lasertools 7588 Instruction Manual

5 018341 075880

Our products are designed to be used correctly and with care for the purpose for which they are intended.
No liability is accepted by The Tool Connection for incorrect use of any of our products, and the Tool
Connection cannot be held responsible for any damage to personnel, property or equipment when using
the tools. Incorrect use will also invalidate the warranty.

If applicable, the applications database and any instructional information provided has been designed
to offer general guidance for a particular tool’s use and while all attention is given to the accuracy of the
data no project should be attempted without referring first to the manufacturer’s technical documentation
(workshop or instruction manual) or the use of a recognised authority such as Autodata.

It is our policy to continually improve our products and thus we reserve the right to alter specifications and
components without prior notice. It is the responsibility of the user to ensure the suitability of the tools and
information prior to their use.

7588

Engine Timing Tool Kit

Audi/VW 3.0TDI Diesel

7588_Instructions_v3

Guarantee

If this product fails through faulty materials or workmanship, contact our
service department direct on: [phone]. Normal wear and tear
are excluded as are consumable items and abuse.

Distributed by The Tool Connection Ltd

Kineton Road, Southam, Warwickshire CV47 0DR
T [phone] F [phone]
[e-mail] www.toolconnection.co.uk

www.lasertools.co.uk

• Engine applications include: Audi A4, A5, A6, A7, A8, Q5, Q7
VW Amorak; all from 2014 onwards.

• 3.0L TDI Engines.

• Equivalent to OEM tools:
T10060A, T40310, T40237, T40316, T40245, 3359, T40049.

• For sprocket and pulley holding tools, see Laser 7279.

www.lasertools.co.uk

Components

Designed to allow the engine timing to be set and checked on the Audi and Volkswagen 3.0L
TDi diesel engines listed. The 7588 is a 9 piece kit which provides all the timing tools required
for chain removal, timing checking and setting.

Note: Use in accordance with OEM instructions only.

C

F

A

D

B

E

G

Ref Code OEM Description

A C283 T10060A Camshaft gear locking pins x2

B C922 T40310 Intermediate sprocket holding and turning tool

C C043 T40237 Crankshaft locking pin

D C282 T40316 Tensioner locking pins x2

E C923 T40245 High pressure fuel pump sprocket locking tool

F C216 3359 Balance shaft locking pin

G C408 T40049 Crankshaft turning tool

2 7
