP DMX ON/OFF, ignited by inverter，
protect and lengthen the lifetime of the bulb
www.leahualight.com 3
Other functions
Fixture and lamp usage time display
Highly Positioning precision
Adjustable fan speed
Built-in analyzer for easy fault finding, error messages
Input signal isolating protection
3 Board Instruction
Key description:
“LEFT”、“ RIGHT”： Return to the previous interface
“UP”、“ DOWN”： choose、edit
“OK”： executive function、start edit、exit edit
MENU: Enter the menu option
DOWN: After an option
UP: previous option
ENTER: Confirm the selected function
Set interface:
name
description
mode
DMX
slave：receive dmx singal from master or
controller
www.leahualight.com 4
auto
master：auto，send dmx single to slave
Sound
Receive the sound and run the built-in
application effect
DMX address
1-512
press “OK ”to edit,choose the hundred's
place;press “Up”,”Down”change the address
code,press again the “OK”to choose the
decade edit.press “OK”again choose units
edit,once press to exit the edit.
channel
16
17 -20CH no function
20
17 -20CH control the speed
X inversion
close
open
Y inversion
close
open
XYencoder
close
Don’t use the encoder (light coupling)
correct position
open
Using encoder (light coupling) judging
out-of-step and automatically correct
position
No DMX
singal
keep
According to the original state continues to
run
clear
The motor return, stop running
Protect screen
open
Close the backlit idle for 30 seconds
close
Backlit keep open
Switch on light
bubble
open
start the lamps, lamp light up automatically
close
Start the lamps and lanterns, the bulb is not
bright
Recover
default setting
No
Yes
Press "ok" is to restore the default Settings
www.leahualight.com 5
Information interface:
name
description
software version
The current software version
total time
Cumulative time (accurate to minutes)
The use of time
This boot since the use of time (down to minute)
Total light soaking
time
Total light bubble time (accurate to minutes)
The light soaking
time
The light of this boot since bubble time (dow
n to minute)
DMX channel
In the condition of DMX, showing all channels of
value (number), thus the child into the interface,
display as a percentage value and channel value
for viewing
System error record
If red ERR lights shine, then failed to reset or run
out of step, can enter child interface for details.
After the view can press "ok" the error record to
empty
Manual control interface:
This interface is used to control the current lamps , neither belongs to
the slave machine (not receiving DMX signal) also does not belong to
the master machine (not send DMX signal)
name
description
reset
press "ok" after see confirmation dialog, press the "ok" ke
y once again, after carry into the interface, reset all motor
light bulb
control
open
close
www.leahualight.com 6
Color
wheel
0-255
Press "ok" to enter edit state. At this point is
selected, click on "next" button to change ch
annels values, press the "ok" button once agai
n and exit the editor.
。。。。。。
0-255
Gobo
wheel
speed
0-255
Advanced interface:
Enter the show advanced interface, please enter the password: XX
XXXX. Specific operation process: press the up and down key to
choose Numbers (a *) at a time. Password input after fully, final
ly press the "ok" key password authentication.
name
description
The biggest
bright time
0-9999
set up on time
encryption m
ode
close
times
set up the use of lamps
time
install the use time of lamps
Encryption
parameters
(frequency/ti
me)
0-9999
After the encryption mode to open the work. Can
be set up the use of lamps (number/time)
www.leahualight.com 7
Inverted Display Interface:
Click "ok" button, the interface inversion can be 180 degree show.
English interface:
Click "ok" button, the interface, switch to English mode.
Chinese interface:
Click "ok" button, the interface, switch to the Chinese model.
The factory interface:
Enter the factory interface, display, please enter the password:
XXXXXX. Specific operation process: press the up and down key to
choose Numbers (a *) at a time. Password input after fully, finally press
the "OK" (OK) key password authentication.
