LBL Lighting Modo User Manual

Installation Instructions for

980FSJMODOH

Modo Head

Fusion Jack™

GP I :ENERAL RODUCT NFORMATION

This product is suitable for indoor dry locations only.

Replacing the Lamp

HD474_50FSJ

CAUTION - RISK OF FIRE

This product must be installed in accordance with
the applicable installation code by a person familiar
with the construction and operation of the product
and the hazards involved.

Use minimum 90°c supply conductors.

1.0

1A

RETAINING

RING

1

CAUTION:To reduce the risk of a burn or electric shock

during relamping, disconnect the power to the fixture.

1

Unscrew and remove the retaining ring, and any lens, louver, or
accessory installed.

LAMP

2

SOCKET

1B

4

NOTE:Use only your fingers and a soft cloth to replace

the lamp.

Use Watt MR16 Front CoverMAX 50
Halogen Lamp

LAMP PINS

3

2

Remove the lamp from the socket.

3

Push the lamp pins completely into the socket holes.

4

Replace the retaining ring and any lens, louver, or accessory.

1

SAVETHESE INSTRUCTIONS!
