WELCOME

Just in case you are not familiar with us, our company began

as a family business in 1932 as Chicago Combustion

Corporation. The founder, Louis McGlaughlin, introduced

the first gas-fired broiler at the 1939 World’s Fair in New York.

These first commercial units added a unique charcoal flavor

to restaurant cooking and became the platform for the outdoor

gas-fired barbecue grill.

LazyMan Inc.

DELUXE GOURMET GRILLS

560 Independence Street, Belvidere NJ 07823

Louis’ son, Don, Sr., pioneered the outdoor gas-fired grill design

in 1954. He was the first to adapt the use of a plumber’s 20 lb.

propane cylinder to an outdoor gas-fired barbecue. The first

portable and stationary gas barbecues for outdoor residential

use were made by the Chicago Combustion Corporation in

1955 and 1956. In the sixties, sales of outdoor gas barbecues

took off in a big way. During this expansion period, the

company was producing as many as 35,000 gas barbeques

per year at the factory in Belvidere, New Jersey. Eventually,

the company name was changed to LazyMan, Inc., now

considered to be the inventors and originators of the gas fired

outdoor barbeque.

With more than 80 years of experience and three generations

of family ownership, the company has continued to innovate.

State of the art grilling components have continuously been

developed to manufacture gas barbecues that could withstand

the increasing demand for hot and even cooking, and at the

same time, endure the rigors of the outdoor environment. The

burners were built from the lineage of burner technology which

originally formed the basis of the Chicago Combustion

Company. It has always been our number one goal to

manufacture gas-fired barbecues that would stand the test

of time and set us apart from the competition. LazyMan is the

oldest manufacturer of gas fired barbeques and possibly one

of the best kept secrets in the industry.

[phone] • [phone]
FAX: [phone]

www.lazyman.com

Starting in 2010, Lazy Man Inc. took its next evolutionary leap

with the purchase of the company by Brian Sadowski.

In keeping with the tradition pioneered by Louis McGlaughlin,

the company continues to build products that can stand the

test of time, and possibly a lifetime. And, just like Louis and

his son Don Sr., Brian continues to bring fresh ideas to add

to the existing 80 year pool of innovations. This continued

commitment has brought exciting growth for LazyMan Inc.

and allows the company to remain the premier, luxury gas grill

company. All LazyMan products are proudly made in the U.S.A.

LazyMan Inc. reserves the
right to change appearances
of products appearing in this
catalogue.
This is part of the naturally
occurring, continued
development process.

LM210 SERIES

MASTERPIECE MOBILE GRILLS WITH CUSTOM CART

LM210-40MC

40” Grill

AVAILABLE IN 4 MODELS:

LM210-40MC

40” Mobile Grill with 4 main burners

LM210-28MC

28” Mobile Grill with 3 main burners

LM210-40/20MC

40” Mobile Grill with 4 main burners & 1 side burner
(combination grill)

LM210-28/20MC

28” Mobile Grill with 3 main burners & 1 side burner
(combination grill)

• The Original All Stainless Steel Outdoor Barbecue with
all stainless steel construction that lasts a lifetime.

• Stainless steel components are durable, easy to clean
and will not rust - ideal for salt air environment.

• Mobile cart is enclosed with access doors for storage
and two stainless steel side shelves

• Internal gas piping and fittings are included for easy
connection to gas supply. Available for either LP gas or
Natural Gas. Please specify when ordering.

• Electronic ignition for easy, safe, reliable starting.

LM210-40/20MC

40” Grill w/ Single Side Burner

• Fast start-up from independently controlled 12,000
BTU burners ensure professional cooking results.

• Heavy duty rubber wheels for ease of mobility - includes
2 straight casters and 2 locking swivel casters.

• Completely assembled at the factory before shipping.
Simply unpack and cook!

• Available options include grate upgrade, other broiler
burner/surface burner configurations, and custom fitted
vinyl covers (sold separately).

• Superior construction using commercial quality,
professional grade Type 304 Stainless Steel.

• Stainless Steel SS Class cooking hood with a 750°
thermometer and full width polished stainless steel
comfort cool handle.

• 115 volt electric rotisserie motor with heavy- duty spit
rod is standard on all mobile models.

• ‘Broil Rite Stainless Steel Flavor Enhancers’ offer a
unique heat distribution system that radiates heat
evenly.

• Stainless Steel Toasting Rack Included.

• Vinyl Cover (sold separately)

MODEL DESCRIPTION /BURNERS BTUs OVERALL DIMENSIONS GRILLING AREA SHIP WT.

M210-28MC 28” Grill w/ 3 Main Burners 36,000 24”x 55-1/2” x 48“ 24” x 15” 300 lbs.
LM210-40MC 40” Grill w/ 4 Main Burners 48,000 24” x 67-1/2” x 48“ 36” x 15” 375 lbs.
LM210-28/20MC (Combination) 28” Grill w/ 3 Main+ 1 Side 56,000 24” x 71-1/2” x 48“ 24” x 15” 310 lbs.
LM210-40/20MC (Combination) 40” Grill w/4 Main + 1 Side 68,000 24” x 83-1/2” x 48” 36” x 15” 410 lbs.

