LAZER Z1 User Manual

Z1 LED MUDCAP

Lamorinièrestraat 33-37

2018 Antwerp - Belgium

www.lazersport.com

5. How to change the batteries

battery

battery insulator

battery

Turn

1

Lift up

2

Replace

3

USER MANUAL

USER MANUAL

1. Remove the plastic battery insulation tab prior to use 3. Install the mudcap into the helmet

4. Light mode2. Insert the led into the mudcap

Z1 LED MUDCAP

battery

battery insulator

battery

1- STILL MODE

2 - FLASHING MODE #1 3 - FLASHING MODE #2 4 - FLASHING MODE #3

5 - OFF

battery

battery insulator

battery

1- STILL MODE

2 - FLASHING MODE #1 3 - FLASHING MODE #2 4 - FLASHING MODE #3

5 - OFF

battery

Turn

1

Insert the lower tongue of the mudcap into the groove of the led

1

Insert

1

Press the button

PRESS 3 SECONDS

1

Lift up

2

Gently lift the upper section of the mudcap, whilst rotating the led into position

2

Push and click in

2

Pull it out

3

The led is now ﬁrmly installed into the mudcap

3
