MOTORCYCLE AL ARM SYSTEMS
®
GB
850H-850T USER GUIDE
OPERATING INSTRUCTION
BUTTON 1 BUTTON 2
Pict. 1
ALARM ARMING: Push button no.1; arming is
signalled by two flashes of the direction lights.
After 30 seconds all sensor circuits are active,
except the ignition circuit which is instant after
IF LED FLASHES WHILST
PRESSING A REMOTE BUTTON
THIS INDICATES THAT THE
INTERNAL BATTERY IS GETTING
LOW
arming.
ALARM DISARMING: Push button no.1; disarming is signalled by one flash of the direction
lights and one acoustic signal.
PANIC FUNCTION: Pressing the button no .2 you will activate the siren for 10 seconds. If you wish
to stop it during this time, push it again.
ALARM CONDITIONS SIGNALLING
If any alarm conditions occurred while you where away from the motorcycle: DURING DISARMING, look
at the direction light:
SHORT FLASH OF DIRECTION LIGHT: an alarm conditions occurred.
LONG FLASH OF DIRECTION LIGHT: no alarm conditions occurred.
SENSORS TEST
Arm the alarm by remote handset.
CONTACT SENSORS: wait 30" before activing the contact switch connected to the grey wire.
ANTILIFT SENSOR: after 30" tilt the motocycle.
IGNITION SWITCH SENSOR: Turning ON the ignition switch will cause an alarm condition and the
engine will not start.
Every test will cause an alarm condition: siren will sound for 30 seconds, and then reset for 10
seconds; after this time alarm system will be ready for any other alarm condition.
AUTOCODE PROCEDURE
To code a new remote handset or to delete a lost one, you need a functioning trasmitter.
1) Disarm the alarm with the remote handset;
2) Connect WHITE-RED wire to ground;
3) Turn ON the ignition switch;
4) The LED mounted on the motorcycle will turns on and remains on, indicating the self-learning
condition.
5) Press button no.1 of the original remote control followed by the next remote controls you wish to code.
Acceptance of the code of each remote control is indicated by the LED extinguishing for 1 second
and then re-illuminating. You can code a maximum of four remote handsets.
6) At the end of these operations turn OFF the ignition switch, disconnect WHITE-RED wire and test all
.
the coded remote handsets.
If you haven't any functioning remote, you must call your nearest LASERLINE area dealer.
Power supply........................................................................................................................12V DC
Current draw with alarm ON ............................................................................................... <6 mA
Current draw with alarm OFF ............................................................................................... <5mA
Stop engine relay contacts capacity ............................................................................................. 7A
NOTE: Manufacturer declines any responsability for damage or malfunction of the alarm and the vehicle
electrical system due to WRONG INSTALLATION OR TAMPERING.Alarms are only a deterrant against
any theft from or of the motorcycle.LASERLINE RESERVES THE RIGHT TO EFFECT CHANGES OF THE
PRODUCT WITHOUT FURTHER NOTICE.
TECHNICAL DATA:
Dealer Stamp