3

LM210 SERIES

MASTERPIECE MOBILE GRILLS WITH STANDARD CART

• With an open cart design, the LM210 Series grill with
Standard Cart has all the same grilling features as the
custom grills. These can be customized in different broiler
burner/surface burner combinations.

• Internal gas piping and fittings are included for easy
connection to gas supply. Available for either LP gas or
Natural Gas. Please specify when ordering.

LM210-40M

40” Grill

LM210-40/30M

40” Grill w/ Dual Side Burner

• Electronic ignition for easy, safe, reliable starting.

• Fast start-up from independently controlled 12,000
BTU burners ensure professional cooking results.

• Heavy duty 8” rubber wheels for ease of mobility- includes
2 straight casters and 2 locking swivel casters.

• Completely assembled at the factory before shipping.
Simply unpack and cook!

• 115 volt electric rotisserie motor with heavy-duty spit
rod is standard on all mobile models.

• Stainless Steel SS Class cooking hood with full width
polished stainless steel comfort cool handle

• Cart is equipped with a built-in storage shelf at the
bottom of the cart and attractive storage side
shelf for the propane tank on LP models.

• A 750° hood thermometer is included with all models.

• Slide-out stainless steel drip pan(s) for easy cleaning of
grilling residues and grease. Pan is included under both
the grilling area (main burners) and under the side burner
area (for combination gills).

• Larger models have locking swivel caster wheels
for stability.

• Includes Toasting Rack.

• Vinyl Covers are also available separately.

LM210-28M

28” Grill

MODEL DESCRIPTION/BURNER CONFIGURATION BTUs OVERALL DIM. SHIP WT.

LM210-28M 28” Grill w/3 Main Burners 36,000 24” x 55” x 46” 237 lbs.
LM210-28/20M 28” Grill w/3 Main burners + 1 Side Burner (Combination) 56,000 24” x 71” x 46” 283 lbs.
LM210-40M 40” Grill w/4 Main Burners ) 48,000 24” x 67” x 46” 300 lbs
LM210-40/20M 40” Grill w/4 Main Burners + 1 Side Burner (Combination) 68,000 24” x 83” x 46” 355 lbs.
LM210-40/30M 40” Grill w/4 Main Burners + 2 Side Burners (Combination) 88,000 24” x 96” x 46” 400 lbs.
LM210-403028M 40” + 28” Grill w/4 Main burners & 2 Side Burners + 3 Main 124,000 24” x 124”x 46” 520 lbs.

4

LM210 SERIES

MASTERPIECE GRILLS WITH MOBILE AND PATIO CARTS

This dual grill combination (LM210-403028M) is a good example of
the extent that LazyMan Inc. can extend their design and
manufacturing capabilities. The combination of grills and side
burners into a single structural unit can literally result in endless
combinations to meet your back yard requirements. While we try to
stay with ‘standards’ as shown to the left, we want every customer
to understand that we can create amazing designs to fulfill your
needs for your backyard paradise.
This grill boasts a powerful, 40”, 48,000 BTU grill on the left, a 30”,
24,000 BTU dual power side burner in the center, and a 28”, 36,000
BTU grill on the right.

LM210-403028M

40” Grill + 28” Grill w/ Dual

Side Burner

PATIO BASE

This newly designed PATIO BASE has been added to the 210 Series
line-up of unique barbeque designs and is surely out to grab the
attention of your patio quests. Its unique futuristic design proves to
be an eye catcher that is not just a pretty face. It is loaded with all of
the features that the LazyMan 210 Series Masterpiece grills are
known for. This 28” grill is a three burner, all stainless steel outdoor
gas-fired barbecue with two large side shelves.

LM210-28 Patio

28” Grill w/ Patio Cart

• All type 304 stainless steel construction.

• Three stainless steel burners (12,000 Btu ea.).

• Electronic ignition.

• Stainless Steel hood.

• 115 volt rotisserie.

• Stainless steel cooking grates.

• Stainless steel drip pan to catch grease and debris not
consumed in the cooking process.

• Stainless steel side shelves.

• Heavy Duty base with tank holder in back. Base includes a
hidden bolt-down feature for added security.

• Towel Handle Inculded.

LazyMan ‘Flavor Enhancers’ represent a unique series
of stainless steel plates placed on top of each
burner of all 210 Series grills. Their venting system
allows burner flames to pass through the plates and
at the same time catch grease and drippings coming
from the meats being cooked. This grease splatters
back up into the meat adding additional flavor and
juiciness to the meat. You can taste the difference!

LazyMan ‘Flavor Enhancers’

5

LM210 SERIES

MASTERPIECE BUILT-IN GRILLS

The LM210 Series Masterpiece Built-in Grills come in 2 basic sizes:

28” and 40” widths. These grills can be ordered without a hood, with a
standard hood, or with a roll-top hood. The roll-top hood is used when
there is limited clearance between the back of the grill and the back-drop of
the island. The roll-top hood is pictured to the left. The standard hood is
pictured on the previous page and comes standard on the Mobile Series
freestanding grills. Grills ordered without a hood come with a heavy duty
stainless steel weather cover.

