LBL Lighting Swing H User Manual

Installation Instructions for

980FSJSWINGH

Swing Head (LED)

Fusion Jack™

GP I :ENERAL RODUCT NFORMATION

This product is suitable for indoor dry locations only.

CAUTION - RISK OF FIRE

This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.

Use minimum 90°c supply conductors.

HD503_LEDFSJ

1.2

Replacing the Lamp

1A

ACCESSORY

BASE

1

LAMP

CAUTION:To reduce the risk of a burn or electric shock
during relamping, disconnect the power to the fixture.

1

Push the lamp into the accessory base.

1B

2

FIXTURE

HEAD

The lamp is rated to draw 6 Watts at 12 volts.

2

Screw the lamp into the fixture head.

1

SAVETHESE INSTRUCTIONS!

7400 Linder Ave, Skokie, IL 60077

800.323.3226 - 847.626.6300

www.lbllighting.com

© 2014 LBL Lighting.All rights reserved. The "LBL Lighting" graphic is a
registered trademark of LBL Lighting. LBL Lighting reserves the right to
change specifications for product improvements without notification.
