Laser CDBB-166-SLV Datasheet

1

USER MANUAL

GHETTO BLASTER

CD BOOMBOX

CDBB-166-SLV

2

IMPORTANT SAFETY INSTRUCTIONS:

1. Read the instructions.

2. Keep the instructions for future use.

3. The device must not be used near water.

4. Make sure no liquid is spilled onto the device.

5. Move the device carefully to avoid shocks.

6. Do not block the device outputs.

7. Do not place the device near a heat source (e.g. radiator). Do not expose it to the sun.

8. Plug the device as instructed in this guide.

9. This product has a connection with overload protection device (security device).

10. The cord should be unplugged after a long period of use.

11. Device should be repaired by a qualified person when:
a. Power cord is damaged,
b. objects have fallen into the apparatus or a liquid has been spilled onto the device,
c. device was exposed to rain,
d. device does not work correctly without notable exterior change,
e. device falls and the subwoofer is broken.

12. The user shall not try to maintain device beyond that which is described in this

information form. The guarantee would be negated.

3

LOCATION OF CONTROLS
MAIN UNIT

1) Handle

2) On/Standby button

3) TS (Track Separation) / Play Mode button

4) Memory/Clock-Adjust button

5) Standby LED indicator

6) LCD display

7) Stop /St-Mono button

8) Play/Pause button

9) Preset EQ button

10) USB Socket

11) 3.5mm Aux-in jack

12) 3.5mm Headphone jack

13) Function button

14) Sleep/Timer button

15) PRE/FOLDER button

16) Volume knob

17) Skip/Tuning Up /Down button

18) CD door

19) Speaker

20) FM rod antenna

21) AC socket

22) Battery compartment

23) Record button

Caution:

This unit should not be Adjusted or repaired by anyone except the qualified service personnel.

Important:

Since the movement of the CD mechanism and the sensitive circuitry may cause interference to the radio

tuner nearby, please switch this unit off while operating other radio devices.

Precautions for use
Installation

• Unpack all parts and remove protective material.

• Do not connect the unit to the mains before checking the main voltage and before all other connections

have been made.

• Do not cover any vents and make sure that there are several centimeters of space around the unit for

ventilation.

AC Connection

1. Connect the detachable power cord to the AC socket (21) and the other end to the AC outlet.

2. When you first plug the unit into the mains, the unit will go into standby mode.

3. Press the On/Standby button (2) to turn on the unit. If the LCD display (6) is on with backlighting, it

means the power supply is normal. Now your system is ready to play music.

DC connection

For DC operation, please insert 8 pcs size C (UM-2) batteries into the compartment (22) as below direction

and unplug the AC socket (21) during operating with battery.