The LM210 Series Masterpiece Built-in Side Burners also come

in single and double burner units. These burners come complete with
a heavy duty stainless steel weather cover.

Model LM210-40

Model LM210-30

MODEL GRILL SIZE & BURNERS BTUs OVERALL DIMS. SHIP WT.

Model LM210-20

Model LM210-28

LM210-28 28” Grill w/ 3 Main Burners 36,000 28” x 21” x 12” 73 lbs.
LM210-40 40” Grill w/ 4 Main Burners 48,000 40” x 21” x 12” 103 lbs.
LM210-20 20” Single Side Burner 20,000 16” x 21” x 12” 30 lbs.
LM210-30 30” Dual Side Burner 40,000 28” x 21” x 12” 48 lbs.
LM210-28/20 28” Grill w/ Single Side Burner 56,000 44” x 21” x 12” 97 lbs.
LM210-40/20 40” Grill w/ Single Side Burner 68,000 56” x 21” x 12” 127 lbs.
LM210-40/30 40” Grill w/ Dual Side Burner 88,000 68” x 21” x 12” 147 lbs.

MODEL HOOD OPTIONS BTUs OVERALL DIMS. SHIP WT.

LM210-28-SH 28”Grill w/ Standard Hood 36,000 28” x 21” 105 lbs.
LM210-28-RT 28” Grill w/ Roll Top Hood 36,000 28” x 21” 102 lbs.
LM210-28/20-SH 28” w/ Single Side Burner & Std Hood 56,000 44” x 21” 162 lbs.
LM210-28/20-RT 28” w/ Single Side Burner & Roll Top 56,000 44” x 21” 159 lbs.
LM210-40-SH 40” Grill w/ Standard Hood 48,000 40” x 21” 151 lbs.
LM210-40-RT 40” Grill w/ Roll Top Hood 48,000 40” x 21” 140 lbs.
LM210-40/20-SH 40” w/ Single Side Burner & Std Hood 68,000 56” x 21” 208 lbs.
LM210-40/20-RT 40” w/ Single Side Buarner & Roll Top 68,000 56” x 21” 197 lbs.
LM210-40/30-SH 40” w/ Dual Side Burner & Std Hood 88,000 68” x 21” 231 lbs.
LM-210-40/30-RT 40” w/Dual Side Burner & Roll Top 88,000 68” x 21” 220 lbs.

See page 8 for dimensions

6

LM210 SERIES

MASTERPIECE INSULATION PANELS

LM210 Series Masterpiece Insulation Panels allow for the barbecue
unit to be installed into a wood or otherwise combustible outdoor
structure. Sizes are available for all LM210 Series sizes and
combinations. The island cut-out sizes INCREASE to allow for the
additional panel thickness insert. The most popular sizes are listed
below.

GRILL MODEL INSULATION PANEL KIT P/N CUT-OUT DIMENSIONS

LM210-20 SSIK-20 18-1/8”Wx 22”D x 12-3/4“H
LM210-28 SSIK-28 30-1/4”Wx 22”D x 12-3/4“H
LM210-30 SSIK-30 30-1/4”Wx 22”D x 12-3/4“H
LM210-40 SSIK-40 42-1/4”Wx 22”D x 12-3/4“H
LM210-28/20 SSIK-28/20 48-1/8”Wx 22”D x 12-3/4”H
LM210-40/20 SSIK-40/20 60-1/8”Wx 22”D x 12-3/4”H
LM210-40/30 SSIK-40/30 72-1/4” W x 22”D x 12-3/4” H

LM210 SERIES

MASTERPIECE CUSTOM COMBINATIONS

Our versatility is one of our greatest
assets. You can customize any
grill/burner, either mobile or built in,
to create your own outdoor designer
kitchen just like the pros!

Give us a call today and we’ll help
you with your design plan.

7

ISLAND CUT-OUT DIMENSIONS / HOOD PROFILES

SEE NOTE #1

NON-COMBUSTIBLE MATERIAL ONLY

GRILL MODEL “A” “B” “C” “D” “E” “F” “G” “H” “I”

SEE NOTE #2

LM210-20 16-1/8” 21” 12” 1-1/8” 2”
LM210-28 28-1/4” 21” 12” 1-1/8” 2”
LM210-30 28-1/4” 21” 12” 1-1/8” 2”
LM210-40 40-1/4” 21” 12” 1-1/8” 2”
LM210-28/20 44-1/8” 21” 12” 1-1/8” 2”
LM210-40/20 56-1/8” 21” 12” 1-1/8” 2”
LM210-40/30 68-1/4” 21” 12” 1-1/8” 2”

