LBL Lighting Tav 14 User Manual

Installation Instructions for

980TAV14O

Tav 14 Outdoor

Outdoor

GP I :ENERAL RODUCT NFORMATION

This product is suitable for wet locations.

This product can mount either to a 4” square electrical box with a
round plaster ring or an octagon electrical box.

CAUTION - RISK OF FIRE

This product requires installation by a qualified
electrician. Before installing be sure to read all
instructions and TURNTHE POWER TO THE
ELECTRICAL BOX OFF.

OD734_LED

1.0

Install the Fixture

1A 1B

ALLEN
WRENCH

1

1

FIXTURE
SCREW

1

#8-32 SCREW

ELECTRICAL BOX

3

3

MOUNTING PLATE

1

With the Allen wrench provided, remove the four fixture
screws.

Remove the mounting plate from the back of the

2

fixture.

3

Attach the mounting plate to the electrical box using
the two #8-32 screws provided.

1

1C

5

6

4

Connect the mounting plate ground wire to a suitable
ground in accordance with local electrical codes.

5

Connect the white fixture wire to the neutral power line
wire with a wire nut.

1E

4

8

For wet locations, caulk around the base with
waterproof construction sealant.

6

Connect the black fixture wire to the hot power line
wire with a wire nut.

1D

7 7

7

7

Reinstall the fixture onto the mounting plate and secure
it in place with the four fixture screws.

7

SAVE THESE INSTRUCTIONS!

7400 Linder Ave, Skokie, IL 60077

800.323.3226 - 847.626.6300

www.lbllighting.com
