Leaf&Bean D8046 Operating Manual

D8046 Electric Milk Warmer & Frother

Operating Manual

Thank you for choosing the Davis & Waddell Leaf & Bean Electric Milk Warmer & Frother. To
ensure proper operation and to maintain the lifespan of your appliance, please read these
instructions carefully before use.

1. Key Features

 Will froth 115ml of milk when used with the whisking insert
 Will warm 240ml of milk when used with the stirring insert
 From cold to hot milk in 80 seconds
 Will automatically switch off when ready

2. Important Safety Instructions

When using electric appliances, especially when children are present basic safety

precautions should always be followed, including the following:

 Read all the instructions before operating this appliance.
 Children should be supervised to ensure they do not play with the appliance, and be

sure to keep them away from hot milk and jug.

 Do not immerse in water or any other liquid
 Unplug the appliance when not in use or being cleaned.
 Pull out from the power outlet by grasping the plug, never by the cord.
 Keep away from moving parts
 Always check the integrity of the cord before use, if the cord or plug is damaged do

not use.

 This appliance should be kept away from hot gas, heated oven, electric burner or any

hot surface

 The appliance should always be used on a hard stable surface, such as table or

benchtop.

 Take care when the appliance is in use or has just been used as it becomes hot and

may cause burns or scalding, always use the handle.

 Do not operate without milk in the jug
 By exceeding the filling capacity the jug may overflow
 This appliance is intended for household use, not commercial use.
 Store these instructions for future reference.

3. Marks

For different functions

4. Jug: S/S Housing
Non-stick coating inside

5. Indicator lights

6. On/Pause button

7. Power base

With cord

3. Know Your Frother

8. Whisking insert

For frothing milk

9. Stirring Insert

For heating milk

1. Transparent lid

2. Silicone ring

4. Operation Instructions

Before using the appliance for the first time please clean and dry the jug and accessories

thoroughly.

Choose the appropriate insert and set it inside the jug, see the function below for reference.

Pour the milk into the jug to the appropriate fill line, see below for reference

Push the button to start the machine

 Frothing & Heating/Heating: touch the button and the blue and red lights will turn

on, the red light keeps flashing for 30 seconds, the blue light will turn off when your

milk is ready, the machine will automatically turn off at the same time.

 Frothing cold milk: pour the cold milk into the jug and push the button for 1-2

seconds until the blue light turns on. After 80 seconds the machine finishes, the blue

light turns off and the red light will flash for 30 seconds

Insert

Function

Max capacity

Time

Frothing cold milk

115ml

65s

Frothing & Heating

115ml

80-90s

Heating

(a small amount of froth)

240ml

100-120s

For best results

 Always use your frother first to froth or heat your milk. While it is operating prepare

your coffee or hot chocolate and serve immediately

 Use low-fat milk for best frothing results
 Cold milk can be frothed in this appliance but it won’t keep it chilled
 Milk heats to approximately 65-70C. This is the ideal temperature to ensure the best

flavour of your coffee.

 Keep the whisks in a safe place, they are small and can be easily lost
 After frothing and heating allow 2 minutes for the thermostat to reset and the

frother to be ready for use again. To shorten this time, rinse with water and wipe dry
after each use.

 The frother is designed to heat and froth milk, if you add flavourings, coffee granules

or hot chocolate powder, in the frother be sure to thoroughly clean immediately
after use.

5. Care

 Do not immerse in water and do not use any detergents, just wipe the base with a

damp cloth or towel. To clean the jug and inserts rinse out with water.

 Not dishwasher safe
 Do not leave the appliance in a damp or steamy environment
 This appliance is operated by an electric motor; there is no need to use lubrication

for any moving parts, motor, bearings or sharpening surfaces.

6. Troubleshooting

Issue

Reason

Solution

Indicator light

doesn’t work, jug
doesn’t work

1、Plug is not inserted properly.

Re-insert

2、Jug and power base has poor

contact.

Check the jug and try again
3、No power supply to the outlet

Check the electric circuit

4、Problem with components

Contact your retailer

Jug ceases to work
after starting
operation

1、Jug temperature is too high

Rinse with cold water inside the
jug to reduce temperature

2、Jug damaged with immersion in

water

No longer use it, this is not
covered by guarantee

Motor doesn’t work

1、Jug not cleaned in good time

after use, milk locks the mechanism.

Clean and move the shaft sleeve
of motor by hand to loosen it.

2、 Motor damage

Contact your retailer

No heating

1、Machine damage

Contact your retailer

Charring

1、Dosage of milk either too little or

too much

Use the dosage of milk
according to the dial

2、Jug reused without cleaning

Always clean in good time after
use

3、Actual voltage much lower than

specified voltage

Use the appropriate voltage

7. Guarantee

If after following these instructions the milk frother does not work, there may be a
manufacturing problem. If this is the case, Albi guarantees this product for 1 year from the
date of purchase. The full details of this guarantee can be found at www.albi.com.au or by
calling [phone]. In the event of such a problem you should return it to the place from
which you bought it, WITH PROOF OF PURCHASE, in the form of a valid receipt. Damage
through misuse will nullify this guarantee.

For any other advice please contact:

Customer Service
Albi
87 Chifley Drive,
Preston Vic 3072

Phone: [phone]
Email: [email protected]