ACCESSORY DESCRIPTION

BI-DRW-1 Built-In Single Drawer/Trash Bin 15-3/4” 12-3/4”
BI-DRW-2 Built-In Drawers-Double 15-3/4” 12-3/4”
BI-DRW-3 Built-In Drawers-Triple 15-3/4” 12-3/4”
AC-BIDI-28 Built-In Double Doors-28” 16” 24-1/4”
AC-BIDI-40 Built-In Double Doors-40” 16” 36-1/4”
BI-1X-DI (R) Built-In Single Door-Right Hand 16” 12-1/8”
BI-1X-DI (L) Built-In Single Door-Left hand 16” 12-1/8”
LM-VC Island Vent Cover 12” 12”

NOTE #1- THIS AREA CAN BE REMOVED AND BE USED FOR OUR FREESTANDING GRILL WITH THE SIDE SHELVES AND SIDE
BRACKETS REMOVED. CUTOUT SIZE: 28-1/4” WIDE (28” GRILL), 40-1/4” WIDE (40”GRILL) X 22” DEEP X 37 1/4” ISLAND HEIGHT.

NOTE #2- VENT CUTOUT SIZE-10” X 10”. ACTUAL VENT MEASURES 11 1/2” X 11 1/2”. ORDER PART #LM-VC.

8

MODEL A SERIES

OPEN HEARTH BUILT-INS

Model A4TS

Model A4TS

The Lazy Man Model A Series Barbecues are commercial level and are designed to
give you complete cooking control. All Model A Series Open Hearth Gas Grills have
Stainless Steel Type 304 construction chassis, insert pan, drip pan and cooking
grates. Models feature two burners per section at 20,000 BTU’s per burner and are
available in sizes from 17” to 68” long. These grills use natural lava rock and
are completely assembled. Optional stainless steel weather cover available.

The A1TS through A4TS Series Open Hearth grills have been designed for built-in
outdoor installations in masonry or other non- combustible materials. These grills are
not intended to be mounted in wood or any other combustible materials, nor are they
meant to be surface mounted.

Model A3TS

Model A3TS

Model A2TS

Model A2TS

Model A1TS

Model A1TS

The A1TS/SS through A4TS/SS Series Open Hearth grills have been designed for
surface mount applications onto non-combustible materials such as masonry, brick,
stone, and cement. All sides and rear are finished with eye-pleasing brushed
stainless steel. While these grills are meant to be surface mounted, they can also
be used as a built-in.

All Model A Series barbecues can also be ordered with a 60,000 BTU side
burner attached to the left side of the main grill. These are ordered by adding /60
to the end of the model number. Example: A3TS/P+BIG-60-U. This model is shown
below. Optional hoods are also available for all Model A Series grills and are
available in full length or partial lengths by section (1 through 4). Please add the
following suffixes to the part numbers when ordering:

-FACC (One Section Hood)

-FACC2 (Two Section Hood)

-FACC3 (Three Section Hood)

-FACC4 (Four Section Hood)

Model A1TS/B60

Utility Stove w/60,000 BTUs

SPECIFICATIONS A1TS A1TS/SS A2TS A2TS/SS A3TS A3TS/SS A4TS A4TS/SS A1TS/B60

Number of burners 2 4 6 8 1
Width 16-5/16” 32-3/4” 49” 65-1/4” 16-1/2”

Depth 21” 21” 21” 21” 21”
Height 7 ” 7 ” 7” 7” 7”
Cooking Area 16-1/4”x 16-1/4” 16-1/4”x 32-1/2” 16-1/4”x 48-3/4” 16-1/4”x 65” N/A
Cooking Area Sq.In. 264 528 792 1,056 N/A
Ship Wt. ATS 42 lbs. 85 lbs. 126 lbs. 170 lbs. 48 lbs.
Ship Wt. ATS/SS 52 lbs. 95 lbs. 136 lbs. 170 lbs. 52 lbs.

Model A3TS/P+BIG-60-U

9

MODEL A SERIES

OPEN HEARTH BUILT-INS

See Page 17

NON-COMBUSTIBLE MATERIAL ONLY

Cut-Out Dimensions

Grill Model Dim ‘A’ Dim ‘B’ Dim ‘C’

A1TS/B60 16-3/4” 21” 7”
A1TS or A1TS/SS 16-3/4” 21” 7”
A2TS or A2TS/SS 33” 21” 7”
A3TS or A3TS/SS 49-1/4” 21” 7”
A4TS or A4TS/SS 65-1/2” 21” 7”

Installation Method #1 for the Open Hearth Series grills uses a rear gas pipe exit point into the masonry island. The
masonry should be laid so that there is a horizontal notch running from front to back on the gas side, and partially back
on the non-gas side. This product is shipped with the gas side on the left and the ‘stubbed’ side on the right. This notch
should measure 1-1/2” wide by 3-1/2” high and be located at the bottom of the main cutout. On the ‘stubbed’ side of
the gas line, the notch needs only to be 2” back from the front. Reverse the notches and hole location if it is desired to
change the gas input line from the left side to the right side. With this installation method, the grill is inserted into place
from the FRONT. After the grill is in place and connected, the front portion of the notch can be covered with cover
stones as shown in the above diagram.

