LBL Lighting Modo Glass Shield Accessory User Manual

Installation Instructions for

980MODOACC

Modo Accessory

ACCESSORIES

GENERAL PRODUCT INFORMATION:

This product must be used with LBL Lighting systems only.

Install the Modo Accessory

1A

1C

HAC476_, HAC478_

MODO

5

ACCESSORY

1.0

LOUVER OR
GLASS LENS

1

Unscrew the retaining ring from the Modo Head.

2

Place the optional louver or glass lens into the retaining ring.

RETAINING RING

1B

3

LAMP

SOCKET

Use MAX 50 Watt MR16 Front Cover Halogen
Lamp.

3

Push the lamp pins completely into the socket holes.

RETAINING

RING

4

Slide the accessory base onto the accessory seat.

5

Screw the retaining ring into the Modo Head to secure
the accessory.

ACCESSORY
BASE

4

ACCESSORY
SEAT

1

SAVE THESE INSTRUCTIONS!
