lasertools 4346 Instruction Manual

Engine Timing Tool Kit

VAG 1.4, 1.9, 2.0 TDI PD

1.2, 1.6, 2.0 TDI CR

Part No. 4346

www.lasertools.co.uk

Introduction

Provides the essential camshaft, crankshaft and tensioner setting tools for
the popular VAG designed 1.4, 1.9 and 2.0 TDi PD and 1.2, 1.6 and 2.0 TDI
CR diesel engines from 2002 to 2015. See engine code application list.

Plan Layout

Ref. Comp. Code OEM Ref. Description

A C157 T10050 Crankshaft Locking Tool

B C304 T10100 Crankshaft Locking Tool

C C216 VW3359, T20102 Camshaft Pulley Locking Pins

D C283 T10060, T10060A Tensioner Pin, Auxiliary Drive

Belt

E C282 T10115 Tensioner Pin, Cambelt