10

STAINLESS STEEL

ELITE SERIES GRILLS

Model A4CC/SSE-FACC2

shown with optional 2-section hood

Model A4CC/SSE - 8 burner grill

The Elite Series Grills are built entirely of heavy duty, stainless Steel Type
304 material providing a lifetime of worry free cooking. These grills all
feature heavy duty construction and chassis, insert pans, drip pans,
burners, cooking grates, side shelves, lower storage shelf, a mobile base,
heavy duty wheels, and natural lava rock. Ships completely assembled and
ready for use. Hose and regulator are included.

The Elite Series Grills feature a burner delivery system capable of
delivering fast, high heat cooking results. These grills feature
independently controlled heat zones using lava rock to create the
ultimate in barbecue flavor. Each burner boasts a very generous 20,000
BTU heat rating.

The internal firebox is designed to route excess grease and marinades
through stainless steel burner pans and into a separate drip tray.
Optional hoods are available for all size Elite grills and are available in full
length or partial lengths by section (1 through 4). Complete rotisserie
systems are also available. Please add the following suffixes to the part
number when ordering:

-FACC (One Section Hood)

-FACC2 (Two Section Hood)

-FACC3 (Three Section Hood)

-FACC4 (Four Section Hood)

Model A3CC/SSE - 6 burner grill

Model A2CC/SSE - 4 burner grill

If a rotisserie system is desired, add –ROT to the end of the above part
numbers. Example: A3CC/SSE-FACC2-ROT (A3CC/SSE grill with a two section
(partial) hood with a rotisserie system). If it is desired to add a
Big60, 60,000 BTU power burner on the far left section, add /B60 at the
end of the previous part numbers.

GRIDDLE PART NUMBERS

AC-SMSG (1 section)

AC-BMSG (2 sections)

SPECIFICATIONS A2CC- SSE A3CC- SSE A4CC- SSE

Number of burners 4 6 8
Width 56-1/2” 73” 89”
Depth 24-1/4” 24-1/4” 24-1/4”
Height 33” 33” 33”
Cooking Area 16-1/4”x 32 ½” 16-1/4”x 49” 16-1/4”x 65”
Cooking Area Square In. 528 792 1,056
Shipping Weight 165 lbs. 265 lbs. 355 lbs.

11

BIG 60 AND CHEF’S MATE

UTILITY STOVES

The Big 60 Series represents the ULTIMATE in the line of outdoor cooking stoves. Each model uses a HUGE 60,000 BTU burner(s)
creating the ultimate in power burner performance while enabling infinite adjustment of the burner. This is accomplished by the
3-ring design of the burner. Each ring can be turned on separately or turned on all together while still being able to adjust the
height of the flame with the control knob. The end result is infinite power and adjustability. The Big 60 Series is available in both
single burner and double burner construction, and available in stainless steel or durable black powder coat finish.

The Chef’s Mate Series represents a more economical line of outdoor cooking stoves and uses an 18,000 BTU single ring burner
with full adjustability. This ‘work horse’ of a cooking stove can still deliver fast, high temperature cooking while taking it easy on
your pocketbook. The Chef’s Mate Series is also available in a single burner or double burner design and comes in a durable black
powder coat finish.

• Triple control utility stove has 3-ring cast iron burners.

• Includes (1) 10,000 BTU ring, (1) 20,000 BTU ring, and (1) 30,000 BTU
ring for the HUGE total of 60,000 BTU’s per burner.

• The rugged durability of commercial construction provides a lifetime of
dependable service.

• Stainless steel models feature all stainless type 304 exterior for long
lasting beauty and durability.

• Available in single burner and double burner models. Larger models are
available upon request.

• All LP (Liquid Propane Tank) models include hose and regulator.

• All BIG 60 models include extension legs for a choice of cooking heights
of either 9” or 25” tall. Start short and later go tall when desired.

SSBIG60I Stainless Steel
Triple Ring Single Burner
Utility Stove

BIG60I Triple Ring Single
Burner Utility Stove ­High Temperature
Powder Coating

CHEF I Chef’s Mate Single
Burner Utility Stove ­High Temperature
Powder Coating

SSBIG60II Stainless Steel
Triple Ring Double
Burner Utility Stove

BIG60II Triple Ring Double
Burner Utility Stove­ Painted w/ leg extensions
installed

CHEF II Chef’s Mate
Double Burner Utility
Stove ­High Temperature
Powder Coating

12

LAZYMAN

VINYL COVERS

LazyMan offers heavy duty vinyl covers for the ultimate protection of your backyard investment. Each vinyl cover is
made to create a custom fit for your particular grill or cooking product. LazyMan offers covers for nearly every product
made by LazyMan and the most popular covers are listed in the following tables.

LM210 Series Mobil/Freestanding Grills

Grill Model Vinyl Cover Model Vinyl Cover Description Shipping Wt.

