Leadtek Research S202 Users Manual

Leadtek S202

Jun 29, 2016

Wi-Fi Smart Power Plug

User Manual

Contents

FCC Statement............................................................................................................................................................ 3

Product Overview ...................................................................................................................................................... 6

Features ..................................................................................................................................................................... 6

Install APP .................................................................................................................................................................. 7

WiFi LED Indicator ...................................................................................................................................................... 8

Network Configuration ............................................................................................................................................ 10

APP Operation Instructions ...................................................................................................................................... 14

Frequently Asked Questions .................................................................................................................................... 26

Manual Update History ............................................................................................................................................ 30

2

FCC Statement

P 15.19(a)(3):

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

15.105(b):

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the interference by one or more of the

following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

3

This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired

operation of the device.

Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio

exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le

brouillage est susceptible d'en compromettre le fonctionnement.

This device complies with RSS 247 of Industry Canada. This Class B device meets all the requirements
of the Canadian interference-causing equipment regulations.

Cet appareil numérique de la Classe B respecte toutes les exigences du Règlement sur le matériel

brouilleur du Canada.

5

Product Overview

Leadtek S202 Wi-Fi Smart Power Plug is a general 2.4 G WiFi (802.11 b/g/n) device we introduced. It

is designed for new home automation systems. It can be used in the Internet or Intranet. When it is

connected to network, users can use mobile APP to remotely control it from anywhere.

Features

Voltage/current/power consumption measurement.

Have four independent controllers to control three power sockets and USB ports.

Support wireless remote control.

Support smart network configuration.

Support up to 36 timer schedule tasks.

6

Install APP

For iOS Users:

Start App Store and key in "amor Power" to search and install the APP.

For Android Users:

Search "amor Power" in the app market to download and install the APP.

7

WiFi LED Indicator

LED Indication

Description

Flashing (every 2.6s)

Smart configuration mode (factory default status)

iOS users can use "amor Power" APP to configure the device to the

remote control mode.

Flashing (every 0.5s)

Direct connection mode

The device SSID shows in the WiFi list of the mobile device. And users

can connect it directly through WiFi and control it. In this mode the

device is not connected to the WiFi Router, so it can't be controlled

remotely. You can enter the APP's device settings page to configure it to

the remote mode.

Flashing (every 0.2s)

The device is trying to connect to the Router.

On

Remote control mode. The device has been connected to the Router

successfully, and mobile APP can remotely control it anywhere anytime.

WiFi Status Indicator

8

Socket On/Off Status Indicators

LED Indication

Description

On

The power socket is turned on or the temperature function is enabled.

So the socket will automatically turn on or off when the preset temp is

reached.

Off

The power socket is turned off and the temperature function is

disabled.

There are four On/Off status indicators for indicating the three common power sockets and a group

of 5V/1~2A USB ports.

9