name
description
Reset the
calibration
(fine)
0-255
X calibration
0-255
Y calibration
0-255
Dimmer calibration
0-255
Color wheel calibration
0-255
Gobo wheel calibration
0-255
focuscalibration
0-255
Prism calibration
0-255
Atomizing calibration
Channel setting
set up channel switch
Screen saver
mode
Mode 1
Display address code
Mode 2
Display factory LOGO
Mode 3
No display (keep)
Bright time
reset
No
Yes
www.leahualight.com 8
4 DMX CHANNEL SHEET
CH
Channel
DMX
value
Description
1
Pan
0-255
Pan movement range 540º
2
Tilt
0-255
Tilt movement range 280º
3
Pan/Tilt Speed
Pan/Tilt Time
0-255
Quick Slow
4
Shutter,Strode
0-255
5
Dimmer
0-255
Dark bright
6
Color Wheel
0-255
WHITE
WHITE + RED
RED
RED + ORANGE
ORANGE
ORANGE+ QUAMARINE
AQUAMARINE
AQUAMARINE + GREEN
GREEN
GREEN+LIGHT GREEN
LIGHT GREEN
LIGHT REEN+LAVENDER
LAVENDER
LAVENDER+PINK
PINK
PINK+YELLOW
YELLOW
YELLOW+MAGENTA
MAGENTA
MAGENTA+CYAN
CYAN
www.leahualight.com 9
CYAN+CTO 260
CTO 260
CTO260+CTO 190
CTO 190
CTO 190+CTB 8000
CTB8000
CTB8000+BLUE
BLUE
BLUE+WHITE
SLOW ROTATION(0.2rpm)
7
Gobo
0-255
WHITE
Gobo1
Gobo2
Gobo3
Gobo4
Gobo5
Gobo6
Gobo7
Gobo8
Gobo9
Gobo10
Gobo11
Gobo12
Gobo13
Gobo14
Gobo15
Gobo16
Gobo17
Gobo rotation, forward Stop
Gobo rotation, backward
Gobo2 Shake (slow to Quick)
Gobo3 Shake(slow to quick)
Gobo4 Shake(slow to quick)
www.leahualight.com 10
Gobo5 Shake(slow to quick)
Gobo6 Shake(slow to quick)
Gobo7 Shake(slow to quick)
Gobo8 Shake(slow to quick)
Gobo9 Shake(slow to quick)
Gobo10Shake(slow to quick)
Gobo11 Shake(slow to quick)
Gobo12 Shake(slow to quick)
Gobo13 Shake(slow to quick)
Gobo14 Shake(slow to quick)
Gobo15 Shake(slow to quick)
Gobo16 Shake(slow to quick)
8
Focus
0-255
9 Prism
0-255
10
Prism rotation
0-255
11
ZOOM
0-255
No Function
12
Frost
Soft atomizing effect
13
Pan fine
0-255
14
Tilt fine
0-255
15
Lamp
0-255
If the current is light lamp
off100-105, such as the current is
extinguished the light bulb200-205
16
RESET
0-255
Lamp reset240-255
5 DIFFICULTY RESOLUTION
The following is a list of problems and resolution, and other
malfunction preparing work should be professionally qualified staff to
deal with.
1. Bulb not working
a) Check whether approaching the service life of light bulbs, then
www.leahualight.com 11
change it
b) Check whether bulbs circuitry leak, loss or connect poorly
2. Beam appears bleak
a) The bulbs maybe approach the service life, then change it, or
the optical components are unclean.
b) Bulbs have accumulation of dust, so the bulbs and other parts
inside the lamp should be cleaned and maintained in regular
period.
3. Computer lamp work intermittently
a) Check whether the fan process naturally and become dirty
b) Check inner temperature-response control plug is off
c) Check whether the circuitry is good
4. The computer lamp not controlled by controller during lighting
a) Check numeral starting address and the connection of
communication control circuit
b) The corresponding channel button of controller is open or not
c) Check whether the fuse on power supply input jack is broken
off
6 AFTER SERVICE
1. Our company offer technical consultation to customers for ever.
2. If the machine is wrong and need repairmen, please truthfully fill in
the related content and feedback us the problems timely, as well as
we have to improve the product.
3. In addition to the lamp, also matching accessories are as follows：
accessories：Power line 1 piece Optional parts：(customers）
www.leahualight.com 12
Warranty Card
Name Model Production Purchase
Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the
warranty will not work (warranty period and terms, see the following)
warranty period：one year since purchase warranty terms：1、If fail when using the product
in normal state, you can made under the provisions of the warranty, show the warranty card
and purchase bills(copy), and enjoy free maintenance service in a specific service center or
the manufacturer.
2. The following will be the implementation of paid service:
(1)Without the effective warranty card
(2)There’s blank, alter and no point-of-sale name
(3)Fail caused by unresistance
(4)Fail caused by transportation or unloading
(5)Fail caused by not operate by manual
(6)Fail caused by disassemble without unauthorized
(7)Fail caused by using the unauthorized control system
Note:
Based on our company continue to improve the product, the statement
containing data may have changed, and will not notice the change any
more. Company retains its right to change specifications related when
product is improved. Thanks for your understanding.
End User
Company Name:
Add:
Sale Store
Link man:
Tel: Stamp
Loading...