LM210-28M AC-2028 Heavy Duty Vinyl Cover for LM210-28M or MC Grill 6 lbs.
LM210-28MC AC-2028 Heavy Duty Vinyl Cover for LM210-28M or MC Grill 6 lbs.
LM210-28 Patio AC-2028 Heavy Duty Vinyl Cover for LM210-28M or MC Grill 6 lbs
LM210-28/20M AC-2028/20 Heavy Duty Vinyl Cover for LM210-28/20M or MC Grill 7 lbs.
LM210-28/20MC AC-2028/20 Heavy Duty Vinyl Cover for LM210-28/20M or MC Grill 7 lbs.
LM210-40M AC-2040 Heavy Duty Vinyl Cover for LM210-40M or MC Grill 7 lbs.
LM210-40MC AC-2040 Heavy Duty Vinyl Cover for LM210-40M or MC Grill 7 lbs.
LM210-40/20M AC-2040/20 Heavy Duty Vinyl Cover for LM210-40/20M or MC Grill 8 lbs.
LM210-40/20MC AC-2040/20 Heavy Duty Vinyl Cover for LM210-40/20M or MC Grill 8 lbs.
LM210-40/30M AC-2040/30 Heavy Duty Vinyl Cover for LM210-40/30M Grill 9 lbs.
LM210-40/30/28 MAC-2040/30/38 Heavy Duty Vinyl Cover for LM210-40/30/28M Grill 14 lbs.

LM210 Series Built-In Grills

Grill Model Vinyl Cover Model Vinyl Cover Description Shipping Wt.

LM210-28-RT AC-21028BI Heavy Duty Vinyl Cover for LM210-28-RT Grill 8 lbs.
LM210-40-RT AC-21040BI Heavy Duty Vinyl Cover for LM210-40-RT Grill 8 lbs.
LM210-28-SH AC-SSCH28BI Heavy Duty Vinyl Cover for LM210-28-SH Grill 8 lbs.
LM210-40-SH AC-SSCH40BI Heavy Duty Vinyl Cover for LM210-40-SH Grill 9 lbs.

Elite Series Mobile Grills

Grill Model Vinyl Cover Model Vinyl Cover Description Shipping Wt.

A2CC/SSE AC-VA2CC/SSE Heavy Duty Vinyl Cover for A2CC/SSE Grill 7 lbs.
A3CC/SSE AC-VA3CC/SSE Heavy Duty Vinyl Cover for A3CC/SSE Grill 8 lbs.
A4CC/SSE AC-VA4CC/SSE Heavy Duty Vinyl Cover for A4CC/SSE Grill 9 lbs.

13

MALIBU GRILL

INTRODUCING THE MALIBU GRILL - THE LATEST IN THE LINE OF INNOVATIVE PRODUCTS FROM LAZYMAN

The “Malibu” grill series is the latest product offering from LazyMan and carries on the 80 year old tradition that LazyMan has
been known for: forever lasting quality, life-long endurance, and beauty. The product series consists of the 30” grill, both
built-in and freestanding, the 42” grill, both built-in and freestanding, and matching doors and drawer combinations.

• All freestanding models come with a built-in trash bag
holder at the tip of the left side shelf.

• All freestanding models come with heavy duty, 3”
industrial swivel casters. The front casters are locking for
maximum stability.

Some of the features of the Malibu Freestanding
grill are as follows:

• All freestanding models, for LP applications, come with a
built-in sliding tank tray using heavy duty ball bearing
slides. This allows for easy access to the propane tank and
minimizes the need to ‘angle and tilt’ the tank during the
removal and exchange process.

• All freestanding models come with extra-large, folding side
shelves for easy storage.

• All freestanding models are equipped with an internal
storage shelf to conveniently store extra items such as

cooking utensils, spices, and the rotisserie motor.

Some of the key features of the Malibu grill are as
follows:

• Made entirely from heavy duty 304 stainless steel with
both a beautiful #4 brushed finish and a #8 chrome-like
finish for the front panel. All fasteners used on the grill are
also stainless.

• Powerful and new-to-the-market, 14GA stainless steel
H-Burners deliver lasting performance with a rating of
25,000 BTU’s each.

• All freestanding models come with a built-in paper towel
holder under the right side shelf.

• Grills are manufactured using all welded construction. This
means that all seams are ‘sealed’ which eliminates the
chances of ‘seepage’ of grease and marinades into the grill
body.

• 9 Volt, sealed operating system allows for reliable ignition
year after year.

• Hood light comes standard with all grills and uses an
extra-bright 10W Halogen light.

14

MALIBU GRILL

More of the key features of the Malibu Grill:

• All ‘finished’ surfaces including the main hood, the rear
hood, and the bullnose assembly are manufactured with
‘seamless’ welded construction with polished highlights,
creating a beautiful end result.

• Individual, grounded electronic igniters are used for each
burner. Push in on the desired control knob and that
burner lights.

• Hood thermometer comes standard with all grills to
measure the inside grill temperature. This allows you to
preheat and add your food product just at the right
moment for perfect cooking.

• Tilt-up rear warming rack allows you to lift up, slide over,
and move out of the way when you need a little more

room for flipping your burgers.

• Stainless steel, heavy duty cooking grates- for when the
grilling gets large and heavy.

• Optional rotisserie system includes a rear 15,000 BTU
infra-red burner, heavy duty stainless spit rod, spit forks,
and a quiet rotisserie motor.

