For HELP, call La-Z-Boy
2012 OWNER’S MANUAL
Seduce
® Spas at 1.800.465.2933.
3180220
La-Z-Boy® Spas - Sales & Marketing Division
4411 Bee Ridge Road. # 299
Sarasota, Florida 34233
1.800.465.2933
www.lazboyspas.com
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
La-Z-Boy® Classic Spas
Owner’s Manual
Table of Contents
Safety Information…………………………………………………………………………. 3
Guarantee………………………………………………………………………………….. 7
Introduction…………………………………………………………………………………. 9
Model Overview……………………………………………………………………………. 10
Location and Installation…………………………………………………………………... 12
Electrical Specifications…………………………………………………………………… 15
Start Up……………………………………………………………………………………... 21
Water Quality……………………………………………………………………………….. 26
In-Touch 1000 Controls…………………………………………………………………… 29
Color Coordinated Cover………………………………………………………………….. 31
Water Management………………………………………………………………………... 32
Frequently Asked Questions……………………………………………………………… 33
Troubleshooting……………………………………………………………………………. 36
Maintenance and Care……………………………………………………………………. 41
Shutdown / Winterization………………………………………………………………….. 44
Glossary…………………………………………………………………………………….. 45
Notes………………………………………………………………………………………... 46
Important: La-Z-Boy Spas is dedicated to offering you the best in customer
satisfaction and service. Be sure to read, complete, sign, and send in the guarantee
card within 30 days of purchase to ensure you understand what you are entitled to
in terms of service. If you have any questions, you can call your local dealer for more
information.
Version 1.0
Copyright © 2011 La-Z-Boy® Spas. All rights reserved. No portion of this manual may be reproduced in
any manner without express written permission from La-Z-Boy Spas.
La-Z-Boy
Ontario Inc.
La-Z-Boy Spas may make product modifications and enhancements. Specifications may change without
notice. International products may be configured differently to meet local electrical requirements.
Dimensions are approximate.
®
is a registered trademark of La-Z-Boy Incorporated and is used under license to 2217044
2
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
Important Safety Instructions and Warnings
Read and Follow All Instructions
To reduce the risk of injury, do not permit children to use this product un-
less they are closely supervised at all times.
Warning: Children should NOT
use a spa / hot tub without alert
adult supervision.
Warning: Do not use spas or hot
tubs unless all suction guards
are installed to prevent body and
hair entrapment.
Warning: People using medications and/or having an adverse medical history should
consult a physician before using
spa or hot tub.
Warning: Do not use drugs or
alcohol before or during the use
of a spa or hot tub, to avoid
unconsciousness and possible
drowning.
Warning: Pregnant or possibly
pregnant women should consult
a physician before using a spa or
hot tub.
Warning: Water temperature in
excess of 38°C may be injurious
to your health.
Warning : People with infectious
diseases should not use a spa or
hot tub.
Warning: To avoid injury,
exercise care when entering or
exiting the spa or hot tub.
Warning: Before entering the
spa or hot tub, measure the
water temperature with an accurate thermometer.
Warning: Do not use a spa or
hot tub immediately following
strenuous exercise.
SAVE THESE INSTRUCTIONS
3
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
Important Safety Instructions and Warnings
Read and Follow All Instructions
To reduce the risk of injury, do not permit children to use this product un-
less they are closely supervised at all times.
Warning: Prolonged immersion
in a spa or hot tub may be
injurious to your health.
Warning: Do not permit or use
electric appliances (such as a
light, telephone, radio or
television) within 1.5 meters of
spa or hot tub.
Caution: Maintain water
chemistry in accordance with the
manufacturer’s instructions.
HYPERTHERMIA
Hyperthermia occurs when the
internal temperature of the body
reaches a level several degrees
above the normal body
temperature of 37°C. The
symptoms of hyperthermia
include:
1) Unawareness of impending
hazard;
2) Failure to perceive heat;
3) Failure to recognize the need
to exit the spa or hot tub;
4) Physical inability to exit the
spa or hot tub;
5) Fetal damage in pregnant
women; and
6) Unconsciousness and
resulting in the danger
of drowning.
Warning: The use of alcohol or
drugs can greatly increase the
risk of fatal hyperthermia
in hot tubs or spas
.
SAVE THESE INSTRUCTIONS
4
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
Warning Sign
Warning Sign Must Be Posted – The orange WARNING sign like the one shown is
packed with your new spa / hot tub. This sign must be posted in a prominent place in
close proximity to the spa installation site immediately upon completion of spa
installation.
Important: It is extremely important that this sign be permanently placed in clear view
of persons using the spa / hot tub. Occasional spa / hot tub users may not be aware of
some of the dangers hot water poses to pregnant women, small children, seniors, and
people under the influence of alcohol. If you did not receive a warning sign or your
sign has become damaged, please call your local dealer for a replacement.