• Optional, adjustable,
23,000 BTU infra-red main
sear burner for high
temperature cooking.
Allows heat adjustment
down to the slightest levels
for cooking thin meats,
fish, and vegetables.

15

• Easy slip-in island
installation with beautiful
results. Add the optional
door and drawer
combinations and you are
ready to enjoy your new
back-yard kitchen and a
touch of paradise.

MALIBU GRILL

MODELS AND MODEL NUMBERS

MODEL DESCRIPTION BTUs

LM30 30” Built-In Grill 50,000
LM30R 30” Built-in Grill w/ Rotisserie 65,000
LM30S 30” Built-in Grill w/ Sear Burner 48,000
LM30RS 30” Built-in Grill w/ Sear and Rotis. 63,000
LM30FS 30” Freestanding Grill 50,000
LM30RFS 30” Freestanding w/ Rotisserie 65,000
LM30SFS 30” Freestanding w/ Sear Burner 48,000
LM30RSFS 30” Freestanding w/ Sear and Rotis. 63,000

MODEL DESCRIPTION BTU’S

LM42 42” Built-In Grill 75,000
LM42R 42” Built-in Grill w/ Rotisserie 90,000
LM42S 42” Built-in Grill w/ Sear Burner 73,000
LM42RS 42” Built-in Grill w/ Sear and Rotis. 88,000
LM42FS 42” Freestanding Grill 75,000
LM42RFS 42” Freestanding w/ Rotisserie 90,000
LM420SFS 42” Freestanding w/ Sear Burner 73,000
LM42RSFS 42” Freestanding w/ Sear and Rotis. 88,000

30” Primary and Secondary Cooking Area: 750 Sq. In.

42” Primary and Secondary Cooking Area: 1077 Sq. In.

16

MALIBU 42” FREESTANDING GRILLMALIBU 30” FREESTANDING GRILL

MALIBU SERIES

BUILT-IN APPLICATION REQUIREMENTS AND CUTOUTS

NON-COMBUSTIBLE MATERIAL ONLY

ISLAND CUT-OUT DIMENSIONS

MODEL DESCRIPTION “A” “B” “C” “D” “E” “F” “G”

LM30 30” MALIBU GRILL- BUILT-IN 29” 21 5/8” 10 1/2”
LM42 42” MALIBU GRILL- BUILT-IN 41” 21 5/8” 10 1/2”
BI-DWR-1 BUILT-IN DRAWERS- TRASH BIN 15 3/4” 12 3/4”
BI-DWR-2 BUILT-IN DRAWERS- DOUBLE 15 3/4” 12 3/4”
BI-DWR-3 BUILT-IN DRAWERS- TRIPLE 15 3/4” 12 3/4”
AC-BIDI-28 BUILT-IN DOUBLE DOORS-28” 16” 24 1/4”
AC-BIDI-40 BUILT-IN DOUBLE DOORS-40” 16” 36 1/4”
BI-1X-DI (R) BUILT-IN SINGLE DOOR-RIGHT 16” 12 1/8”
BI-1X-DI (L) BUILT-IN SINGLE DOOR- LEFT 16” 12 1/8”

NOTE #1- THIS AREA CAN BE REMOVED AND BE USED FOR OUR FREESTANDING GRILL WITH THE SIDE SHELVES AND SIDE
BRACKETS REMOVED. CUTOUT SIZE: 30-1/4” WIDE (30” GRILL), 42 1/4” WIDE (42”GRILL) X 22” DEEP X 37 1/4” ISLAND HEIGHT.

NOTE #2- VENT CUTOUT SIZE-10” X 10”. ACTUAL VENT MEASURES 11 1/2” X 11 1/2”. ORDER PART #LM-VC.

17

MALIBU SERIES

BUILT-IN GRILL OVERALL DIMENSIONS

Malibu 30” Built-in Malibu 42” Built-in

18

MALIBU SERIES

FREESTANDING GRILL OVERALL DIMENSIONS

Malibu 30” Freestanding

Malibu 42” Freestanding

19

MALIBU SERIES

DOORS

Stainless Steel Double Door Insert-28”
Model AC-BIDI-28

LazyMan stainless steel double door inserts are
made from the identical 304 Stainless Steel we
make all our grills from. The double doors are
designed for any type of built-in architecture you
may have. The outer trim edge will finish off the
opening for a smooth sleek finish to your project.
It fits perfectly under our LM30 Malibu Grill, LM210-28
or LM 210-30 units.
Cutout size: 24.25" Wide x 16” High
Finished size: 27.5” Wide x 19.5” High

Stainless Steel Double Door Insert-40”
Model AC-BIDI-40

Stainless steel extra wide double door inserts are
ideal for larger requirements and are perfect for
mounting under the LM42 Malibu grill or the
LM210-40 series grills.
Cutout size: 36.25” Wide x 16” High
Finished size: 39.5” Wide x 19.5” High

Left Stainless Steel Door Insert
Model BI-1X-DI (L)

The left 304 grade stainless steel doors are the
highest quality door inserts available on the market
today. Mix and match the left, right and double
doors to create outdoor kitchen of your dreams.
The thick heavy duty construction will guarantee that
you will still love your doors for decades to come.
Cutout size: 12.125” Wide x 16” High
Finished size: 17.875” Wide x 19.5” High