5
Dealer:
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
Date Purchased:
Company:
Address:
Telephone:
Installer:
Date Installed:
Company:
Address:
Telephone:
Spa:
Date Delivered:
Serial Number:
Model:
Color:
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
__________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
___________________________________________________________________
Your unique spa / hot tub serial number is located on a data plate on the back of the
equipment access door below the topside control panel. When calling for service,
please have your serial number in hand.
6
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
7
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
8
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
Introduction
Your choice of a La-Z-Boy® Classic Spa indicates that you are devoted to excellence.
The management and staff appreciate your patronage and take pride in the tradition of
quality spas / hot tubs that our company represents.
To properly acquaint yourself with your spa / hot tub, we suggest that you take time to
read through this manual before hook up and operation. Doing so will familiarize you
with important operating and safety procedures, thereby ensuring an enjoyable
experience right from the start.
If you need any more information than this manual provides, feel free to call your local
dealer or visit our web site at www.lazboyspas.com.
WARNING: This manual was written to ensure the proper use and
installation of your spa / hot tub. Any modifications to the
procedures outlined in this manual may result in voiding your
guarantee.
This manual and its contents are subject to change without notice. Although we have
prepared this manual as accurately as possible, we are not liable for errors or
omissions; loss, injury, or damages caused by improper installation; or use of spa / hot
tub (improper or otherwise).
Notes:_______________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
_____________________________________________________________________
9
For HELP, call La-Z-Boy
Seduce - 120V Operation
® Spas at 1.800.465.2933.
Model Overview
Dimensions:
Seats:
Water Jets:
Capacity:
Dry Weight:
Filled Weight:
Electrical:
GFCI:
84”L x 84”W x 35”D
5
30
251 USG / 950L
400 Lbs / 182 kg
2500 Lbs / 1134 kg
120VAC 15A 60Hz
15A GFCI and cord Included
10
For HELP, call La-Z-Boy
Seduce - 240v Operation
® Spas at 1.800.465.2933.
Model Overview
Dimensions:
Seats:
Water Jets:
Capacity:
Dry Weight:
Filled Weight:
Electrical:
GFCI:
84”L x 84”W x 35”D
5
30
251 USG / 950L
400 Lbs / 182 kg
2500 Lbs / 1134 kg
240 VAC 50A 60Hz
50 Amp (Not Included)
11
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
Location and Installation
Proper planning is an important consideration when installing your new spa / hot tub.
Site selection is a critical step and requires serious thought. Planning ahead makes the
installation process easier. The following information is provided to assist you in site
preparations.
1. Always comply with local building codes and obtain any necessary permits. You
may also need to consult with an engineer to address your specific design
needs.
2. Contact an electrician to assess your electrical needs, install wiring, and assure
a safe operation.
3. Position your spa / hot tub with proper access to water, drainage, and electricity.
4. Place your spa / hot tub on a uniform solid, flat surface designed to properly
support its weight. For external installations, a 4-inch (10 cm) thick cement pad
suffices. See page 14 for conduit entry locations for your model spa.
5. For internal installations, check the load carrying capabilities of the floor on
which the spa will reside. Most homes meet the requirement of 80 pounds per
square foot.
6. Assure that your spa / hot tub will fit into the space you have chosen and the
delivery route will accommodate its large size.
7. Provide adequate ventilation for the humidity created by your spa / hot tub. In
most cases, the Color Coordinated Cover is sufficient.
8. Protect the pump and all equipment from the weather by ensuring the cabinet
panels are secure at all times.
9. Allow 6 inches (10 cm) of unobstructed access to all sides (front 36 inched / 1
meter) of your spa / hot tub for normal servicing. Your spa / hot tub is not designed to be recessed in the ground or in a deck.
12
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
Location and Installation
Figure 1 – Clearances and Support
13
For HELP, call La-Z-Boy
® Spas at 1.800.465.2933.
The following dimensions can be used to determine the proper location of submerged
conduits in concrete slab installations. All dimensions are made from the outside of the
spa / hot tub. The topside control panel is shown at bottom of the diagram for
reference.
A
B
Figure 2 – Conduit Entry Location Reference Points
Model Dimension A Dimension B
Seduce
30” / 76 cm 8” / 20 cm
Table 1 – Conduit Entry Location Dimensions
10. Consider positioning your spa / hot tub out of or adequately protecting it from
the wind. Just as people can get cold on cool / windy days so can your spa / hot
tub. Windy environments can significantly increase operating costs.
11. Consider using an insulating pad. In cold climates, the gr ound can rob heat from
the spa / hot tub and increase your operating costs. Consider using a suitable,
outdoor insulating pad in such environments.
14
Loading...