Right Stainless Steel Door Insert
Model BI-1X-DI (R)

The right 304 grade stainless steel doors are the
highest quality door inserts available on the market
today. Mix and match the left, right and double
doors to create outdoor kitchen of your dreams.
The thick heavy duty construction will guarantee that
you will still love your doors for decades to come.
This door will fit perfectly under our LM 210-20 side
burner for added storage.
Cutout size:: 12.125” Wide x 16” High
Finished size: 17.875” Wide x 19.5” High

20

MALIBU SERIES

DRAWERS

Stainless Steel Drawer Combination Insert with
3 Drawers
Model BI-DRW-3

Mix and match these ultra-high quality drawer
combinations with other drawers and/or door
configurations to create your ultimate in outdoor
kitchen storage. Drawers use the same thick, heavy
duty construction as the LazyMan doors to provide
lasting durability. Heavy duty, outdoor ball bearing
drawer slides are standard on all drawers.

• Cutout size: 12.75” Width x 15.75” High

• Finished size: 16” Wide x 19.5” High x 21.5”
Deep. Upper 2 drawers: 3.75” High, Lower
drawer: 7.62” High, both 20.50” Deep

Stainless Steel Drawer Combination Insert with
2 Drawers
Model BI-DRW-2

This 2-drawer combination has the same external
dimensions as the 3-drawer and 1-drawer
combination.

• Cutout size: 12.75” Wide x 15.75” High

• Finished size: 16” Wide x 19.5” High x 21.5”
deep. Both drawers: 7.62” High x 20.50” Deep

Stainless Steel Ultra-Deep Drawer and Trash
Receptacle
Model BI-DRW-1

This single deep drawer model is used as a
convenient method to place trash while you are
creating your outdoor grilled masterpiece. This
drawer comes complete with 2 removable, plastic
waste containers for easy clean-up.

• Cutout size: 12.75” Wide x 15.75” High

• Finished size: 16” Wide x 19.5” High x 21.5”
deep. Drawer: 15.25” High x 20.50” Deep

21

MALIBU SERIES

ACCESSORIES

Stainless Steel Island Vent Cover
Model LM-VC

The Island Vent Cover is designed to allow the
exact venting size for built-in grill island
applications. This vent cover uses the same,
beautiful, brushed stainless material as all other
LazyMan grills and accessories. Proper venting
requires (3) vents 10” x 10” or 100 sq, in. each to
be placed on both sides and back of the
Bar-B-Que island.

• Cutout size: 10” x 10”

• Finished size: 11.50” x 11.50”

Stainless Steel Island Tank Tray
Model LM-ITT

The Island Tank Tray provides a convenient
method of handling the propane tank cylinder for
island LP applications. Made from brushed
stainless steel, this tank tray allows easy sliding in
and out of the propane tank through an opening cut
in the island. This opening is commonly bordered
by and either one of the LazyMan double access
door models. Please note that the door frame
opening must be level with the island bottom
surface. This tray is equipped with heavy duty
outdoor rated drawer slides.

Vinyl Cover for Malibu 30” Built-in
Model LMVC-30BI

Custom Vinyl Covers are made specifically to fit the
Malibu series 30” Built-In grill. Covers are made of
heavy duty grey vinyl with fabric backing and are
elastic bound for a tight custom fit. All covers come
with the LazyMan logo printed in black and will
provide years of protection to protect your backyard
investment.

22

MALIBU SERIES

VINYL COVERS

Vinyl Cover for Malibu 42” Built-in
Model LMVC-42BI

Custom Vinyl Covers are made specifically to fit the
Malibu series 42” Built-In grill. Covers are made of
heavy duty grey vinyl with fabric backing and are
elastic bound for a tight custom fit. All covers come
with the LazyMan logo printed in black and will
provide years of protection to protect your backyard
investment.

Vinyl Cover for Malibu 30” Freestanding
Model LMVC-30FS

Custom Vinyl Covers are made specifically to fit the
Malibu series 30” Freestanding grill. Covers are
made of heavy duty grey vinyl with fabric backing
and come with a front Nylon zipper for easy
covering and uncovering. Freestanding models also
come with a rear vinyl vent. All covers come with
the LazyMan logo printed in black and will provide
years of protection to protect your backyard
investment.

Vinyl Cover for Malibu 42” Freestanding
Model LMVC-42FS

Custom Vinyl Covers are made specifically to fit the
Malibu series 42” Freestanding grill. Covers are
made of heavy duty grey vinyl with fabric backing
and come with a front Nylon zipper for easy
covering and uncovering. Freestanding models also
come with a rear vinyl vent. All covers come with
the LazyMan logo printed in black and will provide
years of protection to protect your backyard
investment.

23

Over 85

Years of

Excellence

All LazyMan products are proudly MADE IN THE U.S.A.

Brian Sadowski

President

LazyMan Inc.

www.lazyman.com

908.475.5315

800.475.1950
